Sealey CST983.V2 User manual

SACK TRUCKS
MODEL NO’S: CST983.V2, CST986.V2, CST987.V2,
CST988.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
CST983.V2 CST986.V2 CST987.V2 CST988.V3 Issue 3 (H,3,F) 28/06/23
Original Language Version
© Jack Sealey Limited
Refer to
instructions
1. SAFETY
9Always load evenly with the centre of gravity of the load as near the centre and rear of the plate as possible.
9Obtain additional support for large or wide loads to prevent tipping.
8DO NOT overload the truck - see Specification.
8DO NOT leave unattended, especially when loaded, unless the wheels are chocked or the truck is otherwise secured.
8DO NOT use truck on uneven ground and do not run over curbs or steps - use a ramp.
8DO NOT allow others to ride on the truck.
8DO NOT use the truck if any part is damaged, paying particular attention to the wheels.
2. INTRODUCTION
Strong tubular steel construction with welded joints. Heavy-duty wheels feature steel inserts for added
strength and durability. Can be rested on handles for at loading. Fitted with rubber handgrips.
3. SPECIFICATION
Model No: CST983.V2 CST986.V2 CST987.V2 CST988.V3
Capacity: 150kg 200kg 200kg 250kg
Height(s): 1170mm 1100mm 1190mm 1260mm
Overall Width: 460mm 550mm 545mm 560mm
Platform Depth: 220mm 180mm 255mm 220mm
Wheel Size: Ø210mm Ø250mm Ø250mm Ø250mm
Wheel Width: 50mm 90mm 90mm 90mm
4. ASSEMBLY
4.1. WHEELS
4.1.1. Ensure axle is clean from dust and dirt to allow free movement of the wheel.
4.1.2. For Model No’s. CST987.V2 and CST988.V3 the axle (fig.1.1) needs to be put through the frame before the wheels can be attached.
4.1.3. Slide the wheel (fig.1.2) onto the axle, put on the washer (fig.1.3) and complete by pushing the split pin (fig.1.4) through the hole in the end of
the axle and bending over to retain.
4.1.4. Repeat for the other side.
5. FEATURES
5.1. Model CST983.V2 has solid tyres whilst Models CST986.V2, CST987.V2, & CST988.V3 have pneumatic tyres.
5.2. CST983 can be rested on its handles for at loading.
5.3. CST988 is a case carrying model with a high back, ‘P’ handle and at loading capabilities.
g.1

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 [e-mail] www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Parts support is available for this product. Please log on to www.sealey.co.uk, email [e-mail] or telephone [phone]
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste.All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations. REGISTER YOUR
