Sealite SL-75 Supplement

Version 1.4
SL-75
3-5NM+ Solar Marine Lantern
Installation & Service Manual

Latest products and information available at www.sealite.com
2
SL-75
3–5NM+ Solar Marine Lantern
SL-75
3-5NM+ Solar Marine Lantern
PCD 200
PCD 162
PCD 150
3 x 7
4 x 4
16 X 15 Slots
6 Places
314
158
114.55
114.55
190.7
4 x 4.00 THRU
PCD 150.00
Lens and base
moulded from
UV-stabilised
LEXAN®
polycarbonate
Large industry
standard 200mm bolt
pattern for ease
of installation. Optional
bases available
Dual internal
high-performance solar
modules
Internal
user-replaceable
battery in sealed
compartment
Single LED Optic

Latest products and information available at www.sealite.com
3
SL-75
3–5NM+ Solar Marine Lantern
Table of Contents
Introduction....................................................................................................... Page 4
Operating Principle .......................................................................................... Page 4
Technology........................................................................................................ Page 4
SL-75 Model ...................................................................................................... Page 5
Installation......................................................................................................... Page 6
Selecting an Intensity/Power Setting.............................................................. Page 7
Selecting a Flash Code .................................................................................... Page 7
Flash Codes ...................................................................................................... Page 8
Optional IR Remote Control .......................................................................... Page 14
Sealite IR Controller / Universal Remote Compatibility.............................. Page 14
IR Controller Functions.................................................................................. Page 15
Test Mode / Configure................................................................................. Page 15
Normal Operation........................................................................................ Page 15
Read ........................................................................................................... Page 15
Flash Code.................................................................................................. Page 15
Flash Code Numbers.................................................................................. Page 16
Intensity....................................................................................................... Page 16
Battery Status ............................................................................................. Page 16
Lux .............................................................................................................. Page 16
Error / Acknowledge Indication ................................................................... Page 18
Configuration Settings................................................................................. Page 18
Hibernation Mode (Advanced Users).......................................................... Page 19
Storage Mode (Advanced Users)................................................................ Page 20
Operational Mode ....................................................................................... Page 21
Optional GPS Synchronisation ..................................................................... Page 22
Optional AvMesh® Monitoring & Control System....................................... Page 23
Optional GSM Monitoring & Control System............................................... Page 23
Fixed Structure Orientation........................................................................... Page 23
Maintenance and Servicing ........................................................................... Page 24
Trouble Shooting ............................................................................................ Page 25
Sealite LED Light Warranty ........................................................................... Page 26
Version No. Description Date Author Approved
1.0 Launch Jan 2017 C.Bernardo M.Nicholson
1.1 Spec Update Feb 2017 B.Gielen M.Nicholson
1.2 Sim Card Install. April 2017 A.Dixon M.Nicholson
1.3 Spec Update May 2017 C.Bernardo M.Nicholson
1.4 Operational Mode June 2017 B.Gielen M.Nicholson
1.5 Update Dip Switches April 2019 M.Dutka M.Nicholson

Latest products and information available at www.sealite.com
4
SL-75
3–5NM+ Solar Marine Lantern
Introduction
Congratulations! By choosing to purchase a Sealite lantern you have become the owner of
one of the most advanced LED marine lanterns in the world.
Sealite Pty Ltd has been manufacturing lanterns for over 25 years, and particular care has been taken to
ensure your lantern gives years of service.
As a commitment to producing the highest quality products for our customers, Sealite has been independently
certified as complying with the requirements of ISO9001:2008 quality management system.
Sealite lanterns comply with requirements of the US Coast Guard in 33 CFR part 66 for Private Aids To
Navigation.
By taking a few moments to browse through this booklet, you will become familiar with the versatility of your
lantern, and be able to maximise its operating function.
Operating Principle
The solar module of the lantern converts sunlight to an electrical current that is used to charge the battery. The
battery provides power to operate the lantern at night.
The flasher unit has very low current requirements. A microprocessor drives an ultra bright LED through a
through a DC/DC converter, which enables the LED’s to operate within the manufacturer’s specifications. The
battery is protected from over-charging within the circuit to ensure maximum battery life.
On darkness, the microprocessor will initiate a program check and after approximately 1 minute begin flashing
to the set code
Technology
Sealite is the world’s fastest growing manufacturer of marine aids to navigation. We
employ leading mechanical, optical, hardware & software engineers to create innovative
products to service the needs of our customers worldwide, and offer the widest range of
solar-powered LED lanterns in the marketplace.
Electronics
Sealite employs leading in-house electronic engineers in the design and development of software and related
circuitry. All individual electronic components are sourced directly by Sealite procurement staff ensuring that
only the highest quality components are used in our products.
LED Technology
All marine lanterns use the latest advancements in LED (Light Emitting Diode) technology as a light source.
The major advantage of LED’s over traditional light sources is well established in that they typically have an
operational life in excess of 100,000 hours, resulting in substantial savings to maintenance and servicing
costs.
Precision Construction
Commitment to investing in the design and construction of injection-moulded parts including optic lenses, light
bases and a range of other components ensures that all Sealite products are of a consistent & superior quality.
Optical Performance
Sealite manufactures a range of marine LED lenses moulded from multi-cavity dies. The company has
superior in-house lens manufacturing capabilities to support outstanding optical performance.
Award-winning, Patented Technology
Several United States and Australian patent registrations are held on Sealite’s range of innovative designs,
with other regional patents pending in Canada, United Kingdom and Europe.

Latest products and information available at www.sealite.com
5
SL-75
3–5NM+ Solar Marine Lantern
SL-75 Model
The Sealite SL-75 is exceptional in its unique ability to be able to ‘track the sun’ and operate
reliably in low sunlight conditions. The SL-75 has been proven to operate as a 3–5+ nautical mile
compact buoy lantern in various low sunlight environments such as Britain, Canada and Europe.
•Specications subject to change or variation without notice *Subject to standard terms and conditions †Intensity setting subject to solar availability
SPECIFICATIONS•*
Light Characteristics
Light Source High efciency LED
Available Colours Red, Green, White,Yellow, Blue
SL-75-7D Typical Maximum Intensity (cd) Red - 98 Green - 104 White - 131 Yellow - 65
SL-75-5D Typical Maximum Intensity (cd) Red - 143 Green - 109 White - 183 Yellow - 87
Visable Range (NM/km) 3-5 / 5.5 - 9
Horizontal Output (degrees) 360
Vertical Divergence (degrees) 7.5 (standard) / 5 (optional)
Available Flash Characteristics 310 plus custom character
Intensity Adjustments Multiple intensity settings
LED Life Expectancy (hours) >100,000
Electrical Characteristics
Circuit Protection Integrated
Nominal Voltage (VDC) 3.6
Autonomy (days) >30 (14 hour darkness, 12.5% duty cycle)
Temperature Range -40 to 80°C
Solar Characteristics
Solar Module Type Multicrystalline
Power Supply
Battery Type High grade NiMH
Battery Capacity (Ah) - Standard 17.2
Battery Capacity (Ah) - Large 21.5
Nominal Voltage (V) 3.6
Physical Characteristics
Body Material LEXAN® Polycarbonate – UV stabilized
Lens Material LEXAN® Polycarbonate – UV stabilized
Lens Design Single LED Optic
Mounting 3 types: 3 & 4 hole 200mm bolt pattern, 3 hole 150mm bolt pattern,
4 hole 162mm bolt pattern
Height (mm/inches) 314 / 12 3/8
Width (mm/inches) 231 / 9 1/8
Mass (lbs/kg) 5.5 / 2.5
Product Life Expectancy Up to 12 years
Certications
EMC FCC Part 15 Rules & ANSI C63.4: 2014.
EN61000-6-2: 2005 (IEC 61000-6-2:2005) Part 6-2 Immunity. EN 61000-
6-4: 2007 (IEC 61000-6-4: 2006) Electromagnetic compatibility (EMC)
- Part 6-4 Emission.
IEC 61000-4-2: 2008 Ed 2 Part 4-2 Electrostatic discharge immunity test.
IEC 61000-4-3: 2006 Ed 3 Part 4-3. Radiated, radio-frequency,
electromagnetic eld immunity.
IALA Signal colours compliant to IALA E-200-1
Quality Assurance ISO9001:2008
Waterproof IP68
Intellectual Property
Trademarks SEALITE® is a registered trademark of Sealite Pty Ltd
Warranty * 3 years
Options Available GPS Synchronisation
Bird Deterrent
SL-75-5D (5 Degree divergence model)
GSM Monitoring & Control System
Charging Port

Latest products and information available at www.sealite.com
6
SL-75
3–5NM+ Solar Marine Lantern
Charging the Battery
New lanterns should be left in the sun for 1-2 days to ensure battery is charged before placing
in service. Please note, lantern will re-charge even when toggle switch is turned to ‘OFF’
position.
Preferred Installation Location
For best lantern performance, ensure solar modules are not covered and are in clear view of the sky
with no shadows.
Manual Setting
The lantern can be programmed via 3 methods,
1. Bluetooth connectivity via the SealiteProTM App
2. Manually via the Switch settings
3. Via the optional IR Controller
If programming via the SealiteProTM App, please see the separate SealiteProTM Instruction Manual.
4
5
6
7
8
9
A
B
C
D
E
F
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0
1
2
3
AB
ON
OFF Rotary
Switch A
Rotary
Switch B
Intensity Setting
ON / OFF
Switch
User
Replaceable
Battery
Lantern
Base
Installation
Manual Setting
Lantern is activated by ON/OFF Switch. Intensity and flash settings need to be set prior to activation.
1. Remove the marked flash adjustment bung from the base of the lantern and set internal toggle
switch to ‘ON’.
2. The power and range settings of the lantern are adjusted by setting the DIP switches inside the
lantern. Your lantern is normally set to maximum range (see ‘Selecting an Intensity/Power Setting’
section of this manual).
3. Set rotary switches to the required flash code (see ‘Selecting a Flash Code’ section of this
manual).
4. Replace flash adjustment bung.
5. A sealed vent on the base allows air transfer without moisture intake, and should not be disturbed.
6. To test place dark cover (towel or jacket) on top of lantern to activate sensor, lantern will come on.
7. Ensure that the unit is bolted to an even, flat surface.

Latest products and information available at www.sealite.com
7
SL-75
3–5NM+ Solar Marine Lantern
Intensity/power settings on Sealite lanterns operate via DIP switches, located near the rotary switches
on the flasher unit. The intensity/power settings may be used to reduce the power consumption and
intensity of the lantern. Setting the lantern to 25% intensity will reduce the power consumption to 25%
of the normal 100% setting and the range by 20% - 40% depending on the maximum intensity. Refer
to Sealite power calculator to confirm reduced range.. This setting may be used to adjust the current
draw of the light to local sunlight conditions.
The following diagrams indicate intensity/power settings:-
Power Consumption Calculator
If the number of Full Sunlight hours is less than 2.5-3.0 hours, please consider reducing the intensity
(Power) or reducing the Duty Cycle.
All lanterns have 2 rotary switches marked A and B on the flasher
unit. Turning the small arrows to the appropriate number or letter
will set the code (see ‘Flash Codes’ section, of this manual). The
unit may take up to one minute to activate a new flash code. A
comprehensive list of available flash codes is listed on pages in
the ‘Flash Codes’ section of this manual.
Example:
100%
1 2
ON
75%
1 2
ON
50%
1 2
ON
25%
1 2
ON
Intensity
Setting
Power
mA / hour
100% 350mA
75% 263mA
50% 175mA
25% 88mA
4
5
6
7
8
9
A
B
C
D
E
F
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0
1
2
3
A
B
SWITCH FLASH CODE ON OFF
AB
A 0 FL 3 S 0.3 2.7
Night Hours
(use 13.7 if
unknown)
Power
mA/hour
Duty Cycle
(e.g. 20% = 0.2)
Total power
used per night
(mA)
XX =
Total power
used per night
(mAh)
Solar Panel
Charge (mA)
Number of full sunlight hours
required to break even
(the amount of time it will take for the solar to
replace what the light took out overnight)
/ 279 =
Selecting an Intensity/Power Setting
Selecting a Flash Code - Rotary Switches A & B

Latest products and information available at www.sealite.com
8
SL-75
3–5NM+ Solar Marine Lantern
Flash Codes
The Sealite SL-75 may be set to any of 256 IALA recommended flash settings which are user-adjustable
onsite without the need for external devices.
SEALITE® code reference is listed by number of flashes
For the latest version of this document visit www.sealite.com,
or email [email protected]
Symbols
FL Flash followed by number Eg. FL 1 S, one flash every second
F Fixed
Q Quick flash
VQ Very quick flash
OC Occulting; greater period on than off
ISO Isophase; equal period on and off
LFL Long flash long
MO Morse code ( ) contains letter
For example, VQ (6) + LFL 10 S means 6 very quick flashes followed by a long flash, during a
10-second interval.
The amount of power your lantern draws through the night depends on the duty cycle, i.e. the amount of
time on as a proportion to the timing cycle. For example, 0.5 seconds on and 4.5 seconds off equals a
10% duty cycle.
It is best to operate at the lowest duty cycle appropriate to the actual needs of the application.
Recommended Rhythm for Flashing Light - IALA Regions A and B
MARK DESCRIPTION RHYTHM
Port Hand & Starboard Marks: Any, other than Composite Group Flashing (2+1)
Preferred Channel Starboard: Composite Group Flashing (2+1)
Preferred Channel Port: Composite Group Flashing (2+1)
North Cardinal Mark: Very quick or quick
East Cardinal Mark: Very quick (3) every 5 seconds or quick (3) every 10 seconds
South Cardinal Mark: Very quick (6) + long flash every 10 seconds or quick (6) + long flash every 15 seconds
West Cardinal Mark: Very quick (9) every 10 seconds or quick (9) every 15 seconds
Isolated Danger Mark: Group flashing (2)
Safe Water Mark: Isophase, occulting, one long flash every 10 seconds or Morse Code “A”
Special Marks: Any, other than those described for Cardinal, Isolated Danger or Safe Water Marks

Latest products and information available at www.sealite.com
9
SWITCH
IR
Controller FLASH CODE ON OFF
AB
0 0 000 F (Steady light)
D 3 211 VQ 0.5 S 0.2 0.3
- - 274 VQ 0.5 S 0.25 0.25
E 3 227 VQ 0.6 S 0.2 0.4
F 3 243 VQ 0.6 S 0.3 0.3
7 3 115 Q 1 S 0.2 0.8
8 3 131 Q 1 S 0.3 0.7
9 3 147 Q 1 S 0.4 0.6
A 3 163 Q 1 S 0.5 0.5
8 4 132 Q 1 S 0.8 0.2
B 3 179 Q 1.2 S 0.3 0.9
- - 293 FL 1.2 S 0.4 0.8
9 4 148 Q 1.2 S 0.5 0.7
C 3 195 Q 1.2 S 0.6 0.6
F 4 244 FL 1.5 S 0.2 1.3
1 0 16 FL 1.5 S 0.3 1.2
0 5 5 FL 1.5 S 0.4 1.1
0 4 4 FL 1.5 S 0.5 1.0
2 0 32 FL 2 S 0.2 1.8
3 0 48 FL 2 S 0.3 1.7
4 0 64 FL 2 S 0.4 1.6
5 0 80 FL 2 S 0.5 1.5
6 0 96 FL 2 S 0.7 1.3
7 0 112 FL 2 S 0.8 1.2
1 2 18 ISO 2 S 1.0 1.0
8 0 128 FL 2.5 S 0.3 2.2
9 0 144 FL 2.5 S 0.5 2.0
D 6 214 FL 2.5 S 1.0 1.5
1 5 21 FL 3 S 0.2 2.8
A 0 160 FL 3 S 0.3 2.7
2 5 37 FL 3 S 0.4 2.6
B 0 176 FL 3 S 0.5 2.5
3 5 53 FL 3 S 0.6 2.4
C 0 192 FL 3 S 0.7 2.3
D 0 208 FL 3 S 1.0 2.0
2 2 34 ISO 3 S 1.5 1.5
5 4 84 OC 3 S 2.0 1.0
E 2 226 OC 3 S 2.5 0.5
4 6 70 OC 3.5 S 2.5 1.0
4 5 69 FL 4 S 0.2 3.8
5 5 85 FL 4 S 0.3 3.7
E 0 224 FL 4 S 0.4 3.6
F 0 240 FL 4 S 0.5 3.5
6 5 101 FL 4 S 0.6 3.4
0 1 1 FL 4 S 0.8 3.2
1 1 17 FL 4 S 1.0 3.0
2 1 33 FL 4 S 1.5 2.5
3 2 50 ISO 4 S 2.0 2.0
3 6 54 OC 4 S 2.5 1.5
F 2 242 OC 4 S 3.0 1.0
3 1 49 FL 4.3 S 1.3 3.0
8 5 133 FL 5 S 0.2 4.8
4 1 65 FL 5 S 0.3 4.7
- - 279 FL 5 S 0.4 4.6
5 1 81 FL 5 S 0.5 4.5
9 5 149 FL 5 S 0.9 4.1
6 1 97 FL 5 S 1.0 4.0
7 1 113 FL 5 S 1.5 3.5
SWITCH
IR
Controller FLASH CODE ON OFF
AB
4 2 66 ISO 5 S 2.5 2.5
8 2 130 LFL 5 S 2.0 3.0
0 3 3 OC 5 S 3.0 2.0
1 3 19 OC 5 S 4.0 1.0
2 3 35 OC 5 S 4.5 0.5
C 6 198 FL 6 S 0.2 5.8
B 5 181 FL 6 S 0.3 5.7
C 5 197 FL 6 S 0.4 5.6
8 1 129 FL 6 S 0.5 5.5
9 1 145 FL 6 S 0.6 5.4
A 1 161 FL 6 S 1.0 5.0
7 5 117 FL 6 S 1.2 4.8
B 1 177 FL 6 S 1.5 4.5
5 2 82 ISO 6 S 3.0 3.0
9 2 146 LFL 6 S 2.0 4.0
6 4 100 OC 6 S 4.0 2.0
3 3 51 OC 6 S 4.5 1.5
4 3 67 OC 6 S 5.0 1.0
- - 280 FL 7 S 0.4 6.6
A 4 164 FL 7 S 1.0 6.0
9 6 150 FL 7 S 2.0 5.0
5 6 86 OC 7 S 4.5 2.5
D 5 213 FL 7.5 S 0.5 7.0
C 1 193 FL 7.5 S 0.8 6.7
E 5 229 FL 8 S 0.5 7.5
B 4 180 FL 8 S 1.0 7.0
6 2 98 ISO 8 S 4.0 4.0
A 2 162 LFL 8 S 2.0 6.0
6 6 102 OC 8 S 5.0 3.0
- - 294 OC 8 S 6.0 2.0
B 2 178 LFL 8 S 3.0 5.0
F 5 245 FL 9 S 0.9 8.1
C 4 196 FL 9 S 1.0 8.0
7 6 118 OC 9 S 6.0 3.0
0 6 6 FL 10 S 0.2 9.8
1 6 22 FL 10 S 0.3 9.7
- - 281 FL 10 S 0.4 9.6
D 1 209 FL 10 S 0.5 9.5
2 6 38 FL 10 S 0.8 9.2
E 1 225 FL 10 S 1.0 9.0
1 4 20 FL 10 S 1.5 8.5
C 2 194 LFL 10 S 2.0 8.0
D 2 210 LFL 10 S 3.0 7.0
7 2 114 ISO 10 S 5.0 5.0
2 4 36 LFL 10 S 4.0 6.0
8 6 134 OC 10 S 6.0 4.0
5 3 83 OC 10 S 7.0 3.0
6 3 99 OC 10 S 7.5 2.5
- - 303 FL 11 S 1.0 10.0
- - 302 FL 12 S 1.0 11.0
F 1 241 FL 12 S 1.2 10.8
D 4 212 FL 12 S 2.5 9.5
3 4 52 LFL 12 S 2.0 10.0
0 2 2 FL 15 S 1.0 14.0
4 4 68 LFL 15 S 4.0 11.0
7 4 116 OC 15 S 10 5.0
A 6 166 LFL 20 S 2.0 18.0
E 4 228 FL 26 S 1.0 25.0

Latest products and information available at www.sealite.com
10
SL-75
3–5NM+ Solar Marine Lantern
SWITCH
IR
Controller FLASH CODE ON OFF ON OFF
AB
0 A 10 FL (2) 4 S 0.5 1.0 0.5 2.0
E B 235 VQ (2) 4 S 0.2 1.0 0.2 2.6
1 A 26 FL (2) 4.5 S 0.3 1.0 0.3 2.9
2 A 42 FL (2) 4.5 S 0.4 1.0 0.4 2.7
3 A 58 FL (2) 4.5 S 0.5 1.0 0.5 2.5
- - 277 FL (2) 4.6 S 0.3 0.3 0.3 3.7
F 9 249 FL (2) 5 S 0.2 0.8 0.2 3.8
2 C 44 FL (2) 5 S 0.2 1.2 0.2 3.4
4 A 74 FL (2) 5 S 0.4 0.6 0.4 3.6
- - 282 FL (2) 5 S 0.4 1.1 0.4 3.1
0 7 7 FL (2) 5 S 0.5 1.0 0.5 3.0
1 7 23 FL (2) 5 S 1.0 1.0 1.0 2.0
- - 257 FL (2) 5 S 0.3 1.0 0.3 3.4
9 B 155 Q (2) 5 S 0.3 0.7 0.3 3.7
2 9 41 Q (2) 5 S 0.5 0.5 0.5 3.5
- - 305 FL (2) 5 S 0.5 0.7 0.5 3.3
5 A 90 FL (2) 5.5 S 0.4 1.4 0.4 3.3
7 8 120 FL (2) 6 S 0.3 0.6 1.0 4.1
A A 170 FL (2) 6 S 0.3 0.9 0.3 4.5
6 A 106 FL (2) 6 S 0.3 1.0 0.3 4.4
7 A 122 FL (2) 6 S 0.4 1.0 0.4 4.2
- - 283 FL (2) 6 S 0.4 1.2 0.4 4.0
9 9 153 FL (2) 6 S 0.5 1.0 0.5 4.0
2 8 40 FL (2) 6 S 0.8 1.2 0.8 3.2
- - 256 FL (2) 6 S 0.8 0.8 0.8 3.6
3 7 55 FL (2) 6 S 1.0 1.0 1.0 3.0
3 9 57 Q (2) 6 S 0.3 0.7 0.3 4.7
- - 295 LFL + FL 6 S 3.0 1.0 1.0 1.0
- - 273 FL (2) 6.5 S 0.5 1.0 0.5 4.5
- - 283 FL (2) 7 S 0.4 1.2 0.4 5.0
- - 311 FL (2) 7 S 0.5 1.5 0.5 4.5
A 9 169 FL (2) 7 S 1.0 1.0 1.0 4.0
7 B 123 FL (2) 8 S 0.4 0.6 2.0 5.0
8 A 138 FL (2) 8 S 0.4 1.0 0.4 6.2
- - 285 FL (2) 8 S 0.4 1.7 0.4 5.5
4 7 71 FL (2) 8 S 0.5 1.0 0.5 6.0
- - 297 FL (2) 8 S 0.5 0.5 1.5 5.5
8 8 136 FL (2) 8 S 0.8 1.2 2.4 3.6
5 7 87 FL (2) 8 S 1.0 1.0 1.0 5.0
4 C 76 OC (2) 8 S 3.0 2.0 1.0 2.0
5 C 92 OC (2) 8 S 5.0 1.0 1.0 1.0
F B 251 VQ (2) 8 S 0.2 1.0 0.2 6.6
- - 286 FL (2) 9 S 0.4 1.7 0.4 6.5
9 A 154 FL (2) 10 S 0.4 1.6 0.4 7.6
- - 287 FL (2) 10 S 0.4 2.2 0.4 7.0
6 7 103 FL (2) 10 S 0.5 1.0 0.5 8.0
7 7 119 FL (2) 10 S 0.5 1.5 0.5 7.5
6 9 105 FL (2) 10 S 0.5 2.0 0.5 7.0
- - 298 FL (2) 10 S 0.5 0.5 1.5 7.5
8 7 135 FL (2) 10 S 0.8 1.2 0.8 7.2
B 9 185 FL (2) 10 S 1.0 1.0 1.0 7.0
9 7 151 FL (2) 10 S 1.0 1.5 1.0 6.5
4 9 73 Q (2) 10 S 0.6 0.4 0.6 8.4
B A 186 FL (2) 12 S 0.4 1.0 0.4 10.2
C 9 201 FL (2) 12 S 0.5 1.0 0.5 10.0
D 9 217 FL (2) 12 S 1.5 2.0 1.5 7.0
A 8 168 FL (2) 15 S 0.5 1.5 2.0 11.0
A 7 167 FL (2) 15 S 1.0 2.0 1.0 11.0
8 B 139 Q (2) 15 S 0.2 0.8 0.2 13.8
C A 202 FL (2) 20 S 1.0 3.0 1.0 15.0
D A 218 FL (2) 25 S 1.0 1.0 1.0 22.0

Latest products and information available at www.sealite.com
11
SL-75
3–5NM+ Solar Marine Lantern
SWITCH
IR
Controller FLASH CODE ON OFF ON OFF ON OFF
AB
7 9 121 Q (3) 5 S 0.5 0.5 0.5 0.5 0.5 2.5
5 9 89 VQ (3) 5 S 0.2 0.3 0.2 0.3 0.2 3.8
0 C 12 VQ (3) 5 S 0.3 0.2 0.3 0.2 0.3 3.7
E 9 233 VQ (3) 5 S 0.3 0.3 0.3 0.3 0.3 3.5
- - 308 FL (3) 5 S 0.3 0.7 0.3 0.7 0.3 3.7
0.3 3.7 60 FL (3) 6 S 0.5 1.0 0.5 1.0 0.5 2.5
2 B 43 FL (2+1) 6 S 0.3 0.4 0.3 1.2 0.3 3.5
SWITCH
IR
Controller FLASH CODE ON OFF ON OFF ON OFF
AB
A B 171 Q (3) 6 S 0.3 0.7 0.3 0.7 0.3 3.7
F A 250 FL (3) 8 S 0.5 1.0 0.5 1.0 0.5 4.5
- - 301 FL (3) 8 S 1.5 0.5 0.5 0.5 0.5 4.5
- - 266 Q (3) 9 S 0.5 0.5 0.5 1.0 0.5 6.0
0 B 11 FL (3) 9 S 0.3 1.0 0.3 1.0 0.3 6.1
- - 306 FL (3) 9 S 0.5 1.5 0.5 1.5 0.5 4.5
B 7 183 FL (3) 9 S 0.8 1.2 0.8 1.2 0.8 4.2
B 8 184 FL (3) 10 S 0.3 0.7 0.3 0.7 0.9 7.1
C 8 200 FL (3) 10 S 0.4 0.6 0.4 0.6 1.2 6.8
- - 290 FL (3) 10 S 0.4 0.8 0.4 0.8 0.4 7.2
C B 203 FL (3) 10 S 0.5 0.5 0.5 0.5 0.5 7.5
C 7 199 FL (3) 10 S 0.5 1.5 0.5 1.5 0.5 5.5
D B 219 FL (3) 10 S 0.6 0.6 0.6 0.6 0.6 7.0
- - 278 FL (3) 10 S 0.9 1.1 0.9 1.1 0.9 5.1
D 7 215 FL (3) 10 S 1.0 1.0 1.0 1.0 1.0 5.0
- - 261 FL (3) 10 S 0.35 0.65 0.35 0.65 0.35 7.65
3 8 56 FL (2+1) 10 S 0.5 0.7 0.5 2.1 0.5 5.7
8 9 137 OC (3) 10 S 5.0 1.0 1.0 1.0 1.0 1.0
B B 187 Q (3) 10 S 0.3 0.7 0.3 0.7 0.3 7.7
D 8 216 FL (2 + 1) 10 S 0.5 0.5 0.5 0.5 1.5 6.5
- - 288 FL (3) 12 S 0.4 2.1 0.4 2.1 0.4 6.6
1 B 27 FL (3) 12 S 0.5 1.5 0.5 1.5 0.5 7.5
E A 234 FL (3) 12 S 0.5 2.0 0.5 2.0 0.5 6.5
E 7 231 FL (3) 12 S 0.8 1.2 0.8 1.2 0.8 7.2
B 6 182 FL (3) 12 S 1.0 1.0 1.0 3.0 1.0 5.0
4 8 72 FL (2+1) 12 S 0.8 1.2 0.8 2.4 0.8 6.0
5 8 88 FL (2+1) 12 S 1.0 1.0 1.0 4.0 1.0 4.0
- - 272 FL (3) 12.5 S 0.5 1.0 0.5 1.0 0.5 9.0
- - 289 FL (3) 13 S 0.4 2.1 0.4 2.1 0.4 7.6
- - 296 LFL + FL(2) 13 S 6.0 1.0 2.0 1.0 2.0 1.0
1 8 24 FL (2+1) 13.5 S 1.0 1.0 1.0 4.0 1.0 5.5
- - 307 FL (3) 14.5 S 0.5 1.0 1.5 3.0 0.5 9.0
F 7 247 FL (3) 15 S 0.3 1.7 0.3 1.7 0.3 10.7
9 D 157 FL (3) 15 S 0.4 1.0 0.4 1.0 0.4 11.8
0 8 8 FL (3) 15 S 0.5 1.5 0.5 1.5 0.5 10.5
- - 259 FL (3) 15 S 0.5 2.0 0.5 2.0 0.5 9.5
- - 260 FL (3) 15 S 1.0 1.0 1.30 1.0 1.0 10.0
F 8 248 FL (2+1) 15 S 0.6 0.3 0.6 0.3 1.4 11.8
0 9 9 FL (2+1) 15 S 0.7 0.5 0.7 0.5 1.9 10.7
1 9 25 FL (2+1) 15 S 0.7 0.7 0.7 0.7 2.1 10.1
6 8 104 FL (2+1) 15 S 1.0 2.0 1.0 5.0 1.0 5.0
- - 265 FL (2+1) 15 S 1.3 0.7 1.3 0.7 3.3 7.7
- - 264 FL (2+1) 15.75 S 0.55 0.35 0.55 0.35 1.45 12.5
1 C 28 VQ (3) 15 S 0.1 0.5 0.1 0.5 0.1 13.7
- - 313 FL (2) + LFL 16 S 2.0 2.0 2.0 2.0 6.0 2.0
4 B 75 FL (3) 20 S 0.5 3.0 0.5 3.0 0.5 12.5
3 B 59 FL (3) 20 S 0.5 1.5 0.5 1.5 0.5 15.5
- - 263 FL (3) 20 S 0.5 2.0 0.5 2.0 0.5 12.0
5 B 91 FL (3) 20 S 0.8 1.2 0.8 1.2 0.8 15.2
6 B 107 FL (3) 20 S 1.0 1.0 1.0 1.0 1.0 15.0

Latest products and information available at www.sealite.com
12
SL-75
3–5NM+ Solar Marine Lantern
SWITCH
IR
Controller FLASH CODE ON OFF ON OFF ON OFF ON OFF ON OFF
AB
D D 221 Q (5) 7 S 0.3 0.7 0.3 0.7 0.3 0.7 0.3 0.7 0.3 2.7
- - 310 Q (5) 9 S 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 4.5
E D 237 Q (5) 10 S 0.3 0.7 0.3 0.7 0.3 0.7 0.3 0.7 0.3 5.7
E 8 232 FL (5) 12 S 0.5 1.5 0.5 1.5 0.5 1.5 0.5 1.5 0.5 3.5
- - 276 FL (5) 16 S 0.5 1.5 0.5 1.5 0.5 1.5 0.5 1.5 0.5 7.5
5 F 95 FL (5) 20 S 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 15.5
9 F 159 FL (5) 20 S 0.8 1.2 0.8 1.2 0.8 1.2 0.8 1.2 0.8 11.2
9 E 158 FL (5) 20 S 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 11.0
SWITCH
IR
Controller FLASH CODE ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF
AB
F D 253 Q (6) 10 S 0.3 0.7 0.3 0.7 0.3 0.7 0.3 0.7 0.3 0.7 0.3 4.7
A F 175 FL (6) 15 S 0.3 0.7 0.3 0.7 0.3 0.7 0.3 0.7 0.3 0.7 0.3 9.7
7 F 127 FL (6) 15 S 0.5 1.0 0.5 1.0 0.5 1.0 0.5 1.0 0.5 1.0 0.5 7.0
SWITCH
IR
Controller FLASH CODE ON OFF ON OFF ON OFF ON OFF
AB
- - 271 VQ (4) 2 S 0.10 0.13 0.10 0.13 0.10 0.13 0.10 1.21
B F 191 VQ (4) 4 S 0.3 0.3 0.3 0.3 0.3 0.3 0.3 2.3
B D 189 Q (4) 6 S 0.3 0.7 0.3 0.7 0.3 0.7 0.3 2.7
8 D 141 Q (4) 6 S 0.4 0.6 0.4 0.6 0.4 0.6 0.4 2.6
- - 299 FL (1+3) 8 S 1.5 0.5 0.5 0.5 0.5 0.5 0.5 3.5
- - 309 FL (4) 7 S 0.3 0.7 0.3 0.7 0.3 0.7 0.3 3.7
1 D 29 FL (4) 10 S 0.5 1.0 0.5 1.0 0.5 1.0 0.5 5.0
2 D 45 FL (4) 10 S 0.8 1.2 0.8 1.2 0.8 1.2 0.8 3.2
F E 254 Q (4) 10 S 0.3 0.7 0.3 0.7 0.3 0.7 0.3 6.7
- - 300 FL (4) 10 S 1.5 0.5 0.5 0.5 0.5 0.5 0.5 4.5
- - 312 FL (4) 11 S 0.5 1.5 0.5 1.5 0.5 1.5 0.5 4.5
B E 190 FL (4) 12 S 0.3 1.7 0.3 1.7 0.3 1.7 0.3 5.7
4 F 79 FL (4) 12 S 0.5 0.5 0.5 0.5 0.5 0.5 0.5 8.5
C E 206 FL (4) 12 S 0.5 1.5 0.5 1.5 0.5 1.5 0.5 5.5
3 D 61 FL (4) 12 S 0.8 1.2 0.8 1.2 0.8 1.2 0.8 5.2
A D 173 Q (4) 12 S 0.3 0.7 0.3 0.7 0.3 0.7 0.3 8.7
4 D 77 FL (4) 15 S 0.5 1.5 0.5 1.5 0.5 1.5 0.5 8.5
8 E 142 FL (4) 15 S 1.0 1.0 1.0 1.0 1.0 1.0 1.0 8.0
7 D 125 FL (4) 15 S 1.5 0.5 0.5 0.5 0.5 0.5 0.5 10.5
D E 222 FL (4) 16 S 0.5 1.5 0.5 1.5 0.5 1.5 0.5 9.5
- - 314 FL (3+1) 18 S 1.5 1.5 1.5 1.5 1.5 4.5 1.5 4.5
- - 304 FL (4) 19 S 0.3 0.7 0.3 0.7 0.3 0.7 0.3 15.7
C D 205 FL (4) 20 S 0.3 3.0 0.3 3.0 0.3 3.0 0.3 9.8
5 D 93 FL (4) 20 S 0.5 1.5 0.5 1.5 0.5 1.5 0.5 13.5
0 D 13 FL (4) 20 S 0.5 1.5 0.5 1.5 0.5 4.5 0.5 10.5
3 F 63 FL (4) 20 S 1.5 1.5 1.5 1.5 1.5 1.5 1.5 9.5
0 F 15 Q (4) 20 S 0.5 0.5 0.5 0.5 0.5 0.5 0.5 16.5
- - 263 FL (4) 20 S 0.5 2.0 0.5 2.0 0.5 2.0 0.5 12.0
E E 238 Q (4) 28 S 0.5 0.5 0.5 0.5 0.5 0.5 0.5 24.5
6 F 111 FL (4) 30 S 0.5 0.5 0.5 0.5 0.5 0.5 0.5 26.5

Latest products and information available at www.sealite.com
13
SL-75
3–5NM+ Solar Marine Lantern
SWITCH
IR
Controller FLASH CODE ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF
AB
- - 275 FL (3+5) 12.2 S 0.9 0.3 0.9 1.0 0.9 0.3 0.3 0.3 0.3 1.0 0.3 0.3 0.3 0.3 0.3 4.5 - -
4 E 78 VQ (9) 10 S 0.2 0.3 0.2 0.3 0.2 0.3 0.2 0.3 0.2 0.3 0.2 0.3 0.2 0.3 0.2 0.3 0.2 5.8
5 E 94 VQ (9) 10 S 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 4.9
1 F 31 Q (9) 15 S 0.2 0.8 0.2 0.8 0.2 0.8 0.2 0.8 0.2 0.8 0.2 0.8 0.2 0.8 0.2 0.8 0.2 6.8
0 E 14 Q (9) 15 S 0.3 0.7 0.3 0.7 0.3 0.7 0.3 0.7 0.3 0.7 0.3 0.7 0.3 0.7 0.3 0.7 0.3 6.7
- - 267 Q (9) 15 S 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 6.5
1 E 30 Q (9) 15 S 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 4.8
- - 291 FL (9) 32.92 S 0.4 0.8 0.4 0.8 0.4 0.8 0.4 0.8 0.4 0.8 0.4 0.8 0.4 0.8 0.4 0.8 0.4
SWITCH
IR
Controller FLASH CODE ON OFF ON OFF ON OFF ON OFF
AB
MORSE CODE ( ) INDICATES LETTER
7 8 120 MO (A) 6 S 0.3 0.6 1.0 4.1
7 B 123 MO (A) 8 S 0.4 0.6 2.0 5.0
8 8 136 MO (A) 8 S 0.8 1.2 2.4 3.6
B 8 184 MO (U) 10 S 0.3 0.7 0.3 0.7 0.9 7.1
C 8 200 MO (U) 10 S 0.4 0.6 0.4 0.6 1.2 6.8
D 8 216 MO (U) 10 S 0.5 0.5 0.5 0.5 1.5 6.5
9 8 152 MO (A) 10 S 0.5 0.5 1.5 7.5
8 9 137 MO (D) 10 S 5.0 1.0 1.0 1.0 1.0 1.0
A 8 168 MO (A) 15 S 0.5 1.5 2.0 11.0
F 8 248 MO (U) 15 S 0.6 0.3 0.6 0.3 1.4 11.8
0 9 9 MO (U) 15 S 0.7 0.5 0.7 0.5 1.9 10.7
1 9 25 MO (U) 15 S 0.7 0.7 0.7 0.7 2.1 10.1
7 D 125 MO (B) 15 S 1.5 0.5 0.5 0.5 0.5 0.5 0.5 10.5
SWITCH
IR
Controller FLASH CODE ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF
AB
6 E 110 VQ (6) + LFL 10 S 0.2 0.3 0.2 0.3 0.2 0.3 0.2 0.3 0.2 0.3 0.2 0.3 2.0 5.0
7 E 126 VQ (6) + LFL 10 S 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 2.0 4.4
2 F 47 Q (6) + LFL 15 S 0.2 0.8 0.2 0.8 0.2 0.8 0.2 0.8 0.2 0.8 0.2 0.8 2.0 7.0
2 E 46 Q (6) + LFL 15 S 0.3 0.7 0.3 0.7 0.3 0.7 0.3 0.7 0.3 0.7 0.3 0.7 2.0 7.0
3 E 62 Q (6) + LFL 15 S 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 2.0 5.8
- - 258 FL (6 + 1) 15 S 0.35 0.65 0.35 0.65 0.35 0.65 0.35 0.65 0.35 0.65 0.35 0.65 1.05 7.95
- - 292 FL (6) + LFL 15 S 0.4 0.8 0.4 0.8 0.4 0.8 0.4 0.8 0.4 0.8 0.4 0.8 2.0 5.8
- - 262 FL (6) + LFL 15 S 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 2.0 7.0
8 F 143 VQ (6) + LFL 15 S 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 2.0 9.4

Latest products and information available at www.sealite.com
14
SL-75
3–5NM+ Solar Marine Lantern
The IR remote is used to communicate with Sealite lighting products that have
an IR sensor fitted. The remote control is used for the following functions:
• Flash Code: read the current flash code, configure a new flash code.
• Lamp Intensity: read the current lamp intensity, configure a new intensity
level.
• Ambient Light Thresholds: read the current light thresholds, configure new
ambient light thresholds.
• Perform a battery health check.
On receiving a valid key signal from the IR Remote, the light will flash once.
The user should wait until the light responds to each keypress before pressing
another key. If there is no response to the keypress after 3 seconds, it has not
been detected by the light and the key can be pressed again.
If an invalid key is detected, the light will flash quickly 5 times. In this case, the
command will have to be restarted.
T/CT/C
Read Lux
Flash Code Intensity Battery Status
Test / Congure
RL
FC I B
3
456
789
0
12
Optional IR Remote Control
Sealite IR Controller / Universal Remote Compatibility
If you lose your Sealite IR Controller, the following Universal Remote Controller has been tested for
compatibility: RCA Type RCR312WR programmed for Phillips TV Type Code 10054
Sealite Key Universal
Remote Key
T Power
11
22
33
44
55
66
77
88
99
00
R Channel+
L Mute
FC Volume+
I Volume-
B Channel-

Latest products and information available at www.sealite.com
15
SL-75
3–5NM+ Solar Marine Lantern
Test Mode / Configure
Pressing the T/C button for upto 5 seconds places the light in Test Mode. The light will flash once in
response to the T/C button being pressed and then turn off.
T/CT/C
Normal Operation
The light will return to normal operation once it has not detected a valid key press for 30 seconds. The
light will flash once to indicate it is returning to normal operation.
Read
Pressing the Read followed by one of the configuration keys shall cause the light to flash the
configured value.
Example Key Sequences:
The light flashes the ‘IR Remote’ number belonging to the currently set Flash
Code. Refer to the Flash Code tables to match the ‘IR Remote’ flash number
to the Flash Code.
The light flashes the current intensity setting: 1 flash for 25%, 2 for 50%, 3 for
75% and 4 for 100%.
The light flashes the current battery status.
The light flashes the sunset level in Lux, followed by a 2 second gap, followed
by the sunrise level. Levels are in the range of 1 to 9.
R
R
R
I
B
FC
LR
T/CT/C
T/CT/C
T/CT/C
T/CT/C
IR Controller Functions

Latest products and information available at www.sealite.com
16
SL-75
3–5NM+ Solar Marine Lantern
I
I1T/CT/C
B
RBT/CT/C
Flash Code
This key sets the flash code on the light.
Example Key sequence:
This sets the flash code to value 123. The light responds by flashing the flash code value.
Flash Code Numbers
The lamp flashes numbers as follows: Hundreds, Tens, Ones. A value of 125 will be flashed as: 1 flash,
followed by a delay, 2 flashes, followed by a delay, 5 flashes.
The flash for number 0 is one long flash.
For example if the current Flash Code is set to 51 via the AB switches, the lamp will flash number 081.
For a flash code set to 01, the lamp will flash 001.
FC
312
FC T/CT/C
Intensity
This function sets the light intensity. Valid intensity values are 1 for 25%, 2 for 50%, 3 for 75% and
4 for 100%.
Example Key sequence:
This sets the light intensity to 25%.
Battery Status
This function reads the battery status. The response from the light is High Voltage: 4 flashes,
Good Voltage: 3 flashes, Low Voltage 2 flashes, Cutoff Voltage or below: 1 flash.
Example Key sequence:

Latest products and information available at www.sealite.com
17
SL-75
3–5NM+ Solar Marine Lantern
Lux
This key sets the ambient light threshold levels.
The format is
Where ‘x’ is the desired setting from the table below.
There are 5 programmable lux levels which are set together for the sunset and sunrise transitions.
Example key sequence:
Assume the current Lux settings are at the factory preset values of 2.
This sets the ambient light level to be lower than the default 100 lux. The light will turn on when its
surroundings are darker.
The light responds by acknowledgement with a long flash.
Level Sunset
(Dusk)
Sunrise
(Dawn)
1 64 100
2* 100 150
3 150 240
4 240 370
5 370 600
* Default / Factory Preset
LT/CT/C
x
L
LT/CT/C
1

Latest products and information available at www.sealite.com
18
SL-75
3–5NM+ Solar Marine Lantern
Error / Acknowledge Indication
If the key sequence is invalid, or an out of bounds value is attempted to be set, the light flashes 5
times for 1 second. (The command then needs to be sent from the start.)
Example key sequence: (Set the intensity level to 5 – undefined.)
The light flashes 5 times for 1 second.
When a key sequence has been entered successfully the light will respond acknowledgement with a
long 1 second flash.
Configuration Settings
The intensity and flash codes can be changed using the switches on the lamp circuit board or with the
IR Remote Control. The lamp intensity and flash code settings are set to the last detected change,
carried out with the IR Remote Control or by changing the switch positions.
Example #1: If the intensity is set at 100% with the intensity switches, and is then set to 50% using
the IR Remote Control, the intensity setting will change to 50%. If the intensity is then set to 75% using
the switches, the new intensity value will be 75%.
In order to change intensity settings using the IR Remoter Control, the lamp must be powered.
The lamp can detect a change in switch settings if they are changed while the light is powered down.
Example #2: The flash code is set according to the switch settings: A=5, B = 1. The operator changes
the flash code to 65 (A=4, B=1) using the IR Remote Control. The new flash code is now configured to
A=4, B=1. The lamp is powered down and the operator changes the flash code switches to A=3, B=1
and powers on the light. The new flash code is now A=3, B=1. If the flash code is read from the light
using the IR Remote Control, the lamp will flash 49 which is the corresponding number for switches
A=3, B=1.
Use the IR Remote Control to read the current lamp intensity setting and flash code.
5
IT/CT/C

Latest products and information available at www.sealite.com
19
SL-75
3–5NM+ Solar Marine Lantern
Hibernation Mode (Advanced users) – only available for lanterns fitted with GPS
For situations where the lantern is put into storage for a known period, the IR Remote control can be
used to configure the lantern into Hibernation Mode for a user programmable date range.
Hibernation Mode maximises conservation of the battery power by disabling the light (will not activate
at night) and shutting off the GPS receiver to rely on the internal clock for date checking. The IR
sensor is still monitored in hibernation mode. Power consumption is only bettered by physically
disconnecting the battery supply.
Hibernation Mode is defined by a start date and end date that are programmed into the lantern via the
IR Remote Control.
Using the IR Remote Control
The lantern must be in Test Mode prior to pressing any of the following key sequences. However,
the lantern will return to Normal Operation if it has not detected a valid key press for a period of 15
seconds. When the lantern exits from Test Mode it will either enter Dusk to Dawn mode, Hibernation
mode, or Storage Mode, if enabled.
LI
Store Hibernation Mode Date Range
The following details the key press sequence that defines the start and end dates of Hibernation
Mode:
where ddmm is the numerical representation of the month (01=January, 08=August) of the start date,
and DDMM is the numerical representation of the end date.
e.g 9th of December is represented by the number sequence 0912.
The lantern will respond by flashing an acknowledge long flash.
This operation only stores the start & end dates into the lantern’s memory and Hibernation Mode still
must be enabled to commence its operation.
Enable Hibernation Mode
Pressing the following key sequence will enable (turn on) Hibernation Mode:
and the lantern will respond with a single flash.
The Lantern will take a new GPS reading, determine the calendar month, and then enter Hibernation
Mode and depending on the current calendar month setting will either Hibernate or enter Dusk-to-
Dawn mode.
By default, Hibernation mode is disabled. Note you can only use this command once a valid
hibernation start & end date has been stored in the lantern.
T/CT/C
LI1
LIm
dm dT/CT/C
MD MD

Latest products and information available at www.sealite.com
20
SL-75
3–5NM+ Solar Marine Lantern
Disable Hibernation / Hibernation Modes
Pressing the following key sequence will disable (turn off) both Hibernation Mode and Seasonal
Hibernation:
and the lantern will respond with a single long flash.
The Lantern will disable Hibernation Mode and enter Dusk-to-Dawn Mode.
Momentarily Wake Up from Hibernation Mode
Pressing the button will wake up the lantern.
At which point the lantern will remain awake for a further 15 secondss to process other commands
from the IR Controller. If no IR commands are received for a period of 15 seconds, the lantern will
return to Hibernation mode.
Read Stored Hibernation Dates
By pressing the following key sequence the lantern will respond with the stored start and end dates for
Hibernation:
Read Hibernation Mode Status
By pressing the following key sequence the lantern will respond with status of Hibernation mode.
Where:
• A single long flash = hibernation mode is Enabled
• Two quick flashes = hibernation mode is Disabled.
T/CT/C
R L I1
T/CT/C
R L I0
T/CT/C
User Case Example: Configuring the lantern for Hibernation
In this example, we want the lantern to hibernate each year from Dec 10th, through to February 15th,
and the lantern is located inside a storage warehouse.
The required key sequence is:
Command IR Controller Key Press
Store the Hibernation
Date Range
Enable Hibernation
LI12 0T/CT/C
1 1 502
LI1T/CT/C
T/CT/C
LI0
