OWNER’S MANUAL
For Household Use Only
FELIX PREMIUM FELIX KOMBI

TABLE OF CONTENTS
Technical Details 2
How To Contact SEBO 2
Important Safety Instructions 3
SEBO FELIX Product Features 4
ET Power Head Features 4
Standard Features of all SEBO Vacuums 5
S-Class Filtration 5
Optional Attachments, Accessories, Bags and Filters 6
Identification of Parts 7
Standard Attachments 7
Power Heads and Floor Tools 7
Assembly 7
Operating Instructions 8
Starting the Machine 8
Operating the Machine 8
Using the Hose Handle & Attachments 8
Detachable Suction Unit 8
Bag Full or Clog Warning – Auto Shut-Off 8
Additional Operating Instructions for FELIX Premium with Power Head 9
Operating with the Power Head 9
Brush Obstruction Light - Auto Shut-Off 9
The Brush Height Adjustment Feature 9
Indicator Lights 9
Power Head aintenance 10
Removing the Brush Roller 10
Cleaning the Brush Roller 10
Use and aintenance of Floor Tools and Brushes 10
The Premium Parquet Brush 10
The Kombi Nozzle 10
Vacuum aintenance 11
Changing the Filter Bag 11
Changing the Motor Protection/Carbon Filter 11
Changing the Exhaust Filter 11
Clog Removal 12
Clogs in the Hose 12
Clogs in the Swivel Neck 12
Clog Removal in the Power Head 12
Clogs in the Airflow Pathway 12
Clogs in the Swivel Neck 12
Trouble-Shooting Guide 13
Additional Trouble-Shooting Guide for Power Heads 14
Premium/Kombi - Bag Housing with Handle Schematic and Part Numbers 15
Premium - 12” Power Head (ET-1) Schematic and Part Numbers 16
Premium Ice Blue - 15” Power Head (ET-2) Schematic and Part Numbers 17
2
Vacuum motor 1300 Watts
Water lift (at motor) 90 inches
Airflow (at motor) 102 CFM
Filter bag capacity .92 gallon
Sound level 82 dB (A)
Body weight (depending on
the attachment) 9.9 - 15.4 lbs
Cord length 31 feet
Range 34.5 feet
Technical details may be subject to change.
TECHNICAL DETAILS - VACUUM
ET-1 ET-2
Brush motor 175 Watts, 1.6 Amps 200 Watts, 1.8 Amps
Width 12 inches 15 inches
Weight 5.4 lbs. 5.7 lbs.
Brush roller Replaceable Replaceable
Brush drive Toothed belt with Toothed belt with
electronic overload electronic overload
protection protection
Technical details may be subject to change.
TECHNICAL DETAILS - OWER HEADS
To contact SEBO in the United States of America:
SEBO America, LLC
Telephone: [phone] • Fax: [phone]
Website: www.sebo.us
To contact SEBO in Canada:
Floor Care Equipment, Ltd.
Telephone: [phone] • Fax: [phone]
Website: www.sebocanada.ca
HOW TO CONTACT SEBO
For Warranty coverage information please refer to your Warranty Card included with your SEBO vacuum cleaner.

IM ORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS ACHINE
3
1. Do not leave vacuum while plugged in. Unplug from
outlet when not in use and before servicing.
2. Do not use outdoors or on wet surfaces.
3. Do not use near small children or pets. Do not allow to be
used as a toy. Use of this product by children should
always be supervised by an adult.
4. Use only as described in this manual. Use only
manufacturer-recommended attachments.
5. Do not use with a damaged cord or plug. If vacuum is not
working as it should, has been dropped, damaged, left
outdoors, or dropped into water, take it to a SEBO service
center.
6. Do not pull or carry by cord, use cord as a handle, close a
door on cord, or pull cord around sharp edges or corners.
Do not run vacuum over cord. Keep cord away from heated
surfaces.
7. Do not unplug by pulling on cord. To unplug, grasp the
plug – not the cord.
8. Do not plug in if power switch is in the “ON” position.
9. Do not use outlets above counters to plug in vacuum –
damage to items in the surrounding area could occur.
10. Always carry the vacuum over steps and sills.
11. Do not handle plug or vacuum handle with wet hands.
12. Do not put any object into vacuum openings. Do not use
machine with any openings blocked. Keep openings free
of lint, hair, and anything that may reduce air flow.
13. Do not re-use filter bags or wash the filters.
14. Do not remove any screws from vacuum.
15. Do not vacuum up anything that is burning or smoking,
such as cigarettes, matches, or hot ashes.
16. Do not use vacuum without filter bag and/or filters in place.
17. Turn off all machine controls before unplugging.
18. Use extra care when cleaning on stairs.
19. Do not use machine to vacuum up flammable or
combustible liquids such as gasoline or use in areas
where they may be present.
20. Machines can cause a fire when operated near flammable
vapors or materials. Do not operate this vacuum near
flammable fluids, dust or vapors.
21. Maintenance and repairs must be done by qualified personnel.
22. Use only original SEBO replacement parts.
23. Do not use vacuum as a step.
24. Do not use the handle assembly (5), which inserts into the
top of the filter bag housing, to carry the machine. The
carrying handle is located on the side of the machine.
25. If vacuum is used on plush carpet or carpet with thick
padding, do not leave machine standing in one place with
machine turned on.
26. While the vacuum is in use, the power cord should be
unwound from the cable reel at least two thirds of its length.
27. Keep hair, loose clothing, fingers, and all parts of body away
from vacuum openings and moving parts. Do not place
fingers or other body parts under vacuum unless it is
unplugged. Do not touch the brush roller while the machine
is plugged in.
28. Do not place the power head over rug or carpet edges.
29. Store the vacuum in a dry place at room temperature. When
the vacuum is not in use, you should rewind the cord onto
the cord reel
30. Any other servicing should be performed by an authorized
service representative.
31. Avoid picking up sharp objects.
32. Always unplug vacuum before connecting or disconnecting
either hose or power head.
33. Use a SEBO power head only in combination with a SEBO
vacuum cleaner.
34. Do not connect power head to a malfunctioning or damaged
vacuum.
When using an electrical appliance, basic precautions must always be followed.
To reduce the risk of electric shock, this vacuum cleaner has a polarized plug; one blade is wider than
the other. This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any
way. Connect only to the outlet type specified on the serial number plate underneath the machine.
SAVE THESE INSTRUCTIONS.
WARNING: To reduce the risk of fire, electric shock, or injury:
!

DESIGNED FOR CARPETS AND HARD FLOORS – The stylish FELIX
offers all the flexibility of a canister vacuum in an upright configu-
ration! It has a "flex" neck with amazing 180° steering ability, an
ultra-modern filtration system, a detachable suction unit that
becomes a hand-held vacuum, and an instant-use suction hose.
Detachable Suction Unit Creates a Hand-held
Portable Vacuum – By removing the power head
or nozzle, the FELIX instantly transforms from an
upright floor vacuum into a handheld portable
vacuum, ideal for cleaning stairs, upholstery and
car interiors. It can be easily carried using its side
handle or the optional shoulder strap attachment.
Superb aneuverability – A unique
180° turning swivel neck offers superb
maneuverability around and under fur-
niture.
A Flat-to-the-floor 6-inch Profile – The
vacuum’s low profile makes cleaning
under furniture and beds easy!
Instant-use Suction Hose – The integrated
instant-use suction hose is always ready! Just pull
it out to clean corners, crevices or furniture. Two
on-board tools and a range of optional attach-
ments can be fitted to the hose, such as a 20-inch
wand for cleaning hard-to-reach areas or a 9-foot
extension hose, which creates a total length of 15
feet...perfect for cleaning stairs.
Full Bag or Clog Indicator – When a full bag, a clog
in the airflow pathway, or an excessively dirty
microfilter is detected, an indicator gauge on the
bag housing lid “fills” with orange color and an air-
flow bypass valve opens, to prevent overheating
and motor damage from a lack of adequate airflow.
Three-level Adjustable Handle – This feature
provides compact storage, maneuverability
when suction unit is detached, and easy
adjustment to user height requirements.
Variable Suction Control on Handle with Soft Start –
The user can select the suction power needed,
from curtains to carpet. And its gradual power-up
extends motor life.
Innovative Exhaust Filter...Design and Function-
ality – Behind the stylish surface hides an ultra-
modern S-class exhaust microfilter that not only
provides excellent filtration, but it also absorbs
motor noise, resulting in extremely quiet operation.
Thirty-one Foot Cord with Rotating Quick-release
Hook – It is easy to quickly unwind the cord by
rotating the hook!
SEBO FELIX RODUCT FEATURES
ET Power Heads -
Designed for All Floor Surfaces.
The power head deep cleans carpets, or its spinning brush roller
can be shut off to clean delicate rugs and hard floors with straight
suction. It also has easy brush roller removal, and an orange warn-
ing light illuminates when brush height is set too high for optimal
cleaning, the bristles are worn, or automatic shut-off occurs due to
a brush obstruction.
Two Power Head Widths with One-sided Edge
Cleaning – The FELIX 1 Premium model is 12
inches wide with a 10 1⁄2-inch cleaning path. The
FELIX 2 Premium - Ice Blue is 14 3⁄4. inches wide
with a 13-inch cleaning path.
ulti-surface Cleaning Capabilities – With a
power head for carpets and a parquet brush for
hard floors, the FELIX PREMIUM provides all the
cleaning flexibility of a canister vacuum!
anual and Automatic Brush Shut Off – The FELIX can clean
delicate rugs or hard floors with straight suction because the
brush roller can be manually switched off by pressing the green
illuminated on/off button on the power head cover. Also, the
brush roller automatically shuts off when the suction hose is
removed from its housing port or when the handle is in its
upright locked position.
Brush Obstruction Light with Automatic
Brush Shut Off – If an obstruction jams the
brush roller, an orange warning light on the
power head illuminates and the brush roller
stops spinning. This feature prevents the belts
from breaking and protects the motor and car-
pet from damage.
Four-level anual Brush Height Adjustment – The brush can
be adjusted up or down for optimal cleaning effectiveness.
Easy Brush Removal and Cleaning – Cleaning
hair or other debris from the brush roller or
replacing it when its bristles are worn is quick
and easy, and no tools are required! This fea-
ture ensures consistently effective brush agita-
tion of the carpet pile.
Easy aintenance – The clog removal door and brush roller are
easy to access on the power head.
4
FELIX Premium odel Includes Power Head, Two On-board
Tools and Parquet Brush – Along with a commercial quality
power head, the FELIX Premium comes standard with a crevice
tool, upholstery nozzle and a premium parquet brush,
which is
perfectly designed for cleaning hard floors.
FELIX Kombi odel Includes Kombi Nozzle and Two On-board
Tools – The FELIX Kombi does not have a power head. Instead,
it includes a Kombi nozzle (a straight suction nozzle for hard
floors and rugs), crevice tool and upholstery nozzle. The Kombi
can accommodate a FELIX Premium power head, which can be
purchased separately.

STANDARD FEATURES OF ALL SEBO VACUUMS
55
Designed and anufactured in Germany – Legendary quality,
reliability and performance make SEBO vacuums the choice of
cleaning professionals throughout the world.
Excellent for Users With Allergies or Asthma – The British
Allergy Foundation recommends SEBO filters.
Tightly Sealed Vacuums Ensure Effective Filtration – Dirty air,
which flows through a vacuum, can only be filtered completely
if it does not escape into the room through seams or seals in
the machine. This is why all SEBO vacuums have tight seals
throughout. Many vacuum companies with high-filtration
claims are actually quoting specifications made by the manu-
facturer of the filter material, as measured in the laboratory,
not the filtration effectiveness of the vacuum itself while oper-
ating. Whether or not dirty air can escape through leaks in the
body of the machine is not considered. The filtration effective-
ness of SEBO vacuums is tested while they operate.
Save oney! SEBO Vacuums Last for Years and Extend Carpet
Life! – If properly maintained, SEBO vacuums save ordinary
residential users hundreds of dollars by providing excellent
performance for ten to fifteen years or more, and their deep-
cleaning power-brush technology extends the life of carpets.
Typical vacuums perform poorly, even when new, and usually
do not last beyond two years. So six or seven “disposable vacu-
ums” must be purchased during the average life expectancy of
just one SEBO machine.
Outstanding Warranty Coverage – SEBO is confident about the
quality of all its vacuums. Therefore, all models include a five-
year warranty on the motor and all non-wear parts.
SEBO icrofilters Ensure Continuously Strong Suction
Performance – They are also long lasting, inexpensive and easy
to change in seconds.
Changing Bags is Easy and Clean – SEBO fil-
ter bags can be changed in just a few sec-
onds, and a cap keeps dust sealed inside
during removal and disposal.
Effective Pet Hair Removal – All SEBO vac-
uums easily remove pet hair!
SEBO’s FILTRATION SYSTE :
Step One. Bags are Better! – On all models,
top-fill, three and four-layer bags are an
integral part of SEBO’s filtration system
because they hold virtually all dirt captured
by the vacuum, which improves the effec-
tiveness and useful life of the microfilters.
They also ensure continuously strong suc-
tion because dirt enters from the top,
deposits at the bottom, accumulates
upward, and air exits through the sides,
which allows unimpeded airflow as they fill
to capacity. And they can be sealed when
full, so no dust can escape into the air dur-
ing bag removal and disposal.
In contrast, without bags to hold nearly all
the captured dirt, the microfilters on bag-
less vacuums quickly clog from excessive
dirt build-up and must be replaced often, or
a loss of suction and cleaning effectiveness
will occur. In addition, dust and other aller-
gens become airborne when emptying bag-
less dirt containers. Lastly, bagless vacuum
microfilters are expensive, usually costing
more than a multi-year supply of SEBO fil-
ter bags.
Step Two. Pre-motor F lters – Pre-motor
filters clean suction air after it passes
through the filter bag, but before it passes
over the vacuum motor. Cooling the motor
with clean air is important because this
increases useful life expectancy.
Step Three. S-class Exhaust M crof lters –
S-class Exhaust Microfilters (S =“Schwebstoff”
= airborne particles) are made from electro-
statically charged micro-fiber material,
which attracts and captures dust particles
from the airflow of the vacuum after it pass-
es over the motor to cool it. This means that
exhaust air is cleaned to the highest level.
The S-class Standard requires filters to
absorb greater than 99.9% of particles down to 0.3 microns in
diameter. For comparison, 100 microns is the diameter of a
human hair. Their advantages are a relatively open texture that
allows smoother airflow for better suction performance, a
longer life expectancy, and they cost less than HEPA filters.

O TIONAL ATTACHMENTS, ACCESSORIES, BAGS & FILTERS
6
In addition to the standard on-board tools, a variety of optional
attachments are available. The 9-foot extension hose (extends
suction hoses) and the 20-inch extension tube are very popular
because they create useful tools for cleaning stairs and out-of-
reach areas.
The Dusting Brush, Straight Tube and Extension Hose
are sold separately and are also available as a 3-piece attachment
kit.
Another popular attachment is the hand-held Turbo Brush
with an
air driven rotating brush for removing pet hair from
upholstery and stairs.
Motor Protection/
Carbon Filters
Part #7012ER
Exhaust Filter
Fun - Part #7095ER01
IceBlue - Part #7095ER02
Classic - Part #7095ER03
Onyx - Part #7095ER04
White - Part # 7095ER11
Rosso - Part # 7095ER12
Premium Parquet Brush
Ice Blue, Onyx, White &
Rosso #7200 S
Fun #7200VO
Classic #7200SR
Kombi Nozzle
Ice Blue, Onyx, White &
Rosso #7260 S
Fun #7240VO
Classic #7240SR
Filter Bags (10)
Part #7029ER
3-piece Attachment Kit
Part #1998AM
See page 10 for more information on the Premium Parquet
Brush and Kombi Nozzle.
SEBO filter bags can be purchased in boxes of ten and filters are
sold as a set. SEBO bags, filters and accessories are reasonably
priced and widely available.
To create a fresh scent while vacuuming, “SEBO FRESH” is
available. To use, deposit a scented stick in the filter bag.
SEBO FRESH
Part #0496AM
Dusting Brush
Part #1387D
Wall & Floor Brush
Part #1325H
Flat Upholstery
Nozzle
Part #1090H
Hand-held Turbo
Brush
Part #6179DA
Radiator Brush
Part #1496D
20-inch Extension Tube
Part #1084H
9-foot Extension Hose
Part #1495AM
Shoulder Strap
Part #7158

IDENTIFICATION OF ARTS
7
Place the power head (16, 28) or floor tool (29, 30) on the floor with the
swivel neck (20) upright. Hold the vacuum vertically and Insert the suction
opening of the vacuum into the swivel neck of the head or tool. Push firm-
ly and evenly downward until the tool release button (14) snaps into the
locked position - see figure 1.
Insert the black end of the hose (6) into the connection on the filter cover
(8) - see figure 2a. Insert the hose handle (19) into the suction opening (18)
on the side of the vacuum - see figure 2b.
Note: Hose must be fully insert-
ed to activate the power head. Press the hose into place on the side of the
machine.
Install the attachment clip (21) to the handle assembly (5) using the includ-
ed screw. Insert the crevice nozzle and upholstery nozzle into the clip - see
figure 3.
Standard Attachments
21. Attachment clip
22. Crevice Nozzle
23. Upholstery Nozzle
NOTE: All illustrations shown in this manual represent the FELIX Premium model except
where part numbers and instructions are different for each model.
Power Heads
16. ET-1: 12-inch Power head, Standard on Premium,
optional for Kombi.
White, orange, red, ivory or black
28. ET-2: 15-inch Power head, Standard on ICE Blue 2,
optional for Ice Blue Kombi. White
Floor Tools
29. Premium Parquet Brush, standard on Premium,
optional for Kombi.
ray black, orange or ivory
30. Kombi Nozzle, standard on Kombi,
optional for Premium.
ray black, orange or ivory
1. Handle grip
2. Upper cable hook
3. On/Off switch, suction control slider
4. Power cable
5. Handle Assembly
6. Hose
7. Bag full indicator
8. Filter bag cover
9. Filter bag housing
10. Filter bag housing release latch
11. Carrying handle
12. Exhaust filter
13. Exhaust filter clamps
14. Tool release button
15. Foot pedal
16. Power head
17. Cable hook
18. Suction opening
19. Hose handle
20. Swivel neck
ASSEMBLY
16
28
21
22
23
L
R
29
30
Figure 1 Figure 2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
2
4
6
13
17
12
11
18
19
20
15
Figure 3
a.
b.

8
O ERATING INSTRUCTIONS
Starting The achine - Figures 3, 4 & 5
Before turning on your vacuum cleaner, make sure that the vacuum is in its
upright locked position and that you have a firm hold on the handle grip to keep
the machine from moving forward.
1. With the power switch (3) in the OFF position, turn the cable hook (17) to the
left or right to release the cable (4). Lift the cable off the upper cable hook -
see figure 3.
2. Adjust the telescopic handle tube (5) to the correct height by pulling out the
handle release lever (32) and gently pulling the tube out to lengthen, or push-
ing it in to shorten. The tube will click into place when it reaches one of the
three lengths available. Release the tab. If the tab does not fit snugly in place,
the tube is set at an incorrect setting. Pull or push the tube until it locks into
one of the three settings - see figure 4.
3. Plug the polarized power cord into a 120 volt wall outlet located near the floor.
4. Slide the On/OFF switch (3) downward toward the MAX position - see figure 5.
Operating the achine - Figures 5 & 6
You may adjust the suction control with the suction control slider (3) as you vacuum different sur-
faces or when using the accessory tools. Slide the button upward for less suction or downward for
more suction - see figure 5
When changing power heads and floor tools, always switch the vacuum off with the main power
switch (3), and then unplug the power cord. NOTE: When switching off the power switch, always
make sure the switch “clicks” into the OFF position before unplugging the power cord.
When you have finished using the vacuum, turn it off by sliding the on/off switch to the OFF posi-
tion. Then, unplug the cord and wind it onto the upper cable hook and upper hook. The rubber tip
on the end of the handle allows the vacuum to be propped against a wall without damage.
WARNING! The quality, condition, coating, texture, age and manufacturing technique of all floor surfaces vary.
Therefore, vacuums with rotating brushes, including your SEBO, may damage some floor coverings or surfaces. Some types
of high-gloss hardwood floors, cushion vinyl, berber carpets, long shag, and delicate or hand-woven carpets are particularly vul-
nerable to damage by rotating brushes. When possible, consult the materials supplied by your flooring manufacturer for infor-
mation on proper upkeep and cleaning. To ensure that your new SEBO vacuum cleaner is compatible with your floor, please
!
4
Figure 3 Figure 4
17
Figure 5
+
MAX
OFF
5
Using the Hose Handle, Hose & Attachments - Figures 6 & 7
The hose handle (19) is useful for vacuuming corners and hard-to-reach areas. You may use the hose
handle with or without an attachment. Pull the hose handle (19) from the suction opening (18) in the
side of the vacuum. Keep a firm hold on the handle grip while using the hose handle as it could tip
if the hose is pulled too far. The standard attachments [the crevice nozzle (22) and upholstery noz-
zle (23)] and optional attachments [the hand-held Turbo brush (24), dusting brush (25), straight tube
(26) and extension hose (27)] may be inserted onto the hose handle. It is not necessary to turn off the
vacuum while switching the attachments. NOTE: When using the hose and attachments, keep the
vacuum in its upright position.
To change a floor tool or power head, switch off the power and unplug the vacuum. Press the tool
release button (14) and pull the vacuum out of the swivel neck (20). Insert the vacuum into the new
tool and push down gently until it snaps into place. Plug the vacuum in and switch the power on.
Detachable Suction Unit - Figure 7
When detached from the power head, or floor tool, the FELIX transforms itself into a lightweight,
powerful suction unit, which can be carried around using its comfortable carrying handle (figure 7).
Ideal for cleaning stairs, car interiors or upholstery. To remove a floor tool or power head, switch off the power and unplug
the vacuum. Press the tool release button (14) and pull the vacuum out of the swivel neck (20).
Full Bag or Clog Indicator – Figure 4
When a full bag, a clog in the airflow pathway, or an excessively dirty microfilter is detected, an indicator gauge on the bag
housing lid (7) “fills” with orange color. The user should turn the switch off, unplug the machine and immediately insert a new
bag or remove the clog (to remove a clog, refer to the Clog Removal section on page 12). If the airflow is still restricted, the
“BA FULL OR CLO ” indicator will again display and the machine will shut off.
Figure 7
3
32
Figure 6
19
18
test the vacuum cleaner on each type of flooring surface in a small inconspicuous area to determine if any damage
occurs. If damage occurs, stop using the vacuum cleaner immediately!
7

9
Operating with the Power Head - Figures 8, 9 & 10
When the power head is on with the handle in the upright locked position (see figure 8), the
brush roller on your power head will not spin.
To release the power head from the upright locked position, press down on the foot pedal
(#15, figure 9) and lower the handle into the normal operating position. The brush roller
will then start spinning and the green light on the power head will illuminate. The handle
can be lowered to a horizontal position useful for vacuuming under beds.
NOTE: the brush roller is off and stopped only when the machine is in an upright position
and the handle is completely locked in place, or when the hose handle is removed from the
side of the vacuum. If you have the machine at an angle, the brush roller will spin. Leaving
the machine in a stationary position for an extended period of time while the brush roller
is spinning may cause damage to your floor or carpet. You may also switch off the brush
roller by pressing the on/off switch (#35, figure 11) on the top of the power head.
You may adjust the suction control with the suction control slider (#3, figure 5) as you vac-
uum different surfaces or when using the accessory tools. For optimal cleaning and brush-
ing, operate the machine at the maximum suction power setting and push the power head
slowly over the carpet.
Always turn the power switch off when changing heads or unplugging the vacuum. Slide
the power control slider on to its OFF position, then unplug the vacuum when changing
heads or storing the vacuum. Make sure the handle is in its upright locked position before
letting go of the handle. NOTE: When switching off the power switch, always make sure the
switch “clicks” into the OFF position before unplugging the power cord.
The use of a power head is recommended for the optimal cleaning of carpets. The rotating
of the swivel neck (#20, figure 10) allows the power head to move in any direction.
ADDITIONAL O ERATING INSTRUCTIONS FOR OWER HEADS
Figure 8
Figure 9
The Brush Height Adjustment Feature - Figure 11
To manually adjust the brush height, rotate the dial (33) for high carpet (dial set-
ting 4) and progressively lower to bare floor (dial setting 1). The amber light
located on top of the power head (34) will illuminate if the height setting is too
high (the green light (35) will also be illuminated). Dial down to the next number
until the amber light turns off (the green light will stay illuminated). If the amber
light does not turn off, the brush roller may be worn. Intermittent flickering is
normal.
Figure 11
33
34
35
Indicator Lights - Figure 11
By pushing the foot pedal (figure 9) and lowering the handle, you activate the power head and the brush begins spinning.
Failure to use the foot pedal will cause lasting damage to the machine. The electronic brush control constantly monitors the
status of the brush, communicating the status through the lights on top.
Green and Amber Light: The brush is not fully engaged in the carpet. The height adjustment should be lowered. If the
(34 and 35, figure 11) height adjustment is at its lowest setting, the brush is worn and needs to be replaced.
Green Light Only: Brush is working well. We strongly recommend selecting a brush height that is only one level
(35, figure 11) beneath that at which both the green and amber lights are on. For maximum cleaning perform-
ance, the brush height adjustment can be lowered to its lowest setting.
Amber Light Only: The brush is blocked. Turn off the machine, unplug it, and then remove the blockage.
(34, figure 11)
To clean delicate or hard floor surfaces, the power head is equipped with an on/off switch (# 35, figure11). When this switch
is used to turn off the brush roller, the green indicator light is also turned off.
Figure 10
20
15
Brush Obstruction Light & Auto Shut Off – Figure 11
If an obstruction becomes jammed in the brush roller, an amber warning
light will quickly flash (34), the brush roller will immediately stop spinning
and the vacuum will shut off. The user should turn the power switch off, unplug
the machine, and immediately remove the obstruction. If the user restarts the
machine without removing the obstruction, the power head will again shut off
and the amber light will turn on.
This prevents the belt from breaking and pro-
tects the motor from damage.

OWER HEAD MAINTENANCE
10
To remove a brush or floor tool, switch off the power and unplug the
vacuum. Then, press the tool release button (14) and pull the vacuum out of the
neck.
Premium Parquet Brush - Figure 13
The Premium parquet brush is specially designed for use on hard surfaces. The
brush should be cleaned regularly. Remove the parquet brush from the vacuum to
clean. Fibers and hair can be pulled out of the bristles manually, or vacuum the
bristles using the flexible hose.
Kombi Nozzle - Figure 14
The Kombi nozzle is adjustable for carpet or hard floors. To set for carpet, slide the
up arrow button (39) to the right until it clicks into place. The hard floor dusting
brush will raise up allowing the head to move over the carpet. To set for hard floors,
slide the down arrow button (40) to the left until it clicks into place. The brush will
lower to gently sweep your floors. The sl der n F gure 14 s set n the pos t on for
carpet. The brush should be cleaned regularly. Remove the Kombi nozzle from the
vacuum to clean. Fibers and hair can be pulled out of the bristles manually, or vac-
uum the bristles using the flexible hose.
Figure 13
Figure 14
40
Always unplug vacuum from outlet before dismantling any part of machine!
!
USE AND MAINTENANCE OF FLOOR TOOLS AND BRUSHES
39
L
L
L
L
To remove the power head, switch off the power and unplug the
vacuum. Then, press the tool release button (12) and pull the vacuum
out of the swivel neck.
Removing the Brush Roller - Figure 12
To remove the brush roller, press the button marked “PRESS” (36) and
turn the brush roller end cap (37) downward. Turn the brush (38) slight-
ly to the right and pull it out. We recommend regular removal of threads
and hair which have wound around the brush roller.
Cleaning the Brush Roller
Unplug the vacuum before attempting to clean the brush.
The brush should be cleaned regularly. Fibers and hair can be pulled out
of the brush while manually rotating the roller, or the roller can be
removed from the power head to clean it.
Always unplug vacuum from outlet before dismantling any part of the machine!
!
Figure 12
36
37
38
12” Brush roller
Part # 5010AM
15” Brush roller
Part # 2838AM

11
VACUUM MAINTENANCE
Changing the Filter Bag - Figures 17 & 18
To change the filter bag, set the canister upright, open the filter bag
cover (8) by pulling the cover release flap (10) upward (figure 17).
Seal the filter bag with the sealing cap (42). rasp the sealing plate
(44) of the filter bag with your thumb and forefinger as shown in fig-
ure 18 and lift the filter bag (43) out. Lower a new bag into the hold-
er, making sure that the 4 small tabs (indicated by arrows on the
sealing plate) fit into the appropriate grooves. The front tab (45) of
the sealing plate will fit loosely over the wire latch lock. Push the
filter bag cover (8) down firmly and snap the cover release flap (10)
into place. For your convenience, there is a diagram on every filter
bag showing the correct placement of the bag. Do not re-use the
filter bags. NOTE: The nature of the contents of the filter bag will
affect the point at which it needs changing. Fine dust may require
an earlier change even though the bag is not full. Fluff or hair allows
air to pass through easily, so the filter bag may overfill before the
orange “bag full” indicator displays.
Changing the Exhaust Filter - Figures 19 & 20
The exhaust filter (12) needs to be changed when it becomes
extremely dirty or clogged with dust, or after approximately 15 to
20 filter bags have been used. To remove the exhaust filter, set the
vacuum upright, and remove the filter retaining rings (13). To
release the filter retaining ring, use your thumb to push the retain-
ing ring clip the direction of the arrow, then pull the clip up. Pull the
plastic reinforced fabric strips out of the housing slot (48), and
remove the filter. To replace the filter, insert the plastic strip on one
end of the filter into the housing slot (48) and hold in place with one
hand while wrapping the filter around the machine, pulling it
taught. While holding the filter together, insert the top of the plas-
tic strip into the slot. While holding the top of the strip in place,
push the rest of the strip firmly into the slot. Replace the retaining
rings.
NOTE: When reassembling, please ensure that the exhaust
filter is fitted correctly in the housing slots and the filter retaining
rings are installed correctly. Otherwise, the filter will be ineffec-
tive.
Figure 18
Figure 20
Figure 19
Always unplug vacuum from outlet
before dismantling any part of machine!
!
Changing the otor Protection/Carbon Filter -
Figure 19
After 10 to 20 bags have been used, change the motor protec-
tion/carbon filter (46). To remove the filter, set the vacuum upright,
pull the cover release flap (10) outward and open the filter bag
cover (8). Remove the filter bag (see above). rasp the handle (47)
on the filter and pull it out. To replace, use the handle (47) to hold
on to and slide the new filter down into the bottom of the filter bag
housing. When correctly seated, it will snap into place. Insert the
filter bag, close the filter bag cover.
Figure 16
NOTE: Never operate the vacuum with incorrectly attached filters or without filters, filter bag, or filter bag housing
cover (8). Do not re-use filter bags. Do not wash and re-use filters.
7
4243
45 44
13
Figure 17
13
43
12
46
48
12
12
47
Filter bag
Part # 7029ER
Motor protection/
carbon filter
Part # 7012ER
Exhaust filter
Part #:
7095ER01 - Fun
7095ER02 - Ice Blue
7095ER03 - Classic
7095ER04 - Onyx
7095ER11 - White
7095ER12 - Rosso
When the “bag full” indicator (7) displays, airflow is reduced due to
a full filter bag, dirty filters, or a clog. If the filter bag is empty and
the filters are clean, you may have a clog. Refer to page 12.
8
10

CLOG REMOVAL
12
Clogs in the Hose - Figures 21, 22, 23 & 24
Check for suction at the end of the hose (6) by pulling the hose handle (19) out of the
suction opening (18). If you can only feel a small amount of suction, the clog is in the
hose. To clear a blockage in the hose, hold the hose handle upright with one hand
blocking the top and switch on the machine. Quickly lift your hand on and off the end
of the hose. If that does not clear the clog, you may also clear clogs by reversing the
hose. To remove the hose from the machine, lift the filter bag cover. Loosen the safe-
ty ring (#49, figure 23) located inside the cover by pushing the lever clockwise as
shown in figure 23. Remove the hose. Close the filter bag cover and insert the hose
handle into the connecting tube (#50, figure 24) of the filter cover. Hold the hose
upright with one hand blocking the top and switch on the machine. If necessary, quick-
ly lift your hand on and off the end of the hose. When the clog is cleared, remove the
hose handle from the connecting tube. Loosen the safety ring (49) and insert the other
end of the hose back into the connecting tube. Release the safety ring so that it
secures the hose. Make sure the hose is connected, then close the filter bag cover.
Note: Do not insert a wire or stick into the hose. Doing so may cause damage to the
hose.
Clogs in the Swivel Neck - Figure 25
To check for a clog in the swivel neck (20), remove the head by pressing the release but-
ton (14). Pull the vacuum out of the swivel neck. Clean out pathway.
Always unplug vacuum from outlet before removing any clogs!
!
Figure 26
Figure 22
Figure 21
6
7
8
Figure 23
49
19
8
18
Figure 24
6
19
50
CLOG REMOVAL IN THE OWER HEAD
Clogs in the Airflow Pathway - Figure 26
Many clogs can be removed by accessing the airflow pathway via the orange colored
access door (51) located on the underside of the power head.
Clogs in the Swivel Neck - Figures 26 & 27
To check for a clog in the swivel neck (20), remove the head by pressing the release but-
ton (14). Pull the vacuum out of the swivel neck. Push the obstruction down the neck
with a stick or long screwdriver and remove it through the orange access door (51).
51
Figure 27
14 20
L
R
Figure 25
20
14

TROUBLE-SHOOTING GUIDE
13
PROBLE
Does not turn on
Bag full indicator shows
Poor Suction
Does not pick up
Filter bag door won’t
fully close
Filter bag doesn’t fit into
position
REASON
1. Not plugged into working outlet.
2. Cord worn, cut or broken.
3. The power control slider switch is
set to the “OFF” position.
1. Bag full.
2. Clog in hose, swivel neck, brush or
head
1. Exhaust filter dirty.
1. Hose handle is not correctly
inserted into suction opening.
2. Hose is not connected correctly
into the connecting tube.
3. The suction control dial is rotated
to no suction setting.
4. Filter bag cover not closed.
1. Cover release flap not fully closed.
2. Bag not inserted properly.
3. Cover latch spring bent.
1. Motor protection filter not
properly inserted.
SOLUTION
1. Use another outlet.
2. Replace cord.
3. Slide slider switch toward the MAX
position. See page 8.
1. Replace filter bag. See page 11.
2. See Clog Removal on page 12.
1. Replace exhaust filter. See page 11.
1. Reinsert hose handle firmly into
suction opening.
2. Check the safety ring. See page 12.
3. Slide suction control slider to
higher suction setting. See page 8.
4. See below.
1. Reinsert bag. Lock the cover
release flap (10) down firmly.
2. Reinsert bag. Lock the cover
release flap (10) down firmly.
3. Straighten cover latch spring.
1. Remove the filter bag and make
sure the motor protection filter is
seated correctly See page 11.
Always unplug vacuum from outlet before dismantling any part of the machine!
!
NOTE: Power head users, please see page 14 for additional
trouble shooting guide information.

14
ADDITIONAL TROUBLE-SHOOTING GUIDE FOR OWER HEADS
PROBLE
Does not turn on
Bag full or clog light on
& machine shuts off
Amber and green lights
are both on
No lights are
illuminated
Amber light is on &
power head shuts off
Does not pick up
REASON
1. The switch on the power head
is off.
2. The internal switch in the
swivel neck is off because the
machine is in the upright locked
position.
3. The switch in the air duct housing
is not engaged.
1. Clog in hose, swivel neck, brush or
head
1. Brush worn.
2. Reduced brush action.
3. Incorrect pile adjustment setting
1. Main power switch on handle is in
the “off” position.
2. The switch on the power head
is off.
3. The internal switch in the
swivel neck is off because the
machine is in the upright locked
position.
1. Obstruction in brush roller.
2. Clog in airflow pathway or
swivel neck.
3. Overload shut down from
excessively deep but loose
carpet pile (e.g., long shag
carpet).
1. Brush roller has hair or debris
wrapped around it.
SOLUTION
1. Press the power head brush
on/off switch. See page 9.
2. Release the foot pedal and
lower the machine to
operating level. See page 9.
3. Re-insert the hose handle (19) into
the suction opening (18).
1. See Clog Removal on page 12.
1. Replace brush. See page 10.
2. Brush is not fully in contact
with the floor.
3. Re-position pile adjustment knob
1. Slide power swith to “on” and
adjust suction level.
2. Press the power head brush
on/off switch. See page 9.
3. Release the foot pedal and
lower the vacuum to operating
level. See page 9.
1. Remove brush roller
obstruction. See page 10.
2. Remove clog. See page 12.
3. If carpet pile is too deep and
loose, then use a “shag rake”
attachment instead of the
ET-1 or ET-2 power head.
1. Clean brush roller. See page 10.
Always unplug vacuum from outlet before dismantling any part of the machine!
!

15
FELIX REMIUM / KOMBI
#9806AM FELIX PREMIUM Ice Blue (White/Blue) - 12 inch
#9803AM FELIX PREMIUM Fun (Orange/Purple) - 12 inch
#9804AM FELIX PREMIUM Classic (Ivory/Plaid) - 12 inch)
#9807AM FELIX PREMIUM Onyx (Black/Silver) - 12 inch
#9808AM FELIX PREMIUM White (White) - 12 inch
#9809AM FELIX PREMIUM Rosso (Red) - 12 inch
#9813AM FELIX PREMIUM Ice Blue (White Blue) - 15 inch
#9824AM FELIX KOMBI Ice Blue (White/Blue)
#9825AM FELIX KOMBI Fun (Orange/Purple)
#9826AM FELIX KOMBI Classic (Ivory/Plaid)
Bag Hous ng w th Handle
9806A , 9813A , 9824A Ice Blue (White/Blue) achines
Pos. Part # Descr pt on
1 7078 S Air duct
27064 Internal wiring harness ET
3 7071 Internal cable
401016 Screw STS 4x16 - T20
5 7056 S Valve cover
6 7111ER Printed circuit board 120V
77098 Sound insulation
8 1047 VAC motor seal
97009 Rubber mounting
10 7041ER VAC motor 120V
11 05140S Carbon brush set
12 7143ER Dust bag housing
13 7012ER Motor Protection filter
14 7081ER Handle tube
15 0127 Screw M 4x10K
16 7025 Valve disc
17 7028ER Valve spring set (old & new)
18 7090 S Hose duct
19 7027 S Cable hook
20 7093WE Cover, dust bag housing w/35&45 - white
21 01017 Screw STS 4x20 - T20
22 7029ER Dust bag
23 7091WE Filter cover - white
24 7095ER02 Exhaust filter
25 7017 S Exhaust filter clamp - gray black
26 7159WESE Lower housing - white
27 7145 S Tube plug
28 7164WE Handle complete w/15, 32-34
29 7127D Cable
30 7038WE Switch assembly, cpl.
31 7050SB Hose cpl.
33 0103 Screw C3.9x16
35 7082WE Handle release lever, cpl
36 7094ER Filter Indicator, cpl.
37 7018OR Retaining ring w/spring
38 7032ER Switch lever, cpl.
39 7260 S Kombi nozzle (Incl. w/KOMBI)
7248ER Brush strip w/cap for KOMBI
40 1491 S Upholstery nozzle - gray black
41 1092 S Crevice nozzle - gray black
42 7097WE Double attachment clip - white
43 7200 S Premium Parquet Brush (incl. w/PREMIUM)
7207ER Brush Strip Set (2 pcs. for 7200)
44 7212 S Button cover for 7200
45 7024ER Cover latch spring
9803A & 9825A Fun (Orange/Purple) achine Exceptions
20 7093VO Cover, dust bag housing w/35&45 - orange
23 7091VO Filter cover - orange
24 7095ER01 Exhaust filter
26 7170SE Lower housing
28 7164 SVO Handle complete w/15, 32-34
30 70038VO Switch assembly, cpl.
35 7082VO Handle release lever, cpl
39 7240VO Kombi nozzle (incl. w/KOMBI)
42 7097VO Double attachment clip - orange
43 7200VO Premium Parquet Brush (incl. w/PREMIUM)
9807A Onyx (Black/Silver) achine Exceptions
18 7090SW Hose duct
19 7027SW Cable hook
20 7093SW Cover, dust bag housing w/35&45 - black
23 7091SW Filter cover - black
24 7095ER04 Exhaust filter
25 7017SB Exhaust filter clamp - silver
26 7173SE Lower housing
28 7164 SSW Handle complete w/15, 32-34
30 7038SW Switch assembly, cpl.
35 7082SW Handle release lever, cpl
40 1491SW Upholstery nozzle - black
41 1092SW Crevice nozzle - black
42 7097SW Double attachment clip - black
9808A White (White) achine Exceptions
18 7090WE Hose duct
19 7027WE Cable hook
24 7095ER11 Exhaust filter
25 7017H Exhaust filter clamp - light gray
40 1491JE Upholstery nozzle - light gray
41 1092JE Crevice nozzle - light gray
9809A Rosso (Red) achine Exceptions
18 7090DR Hose duct
19 7027DR Cable hook
20 7093DR Cover, dust bag housing w/35&45 - red
23 7091DR Filter cover - red
24 7095ER12 Exhaust filter
25 7017SB Exhaust filter clamp - silver
26 7186SE Lower housing
28 7164 SDR Handle complete w/15, 32-34
30 7038DR Switch assembly, cpl.
35 7082DR Handle release lever, cpl
42 7097 S Double attachment clip - gray black
9804A & 9826A Classic (Ivory/Plaid) achine Exceptions
18 7090SR Hose duct
19 7027SR Cable hook
20 7093HE Cover, dust bag housing w/35&45 - ivory
23 7091HE Filter cover - ivory
24 7095ER03 Exhaust filter
25 7017SR Exhaust filter clamp - burgundy
26 7168SE Lower housing
28 7164HE Handle complete w/15, 32-34
29 7127SR Cable
30 7038HE Switch assembly, cpl.
31 7050HE Hose cpl. - ivory
34 1035SR Cable grommet
35 7082HE Handle release lever, cpl
39 7240SR Kombi nozzle (Incl. w/KOMBI)
40 1491HE Upholstery nozzle - ivory
41 1092HE Crevice nozzle - ivory
42 7097SR Double attachment clip - burgundy
43 7200SR Premium Parquet Brush (incl. w/PREMIUM)
40
41
42

FELIX REMIUM
#9806AM FELIX PREMIUM Ice Blue (White/Blue) - 12 inch
#9803AM FELIX PREMIUM Fun (Orange/Purple) - 12 inch
#9804AM FELIX PREMIUM Classic (Ivory/Plaid) - 12 inch
#9807AM FELIX PREMIUM Onyx (Black/Silver) - 12 inch
#9808AM FELIX PREMIUM White (White) - 12 inch
#9809AM FELIX PREMIUM Rosso (Red) - 12 inch
Power Head - 12 nch (ET-1)
9806A Ice Blue (White/Blue) achines
Pos. Part # Descr pt on
100 2324 S Chassis ET-1
101 2302 S Bumper, cpl.
102 2314 S Bearing block, left cpl.
103 2923 Belt 333 3M HTDII-6
104 5010AM Brush roller, cpl.
105 2313 S Bearing block, right cpl.
106 2929 Spring
107 2316 S Pile adjustment assembly, cpl.
108 2909VO Access door w/axle & spring
109 2304 S Rear bottom plate, cpl.
110 2931 S Pile adjustment button
111 2306 S Wheel, cpl.
112 2937OR Foot pedal w/axle & spring
113 2307 S Swivel neck assembly, cpl.
114 0876ER Wiring swivel neck
115 2947 S Cover, TS-neck
116 2950ER Segments, TS-neck
117 1737 S Release button w/leaf spring
118 2952 S Button cover, TS-neck
119 2945 S Swivel neck slide
120 2951 S Socket cover, TS-neck
121 01027 Screw F 3.9x9.5
122 2954 Swivel neck bearing
123 2311 Swivel neck support, right
124 2312 Swivel neck support, left
125 0880 Wiring swivel neck switch
126 2928 Axle
127 01021 Screw F 3.9x13
128 2973ER Brush motor 120V, 175W w/ pulley
129 05141S Carbon brush set
130 01020 Screw F 3.9x21
131 2958ER Lever w/leaf spring
132 05114 Switch 2 - pole
133 0881 Wire
134 2983ER Printed circuit board - 175W
135 2331WESE Power head cover
136 0176TL Screw AM 4x30
137 5402 Wire tie
138 2319 Motor pulley
139 2957 On/Off button/lens
140 2956 Brush light lens
141 2959ER Switch cpl (131-133)
9803A Fun (Orange/Purple) achine Exceptions
135 2333VOSE Power head cover
9804A Classic (Ivory/Plaid) achine Exceptions
100 2324SR Chassis ET-1
101 2302SR Bumper, cpl.
105 2313SR Bearing block, right cpl.
110 2931SR Pile adjustment button
111 2306SR Wheel, cpl.
113 2307SR Swivel neck assembly, cpl.
115 2947SR Cover, TS-neck
117 1737SR Release button w/leaf spring
118 2952SR Button cover, TS-neck
119 2945SR Swivel neck slide
120 2951SR Socket cover, TS-neck
135 2332HESE Power head cover
9807A Onyx (Black/Silver) achine Exceptions
110 2931SB Pile adjustment button
135 2360SWSE Power head cover
9808A White (White) achine Exceptions
100 2324H Chassis ET-1, light gray
101 2302H Bumper, cpl.
102 2314H Bearing block, left cpl.
105 2313H Bearing block, right cpl.
107 2316H Pile adjustment assembly, cpl.
109 2304H Rear bottom plate, cpl.
110 2931H Pile adjustment button
111 2306H Wheel, cpl.
113 2307H Swivel neck assembly, cpl.
115 2947H Cover, TS-neck
117 1737H Release button w/leaf spring
118 2952H Button cover, TS-neck
119 2945H Swivel neck slide
120 2951H Socket cover, TS-neck
9809A Rosso (Red) achine Exceptions
110 2931SB Pile adjustment button
135 2330DRSE Power head cover - red
16

17
FELIX REMIUM - ICE BLUE
#9813AM FELIX PREMIUM Ice Blue (White Blue) - 15 inch
Power Head - 15 nch (ET-2)
9813A Ice Blue (White/Blue) achine
Pos. Part # Descr pt on
100 2325 S Chassis ET-2
101 2303 S Bumper, cpl.
102 2314 S Bearing block, left cpl.
103 2923 Belt 333 3M HTDII-6
104 2838AM Brush roller, cpl.
105 2313 S Bearing block, right cpl.
106 2929 Spring
107 2316 S Pile adjustment assembly, cpl.
108 2909VO Access door w/axle & spring
109 2305 S Rear bottom plate, cpl.
110 2931 S Pile adjustment button
111 2306 S Wheel, cpl.
112 2937OR Foot pedal w/axle & spring
113 2307 S Swivel neck assembly, cpl.
114 0876ER Wiring swivel neck
115 2947 S Cover, TS-neck
116 2950ER Segments, TS-neck
117 1737 S Release button w/leaf spring
118 2952 S Button cover, TS-neck
119 2945 S Swivel neck slide
120 2951 S Socket cover, TS-neck
121 01027 Screw F 3.9x9.5
122 2954 Swivel neck bearing
123 2311 Swivel neck support, right
124 2312 Swivel neck support, left
125 0880 Wiring swivel neck switch
126 2928 Axle
127 01021 Screw F 3.9x13
128 2974ER Brush motor 120V, 200W w/pulley
129 05141S Carbon brush set
130 01020 Screw F 3.9x21
131 2958ER Lever w/leaf spring
132 05114 Switch 2 - pole
133 0881 Wire
134 2984ER Printed circuit board - 200W
135 2341WESE Power head cover
136 0176TL Screw AM 4x30
137 5401 Wire tire
138 5402 Wire tire
139 2319 Motor pulley
140 2957 On/off button/lens
141 2956 Brush light lens
142 2959ER Switch (131-133)
