Sena R1 EVO User manual

SMART CYCLING HELMET
1.0.1
QUICK START GUIDE
ENGLISH

RIDE CONNECTED
The R1 EVO with built-in Bluetooth®capabilities
allows you to hear GPS navigation, take phone
calls and listen to your favorite tunes. You can
use the Mesh IntercomTM to communicate with
other R1 EVO users and use the LED Taillight to
ride safely.
Bluetooth®Integrated
Mesh Intercom™
900 meters (0.5 miles)*
LED Taillight
Voice Command
* in open terrain

GETTING STARTED
1. This product comes with a Quick Start
Guide, which is a basic version of the
User’s Guide. A FULL VERSION OF THE
USER’S GUIDE CAN BE DOWNLOADED
AT SENA.COm.
2. Update this product for free with the latest
firmware to fully enjoy the new advanced
features built into this product. Visit
sena.com to see how to update your
product.
3. Users can follow Sena on Facebook,
YouTube, Twitter and Instagram to
receive the most up to date information
on products, helpful tips and all other
announcements regarding Sena products.
GETTING STARTED
SENA Technologies, Inc.
sena.com
Customer Support: support.sena.com

Product Details
Speakers
Bluetooth
System's Buttons
Microphone
Center
Button
(+) Button
Blue/Red/
Green
LED Lights
(-) Button
Fault Reset Button
DC Power Charging &
Firmware Upgrade Port
SENA Button
QuICk START GuIDE
QuICk START GuIDE

How To Fit the Helmet
1. Position the helmet on your head with the
front covering your forehead.
2. Position the strap adjuster centered, just
below your ears.
3. Position the helmet low on your forehead
with the buckle under the chin and back
against the throat. The straps should fit
comfortably around both ears.
4. After removing the chinstrap pad, adjust
the chinstrap tension at the buckle so
the chinstrap is tight and comfortable
by pulling the chinstrap end through
the buckle to either tighten or loosen as
needed.
Chinstrap
Strap Adjuster
Buckle
Chinstrap Pad
O-Ring
QuICk START GuIDE

5. Secure the excess strap with O-ring and
then attach the chinstrap pad.
Note: Check the
chinstrap’s position and
tension regularly to ensure
proper fit.
6. Turn the retention system knob clockwise
to tighten or counterclockwise to loosen.
7. To change the height of the retention
system, firmly pull or push the retention
system upward or downward to a different
position.
Retention System Knob Retention System
WARNING: For maximum protection, this helmet
must be fitted and attached properly to the wearer’s
head in accordance with the following instructions. If
after adjustment the helmet does not fit properly, do
not use the helmet. Return it to the retailer or Sena.
QuICk START GuIDE

Sena Cycling App
By simply pairing your phone with your headset, you can
use the Sena Cycling App for quicker and easier set up
and management.
• App Features: Mesh Intercom, Music, FM Radio, LED
Taillight, Device settings, Quick Start Guide, and User’s
Guide.
• Download
- Android: Google Play Store> ‘Sena Cycling’
- iOS: App Store > ‘Sena Cycling’
Sena Device Manager
The Sena Device Manager allows you to upgrade the
firmware and configure its settings directly from your PC
or Apple computer. Download the Sena Device Manager
from sena.com.
QuICk START GuIDE

Basic Operations
QuICk START GuIDE
Checking the Battery Level
Powering On
=1s
HOLD
Volume Up
=
1x
TAP
Powering Off
=
1x
TAP
Volume Down
=
1x
TAP
Visual Method
=1s
HOLD
=
HIGH
=
MED
=
LOW

QuICk START GuIDE
Mobile Phone Pairing
Press and hold the (+) Button and Center Button for
10 seconds when the R1 EVO is turned off.
=10s
HOLD
=
Alternating blue
and red flashing
lights indicate
device is now
discoverable.
LED
STATUS
=
PIN
NUMBER
Phone Pairing

QuICk START GuIDE
Mobile Phone
Answer a Call
=1x
TAP
End/Reject a Call
=2s
HOLD
Make Call with
Voice Dialer
=3s
HOLD
Music Controls
Play/Pause
=1s
HOLD
Next Track
=1s
HOLD
Previous Track
=1s
HOLD

QuICk START GuIDE
Mesh Intercom™
When Mesh Intercom is enabled, the R1 EVO will
automatically connect to nearby R1 EVO users and allow
them to talk to each other by pressing the Center Button.
Mic Enable/Disable (Default: Enable)
Users can enable/disable the microphone when
communicating in a Mesh Intercom.
Enable/Disable the Microphone
=1s
HOLD
Mesh Intercom On
=1x
TAP
“Mesh intercom on”
Mesh Intercom Off
=1x
TAP
"Mesh intercom off"

QuICk START GuIDE
Channel Setting (Default: channel 1)
If the Mesh Intercom communication experiences interference
because other groups are also using channel 1, change the
channel. You can select one of 1 to 9 channels.
Using the button
Enter into the Channel Setting
=2x
TAP
“Channel setting, 1”
Navigate Between the Channel
(1 2 ••• 8 9 Exit 1 •••)
=
1x
TAP
or =1x
TAP
“#”
Save the Channel
=1x
TAP
"Channel is set, channel #"

QuICk START GuIDE
Note: To exit the Channel Setting, tap the (+) Button
or the (-) Button until you hear a voice prompt, “Exit”,
and tap the Center Button.
Using the Sena Cycling App
You can select the channel through the Sena Cycling App.

Radio
QuICk START GuIDE
FM Radio On
=1s
HOLD
Scan Stations
=1s
HOLD
=1s
HOLD
Navigating Preset
Stations
=1s
HOLD
Note: You can also use the Sena Device Manager or
the Sena Cycling App to save the preset stations.
FM Radio Off
=1s
HOLD
Seek Stations
=
2x
TAP
=
2x
TAP

LED Taillight
Using the Voice Command
LED On
=1x
TAP =“Taillight”
or
“Hello Sena”
LED Off
=1x
TAP =“Taillight”
or
“Hello Sena”
Using the SENA Button
LED On and Solid Night Flash
=1x
TAP 1s~
=1x
TAP 1s~
Day Flash LED Off
=1x
TAP 1s~
=1x
TAP
Using the Sena Cycling App
You can control the LED Taillight through the Sena
Cycling App.
QuICk START GuIDE

QuICk START GuIDE
Bluetooth System Configuration
Menu
Accessing the
Configuration Menu
=10s
HOLD
Execute Menu Options
=1x
TAP
Navigating Between
Menu Options
=1x
TAP
=1x
TAP
Troubleshooting
Factory Reset
=10s
HOLD
=2x
TAP
=1x
TAP
Fault Reset
=
Note: Fault Reset
will not restore the
Bluetooth system to
factory default settings.

TYPE OPERATION BUTTON COMMANDS
Basic
Operations
Power on 1s
HOLD
Power off 1x
TAP
Volume up/down or 1x
TAP
Mobile
Phone
Answer phone call 1x
TAP
End/reject phone call 2s
HOLD
Voice dial 3s
HOLD
Music
Play/Pause music 1s
HOLD
Track forward 1s
HOLD
Track back 1s
HOLD
QuICk REFERENCE
QuICk REFERENCE

TYPE OPERATION BUTTON COMMANDS
Mesh
Intercom™
Mesh Intercom
on/off 1x
TAP
Mic enable/disable 1s
HOLD
Channel setting 2x
TAP
FM Radio
FM radio on/off 1s
HOLD
Select preset 1s
HOLD
Seek forward/
backward or 2x
TAP
Scan up FM band/
stop scanning 1s
HOLD
LED Taillight
LED on and solid 1x
TAP
1x
TAP
1x
TAP
1x
TAP
Night flash
Day flash
LED off
QuICk REFERENCE
D00161_1.0.1_EN_February2020
