The FramePro ®701XP nailers are designed with the
Pro in mind. XtremePro models have improved internal and
external features for improved durability and comfort. These
compact framers are easy to handle, and easy on the arm. The
30˚ short, in-line magazine, provides excellent maneuverability
and line of sight. Drive a wide range of fasteners from 2" to 3½"
to handle virtually any job.
Applications:
For framing, truss building, sub flooring, sheathing, decking,
wood-to-concrete block, siding, fencing, pallets and crate
assembly
Features and Benefits:
• Five-year limited warranty
• Upgraded XtremePro internal features include:
anodized sleeve for additional strength and durability;
urethane sleeve cap protects sleeve from wear;fixed
fi ring valve improves tool life and speed; and positive
stop guide body aligns nail and driver for consistent drive
• Comfort and convenience features include: overmold
grip and trigger, 360° adjustable exhaust, rafter hanger
and construction ruler
• Aggressive sawtooth safety that really digs in for toenailing
•Straight-line 30˚ magazine for better line of sight and simple
two-step loading
• Last nail lock out, prevents dry firing
Tool Specifications:
Power: 904 in/lbs
Item#: 2H0133N Sequential
Weight: 8.0 lbs (3.6 kg
Height: 3¼ " (336.5 mm)
Length: 14¼" (362 mm)
Nail Capacity: 56-80, depending on gauge
Reg. Operating Pressure: 70 –120 psig
Mode of Operation: Available with either Restrictive Trigger or
Dual Action activating mechanisms.
Fastener Specifications:
FramePro 701XP nailer drives 2" to 3½" smooth shank
nails (Sencote®or plain); 2" to 3" ring-shank nails; 3" screw-shank
and clipped“D” head nails. Shank diameters include .113", .120"
and .131".
FramePro®701XP
XtremePro™ 3½" Framing/Sheathing Nailer
®
©2007 Senco Products, Inc. www.senco.com

Adjustable Exhaust 360°
Ergonomic Design –
Superb balance for use all day
Aggressive Toenail Safety –
Teeth grip studs with real bite
for precise positioning
Dry Fire Lockout –
Prevents dry firing, missed operations
and signals when to reload
In-line Magazine –
Better line of sight for
right and left handers
improves balance and
reduces fatigue
Overmold Trigger
Construction Ruler –
For quick measurements
Full Comfort Overmold Grip –
Reduces fatigue
Rear Two-Step Loading –
Quick and easy for right or left handers
®
®
Rafter Hanger
EZ-Clear Mechanism –
Minimizes time freeing jammed nails
No-Mar Pad –
Protects work surface
FramePro®701XP
XtremePro™ 3½" Framing/Sheathing Nailer
Always read the Operators Manual and Safety Instructions with all tools to ensure
proper use and safety precautions. For additional information on trigger systems and
how SENCO will save you time, reduce costs, and increase quality, call our toll-free
Action Line: 800-543-4596 to find your nearest Authorized Senco Dealer, Distributor
or visit our web site at: www.senco.com
®
©2007 Senco Products, Inc. www.senco.com
Choose the right trigger system for your specific needs!
Sequential Actuation Trigger (also known as restrictive trigger or trigger fire) operates in the
following a sequence - depress the safety element at the nose of tool against the work surface
then pull the trigger. After each fastener is driven, release the trigger and lift the tool off the
work surface before starting the sequence again. This trigger is recommended and acceptable
for most applications.
Contact Actuation Trigger (also known as dual action, bounce or bottom fire) operates in the
following sequence- pull the trigger first and keep the trigger pulled while moving the tool
along the work surface with a bouncing motion, depressing the safety element at the nose of
the tool against the work surface where the fastener is to be driven. This trigger is
recommended for use by trained professionals only in high production or volume applications.
Thumb Wheel Adjustable
Depth-of-Drive –
Drives nails to a consistent
and controllable depth
5-Year Limited
Warranty –
XP Durability
