Sennheiser ew 112 G3 User manual

ew 100 Sets
ew 112 G3 Presentation Set
ew 122 G3 Presentation Set
ew 152 G3 Headset
ew 172 G3 Instrument Set
ew 135/145/165 G3 Vocal Sets
The ew 122 G3 is a wireless microphone set. The ew 122 G3 consists of the
same components as ew 112 G3 but with ME 4 clip-on cardioid microphone.
The compact clip-on microphone rejects noises coming from the side which means
less risk of feedback.
The ew 152 G3 is a wireless microphone set. The ew 152 G3 consists of the
same components as ew 112 G3 but with ME 3 headworn cardioid microphone.
The included condenser headworn
microphone is easy to wear, has
great pop protection and produces
powerful sound.
FEATURES
Sturdy metal housing (transmitter

and receiver)
42 MHz bandwidth: 1,680 tunable UHF

frequencies for interference-free reception
Enhanced frequency bank system with up

to 12 compatible frequencies
High-quality true diversity reception

Automatic frequency scan feature

searches for available frequencies
Pilot tone squelch for eliminating

RF interference when transmitter is
turned off
Enhanced AF frequency range

Increased range for audio sensitivity

Wireless synchronization of transmitters

via infrared interface
Illuminated graphic display (transmitter

and receiver)
Auto-Lock function avoids accidental

changing of settings
HDX compander for crystal-clear sound

Transmitter feature battery indicatation in

4 steps, also shown on receiver display
Programmable Mute function

Integrated Equalizer and Soundcheck mode

Contacts for recharging BA 2015 accupack

directly in the transmitter
Wide range of accessories adapts the

system to any requirement
The ew 112 G3 is a wireless microphone set, consisting of a True Diversity
receiver, a bodypack transmitter with ME 2 clip-on omni-directional microphone
plus accessories. It is versatile for
every style of presentations.
A wireless link from receiver to the
transmitter allows synchronization
of frequencies for easy setup. Backlit
graphic displays make them easy to
read under all lighting conditions.

The ew 135 G3 is a wireless microphone set, consisting of a True Diversity
receiver, a handheld transmitter with e 835 microphone head plus accessories.
It is versatile for every style of music and presentations. A wireless link from
receiver to the transmitter allows synchronization of frequencies for easy setup.
Backlit graphic displays make them easy to read under all lighting conditions.
The ew 145 G3 consists of the same components as ew 135 G3
but with an e 845 microphone head.
The ew 165 G3 consists of the same components as ew 135 G3
but with an e 865 microphone head.
FEATURES
ew 135 G3/ew 145 G3/
ew 165 G3 Vocal Sets
See above mentioned list of features plus
Handheld transmitter with easy-

exchangeable microphone heads from
evolution series
ew 100 Sets
The ew 172 G3 is a wireless instrument set, consisting of a True Diversity
receiver, a bodypack transmitter with CI 1 jack cable plus accessories. It is versatile
for picking up instruments.
The system features a virtual cable
emulator to get sound response just
like a cable, a built-in guitar tuner
and an EQ. The frequency respon-
se starts at 25 Hz for natural bass
reproduction.

ew 100 Sets
ARCHITECT’S SPECIFICATIONS
ew 112 G3 Presentation Set
Complete plug & play wireless microphone set with clip-on microphone (permanent polarized, omni-directional) for multi-purpose
application. The devices shall have metal housings for rugged use. 42 MHz bandwidth with 1,680 tunable frequencies. 20 banks
with up to 12 compatible frequencies, 1 bank for individual selectable frequencies. Scan function and wireless synchronization to the
transmitter for easy setup. HDX compander delivers high-quality sound performance. The transmitter shall have a sensitivity range
of 48 dB. The receiver offers a maximum output level of +18 dBu (+6 dB gain). True Diversity and pilot tone squelch for interference-
free reception.
The transmitter shall have a programmable Mute switch (RF on/off, AF on/off, disabled)
Charging contacts on transmitter for recharging BA 2015 accu pack directly in the transmitter shall be available. 3-step battery + Low-
Battery indication on transmitter and receiver shall give reliable information on operation time. Menu operation, auto-lock function and
illuminated graphic displays on transmitter and receiver for user-friendly operation.
A RF Mute function on transmitter and receiver allows offline settings. An equalizer and soundcheck mode is integrated in the receiver.
A wide range of clip-on and headworn microphones and accessories shall be available for the system. The wireless microphone system
shall feature a true-diversity receiver with 42 MHz of available tuning bandwidth with a total of 1,680 frequencies accessible in 25 kHz
steps. The wireless microphone receiver must feature one balanced XLR output with a max. output of +18 dBu, and one unbalanced ¼”
output with a max. output of +12 dBu. The wireless microphone receiver must feature two BNC antenna inputs, one for each receiver
module in the true diversity system.
The wireless microphone receiver must feature an automatic frequency scanning function that utilizes twenty (20) banks of pre-coor-
dinated frequencies that are free of intermodulation interference. The wireless microphone receiver must also feature a user bank in
order to store user defined frequencies. The wireless microphone transmitter must operate on two 1.5 V AA battery cells. The wireless
microphone transmitter must have access to 1,680 frequencies tuned in 25 kHz steps across a defined 42 MHz bandwidth. The wireless
microphone transmitter must feature a backlit display that displays frequency information, AF level, battery level. The wireless micro-
phone transmitter must transmit a pilot-tone squelch. The wireless microphone transmitter must have a specified RF output power of
30 mW. The wireless microphone receiver must accept 12 V DC power via BNC antenna inputs.
ew 122 G3 Presentation Set
Complete plug & play wireless microphone set with clip-on microphone (condenser, cardioid) from Sennheiser evolution series for
multi-purpose application. Further discription see paragraph ew 112 G3.
ew 152 G3 Head Set
Complete plug & play wireless microphone set with headworn microphone (permanent polarized, cardioid) for hands-free
application. Further discription see paragraph ew 112 G3.
ew 172 G3 Head Set
Complete plug & play wireless instrument set from Sennheiser evolution series for multi-purpose application.
Further discription see paragraph ew 112 G3.
ew 135 G3 Vocal Set
Complete plug & play wireless microphone set with easy-exchangeable e 835 microphone head (dynamic, cardioid) from Sennheiser
evolution series for multi-purpose application.
Further discription see paragraph ew 112 G3.
ew 145 G3 Vocal Set
Complete plug & play wireless microphone set with easy-exchangeable e 845 microphone head (dynamic, super-cardioid) from
Sennheiser evolution series for multi-purpose application. Further discription see paragraph ew 112 G3.
ew 165 G3 Vocal Set
Complete plug & play wireless microphone set with easy-exchangeable e 865 microphone head (electret-condenser, super-cardioid)
from Sennheiser evolution series for multi-purpose application.
Further discription see paragraph ew 112 G3.

ew 100 Sets
TECHNICAL DATA
SYSTEM
RF frequency range ................................................516…865 MHz
1,785....1,800 MHz
Transmission/receiving frequencies...................512.....1,865 MHz: 1,680
1,785....1,800 MHz: 1,500
Presets.......................................................................12
Switching bandwidth.............................................512.....1,865 MHz: 42 MHz
1,785....1,800 MHz: 15 MHz
Compander ...............................................................HDX
Frequency response ...............................................25…18,000 Hz
Signal-to-noise ratio ..............................................> 110 dB(A)
THD, total harmonic distortion ............................< 0,9 %
RECEIVERS
True diversity
Antenna connector.................................................2 x BNC, 50 O
Audio output level (balanced).............................XLR: +18 dBu max
Audio output level (unbalanced)........................Jack: +12 dBu max
Dimensions...............................................................202 x 212 x 43 mm
Weight.......................................................................~ 900g
TRANSMITTER
RF output power .....................................................typ. 30 mW battery AA (Mignon)
Power supply............................................................2 x AA batteries
Operating time ........................................................typ. 8h
Input voltage range mic ........................................1.8 V eff
Input voltage range line........................................3 V eff
Dimensions...............................................................82 x 64 x 24 mm
Weight.......................................................................~ 160g
Continued on page 5

ew 100 Sets
TECHNICAL DATA
Microphones (SK 100)
ME 2 ME 3-ew ME 4
Microphone type ............................. condenser condenser condenser
Sensitivity......................................... 20 mV/Pa 1.6 mV/Pa 40 mV/Pa
Pick-up pattern................................ omni-directional cardioid cardioid
Max. SPL............................................ 130 dB SPL 150 dB SPL 120 dB SPL
Microphone heads (SKM 100)
MMD 835-1 MMD 845-1 MMK 865-1
Radio microphone type ................. dynamic dynamic condenser
Sensitivity......................................... 2.1 mV/Pa 1.6 mV/Pa 1.6 mV/Pa
Pick-up pattern................................ cardioid super-cardioid cardioid/super-cardioid,
switchable
Max. SPL............................................ 154 dB SPL 154 dB SPL 152 dB SPL
Frequency response ....................... 80.....18,000 Hz 80.....18,000 Hz 80.....18,000 Hz
DELIVERY INCLUDES for ew 112 / ew 122 / ew 152 / ew 172 G3
1 EM 100 G3 rack-mount receiver
1 SK 100 G3 bodypack transmitter
1 ME 2 clip-on microphone (omni-directional) (ew 112) or
1 ME 4 clip-on microphone (cardioide) (ew 122) or
1 ME 3-ew headset microphone (cardioid) (ew 152) or
1 CI instrument cable (ew 172)
1 NT 2 power supply unit
2 Antennas
2 Stacking elements
2 AA batteries
1 Instruction Manual
DELIVERY INCLUDES for ew 135 / ew 145 / ew 165 G3
1 SKM 100-835 G3 handheld transmitter
with cardioid dynamic head or
1 SKM 100-845 G3 handheld transmitter
with super-cardioid dynamic head or
1 SKM 100-865 G3 handheld transmitter
with super-cardioid condenser head
1 EM 100 G3 rack receiver
1 MZQ 1 microphone clip
1 NT 2 power supply unit
2 Antennas
2 Stacking elements
2 AA batteries
1 Instruction Manual

ew 100 Sets
DIMENSIONS
EM 100 G3SK 100
CONNECTIVITY
21
3
+
SKM 100

ew 100 Sets
POLAR PATTERN
0
5
10
15
20
25
dB
30°30°
60°
60°
90°90°
120°
150°
120°
150°
0°
180°
125 Hz
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
8000 Hz
16000 Hz
ME 3-ew ME 4-ew
MMD 835-1
MME 865-1
MMD 845-1
0
5
10
15
20
25
dB
30°30°
60°
60°
90°90°
120°
150°
120°
150°
0°
180°
125 Hz
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
8000 Hz
16000 Hz
0
5
10
15
20
25
dB
30°30°
60°
60°
90°90°
120°
150°
120°
150°
0°
180°
125 Hz
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
8000 Hz
16000 Hz
0
5
10
15
20
25
dB
30°30°
60°
60°
90°90°
120°
150°
120°
150°
0°
180°
125 Hz
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
8000 Hz
16000 Hz
0
5
10
15
20
25
dB
30°30°
60°
60°
90°90°
120°
150°
120°
150°
0°
180°
125 Hz
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
8000 Hz
16000 Hz

ew 100 Sets
FREQUENCY RESPONSE
ME 4-ew
Hz
100 1.00010.000
dBV
-10
-20
-30
-40
-50
-60
50 100
0° / 1 m 90° / 1 m
200 5001k 2k 5k 10k20k
0° / 10 cm
ME 2
Hz
100 1.00010.000
dBV
-10
-20
-30
-40
-50
-60
50 100 200 5001k 2k 5k 10k20k
ME 3-ew
Hz
100 1.00010.000
dBV
-40
-50
-60
-70
-90
-100
50 100
1 m5cm
200 5001k 2k 5k 10k20k
MME 865-1
Hz
100 1.00010.000
dBV
-30
-40
-50
-60
-70
-8050 100
0° 90°
200 5001k 2k 5k 10k20k
MMD 835-1
Hz
100 1.00010.000
dBV
-30
-40
-50
-60
-70
-8050 100 200 5001k 2k 5k 10k20k
MMD 845-1
Hz
100 1.00010.000
dBV
-30
-40
-50
-60
-70
-8050 100 200 5001k 2k 5k 10k20k

PRODUCT VARIANTS
ew 112 G3 Presentation Set Cat. No.
ew 112 G3-A-EU 516...558 MHz 503100
ew 112 G3-A-US 516...558 MHz 503169
ew 112 G3-A-UK 516...558 MHz 503170
ew 112 G3-G-EU 566...608 MHz 503171
ew 112 G3-G-US 566...608 MHz 503172
ew 112 G3-G-UK 566...608 MHz 503173
ew 112 G3-B-EU 626...668 MHz 503174
ew 112 G3-B-US 626...668 MHz 503175
ew 112 G3-B-UK 626...668 MHz 503176
ew 112 G3-C-EU 734...776 MHz 503177
ew 112 G3-C-US 734...776 MHz 503178
ew 112 G3-C-UK 734...776 MHz 503179
ew 112 G3-D-EU 780...822 MHz 503180
ew 112 G3-D-EU-X 780...822 MHz 503181
ew 112 G3-D-UK 780...822 MHz 503182
ew 112 G3-E-EU 823...865 MHz 503183
ew 112 G3-E-EU-X 823...865 MHz 503184
ew 112 G3-E-UK 823...865 MHz 503185
ew 112 G3-GB 606…648 MHz 504638
ew 112 G3-1G8
1,785…1,800 MHz 504900
ew 122 G3 Presentation Set Cat. No.
ew 122 G3-A-EU 516...558 MHz 503101
ew 122 G3-A-US 516...558 MHz 503187
ew 122 G3-A-UK 516...558 MHz 503188
ew 122 G3-G-EU 566...608 MHz 503189
ew 122 G3-G-US 566...608 MHz 503190
ew 122 G3-G-UK 566...608 MHz 503191
ew 122 G3-B-EU 626...668 MHz 503192
ew 122 G3-B-US 626...668 MHz 503193
ew 122 G3-B-UK 626...668 MHz 503194
ew 122 G3-C-EU 734...776 MHz 503195
ew 122 G3-C-US 734...776 MHz 503196
ew 122 G3-C-UK 734...776 MHz 503197
ew 122 G3-D-EU 780...822 MHz 503198
ew 122 G3-D-EU-X 780...822 MHz 503199
ew 122 G3-D-UK 780...822 MHz 503200
ew 122 G3-E-EU 823...865 MHz 503201
ew 122 G3-E-EU-X 823...865 MHz 503202
ew 122 G3-E-UK 823...865 MHz 503203
ew 122 G3-GB 606…648 MHz 504639
ew 122 G3-1G8
1,785…1,800 MHz 504901
ew 152 G3 Presentation Set Cat. No.
ew 152 G3-A-EU 516...558 MHz 503102
ew 152 G3-A-US 516...558 MHz 503205
ew 152 G3-A-UK 516...558 MHz 503206
ew 152 G3-G-EU 566...608 MHz 503207
ew 152 G3-G-US 566...608 MHz 503208
ew 152 G3-G-UK 566...608 MHz 503209
ew 152 G3-B-EU 626...668 MHz 503210
ew 152 G3-B-US 626...668 MHz 503211
ew 152 G3-B-UK 626...668 MHz 503212
ew 152 G3-C-EU 734...776 MHz 503213
ew 152 G3-C-US 734...776 MHz 503214
ew 152 G3-C-UK 734...776 MHz 503215
ew 152 G3-D-EU 780...822 MHz 503216
ew 152 G3-D-EU-X 780...822 MHz 503217
ew 152 G3-D-UK 780...822 MHz 503218
ew 152 G3-E-EU 823...865 MHz 503219
ew 152 G3-E-EU-X 823...865 MHz 503220
ew 152 G3-E-UK 823...865 MHz 503221
ew 152 G3-GB 606…648 MHz 504640
ew 152 G3-1G8
1,785…1,800 MHz 504902
ew 172 G3 Instrument Set Cat. No.
ew 172 G3-A-EU 516...558 MHz 503103
ew 172 G3-A-US 516...558 MHz 503223
ew 172 G3-G-EU 566...608 MHz 503224
ew 172 G3-G-US 566...608 MHz 503225
ew 172 G3-B-EU 626...668 MHz 503226
ew 172 G3-B-US 626...668 MHz 503227
ew 172 G3-C-EU 734...776 MHz 503228
ew 172 G3-C-US 734...776 MHz 503229
ew 172 G3-D-EU 780...822 MHz 503230
ew 152 G3-D-EU-X 780...822 MHz 503231
ew 172 G3-D-UK 780...822 MHz 503332
ew 172 G3-E-EU 823...865 MHz 503233
ew 172 G3-E-EU-X 823...865 MHz 503234
ew 172 G3-E-UK 823...865 MHz 503235
ew 152 G3-GB 606…648 MHz 504641
ew 152 G3-1G8
1,785…1,800 MHz 504903
Continued on page 10
ew 100 Sets

PRODUCT VARIANTS
ew 135 G3 Vocal Set Cat. No.
ew 135 G3-A-EU 516...558 MHz 503104
ew 135 G3-A-US 516...558 MHz 503237
ew 135 G3-A-UK 516...558 MHz 503238
ew 135 G3-G-EU 566...608 MHz 503239
ew 135 G3-G-US 566...608 MHz 503240
ew 135 G3-G-UK 566...608 MHz 503241
ew 135 G3-B-EU 626...668 MHz 503242
ew 135 G3-B-US 626...668 MHz 503243
ew 135 G3-B-UK 626...668 MHz 503244
ew 135 G3-C-EU 734...776 MHz 503245
ew 135 G3-C-US 734...776 MHz 503246
ew 135 G3-C-UK 734...776 MHz 503247
ew 135 G3-D-EU 780...822 MHz 503248
ew 135 G3-D-EU-X 780...822 MHz 503249
ew 135 G3-D-UK 780...822 MHz 503250
ew 135 G3-E-EU 823...865 MHz 503251
ew 135 G3-E-EU-X 823...865 MHz 503252
ew 135 G3-E-UK 823...865 MHz 503253
ew 135 G3-GB 606…648 MHz 504642
ew 135 G3-1G8
1,785…1,800 MHz 504904
ew 145 G3 Vocal Set Cat. No.
ew 145 G3-A-EU 516...558 MHz 503105
ew 145 G3-A-US 516...558 MHz 503255
ew 145 G3-G-EU 566...608 MHz 503256
ew 145 G3-G-US 566...608 MHz 503257
ew 145 G3-B-EU 626...668 MHz 503258
ew 145 G3-B-US 626...668 MHz 503259
ew 145 G3-C-EU 734...776 MHz 503260
ew 145 G3-C-US 734...776 MHz 503261
ew 145 G3-D-EU 780...822 MHz 503262
ew 145 G3-D-EU-X 780...822 MHz 503263
ew 145 G3-D-UK 780...822 MHz 503264
ew 145 G3-E-EU 823...865 MHz 503265
ew 145 G3-E-EU-X 823...865 MHz 503266
ew 145 G3-E-UK 823...865 MHz 503267
ew 145 G3-GB 606…648 MHz 504643
ew 145 G3-1G8
1,785…1,800 MHz 504905
ew 165 G3 Vocal Set Cat. No.
ew 165 G3-A-EU 516...558 MHz 503106
ew 165 G3-A-US 516...558 MHz 503269
ew 165 G3-G-EU 566...608 MHz 503270
ew 165 G3-G-US 566...608 MHz 503271
ew 165 G3-B-EU 626...668 MHz 503272
ew 165 G3-B-US 626...668 MHz 503273
ew 165 G3-C-EU 734...776 MHz 503274
ew 165 G3-C-US 734...776 MHz 503275
ew 165 G3-D-EU 780...822 MHz 503276
ew 165 G3-D-EU-X 780...822 MHz 503277
ew 165 G3-D-UK 780...822 MHz 503278
ew 165 G3-E-EU 823...865 MHz 503279
ew 165 G3-E-EU-X 823...865 MHz 503280
ew 165 G3-E-UK 823...865 MHz 503281
ew 165 G3-GB 606…648 MHz 504644
ew 165 G3-1G8
1,785…1,800 MHz 504906
ew 100 Sets

RECOMMENDED ACCESSORIES
Cat. No.
Earworn microphones, 3.5 mm jack plug
omni:
black Ear Set 1-ew 504232
beige Ear Set 1-ew-3 504233
cardioid:
black Ear Set 4-ew 504236
beige Ear Set 4-ew-3 504237
Clip-on microphones, 3.5 mm jack plug
omni:
black MKE 1-ew 502876
white MKE 1-ew-1 502877
brown MKE 1-ew-2 502878
beige MKE 1-ew-3 502879
black
MKE 2-ew Gold 009831
beige
MKE 2-ew-3 Gold 0 09832
black MKE 40-ew 500527
Headmicrophones thin connection cable, 3.5 mm jack plug
omni:
black HSP 2-ew 009866
beige HSP 2-ew-3 009872
cardioid:
black HSP 4-ew 009867
beige HSP 4-ew-3 009873
Headmicrophones thin connection cable, 3.5 mm jack plug,
shorter microphone boom and smaller neckband
omni:
black HSP 2-ew-M 500693
beige HSP 2-ew-3-M 500692
cardioid:
black HSP 4-ew-M 500699
beige HSP 4-ew-3-M 500698
Antenna Splitter for 1800 MHz – ASA 1-1G8 504914
Antenna Booster for 1800 MHz – AB 3-1G8 504915
Directional Antenna for 1800 MHz – AD 1800 504916
19“ RackMount Kit – GA 3 503167
Antenna Front Mount Kit – AM 2 009912
Power supply for one L 2015
NT 1-1-EU (EU version, 230 V) 503158
NT 1-1-UK (UK version, 230 V) 503874
NT 1-1-US (US version, 120 V) 503873
Power supply for up to three L 2015
NT 3-1-EU (EU version, 230 V) 503159
NT 3-1-UK (UK version, 230 V) 503877
NT 3-1-US (US version, 120 V) 503876
GA 3 – Rack-mount kit 503167
AM 2 – Antenna Mount kit 009912
CC 3 – System Case 503168
L 2015 – Charging unit 009828
BA 2015 – Rechargeable battery pack 009950
Cat. No.
ASA 1 – Active antenna splitter 503165
A 1031 – Antenna 004645
A 2003 – Passive directional antenna 003658
AB 3 – Antenna booster 021822
ME 4 – Clip-on microphone, cardioid, black 503156
CI 1 – Instrument cable 503163
ew 135 / ew 145 / ew 165 G3 Vocal Sets
MMD 835-1 – evolution microphone head 502575
MMD 845-1 – evolution microphone head 502576
MME 865-1 – evolution microphone head 502581
MZW 1 – Windshield 004839
KEN 2 – Identification rings 530195
LA 2 – Charging adapter for
handheld microphones 503162
CC 3 – System case 503168
Sennheiser electronic GmbH & Co. KG
Am Labor 1, 30900 Wedemark, Germany
www.sennheiser.com
04/13 Sennheiser is a registered trademark of Sennheiser electronic GmbH & Co. KG. www.sennheiser.com. Copyright © 04/2013. All rights reserved. Errors and omissions excepted.
ew 100 Sets
Contact your local Service Partner:

ew 100 G3 Presentation Set
ew 100 ©Presentation Sets
RF Wireless Systems | evolution wireless G3
General Description
This system is ideal for theater and presentation use. The ME 2 and ME 4 clip-
on microphones are virtually invisible. The extremely small SK 100 G3 body-
pack transmitter and the EM 100 G3 rack-mountable receiver each feature
20 frequency banks with one user bank and 12 directly accessible frequency
presets. Each system is ready for immediate use.
Technical Specifications
ew 100 ©
Modulation............................................... wideband FM
Frequency ranges .......................516–558, 566–608,
................... 626–668, 734–776, 780–822, 823–865
Transmission/Receiving
frequencies .............. 20 channel banks, 1 user bank,
...................................12 factory preset channels each
Switching bandwidth........................................42 MHz
Noise reduction system.....................Sennheiser HDX
AF frequency response.......................25 – 18,000 Hz
S/N ratio (at 1mV and peak deviation) .. ≥110 dBA
THD (at nominal deviation and 1 kHz) ........ .≤0.9 %
EM 100 ©
Receiver principle................................... True Diversity
Sensitivity (with HDX,
peak deviation)................... <2.5 µV at 52 dBAeff S/N
Adjacent channel rejection..............................≥65 dB
Intermodulation attenuation..........................≥65 dB
Blocking ...............................................................≥70 dB
Pilot-tone squelch....................................... detachable
Antenna inputs ...................................... 2 BNC sockets
AF output voltage (at peak deviation,
1 kHz AF)......................... 1/4“ (6.3 mm) jack socket,
................................ unbalanced: +12 dBu XLR socket,
...........................................................balanced: +18 dBu
Power supply......................................................12 V DC
Dimensions ................................7.48“ x 8.35“ x 1.69“
Weight ................................................. approx. 1.99 lbs
SK 100 ©
RF output power at 50 Ω......................... typ. 30 mW
AF frequency response...........25 – 18,000 Hz (Line)
Max input voltage transmitter / line..................3 Veff
Input impedance transmitter / line ................ 40 kΩ,
.......................................................... unbalanced / 1MΩ
Power supply..............................2 AA batteries, 1.5 V
Nominal voltage..................................................... 2.4 V
Operating time...................................................typ. 8 h
Dimensions ................................3.23“ x 2.52“ x 0.94“
Weight .................................................. approx. 5.64 oz
ME 2
Transducer principle.....................................condenser
Sensitivity ...................................................... 20 mV/Pa
Pick-up pattern ..................................omni-directional
Max. SPL ....................................................... 130 dB SPL
ME 4
Transducer principle.....................................condenser
Sensitivity ...................................................... 40 mV/Pa
Pick-up pattern ................................................. cardioid
Max. SPL ....................................................... 120 dB SPL
System variants and included components:
ew 112 G3 – (1) SK 100 G3 bodypack transmitter, (1) ME 2 omni-
directional clip-on microphone, (1) EM 100 G3 rack-mountable receiver
ew 122 G3 – (1) SK 100 G3 bodypack transmitter, (1) ME 4 cardioid clip-
on microphone, (1) EM 100 G3 rack-mountable receiver
For recommended accessories please visit www.sennheiserusa.com
Features
Sturdy metal housing
Automatic frequency management for transmitter and receiver
Tunable UHF frequencies within a large switching bandwidth
Programmable MUTE switch
Wireless synchronization of transmitters via infrared interface
Enhanced frequency bank management with up to 12 compatible
frequencies
42 MHz bandwidth, 1,680 switchable frequencies
Increased range for audio sensitivity
Easy-to-read illuminated dot matrix display with warning indicator
More control options (menu)
Enhanced AF frequency range
Soundcheck mode
Integrated equalizer
Contacts for recharging the BA 2015 accupack directly in the
transmitter
(2) AA batteries for over 8 hours of use
4-level battery indicator for transmitter
HDX compander for crystal-clear sound
True diversity receiver for optimum reception
High RF output power for large range
Suitable for 19” rack mounting (1 U)
ew 112 ©Presentation Set
with ME 2 clip-on microphone
ew 122 ©Presentation Set
with ME 4 clip-on microphone

ew 100 ©Presentation Sets
RF Wireless Systems | evolution wireless G3
Architect and Engineering Specifications
The wireless microphone system shall feature a true-diversity receiver with 42 MHz of available tuning bandwidth with a total
of 1,680 frequencies accessible in 25 kHz steps. The wireless microphone receiver must feature one balanced XLR output with a
max. output of +18 dBu, and one unbalanced ¼” output with a max. output of +12 dBu. The wireless microphone receiver must
feature two BNC antenna inputs, one for each receiver module in the true diversity system. The wireless microphone receiver
must feature a backlit display that displays AF and RF levels, battery telemetry from the transmitter, operating frequency, and
diversity switching information. The wireless microphone receiver must feature an automatic frequency scanning function that
utilizes twenty (20) banks of pre-coordinated frequencies that are free of intermodulation interference. The wireless microphone
receiver must also feature a user bank in order to store user defined frequencies. The wireless microphone transmitter must
operate on two 1.5V AA battery cells. The wireless microphone transmitter must have access to 1,680 frequencies tuned in 25
kHz steps across a defined 42 MHz bandwidth. The wireless microphone transmitter must feature a backlit display that displays
frequency information, AF level, battery level. The wireless microphone transmitter must transmit a pilot-tone squelch. The wire-
less microphone transmitter must have a specified RF output power of 30mW. The wireless microphone receiver must accept 12V
DC power via BNC antenna inputs.
Limited Product Warranty/Service
Sennheiser Electronic Corporation extends the following limited product warranty for Sennheiser products:
The warranty period for all covered Sennheiser products is two years from the date of purchase. Not covered by this warranty are
accessories and other consumables; for example, items of wear and tear, such as cables. During the warranty period, Sennheiser
Electronic Corporation warrants that the Sennheiser equipment will be free from defects in materials and workmanship used
in making the product. Abnormal conditions, deliberate abuse and damage due to accidents, operator’s error, or unauthorized
service attempts are excluded from any warranty claims. Under this warranty, Sennheiser Electronic Corporation will repair, or
at its option, replace free of charge the covered defective Sennheiser product, provided it is returned (postage paid, with proof
of purchase from the original seller) to a Sennheiser Service Facility. Products should be returned in their original package, or
otherwise suitably protected to avoid shipping damage. Either product registration or a valid, dated proof of purchase is accepted
to establish the warranty period. The Sennheiser Service Department will be the sole authority to determine the validity of all
warranty issues.
This Limited Product Warranty is Sennheiser Electronic Corporation’s only warranty, and the customer’s only remedy concerning
Sennheiser products. All other representations and warranties, express or implied, written or oral, including, but not limited to,
any warranties of merchantability, fitness for a particular purpose, or non-infringement, are expressly excluded. As a result,
except as set forth in the previous paragraphs, the product is sold “as-is” and the customer is assuming the entire risk as to the
product’s suitability for his needs, its quality and its performance.
In no event will Sennheiser Electronic Corporation be liable for direct, indirect, special, incidental or consequential damages
resulting from any defect in the product or from its use, even if advised of the possibility of such damages.
Sennheiser Electronic Corporation
One Enterprise Drive, Old Lyme, CT 06371
Tel: [phone] • Fax: [phone]
www.sennheiserusa.com
