Sensear SM1P Ex Manual

SM1P Ex
TECHNICAL INFORMATION
Rev: 6/30/22
For most recent technical information, visit
sensear.com/support/technical-information

FORWARD
Product Safety and RF Exposure Compliance:
This product is designed to be used in isolation or in conjunction with a
two-way radio. Before using this product with a two-way radio, read
the operating instructions for safe usage contained in the Product Safety
and RF Exposure booklet enclosed with the two-way radio.
FCC COMPLIANCE STATEMENT
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment intoan outlet on a circuit different
from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician
for help
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation
FCC ID: XKS-SM1xSR IC: 8376A-SM1XSR
FCC ID: QOQWT32I IC:5123A BGTWT32I
English
SM1P Ex Technical Information
1

English
TECHNICAL SPECIFICATIONS
Headband
Behind-the-Neck
Helmet
Mount
Weight
495g (17.46
oz.)
428g (15.09
oz.)
480g (16.93
oz.)
Operating
temperature -20°C to +60°C (-4°F to 140°F)
Charing
temperature
0°C to +40°C (32°F to 104°F)
Non-Intrinsically Safe
Intrinsically Safe
Battery type
2650mAh Lithium Polymer,
rechargeable
2250mAhLithiumion,
rechargeable
Battery charge time
7 hours
4 hours
Operating time
24 hours
18-24 hours
Housing
Material PP, ABS + TPE
RoHS Compliant
Yes
SM1P Ex Technical Information
2

NRR AND SLC80
The SM1P Ex has been certified to international hearing protection
standards including AS/NZS 1270:2002, ANSI S3.19-1974, ANSI
S12.6-2008,EN352-1, EN352-3,EN352-4, andEN352-6. The following
passive attenuation ratings were observed:
PASSIVE ATTENUATION (ANSI S3.19 -1974)
SM1P Ex measured in accordance with ANSI S3.19 -1974.
Headband mount - SM1PBEXxx
Frequency (Hz) 125 250 500 1000 2000 3150 4000 6300
8000
NRR
Mean
attenuation
(dB)
22.1
24.4
31.1
35.1
35.8
37.0
39.9
40.7
40.7
27 dB
Standard
deviation(dB)
3.1 2.4 2.0 2.5 3.2 3.0 3.3 2.7 2.9
Behind-the-Neck mount- SM1PEXxx
Frequency (Hz) 125 250 500 1000 2000 3150 4000 6300
8000
NRR
Mean
attenuation
(dB)
18.9 22.4 28.6 33.6 33.5 35.3 37.3 38.8 37.4
24 dB
Standard
deviation(dB)
3.5 3.4 2.6 2.8 2.3 3.5 4.0 2.9 3.4
Helmet mount - SM1PHEXxx
Frequency (Hz) 125 250 500 1000 2000 3150 4000 6300 8000 NRR
Mean
attenuation
(dB)
18.6 20.8 27.3 33.6 37.1 35.5 35.3 37.1 35.0
23 dB
Standard
deviation(dB)
3.2 2.7 3.1 3.9 2.3 3.1 3.8 3.8 3.4
English
SM1P Ex Technical Information
3

PASSIVE ATTENUATION (ANSI S12.6 – 2008)
SM1P Ex measured in accordance with ANSI S12.6 - 2008.
Headband mount - SM1PBEXxx
Frequency (Hz)
125
250
500
1000
2000
4000
8000
NRR(SF)
Mean attenuation
(dB)
21.4 21.9 29.8 33.7 35.8 37.2 38.5
27 dB
Standard
deviation(dB)
3.0 2.1 1.7 2.8 1.5 1.9 2.8
APV80
18.9
20.1
28.4
31.3
34.5
35.6
36.1
Behind-the-Neck mount- SM1PEXxx
Frequency (Hz) 125 250 500 1000 2000 4000 8000 NRR(SF)
Mean attenuation
(dB)
18.7
19.9
28.0
34.1
31.5
35.6
35.3
24.3 dB
Standard
deviation(dB)
3.0 2.5 2.2 1.7 3.2 3.4 4.1
APV80 16.2 17.8 26.2 32.7 28.8 32.7 31.9
Helmet mount - SM1PHEXxx
Frequency (Hz) 125 250 500 1000 2000 4000 8000 NRR(SF)
Mean attenuation
(dB)
15.0 17.7 25.2 30.4 33.9 34.5 33.8
19.1 dB
Standard
deviation(dB)
6.5
6.7
6.6
4.0
3.3
5.9
5.1
APV80 9.5 12.1 19.7 27.0 31.1 29.5 29.5
English
SM1P Ex Technical Information
4

PASSIVE ATTENUATION (AS/NZS 1270:2002)
SM1P Ex measured in accordance with AS/NZS 1270:2002.
Headband mount - SM1PBEXxx
Frequency (Hz)
125 250
500
1000 2000 4000 8000
SLC
(80)
Mean
attenuation(dB)
20.3
21.7
30.3
33.2
35.2
36.6
37.3
31dB,
Class 5
Standard
deviation(dB)
4.3
3.1
2.7
3.0
2.7
2.5
3.3
Mean atten. –
Standard dev.
(dB)
16.0
18.6
27.6
30.2
32.5
34.1
34.0
Behind-the-Neck mount- SM1PEXxx
Frequency (Hz)
125 250 500
1000
2000
4000 8000
SLC
(80)
Mean
attenuation(dB)
19.3
20.0
27.0
33.7
30.5
33.9
33.0
27 dB,
Class 5
Standard
deviation(dB)
5.1
4.1
3.7
2.4
4.5
3.8
5.2
Mean atten. –
Standard dev.
(dB)
14.2
15.9
23.3
31.3
26.0
30.1
27.8
Helmet mount - SM1PHEXxx
Frequency(Hz)
125 250 500 1000 2000 4000 8000
SLC
(80)
Mean
attenuation(dB)
15.6
19.1
24.7
29.7
34.0
34.5
33.4
26 dB,
Class 5
Standard
deviation(dB)
5.7
5.5
5.2
3.9
3.0
5.5
5.0
Mean atten. –
Standard
dev. (dB)
9.9
13.6
19.5
25.8
31.0
29.0
28.4
English
SM1P Ex Technical Information
5

PASSIVE ATTENUATION (EN352-1AND EN352-3)
SM1P Ex measured in accordance with EN352-1 and EN352-3.
Headband mount- SM1PBEXxx (EN352-1)
Frequency (Hz) 125 250 500 1000 2000 4000 8000 H M L SNR
(dB)
Mean attenuation (dB)
22.5
24.5 31.5 34.9 35.8 38.0 39.8
35
30
24 33
Standard deviation (dB)
4.8
2.6
2.3
3.1
2.5
2.1
2.7
Mean attenuation –
Standard deviation(dB)
17.7
21.9 29.2 31.8 33.3 35.9 37.1
Behind-the-Neck mount - SM1PEXxx (EN352-1)
Frequency (Hz) 125 250 500 1000 2000 4000 8000 H M L SNR
(dB)
Mean attenuation (dB)
20.7
21.3
27.7
34.0
33.3
35.3
36.1
32
27
21 30
Standard deviation (dB) 5.1 3.3 3.1 2.5 2.9 2.3 2.6
Mean attenuation –
Standard deviation(dB)
15.6
18.0
24.6
31.5
30.4
33.0
33.5
Helmet mount- SM1PHEXxx (EN352-3)
Frequency (Hz)
125
250
500
1000
2000
4000
8000
H
M
L
SNR
(dB)
Mean attenuation (dB)
20.4
22.2 28.2 33.5 36.9 38.0 37.5
34
28
22 31
Standard deviation (dB) 3.6 3.3 3.3 3.6 2.3 3.9 3.0
Mean attenuation –
Standard deviation(dB)
16.9
18.8 24.9 29.8 34.6 34.1 34.6
English
SM1P Ex Technical Information
6

TheSM1P Ex has level dependent facilities and the criterion levels
as defined in EN352-4 are displayed below:
Model
H M L
dB(A)
SM1P Ex 108.6 104.6 103.4
TWO-WAY RADIO INPUT (EN352-6)
NRR
SLC [80]
SNR
NRR[SF]
ANSI S3.19-1974
AS/NZS 1270:2002
EN352-1 andEN352-3
ANSIS12.6 –2008
US
Australia
EU
US & Canada
Foam
Foam
Foam
Foam
Headband
30dB
32dB, Class 5
37dB
33dB
Behind-
the-Neck
31dB
33dB, Class 5
38dB
33dB
Helmet
29dB
30dB, Class 5
38dB
31dB
TWO-WAY RADIO INPUT (EN352-6)
The electrical input level for which the mean plus one standard
deviation is A-weighted diffused-field related sound pressure level is
equal to 82 dB(A) is an RMS voltage U = 108mV.
SIZE RANGES
WARNING Earmuffs complying with EN352-1 are of ‘small size
range’, ‘Medium size range’ or‘large size range’. ‘Medium size range’
earmuffs will fit most wearers. ‘Small size range’ or ‘large size range’
earmuffs are designed to fit wearers for whom ‘medium size range’
earmuffs are not suitable. The SM1P Ex headband, SM1P Ex
behind-the-neck, and SM1P Ex helmet adapters may be adjusted for
small, medium, or large size.
English
SM1P Ex Technical Information
7

MAINTENANCE AND CLEANING
The headset is an active hearing protector that allows audible contact with
your surroundings while providing protection from harmful noise.
It is recommended that the headset is fitted, adjusted, and maintained in
accordance with these instructions. This headset should always be worn in noisy
surroundings. The headset should be regularly inspected for serviceability.
Warning:
• If these instructions are not followed the protection of the
headset will be severely impaired.
• Noise reduction will be adversely affected by anything that
impairs the seal of the earmuff cushions against the head,
such as thick spectacle frames and balaclavas
• The reported attenuation will be obtained only if the headset
is in good condition and worn as directed (Refer to AS/NZS
1269.3 for guidance).
• This product should not be used where there is a risk that the
connecting cord could be caught up during use.
• This product is provided with level-dependent in-ear audio
playback. The wearer should check correct operation before
use. If distortion, or failure is detected. The wearer should
refer to the manufacturer’s advice for maintenance and/or
replacement.
Warning:
• Performance may deteriorate with battery usage. The typical
period of continuous use that can be expected from the
headset will depend on the two-way radio battery.
• The output of the level-dependent circuit of this hearing
protector may exceed the daily limit sound level. This limit
can be adjusted with a Sensear programming tablet.
• This headsethas been tested and approved according to the
methods described in the EN352series of standards.
English
SM1P Ex Technical Information
8

CLAMPING FORCE
The clamping force of the SM1P Exhas been measured in accordance
with AS/NZS 1270
Model Part # Units
Initial
measurements
Post-flex
measurements
A B C A B C
SM1PEx-
Headband
mount
SM1PBXXX
& SM1BBXXX
Newtons
(N) 11.6
11.1
11.1 11.1
10.7
11.1
Pounds
(lbs) 2.6 2.5
2.5 2.5 2.4 2.5
SM1P Ex -
Behind-the-
Neck mount
SM1PEXXX
& SM1BEXXX
N 14.2
14.7
14.2 14.2
14.7
14.2
lbs
3.2 3.3 3.2 3.2 3.3 3.2
SM1PEx-Helmet
mount
SM1PHXXX
&
SM1BHXXX
N 9.3 9.3
9.3 9.3 8.9 9.3
English
SM1P Ex Technical Information
9

INTRINSICALLY SAFE CERTIFICATION – Ex MODEL
The SM1P Ex meets the following international standards for use in
explosive gas environments:
II 1G Ex ia IIC T3Ga (-20oC ≤Ta ≤+40oC)
I M1Ex ia I Ma (-20oC ≤ Ta ≤+60oC)
Class I, Division 1 Groups A-D, T3C (-20oC ≤ Ta ≤ +40oC)
Class I, Zone 0, AEx ia IIC T3 Ga (-20oC ≤ Ta ≤ +40oC)
Ex ia IIC T3 Ga (-20oC ≤ Ta ≤ +40oC)
Or
II 2G Ex ibIIC T4Gb(-20oC ≤ Ta ≤ +40oC)
II 2D Ex ibIIIC T155oC Db (-20oC ≤Ta ≤+40oC)
I M2Ex ibI Mb(-20oC ≤Ta ≤+60oC)
Cl I, Div 1GrpA-D, T4 (-20oC ≤Ta ≤+40oC)
Cl I, Zn1, AEx ib IIC T4Gb(-20oC ≤ Ta ≤+40oC)
Cl II, Zn 21, AEx ibIIIC T155oC Db (-20oC ≤Ta ≤+40oC)
MARKINGS
TheSM1P-Ex contains the following markings:
Hazardous location class and group and temperature class
or
Where“XXXX” is the number ofthe ATEX Notified Body responsible for
the ATEX QAN.
ENTITY PARAMETERS
The following entity parameters are for whenSM1P Ex is used with
SRCK61xxCCxx at the radio end of the interface cable.
Entity parameter
Value
Ui
8.4 V
Ci
0.15µF
Li 0µH
Co
≥Ci + C cable
Lo
≥Li + L cable
English
SM1P Ex Technical Information
10

COPYRIGHT NOTICE
This document remains the property of Sensear Pty. Ltd. All rights
reserved. No part of this document may be reproduced in any form,
either in an electronic retrieval system or otherwise, without the prior
written consent of Sensear Pty. Ltd.
IMPORTANT NOTICE
Sensear Pty. Ltd. Reserves the right to make corrections,
modifications, enhancement, improvements and other changes to
its products and services and to discontinue any product or service
without notice.
Whilst Sensear Pty. Ltd. makes every effort to ensure that the
information in this document is correct at the time of publication, users
and potential users should first check with Sensear Pty. Ltd. to ensure
that they have received the most up-to-date documentation.
English
SM1P Ex Technical Information
11

Waste (Disposal) of your Electronic and Electric Equipment
European Union (EU) Waste of Electrical and Electronic Equipment (WEEE) directive
The European Union’s WEEE directive requires that productssold into EU countries must have the crossed-
out trash bin label on the product (or the package in some cases). As defined by the WEEE directive, this
cross-out trash bin label means that customers and end-users in EU countries should not dispose of
electronic and electrical equipment or accessories in household waste. Customers or end-users in EU
countries should contact their local equipment supplier representative or service centre for information about
the waste collection system in their country.
Directive del’UnionEuropéenne (UE) sur l’Élimination des Équipements Électriqueset Électroniques
(DEEE)
La directiveDEEE del’UnionEuropéenne impose que les produits vendus dans les pays de l’UE portent la
marque (éventuellement sur l’emballage) d’une poubelle sur roues barrée d’unecroix. Comme la directive
DEEEl’explicite, cette marque composée d’une poubelle sur roues barréed’unecroix signifie queles clients et
les utilisateurs des pays de l’UE ne devraient pas inclure leurséquipements électriques et électroniques ou
accessoires dans leurs déchets ménagers. Lesclients ouutilisateurs despays del’UE devraient contacter le
représentant local deleurfournisseur d’équipement ou un centre de service pour s’informer surle système de
collection de déchets dansleur pays.
Derichtlijn inzake afgedankte elektrische enelektronische apparatuur (AEEA) van de Europese Unie
(EU)
De richtlijn AEEA van de Europese Unie vereist dat product en die in de landen van de EU worden verkocht
(of in sommige gevallen de verpakking daarvan), moeten zijn voorzien van het etiket met een doorgekruiste
vuilnisbak. Zoals bepaald door de richtlijn AEEA, betekent dit etiket met de doorgekruiste vuilnisbak dat klanten en
eindgebruikers indelanden vande EU elektrische en elektronischeapparatuur of toebehorenniet met het
huisvuil mogen wegwerpen. Klanten en eindgebruikers binnen de EUmoeten contact opnemen met hun plaatselijke
leverancierof onderhoudscentrum voor informatie over het afval inzamelsysteem inhunland.
Richtlinie über Elektro- und Elektronik-Altgeräte (WEEE) der Europäischen Union (EU)
Produkte, die in EU Ländern auf den Markt gebracht werden, müssenmit einer durchgestrichenen Abfalltonne
gekennzeichnet sein (oder in einzelnen Fällen die Verpackung). Die WEEE Direktive definiert, dass Kunden
und Endnutzer in Ländern der Europäischen Union (EU) elektronische und elektrische Geräte sowie
elektronisches oder elektrisches Zubehör nicht in
den Hausmüll entsorgen dürfen.Innerhalbder EUsetzenSiesichbittemit dem örtlichen Vertreter oder
Kundendienst Ihres Gerätelieferanten in Verbindung, der IhnenAuskunft
zur Altgeräteentsorgung/-abholung geben kann.

La direttiva de la Unione Europea (EU) sui rifiuti di apparecchiature elettriche ed elettroniche (RAEE)
Ladirettiva RAEEdellaUnione Europea richiedecheiprodottivendutineipaesi della
UEdebbanoesseremarcaticonil simbolodiuncontenitoredispazzaturamobilebarratosulprodotto(oincasi
eccezionalisull’imballaggio).Ilsimbolo di uncontenitoredi spazzatura mobile barrato, conforme alla direttiva
RAEE, significachiiclientieidetentorifinalinei paesidellaUE,nondovrebberosmaltire
gliapparecchiogliaccessori elettronici edelettrici coninormali rifiutidomestici. I clienti oidetentorifinalinei paesi
della UEdovrebberorivolgersi alfornitore,rappresentanteocentrodi riparazione localeperottenere
informazionisuisistemipredispostinel propriopaeseper laraccolta ditaliapparecchiusati.
Directiva daUniãoEuropeia (UE) relativa aos Resíduos de Equipamentos Eléctricos eElectrónicos (REEE)
ADirectivaREEEdaUniãoEuropeiaexige queosprodutosvendidosempaísesda
UEtenhamaetiquetacomosímbolo do contentordolixobarrado comuma cruz
nopróprioproduto(ou,emdeterminados casos, naembalagem). Tal como definido pelaDirectiva
REEE,estecontentor dolixo barradocomumacruzsignificaqueos clienteseutilizadores finais nos países da
UEnãodevemeliminarequipamentoseléctricose electrónicos ou acessórios junto com o lixo doméstico.
Osclientes
ouutilizadoresfinaisnospaísesdaUEdevemcontactarorepresentantelocaldofornecedordoequipamento
ouumcentrode assistência paraobter informações relativas aosistemaderecolhadelixo
no país ondevivem.
Директива Европейского Союза (ЕС) об утилизации электрического иэлектронного
оборудования («УЭЭО»).
Директива«УЭЭО»ЕвропейскогоСоюза требует,чтобынаизделиях,продаваемыхвстранахЕС(ав
отдельных случаях на
ихупаковке),былананесенамаркировка ввиде перечёркнутого мусорного
контейнера.Какустановлено в директиве
«УЭЭО», такая маркировкав видеперечёркнутогомусорного контейнера означает, чтопокупатели и
конечные пользователи не должны выбрасывать электронное и электрическое
оборудованиеилиприборы
вбытовоймусор. Покупателям иконечным пользователям встранах ЕСследует обращаться к
местным представителям поставщиков оборудования или
всервисныецентрыдляполучения информации осистеме сбора отходов в их стране.
La directiva de la Unión Europea (EU) sobre Residuos de Aparatos Eléctricos y Electrónicos (RAEE)
Ladirectiva RAEEde la Unión Europea requierequelosproductos vendidos enlospaísesdela UEseanrotulados
medianteel símbolo de un contenedor debasuratachadosobreelproducto (oenalgunoscasossobreelenvase).
Conforme con ladirectiva RAEE,el símbolodel contenedorde basuratachadosignificaquelosclientesy
usuariosfinalesenlospaísesdelaUE nodeberíandedisponer losaparatos eléctricosoelectrónicosniningunodesus
componentes junto a la basuradoméstica.
ClientesousuariosfinalesenlospaísesdelaUEdebenentrarencontactoconelcentrodeserviciooproveedores
del equipo para obtener información acerca del sistema de recolección en su pa
