Sensear SM1R Manual

SM1R
TECHNICAL INFORMATION
Rev: 6/30/22
For most recent technical information, visit
sensear.com/support/technical-information

FORWARD
Product Safety and RF Exposure Compliance:
This product is designed to be used in isolation or in conjunction with a
two-way radio. Before using this product with a two-way radio, read
the operating instructions for safe usage contained in the Product Safety
and RF Exposure booklet enclosed with the two-way radio.
FCC COMPLIANCE STATEMENT
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient orrelocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected
• Consult the dealeroranexperienced radio/TV technician
for help
English
SM1R Technical Information
1

TECHNICAL SPECIFICATIONS
Headband
Behind-the-Neck
Helmet
Mount
Weight
495g (17.46
oz.)
428g (15.09
oz.)
480g (16.93
oz.)
Operating
temperature
-20°C to +60°C (-4°F to 140°F)
Charing
temperature
0°C to +40°C (32°F to 104°F)
Non-Intrinsically Safe
Intrinsically Safe
Battery type
2650mAhLithiumPolymer,
rechargeable
2250mAh Lithium
ion, rechargeable
Battery charge time
7 hours
4 hours
Operating time
24 hours
18-24 hours
Housing
material
PP, ABS + TPE
RoHS Compliant
Yes
English
SM1R Technical Information
2

NRRAND SLC80
The SM1R has been certified to international hearing protection
standards including AS/NZS 1270:2002, ANSI S3.19-1974, ANSI
S12.6-2008, EN352-1, EN352-3, EN352-4, and EN352-6. The
following passive attenuation ratings were observed:
PASSIVEATTENUATION(ANSI S3.19-1974)
SM1R measured in accordance with ANSI S3.19 -1974.
Headband mount- SM1RB001
Frequency (Hz)
125
250
500
1000
2000
3150
4000
6300
8000
NRR
Mean
atten.
(dB)
22.1 24.4 31.1 35.1
35.8 37.0 39.9 40.7 40.7
27 dB
Standard dev.
(dB)
3.1 2.4 2.0 2.5 3.2 3.0 3.3 2.7 2.9
Behind-the-Neckmount–SM1RE001
Frequency (Hz) 125 250 500 1000 2000 3150 4000 6300
8000
NRR
Mean
atten.
(dB)
18.9 22.4 28.6 33.6 33.5 35.3 37.3 38.8 37.4
24 dB
Standard dev.
(dB)
3.5 3.4 2.6 2.8 2.3 3.5 4.0 2.9 3.4
Helmet mount – SM1RH001
Frequency (Hz) 125 250 500 1000 2000 3150 4000 6300 8000 NRR
Mean
atten.
(dB)
18.6 20.8 27.3 33.6 37.1 35.5 35.3 37.1 35.0
23 dB
Standard dev.
(dB)
3.2
2.7
3.1
3.9
2.3
3.1
3.8
3.8
3.4
English
SM1R Technical Information
3

PASSIVE ATTENUATION (ANSI S12.6– 2008)
SM1R measured in accordance with ANSI S12.6 - 2008.
Headband mount- SM1RB001
Frequency (Hz)
125
250
500
1000
2000
4000
8000
NRR(SF)
Mean
attenuation
(dB)
21.4
21.9
29.8
33.7
35.8
37.2
38.5
27 dB
Standard
Dev. (dB)
3.0
2.1
1.7
2.8
1.5
1.9
2.8
APV80
18.9
20.1
28.4
31.3
34.5
35.6
36.1
Behind-the-Neckmount-SM1RE001
Frequency (Hz)
125
250
500
1000
2000
4000
8000
NRR(SF)
Mean
attenuation
(dB)
18.7
19.9
28.0
34.1
31.5
35.6
35.3
24.3 dB
Standard
Dev. (dB)
3.0 2.5 2.2 1.7 3.2 3.4 4.1
APV80 16.2 17.8 26.2 32.7 28.8 32.7 31.9
Helmet mount - SM1RH001
Frequency (Hz)
125
250
500
1000
2000
4000
8000
NRR(SF)
Mean
attenuation
(dB)
15.0
17.7
25.2
30.4
33.9
34.5
33.8
19.1 dB
Standard
Dev. (dB)
6.5 6.7 6.6 4.0 3.3 5.9 5.1
APV80 9.5 12.1 19.7 27.0 31.1 29.5 29.5
English
SM1R Technical Information
4

0
PASSIVEATTENUATION (AS/NZS 1270:2002)
SM1R measured in accordance with AS/NZS 1270:2002.
Headband mount- SM1RB001
Frequency (Hz)
125 250 50 100
0
200
0
400
0
8000
SLC
(80)
Mean atten.
(dB)
20.3
21.7
30.3
33.2
35.2
36.6
37.3
31dB,
Class 5
Standard
dev. (dB)
4.3
3.1
2.7
3.0
2.7
2.5
3.3
Mean atten. –
Standard
dev. (dB)
16.0
18.6
27.6
30.2
32.5
34.1
34.0
Behind-the-Neckmount-SM1RE001
Frequency (Hz)
125
250
500
1000
2000
4000
8000
SLC
(80)
Mean
attenuation(dB)
19.3
20.0
27.0
33.7
30.5
33.9
33.0
27 dB,
Class 5
Standard
deviation(dB)
5.1
4.1
3.7
2.4
4.5
3.8
5.2
Mean atten. –
Standard dev.
(dB)
14.2
15.9
23.3
31.3
26.0
30.1
27.8
Helmet mount - SM1RH001
Frequency(Hz)
125 250 500 1000 2000 4000 8000
SLC
(80)
Mean atten.
(dB)
15.6
19.1
24.7
29.7
34.0
34.5
33.4
26 dB,
Class 5
Standard
deviation(dB)
5.7
5.5
5.2
3.9
3.0
5.5
5.0
Mean atten. –
Standard
dev. (dB)
9.9
13.6
19.5
25.8
31.0
29.0
28.4
English
SM1R Technical Information
5

PASSIVE ATTENUATION (EN352-1 ANDEN352-3)
SM1R measuredin accordance with EN352-1and EN352-3.
Headband mount- SM1RB001 (EN352-1)
Frequency (Hz) 125 250 500 1000 2000 4000 8000
H M L SNR
(dB)
Mean attenuation
(dB)
22.5
24.5
31.5
34.9
35.8
38.0
39.8
35 30 24 33
Standard Dev. (dB)
4.8
2.6
2.3
3.1
2.5
2.1
2.7
Mean attenuation –
Standard Dev. (dB)
17.7
21.9
29.2
31.8
33.3
35.9
37.1
Behind-the-Neck mount- SM1RE001(EN352-1)
Frequency (Hz) 125 250 500 1000 2000 4000 8000 H M L SNR
(dB)
Mean attenuation
(dB)
20.7
21.3
27.7
34.0
33.3
35.3
36.1
32 27 21 30
Standard Dev. (dB)
5.1
3.3
3.1
2.5
2.9
2.3
2.6
Mean attenuation –
Standard Dev. (dB) 15.6
18.0 24.6 31.5 30.4 33.0 33.5
Helmet mount-SM1RH001 (EN352-3)
Frequency (Hz)
125
250
500
1000
2000
4000
8000
H
M
L
SNR
(dB)
Mean attenuation
(dB)
20.4 22.2 28.2 33.5 36.9 38.0 37.5
34 28 22 31
Standard Dev. (dB)
3.6
3.3
3.3
3.6
2.3
3.9
3.0
Mean attenuation –
Standard Dev. (dB) 16.9
18.8 24.9 29.8 34.6 34.1 34.6
English
SM1R Technical Information
6

The SM1R has level dependent facilities and the criterion levels as
defined in EN352-4 are displayed below:
Model
H M L
dB(A)
SM1R 108.6 104.6 103.4
TWO-WAY RADIO INPUT (EN352-6)
The electrical input level for which the mean plus one standard
deviation is A-weighted diffused-field related sound pressure
level is equal to 82 dB(A) is an RMS voltage U = 108mV.
SIZE RANGES
Warning- Earmuffs complying with EN352-1 are of ‘small size range’,
‘Medium size range’ or ‘large size range’. ‘Medium size range’
earmuffs will fit most wearers. ‘Small size range’ or ‘large size range’
earmuffs are designed to fit wearers for whom ‘medium size range’
earmuffs are not suitable. The SM1R Headband, SM1R Behind-the-
Neck, and SM1R Helmet adapters may be adjusted for small,
medium, or large size.
English
SM1R Technical Information
7

MAINTENANCE AND CLEANING
The headset is an active hearing protector that allows audible contact with
your surroundings while providing protection from harmful noise.
It is recommended that the headset is fitted, adjusted, and maintained
in accordance with these instructions. This headset should alwaysbeworn
in noisy surroundings. The headset should be regularly inspected for
serviceability.
Warning:
• If these instructions are not followed the protection of the
headset will be severely impaired.
• Noise reduction will be adversely affected by anything that
impairs the seal of the earmuff cushions against the head,
such as thick spectacle frames and balaclavas
• The reported attenuation will be obtained only if the headset
is in good condition and worn as directed (Refer to AS/NZS
1269.3 for guidance).
• This product should not be used where there is a risk that the
connecting cord could be caught up during use.
• This product is provided with level-dependent in-ear audio
playback. The wearer should check correct operation before
use. If distortion, or failure is detected. The wearer should
refer to the manufacturer’s advice for maintenance and/or
replacement.
Warning:
• Performance may deteriorate with battery usage.
The typical period of continuous use that can be
expected from the headset will depend on the two-
way radio battery.
• The output of the level-dependent circuit of this hearing
protector may exceed the daily limit sound level. This limit
can be adjusted with a Sensear programming tablet.
• This headset has been tested and approved according to
the methods described in the EN352 series of standards.
English
SM1R Technical Information
8

CLAMPING FORCE
The clamping force ofthe SM1R has been measured in accordance with
AS/NZS 1270:
Model Part # Units
Initial
measurements
Post-flex
measurements
A B C A B C
SM1R –
Headband
mount
SM1RB001 Newtons
(N) 11.6 11.1
11.1 11.1 10.7 11.1
Pounds
(lbs) 2.6 2.5 2.5 2.5 2.4 2.5
SM1R –
Behind-
the-Neck
mount
SM1RE001
N
14.2 14.7 14.2 14.2 14.7 14.2
lbs 3.2 3.3 3.2 3.2 3.3 3.2
SM1R –
Helmet mount
SM1RH001
N 9.3 9.3 9.3 9.3 8.9 9.3
MAINTENANCE AND STORAGE OF YOUR HEADSET
This product maybe adversely affected by certain chemical substances.
Further information should be sought from the manufacturer.
The headset contains replaceable cushions (Part # SMHK0000). Cushions are
recommended to be replaced every 3-6 months to maintain the
appropriate hearing protection that the product is certified to. Cushions
should be inspected regularly for signs ofdamageor wear. Cushions canbe
removed simply be gripping the cushion and pulling firmly to unclip
from the baseplate. Replacement cushions maybe pushed into the clips
around thebaseplate.
The headset should be stored at room temperature(between15°C/59°F and
25°C/77°F).
English
SM1R Technical Information
9

INTRINSICALLY SAFE CERTIFICATION– IS MODEL
TheSM1R-IS meets the following international standards for use in
explosive gas environments:
• TIA-4950-ARev. May 13,2014
Requirements For Battery-Powered, Portable Land Mobile Radio
Applications in Class I, II, III, Division 1, Hazardous (Classified)
Locations
• CSA C22.2 No. 157-92 (R2012) + UPD1 + UPD2
Intrinsically Safe and Non-Incendive Equipment for usein
Hazardous Locations
• UL913 5th Ed. February 21, 1997
Standard for Intrinsically Safe Apparatus and Associated
Apparatus for Use in Class I, II,III, Division 1,Hazardous (Classified)
Locations
MARKINGS
The SM1R-IS contains the following markings:
Manufacturer’s name, Hazardous location class and group and temperature class
English
SM1R Technical Information
10

COPYRIGHT NOTICE
This document remains the property of Sensear Pty. Ltd. All rights
reserved. No part of this document may be reproduced in any form, either
in an electronic retrieval system or otherwise, without the prior written
consent of Sensear Pty. Ltd.
IMPORTANT NOTICE
Sensear Pty. Ltd. Reserves the right to make corrections, modifications,
enhancement, improvements and other changes to its products and
services and to discontinue any product or service without notice.
While Sensear Pty. Ltd. makes every effort to ensure that the
informationin this documentis correctat the time of publication, users and
potential users should first checkwith SensearPty. Ltd. to ensure that they
have received the most up-to-date documentation.
English
SM1R Technical Information
11

Waste (Disposal) of your Electronic and Electric Equipment
European Union (EU) Waste of Electrical and Electronic Equipment (WEEE) directive
The European Union’s WEEE directive requires that products sold into EU countries must have the
crossed- out trash bin label on the product (or the package in some cases). As defined by the WEEE
directive, this cross-out trash bin label means that customers and end-users in EU countries should
not dispose of electronic and electrical equipment or accessories in household waste. Customers or
end-users in EU countries should contact their local equipment supplier representative orservicecenterfor
information about the waste collection system in their country.
Directivedel’UnionEuropéenne (UE) surl’Éliminationdes Équipements Électriqueset Électroniques
(DEEE)
La directiveDEEE del’UnionEuropéenne impose que les produits vendus dans les pays de l’UE portent la
marque(éventuellement sur l’emballage) d’une poubellesur roues barrée d’unecroix. Comme la directive
DEEEl’explicite, cettemarque composée d’une poubelle sur roues barréed’unecroix signifie queles clients et
les utilisateurs des pays de l’UE ne devraient pas inclure leurséquipements électriques et électroniques ou
accessoires dans leurs déchets ménagers. Lesclients ouutilisateurs despays del’UE devraient contacter le
représentant local deleurfournisseur d’équipement ou uncentre de service pour s’informersurle système de
collection de déchets dansleur pays.
Derichtlijninzakeafgedankteelektrische enelektronischeapparatuur (AEEA) vande Europese Unie
(EU)
De richtlijn AEEA van de Europese Unie vereist dat product en die in de landen van de EU worden verkocht
(of in sommige gevallen de verpakking daarvan), moeten zijn voorzien van het etiket met een doorgekruiste
vuilnisbak. Zoals bepaald door de richtlijn AEEA, betekent dit etiket met de doorgekruiste vuilnisbak dat klanten en
eindgebruikers indelanden vande EU elektrische en elektronischeapparatuur of toebehorenniet met het
huisvuil mogen wegwerpen. Klanten en eindgebruikers binnen de EUmoeten contact opnemen met hun plaatselijke
leverancierof onderhoudscentrum voor informatie over het afval inzamelsysteem inhunland.
Richtlinie über Elektro- und Elektronik-Altgeräte (WEEE) der Europäischen Union (EU)
Produkte, die inEULändern auf denMarkt gebracht werden,müssenmit einer durchgestrichenenAbfalltonne
gekennzeichnet sein (oder in einzelnen Fällen die Verpackung). Die WEEE Direktive definiert, dass Kunden
und Endnutzer in Ländern der Europäischen Union (EU) elektronische und elektrische Geräte sowie
elektronisches oder elektrisches Zubehör nicht in
denHausmüllentsorgendürfen.Innerhalbder EUsetzenSiesichbittemit demörtlichenVertreteroder
Kundendienst Ihres Gerätelieferanten in Verbindung, der IhnenAuskunft
zurAltgeräteentsorgung/-abholunggebenkann.

La direttiva de la Unione Europea (EU) sui rifiuti di apparecchiature elettriche ed elettroniche (RAEE)
Ladirettiva RAEEdellaUnione Europea richiedecheiprodottivendutineipaesi della
UEdebbanoesseremarcaticonil simbolodiuncontenitoredispazzaturamobilebarratosulprodotto(oincasi
eccezionalisull’imballaggio).Ilsimbolo di uncontenitoredi spazzaturamobile barrato, conforme alla direttiva
RAEE, significachiiclientieidetentorifinalinei paesidellaUE,nondovrebberosmaltire
gliapparecchiogliaccessorielettroniciedelettriciconinormali rifiutidomestici. I clientioidetentorifinalinei paesi
della UEdovrebberorivolgersi alfornitore,rappresentanteocentrodi riparazione localeperottenere
informazionisuisistemipredispostinel propriopaeseper laraccolta ditaliapparecchiusati.
Directiva daUniãoEuropeia (UE) relativa aos Resíduos de Equipamentos Eléctricos eElectrónicos (REEE)
ADirectivaREEEdaUniãoEuropeiaexige queosprodutosvendidosempaísesda
UEtenhamaetiquetacomosímbolo do contentordolixobarrado comuma cruz
nopróprioproduto(ou,emdeterminados casos, naembalagem). Tal como definido pelaDirectiva
REEE,estecontentor dolixo barradocomumacruzsignificaqueos clienteseutilizadores finais nos países da
UEnãodevemeliminarequipamentoseléctricose electrónicosou acessórios junto com o lixo doméstico.
Osclientes
ouutilizadoresfinaisnospaísesdaUEdevemcontactarorepresentantelocaldofornecedordoequipamento
ouumcentrode assistência paraobter informações relativas aosistemaderecolhadelixo
nopaís ondevivem.
Директива ЕвропейскогоСоюза(ЕС) обутилизации электрического иэлектронного
оборудования («УЭЭО»).
Директива«УЭЭО»ЕвропейскогоСоюзатребует,чтобынаизделиях,продаваемыхвстранахЕС(ав
отдельных случаях на
ихупаковке),былананесенамаркировкаввидеперечёркнутогомусорного
контейнера.Какустановлено в директиве
«УЭЭО», такая маркировкав видеперечёркнутогомусорного контейнера означает, чтопокупатели и
конечные пользователи не должны выбрасывать электронное и электрическое
оборудованиеилиприборы
вбытовоймусор. Покупателям иконечнымпользователям встранахЕСследуетобращаться к
местным представителям поставщиков оборудования или
всервисныецентрыдляполучения информации осистеме сбора отходов в их стране.
La directiva de la Unión Europea (EU) sobre Residuos de Aparatos Eléctricos y Electrónicos (RAEE)
Ladirectiva RAEEde la Unión Europea requierequelosproductos vendidos enlospaísesdela UEseanrotulados
medianteel símbolo de un contenedor debasuratachadosobreelproducto (oenalgunoscasossobreelenvase).
Conforme con ladirectiva RAEE,el símbolo del contenedorde
basuratachadosignificaquelosclientesy usuariosfinalesenlospaísesdelaUE nodeberíandedisponer
losaparatos eléctricosoelectrónicosniningunodesus componentes junto a la basuradoméstica.
ClientesousuariosfinalesenlospaísesdelaUEdebenentrarencontactoconelcentrodeserviciooproveedores
del equipo para obtener información acerca del sistema de recolección en su pa
