SENSIRION SFC5 Series User manual

SFC5xxx
Quick start guide
for mass flow controller kit
1.000.767 / 2104-EK-F5x-EN
Thank you for your interest
in our mass flow controller solutions.
Sensirion AG
Laubisrütistrasse 50 · 8712 Stäfa · Switzerland · phone [phone] · [email protected]
www.sensirion.com

Please find all information about our mass flow controllers,
including necessary soware, on our website: www.sensirion.com/sfc5500
Set-up
• Install up-to-date “SFC5xxx viewer” soware and USB drivers from our website.
• Connect your mass flow controller to a source of pressurized gas (mind the
arrow indicating flow direction). For your first measurement, the outlet can stay
unconnected.
• Connect the DB9 cable to the mass flow controller (sold separately from evaluation kit).
• Connect the USB part of the cable to your PC.
• Choose the right plug, insert it into power adapter and connect it to 100-240 VAC.
Controlling gas flow
• Go to “Data Display” tab.
• 1Select the desired flow units (e.g. normalized or physical calibration units).
• 2Click “Run”. You can optionally log the data.
• 3Specify the desired flow set point and click „Set“.
Getting started with Sensirion SFC5xxx viewer soware
• Start the SFC5xxx viewer soware.
• Select the COM port the mass flow controller is connected to and click “Open”.
• Choose the calibration for the gas you have connected, right-click on it and
select “Load Calibration”.
01 03
02
2
1
3
Gas FlowGas Flow
