Sentiotec Infrabox basic S Guide

Version 11/20 ID no. 1-052-866
EN
DE
INSTRUCTIONS FOR INSTALLATION AND UNS
English
FR
Infrared control unit
Infrabox basic S
Infrabox basic S set 1-035-705 / IRB-BS-S
Infrabox basic S white set 1-039-847 / IRB-BS-W-S

Table of Contents
1. About this instruction manual 4
2. Important information for your safety 5
2.1. Intended use 5
2.2. Safety information for the installer 7
2.3. Safety information for the user 8
3. Product description 9
3.1. Scope of delivery 9
3.2. Optional accessories 9
3.3. Product features 9
4. Installation 11
4.1. Installing the power supply unit 11
4.2. Installing the control unit 12
4.3. Installing the foil temperature sensor 14
5. Electrical connection 15
5.1. Connection area for sensor/control unit/seat sensor 15
5.2. Connection diagram for 230 V 16
5.3. Connecting the foil sensor (optional) 17
5.4. Connecting the seat sensor (optional) 17
5.5. Connecting the HV input (enable input) 17
5.6. Connecting the safety temperature limiter (optional) 17
5.7. Connecting the infrared heater / infrared plate 17

EN
6. Commissioning 18
6.1. Operating mode 19
6.2. Operating type (infrared heater/infrared plate) 20
6.3. Operating time 21
6.4. Foil sensor 22
6.5. Seat time (optional for seat sensor) 23
6.6. On-time (I/0 timer) 24
6.7. Leading/trailing edge phase control 26
6.8. HV input (enable input) 26
7. Testing 27
8. Operation 28
8.1. Description of control elements 28
8.2. Switching the infrared controller 29
8.3. Dimming function for the infrared heater/infrared plate 29
8.4. Seat sensor (optional) 29
9. Troubleshooting 30
9.1. Error messages 30
10. Cleaning and maintenance 31
10.1. Cleaning 31
10.2. Maintenance 31
11. Disposal 31
12. Technical data 32

Instructions for installation and use p. 4/32
1.About this instruction manual
Read these installation and operating instructions carefully and keep them close
to the infrared control unit. This ensures that you can refer to information on
safety and operation at any time.
Symbols used for warning notices
In these instructions for installation and use, a warning notice located next to
an activity indicates that this activity poses a risk. Always observe the warning
notices. This prevents damage to property and injuries, which in the worst case
may be fatal.
The warning notices contain keywords, which have the following meanings:
DANGER!
Serious or fatal injury will occur if this warning notice is not observed.
WARNING!
Serious or fatal injury can occur if this warning notice is not observed.
CAUTION!
Minor injuries can occur if this warning notice is not observed.
ATTENTION!
This keyword is a warning that damage to property can occur.
Other symbols
This symbol indicates tips and useful information.
Do not cover Read the operating instructions
These installation and operating instructions can also be found in
the downloads section of our website: www.sentiotec.com/downloads.

EN
Instructions for installation and use p. 5/32
2.Important information for your safety
The Infrabox Basic infrared controller has been produced in ac-
cordance with the safety regulations applicable for technical units.
However, hazards may arise during use. Therefore adhere to the
following safety information and the specic warning notices in
the individual chapters. Also observe the safety information for the
devices connected.
2.1. Intended use
The Infrabox Basic infra controller is used exclusively for control-
ling and operating the light/fan and infrared heater/infrared plate.
Observe the instructions for this in the operating instruction manual.
The Infrabox Basic infrared controller may only be used for control-
ling a maximum capacity of 3.5 kW.
Overview of the operating modes:
Switchable: up to 3.5 kW
Half-wave control (dimmable): up to 1.3 kW
Leading edge phase control (dimmable): up to 350 W
The Infrabox infrared controller is suitable for use with intrinsi-
cally safe infrared heaters and infrared plates. If no intrinsically
safe products are being used, a safety temperature limiter
must be connected.

Instructions for installation and use p. 6/32
Suitable infrared heaters: DIR-350-R, WIR-350-R, DIR-500-R,
WIR-500-R, DIR-750-R, WIR-750-R, DIR-1300-R, WIR-1300-R,
ECO-350-R, ECO-350-G, ECO-500-R, ECO-500-G, ECO-750-R,
O-IRC-W
Suitable infrared plates: IR-WP-175, IR-WP-100, IR-WP-390,
IR-WP-510, IR-WPHL-510, IR-WPHL-100, IR-WPHL-390,
IR-WPHL-175
ATTENTION!
Only use infrared plates in connection with the optional WC4-IRF-F foil
sensors.
Before using the controller for the rst time, check that the cabin is
ready to operate.
●Only the mains connection cable provided or the optional one
for Switzerland (IR-CP-CH) may be used.
●The power supply unit may only be installed and operated to-
gether with the control unit provided.
Any use exceeding this scope is considered improper use. Improper
use can result in damage to the product, severe injuries or death.

EN
Instructions for installation and use p. 7/32
2.2. Safety information for the installer
●The clamping connections may only be installed by a qualied
electrician or similarly qualied person.
●The plugs connectors may be installed by the user.
●Installation and connection of the infrared control unit may only
be performed when the power supply is disconnected.
●Also comply with the regulations applicable at the installation
location.
●Before the infrared controller is switched on, make sure that no
ammable objects have been hung over the infrared heater or
on the infrared plate.
●For your own safety, consult your supplier in the event of prob-
lems that are not described in su󰀩cient detail in the installation
and operating instructions.

Instructions for installation and use p. 8/32
2.3. Safety information for the user
●The infrared controller must not be used by children under
8 years old.
●The infrared controller may be used by children age 8 years or
older, by persons with limited psychological, sensory or mental
capabilities or by persons with lack of experience/knowledge
only when:
– They are supervised.
– They have been shown how to use the device safely and
are aware of the hazards that could occur.
●Children must not play with the device.
●Children under 14 years of age may only clean the device if they
are supervised.
●For health reasons, do not use the infrared cabin if you are under
the inuence of alcohol, medication or drugs.
●Before the infrared controller is switched on, make sure that no
ammable objects have been hung over the infrared heater or
on the infrared plate.
●For your own safety, consult your supplier in the event of problems
that are not described in su󰀩cient detail in the user instructions.

EN
Instructions for installation and use p. 9/32
3.Product description
3.1. Scope of delivery
●Infrabox basic control unit
●Infrabox basic power unit
●Mains connection cable 2.5 m (IR-CP-EU)
●Installation material
●Installation instruction manual
●HV plug
3.2. Optional accessories
●Foil sensor (WC4-IRF-F) incl. 5 m connection cable
●Seat sensor (IRB-F-S) incl. 1 m connection cable
●Infrared heater plug (item no.: WC4-P-RA)
●Infrared mains connection cable 2.5 m, Switzerland (item no.: IR-CP-CH)
3.3. Product features
The Infrabox infrared controller features the following functions:
●Switching the infrared heater or infrared plate with a heating capacity of
max. 3.5 kW
●Controlling (dim) the infrared controller in 5 levels with the half-wave control
unit (up to 1.3 kW)
●Controlling (dim) the infrared controller in 5 levels with the leading edge phase
control (up to 350 W)
●Seating sensor function (optional accessories)
●Timer function
●Remote start function

Instructions for installation and use p. 10/32
●If infrared heaters are connected, they must have a safety temperature limiter.
For suitable infrared heaters see 2.1. Intended use on page 5.
●If infrared plates are connected, the WC4-IRF-F foil sensors must be used
and activated (see 4.3. Installing the foil temperature sensor on page 14
and 5.3. Connecting the foil sensor (optional) on page 17). For suitable
infrared plates see 2.1. Intended use on page 5.
●Automatic heating time limit
The infrared controller shuts down automatically after the maximum heat-
ing period for safety reasons (see also 6.3. Operating time on page 21).
The EN 60335-2-53 species a maximum heating period limit of 6 hours
for private infrared cabins. For infrared cabins in hotels, apartment blocks
and similar locations, a maximum heating period limit of 12 hours is
permissible. Extending the heating period limit to 18 hours or 24 hours
is only permitted in public infrared cabins.
!
The Infrabox Basic infrared controller is suitable for use with intrinsically
safe infrared heaters and infrared plates. If no intrinsically safe products
are being used, a safety temperature limiter must be connected.

EN
Installation instructions, only for experts p. 11/32
4.Installation
4.1. Installing the power supply unit
ATTENTION!
Damage to the unit
●Install the power supply unit in a dry place. Maintain a maximum ambient
temperature of 40 °C and a maximum humidity of 95%.
●A free circulation of air must be ensured to cool the power supply unit.
The power supply unit must not be covered by any objects or materials.
The power supply unit is installed on the cabin roof (Fig. 1), on the cabin wall or
in another suitable location in accordance with the ambient conditions. The power
is supplied with a mains connection cable and safety plug.
1. Screw the Infrabox power supply unit housing to the cabin ceiling or the cabin
wall with the four wooden screws provided (16 mm long).
Fig. 1 Installing the power supply unit

Installation instructions, only for experts p. 12/32
4.2. Installing the control unit
The control unit 2of the infrared controller is installed on the outside wall
of the cabin with a maximum clearance of 10 metres from the power supply
unit 1(see Fig. 2). For the installation, a standard jigsaw is required to cut out
the recess for the control unit. The operating unit can be installed both inside
and outside the cabin.
*For installation inside a sauna cabin, maintain a distance of at least 30 cm to
the ceiling. (see Fig. 2 Control panel position on page 12).
ATTENTION!
Damage to the unit
●The control unit 2of the infrared controller is splashproof
(protection class IP X4).
●Work on the control panel may only be carried out using a standard screw-
driver. Using a cordless screwdriver may irreparably damage the housing.
Power unit
Infrabox Basic
External view
Control
unit
1
2
Fig. 2 Control panel position
min. 30 cm *
*for assembly inside the cabin

EN
Installation instructions, only for experts p. 13/32
1. Cut out the 60 x 48 mm recess using a jigsaw, for example.
2. Provide cable guides for the connecting cable.
3. Screw the housing to the cabin wall by screwing the 4 wood screws supplied
through the hole.
4. The front panel of the control unit is inserted with slight pressure into
the housing. Ensure that the lower catches engage noticeably.
5. Connect the 4-pin plug to the RJ11 socket on the control unit.
Fig. 4 Installing the control unit
Fig. 3 Installing the control unit
60 mm
48 mm

Installation instructions, only for experts p. 14/32
If the foil temperature sensor is not tted directly on the infrared plate,
it will produce incorrect measured values. Install the foil temperature
sensor directly on the foil.
The foil temperature sensor is only required for infrared plate heating sys-
tems. Observe the details of the plate heating system manufacturer here.
4.3. Installing the foil temperature sensor
The foil temperature sensor is installed directly on the infrared heating plate and
xed with a cable strain relief (see Fig. 5: Installing the foil temperature sensor
on page 14).
Install the sensor head 1of the foil temperature sensor directly between the in-
sulation and heating foil 4.
1. Secure the foil temperature sensor with the strain relief 2outside the foil
area.
2. Lay the 2-pin cable 3in the cabin wall and secure with cable ties.
3. A foil temperature sensor must be activated to use it (6.4. Foil sensor on
page 22).
Fig. 5: Installing the foil temperature sensor

EN
Installation instructions, only for experts p. 15/32
5.Electrical connection
Observe the following points when connecting the power to the infrared controller:
●Work on the infrared controller may only be performed when the power has
been disconnected.
All components on the Infrabox Basic power supply unit are connected as shown
in the gures below:
5.1. Connection area for sensor/control unit/seat sensor
Fig. 6: Connection area for sensor/control unit/seat sensor
1 2 3
STB
Auto
FF
rd wt bk
1Seat sensor (optional)
2Foiltemperature sensor (FF)
Safety temperature limiter (STB)
3Infrabox control unit
rd = red = rot
wt = white = weiß
bk = black = schwarz

Installation instructions, only for experts p. 16/32
230V/50Hz
max.16A 230V/50Hz
max.3,5kW 230 VAC
5.2. Connection diagram for 230 V
4 5 6
4Mains connection cable 230 V / 50 Hz max. 16 A
5Infrared heater max. 3.5 kW
6Remote start (230 V / 50 Hz)
Fig. 7: Connection area for 230 V

EN
Installation instructions, only for experts p. 17/32
5.3. Connecting the foil sensor (optional)
Clamp the foil sensor line on the 2-pin foil sensor plug to FF accord-
ing to Fig. 6: Connection area for sensor/control unit/seat sensor on
page 15.
5.4. Connecting the seat sensor (optional)
Clamp the seat sensor line to the 3-pin seat sensor plug accord-
ing to Fig. 6: Connection area for sensor/control unit/seat sensor
on page 15. Observe the instructions for this in the operating
instruction manual.
5.5. Connecting the HV input (enable input)
The input becomes active by applying alternating current (230 V /
50 Hz). The input is connected using 2-pole HV plug according to
Fig. 7: Connection area for 230 V on page 16.
Refer to chapter 6.8. HV input (enable input) on page 26 to fol-
low the exact step-by-step procedure.
5.6. Connecting the safety temperature limiter
(optional)
When using infrared heaters and infrared plates without intrinsic safe-
ty, a safety temperature limiter is required and must be connected!
The STB line is connected as shown in Fig. 6: Connection area for
sensor/control unit/seat sensor on page 15 to the STB connection.
5.7. Connecting the infrared heater / infrared plate
Connect the infrared heater/infrared plate to the connection provided
according to Fig. 7: Connection area for 230 V on page 16.
Observe the instructions for this in the operating instruction manual.
WARNING!
Personal injury
●The clamping connections may only be installed by a qualied electri-
cian or similarly qualied person.

Installation instructions, only for experts p. 18/32
ON
OFF
DIP-Bank 4 DIP-Bank 3 DIP-Bank 2 DIP-Bank 1
6.Commissioning
By default, all function selection switches are set to OFF.
Each DIP-Bank provides setting options for the product features of Infrabox
Basic, which are listed below and described in detail.
The settings made in each function setting are shown in the DIP-Bank as well
as the function selection switch.
Fig. 8: Function selection switch - Standard setting
Note that the controller needs to be disconnected from the mains for
10 seconds after making changes so that the settings are saved.
For standard deliveries, the features are as follows:
Operating mode: Normal
Operating type: Switch
Operating time: 6 hours
Foil sensor: O󰀨
Leading/trailing edge phase control: Not activated

EN
Installation instructions, only for experts p. 19/32
In the operating mode the following
settings are possible:
ON
OFF
Operating mode
Operating time
Infra
Infra
Operating time
Operating time Operating time
Fig. 9: Operating mode
Operating mode
Function selec-
tion switch 1 2
Normal OFF OFF
Timer I/0 ON OFF
Seat (optional) ON ON
6.1. Operating mode
DIP-Bank 1
Function selection switch 1 and 2
Normal: Switchable or dimmable infrared heater/infrared plate.
The dimming function of the infrared heater/infrared plate is activated via the infra-
controller, see 6.2. Operating type (infrared heater/infrared plate) on page 20.
Timer I/0 (On/O󰀨): in the On/O󰀨 operating mode, the controller switches o󰀨 after
the set On-time has elapsed and is not activated again.
Switchable infrared heater / infrared plate.
For additional settings, see 6.6. On-time (I/0 timer) on page 24 and
Fig. 16: Timer I/0 operating mode on page 25.
Seat (Function is only available in combination with the optional seat sensor)
For additional settings, see 6.5. Seat time (optional for seat sensor) on page 23.

Installation instructions, only for experts p. 20/32
Fig. 10: Infrared operating type
6.2. Operating type (infrared heater/
infrared plate)
DIP-Bank 1
Function selection switch 3 and 4
ON
OFF
Operating mode
Operating time
Infra
Infra
Operating time
Operating time Operating time
Operating mode
The following settings are possible
for the infra-controller:
Function selection
switch 3 4
Switch OFF OFF
Leading edge
phase control
ON OFF
Half-wave control OFF ON
ATTENTION!
The specied output limits may not be exceeded!
Switching: Switching the infrared heater or infrared plate with a heating capacity
of max. 3.5 kW. No dimming function.
Leading edge phase control: Controlling (dimming) the infrared heater/infrared
plate is possible in 5 levels up to 350 W.
Half-wave control: Controlling (dimming) the infrared heater/infrared plate is
possible in 5 levels up to 1.3 kW.
To enable optimum functionality, we recommend the leading edge phase control
function for infrared heaters with visible light. The half-wave control function is
suitable for infrared plates and infrared heaters without visible light.
