Air fryer
Dear Customer,
Before using the appliance, read the following instructions
carefully and keep this manual for future reference. The
appliance must only be used by persons familiar with these
instructions.
Connection to the mains supply
The appliance should only be connected to an earthed
socket installed in accordance with the regulations.
Make sure that the supply voltage corresponds with the
voltage marked on the rating label.
This product complies with all binding CE labelling
directives.
Familiarisation
1. Operating display
2. Housing
3. Basket insert with ceramic coating
4. Basket holder with ceramic coating
5. Release button
6. Handle
7. Power cord with plug
8. Display symbols
Important safety instructions
∙In order to avoid hazards, repairs
to this electrical appliance or its
power cord must be carried out by
our customer service. If repairs are
needed, please send the appliance to
our customer service department (see
appendix).
∙Before cleaning the appliance,
ensure it is disconnected from the
power supply and has cooled down
completely.
∙To avoid the risk of electric shock, do
not clean the housing or power cord
with water and do not immerse them.
∙For detailed information on cleaning
the appliance, please refer to the
section Cleaning and care.
∙The appliance is not intended to be
operated by means of an external
timer or separate remote-control
system.
∙Place the appliance on a stable, heat-
resistant work surface impervious to
splashes and stains, with sufcient
space around it.
∙Caution: Once the basket holder
has been removed, do not touch the
interior of the fryer. The surface where
the holder is inserted is marked with
a warning sign ‘Hot surfaces’ ,
drawing your attention to this danger.
∙Caution: When the basket holder
is pulled out, hot steam is emitted.
Steam is also emitted through the rear
ventilation slots. Keep your hands
away from the area above the unit and
do not lean over it.
∙The food itself, the holder and
the insert are hot. Always use the
handle when touching the holder or
basket. Wait for the food to cool down
slightly before touching it.
∙Always place the basket holder onto a
heat-resistant surface.
∙This appliance is intended for
domestic or similar applications, such
as the
- staff kitchens in shops, ofces and
other similar working environments,
- agricultural working environments,
- by customers in hotels, motels etc.
and similar accommodation,
- in bed-and breakfast type
environments.
∙Children under 8 must not be
permitted to operate this appliance.
∙Older children of 8 or more, however,
may operate the appliance if they are
under constant supervision.
GB

10
142 x 208 mm
∙The appliance may only be used
by persons with reduced physical,
sensory or mental capabilities, or
lacking experience and knowledge,
if they have been given supervision
or instruction concerning the use of
the appliance and fully understand
all dangers and safety precautions
involved.
∙Children must not be permitted to play
with the appliance.
∙Children must not be permitted to
carry out any cleaning or maintenance
work on the appliance.
∙The appliance and its power cord must
be kept well away from children under
8 at all times.
∙Caution: Keep any packaging materials well away
from children - such materials are a potential source of
danger, e.g. of suffocation.
∙Do not leave the deep fryer unattended while in use.
∙ Do not operate the fryer without the basket tted in its
holder.
∙Every time the appliance is used, the main body
including the power cord as well as any attachment tted
should be checked thoroughly for any defects. Should
the appliance, for instance, have been dropped onto
a hard surface, or if excessive force has been used to
pull the power cord, it must no longer be used: even
invisible damage may have adverse effects on the
operational safety of the appliance. In this case, please
contact our customer service.
∙Do not place the appliance underneath any wall-
cupboards or hanging objects, nor directly by a wall or in
a corner.
∙ Ensure that no inammable materials are stored in the
vicinity.
∙Caution: Do not cover the ventilation slots.
∙Caution: Do not allow the appliance or its power cord
to touch hot surfaces or to come into contact with any
heat sources. Do not allow the power cord to hang free;
the cord must be kept well away from hot parts of the
appliance.
∙ Let the appliance cool down sufciently before moving it.
∙Always remove the plug from the wall socket
-after use,
-in case of any malfunction, and
-before cleaning the appliance.
∙When removing the plug from the wall socket, never pull
on the power cord; always grip the plug itself.
∙No responsibility will be accepted if damage results from
improper use, or if these instructions are not complied
with.
Intended use
∙This appliance must only be used for cooking food. Any
other use must be considered improper and may lead to
personal injuries or material damage.
∙Unlike conventional deep-fryers, this appliance is not
intended to be used with oil or fat.
Before using for the rst time
∙ Before using the appliance for the rst time, remove any
remaining packaging materials and stickers.
∙Heat the appliance for 15 minutes to 200 °C without any
food. This will lessen the inherent smell of the appliance
(see Using the manual temperature / time selection).
∙Ensure adequate ventilation by opening windows or
balcony doors.
∙Clean the appliance afterwards as described in Cleaning
and care.
Operating display
Display - Automatic programmes
Selector keys - Temperature higher
/ lower
Display - Cooking / Hot-air
Display - Heating up
Display - Temperature
Display - Remaining running time
Selector keys - Time increase /
decrease
Selector key - On / Off & Start / Stop
Selector key - Automatic programmes
& Saving changes to automatic
programmes (Memory function)

11
142 x 208 mm
Preparing the unit
1. Always place the unit on a dry, level, non-slip and
heat-resistant surface impervious to contact with the
rubber feet.
2. Prepare the food to be air-fried.
3. Insert the plug into the socket.
4. Put the food into the basket with the holder tted.
Make sure you do not exceed the ‘MAX’ marking.
5. Install the basket holder in the appliance. If it is tted
correctly, a beep signal is heard and the display
ashes briey. The red indicator lamp on the front
comes on. Without the holder tted, the appliance
cannot be operated.
6. Turn the fryer on by pressing the key for 2
seconds. To switch off, press it again for 2 seconds.
If the appliance is not being used, it will switch off
automatically after a short time.
Using automatic programmes
Symbol Food Tips Temperature Time
French fries (deep-frozen) Turn once
Max. 1.5 kg
Turn repeatedly
200 °C 20 – 30 min
35 – 45 min
Bacon 180 °C 16 min
Chicken parts (fresh)
Chicken parts (deep-frozen)
Chicken (whole, max. 1.5 kg)
Turn once
Turn once
Turn repeatedly
180 °C 20 – 25 min
22 – 25 min, depending on thickness
60 min
Shrimps (fresh)
Shrimps (deep-frozen) 180 °C 12 min 15 – 17 min
Meat 180 °C 10 – 16 min, depending on thickness
Small cakes in ovenproof
cake-tins 200 °C 13 – 17 min
Vegetables, eg
zucchini
carrots Turn once Turn once
160 °C 15 – 17 min
10 – 12 min
Fish 180 °C 18 min
1. Proceed as described under Preparing the unit (1-6)
and tap the key.
Ü The rst automatic programme shows on the
display.
2. Keep tapping the key until the desired automatic
programme is shown. Temperature and time alternate
in the display.
Hint:
To adjust the temperature and time settings individually,
press the or keys to set the time resp.
temperature.
The Memory function allows for permanently saving
changes to the automatic programme. This is done by
keeping the key pressed for approx. 2 seconds. 2
beep signals conrm that the setting has been saved.
3. Tap the key.
ÜThe food is now being cooked. The display
changes between temperature and remaining
running time. Audible beeps indicate that the pre-set
processing time has elapsed.

12
142 x 208 mm
4. Use the handle to remove the basket holder from the
fryer.
5. Press the release on the basket handle and take out
the basket.
6. Transfer the cooked food into a heat-resistant
container.
7. Allow the basket holder and basket sufcient time to
cool down.
8. Remove the plug from the wall socket.
9. Clean the basket holder and basket as described
under Cleaning and care.
Using the manual temperature / time selection
1. Proceed as described under Preparing the unit (1-6).
2. Use the or keys to adjust the minutes.
3. Use the or keys to adjust the temperature.
4. Tap the key. The display alternates between
temperature and remaining running time.
ÜThe food is now being cooked. Audible beeps
indicate that the pre-set processing time has elapsed.
5. Proceed as described in the section Using automatic
programmes, steps 4-9.
Useful hints for air-frying
∙You can prepare your food using the basic automatic
programme settings, or adjust the settings according to
your own requirements.
∙Note that the cooking times listed are only approximate.
Depending on the type of food, the cooking times and
temperatures may have to be adjusted.
∙With larger quantities, the cooking time increases. We
recommend frequent turning of the food.
∙If the food turns out too dark, try lowering the
temperature rst, before shortening the cooking times.
∙For nutritious, healthy deep-frying we recommend to
use a temperature setting of no higher than 170°C
when deep-frying amylaceous food, i.e. food with a
higher-than-average starch content. With the reduced
frying temperature, and with an equally reduced amount
of food in the frying basket, the build-up of substances
detrimental to health is limited to a minimum.
∙There is a wide range of recipe ideas for your hot-air
fryer
or under www.severin.de/Service/recipes
Cleaning and care
∙Before cleaning the appliance, ensure that the air fryer
disconnected from the power supply and has completely
cooled down.
∙Caution: To avoid the risk of electric shock, do not
clean the outside of the fryer or its power cord with any
liquids and do not immerse either of them in water.
∙To prevent scratches to the ceramic coating on the
basket and its holder, do not use abrasives or harsh
cleaning solutions.
∙The basket and holder should be cleaned with hot soapy
water. Wipe thoroughly dry afterwards.
∙Caution: Do not put any parts in a dishwasher.
∙The exterior of the housing and the surface where the
basket holder is inserted may be cleaned with a damp,
lint-free cloth.
Disposal Devices marked with this symbol must be
disposed of separately from your household
waste, as they contain valuable materials which
can be recycled. Proper disposal protects the
environment and human health. Your local authority or
retailer can provide information on the matter.
Guarantee
This product is guaranteed against defects in materials
and workmanship for a period of two years from the date
of purchase. Under this guarantee the manufacturer
undertakes to repair or replace any parts found to be
defective, providing the product is returned to one of our
authorised service centres. This guarantee is only valid
if the appliance has been used in accordance with the
instructions, and provided that it has not been modied,
repaired or interfered with by any unauthorised person, or
damaged through misuse.
This guarantee naturally does not cover wear and tear,
nor breakables such as glass and ceramic items, bulbs
etc. This guarantee does not affect your statutory rights,
nor any legal rights you may have as a consumer under
applicable national legislation governing the purchase
of goods. If the product fails to operate and needs to
be returned, pack it carefully, enclosing your name and
address and the reason for return. If within the guarantee
period, please also provide the guarantee card and proof
of purchase.
