Manual
MOVI-C®
Fault Descriptions MOVISAFE® CS..A
Edition 10/2022 27799182/EN

SEW-EURODRIVE—Driving the world

Table of contents
Manual – Fault Descriptions MOVISAFE® CS..A 3
Table of contents
1 General information.................................................................................................................. 4
1.1 Other applicable documentation .....................................................................................4
2 Fault list – safety technology .................................................................................................. 5
2.1 Fault 13 Encoder 1..........................................................................................................5
2.2 Fault 14 Encoder2........................................................................................................14
2.3 Fault 15 Encoder3........................................................................................................23
2.4 Fault 18 Software error .................................................................................................32
2.5 Fault 20 Device monitoring ...........................................................................................32
2.6 Fault 25 Parameter memory monitoring .......................................................................36
2.7 Fault 27 Encoder system ..............................................................................................37
2.8 Fault 32 Communication ...............................................................................................39
2.9 Fault 60 Safe digital input .............................................................................................39
2.10 Fault 61 Safe digital output ...........................................................................................42
2.11 Fault 62 STO output......................................................................................................47
2.12 Fault 63 Speed-dependent drive safety function ..........................................................49
2.13 Fault 64 Position-dependent drive safety functions ......................................................59
2.14 Fault 65 Other drive safety function ..............................................................................64
2.15 Fault 66 Safety-related fault..........................................................................................65
2.16 Fault 67 Safe communication .......................................................................................78
2.17 Fault 68 Safe communication profile.............................................................................85
2.18 Fault 69 Micro controller or diagnostics error................................................................88
2.19 Fault 70 Safe brake system ..........................................................................................89
27799182/EN – 10/2022

1General information
Other applicable documentation
Manual – Fault Descriptions MOVISAFE® CS..A
4
1 General information
1.1 Other applicable documentation
This document supplements the operating instructions and limits the application notes
according to the following information. Use this documentation only in connection with
the operating instructions.
• Operating instructions:
– "MOVIDRIVE® modular", "MOVIDRIVE® system", "MOVIDRIVE® technology"
– "MOVITRAC® advanced"
• Manuals:
– "MOVIDRIVE® modular/system/technology – safety card MOVISAFE® CS..A
(version 4)"
– "MOVI‑C®decentralized electronics–MOVISAFE® CS..A safety option"
– "Inverters of the MOVI-C® modular automation system with CiA402 device pro-
file"
Always use the latest edition of the documentation and the software.
The SEW‑EURODRIVE website (www.sew‑eurodrive.com) provides a wide selection
of documents for download in various languages. If required, you can also order print-
ed and bound copies of the documentation from SEW‑EURODRIVE.
27799182/EN – 10/2022

2
Fault list – safety technology
Fault 13 Encoder 1
Manual – Fault Descriptions MOVISAFE® CS..A 5
2 Fault list – safety technology
Following a list of safety technology relevant device faults, their causes, and remedial
measures.
2.1 Fault 13 Encoder 1
Subfault: 13.1
Description: Error during position comparison check
Response: FS – warning
Cause Measure
Fault detected when comparing raw position and
track counter of absolute encoder.
– Check the track signal wiring.
– Check for EMC-compliant installation.
– Replace the encoder.
– Replace the encoder card.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive using the motor encoder even if
the external position encoder is faulty.
Subfault: 13.10
Description: Position tolerance range exceeded
Response: FS – warning
Cause Measure
Jump in position impermissibly large. – Check the startup parameters.
– Check the wiring.
– Check interference sources (light beam inter-
rupted, reflector, data cables, etc.).
– Replace the encoder.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive using the motor encoder even if
the external position encoder is faulty.
Subfault: 13.11
Description: Encoder data timeout
Response: FS – warning
Cause Measure
Communication to encoder has failed. Contact SEW‑EURODRIVE Service.
Internal fault detected in resolver evaluation. Check for EMC-compliant installation.
27799182/EN – 10/2022

2Fault list – safety technology
Fault 13 Encoder 1
Manual – Fault Descriptions MOVISAFE® CS..A
6
Subfault: 13.14
Description: Communication error
Response: FS – warning
Cause Measure
Faulty communication with encoder. – Check the voltage supply.
– Check for EMC-compliant installation.
– Check the wiring.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive using the motor encoder even if
the external position encoder is faulty.
Subfault: 13.17
Description: High level in signal cable – fault
Response: FS – warning
Cause Measure
Permanent high level of data signal detected. – Check the wiring.
– Check the encoder.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive using the motor encoder even if
the external position encoder is faulty.
Subfault: 13.19
Description: Low level in signal cable – fault
Response: FS – warning
Cause Measure
Permanent low level of data signal detected. – Check the wiring.
– Check the encoder.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive using the motor encoder even if
the external position encoder is faulty.
27799182/EN – 10/2022

2
Fault list – safety technology
Fault 13 Encoder 1
Manual – Fault Descriptions MOVISAFE® CS..A 7
Subfault: 13.21
Description: SSI encoder – fault
Response: FS – warning
Cause Measure
SSI encoder detected a fault. – Check the startup parameters.
– Check the settings on the SSI encoder.
– Check the wiring.
– Check interference sources (light beam inter-
rupted, reflector, data cables, etc.).
– Replace the encoder.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive even with a faulty external posi-
tion encoder.
Subfault: 13.23
Description: Internal fault
Response: FS – warning
Cause Measure
Encoder signaled internal fault.
INFORMATION
The encoder fault code is displayed in
MOVISUITE® in the [Diagnostics] > [Fault
memory T.] parameter group in the "Internal" pa-
rameter.
– Check the wiring.
– Check interference sources (light beam inter-
rupted, reflector, data cables, etc.).
– Replace the encoder.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive using the motor encoder even if
the external position encoder is faulty.
Subfault: 13.50
Description: Safety card encoder fault
Response: FS – encoder fault
Cause Measure
Encoder fault detected on safety card. – Check the wiring.
– Check interference sources.
– Apply the shield of the encoder cable over a
large area.
– Check the encoder.
27799182/EN – 10/2022

2Fault list – safety technology
Fault 13 Encoder 1
Manual – Fault Descriptions MOVISAFE® CS..A
8
Subfault: 13.51
Description: Safety card encoder warning
Response: FS – warning
Cause Measure
Encoder fault detected while drive safety function
is inactive.
– Check the wiring.
– Check interference sources.
– Apply the shield of the encoder cable over a
large area.
– Check the encoder.
Subfault: 13.52
Description: Encoder signal fault
Response: FS – warning
Cause Measure
Unexpected encoder signals. – Check the wiring.
– Check interference sources.
– Apply the shield of the encoder cable over a
large area.
– Check the encoder.
Subfault: 13.53
Description: Maximum frequency exceeded
Response: FS – warning
Cause Measure
Maximum permitted signal frequency exceeded. – Check the maximum input frequency.
– Check the wiring.
– Check interference sources.
– Apply the shield of the encoder cable over a
large area.
– Check the encoder.
Subfault: 13.54
Description: Cross comparison error
Response: FS – warning
Cause Measure
Cross comparison error in encoder evaluation. – Check the wiring.
– Check interference sources.
– Apply the shield of the encoder cable over a
large area.
– Check the encoder.
27799182/EN – 10/2022

2
Fault list – safety technology
Fault 13 Encoder 1
Manual – Fault Descriptions MOVISAFE® CS..A 9
Subfault: 13.55
Description: Signal level monitoring
Response: FS – warning
Cause Measure
Track signal level not within tolerance band. – Check the wiring.
– Check interference sources.
– Apply the shield of the encoder cable over a
large area.
– Check the encoder.
Subfault: 13.56
Description: Maximum speed exceeded while encoder fault muting is active
Response: FS – system error
Cause Measure
Maximum permitted speed exceeded while en-
coder fault muting is active.
– Check the maximum speed of the application
while encoder fault muting is active and adjust if
necessary.
– Check the parameter setting of the safety card
and adjust if necessary.
Subfault: 13.57
Description: Maximum speed exceeded
Response: FS – encoder fault
Cause Measure
Permitted maximum speed exceeded. – Check the maximum speed of the application
and adjust if necessary.
– Check the parameter setting of the safety card
and adjust if necessary.
Subfault: 13.58
Description: Detection limit exceeded
Response: FS – warning
Cause Measure
Speed exceeded detection limit. – Check the maximum speed of the application
and adjust if necessary.
– Check the parameter setting of the safety card
and adjust if necessary.
Subfault: 13.59
Description: Encoder no longer referenced
Response: FS – warning
Cause Measure
Diagnostics error detected during encoder evalu-
ation. Referencing is canceled.
– Remove the cause of the error.
– Reference the encoder again.
27799182/EN – 10/2022

2Fault list – safety technology
Fault 13 Encoder 1
Manual – Fault Descriptions MOVISAFE® CS..A
10
Subfault: 13.60
Description: Travel limit exceeded
Response: FS – encoder fault
Cause Measure
Travel limit violated for an application with limited
travel distance.
– Check the startup parameters.
– Check the application.
– Perform referencing again.
Subfault: 13.61
Description: Wrong number of bits per telegram
Response: FS – warning
Cause Measure
The number of bits received per telegram does
not match the number of parameterized bits.
– Check the startup parameters.
– Check the wiring.
– Check interference sources.
Subfault: 13.62
Description: Wrong cycle frequency
Response: FS – warning
Cause Measure
Measured clock does not correspond with param-
eterized clock.
– Check the startup parameters.
– Check the wiring.
– Check interference sources.
Subfault: 13.64
Description: Inconsistent or corrupt data
Response: FS – warning
Cause Measure
Inconsistent or corrupt data detected during en-
coder evaluation.
– Check interference sources (e.g. from the area
of EMC).
– Check the encoder cable or shield.
– Check the startup parameters.
Subfault: 13.65
Description: Illumination color error
Response: FS – warning
Cause Measure
The lighting color in the encoder data does not
match the lighting color in use.
– Switch the device off and on again.
– If the fault occurs repeatedly, replace the en-
coder and send it to SEW‑EURODRIVE together
with the fault number. For further support, contact
SEW‑EURODRIVE Service.
27799182/EN – 10/2022

2
Fault list – safety technology
Fault 13 Encoder 1
Manual – Fault Descriptions MOVISAFE® CS..A 11
Subfault: 13.66
Description: No position code visible
Response: FS – warning
Cause Measure
Optical encoder cannot decode valid barcode/
matrix code in field of view.
– Check the code tape for damage (e.g. gaps,
covering, contamination, reflecting materials, or
ambient light sources).
– Check the optical system of the encoder for
damage or dirt.
– Check diagnostic data indicating faulty as-
sembly.
– Check the encoder for proper mounting, such
as distance to the code tape, lateral offset or
twisting.
– To make the system more robust, increase the
value of the "Threshold for tolerated faults – PXV
encoder".
– If the fault occurs repeatedly, replace the en-
coder and send it to SEW‑EURODRIVE together
with the fault number. For further support, contact
SEW‑EURODRIVE Service.
Subfault: 13.67
Description: SSI encoder – warning
Response: FS – warning
Cause Measure
SSI encoder signaled a warning. – Check the startup parameters.
– Check the settings on the SSI encoder.
– Check the wiring.
– Check interference sources (light beam inter-
rupted, reflector, signal cables, etc.).
– Replace the encoder.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive even with a faulty external posi-
tion encoder.
Subfault: 13.68
Description: Internal fault – overflow
Response: FS – warning
Cause Measure
Overflow detected during internal calculation. Adjust startup parameters, such as numerator
scaling/denominator scaling.
27799182/EN – 10/2022

2Fault list – safety technology
Fault 13 Encoder 1
Manual – Fault Descriptions MOVISAFE® CS..A
12
Subfault: 13.69
Description: Invalid HIPERFACE® communication
Response: FS – warning
Cause Measure
Failure to establish connection with encoder. – Acknowledge the encoder fault in the basic
device.
– Check the voltage supply.
– Check interference sources (e.g. from the area
of EMC).
– Check the wiring.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive using the motor encoder even if
the external position encoder is faulty.
Subfault: 13.70
Description: Error detecting low level
Response: FS – warning
Cause Measure
Fault detected while sensing low level. – Check the wiring.
– Check the encoder.
– If the fault occurs repeatedly, replace the safety
card and send it together with the fault number to
SEW‑EURODRIVE. For further support, contact
SEW‑EURODRIVE Service.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive using the motor encoder even if
the external position encoder is faulty.
27799182/EN – 10/2022

2
Fault list – safety technology
Fault 13 Encoder 1
Manual – Fault Descriptions MOVISAFE® CS..A 13
Subfault: 13.71
Description: Response time of safety card exceeded
Response: FS – warning
Cause Measure
The response time for calculating the speed or
acceleration cannot be adhered to. This can be
due to the following reasons:
– The safety card has received more corrupt tele-
grams from the encoder than the error tolerance
allows.
– The actual refresh time of the encoder is
greater than parameterized.
– Check the wiring.
– Check the encoder.
– Adjust the refresh time to the value in the en-
coder manual.
– If the fault occurs repeatedly, replace the safety
card and send it together with the fault number to
SEW‑EURODRIVE. For further support, contact
SEW‑EURODRIVE Service.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive using the motor encoder even if
the external position encoder is faulty.
Subfault: 13.72
Description: Internal fault – overflow during position calculation
Response: FS – warning
Cause Measure
Overflow detected during internal calculation of
the position.
Adjust startup parameters, for example:
– Numerator scaling/denominator scaling of the
encoder.
– User units of the position.
Subfault: 13.73
Description: Encoder range overflow pending
Response: FS – warning
Cause Measure
The encoder is just before overflow. The system
is too fast. The position difference is above the
1/4 encoder range. With 1/2 encoder range, an
undetected reversal of the direction of rotation oc-
curs and consequently a permanent error in posi-
tion.
– Reduce the system speed.
– Use an encoder with a larger encoder measur-
ing range (resolution/multi-turn range).
27799182/EN – 10/2022

2Fault list – safety technology
Fault 14 Encoder2
Manual – Fault Descriptions MOVISAFE® CS..A
14
2.2 Fault 14 Encoder2
Subfault: 14.1
Description: Error during position comparison check
Response: FS – warning
Cause Measure
Fault detected when comparing raw position and
track counter of absolute encoder.
– Check the track signal wiring.
– Check for EMC-compliant installation.
– Replace the encoder.
– Replace the encoder card.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive using the motor encoder even if
the external position encoder is faulty.
Subfault: 14.10
Description: Position tolerance range exceeded
Response: FS – warning
Cause Measure
Jump in position impermissibly large. – Check the startup parameters.
– Check the wiring.
– Check interference sources (light beam inter-
rupted, reflector, signal cables, etc.).
– Replace the encoder.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive using the motor encoder even if
the external position encoder is faulty.
Subfault: 14.11
Description: Encoder data timeout
Response: FS – warning
Cause Measure
Internal fault detected in resolver evaluation. Check for EMC-compliant installation.
Communication to encoder failed. Contact SEW‑EURODRIVE Service.
27799182/EN – 10/2022

2
Fault list – safety technology
Fault 14 Encoder2
Manual – Fault Descriptions MOVISAFE® CS..A 15
Subfault: 14.14
Description: Communication error
Response: FS – warning
Cause Measure
Faulty communication with encoder. – Check the voltage supply.
– Check for EMC-compliant installation.
– Check the wiring.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive using the motor encoder even if
the external position encoder is faulty.
Subfault: 14.17
Description: High level in data line – fault
Response: FS – warning
Cause Measure
Permanent high level of data signal detected. – Check the wiring.
– Check the encoder.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive using the motor encoder even if
the external position encoder is faulty.
Subfault: 14.19
Description: Low level in data line – fault
Response: FS – warning
Cause Measure
Permanent low level of data signal detected. – Check the wiring.
– Check the encoder.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive using the motor encoder even if
the external position encoder is faulty.
27799182/EN – 10/2022

2Fault list – safety technology
Fault 14 Encoder2
Manual – Fault Descriptions MOVISAFE® CS..A
16
Subfault: 14.21
Description: SSI encoder – fault
Response: FS – warning
Cause Measure
SSI encoder detected a fault. – Check the startup parameters.
– Check the settings at the SSI encoder.
– Check the wiring.
– Check interference sources (light beam inter-
rupted, reflector, signal cables, etc.).
– Replace the encoder.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive even if the external position en-
coder is faulty.
Subfault: 14.23
Description: Internal fault
Response: FS – warning
Cause Measure
Encoder signaled internal fault.
INFORMATION
The encoder fault code is displayed in the "In-
ternal" parameter in the parameter group [Diag-
nostics] > [Fault memory T.] in MOVISUITE®.
– Check the wiring.
– Check interference sources (light beam inter-
rupted, reflector, signal cables, etc.).
– Replace the encoder.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive using the motor encoder even if
the external position encoder is faulty.
Subfault: 14.50
Description: Safety card encoder fault
Response: FS – encoder fault
Cause Measure
Encoder fault detected on safety card. – Check the wiring.
– Check interference sources.
– Apply the shield of the encoder cable over a
large area.
– Check the encoder.
27799182/EN – 10/2022

2
Fault list – safety technology
Fault 14 Encoder2
Manual – Fault Descriptions MOVISAFE® CS..A 17
Subfault: 14.52
Description: Encoder signal fault
Response: FS – warning
Cause Measure
Unexpected encoder signals. – Check the wiring.
– Check interference sources.
– Apply the shield of the encoder cable over a
large area.
– Check the encoder.
Subfault: 14.53
Description: Maximum frequency exceeded
Response: FS – warning
Cause Measure
Maximum permitted signal frequency exceeded. – Check the maximum input frequency.
– Check the wiring.
– Check interference sources.
– Apply the shield of the encoder cable over a
large area.
– Check the encoder.
Subfault: 14.54
Description: Cross comparison error
Response: FS – warning
Cause Measure
Cross comparison error in encoder evaluation. – Check the wiring.
– Check interference sources.
– Apply the shield of the encoder cable over a
large area.
– Check the encoder.
Subfault: 14.55
Description: Signal level monitoring
Response: FS – warning
Cause Measure
Track signal level not within tolerance band. – Check the wiring.
– Check interference sources.
– Apply the shield of the encoder cable over a
large area.
– Check the encoder.
27799182/EN – 10/2022

2Fault list – safety technology
Fault 14 Encoder2
Manual – Fault Descriptions MOVISAFE® CS..A
18
Subfault: 14.56
Description: Maximum speed exceeded while encoder fault muting is active
Response: FS – system error
Cause Measure
Maximum permitted speed exceeded while en-
coder fault muting is active.
– Check the maximum speed of the application
while encoder fault muting is active and adjust if
necessary.
– Check the parameter setting of the safety card
and adjust if necessary.
Subfault: 14.57
Description: Maximum speed exceeded
Response: FS – encoder fault
Cause Measure
Permitted maximum speed exceeded. – Check the maximum speed of the application
and adjust if necessary.
– Check the parameter setting of the safety card
and adjust if necessary.
Subfault: 14.58
Description: Detection limit exceeded
Response: FS – warning
Cause Measure
Speed exceeded sensing limit. – Check the maximum speed of the application
and adjust if necessary.
– Check the parameter setting of the safety card
and adjust if necessary.
Subfault: 14.59
Description: Encoder no longer referenced
Response: FS – warning
Cause Measure
Diagnostics error detected during encoder evalu-
ation. Referencing is canceled.
– Remove the cause of the error.
– Reference the encoder again.
Subfault: 14.60
Description: Travel limit exceeded
Response: FS – encoder fault
Cause Measure
Travel limit violated for an application with limited
travel distance.
– Check the startup parameters.
– Check the application.
– Perform referencing again.
27799182/EN – 10/2022

2
Fault list – safety technology
Fault 14 Encoder2
Manual – Fault Descriptions MOVISAFE® CS..A 19
Subfault: 14.61
Description: Wrong number of bits per telegram
Response: FS – warning
Cause Measure
The number of bits received per telegram does
not match the number of parameterized bits.
– Check the startup parameters.
– Check the wiring.
– Check interference sources.
Subfault: 14.62
Description: Wrong cycle frequency
Response: FS – warning
Cause Measure
Measured clock does not correspond with param-
eterized clock.
– Check the startup parameters.
– Check the wiring.
– Check interference sources.
Subfault: 14.64
Description: Inconsistent or corrupt data
Response: FS – warning
Cause Measure
Inconsistent or corrupt data detected during en-
coder evaluation.
– Check interference sources (e.g. from the area
of EMC).
– Check the encoder cable or shield.
– Check the startup parameters.
Subfault: 14.65
Description: Illumination color error
Response: FS – warning
Cause Measure
The lighting color in the encoder data does not
match the lighting color in use.
– Switch the device off and on again.
– If the fault occurs repeatedly, replace the en-
coder and send it to SEW‑EURODRIVE together
with the fault number. For further support, contact
SEW‑EURODRIVE Service.
27799182/EN – 10/2022

2Fault list – safety technology
Fault 14 Encoder2
Manual – Fault Descriptions MOVISAFE® CS..A
20
Subfault: 14.66
Description: No position code visible
Response: FS – warning
Cause Measure
Optical encoder cannot decode valid barcode/
matrix code in field of view.
– Check the code tape for damage (e.g. gaps,
covering, contamination, reflecting materials, or
ambient light sources).
– Check the optical system of the encoder for
damage or dirt.
– Check diagnostic data indicating faulty as-
sembly.
– Check the encoder for proper mounting, such
as distance to the code tape, lateral offset or
twisting.
– To make the system more robust, increase the
value of the "Threshold for tolerated faults – PXV
encoder".
– If the fault occurs repeatedly, replace the en-
coder and send it to SEW‑EURODRIVE together
with the fault number. For further support, contact
SEW‑EURODRIVE Service.
Subfault: 14.67
Description: SSI encoder – warning
Response: FS – warning
Cause Measure
SSI encoder signaled a warning. – Check the startup parameters.
– Check the settings at the SSI encoder.
– Check the wiring.
– Check interference sources (light beam inter-
rupted, reflector, signal cables, etc.).
– Replace the encoder.
INFORMATION
In "Emergency mode" manual mode, you can
move the drive even if the external position en-
coder is faulty.
Subfault: 14.68
Description: Internal fault – overflow
Response: FS – warning
Cause Measure
Overflow detected during internal calculation. Adjust startup parameters, such as numerator
scaling/denominator scaling.
27799182/EN – 10/2022
