Sharp FP-J30M User manual

Free standing type
AIR PURIFIER
OPERATION MANUAL
R
FP-J30M
“Plasmacluster” and “Device of a cluster of grapes” are
trademarks of Sharp Corporation.
*The number in this technology mark indicates an
approximate number of ions supplied into air of 1 cm3,
which is measured around the center of a room with
the “high-density plasmacluster 7000” applicable oor
area (at 1.2 m height above the oor) at the medium
wind volume in air purifying mode, when an air purier
using the high-density plasmacluster ion evolving
device is placed close to a wall. This product is
equipped with a device corresponding to this capacity.
OM_FP-J30Ｍ.indd 1 2017/11/10 16:48:02

HEPA Filter
Deodorizing Filter
Back Panel
Please read before operating your new Air Purier
The air purier draws in room air from the air intake, passes the air through a pre-
Filter, a HEPA Filter inside of the unit, then discharges the air through the air outlet.
The HEPA Filter can remove 99.97% of dust particles as small as 0.3 microns that
pass through the lter.
The Deodorizing Filter gradually absorbs odors as they pass through the lter.
Some odors absorbed by the lter may break down over time, resulting in additional
odor. Depending on the usage environment, especially when the product is used in
extreme environments (signicantly more severe than normal household use), this
odor may become strong in a shorter period than expected. If the odor persists, the
lter should be replaced.
NOTE
• The air purier is designed to remove air-suspended dust, but not harmful gases
(for example, carbon monoxide contained in cigarette smoke).
OM_FP-J30Ｍ.indd 2 2017/11/10 16:48:03

E-1
Thank you for purchasing the SHARP
Air Purier. Please read this manual carefully.
Before using this product, be sure to read the
section: “Important Safety Instructions.”
After reading this manual, keep it in a
convenient location for future reference.
For your reference, we recommend to keep
this manual in the place where you can read
at any time.
IMPORTANT SAFETY INSTRUCTIONS
.....E-2
PART NAMES...............................................E-4
FILTER INSTALLATION ............................. E-5
OPERATION .................................................E-6
CARE AND MAINTENANCE .....................E-8
REPLACEMENT GUIDELINES ................. E-9
TROUBLESHOOTING ..............................E-10
SPECIFICATIONS...................................... E-11
CONTENTS
FEATURES
Unique Combination of Air Treatment
Technologies
Filtration System + Plasmacluster
TRAPS DUST*
Pre-lter traps dust and other large
airborne particles.
REDUCES ODORS
Deodorizing lter absorbs many common
household odors.
REDUCES POLLEN & MOLD*
HEPA lter traps 99.97% of particles as
small as 0.3 microns.
FRESHENS
Plasmacluster treats the air similar to
the way nature cleans the environment
by emitting a balance of positive and
negative ions.
*When air is drawn through the lter
system.
OM_FP-J30Ｍ.indd 1 2017/11/10 16:48:03

E-2
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be followed,
including the following:
WARNING - To reduce the risk of electrical shock, re or injury to persons:
• Read all instructions before using the unit.
• Use only a 220-240 volt outlet.
• Do not use the unit if the power cord or plug is damaged or the connection to the
wall outlet is loosened.
• Periodically remove dust from the power plug.
• Do not insert ngers or foreign objects into the air intake or air outlet.
• When removing the power plug, always hold the plug and never pull the cord.
Electrical shock and/or re from short circuit may occur as a result.
• Be careful not to damage the power cord, it may cause electric shock, excess heat or
res.
• Do not remove the plug when your hands are wet.
• Do not use this unit near gas appliances or replaces.
• Remove the power plug from the wall outlet before cleaning the unit and when not
using the unit.
Electrical shock from bad insulation and/or re from short circuit may occur as a result.
•When cleaning the unit, or when the unit is not in use, be sure to unplug the unit. Electrical
shock and/or re from a short circuit may result.
• If the power cord is damaged, it must be replaced by the manufacturer, its service
agent, Sharp Approved Service Center or similarly qualified person in order to
avoid a hazard.
• Do not operate when using aerosol insecticides or in rooms where there is oily residue,
incense, sparks from lit cigarettes, chemical fumes in the air or in very high humidity
conditions, such as a bathroom.
• Be cautious when cleaning the unit. Corrosive cleansers may damage the exterior.
• Only a Sharp Authorized Service Center should service this air purifier. Contact the
nearest Service Center for any problems, adjustments, or repairs.
• This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
NOTE - Radio or TV Interference
If this air purier should cause interference to radio or television reception, try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the unit and radio/TV/wave-clock receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
OM_FP-J30Ｍ.indd 2 2017/11/10 16:48:03

E-3
CAUTIONS CONCERNING OPERATION
• Do not block the intake and/or air outlet.
• Do not use the unit near or on hot objects, such as stoves or heaters or where it may
come into contact with steam.
• Do not lay the unit down when using.
• Always hold the handle on the back of the unit when moving it.
• Do not use without the lter inside the unit.
• Do not wash and reuse the HEPA lter and the Deodorizing lter.
Not only does it not improve lter performance, it may cause electric shock or malfunction.
INSTALLATION GUIDELINES
•When using the unit, place it away from equipment utilizing electric waves such as
televisions or radios to avoid electrical interference.
• Avoid use in locations where furniture, fabrics or other items may come in contact
with and restrict the air intake and/or air outlet.
• Avoid use in locations where the unit is exposed to condensation or drastic
temperature changes. Appropriate conditions are when room temperature is
between 0 – 35 ºC.
• Place on a stable surface with sufcient air circulation.
When placing the unit on a heavily carpeted area, the unit may vibrate slightly.
• Avoid locations where grease or oily smoke is generated.
The unit surface may crack as a result.
•Place the unit about 30 cm(1 ft) away from the wall in order to ensure proper
airow.
The dust collecting performance will be the same even if using the unit 3cm away from
the wall, but place it as far as possible(30cm away recommended) because it may dirty
the wall or oor around.
FILTER GUIDELINES
• Follow the instructions in this manual for correct care and maintenance of the lter.
OM_FP-J30Ｍ.indd 3 2017/11/10 16:48:03

E-4
PART NAMES
13
15
2
1
1Main Unit 8
MODE Button, indicator light(green)
(Press 3 sec.)
Plasmacluster Ion ON/OFF Button
2Air Outlet
3OFF TIMER Button,Indicator Light(green)
(Press 3 sec.) Filter Reset Button
9HEPA Filter
10 Deodorizing Filter
4Replace Filter indicator Light(orange) 11 Back Panel (Pre-Filter)
5Plasmacluster Ion Indicator Light (blue) 12 Bottom Tabs
6POWER ON/OFF Button 13 Handle
7HAZE Button, indicator Light (green)
(Press 3 sec.) LIGHT ON/OFF Button
14 Power Cord
15 Plug
(Shape of plug depends on country.)
FRONT
BACK
4
8
6
3
14
9
11
12
5
7
10
OM_FP-J30Ｍ.indd 4 2017/11/10 16:48:05

E-5
1
Remove the Back Panel.
Pull the Back Panel while holding down
the Main Unit.
2
Remove the plastic bag from the
Filter.
3
Place the Filter within the Main
Unit.
Do not install the filter backwards or
the unit will not operate properly.
4 Replace the Back Panel to the
main unit.
FILTER INSTALLATION
To maintain the quality of the  lter, it is installed in the main unit and packed in plastic
bag. Be sure to remove the  lter from the plastic bag before using the unit.
• Do not operate the unit without the  lter.
Pull
Be sure to remove the power plug
from the wall outlet.
3Push
Bottom Tabs
Push
OM_FP-J30Ｍ.indd 5 2017/11/10 16:48:10

E-6
OPERATION
MED MAX SLEEP
The unit operates at HIGH fan speed for 60 minutes and then alternates between Low and High level
for 20 minutes each.
CLEAN AIR
START
•Select the desired fan speed.
•Unless the power cord has been unplugged,
the operation starts in the previous mode it
was operated in.
STOP
HAZE
START
10 minutes: Max High fan level
50 minutes: High fan level
20 minutes: Low fan level
20 minutes: High fan level
• If Plasmacluster Ion is OFF, Plasmacluster Ion will not be
released.
• It is possible to switch this mode to another while operating.
However, the HAZE mode will not function after switching
mode.
NOTE
FAN SPEED
SLEEP
• The unit will operate very quietly with low fan speed.
Plasmacluster Ion Indicator goes off automatically.
Even though the indicator is off, Plasmacluster Ion is
dispersed into air unless Plasmacluster Ion is turned off
by .
NOTE
OM_FP-J30Ｍ.indd 6 2017/11/10 16:48:17

E-7
When Indicator is off,
•If Plasmacluster Ion is ON,
•If Plasmacluster Ion is OFF,
3 sec.
OFF
OFF
Light Control
Plasmacluster Ion ON/OFF
You can set the Plasmacluster Ion Indicator to OFF when the Plasmacluster Ion Indicator is bright.
ON
more 3 sec. more 3 sec.
OFF
•When the unit starts operation, the
operation starts in the previous
mode it was operated in.
NOTE
When Plasmacluster Ion is ON, the Plasmacluster Ion Indicator Light will turn on. (blue)
ON OFF
NOTE
Flashing
Lighting
4h ●8h ●CANCEL
OFF TIMER
Select the time turning off the unit during operation. The unit automatically stops once the selected
time is reached.
3 sec.
more 3 sec. more 3 sec.
OM_FP-J30Ｍ.indd 7 2017/11/10 16:48:23

E-8
To maintain optimum performance of this air puri er, please clean the unit including the  lter
periodically.
Be sure to disconnect the power cord from the wall outlet before performing any maintenance.
CARE AND MAINTENANCE
Gently remove dust from the Back Panel
by using a vacuum cleaner attachment or
similar tool.
Back Panel (Pre- lter)
Back Panel
Back Panel
Unit
Wipe with a dry, soft cloth
For stubborn stains or dirt, use a soft cloth dampened with warm water.
• Do not use volatile  uids
Benzene, paint thinner, polishing powder, etc. , may damage the surface.
• Do not use detergents
Detergent ingredients may damage the unit.
CAUTION
1. Add a small amount of kitchen detergent to water and
soak for about 10 minutes.
2. Rinse off the kitchen detergent with clean water.
3. Completely dry the  lter in a well-ventilated area.
How to clean stubborn dirtNOTE
Do not apply excessive pressure when
scrubbing the Back Panel.
CAUTION
Gently remove dust from the HEPA FILTER and Deodorizeing Filter
with a vacuum cleaner attachment or similar tool.
Filters
CAUTION
Tag
HEPA Filter
Deodorizing Filter
Do not WASH in water and DRY in the sun.
The  lters are fragile, be careful not to apply too much force.
• HEPA Filter
Apply the maintenance only on the side with the tag.
Do not clean the opposite side; otherwise, the  lter will be damaged.
• Deodorizing Filter
The maintenance can be applied to the both sides.
OM_FP-J30Ｍ.indd 8 2017/11/10 16:48:28

E-9
REPLACEMENT GUIDELINES
Disposal of Filter
Please dispose of the replaced lter according
to the local disposal laws and regulations.
Replacement timing
When Replace Filter Indicator light turn on*
HEPA Filter
•Filter : Polypropylene
•Frame : Polyester
Filter
Replace the Filter according to the instructions
provided with the replacement lter.
After the exchange, insert the plug in socket and
press the POWER button, and OFF TIMER button 3
seconds.
Deodorizing Filter
•Polypropylene
•Polyester
•Activated charcoal
HEPA
Filter
Deodorizing
Filter
Deodorizing Filter
Model : FZ-F30HFE
Model : FZ-F30DFE
HEPA Filter
Do not wash and reuse the lter
The lter life and replacement period are based
on the condition of smoking 5 cigarettes per day
and the dust collection power is reduced by half
compared with that of new lter.
Filter life varies depending on the room environ-
ment, usage, and location of the unit.
We recommend to replace the filter more fre-
quently if the product is used in a condition signi-
cantly severer than normal household use.
• Please consult your dealer for purchase of
replacement lter.
• Use only lter designed for this product.
*
The Replace Filter indicator light will turn on after
approximately 17,500 hours in Sleep mode.( 2 years ×
24 hours = 17,500)
Filter life varies depend on the operation mode.
OM_FP-J30Ｍ.indd 9 2017/11/10 16:48:32

E-10
Before calling for repair, please review the list below, since the problem may not be a unit malfunction.
TROUBLESHOOTING
SYMPTOM REMEDY (not a malfunction)
Dust and smoke are not removed. • Clean or replace the lter if they appear to be heavily
soiled. (Refer to E-8,E-9)
A clicking or ticking sound is heard
from the unit.
• Clicking or ticking sound may be audible when the unit
is generating ions. (Refer to E-7)
The discharged air has an odor. • Check to see if the lter are heavily soiled.
Replace the lter.
• Plasmacluster Air Puriers emit small traces of ozone
which may produce an odor. These ozone emissions
are well below safety levels.
The Plasmacluster Ion Indicator
doesn’t Light on.
• Check to see if the SLEEP mode is selected.
The Plasmacluster Ion Indicator Light is turned off
3 seconds after the SLEEP mode is selected.
• Check to see if the Plasmacluster Ion OFF is selected.
Press for 3 seconds to light On.
• Check to see if the Light Control OFF is selected.
Press for 3 seconds to light On.
AUTO RESTART • Even when the plug is unplugged or the breaker
is thrown during operation, the unit resumes at the
previous operation mode and settings if the power
recovers.
ON(default)
OFF
(with the unit OFF)
(with the unit OFF)
If the , , lights Lights up for
10 seconds, the setting is ‘ON’.
(simultaneously for more than 3 sec.)
(simultaneously for more than 3 sec.)
If the , , lights ashes for 3
seconds, the setting is ‘OFF’.
OM_FP-J30Ｍ.indd 10 2017/11/10 16:48:38

E-11
Power supply 220-240V 50-60Hz
Fan
Speed
Operation
Fan Speed Adjustment MAX MED SLEEP
Rated Power 50W 30W 13W
Fan Speed 180m3/hour 120m3/hour 60m3/hour
Recommended Room Size ~22m2*1
High density Plasmacluster ion recommended room size ~16m2*2
Cord Length 2.0m
Dimensions 431mm(W)x211mm(D)x411mm(H)
Weight 4.2kg
*1 Size of a room which is appropriate for operating the unit at maximum fan speed.
• It indicates the space where a certain amount of dust particles can be removed in 30 minutes
(JEM1467).
*2 Size of a room in which approximately 7000 ions can be measured per cubic centimeter in the
center of the room (at a height of approximately 1.2 meters from the oor) when the product is
placed next to a wall and run at the MED operation position.
Standby Power In order to operate the electrical circuits while the power plug is inserted in the
wall outlet, this product consumes about 0.6W of standby power.
For energy saving, unplug the power cord when the unit is not in use.
SPECIFICATIONS
OM_FP-J30Ｍ.indd 11 2017/11/10 16:48:38

E-12
MEMO
OM_FP-J30Ｍ.indd 12 2017/11/10 16:48:38

E-13
MEMO
OM_FP-J30Ｍ.indd 13 2017/11/10 16:48:38

Printed in Thailand
TINS-B085KKRZ 17K- 1
SHARP BUSINESS SYSTEMS (INDIA) PRIVATE LIMITED
487/35A, 1ST FLOOR, OUTER RING ROAD,
PEERAGARHI NEW DELHI-110087
OM_FP-J30Ｍ.indd 14 2017/11/10 16:48:38
