Sharp FU-551KB User manual

FU-551KB
R
AIR PURIFIER
OPERATION MANUAL
m¢Ój¨sÔp
¥mñpjj
¦¦kp
Wall mounting type
“Plasmacluster” and “Device of a cluster of
grapes” are trademarks of Sharp Corporation.
* Shelf-placement type
A stand for shelf-placement can be used for
installation.
* The number in this technology mark indicates the
approximate number of ions supplied into 1 cm3
of air, which is measured around the center of a
room (with the “High-Density Plasmacluster 25000”
applicable Àoor area), at a height of 1.2m above
the Àoor, at the MAX wind volume setting in air
purifying mode, and when an air puri¿er using the
high-density plasmacluster ion evolving device is
placed close to a wall.
ENGLISH ©

Before operating your new air puri¿er , please read the following
The air puri¿er draws in room air through the air intake, circulates it through a
Pre-Filter, a Deodorizing Filter and a HEPA Filter inside the unit, and then discharges
it through the air outlet. The HEPA Filter can remove 99.97% of dust particles as
small as 0.3 microns that pass through the ¿lter and also helps absorb odors.
The Deodorizing Filter gradually absorbs odors as they pass through the ¿lter.
Some odors absorbed by the ¿lters will break down over time, causing additional
odors. Depending on usage conditions, and especially if the product is used in
environments signi¿cantly more severe than a normal household, these odors may
become noticeable sooner than expected. If these odors persist replace the ¿lters.
NOTE
• The air puri¿er is designed to remove air-suspended dust and the odors they cause. The air
puri¿er is not designed to remove harmful gases such as carbon monoxide contained in cigarette
smoke. The air puri¿er may not completely remove an odor if the source of the odor is still present.
Pre-Filter
HEPA Filter
Deodorizing Filter

E-1
ENGLISH
FEATURES
Thank you for purchasing this SHARP Air
Puri¿er. Please read this manual carefully
before using the air puri¿er.
After reading, keep the manual in a
convenient location for future reference.
Unique Combination of Air Treatment
Technologies
Triple Filtration System + Plasmacluster
Ions
TRAPS DUST*
Pre-¿lter traps dust and other large
airborne particles.
DECREASES ODORS
Deodorizing ¿lter absorbs many common
household odors.
REDUCES POLLEN & MOLD*
HEPA ¿lter traps 99.97% of particles as
small as 0.3 microns.
FRESHENS
By emitting a balance of positive and neg-
ative ions, Plasmacluster air treatment is a
natural process.
*When air is circulated through the ¿lter
system.
Sensor technology continuously monitors
air quality, and automatically adjusts
operation based on air purity level.
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
..... E-2
PART NAMES...............................................E-4
PREPARATION ............................................E-6
OPERATION .................................................E-7
USEFUL FUNCTION .................................E-10
CARE AND MAINTENANCE ................... E-11
TROUBLESHOOTING ..............................E-15
SPECIFICATIONS......................................E-16
CONTENTS

E-2
IMPORTANT SAFETY INSTRUCTIONS
Always follow basic safety precautions when using electrical appliances, including
the following:
WARNING -
Always observe the following to reduce the risk of electrical shock, ¿re, or injury:
• Read all instructions before using the unit.
• Use only a 220 volt outlet.
• Do not use the unit if the power cord or plug is damaged or if the connection to the wall
outlet is loose.
• Periodically remove dust from the plug.
• Do not insert ¿ngers or foreign objects into the air intake or air outlet.
• When removing the power plug, always hold the plug - never pull on the cord.
Failure to do so can cause a short circuit resulting in electrical shock or ¿re.
• Do not remove the plug while your hands are wet.
• Do not place the unit near gas appliances or ¿replaces.
• Always unplug the unit when cleaning the unit, or when the unit is not in use.
Failure to do so can cause a short circuit resulting in electrical shock or ¿re.
• In order to avoid safety hazards, if the power cord is damaged, it must be replaced
by either the manufacturer, a service agent, a Sharp authorized Service Center or a
similarly quali¿ed service provider.
• Only a Sharp Authorized Service Centre should service this air puri¿er. Contact the nearest
Service Centre for any problems, adjustments, or repairs.
• Do not operate the unit in rooms where aerosol insecticides are present. Do not operate the
unit in rooms where there is oily residue, incense, sparks from lit cigarettes, or chemical fumes
in the air. Do not operate the unit in places where it may get wet, such as a bathroom.
• Be cautious when cleaning the unit. Strong corrosive cleansers can damage the exterior.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory, or mental capabilities, nor by persons with insuf¿cient experience and knowledge of
how to operate the unit, unless they are given proper supervision and instruction on how to
use the unit by a person responsible for their safety. Do not allow children to play with the unit.
NOTE - What to do if the unit interferes with radio or TV reception
If the air puri¿er interferes with radio or television reception, try one or more of the following
measures:
• Adjust or reposition the receiving antenna.
• Increase the distance between the unit and the radio or TV.
• Connect the equipment into an outlet on a circuit different from that of the radio or TV
receiver.
• Consult the dealer or a quali¿ed radio or TV technician.

E-3
ENGLISH
CAUTIONS CONCERNING OPERATION
• Do not block the air intake or air outlet.
• Do not place the unit near or on hot objects, such as stoves or heaters, or where it may come
into contact with steam.
• Always operate the unit in an upright position.
• Do not operate the unit without the ¿lters properly installed.
• Do not wash and reuse the HEPA ¿lter and the Deodorizing ¿lter.
Doing so will not improve ¿lter performance and can also cause electric shock or operating
malfunctions.
• Clean the exterior with a soft cloth only.
Do not use volatile liquids or detergents.
Doing so can damage or crack the exterior of the unit.
In addition, doing so can cause sensor malfunctions.
• Keep the unit away from water.
• When cleaning the room with chemicals, please stop the unit and cover with a sheet, etc. so
the chemicals do not adhere to the unit.
• After the room cleaning, please be sure to adequately ventilate the room from chemicals and
gas generated from the chemicals before operating the unit.
INSTALLATION GUIDELINES
• When using the unit, place it at least 2 meters away from equipment that emits electric
waves, such as televisions or radios, to avoid electrical interference.
• Avoid locations where the sensors are exposed to direct wind.
Doing so can cause the unit to malfunction.
• Avoid locations where furniture, fabrics, or other objects can come in contact with the
unit and interfere with the intake and outtake of air.
• Avoid locations where the unit is exposed to condensation or drastic changes in
temperature. Appropriate room temperature is between 0 – 35 ºC.
• Place the unit on a level and stable surface with suf¿cient air circulation.
When placed on heavy carpet, the unit may vibrate slightly.
• Avoid locations that generate grease or oily smoke.
Doing so can cause the unit exterior to crack and the sensors to malfunction.
• Make sure the wall is strong enough to hold the unit’s weight.
• When wall mounted installation is not possible / When installation on a shelf, use a stand for
shelf-placement [FZ-K51STE] for installation.
For more information, please contact your dealer.
FILTER GUIDELINES
• Follow the instructions in this manual for proper ¿lter care and maintenance.

E-4
PART NAMES
UNIT
1
56
7
911 10
15
12 13 14 16 17 18 19 20
2
8
4
3(Plug shape varies by country)
lndicates air purity according
to 3 color-coded levels.
Clean sign
green
clean
red
impure
Air Outlet (Right & Left) Pre Filter (Bottom)
Air Outlet (Bottom) Remote control sensor area
Power Code/Plug Timer Indicator Light (green)
Plasmacluster Sign/Indicator Light (blue) Fan Speed Indicator Light (blue)
Pre Filter (Front) Filter Cleaning Indicator Light (orange)
Deodorizing Filter Unit Replacement Light (red)
HEPA Filter Unit Cleaning Indicator Light (orange)
Front Panel Check Indicator Light (green)
Sensor Cover (Dust/Odor sensor) Fan Speed Button
Filter Cover Power ON/OFF Button
111
212
313
414
515
616
717
818
919
10 20

E-5
ENGLISH
Remote Control
1
2
3
4
5
6
7
8
915
14
13
12
11
10
1Transmitter
2Fan Speed icon
3Display for TIME /Timer setting
4Light Control Button
5POWER ON/OFF Button
6Fan Speed setting Button
7OFF TIMER Button
8ON TIMER Button
9TIME /Timer setting Button
10 Battery icon
11 Sending icon
12 PLASMACLUSTER icon
13 PLASMACLUSTER ON/OFF Button
14 TIME Button
15 Reset Button
Remove the battery cover and insert two AAA batteries.
Make sure the positive and negative ends are facing in
the correct direction,as shown below.
1. Remote controller should never be exposed
to direct sunlight.
2. Transmitter & receiver should always be
clean to ensure proper communication. Use
a soft cloth to clean them.
3. In case other appliance operation is affected
by the remote control, change their position
or consult your dealer.
Screw the holder onto the wall and slide the controller
inside the holder.
NOTE

E-6
1
2
3
4
5
PREPARATION
TIME SETTING FOR REMOTE CONTOROL
OPERATION OF REMOTE CONTROL
< Ex. Set the TIME “AM10:30” >
or
or
Remote control
sensor area
Transmitter
Point the remote control towards the Remote control
sensor area and press the desired button. The unit
generates a beep when it receives the signal.
• Make sure no items, such as curtains, block the signal
the Remote control sensor area.
• The signal effective distance is 7 meters.
• Do not expose the Remote control sensor area
to direct sunlight. This may adversely affect its
operation.
• Use of certain Àuorescent lamps in the same room
may interfere with transmission of the signal.
CAUTION

E-7
ENGLISH
OPERATION
Power ON / OFF
FAN SPEED
START
STOP
Select the desired fan speed.
AUTO The fan speed is automatically switches between HIGH and LOW depending on the
amount of impurities in the air.
The sensors detect impurities for ef¿cient operation.
OPERATION OF THE UNIT
or
Beep
Beep
AUTO LOW MED MAX FULLPOWER
Beep Beep Beep Beep Beep
START
AUTO LOW MED
FULL POWER MAX
STOP
Beep
Beep
Beep
Beep
Beep Beep
Beep
Beep
Beep

E-8
OPERATION (continued)
ON TIMER / OFF TIMER
< Ex. Set the TIME “PM9:20” >
SET
1
2
3
4
5
OFF TIMER ON TIMER SETTING
Press
or
or
CANCELLATION
OFF TIMER
ON TIMER
Beep
Beep
Beep

E-9
ENGLISH
LIGHT CONTROL
PLASMACLUSTER ION ON/OFF
You can set the PLASMACLUSTER LIGHT icon to OFF when their LIGHT icon is bright
When the Plasmacluster Ion function is ON, the Plasmacluster Ion light is on.
TURN ON
ON OFF
TURN OFF
Beep
Beep Beep
Beep Beep
Beep

E-10
USEFUL FUNCTION
ADJUSTING SENSOR SENSITIVITY
FILTER CLEANING INDICATOR LIGHT
AUTO RESTART
CANCELLATIONON
Set the desired sensor sensitivity.
1
1
2
2
3
3
(with the unit ON)
(with the unit ON)
(with the unit OFF) (with the unit OFF)
more 3 sec.
more 3 sec.
more 5 sec. more 5 sec.
Low
720h 1,440h 2,160h
Standard High
• The sensor sensitivity setting is saved even after the unit is unplugged.
You can set the time of ¿lter cleaning indicator light turn on.
If the unit is unplugged or if there is a power failure, the unit will resume operation with the previous
settings after power is restored.
UNIT UNIT
• When the lamps light up for 5 seconds, settings are complete.
• When the lamps Àash for 5 seconds, settings are cancelled.
Beep Beep
Beep
Beep
Beep
NOTE
or
or

E-11
ENGLISH
CARE AND MAINTENANCE
FILTER CLERNING INDICATOR
The Filter Cleaning Indicator Light will turn on after approximately 720 hours.
(30 days × 24 hours =720 hours)
This is a reminder to perform the maintenance described below. After performing maintenance, reset
the Filter Cleaning Indicator.
FILTER
CLEANING
(with the unit ON)
more 3 sec.
• Even if the indicator light is off , After performing
maintenance, please reset the Filter Cleaning Indicator.
• You can set the length of time. (Ref. E-10)
CARE INDEX
• Filter Indicator Light turns on.
Pre-¿lter (Front) (Ref. E-12)
Pre-¿lter (Bottom) (Ref. E-13)
Sensor (Ref. E-13)
UNIT
Wipe with a dry, soft cloth.
CAUTION
• Do not use volatile Àuids
Benzene paint thinner, polishing powder, etc.
can damage the surface.
• Do not use detergents
Detergent ingredients can damage the unit.
a
reminder
to
perform
th
r
Cleanin
g
Indicator.
(
with the unit
ON
more
NOTE

E-12
CARE AND MAINTENANCE (continued)
PRE-FILTER (FRONT)
Gently remove dust with an appropriate
cleaning tool, such as a vacuum cleaner
with the proper attachment.
<If the front panel came out of the unit>
Insert the tab of the front panel
into the tab of the unit.
NOTE
• You can also clean the pre-filter by detaching it from the unit.
After removing the pre-filter, install it in the order shown below.
1
2
90°
1
2

E-13
ENGLISH
SENSOR
Gently remove dust with an appropriate
cleaning tool, such as a vacuum cleaner
with the proper attachment.
Gently remove dust with an appropriate
cleaning tool, such as a vacuum cleaner with
the proper attachment.
NOTE
1. Rinse the sensor ¿lter with tap water.
2. Completely dry the sensor ¿lter in a ventilated area.
SENSOR FILTER
PRE-FILTER (BOTTOM)
1
2

E-14
CARE AND MAINTENANCE (continued)
FILTER REPLACEMENT
UNIT REPLACEMENT LIGHT
When to replace the ¿lter
Please consult your dealer.
• HEPA Filter About 2 years after ¿rst use
MODEL: FZ-K51HFE
• Deodorizing Filter About 2 years after ¿rst use
MODEL: FZ-K51DFE
These ¿lter lifespan and replacement suggestions are based on purifying a room in which 10
cigarettes are smoked per day and the unit’s dust collection and deodorizing performance has
declined to half the level of a new ¿lter.
Disposing of ¿lters
Dispose of used ¿lters according to local laws and regulations.
HEPA Filter material :
• Filter : Polypropylene
• Frame: polyethylene
Deodorizing Filter material :
• Deodorizer : Activated charcoal
• Filter : Paper
The Unit Replacement light will turn on after approximately 17,500 hours.
( 2 years × 24 hours = 17,500)
When to replace the unit
Please consult your dealer.
Elapsed Time Display Message
Begin use
Approx. 17,500 hours Flashing slowly Replace the Plasmacluster
Ion Generating Unit
Approx. 19,000 hours Flashing fast No Plasmacluster Ion

E-15
ENGLISH
TROUBLESHOOTING
Before calling for service, please review the troubleshooting chart below to make sure that the problem is
not a unit malfunction.
SYMPTOM REMEDY (the following are not due to a malfunction)
Odor and smoke persists. • Check the ¿lters. If they appear to be extremely dirty, clean or
replace them.
The Clean sign is green even
when the air is not clean.
• The air may have been dirty when the unit was plugged in.
Unplug the unit, wait one minute, and then plug the unit in again.
The Clean sign is orange or red
even when the air is clean.
• Dirty or clogged sensor openings interfere with sensor operation.
Gently clean the sensor cover. (Ref. E-13).
The unit makes a clicking or
ticking sound.
• The unit may make clicking or ticking sounds when it is generating
ions.
Air discharged from the unit
has an odor.
• Check to see if the ¿lters are extremely dirty.
• replace the ¿lters.
• Plasmacluster Air Puri¿ers emit small traces of ozone that can
produce an odor.
The unit does not operate when
cigarette smoke is in the air. • Check to see if the unit is installed in a location that makes it dif¿cult
for the sensors to detect cigarette smoke.
• Check to see if the sensor openings are blocked or clogged.If they
are blocked or clogged, clean the sensor cover and sensor ¿lter.
The Filter cleaning Indicator
Light is on. • Whenever replacing the ¿lters, connect the power cord to an outlet
and then press the Reset Button. (Ref. E-11)
The Plasmacluster sign is
turned off. • Check to see if the Lights OFF Mode is selected. If it is selected,
press the Lights Control Button to turn the indicator lights on.
(Ref. E-9)
The Unit change light is
Àashing. • Need to replace the Plasmacluster ion unit.
Please consult your dealer.
The Unit cleaning light is
Àashing. • Need to clean the Plasmacluster ion unit.
Please consult your dealer.
The Clean sign change color
frequently. • The Clean sign automatically change color when the sensor detect
impurities.
The Check light is Àashing. • Turn off and unplug the unit .wait one minute , and then plug the unit
in again.
If that’s still Àashing, please consult your dealer.

E-16
SPECIFICATIONS
*1 • The recommended room size is an area in which a given amount of dust particles can be removed in
30 minutes.
*2 • Room size in which approximately 25000 ions per cubic centimeter can be measured in the centre of
the room when the unit is placed next to a wall, is running at maximum settings, and is at a height of
approximately 1.2 meters from the Àoor.
Standby Power
When the unit’s power plug is inserted in a wall outlet it consumes about 1.0 watts of standby power in
order to operate electrical circuits.To conserve energy, unplug the power cord when the unit is not in use.
Power supply 220 V 50 Hz
Fan Speed Adjustment FULL POWER MAX MED LOW
CLEAN AIR
Fan Speed (m3/hour) 330 180 115 60
Rated Power (W) 78 24 13 6.5
Noise Level (dBA) 53 42 34 24
Recommended Room Size (m2)*1 ~40
High density Plasmacluster ion recommended room size (m
2
)*2
~25
Cord Length (m) 2.0
Dimensions (mm) 650 (W) × 178 (D) × 440 (H)
Weight (kg) 9.1
FACTORY
USE ONLY
Printed in China
TINS-A870KKRZ 15K- CN 1
