Sharp FP-F50U-W User manual

FRANÇAIS
ESPAÑOL ENGLISH
AIR PURIFIER
Purificateur d’air à fonction
MANUEL D’UTILISATION
OPERATION MANUAL
PURIFICADOR DE AIRE
MANUAL DE OPERACIÓN
Device of this mark is a trademark of Sharp Corporation.
“Plasmacluster” and “Device of a cluster of grapes” are
registered trademarks of Sharp Corporation in Japan,
USA and elsewhere.
This product earned the ENERGY STAR by meeting
strict energy efficiency guidelines set by the US EPA.
US EPA does not endorse any manufacturer claims of
healthier indoor air from the use of this product.
The energy efficiency of this ENERGY STAR qualified
model is measured based on a ratio between the model’
s CADR for Dust and the electrical energy it consumes,
or CADR/Watt.
Ce produit a le droit de porter la marque ENERGY
STAR après avoir répondu à des critères stricts en ce
qui concerne l’efficacité énergétique, tels qu’établis par
l’agence EPA aux É-U. L’agence EPA aux É-U n’appuie
aucunement les témoignages publicitaires du fabricant
indiquant que ce produit rend l’air intérieur des locaux
plus sain.
L’efficacité énergétique de ce modèle, qui bénéficie de
la reconnaissance ENERGY STAR, est mesurée par le
rapport entre le DAP (débit d’air purifié) du modèle et l’
énergie électrique qu’il consomme, soit le rapport DAP/
Watt.
FRANÇAIS
ESPAÑOL
FP-F50U-W

Please read before operating your new Air Purifier
The air purifier draws in room air from the air intake, passes the air through a Pre-
Filter, a intergrated HEPA and deodorization filter inside of the unit, the dischanges the
air through the air outlet. The intergrated HEPA and deodorization filter can remove
99.97% of dust particles as small as 0.3 microns that pass through the filter and
gradually absorbs odors as they pass through the filter.
Some odors absorbed by the filters may break down over time, resulting in additional
odor. Depending on the usage environment, especially when the product is used in ex-
treme environments (significantly more severe than normal household use), this odor
may become strong in a shorter period than expected. If the odor persists, the filter
should be replaced.
NOTE
• The air purifier is designed to remove air-suspended dust and odor, but not harmful gases (for
example, carbon monoxide contained in cigarette smoke). If the source of the odor still exists, the
air purifier may not completely remove the odor.
Intergrated HEPA and Deodorization Filter
Back Panel (Pre-filter)

ENGLISH
E-1
FEATURES
ENGLISH
Declaration of Conformity
SHARP AIR PURIFIER FP-F50U
This ISM device complies with Canadian
ICES-3(B)
Responsible Party:
SHARP ELECTRONICS OF CANADA LTD.
335 Britannia Road East Mississauga, Ontario
L4Z 1W9 Canada
TEL: [phone]
Thank you for purchasing this SHARP Air Pu-
rifier. Please read this manual carefully be-
fore using the air purifier.
After reading, keep the manual in a conven-
ient location for future reference.
Declaration of Conformity
SHARP AIR PURIFIER FP-F50U
This device complies with Part 15 of FCC rules.
Responsible Party:
CONTENTS
FOR CUSTOMER ASSISTANCE(U.S)
......E-2
CONSUMER LIMITED WARRANTY(U.S)
.....E-3
FOR CUSTOMER ASSISTANCE(CANADA)
....E-4
LIMITED WARRANTY(CANADA)...........E-5
IMPORTANT SAFETY INSTRUCTIONS
... E-6
•WARNING .................................................. E-6
• CAUTIONS CONCERNING OPERATION ...E-7
•INSTALLATION GUIDELINES....................E-7
•FILTER GUIDELINES ................................E-7
PART NAMES.............................................E-8
•FRONT VIEW ............................................ E-8
•BACK VIEW ................................................
E-8
•CONTROL PANEL .....................................E-9
PREPARATION FOR USE..........................E-10
•FILTER INSTALLATION ...........................E-10
OPERATION .............................................E-11
•CLEAN AIR MODE...................................E-11
•FAN SPEED Button ................................. E-11
•Plasmacluster ON/OFF Button ................ E-12
•POWER Button ........................................E-12
•CHILD LOCK Button ................................E-12
•OFF TIMER Button ..................................E-12
•
ADJUSTMENT OF SENSOR DETECTION
SENSITIVITY
............................................. E-13
CARE AND MAINTENANCE .................E-14
•BACK PANEL (PRE-FILTER) ........................ E-14
•MAIN UNIT ..............................................E-15
•INTERGRATED HEPA AND
DEODORIZATION FILTER
......................E-15
• FILTER REPLACEMENT GUIDELINES .....E-16
TROUBLESHOOTING
............................E-17
SPECIFICATIONS
....................................E-19
Unique Combination of Air Treatment
Technologies
Triple Filtration System + Plasmacluster
ion
TRAPS DUST*
Washable pre-filter traps dust and other
large airborne particles.
DECREASES ODORS
Deodorizing filter absorbs many common
household odors.
REDUCES POLLEN & MOLD*
True HEPA filter traps 99.97% of particles
as small as 0.3 microns.
FRESHENS
Plasmacluster refreshes the air similar to
the way nature cleans the environment by
emitting a balance of positive and negative
ions.
*When air is drawn through the filter
 system.
100 Paragon Drive, Suite #100,
Montvale, NJ 07645, U.S.A.
SHARP ELECTRONICS CORPORATION

E-2
FOR CUSTOMER ASSISTANCE (the United States)
MODEL NUMBER
SERIAL NUMBER
DATE OF PURCHASE
Dealer Name
Address
City
State
Zip
Telephone
TO PHONE: Dial 1-800-BE-SHARP (237-4277) for:
SERVICE (for your nearest Sharp Authorized Servicer)
PARTS (for your Authorized Parts Distributor)
ACCESSORIES
ADDITIONAL CUSTOMER INFORMATION
TO WRITE: For service problems, warranty information, missing items and other assistance:
Sharp Electronics Corporation
Customer Assistance Center
TO ACCESS OUR WEB SITE: www.sharpusa.com
Please provide the following information when you write or call: model number, serial
number, date of purchase, your complete mailing address (including zip code), your daytime
telephone number (including area code) and description of the problem.
To aid in answering questions if you call for service or for reporting loss or theft, please use
the space below to record the model and serial number located on the back of the unit.
Sharp Plaza Blvd.
Memphis, TN 38193

ENGLISH
E-3
CONSUMER LIMITED WARRANTY FOR U.S. USERS
SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand product (the
“Product”), when shipped in its original container, will be free from defective workmanship and materials, and agrees
that it will, at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufac-
tured equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below.
This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth
below nor to any Product the exterior of which has been damaged or defaced, which has been subjected to improper
voltage or other misuse, abnormal service or handling, or which has been altered or modified in design or construction.
In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and pro-
vide proof of purchase to the servicer.
The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by
law. ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE
ARE LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW. Some states do not
allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those de-
scribed herein, or to extend the duration of any warranties beyond the time period described herein on behalf of Sharp.
The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and
exclusive remedy available to the purchaser. Correction of defects, in the manner and for the period of time described
herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the purchaser with respect
to the Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict
liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the
Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor
shall Sharp be liable or in any way responsible for any incidental or consequential economic or property damage. Some
states do not allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you.
THIS WARRANTY GIVES YOU SPECIFlC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY
FROM STATE TO STATE.
Your Product Model Number & Description:
Warranty Period for this Product:
Additional Item(s) Excluded From Warranty
Coverage:
Where to Obtain Service:
What to Do to Obtain Service:
TO OBTAIN SUPPLY, ACCESSORY OR PRODUCT INFORMATION, CALL 1-800-BE-SHARP, OR VISIT OUR WEBSITE AT
www.sharpusa.com
SHARP ELECTRONICS CORPORATION
CONSUMER LIMITED WARRANTY
FP-F50U-W Air Purifier. Be sure to have this information available
when you need service for your Product.
One (1) year parts and labor from date of purchase.
Appearance items of the Product, filters, accessories, or any printed
materials. Product which has been used for rental and/or commercial
purposes.
From a Sharp Authorized Servicer located in the United States. To
find the location of the nearest Sharp Authorized Servicer, call Sharp
Toll Free at 1-800-BE-SHARP.
Ship prepaid or carry in your Product to a Sharp Authorized Servicer.
Be sure to have Proof of Purchase available. If you ship the Product,
be sure it is insured and packaged securely.
100 Paragon Drive, Suite #100, Montvale, NJ 07645, U.S.A.

E-4
FOR CUSTOMER ASSISTANCE (Canada)
To aid in answering questions if you call for service or for reporting loss or theft, please use
the space below to record the model and serial number located on the back side of the unit.
MODEL NUMBER
SERIAL NUMBER
DATE OF PURCHASE
Dealer Name
Address
City
Province
Postal Code
Telephone
TO PHONE: Dial 1-905-568-7140 for:
SERVICE (for your nearest Sharp Authorized Servicer)
PARTS (for your Authorized Parts Distributor)
ACCESSORIES
ADDITIONAL CUSTOMER INFORMATION
TO WRITE: For service problems, warranty information, missing items and
other assistance:
Sharp Electronics of Canada Ltd.
Customer Care
335 Britannia Road East
Mississauga, Ontario L4Z 1W9
TO ACCESS OUR WEB SITE: www.sharp.ca
Please provide the following information when you write or call: model number, serial number,
date of purchase, your complete mailing address (including postal code), your daytime
telephone number (including area code) and description of the problem.

ENGLISH
E-5
LIMITED WARRANTY
Consumer Electronics Products
Congratulations on your purchase!
Sharp Electronics of Canada Ltd. (“Sharp”) warrants to the first purchaser for this Sharp brand product (“Product”), when shipped in its original
container and sold or distributed in Canada by Sharp or by an authorized Sharp dealer, and Product was not sold “as is” or “sales final” that the
Product will during the applicable warranty period, be free from defects in material and workmanship, and will within the applicable warranty period,
either repair the defective Product or provide the first purchaser a replacement of the defective Product.
Conditions: This limited warranty shall not apply to:
(a)
(b)
(c)
(d)
(e)
(g)
(h)
(i)
(j)
(f)
Any defects caused or repairs required as a result of abusive operation, negligence, accident, improper installation or inappropriate use as
outlined in the owner’s manual or other applicable Product documentation.
Any defects caused or repairs required as a result of any Product that has been tampered with, modified, adjusted or repaired by any person
other than Sharp, a Sharp authorized service centre or a Sharp authorized servicing dealer.
Any defects caused or repairs required as a result of the use of the Product with items not specified or approved by Sharp, including but not l
imited to chemical cleaning agents.
Any replacement of accessories required through normal use of the Product, including but not limited to, earphones, remote controls, AC adapters,
batteries, temperature probe, trays, filters, belts, ribbons, cables and paper.
Any cosmetic damage to the Product surface or exterior that has been defaced or caused by normal wear and tear.
Any defects caused or repairs required as a result of damage caused by any external or environmental conditions, including but not limited to,
transmission line/power line voltage or liquid spillage or acts of God.
If the serial number or model number affixed to Product has been removed, defaced, changed, altered or tampered with.
This limited warranty will not apply if the Product has been used or is being used in a commercial setting or application; this warranty is meant
solely for the non-commercial, household use of the Product by consumers in their home or residence.
Any installation, delivery, setup and/or programming charges
The removal and reinstallation of Over-The-Range Microwave or Microwave Drawer if it is installed in an inaccessible location or requiring removal
of cupboards, handles or other cosmetic parts, or is not installed in accordance with installation instructions included with Product.
How to get service: Warranty service may be obtained upon delivery of the Product, together with proof of purchase (including date of purchase) and
a copy of this limited warranty statement, to an authorized Sharp service centre or an authorized Sharp servicing dealer. In home warranty service will
be carried out to locations accessible by on-road service vehicle and within 50 km of an authorized Sharp service centre on any Sharp Television with
the repair at the servicer's facility. No other person (including any Sharp dealer or service centre) is authorized to extend, enlarge or transfer this
warranty on behalf of Sharp. The purchaser will be responsible for any and all removal, reinstallation, transportation and insurance costs incurred with
exception for Over-The-Range Microwave Oven or Microwave Drawer Oven whereby Sharp will be responsible for the removal and reinstallation.
The express warranties in this limited warranty are, except for consumer purchasers domiciled in Quebec, in lieu of and, except to the extent prohibited
by applicable law, Sharp disclaims all other warranties and conditions, express or implied, whether arising by law, statute, by course of dealing or
usage of trade, including, without limitation, implied warranties or conditions of merchantability and/or quality, fitness for a particular use or purpose,
and/or non-infringement. Limitations (not applicable to consumer purchasers domiciled in Quebec to the extent prohibited under Quebec law): (a)
Sharp shall not be liable for any incidental, special, consequential, economic, exemplary or indirect damages of any kind or nature (including lost profits
or damages for loss of time or loss of use or loss of data) arising from or in any connection with the use or performance of a Product or a failure of
a Product, even if Sharp is aware of or has been advised of the possibility of such damages; (b) the remedies described in this limited warranty c
onstitute complete fulfillment of all obligations and responsibilities of Sharp to the purchaser with respect to the Product and shall constitute full
satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. Some provinces may not allow the exclusion or limitation
of certain damages, or limits on the duration or voiding of implied warranties or conditions; in such provinces, the exclusions and limits herein may
not apply. This limited warranty is, except for consumer purchasers domiciled in Quebec, governed by the laws of the Province in Canada in which
the purchaser has purchased the Product. For consumer purchasers domiciled in Quebec this limited warranty is governed by the laws of Quebec.
WARRANTY PERIODS (calculated from the date of original purchase): Parts & Labour (exceptions noted)
To obtain the name and address of the nearest Authorized Sharp Service Centre or Dealer, or for more information on this Limited Warranty,
Sharp Extended Warranty Offers, Sharp Canada Products or Accessory Sales, please contact Sharp:
By writing to Sharp Electronics Of Canada Ltd. at 335 Britannia Road East Mississauga, Ontario L4Z 1W9
Calling: at 905-568-7140
Visiting our Web site: www.sharp.ca
Audio Product 1 year
Blu-Ray Product 1 year
LCD/LED TV 1 year
Microwave Oven 1 year (magnetron - 4 additional years)
Air Purifier 1 year
3D Glasses 1 year
Wireless LAN Adapter 1 year
Small home appliances 1 year
THIS LIMITED WARRANTY IS VALID ONLY IN CANADA

E-6
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be followed, including the
following:
WARNING - To reduce the risk of electrical shock, fire or injury to persons:
• Read all instructions before using the unit.
• Use only a 120 volt outlet.
• The air purifier has a polarized plug (one blade is wider than the other). This plug will fit in a polar-
ized outlet only one way. If the plug does not fit into the outlet, reverse it. If it still does not fit, con-
tact a qualified electrician or service person.
• Do not use the unit if the power cord or plug is damaged or the connection to the wall outlet
is loosened.
• Periodically remove dust from the plug.
•Do not insert fingers or foreign objects into the air intake or air outlet.
• When removing the power plug, always hold the plug and never pull on the cord.
Electrical shock and/or fire from a short circuit may occur as a result.
• Do not remove the plug when your hands are wet.
•Do not use this unit near gas appliances or fireplaces.
• If the power cord is damaged, it must be replaced by the manufacturer, its service agent, a
Sharp Authorized Service Center or similarly qualified person in order to avoid a hazard.
• Do not operate when using aerosol insecticides or in rooms where there is oily residue, incense,
sparks from lit cigarettes, chemical fumes in the air, or in locations where the unit may get wet,
such as a bathroom.
• Be cautious when cleaning the unit. Strong corrosive cleansers may damage the exterior.
• Only a Sharp Authorized Service Center should service this air purifier. Contact the nearest Service
Center for any problems, adjustments, or repairs.
NOTE - Radio or TV Interference
If this air purifier should cause interference to radio or television reception, try to correct the interfer-
ence by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation distance between the unit and radio/TV receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected.
• Consult the dealer or an experienced radio/TV technician for help.
This product fulfils the requirement of the International standard CISPR 11.
In conformity with this standard, this product is classified as group 2 class B equipment.
Group 2 means that the equipment intentionally generates radio-frequency in the form of electromag-
netic radiation for electro-discharge machining equipment.
Class B equipment means that the equipment suitable to be used in domestic establishments.
This product complies with the maximum allowable concentration of ozone of 0.050 parts per million by
volume (ppmv) in a 24-hour period. The Health Canada Guideline 2010 recommends that the maximum
exposure limit, based on an averaging time of 8 hours, is 0.020 ppmv or less when tested in a sealed,
controlled room approximately 30 m³.

ENGLISH
E-7
CAUTIONS CONCERNING OPERATION
• Do not block the intake and/or air outlet.
• Do not use the unit near or on hot objects, such as stoves or heaters or where it may come into
contact with steam.
• Always operate the unit in an upright position.
• Always hold the handles on both sides of the unit when moving it.
Holding the back panel when carrying may cause it to detach, thus dropping the unit and resulting
in bodily injury.
• Do not operate the unit without the filters properly installed.
• Do not wash and reuse the Intergrated HEPA and deodorization Filter
Washing will not improve filter performance, it may cause electric shock or malfunction.
• Clean the exterior with a soft cloth only.
Do not use volatile fluids and/or detergents.
The unit surface may be damaged or cracked.
In addition, the sensors may malfunction as a result.
• Keep the unit away from water.
INSTALLATION GUIDELINES
• During the operation of the product, please place the unit at least 6.5ft. (2m) away from
equipment utilizing electrical waves such as televisions, radios or wave clocks.
• Avoid a location where the sensor is exposed to direct breeze or draft.
The unit may not operate properly.
• Avoid use in locations where furniture, fabrics or other items may come in contact with and
restrict the air intake and/or air outlet.
• Avoid use in locations where the unit is exposed to condensation or rapid temperature
changes. (Use under appropriate conditions between 41 - 95˚F (5 - 35˚C) in the room.)
(If it is unavoidable please allow unit to stand for 1 hour before switching on.)
•Place on a stable surface with sufficient air circulation.
When placing the unit on a heavily carpeted area, the unit may vibrate slightly.
• Avoid use in locations where grease or oily smoke is generated. (such as in a kitchen, etc.).
The unit surface may crack or the sensor may malfunction as a result.
• Place the unit about 1 ft. (30 cm) away from the wall in order to ensure proper airflow.
Placing the purifier 1ft. or more from wall will reduce dust buildup on wall surface.
FILTER GUIDELINES
• Follow the instructions in this manual for correct care and maintenance of the filter.
Use only filter designed for this product.
To reduce the risk of electric shock, this equipment has a polarized plug (one blade is wider than
the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the
outlet,reverse the plug. If it still does not fit, contact qualified personnel to install the proper outlet.
Do not alter the plug in any way.
•

PART NAMES
FRONT VIEW
BACK VIEW
Control Panel
Odor Sensor
Power Plug Power Cord
Handle
Intergrated HEPA and
Deodorization Filter
Rear Panel
(Pre-filter)
Main Unit
Air Outlet
E-8

ENGLISH
E-9
CONTROL PANEL
ODOR SENSOR
Odor
Monitoring
Odor
Green
Yellow
Red
Room
Odor
Weak
Strong
PLASMACLUSTERION ( )
ON/OFF button
(indicator light-blue)
Lighton :ON;Lightoff : OFF
FAN SPEED button
(indicator lights-green)
POWERbutton
CHILDLOCK button
(indicator light-green)
OFF TIMER button
(indicator lights-green)
FILTERRESET button

E-10
Unplug the unit before installing
or adjusting the filter.
PREPARATIONFOR USE
There is one filter in the main
unit.
Intesrated HEPA and
Deodorization Filter
Back Panel (Pre-filter)
FILTER INSTALLATION
1
Remove the back panel
(pre-filter).
2
Remove the filter
from the plastic bag.
3
The side with a ribbon
attached should face
outward.
4
Install the back panel
(pre-filter).
Click

E-11
OPERATION
CLEAN AIR MODE (NORMAL OPERATION )
1
Press the POWER Button on the display.
• If the power cord was not unplugged between uses, the
unit will automatically re-start at the previously selected
settings.
2Press the FAN SPEED Button to select the
desired fan speed.
CONTROL PANEL
FAN SPEED Button
AUTO operation
The fan speed is automatically controlled depending on the amount of impurities in
the air. The sensors detect the impurities for efficient air purification.
MAX operation
MEDIUM operation
LOW operation
The unit will operate at maximun fan speed .
The unit will operate at medium fan speed .
The unit will operate quietly using minimal air intake.
Press the FAN SPEED Button to select the preferred fan
settings. Indicator lights will show the speed currently
selected.
ENGLISH

E-12
OPERATION
Plasmacluster ON/OFF Button
Press the Plasmacluster ON/OFF Button to turn Plasmacluster Ion
Mode ON and OFF. When Plasmacluster is ON, both the Indicator
Light and Plasmacluster Indicator Light on the front display turn on.
CHILD LOCK Button
POWER ON/OFF Button
Press the Power ON/OFF Button to turn the unit off or on.
Press and hold 3 seconds or longer
NOTE
While CHILD LOCK is enabled,
all functions of the control are
locked.
To enable To disable
Beep Beep Beep
When you want to prevent children or pets from changing operation.
OFF TIMER Button
(Running)
When you want to set the auto shutdown time.
Each press will change the setting in
the following sequence. Beep BeepBeep Beep Beep Beep
2h 4h 8h
DISABLE
Beep Beep
ENABLE DISABLE

E-13
ADJUSTMENT OF SENSOR DETECTION
SENSITIVITY
Set to ‘low” if the DUST MONITOR is constantly red to reduce sensitivity,
and set to ‘high’ if the DUST MONITOR is constantly green to increase sensitivity.
1
With the unit OFF, press the Fan Speed Button for 3 seconds.
The Fan Speed Indicator Lights will display the currently set sensor sensitivity level.
The factory setting is Standard, indicated by the MED light.
2
Press the Fan Speed Button to
set the desired sensor sensitivity.
Refer to the diagram on the right to select
the desired sensor sensitivity level.
3
Press the Power OFF Button.
Note that if the Power OFF Button is not pushed within 8 seconds of adjusting sensor
sensitivity, the setting will be saved automatically. The sensor sensitivity setting will be
saved even if the unit is subsequently unplugged.
Sensor Detection
sensitivity
Fan Speed
Indicator Light
High
Standard
Low
ENGLISH

E-14
CARE AND MAINTENANCE
Before maintenance, be sure to shut down the unit and remove its power plug.
[Otherwise, electric shock or injury may be caused.]
The indicator light
will be lit in one
month if the unit
works 24 hours a
day.
Back Panel (Pre-Filter)
Service the
filter while it is
mounted.
Back Panel (Pre-Filter)
The indicator light is lit when it is time to
maintain the back panel (pre-filter).
Be careful not to apply too much
force to the filter.
Soak the back panel
in water with a small
amount of dish soap.
Rinse the back panel
repeatedly with clean water to
remove the solution residue.
Drip Dry the panel to remove
excess water.
Beep
After maintenance, press and hold the OFF TIMER
Button for 3 seconds or longer to reset the operation
time even if the indicator light is not lit.
ROUTINE MAINTENANCE
As-Needed MAINTENANCE
Use a vacuum cleaner to
remove the dust.
NOTE
BACK PANEL (PRE-FILTER)
1
Service the back panel (pre-filter).
2
After maintenance, insert the power plug.
When the unit starts to run, press and hold
the OFF TIMER Button for 3 seconds or
longer until the indicator light is off.
Once a month

E-15
To keep the unit clean and maintain its long life, we recommend regular care and maintenance.
Never wash the main unit
with water.
Do not use the following articles:
(Otherwise, surface may scratch or internal liquid
leakage may cause malfunction.)
Unplug
If there are stubborn
stains, wipe them off
with a cloth moistened
with water or warm
water (below100℉).
When odor emanates from the air outlet or it is difficult to remove odors,
Clean the integrated HEPA and deodorization filter.
Never wash the filter with water. (Otherwise, the performance
of the filter may be degraded.)
Gently Vacuum the dust.
Clean carefully
Remove the dust from the filter.
Do not apply excessive force because the filter
may be damaged easily.
Put a piece of paper under the filter to keep dirt off
the surrounding area.
Remove the power plug, and then wipe the main unit
with a soft cloth.
Volatile oil
Thinner
MAIN UNIT
Surface cleaning
ENGLISH
Do not use volatile fluids detergents or abrasives.
Bleach
Lapping powder
Abluent
Synthetic detergent
Spraying detergent
Steel wool
INTERGRATED HEPA AND
DEODORIZATION FILTER

E-16
Replacement and Maintenance Cycle
Disposal of Filter
Replacing the Filter
FILTER REPLACEMENT GUIDELINES
Before maintenance, be sure to shut down the unit and remove its power plug.
[Otherwise, electric shock or injury may occur.]
FZ-F50HFU
FZ-F50HFU
HEPA FILTER
Put a piece of paper under the filter during replacement to avoid staining the
surrounding area.
In harsh environments,filter replacement should be more frequent.
NOTE
Model
The filter cannot be washed with water.
Max Service
Life
Filter Name Maintenance
Cycle Replacement
Filter Model
HEPA Filter When odor emanates
from the air outlet 2 years
HEPA filter materials:
• Filter: Polypropylene •Frame: Polyester
1. Replace filter according tothe instructions provided with the replacement filter.
2. Use the date labels as a reminder for when the filter should be replaced.
Please dispose of used filter according to any local laws and regulations.
CARE AND MAINTENANCE
Intergrated HEPA and Deodorization Filter
According to Japan Electric Manufacture's Association JEM 1467, the Max service life is based on
the equivalent condition of the smoke from 5 cigarettes per day whereby the dust collection/deodorization
power is reduced by half compared with that of new filter. It is recommended to replace the filter more
frequently under more severe conditions.

E-17
TROUBLESHOOTING
Before calling for service, please review the Troubleshooting chart below, since the problem may not
be a unit malfunction.
noituloSmelborP
Is the filter still wrapped in the plastic bag?
Take out the filter from the plastic bag.
Is the air flow diminished?
Clean the areas with in the following table:
Is the unit used in a room with strong smells?
If the unit is used in the presence of strong smells such as
cigarette smoke, the filter may smell.
It is recommended to frequently ventilate the room where
the air purifier is used.
Clean the areas with in the following table, if odor
persists, replace the filter.
Clean the areas with in the following table:
After maintenance, press and hold the FILTER RESET
(OFF TIMER) button for 3 seconds or longer.
Clicking or ticking sounds may be audible when the unit
is generating ions.
Odor emanates from
the air outlet.
The FILTER RESET
indicator light is lit.
The FILTER RESET
indicator light does
not turn off.
Clicking or ticking
sounds are heard.
The odor or smoke in
room is not being
reduced.
-
-
-
Reference
Page
ODOR
Back PanelMain Unit
Cleaning Areas
HEPA Filter
Back PanelMain Unit
Cleaning Areas
HEPA Filter
Back PanelMain Unit
Cleaning Areas
HEPA Filter
INDICATOR LIGHT SOUND
E - 10
E - 14~15
E - 14~15
E - 14
E - 14
ENGLISH

E-18
Double check before you call for service.
noituloSmelborP
When starting operation, the sensor may not react instantly
to dust and odors.
After the unit has been running for several minutes, the
sensor sensitivity will become stable.
To test the sensors, shake a dusty cloth near the sensor
opening to see if the light changes color.
If you switch the unit on when the room has a strong smell,
the sensitivity of the odor sensor may be temporarily
deteriorated.
Set Fan Speed to MED and run the unit for several hours.
The Indicator Light
does not change.
-
-
The doors or windows may be open. A sealed environment
is needed to maximize air cleaning performance.
The Indicator Light
never turns green.
Frequent door opening and closing or airflow and
temperature changes may cause reactions.
The Indicator Light
switches its state
frequently.

-
-
Reference
Page
ODOR SENSOR
E - 13
TROUBLESHOOTING
