Sharp KC-F30E User manual

Free standing type
Jenis berdiri sendiri
νӐК
AIR PURIFIER
with Humidifying Function
OPERATION MANUAL
PEMBERSIH UDARA
dengan Fungsi Melembap
BUKU PANDUAN OPERASI
Ȁ˭ǯس،
ůĸdžΒ
R
KC-F30E
KC-F30L
Plasmacluster is a registered trademark of Sharp
Corporation in Japan, Philippines and elsewhere.
Device of a cluster of grapes is a trademark of
Sharp Corporation.
*The number in this technology mark indicates
the approximate number of ions supplied into 1
cm3of air, which is measured around the center
of a room (with the “High-Density Plasmacluster
7000” applicable floor area), at a height of 1.2m
above the floor, at the MAX wind volume setting
in air purifying mode, and when a humidifier
& air purifier or an air purifier using the high-
density plasmacluster ion evolving device is
placed close to a wall. This product is equipped
with a device of corresponding capacity.
HAZE
ENGLISHB. MELAYU
ġNJ
OM_KC-F30E/L.indb 1OM_KC-F30E/L.indb 1 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

Before operating your new air purifier, please read the following
The air purifier draws in room air through the air intake, circulates it through a Pre-Filter,
a Deodorizing Filter and a HEPA Filter inside the unit, and then discharges it through the
air outlet. The HEPA Filter can remove 99.97% of dust particles as small as 0.3 microns
that pass through the filter and also helps absorb odors.
The Deodorizing Filter gradually absorbs odors as they pass through the filter.
Some odors absorbed by the filters will break down over time, causing additional odors.
Depending on usage conditions, and especially if the product is used in environments
significantly more severe than a normal household, these odors may become noticeable
sooner than expected. If these odors persist, replace the filters. (Ref. E-14)
NOTE
• The air purifier is designed to remove air-suspended dust and the odors.
The air purifier is not designed to remove harmful gases such as carbon monoxide contained in
cigarette smoke.
The air purifier may not completely remove an odor if the source of the odor is still present.
HEPA Filter
Pre-Filter
Deodorizing Filter
OM_KC-F30E/L.indb 2OM_KC-F30E/L.indb 2 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

ENGLISH
E-1
ENGLISH
Thank you for purchasing this SHARPAir
Purifier. Please read this manual carefully
before using the air purifier. After reading,
keep the manual in a convenient location for
future reference.
IMPORTANT SAFETY INSTRUCTIONS
.....E-2
PART NAMES...............................................E-4
PREPARATION............................................E-6
OPERATION.................................................E-8
USEFUL FUNCTION...................................E-9
CARE AND MAINTENANCE ...................E-11
TROUBLESHOOTING..............................E-16
SPECIFICATIONS......................................E-17
CONTENTS
FEATURES
A Unique Combination of Air Treatment
Technologies
Triple Filtration System + Plasmacluster +
Humidification
TRAPS DUST*
Pre-Filter traps dust and other large
airborne particles.
DECREASES ODORS
Deodorizing filter absorbs many common
household odors.
REDUCES POLLEN & MOLD*
HEPA filter traps 99.97% of particles as
small as 0.3 microns.
FRESHENS
By emitting a balance of positive and negative
ions, Plasmacluster air treatment is a natural
process.
HUMIDIFIES
Can operate up to 5 hours per filling.**
*When air is circulated through the filter system.
**Room size: up to 16 m2
Sensor technology continuously monitors air
quality and automatically adjusts operation
based on air purity and humidity level.
OM_KC-F30E/L.indb E-1OM_KC-F30E/L.indb E-1 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

E-2
IMPORTANT SAFETY INSTRUCTIONS
Always follow basic safety precautions when using electrical appliances, including the
following:
WARNING - Always observe the following to reduce the risk of electrical shock, fire, or injury:
•Read all instructions before using the unit.
•Use only a 220-240 volt outlet.
• Do not use the unit if the power cord or plug is damaged or if the connection to the wall
outlet is loosened.
• Periodically remove dust from the power plug.
• Do not insert fingers or foreign objects into the air intake or air outlet.
• When removing the power plug, always hold the plug and never pull the cord.
Failure to do so can cause a short circuit resulting in electrical shock or fire.
• Do not remove the plug when your hands are wet.
• Do not use this unit near gas appliances or fireplaces.
• Always unplug the unit when refilling the Humidifying Tray, cleaning the unit, or when the unit is not
in use. Failure to do so can cause a short circuit resulting in electrical shock or fire.
• In order to avoid safety hazards, if the power cord is damaged, it must be replaced by either
the manufacturer, a service agent, a Sharp authorized Service Center or a similarly qualified
service provider.
• Only a Sharp Authorized Service Center should service this air purifier. Contact the nearest Service
Center for any problems, adjustments, or repairs.
• Do not operate the unit in rooms where aerosol insecticides are present. Do not operate the unit in
rooms where there is oily residue, incense, sparks from lit cigarettes, or chemical fumes in the air.
Do not operate the unit in places where it may get wet, such as a bathroom.
• Be cautious when cleaning the unit. Strong corrosive cleansers can damage the exterior.
• When carrying / moving the unit, first remove the Humidifying Tray, and then hold the unit by the
handles on both sides.
• Carrying / moving the unit when there is water in the Humidifying Tray can cause the following:
• Electrical shock.
•Damage to the unit caused by internal spillage.
• Water spillage.
•
Do not drink the water in the Humidifying Tray.
•
Replace the water in the Humidifying Tray daily with fresh tap water, and regularly clean it
(Ref. E-12 and E-13). When the unit is not in use, dispose of the water in the Humidifying Tray.
Leaving water in the Humidifying Tray can cause mold, bacteria, and bad odors.
In rare cases, such bacteria can be a health hazard.
•This appliance is not intended for use by persons (including children) with reduced physical,
sensory, or mental capabilities, nor by persons with insufficient experience and knowledge of how
to operate the unit, unless they are given proper supervision and instruction on how to use the unit
by a person responsible for their safety. Do not allow children to play with the unit.
NOTE - What to do if the unit interferes with radio or TV reception
If the air purifier interferes with radio or television reception, try one or more of the following
measures:
• Adjust or reposition the receiving antenna.
• Increase the distance between the unit and the radio or TV.
• Connect the equipment into an outlet on a circuit different from that of the radio or TV receiver.
• Consult the dealer or an experienced radio/TV technician for help.
OM_KC-F30E/L.indb E-2OM_KC-F30E/L.indb E-2 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

ENGLISH
E-3
CAUTIONS CONCERNING OPERATION
• Do not operate the unit without the filters and the Humidifying Tray properly installed.
• Keep the unit away from water.
• Do not wash and reuse the HEPA filter and Deodorizing filter.
Doing so will not improve filter performance and can also cause electric shock or operating
malfunctions.
• Clean the exterior with a soft cloth only.
Do not use volatile liquids or detergents. Doing so can damage or crack the exterior of the unit.
In addition, doing so can cause sensor malfunctions.
• The frequency of descaling maintenance will depend on the hardness of and the impurities in the
water that you use; the harder the water the more often descaling will be necessary.
• Before moving the unit, make sure it is not operating, and remove the Humidifying Tray while holding
the side handle of the unit.
• When removing / reattaching the Humidifying Tray, be careful not to get your fingers caught inside the
unit.
• When moving the unit, use the handles on both sides.
Do not move the unit when it is in operation.
• Do not block the air intake or air outlet.
• Do not place the unit near or on hot objects, such as stoves or heaters, or where it may come into
contact with steam.
• Always operate the unit in an upright position.
INSTALLATION GUIDELINES
• When using the unit, place it at least 2 meters away from equipment that emits electric waves, such
as televisions or radios, to avoid electrical interference.
• Avoid locations where the sensors are exposed to direct wind.
Failure to do so can cause the unit to malfunction.
• Avoid locations where furniture, fabrics, or other objects can come in contact with the unit and
interfere with the intake and outtake of air.
• Avoid locations where the unit is exposed to condensation or drastic changes in temperature.
Appropriate room temperature is between 0 – 35 ºC.
• Place the unit on a level and stable surface with sufficient air circulation.
When placed on heavy carpet, the unit may vibrate slightly.
Place the unit on a level surface to avoid water leakage from the Humidifying Tray.
• Avoid locations that generate grease or oily smoke.
Failure to do so can cause the unit exterior to crack and the sensors to malfunction.
• The dust collecting ability of the unit is effective even when the unit is as close to 3 cm from the wall,
the surrounding walls and floor may get dirty. Please place the unit at a distance from the wall.
The wall directly behind the air outlet may become dirty over time. When using the unit for an
extended period of time at the same location, periodically clean the walls adjacent to it.
FILTER GUIDELINES
• Follow the instructions in this manual for proper filter care and maintenance.
OM_KC-F30E/L.indb E-3OM_KC-F30E/L.indb E-3 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

E-4
PART NAMES
1Operation Panel / Display (Ref.E-5) 9 Humidifying Tray
2Handle (2 Locations) 10 Float
3Main Unit 11 HEPA Filter
4Air Outlet 12 Deodorizing Fiter
5Filter Frame 13 Sensor (internal)
6Humidifying Filter 14 Back Panel (Pre-Filter)
7Float (in Filter Frame) 15 Air lnlet
8Tray Handle 16 Power Cord / Plug
FRONT
BACK
FRONT / BACK
3
2
1
HAZE
(Plug shape varies by country.)
4
13
5
16
15
11
14
9
7
8
12
6
10
OM_KC-F30E/L.indb E-4OM_KC-F30E/L.indb E-4 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

ENGLISH
E-5
OPERATION PANEL / DISPLAY
Display
1POWER ON/OFF Button 5OFF Timer Button
2HAZE Mode Button / Indicator Light (green) 6Display Select Button
(Press 3 sec.) LIGHT ON/OFF Button (Press 3 sec.) FILTER RESET Button
3MODE Button 7Filter Indicator Light (Orange)
(Press 3 sec.) Plasmacluster Ion ON/OFF Button 8Plasmacluster Ion Indicator Light (blue)
4Fan Speed Indicator Lights (green) 9OFF Timer Indicator Light (green)
6
7
98
54321
Humidify Light
Green.................Humidify ON
Green.................Unit needs water
(Flashing)
Off......................Humidify OFF
Dust Sign
Indicates the air purify level 3 colors.
Green
Orange
Red
Clean
Impure
Humidity / Temperature monitor
Indicates the approximate humidity /
temperature level in the room.
temperature 0 to 50ºC is displayed at 1ºC-intervals
humidity 6 to 99% is displayed at 1%-intervals
-1ºC or less 51ºC or more
OM_KC-F30E/L.indb E-5OM_KC-F30E/L.indb E-5 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

E-6
PREPARATION Always be sure to remove the
power plug from the wall outlet.
FILTER INSTALLATION
4
1
Remove the Back Panel.
2
Remove the Filters from
the plastic bag.
3
Install the Filters in the
correct order as shown.
Install the Back Panel.
Deodorizing filter
(The same on both sides.)
Deodorizing filterHEPA filter
HEPA filter
Click
Place the surface
with tag.
Back Panel
Tag
OM_KC-F30E/L.indb E-6OM_KC-F30E/L.indb E-6 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

ENGLISH
E-7
3
CAUTION
REFILLING THE HUMIDIFYINGTRAY
1
Pull out the Humidifying Tray .
Humidify air passed through by vaporizing water pumped up from Humidifying Tray.
The unit can be used even without water in the Humidifying Tray.
• Do not expose the unit to water. Doing so can cause a short circuit or electrical shock.
• Use only fresh tap water. Using other water sources risks the growth of molds, fungi,
or bacteria.
• Do not use hot water (40 ºC), chemical agents, aromatic substances. Doing so can
deform the unit or cause it to malfunction.
• When removing and installing the Humidifiying Tray, be careful not to spill any water.
• Return the Tray Handle to its original position
before installing.
CAUTION
2
Fill the Humidifying Tray with
tap waterby method or .
CAUTION
CAUTION
・The Filter Frame is floated up when water
is filled.
• When carrying the Humidifying Tray, hold
it with both hands or grip the Tray Handle.
• Gently fill it with water to avoid splash
water.
• Do not fill beyond the “FULL” indicator.
The Humidifying Tray does not get into
the unit if water is filled too much.
A B
A
B
OR
Clean the Humidifying Tray if it becomes
dirty or there is a noticeable odor.
(Ref. E-12,E-13)
Install the Humidifying Tray .
FULL
FULL
Tray Handle
Locate the Handle
in front of Separator. Do not locate the Handle on or behind Separator.
Handle
Separator
HAZE
HAZE
HAZE
OM_KC-F30E/L.indb E-7OM_KC-F30E/L.indb E-7 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

E-8
OPERATION
Power ON / OFF
START
START
STOP • Select the desired fan speed by .
• Unless the power cord has been
unplugged, the operation starts in the
previous mode it was operated in.
HAZE
It operates at Max High fan speed for 10 minutes, followed by 50 minutes operation at High fan speed
and then alternates between Low and High level for 20 minutes each.
10 minutes: Max High fan level
50 minutes: High fan level
20 minutes: Low fan level
20 minutes: High fan level
NOTE
NOTE
SLEEP
AUTO
• It is possible to switch this mode to another while operating.
FAN SPEED
Select the desired fan speed.
• Front surface Indicators go off automatically.
• The fan speed is automatically switched between HIGH and
LOW depending on the humidity and the amount of impurities
in the room.
OM_KC-F30E/L.indb E-8OM_KC-F30E/L.indb E-8 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

ENGLISH
E-9
NOTE
NOTE
LIGHT CONTROL
You can set the front surface Indicators to OFF when the Indicator is too bright.
Press
more than 3
seconds.
Press
more than 3
seconds.
Press
more than 3
seconds.
Press
more than 3
seconds.
Plasmacluster Ion ON/OFF
When Plasmacluster Ion is ON, the Plasmacluster Ion Indicator Light is on. (blue)
You can select either humidity or temperature at the time to be displayed.
ON OFF
OFF
OFF
ON
ON
Changing display (humidity / temperature)
Current temperature and current humidity indicate the estimated values.
The values may be different from values indicated by other temperature gauge hygrometer.
• There is no function for adjusting the temperature.
• Humidity setting cannot be adjusted.
• Cannot dehumidify .
Current humidity
(estimated)
Current temperature
(estimated)
USEFUL FUNCTION
OM_KC-F30E/L.indb E-9OM_KC-F30E/L.indb E-9 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

E-10
USEFUL FUNCTION
Off TIMER
Select the length of time you want. The unit automatically stops once the selected time is reached.
NOTE
• Pressing displays the remaining time.
• To reset the operating time, press while the remaining time is being displayed.
Auto RESTART
If the unit is unplugged or if there is a power failure, the unit will resume operation with the previous
settings after power is restored. The default setting is ON.
OFFON
(with the unit OFF) (with the unit OFF)
Press both buttons at the
same time for 3 seconds or
more.
Press both buttons at the
same time for 3 seconds or
more.
If the , and
indicators light up for 10 seconds,
the setting is completed.
Lighting
1 hour 2 hours 4 hours 8 hours CANCELLATION
OM_KC-F30E/L.indb E-10OM_KC-F30E/L.indb E-10 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

ENGLISH
E-11
CARE AND MAINTENANCE
NOTE How to clean when overly dirty
1. Add a small amount of kitchen detergent to
water and soak for about 10 minutes.
 DO NOT apply excessive pressure when
scrubbing the back panel.
2.Rinse off the kitchen detergent with clean water.
3.Completely dry the filter in a well-ventilated area.
Gently remove dust with an appropriate cleaning tool,
such as a vacuum cleaner with the proper attachment.
1. Remove the Back Panel and removing
the Sensor Filter.
2. Gently remove dust from the Sensor with
an appropriate cleaning tool, such as a
vacuum cleaner with the proper attachment.
3. If the Sensor Filter is overly dirty, wash it
with water and dry it thoroughly.
BACK PANEL
SENSOR
CAUTION
The filter Indicator Light will turn
onafter approximately 720 hours.
(30 days × 24 hours =720 hours)
FILTER INDICATOR
After performing
maintenance, reset
the Filter Indicator.
Press more than 3 seconds.
This is a reminder to perform the
maintenance described below.
(Ref.E-11,E-12,E-13,E-14)
CARE INDEX
Filter Frame
Humidifying Tray
Humidifying Filter
Back Panel
Sensor
Unit
HEPA Filter
(Ref.E-12,E-13)
(Ref.E-14)
(Ref.E-14)
Deodorizing Filter
(Ref.E-14)
SENSOR
BACK PANEL
In case of using at the location where air pollution and odor are significant,
maintain frequently even if Filter Indicator Light is not ON.
Back Panel
Sensor (internal)
Sensor Filter
OM_KC-F30E/L.indb E-11OM_KC-F30E/L.indb E-11 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

E-12
CARE AND MAINTENANCE
HUMIDIFYING FILTER / TRAY
Remove the Filter Frame.
1
2
Remove the Humidifying Filter from the Tray.
Turn the handle down on
the reverse side. Remove the Humidifying Filter.
Pull up
Turn down
Open
Remove
•
CAUTION Drops of water may drip from the Humidifying Filter and the Filter Frame.
CAUTION
Rinse the Humidifying Tray,the Filter Frame and the Humidifying Filter.
Float (Styrofoam)
Float
Humidifying Tray Humidifying Filter
Filter Frame
Cross-Section
view
Float
Tab
2.
Insert the tab of the
float into the hole.
3.
Insert the tab on the
other side of the float
into the hole.
Insert the float
under this tab.
1.
• Do not remove the Floats.
• If the Float comes off from the Humidifying Tray, install it in the order shown below.
Odor occurrence may be suppressed when washing Humidifying Filter and Humidifying Tray with water
carefully even if the Filter Indicator Light is not ON.
OM_KC-F30E/L.indb E-12OM_KC-F30E/L.indb E-12 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

ENGLISH
E-13
Always be sure to remove the power plug
from the wall outlet.
2
3
4
NOTE How to clean the Humidifying Tray and the Filter Frame
when overly dirty
1. • Remove the Filter Frame from the Humidifying Tray and fill it with
water until the “FULL” indicator.
• Put the Filter Frame in water.
2. Add a small amount of kitchen detergent to the water.
3. Soak for 30 minutes.
4. Rinse off the kitchen detergent with clean water.
• Clean any hard-to-reach parts which with a cotton swab or toothbrush.
NOTE
1.
Soak in water with a descaling solution
for about more 30 minutes.
Recommended descaling solutions
• Citric acid (available at some drugstores)
• 100% bottled lemon juice with no pulp.
<with citric acid>
<with lemon juice>
3 cups
of water 1
/
4cup
stir well!
2.
Rinse off the descaling solution
with plenty of water.
stir well!
2 1
/
2cups
of water 3 tea- spoons
• When using lemon juice as your
descalingsolution, allow for more soak
time.
CAUTION
Hook latches
of cover
(3 positions).
Also in the same left side.
Align the directions.
Install
Close
Install the Humidifying Filter
by fitting the grooves at left
and right side to the guides
on the Humidifying Tray.
After maintenance, correctly reattach the parts.
Return the Tray Handle
to its original position. Lift the Tray Handle.
Return it to its
original position.
How to remove the water scale
Guide
Right side
Groove
OM_KC-F30E/L.indb E-13OM_KC-F30E/L.indb E-13 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

E-14
CARE AND MAINTENANCECARE AND MAINTENANCE
UNIT Wipe with a dry, soft cloth.
•
•
CAUTION
Do not use volatile fluids.
Benzene paint thinner or polishing powder can damage the surface.
Do not use detergents.
Detergent ingredients can damage the unit.
• Maintain only the tagged
surface. Do not clean up
the opposite surface.
• Both surfaces can be
maintained.
CLEANING FILTERS
Gently remove dust with an appropriate cleaning tool, such as a vacuum cleaner
with the proper attachment.
In case of using at the location where air pollution and odor are significant,
maintain frequently even if Filter Indicator Light is not ON.
•CAUTION Do not wash the filters. Do not expose to sunlight.
DEODORIZING FILTER HEPA FILTER
Some odors absorbed by the filters will break down over time, causing additional odors. Depending on usage
conditions, and especially if the product is used in environments significantly more severe than a normal
household, these odors may become noticeable sooner than expected.
Replace the filter in those cases or if dust is unable to be removed after maintenance.
Tag
HAZE
OM_KC-F30E/L.indb E-14OM_KC-F30E/L.indb E-14 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

ENGLISH
E-15
•HEPA Filter About 2 years after first use
•Deodorizing Filter About 2 years after first use
•Humidifying Filter About 5 years after first use
Replacement Filter Model
Consult your dealer when purchasing a replacement filter.
AIR PURIFIER MODEL
REPLACEMENT FILTER MODEL
HEPA Filter :
1 unit Deodorizing Filter : 1 unit Humidifying Filter : 1 unit
KC-F30E
KC-F30L
LIFE OF FILTERS
FILTER REPLACEMENT
NOTE
HEPA Filter
Deodorizing Filter
Use the date label to remind you when to replace the filter.
There is the date label on the left side of the unit.
Disposing of filters
Filter life varies depending on the room environment, usage conditions, and location of the unit.
Lifespan of HEPA filter and Deodorizing filter and replacement suggestions are based on purifying
a room in which 5 cigarettes are smoked per day and the unit's dust collection and deodorizing
performance has declined to half the level of a new filter.
Dispose of used filters according to local laws and regulations.
HEPA Filter material :
• Filter : Polypropylene
• Frame : Polyester
Deodorizing Filter material :
• Filter : Activated charcoal,Polyrthylene terephthalate,
Polypropylene
• Frame : Paper
Humidifying Filter material :
• Filter : Rayon, Polyester
FZ-F30MFE
FZ-F30HFE FZ-F30DFE
We recommend replacing the filter more frequently if the unit is used in conditions significantly more
severe (HAZE etc.,) than a normal household.
Humidifying Filter
Do not throw away
the Filter Frame (gray)
Always be sure to remove the power plug
from the wall outlet.
OM_KC-F30E/L.indb E-15OM_KC-F30E/L.indb E-15 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

E-16
TROUBLESHOOTING
ERROR DISPLAY If the error continues to occur, contact a Sharp Service Center.
DIGITAL
INDICATION ERROR DETAILS REMEDY
Fan motor error.
Temperature-humidity sensor error.
Unplug the unit, wait one minute, then plug he unit in
again.
SYMPTOM REMEDY (the following are not due to a malfunction)
Odor and smoke persists.
• The air may have been dirty when the unit was plugged in.
Unplug the unit, wait one minute, and then plug the unit in again.
The Filter Indicator Light is on.
• Check the filters. If they appear to be extremely dirty, clean or
replace them. (Ref. E-11,E-12,E-13,E-14,E-15)
• Dirty or clogged dust sensor openings interfere with sensor
operation. Gently clean the back panel. (Ref. E-11).
• The unit may make clicking or ticking sounds when it is
generating ions.
• Check to see if the filters are extremely dirty.
• Clean or replace the filters.
• Plasmacluster Air Purifiers emit small traces of ozone that can
produce an odor.
• Check to see if the unit is installed in a location that makes it
difficult for the sensors to detect cigarette smoke.
• Check to see if the dust sensor openings are blocked or clogged.
If they are blocked or clogged, clean the back panel. (Ref. E-11)
• Whenever replacing the filters, connect the power cord to an
outlet and then press the Filter Reset Button.
• Check to see if the Lights OFF Mode is selected. If it is selected,
press the Light ON/OFF Button to turn the indicator lights on.
(Ref. E-9)
・Check to see if the SLEEP mode is selected. (Ref. E-8)
• Clean the Humidifying Tray. Make sure that the unit is on a level
surface.
• Check to see if the Humidifying Tray is correctly installed. Check
the Humidifying Filter.
• If the Humidifying Filter is extremely dirty, clean or replace it.
(Ref. E-12, E-13, E-15).
• Humidification amount gets lower when humidity reaches to the
proper amount (55 ~ 65%) by the actuation of humidity sensor in
the case of fan speed automatic.
• There is a difference in the humidity level within the same room.
• The sensor have different measurement parameters.
• If the monitor indicates TEMPERATURE, press the Display Select
Button. (Ref. E-9)
• The Dust Sign lights automatically change color when the dust
sensor detect impurities.
The Dust Sign light is green even
when the air is not clean.
The Dust Sign light is orange or red
even when the air is clean.
The unit makes a clicking or ticking
sound.
Air discharged from the unit has an
odor.
The unit does not operate when
cigarette smoke is in the air.
The Dust Sign lights are turned off.
The Humidify Light does not light off
when the Humidifying Tray is empty.
The water level in the Humidifying
Tray does not decrease or decreases
slowly.
The Dust Sign lights change color
frequently.
There is a discrepancy between the
unit’s Humidity Monitor and another
hygrometer in the room.
Before calling for service, review the troubleshooting chart below to make sure
that the problem is not a unit malfunction.
OM_KC-F30E/L.indb E-16OM_KC-F30E/L.indb E-16 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

ENGLISH
E-17
SPECIFICATIONS
Power supply 220-240V 50-60Hz
Fan Speed Adjustment MAX MED SLEEP
CLEAN AIR Fan Speed (m3/hour) 180 125 52
Rated Power (W) 27 12 4.1
Noise Level (dBA) 48 38 21
CLEAN AIR
&HUMIDIFY
Fan Speed (m3/hour) 180 125 52
Rated Power (W) 27 12 4.1
Noise Level (dBA) 48 38 21
Humidification (mL/hour)*1 350 280 140
Recommended Room Size (m2)*2 ~21
High density Plasmacluster ion recommended room size (m
2
)*3
~17
Humidifying Tray Capacity (L) 1.8
Sensors Dust / Temperature & Humidity
Filter type Dust collection HEPA *4
Deodorization Deodorizing
Cord Length (m) 2.0
Dimensions (mm) 380 (W) × 197 (D) × 570 (H)
Weight (kg) 7.2
*1 • The amount of humidification changes in accordance with indoor and outdoor temperature and
humidity.
The amount of humidification increases as temperatures rises or humidity decreases.
The amount of humidification decreases as temperatures decrease or humidity rises.
• Measurement Conditions : 20 ºC, 30 % humidity (JEM1426)
*2 • The recommended room size is appropriate for operating the unit of maximum fan speed.
• The recommended room size is an area in which a given amount of dust particles can be removed
in 30 minutes.
*3 • Room size in which approximately 7000 ions per cubic centimeter can be measured in the center of
the room when the unit is placed next to a wall, is running at maximum settings, and is at a height
of approximately 1.2 meters from the floor.
*4 • The filter removes more than 99.97% of particles at least 0.3-microns in size. (JEM1467)
Standby Power
When the unit’s power plug is inserted in a wall outlet it consumes about 0.9 watts of standby power in order to
operate electrical circuits.
To conserve energy, unplug the power cord when the unit is not in use.
OM_KC-F30E/L.indb E-17OM_KC-F30E/L.indb E-17 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM

Sebelum mengendalikan pembersih udara baru anda,
sila baca maklumat berikut
Pembersih udara menyedut udara dalam bilik melalui pengambilan udara, mengedarkan
melalui Prapenapis, Penapis Penyahbau dan Penapis HEPA di dalam unit, dan
kemudian melepaskannya melalui saluran udara. Penapis HEPA boleh menyingkirkan
99.97% habuk sekecil 0.3 mikron yang dapat melepasi penapis.
Penapis Penyahbau menyerap bau sedikit demi sedikit semasa udara mengalir melalui
penapis.
Sesetengah bau yang diserap oleh penapis boleh terurai lama-kelamaan, menyebabkan
bau semakin kuat. Bergantung pada keadaan penggunaan, dan terutamanya jika
produk digunakan dalam persekitaran yang jauh lebih teruk daripada rumah biasa, bau
ini boleh dihidu lebih cepat daripada yang dijangkakan. Jika bau masih berterusan,
gantikan penapis. (Ruj.M-14)
NOTA
• Pembersih udara direka untuk menyingkirkan habuk yang terampai dalam udara dan bau.
Pembersih udara ini bukan direka untuk menapis gas berbahaya seperti karbon monoksida yang
terkandung dalam asap rokok.
Pembersih udara mungkin tidak menyingkirkan sepenuhnya bau jika punca bau masih ada.
Penapis HEPA
Prapenapis
Penapis Penyahbau
OM_KC-F30E/L.indb 19OM_KC-F30E/L.indb 19 4/20/2559 BE 6:03 PM4/20/2559 BE 6:03 PM
