Sharp Plasmacluster FU-A80E User manual

ENGLISH
Device of this mark is a trademark of Sharp Corporation.
“Plasmacluster” and “Device of a cluster of grapes” are
registered trademarks of Sharp Corporation in Japan,
USA and elsewhere.
AIR PURIFIER
OPERATION MANUAL
FU-A80E
Free standing type
䠧ㄡځࢊඅ
㽡昤⟆ſ
BUKU PANDUAN OPERASI
PEMBERSIH UDARA
䣥䣊᳊
Jenis berdiri sendiri
Ĺ⛢
MELAYU ENGLISH
OP_FU-A80E-EN+CL+ML.indb 1OP_FU-A80E-EN+CL+ML.indb 1 8/4/11 5:06:28 PM8/4/11 5:06:28 PM

Please read before operating your new Air Purifier
Some odour ingredients absorbed by the filters may become separated and may be
discharged through the air outlet and result in additional odour. Depending on the
usage environment, especially when the product is used in a condition significantly
more severe than household use, this odour may become strong in a shorter period
than expected.
The air purifier is designed to remove air-suspended dust and odour, but not harm-
ful gases (for example, carbon monoxide contained in cigarette smoke). If the odour
sources still exist, it cannot completely remove the odour (for example, odours from
construction materials and pet odours).
It is suggested to open the window a bit when you are smoking in order to facilitate
ventilation.
In this case we recommend purchasing the optional replacement.
HEPA filter (white)
Deodorizing Pre filter (black)
Dust
pollen, dust, particles of cigarette
smoke, pet dander
Odour
cigarette smoke odour,household odour
OP_FU-A80E-EN+CL+ML.indb 2OP_FU-A80E-EN+CL+ML.indb 2 8/4/11 5:06:31 PM8/4/11 5:06:31 PM

E-1
ENGLISH
ENGLISH
FEATURES
Exclusive Combination of Air Treatment
Technologies
Filtration System + Plasmacluster Ion
DECREASES ODOURS
Deodorizing Pre filter absorbs many com-
mon household odours.
REDUCES DUST, POLLEN, DANDER &
MOULD*
HEPA filter traps 99.97% of particles as
small as 0.3 microns.*
REFRESHES
Plasmacluster refreshes the air similar to
the way nature cleans the environment by
emitting a balance of positive and negative
ions.
*From that air is drawn through the filter
system.
Room size : 62m2
Thank you for purchasing the SHARP Air Pu-
rifier. Please read this manual carefully. Be-
fore using this product, be sure to read the
section: “Important Safety Instructions.”
After reading this manual, keep it in a conven-
ient location for future reference.
For your reference, we recommend to keep
this manual in the place where you can read
at any time.
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
.....E-2
PART NAMES ...........................................E-4
FILTER INSTALLATION ...........................E-6
OPERATION .............................................E-7
MAINTENANCE........................................E-8
TROUBLESHOOTING............................E-10
SPECIFICATIONS................................... E-11
OP_FU-A80E-EN+CL+ML.indb 1OP_FU-A80E-EN+CL+ML.indb 1 8/4/11 5:06:32 PM8/4/11 5:06:32 PM

E-2
Read all instructions before using the unit.
When using electrical appliances, basic safety precautions should be followed, including the
following:
WARNING - To reduce the risk of electrical shock, fire or injury to persons:
•Connect the power plug to a dedicated electrical outlet for 220-240V,50/60Hz.
• Do not use the unit if the power cord or plug is damaged or the connection to the wall outlet is
loosened.
•Periodically remove dust from the power plug.
•Do not use an extension cord.
•Do not insert fingers or any objects into the air inlet or air outlet.
•Do not unplug by pulling on cord. To unplug, grasp the plug.
• Do not handle plug or unit with wet hands.
•Unplug the electrical cord before performing any maintenance.
• If the power cord is damaged, it must be replaced by the manufacturer, its service agent, a Sharp
authorized Service Centre or similarly qualified person in order to avoid a hazard.
•Do not use near flammable gases and material such as insecticides, fragrances, and lit cigarettes.
•Do not use in humid place such as bathrooms.
• Contact the nearest Sharp Approved Service Centre for any problems, adjustments, or repairs.
•This appliance is not intended for use by persons (including children) with reduced physical, sen-
sory or mental capabilities, or lack of experience and knowledge, unless they have been given su-
pervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure they do not play with the appliance.
NOTE - Radio or TV Interference
If this air purifier should cause interference to radio or television reception, try to correct the interfer-
ence by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the unit and radio/TV receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected.
•Contact the dealer or an experienced radio/TV technician for help.
IMPORTANT SAFETY INSTRUCTIONS
OP_FU-A80E-EN+CL+ML.indb 2OP_FU-A80E-EN+CL+ML.indb 2 8/4/11 5:06:33 PM8/4/11 5:06:33 PM

E-3
ENGLISH
CAUTIONS CONCERNING OPERATION
•Do not block any opening.
•Do not use the unit near or on hot objects, such as stoves or heaters or radiators.
•Do not use the unit with the wrong position.
• Always hold the handle on both sides of the unit when moving it.
Holding the front panel when carrying may cause it to detach, thus dropping the unit and resulting
in bodily injury.
• Do not use without filters inside the unit.
• Do not wash and reuse the filter.
Not only does it not improve filter performance, but also may cause electrical shock or malfunc-
tion.
• Clean the exterior with a soft cloth only.
Do not use corrosive cleansers, volatile fluids and/or detergents when cleaning the unit.
The unit surface may be damaged or cracked.
In addition, the sensor may malfunction as a result.
INSTALLATION GUIDELINES
• Avoid locations where curtains, etc., come into contact with any opening.
It may become dirty or a malfunction may occur.
• Avoid locations where the unit is exposed to condensation, due to rapid temperature changes.
(If it is unavoidable please allow unit to stand for 1 hour before switching on.)
(Use under appropriate conditions between 0 - 35˚C room temperature.)
• Place on a stable surface with sufficient air circulation.
When placing the unit on a heavily carpeted area, it may cause the unit to vibrate slightly.
• Avoid use in locations where greasy or oily smoke is generated (such as in a kitchen, etc.).
The unit surface may crack or the sensor may malfunction as a result.
FILTER GUIDELINES
• Follow the instructions to handle carefully and keep maintenance.
Do not install any other type of filters.
OP_FU-A80E-EN+CL+ML.indb 3OP_FU-A80E-EN+CL+ML.indb 3 8/4/11 5:06:35 PM8/4/11 5:06:35 PM

E-4
PART NAMES
ILLUSTRATIVE DIAGRAM
INCLUDED
• Operation manual
BACK
1
3
4
2
7
5
6
8
9
10
1 Air Outlet
2 Air Inlet
3 Handle
4 Main Unit
5 HEPA Filter
6 Deodorizing Pre Filter
7 Dust Sensor
8 Date Label
9 Power Cord
10 Plug
OP_FU-A80E-EN+CL+ML.indb 4OP_FU-A80E-EN+CL+ML.indb 4 8/4/11 5:06:36 PM8/4/11 5:06:36 PM

E-5
ENGLISH
MAIN UNIT DISPLAY
11 12 14 15 16 17 18
11 SHOWER Button /
SHOWER Indicator Light (green)
12 Plasmacluster ON / OFF Button /
Plasmacluster ON / OFF Indicator Light (green)
13 CHILD LOCK Button / CHILD LOCK Indicator Light (green)
14 CLEAN SIGN
The colour changes according to the air condition.
15 Plasmacluster Sign (blue)
16 FAN SPEED Indicator Light (green)
17 FAN SPEED Button
18 POWER Button
Green Yellow Red
Clean VeryImpure
13
OP_FU-A80E-EN+CL+ML.indb 5OP_FU-A80E-EN+CL+ML.indb 5 8/4/11 5:06:38 PM8/4/11 5:06:38 PM

E-6
FILTER INSTALLATION
Unplug the electrical cord before
performing any maintenance.
To maintain the quality of the filters, they are packed in plastic bags and installed in the
main unit. Be sure to remove the filters from the plastic bags before using the unit.
1
Remove the front Panel.
Gently grip the bottom of the front panel
and remove it by pulling the bottom gently
towards you.
2
Remove the plastic bags.
3
Place the filters accordingly.
Keep the order of filters.
4
Fix the Front Panel.
Fix the Front Panel by hooking it into
the top of the unit. Swing panel in by
pushing gently until the panel snaps
into place.
5
Record the date when you
start or replace the filters.
HEPA filter (white)
Deodorizing Pre filter (black)
Starting date of use
Replacement Filters
Replace the filters when they are no
longer removing odour or dust.
OP_FU-A80E-EN+CL+ML.indb 6OP_FU-A80E-EN+CL+ML.indb 6 8/4/11 5:06:39 PM8/4/11 5:06:39 PM

E-7
ENGLISH
OPERATION
1
Press to start / stop.
Unless the power cord has been unplugged,
the operation starts in the previous mode it
was operated in.
2
Press to select fan speed.
3
Press to turn Plasmacluster
Ion Mode ON and OFF.
Press to start SHOWER Mode..
The unit will operate at HIGH fan speed for
one hour, then will return to the prior opera-
tion.
"SHOWER" mode is effective when you
would like to clean quickly.
The Dust Sensor automatically moni-
tors dust pollution level and adjusts
fan speed accordingly.
Yellow Red
Clean Very Impure
ON OFF
321
SHOWER Operation
Light Control
Press for 3 seconds to se-
lect ON/OFF of the Plusmaclus-
ter SIGN and the CLEAN SIGN.
AUTO mode
*The air purifier operates the airflow speed
automatically according to the interior
pollution level detected by the sensor.
CHILD LOCK
Press for 3 seconds to select
CHILD LOCK.
Operation of the unit display will be
locked. It is the same method as start-
ing operation.
To cancel the CHILD LOCK mode,
press again for 3 seconds.
CLEAN SIGN
Green
OP_FU-A80E-EN+CL+ML.indb 7OP_FU-A80E-EN+CL+ML.indb 7 8/4/11 5:06:43 PM8/4/11 5:06:43 PM

E-8
CLEANING THE FILTERS
1
Turn off the unit, and unplug the
power cord.
2
Remove the Front Panel.
(Refer to E-6)
3
Clean the filter and Dust sensor.
Gently remove dust from the filter, using a
vacuum cleaner with attachment or similar tool.
Dust Sensor
Remove the Sensor cover, and remove the
dust on the Sensor filter.
If it is very dirty, wash it with water and dry it
thoroughly.
CLEANING THE UNIT
Dust sensor
Deodorizing Pre filter
Sensor cover
Sensor filter
MAINTENANCE
Wipe with a dry, soft cloth.
For stubborn stains or dirt, use a soft cloth
dampened with warm water.
Do not use volatile fluids and deter-
gents.
Benzene, paint thinner, polishing powder,
detergent ingredients etc., may damage
the unit.
Care Cycle :
Whenever dust accumulates on the unit or every 1 month.
OP_FU-A80E-EN+CL+ML.indb 8OP_FU-A80E-EN+CL+ML.indb 8 8/4/11 5:06:45 PM8/4/11 5:06:45 PM

E-9
ENGLISH
FILTER REPLACEMENT GUIDELINES
Filter life varies depending on the room environment, usage, and location
of the unit.
If dust or odour persists, replace the filter.
(Refer to “Please read before operating your new Air Purifier”)
Replacement timing
Replacement Filters
Model : FZ-A80SFE
• HEPA filter : 1 unit
• Deodorizing Pre filter : 1 unit
Replace the filters
(Refer to E-6)
Disposal of Filters
Please dispose the filters according to the local disposal laws and regulations.
HEPA filter material:
• Filter : Polypropylene
• Frame : Polyester
HEPA filter
Deodorizing Pre filter
Record the date when you replace the filters.
Deodorizing Pre filter material:
• Deodorizer : Activated charcoal
• Filter : Polyurethane foam
• Frame : Paper
Starting date of use
Replacement Filters
Replace the filters when they are no
longer removing odour or dust.
• HEPA filter About 2 years after opening
• Deodorizing Pre filter About 2 years after opening
OP_FU-A80E-EN+CL+ML.indb 9OP_FU-A80E-EN+CL+ML.indb 9 8/4/11 5:06:46 PM8/4/11 5:06:46 PM

E-10
TROUBLESHOOTING
Before calling for service, please review the Troubleshooting chart below, since the problem may not
be a unit malfunctions.
PROBLEM SOLUTION (not a malfunction)
The unit leaves smoke and
odours in the air.
• Clean or replace the filters as needed. (Refer to E-9)
• Is the unit installed in a location that is difficult for the
sensor to detect cigarette smoke?
• Are the dust sensor openings blocked or clogged?
(In this case, clean the openings.) (Refer to E-8)
A clicking or ticking sound is
heard from the unit.
• Clicking or ticking sounds may be audible when the unit
is generating ions.
A bad odour comes out of the air
outlet.
• Check to see if the filters are heavily soiled. Replace the
filters. (Refer to E-9)
• Plasmacluster Air Purifiers may produce a slight odour.
This is normal and is a result of the Plasmacluster Ions
refreshing the air.
The Clean Sign is green, but
there is still odour in the air.
• The air could be impure at the time the unit was plugged in.
Unplug the unit, wait one minute, and plug the unit in again.
The Clean Sign illuminates yellow
or red, but the air seems clean.
• Clean the dust sensor with a vacuum cleaner, as it may
be blocked or clogged.(Refer to E-8)
The Clean Sign doesn’t light on. • The Light Control is selected.
Press for 3 seconds to light on.
The Clean Sign lights change
colour frequently.
• The Clean Sign lights automatically change colours as
impurities are detected by the dust sensor.
The unit does not turn on. • The CHILD LOCK mode is selected.
Press for 3seconds
AUTO RESTART
After a power failure, automatically
resume the operation when the
power recovers.
Auto Restart can be set.
• Even when the plug is unplugged or the breaker is thrown
during the operation, the operation resumes at the previous
operation mode and settings if the power recovers.
(with the unit OFF)
ON
(with the unit OFF)
CANCELLATION
(simultaneously for more than 3 sec.)
If the , , lamp lights up for
10 seconds, the setting is complete.
(simultaneously for more than 3 sec.)
OP_FU-A80E-EN+CL+ML.indb 10OP_FU-A80E-EN+CL+ML.indb 10 8/4/11 5:06:48 PM8/4/11 5:06:48 PM

E-11
ENGLISH
SPECIFICATIONS
Model FU-A80E
Power supply 220-240 V 50/60 Hz
Fan
Speed
Operation
Fan Speed Adjustment MAX MED LOW
Rated Power (W) 75 20 5
Air flow (m3/hour) 480 300 120
Noise Level (dBA) 53 41 23
Recommended Room Size *1 62m2
Sensor Dust
Filter type HEPA filter / Deodorizing Pre filter
Cord Length 2.0m
Dimensions 402mm (W) × 245mm (D) × 620mm (H)
Weight 8.1 kg
*1 Size of a room which is appropriate for operating the unit at maximum fan speed.
Standby Power
In order to operate the electrical circuits while the power plug is inserted in the wall outlet, this
product consumes about 0.75W of standby power.
For energy saving, unplug the power cord when the unit is not in use.
OP_FU-A80E-EN+CL+ML.indb 11OP_FU-A80E-EN+CL+ML.indb 11 8/4/11 5:06:50 PM8/4/11 5:06:50 PM

ᆙ⡌䠧ㄡځࢊඅ▶ː㵕
毭㕎偹♫䇂ĀDžᲶઔⅶۮৠ印去䛷毭㕎偹뺕ᮙ沖毭ۛ穔৑⎶ۛ뺕ȗ 减ǝ㽒ؗȠㄡઔ뺔
⫤⍼㽡㳝Ⴢ뺕᝷ؗ⟶ົ쭤ᆌ㽡Ƴゴᚯឥ㽡⦻Ɍ⟆⠊ỹߜ䇂㳝Ⴢ➝뺕气䜓ㄡઔ䏮⥤
ث憔ゴὁᾯ暸䇂氒憔㋞㡣뺔
䠧ㄡځࢊඅ쭤旑ʼn㏫癒䠧ㄡĹ὆㌄䇂㟤ᝧ઴Ჶઔ减ďࡰ⊻⤽キㄡ˅쥼቎箵㡾㡾睞Ĺ
⤽䇂Āㄽࢊ䔌쥽뺔቎⨐ȕ㤇ᘃົᲶઔ㒼뺕܅䠧ㄡځࢊඅďৠ印쨹ᯓ㏫癒Ჶઔ쥼቎
Ღ쬃⦤✄ㄡઔ઴ᚃ㫹ㄡઔ쥽뺔
Ღ旞ὁົ㡾➝汥ᵒᲲ䡢뺕·쩓䠧ㄡ㋊沖뺔
气䜓Ὧٱč뺕ⅸȼᲦ旞ὁჰ柹쩴ȱ૿뺔
*'2#毭㕎偹쟋䆻嗨쟌
ݓ傢䘱ઔ毭㕎偹쟋菛嗨쟌
ᝧྑ
噄䮋뺓㟤ᝧ뺓箵㡾㡾睞䇂󰵿䮗뺓ᚃ㫹
䈅ា
Ჶઔ
箵㡾㡾睞ㄡઔ뺓ᚯឥㄡઔ
OP_FU-A80E-EN+CL+ML.indb 12OP_FU-A80E-EN+CL+ML.indb 12 8/4/11 5:06:51 PM8/4/11 5:06:51 PM

Ĺ⛢
C-1
Ĺ⛢
㮴ᚯ䠧ㄡᆆ㵕∦⥻俒
毭㕎䰾쥧ځ䛷ᗸ僺䛷ᗸ
ژ᝞Ჶઔ
ݓ傢䘱ઔ毭㕎偹印♫ᆪ䜓ᬷ懻ᚯឥᲶઔ뺔
㌪癒㟤ᝧ뺓噄䮋뺓
䈅ាপ睯埗 
*'2#毭㕎偹印瘣䇂᝚哶󰵿
䭧䇂秲䮗뺔
ځࢊ䠧ㄡ
沖毭濔㽡쬌ʩ哨㤇㾓㏫㉰㳝Ⴢ䇂✴᳊뺕ځ䛷
ᗸ僺濘♷ᮔ彏䇂⿽柫䛷ᗸ⧀㏫㉰䠧ㄡ뺔
沖毭毭㕎偹䰾쬘瘣䠧ㄡ뺔
↿痈砂䝅즎O
῵晒ὁ柹Ƌ5*#42䠧ㄡځࢊඅ뺔昧Ȟ俔痙昫
⥷⇜ص뺔ົ㽡⥷ǝ૿ݓ뺕昧䒣·󰩴痙昫ȵ
č䣲嗽즎q濜憔ᙔ؀ư秔r
ົ痙昫⥷⇜ص뺕昧ᝌ⥷⇜ص·ᘃንᵒȵ
皙➝ঞ净뺔
ʼn✴ὁঞ净뺕ⅸȼᲦ旞ὁᝌ⥷⇜ص♷ົὁ
印皙➝⩰痙䇂ໄ✴뺔
䉢종
濜憔ᙔ؀ư秔  %
৻温ɖ䝆 %
ᙔ즫毭㕎偹 %
▶ː %
倂≖ %
倂Οݓ䇂⮫⩰ư秔 %
懾⫧ %
㬐㡒
OP_FU-A80E-EN+CL+ML.indb 1OP_FU-A80E-EN+CL+ML.indb 1 8/4/11 5:06:52 PM8/4/11 5:06:52 PM

C-2
昧Ƴ㽡즳ᆌݓ痙昫⇁⤽⋟᳓뺔
ᵒ㽡㽱අ➝뺕ᯑ浣󰵷࿦⥷ᙔ؀租瘋⏝✼뺕ؗĹࡰ⊻቎čثᚶ쟝
教ʼnژ᝞㽱ۜ뺓㟟㟸ⅾাʈ䇂穔癘즎
sᝌ㽱㒼␕ᇋ氚⏕ܧ8뺓*\䇂Ě㽡㽱㒼␕᯵Č
s቎⨐㽱㒼俍ⅾ␕ᇋ󰩴⍦໱ⅾ氚⏕შᄥ䇂㽱㒼␕᯵󰩴⧟去➝뺕昧ࡧ㽡ځࢊඅ뺔
sᙷ⥤㏫癒㽱㒼␕ᇋČ䇂㟤ᝧ뺔
s昧ࡧ㽡Ნ甒俍뺔
s昧ࡧᝌ⇜⋟ⅾɓˇᲶ㫹␕׺気穔৑ⅾۛ穔৑뺔
s昧ࡧ沖毭⊝⋒㽱俍⧀⊚ۛ␕ᇋ뺔嚌憔⊚ۛ␕ᇋ뺕昧≁␭␕ᇋ뺔
s昧ࡧȵ㒥⇜ᆆ㵕␕ᇋⅾ쭤ᆌ뺔
sົ쩏弱ɓˇ倂≖▶ːݓ뺕昧⊚ۛ㽱㒼俍뺔
s቎⨐㽱㒼俍⍦໱뺕ḇ秖㽭ܲ沥஽뺓ؗ⥂ߙȱ㵕뺓ᆙ⡌⫢ڈ⥂ߙĹḅⅾؘ⤽䦓栐⫧䇂Ǿ柫柯⤟⍩뺕
ȵה঵㽒癘뺔
s昧ࡧົ⟎㧪ㄡ˅઴ؗȠ㫹˅቎⦑尾݄뺓箵ㅐ઴㧪㢊䇂箵㡾瘣氁㽡뺔
s昧ࡧົ㌌ᚊ䦓㘴㒥ʽ傢㽡뺔
s⤽ؔɓˇ痂秳뺓昳⛅ⅾ倂Ο뺕昧ញ氁쬠䰾5JCTR⎦⦕䇂⥂ߙĹḅ뺔
s⥷쭤ᆌď横˅뺓⡝ߓⅾ῵ᙳ印ߓď梦şǾ쥼ࡰ⊻׀䣼쥽ⅾ偍Ť쬗紡઴䏣时䇂Ǿ㽡뺕癒矹Ƞ
ȼ󰩴ᶽܧĀʽ᜹Ƞȼ㽡쭤ᆌ䇂ᙔ؀柫柯䇂Ǿᅦ䇂䈸䌓ⅾ⋟䗨č㽡뺔
ᯑ᝚ḅ䊏䨓׀䣼뺕䒣·Ƞȼďɼ∵㳔⥷쭤ᆌ뺔
㉏Ί♫磮⦉ⅾ㽱戀ᮓ∏
቎⨐⥷䠧ㄡځࢊඅ᜹♫磮⦉ⅾ㽱戀䇂⏕♫沥ⅶᮓ∏뺕昧᝭昅č܂Ā秔ⅾᆪ秔⏝✼ȵΟ⿽ᮓ∏즎
s濜✤昳⛅ⅾ濜✤♷傢⏕♫ᆿ俍뺔
s旙쭤ᆌរ濞氘䛷➁俍㽱 㽱戀⏕♫අ뺔
sᝌ⥷쭤ᆌ䇂㽱㒼Đ⏕♫අ䇂㽱㒼氚⏕ܧď䇂␕᯵Č뺔
s昧쬠䰾쬗璋஽ⅾ쬗紡Ľᛚ䇂➁俍㽱 㽱戀∦⥻Ǿ᜻쪜ᬦߤ뺔
濜憔ᙔ؀ư秔
OP_FU-A80E-EN+CL+ML.indb 2OP_FU-A80E-EN+CL+ML.indb 2 8/4/11 5:06:54 PM8/4/11 5:06:54 PM

Ĺ⛢
C-3
▶ː䇂㉏Ίư秔
s昧ࡧ၃ႇɓˇᲲ৑뺔
s昧ࡧົ㟟㠍뺓ߘ㢑අⅾ⚪㢑අ䦓㠥㢑㫹˅瘣氁ⅾ彜砂Č㽡⥷쭤ᆌ뺔
s昧ࡧົ璤星ʽ傢㽡昕쭤ᆌ뺔
sົ䝕ߣ쭤ᆌ➝뺕ߙḇዠ俖␭ˁ쭤ᆌİ䇂⇜⩆뺔
ົ䝕ߣ쭤ᆌ➝≁␭ݓ砂⧡ৠ印ɼşۮ䛷뺕᳓桉쭤ᆌ去墉뺕᜼哸⦉横া⍦뺔
s쭤ᆌث㇫⤽毭㕎偹➝뺕昧ࡧ㽡쭤ᆌ뺔
s昧ࡧ㏫㊋পض㽡毭㕎偹
์ʼn气ďȊďɼ♰쨂毭㕎偹Ẍ印뺕减ěৠ印᳓桉㽱ۜⅾ⚀皮뺔
s৘ৠ㽡止󰪋◢⊼ᆦ彜砂뺔
昧ࡧ㽡另屘Ẍ㏫㊋݄뺓⌊঵Ẍ㍨˅઴  ⅾ㊋쪤݄㏫㉰쭤ᆌ뺔
์ʼn气ৠ印ɼ쭤ᆌ彜砂া⍦ⅾ䑕怌뺔
⿾ᆦ뺕ʃ῵අŶৠ印ɼ์⿾঵㽒⚀皮뺔
ᙔ즫⋟졈
s浽הᝌ쭤ᆌᙔ♷ົ䡢ᬆ䦓㫹˅ৠ印ĐɓˇᲲ৑⏕戴䇂ໄ✴뺔
 ᙈৠ印ɼᲲ৑ি厇뺕ⅾৠ印᳓桉⚀皮뺔
s昧ࡧᙔ쭜ົ㽭Ƴ㐠᯳ݼ㡣িࢊ减᜼哸⥷쭤ᆌ⢴瞯Ƴٴڰ㳝Ⴢ䇂ໄ✴뺔
቎⨐昕Ὧٱď印浽ה뺕܅昧ົᲲݓᝌ쭤ᆌ䉫䣊Ā᝚➝뺔
쥼ົ%䇂汥ᚊ㐠⦻Ɍč㽡쭤ᆌ뺔쥽
s昧ᙔ쭜ົ䞫๶䇂彜砂ě沖穔嗤ቃ䇂ໄ✴뺔
ᵒ⥷쭤ᆌ♷傢ົ璅⤽ໄポ䇂ໄ✴➝뺕ৠ印᜼哸⥷쭤ᆌ歮󰵿⌛ߣ뺔
s浽הົǝ㽒㈉听ⅾ㈉Ẍ㡾睞䇂ໄ✴쥼቎↿쥽㽡昕쭤ᆌ뺔
쭤ᆌ彜砂ৠ印์⿾䑕怌뺕ⅾʃ῵අ์⿾঵㽒⚀皮뺔
毭㕎偹⋟졈
s浣㥏昤⟆᝚ḅ気弱ᆆ㵕઴倂≖뺔
昧ࡧᙔ쭜ɓˇؗȠ쬌ག䇂毭㕎偹뺔
OP_FU-A80E-EN+CL+ML.indb 3OP_FU-A80E-EN+CL+ML.indb 3 8/4/11 5:06:57 PM8/4/11 5:06:57 PM

C-4
৻温ɖ䝆
䉫懼๼
瘣Ɍ
s㽡昤⟆ſ
1ۛ৑
2気穔৑
3⇜⩆
4Ŋ⦉
5*'2#毭㕎偹
6ݓ傢䘱ઔ毭㕎偹
7㟤ᝧʃ῵අ
8➊⥤⪠䧞
9㽱㒼俍
10 ␕ᇋ
匨温
1
3
4
2
7
5
6
8
9
10
OP_FU-A80E-EN+CL+ML.indb 4OP_FU-A80E-EN+CL+ML.indb 4 8/4/11 5:06:59 PM8/4/11 5:06:59 PM

Ĺ⛢
C-5
Ŋ⦉⠊䗨
11 ᴟߓ䛷ᗸ僺癒埗ⷱ᳊⋢琹
ᴟߓ䛷ᗸ僺癒埗⋟䗨㟣쥼倍嗨쥽
12 ځ䛷ᗸ僺Ჲؔ⋢琹
ځ䛷ᗸ僺Ჲؔ⋢琹⋟䗨㟣쥼倍嗨쥽
13 ׀䣼璌⋢琹׀䣼璌⋢琹⋟䗨㟣쥼倍嗨쥽
14 ㏫㉰΍৫
秷嗨ᝌ⫤⍼䠧ㄡ柴濞♰ি뺔
15 ځ䛷ᗸ僺΍৫쥼妐嗨쥽
16 穔濞ⷱ᳊⋟䗨㟣쥼倍嗨쥽
17 穔濞ⷱ᳊⋢琹
18 㽱㒼⋢琹
倍嗨菃嗨侰嗨
ᮓځ矹ᬷ厇
11 12 14 15 16 17 1813
OP_FU-A80E-EN+CL+ML.indb 5OP_FU-A80E-EN+CL+ML.indb 5 8/4/11 5:07:01 PM8/4/11 5:07:01 PM

C-6
ᙔ즫毭㕎偹
ົ좞弱ɓˇ·؞▶ːݓ뺕昧⊚ۛ㽱㒼俍뺔
ʼn倂좢毭㕎偹䇂柴濞뺕ᙔȼ⟶㽡ၯ✄徠ࡰ怣뺕ᮙᙔ즫ົŊ⦉Č뺔㽡⥷즳ᆌݓ뺕ḇ秖ᝌ毭㕎偹ȗ
卤徠Ĺঽۛ뺔
1
⊄čݓ砂⧡뺔
歮歮␭ˁݓ砂⧡ᯓ温뺕ᮙ⥢ὁ䇂✴歮歮⊈ᯓ温뺔
2

⊄čၯ✄徠뺔
3

⋢⿽䒣✴ᙔ♷毭㕎偹뺔
⋢秕ᯉᙔ♷毭㕎偹뺔
4

๶ᙷݓ砂⧡뺔
沖毭ᝌݓ砂⧡琴ົ쭤ᆌݓ温気弱๶ᙷ뺔
沖毭歮歮⋢⧀❘歟砂⧡뺕䉫ܧ砂⧡๶
ᙷܧʽ뺔
5

ົߣⅾ⤟⍩毭㕎偹➝뺕昧无종
➊⥤뺔
*'2#毭㕎偹쥼䆻嗨쥽
ݓ傢䘱ઔ毭㕎偹쥼菛嗨쥽
Starting date of use
Replacement Filters
Replace the filters when they are no
longer removing odour or dust.
OP_FU-A80E-EN+CL+ML.indb 6OP_FU-A80E-EN+CL+ML.indb 6 8/4/11 5:07:03 PM8/4/11 5:07:03 PM
