Sharp ER-A410 Owner's manual

CODE : 00Z
q
CONTENTS
Parts marked with "!" are important for maintaining the safety of the set. Be sure to replace these parts with specified
ones for maintaining the safety and performance of the set.
SHARP CORPORATION This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
PROGRAMMING MANUA
L
ERA410VPME
ELECTRONIC
CASH REGISTER
ER-A410
MODEL ER-A420
(For “V“ version)
SRV KEY:LKGIM7113RCZZ
PRINTER:PR-45MII
CHAPTER 1. SERVICE (SRV) MODE . . . . . . . . . . . . . . . . . . . . . .1 - 1
CHAPTER 2. PROGRAM (PGM2/PGM1) MODE. . . . . . . . . . . . . .2 - 1
CHAPTER 3. OP X/Z, X1/Z1,X2/Z2 MODE . . . . . . . . . . . . . . . . . .3 - 1
CHAPTER 4.
CHANGING EURO FUNCTION (X2/Z2 MODE JOB) . .4 - 1
ER-A410
ER-A420

ER-A410/ER-A420 SERVICE (SRV) MODE
1 – 1
CHAPTER 1. SERVICE (SRV) MODE
The SRV key is used for operating in the SRV mode.
MASTER RESET clears the entire memory and resumes initial values.
PROGRAM RESET resumes the initial program without clearing mem-
ory.
There are 2 kind of MASTER RESET.
1. PROCEDURE
■MASTER RESET 1
“Procedure A” or “Procedure B”
Procedure A: 1) Set the mode switch to the (SRV’) position.
2) Plug in the AC cord to the wall outlet.
3) While holding down the JOURNAL FEED key, turn
the mode switch to (SRV) position from (SRV’) posi-
tion.
Procedure B: 1) Unplug the AC cord from the wall outlet.
2) Set the mode switch to the (SRV) position.
3) While holding down the JOURNAL FEED key, plug in
the AC cord to the wall outlet.
Note: Procedure B cannot reset the hardware.
It must be operated “Procedure A” to reset the hardware.
■MASTER RESET 2
“Procedure A” or “Procedure B”
Procedure A: 1) Set the mode switch to the (SRV’) position.
2) Plug in the AC cord to the wall outlet.
3) While holding down the JOURNAL FEED key & the
RECEIPT FEED key, turn the mode switch to (SRV)
position from (SRV’) position.
4) Program [0] [1] [2] [3] [4] [5] [6] [7] [8] [9] [00] [000] [.]
[CL] [x] [ST] [TL] keys by depressing in this order.
Procedure B: 1) Unplug the AC cord from the wall outlet.
2) Set the mode switch to the (SRV) position.
3) While holding down the JOURNAL FEED key & the
RECEIPT FEED key, plug in the AC cord to the wall
outlet.
4) Same as “Procedure A”
Note: Procedure B cannot reset the hardware.
It must be operated “Procedure A” to reset the hardware.
■PROGRAM RESET
“Procedure A”, “Procedure B” or “Procedure C”
Prodecure A: 1) Set the mode switch to the (SRV’) position.
2) Plug in the AC cord to the wall outlet.
3) Whithout pressing the JOURNAL FEED key, turn the
mode switch to (SRV) position from (SRV’) position.
Procedure B: 1) Unplug the AC cord from the wall outlet.
2) Set the mode switch to the (SRV) position.
3) Without pressing the JOURNAL FEED key, plug in
the AC cord from the wall outlet.
Procedure C: 1) Unplug the AC cord from the wall outlet.
2) Set the mode switch to the PGM2 position.
3) While holding down the JOURNAL FEED key & the
RECEIPT FEED key, plug in the AC cord to the wall
outlet.
*”Procedure C” can be done when SRV#916_B_+4: PROGRAM
RESET in PGM2 = ENABLE.
Note: Procedure B and C cannot reset the hardware.
It must be operated “Procedure A” to reset the hardware.
2. KEY SETUP PROCEDURE
■MASTER RESET 1
1) During memory clearing and initializing, “***MRS.***” is dis-
played on upper line.
2) When MASTER RESET is finished, the buzzer beeps 3 times.
No message is printed.
■MASTER RESET 2
1) The key text that should be programmed is displayed.
2) During memory clearing and initializing, “***MRS.***” is dis-
played on upper line.
3) When MASTER RESET is finished, the buzzer beeps 3 times.
No message is printed.
■SERVICE RESET
1) When SERVICE RESET is finished, “PROGRAM RESET ***” is
printed. Buzzer does not beep.
3. READING OF THE SRV MODE PROGRAM
List of program reports
Program reports are printed on RECEIPT & JOURNAL.
MASTER RESET 1: Normal MASTER RESET
It clears the entire memory and resumes initial
values.
MASTER RESET 2: It enables the layout of fixed keys in addition to
MASTER RESET 1.
Fixed keys: [0] [1] [2] [3] [4] [5] [6] [7] [8] [9] [00]
[000] [.] [CL] [x] [ST] [TL]
Note: If [000] key is not required, press the same key
in the next step, and [000] key will be inhibited.
ex) 001 0 KEY 3002 1 KEY 3...
JOB# Report name
900 SRV-mode program full item report (not incl. keyboard layout)
950 Keyboard layout report (except Dept. key & PLU key)
951 Keyboard layout report (only Dept. key & PLU key)
990 SSR report

ER-A410/ER-A420 SERVICE (SRV) MODE
1 – 2
[JOB# 900]
Reading the contents of the SRV mode programming
Key operation.
The contents of the programming are printed only on the journal in indi-
vidual formats shown above.
[JOB# 950]
Reading the contents of the SRV mode programming for FREE KEY
LAYOUT setting. (Function Key)
Key operation
*This printing sample is used from the ER-A410.
900 TL
Job code
Contents of the
SRV-mode programming
Date/Time/Cashier code
Machine No. /CC-No./Cashier name
Clerk code/Clerk name
(Printing at Cashier & Clerk system
)
General Z1 reset counter
GT2
PGM2 mode secret code
Domestic currency symbol
Initial text mode
programming
Department
PLU record
PBLU record
Clerk
Cashier
Max number programming
Training cashier No.
Training mode title
GT3
Clerk Z1 reset counter
Houlry Z1 reset counter
PLU Z1 reset counter
Cashier Z1 reset counter
PBLU Z1 reset counter
General Z2 reset counter
Daily net Z2 reset counter
950 TL
Key No. /Key text/Location No.
Job code
Date/Time/Cashier code
Machine No. /CC-No./Cashier name
Clerk code/Clerk name
(Printing at Cashier & Clerk system)

ER-A410/ER-A420 SERVICE (SRV) MODE
1 – 3
[JOB# 951]
Reading the contents of the SRV mode programming for FREE KEY
LAYOUT setting. (Dept. & PLU key)
Key operation
[JOB#990]
Reading the contents of the SRV mode programming for SSR setting.
Key operation
951 TL
Key No. /Key label/Location No.
Job code
Date/Time/Cashier code
Machine No. /CC-No./Cashier nam
e
Clerk code/Clerk name
(Printing at Cashier & Clerk syste
m
990 TL
SSR No. (Reading report only)
Job code
Date/Time/Cashier code
Machine No. /CC-No./Cashier name
Clerk code/Clerk name
(Printing at Cashier & Clerk system)

ER-A410/ER-A420 SERVICE (SRV) MODE
1 – 4
4. SERVICE MODE PROGRAMMING
The following are the key operation required for programming.
Details of [A] [B] [C] [D] will be discussed at each item description.
★mark is MRS setting.
[JOB#901] ER-A410: MRS = 0102
ER-A420: MRS = 0102
#901-A: EFT EASY CARD
#901-B: Tax system
#901-C: 1. Rounding system
#901-D: 1. TAB setting
[JOB#902] ER-A410: MRS = 0000
ER-A420: MRS = 0000
#902-A, B, C: Not used (Fixed at “000”)
#902-D: 1. EFT TERMINAL
[JOB#903] ER-A410: MRS = 5000
ER-A420: MRS = 5000
#903-A: 1. ECR data copy baud rate
#903-B, C, D: Not used (Fixed at “000”)
[JOB#904] ER-A410: MRS = 0000
ER-A420: MRS = 0000
#904-A: 1. Printing of date
#904-B: 1. Printing of consecutive No.
#904-C, D: Not used (Fixed at “00”)
[JOB#905] ER-A410: MRS = 0100
ER-A420: MRS = 0100
#905-A: Not used (Fixed at “0”)
#905-B: 1. Tax printing when taxable subtotal is zero.
2. Tax printing when tax is zero.
#905-C: 1. Printing of rounding amount in receipt. (For Australia)
2. Printing format for split pricing entry. (For Australia)
#905-D: Not used (Fixed at “0”)
1. EFT EASY CARD 901-A
NO 0 ★
YES 2
1. TAX system 901-B
Auto TAX 1~4 0
Auto VAT 1~4 1 ★
Manual VAT 1~4 2
Manual VAT 1 3
Manual TAX 1~4 4
Auto VAT 1 and Auto TAX 2~4 5
1. Rounding system 901-C
Normal 0 ★
SWEDEN 1
DENMARK 4
1. TAB setting 901-D
0. 0
0.0 1
0.00 2 ★
0.000 3
1. EFT TERMINAL 902-D
NO 0 ★
YES 4
XXX
TL
(Job#)
[A] [B] [C] [D]
Numeric entry
4 digits max
0
1. Baud rate (bps) 903-A
9600 4
19200 5 ★
1. Printing of date 904-A
Yes 0 ★
No 4
1. Printing of consecutive No. 904-B
Yes 0 ★
No 4
1. Taxable subtotal is zero 2. Tax is zero 905-B
Skip Print 0
Skip 1 ★
Print Print 4
Skip 5
1. Printing of rounding
amount in receipt 2. Printing format for split pricing entry 905-C
No Normal format 0 ★
Australia format 1
Yes Normal format 2
Australia format 3

ER-A410/ER-A420 SERVICE (SRV) MODE
1 – 5
[JOB#906] ER-A410: MRS = 0001
ER-A420: MRS = 0001
#906-A: 1. Printing of PLU codes
2. Entry which makes the PLU stock counter negative
#906-B: 1. Bottle return function
2. Hash setting
#906-C: 1. Split pricing counting
2. Multiplication entry
#906-D: 1. Presetting of consecutive No.
2. Fractional quantity (3 digit decimal places)
[JOB#907] ER-A410: MRS = 0014
ER-A420: MRS = 0014
#907-A, B: Not used (Fixed at “00”)
#907-C: 1. In case of all individual and all cashier CCD, X report before
CCD entry
2. Locking of REG mode entry after individual cashier reset-
ting
3. Minus DEPT. / PLU
#907-D: 1. Z-counter print for Clerk, Hourly, PLU, Cashier, PBLU, Daily net
2. CCD compulsory
[JOB#908] ER-A410: MRS = 0000
ER-A420: MRS = 0000
#908-A: Printing of GT on Z report
1. Printing of PLU codes 2. Entry which makes the
PLU stock counter
negative 906-A
NO
Allowed unconditionally 0 ★
Operation allowed despite
error massage 1
inhibited 2
YES
Allowed unconditionally 4
Operation allowed despite
error massage 5
inhibited 6
1. Bottle return function 2. Hash setting 906-B
Disable Disable 0 ★
Enable 2
Enable Disable 4
Enable 6
1. Split pricing counting 2. Multiplication entry 906-C
Quantity
Multiplication 0 ★
Successive multiplication 1
Split pricing 2
Package
Multiplication 4
Successive multiplication 5
Split pricing 6
1. Presetting of consecu-
tive No. 2. Fractional quantity 906-D
Yes No 0
Yes 1 ★
No No 2
Yes 3
1. In case of all
individual
and all cash-
ier CCD, X
report before
CCD entry
2. Locking of
REG mode
entry after
individual
cashier
resetting
3. Minus DEPT.
/ PLU / EAN
907-C
Disable
Disable Disable 0
Enable 1 ★
Enable Disable 2
Enable 3
Enable
Disable Disable 4
Enable 5
Enable Disable 6
Enable 7
1. Z-counter print 2. CCD compulsory 907-D
Yes
Non compulsory 0
For individual cashier 1
For all cashier 2
No
Non compulsory 4 ★
For individual cashier 5
For all cashier 6
GT1 (NET) GT2 (+) GT3 (-) 908-A
Print
Print Print 0 ★
Skip 1
Skip Print 2
Skip 3
Skip
Print Print 4
Skip 5
Skip Print 6
Skip 7

ER-A410/ER-A420 SERVICE (SRV) MODE
1 – 6
#908-B: Printing of GT on X report
#908-C: 1. Addition to the hourly total in void mode
2. X1/Z1 report at X2/Z2 mode
3. Resetting of consecutive number in Z1
#908-D: 1. Printing X/Z report (Except the individual cashier and indi-
vidual clerk report)
2. GT resetting at Z1 general resetting
[JOB#909] ER-A410: MRS = 2000
ER-A420: MRS = 2000
#909-A: 1. Printing of balance GT on the Z report
2. Printing of training GT on the X report
3. Printing of training GT on the Z report
#909-B: 1. Printing of data on PLU resetting report
2. All Z1 resetting in X1/Z1 mode
#909-C: 1. Printing of void made & MRG void in Z2 report
2. Printing of void made & MRG void in Z1 report
3. Balance GT resetting at Z1 general resetting
#909-D: 1. Clerk change during entry operation
2. Entry of clerk code compulsory
[JOB#910] ER-A410: MRS = 0200
ER-A420: MRS = 0200
#910-A: 1. Clerk name print on receipt when clerk is changed. (It is
always print on Journal)
2. Overlaped cashier function. (This selection is available only
for “Cashier only” system)
#910-B: 1. Cashier/Clerk code display and print.
2. Auto cashier sign off at the end of transaction
#910-C, D: Not used (Fixed at “00”)
GT1 (NET) GT2 (+) GT3 (-) 908-B
Skip
Skip Skip 0 ★
Print 1
Print Skip 2
Print 3
Print
Skip Skip 4
Print 5
Print Skip 6
Print 7
1. Addition to
the hourly
total in void
mode
2. X1/Z1 report
at X2/Z2
mode
3. Resetting of
consecutive
No.in Z1 908-C
No
Enable No 0 ★
Yes 1
Disable No 2
Yes 3
Yes
Enable No 4
Yes 5
Disable No 6
Yes 7
1. Printing X/Z report 2. GT resetting at Z1 908-D
Receipt & Journal No 0 ★
Yes 1
Journal No 4
Yes 5
1. Printing of
balance GT
on the Z
report
2. Printing of
training GT
on the X
report
3. Printing of
training GT
on the Z
report
909-A
YES
NO YES 0
NO 1
YES YES 2 ★
NO 3
NO
NO YES 4
NO 5
YES YES 6
NO 7
1. Printing of data on
PLU resetting report 2. All Z1 resetting in X1/ Z1 mode 909-B
Yes Enable 0 ★
Disable 2
No Enable 4
Disable 6
1. Printing of
void made &
MRG void in
Z2 report
2. Printing of
void made &
MRG void in
Z1 report
3. Balance GT
resetting at
Z1 general
resetting
909-C
YES YES NO 0 ★
YES 1
NO NO 2
YES 3
NO YES NO 4
YES 5
NO NO 6
YES 7
1. Clerk change during
entry operation 2. Entry of clerk code compulsory 909-D
Disable No (After clerk Z1 only) 0 ★
Yes (Everytime) 2
Enable No (After clerk Z1 only) 4
Yes (Everytime) 6
1. Clerk name print on
receipt when clerk is
changed.
2. Overlaped cashier
function 910-A
No No 0 ★
Yes 1
Yes No 4
Yes 5
1. Cashier/Clerk code
display and print. 2. Auto cashier sign off at the end of transaction 910-B
Hidden No (After cashier Z1 only) 0
Yes (Everytime) 1
Appear No (After cashier Z1 only) 2 ★
Yes (Everytime) 3

ER-A410/ER-A420 SERVICE (SRV) MODE
1 – 7
[JOB#911] ER-A410: MRS = 0000
ER-A420: MRS = 0000
#911-A: 1. Fraction treatment
#911-B, C, D: Not used (Fixed at “000”)
[JOB#912] ER-A410: MRS = 1141
ER-A420: MRS = 1140
#912-A: 1. Date print format
#912-B: 1. Time system
#912-C: 1. After transaction receipt format
2. Copy receipt
3. Footer print control
#912-D: 1. LOGO Message control.
[JOB#913] ER-A410: MRS = 0002
ER-A420: MRS = 0002
#913-A: 1. Content of total VP amount
#913-B: 1. Printing of subtotal by ST key
2. Escape the compulsory of VP and SLIP
*[ • ], [RCPT] keys to escape validation (MGR mode).
#913-C: 1. Buzzer off 2 sec. after lock error
2. Buffered keyboard
1. Fraction treatment 911-A
Round off 0 ★
Round up unit 1
Disregarding 2
Date format 912-A
Month/Day/Year 0
Day/Month/Year 1 ★
Year/Month/Day 2
1. Time system 912-B
12H 0
24H 1 ★
1. After trans-
action receipt 2. Copy receipt 3. Footer print control 912-C
Total only
No
All receipt 0
On selected
function keys at
the time of final-
ization
1
Yes
All receipt 2
On selected
function keys at
the time of final-
ization
3
Detail
No
All receipt 4 ★
On selected
function keys at
the time of final-
ization
5
Yes
All receipt 6
On selected
function keys at
the time of final-
ization
7
1. LOGO Message control 912-D
3-line header instead of a LOGO 0★
(ER-A420)
Glaphical LOGO only 1★
(ER-A410)
Glaphical LOGO and 3-line footer 2
6-line header 3
Glaphical LOGO and 3-line header 4
3-line header and 3-line footer 5
1. Content of total VP amount 913-A
Total amount 0 ★
Tendered amount 1
1. Printing of subtotal by
ST key 2. Escape the compul- sory of VP and SLIP 913-B
No Disable 0 ★
Enable 1
Yes Disable 4
Enable 5
1. Buzzer off 2sec. after
lock error 2. Buffered keyboard 913-C
2-sec. off Yes 0 ★
No 1
Constant
(Till error recovery) Yes 2
No 3
Header
Footer
Type : 0
5
32
LOGO
1
4
LOGO
LOGO

ER-A410/ER-A420 SERVICE (SRV) MODE
1 – 8
#913-D: 1. Drawer closing compulsory
2. Error mode
3. Key touch sound
[JOB#914] ER-A410: MRS = 0100
ER-A420: MRS = 0100
#914-A: 1. Receipt issuing at no-sale
2. [NS] key separation from [TL] key for no-sale function
3. No-sale and EX drawer open
#914-B: 1. No-sale after NON ADD code entry
#914-C: 1. Void mode
#914-D: 1. CHECK CASHING
[JOB#915] ER-A410: MRS = 0020
ER-A420: MRS = 0020
#915-A, B: Not used (Fixed at “00”)
#915-C: 1. ST (-), ST (%) as many times needed/operation only once
#915-D: Not used (Fixed at “0”)
[JOB#916] ER-A410: MRS = 1000
ER-A420: MRS = 1000
#916-A: 1. Print format when and amount overlaps each other REG
mode
#916-B: 1. Finalization by charge (credit) when ST is 0 or below
2. Tendering which is smaller than the sales amount
#916-C: 1. Negative merchandise subtotal
2. Subtotal entry compulsory before tendering
3. Subtotal entry before direct non-tendering finalization
#916-D: 1. Coupon PLU printing on X/Z report
2. Net sales subtotal (NET1) printing on X/Z report
3. CHECK change total printing on X/Z report
[JOB#917] NOT USED:ER-A410: MRS = 0000
ER-A420: MRS = 0000
1. Drawer clos-
ing compul-
sory
2. Error mode 3. Key touch
sound 913-D
Non-compulsory
All lock error Enable 0
Disable 1
Mis operation
(One shot error) Enable 2 ★
Disable 3
Compulsory
All lock error Enable 4
Disable 5
Mis operation
(One shot error) Enable 6
Disable 7
1. Receipt
issuing at
no-sale
2. [NS] key
separation 3. No-sale and EX drawer
open 914-A
Enable
Yes Enable 0 ★
Disable 1
No Enable 2
Disable 3
Disable
Yes Enable 4
Disable 5
No Enable 6
Disable 7
1. No-sale after # entry 914-B
Disable 0
Enable 1 ★
1. Void mode 914-C
Enable 0 ★
Disable 2
1. CHECK CASHING 914-D
Disable 0 ★
Enable 2
1. ST (-), ST (%) as many times needed/
operation only once 915-C
Unlimited 0
Once only 2 ★
1. Print format when and amount overlaps
each other REG mode 916-A
Truncate 0
2 line print 1 ★
1. Finalization by charge
(credit) when ST is 0
or below
2. Tendering which is
smaller than the sales
amount 916-B
Disable Enable 0 ★
Disable 2
Enable Enable 4
Disable 6
1. Negative
merchan-
dise subtotal
2. Subtotal
entry com-
pulsory
before ten-
dering
3. Subtotal
entry before
direct non-
tendering
finalization
916-C
Allow
Noncompulsory Non-compulsory 0 ★
Compulsory 1
Compulsory Non-compulsory 2
Compulsory 3
Disallow
Non-compulsory Non-compulsory 4
Compulsory 5
Compulsory Non-compulsory 6
Compulsory 7
1. Print coupon
PLU’s on
general
report
2. Print net
sales SBTL
(NET1) on
general
report
3. Print CHK
CHANGE on
general
report 916-D
Print
Print Print 0 ★
Skip 1
Skip Print 2
Skip 3
Skip
Print Print 4
Skip 5
Skip Print 6
Skip 7

ER-A410/ER-A420 SERVICE (SRV) MODE
1 – 9
[JOB#918] ER-A410: MRS = 0000
ER-A420: MRS = 0000
#918-A: 1. Printing of text of a tied PLU in set PLU
2. Direct non-tendering finalization after previous tender enter
#918-B: Not used (Fixed at “0”)
#918-C: 1. Printing of Z1/Z2 counter in Z reports
#918-D: Not used (Fixed at “0”)
[JOB#919] ER-A410: MRS = 0000
ER-A420: MRS = 0000
#919-A: Not used (Fixed at “0”)
#919-B: 1. Checking of casher # on guest check when a reorder is
made
2. Guest check No.
#919-C: 1. PBLU entry
2. Amount printing when PLU unit price is 0
#919-D: 1. Conversion ST printing of native ST
[JOB#920] NOT USED ER-A410: MRS = 0000
ER-A420: MRS = 0000
[JOB#921] ER-A410: MRS = 0000
ER-A420: MRS = 0000
#921-A, B: Not used (Fixed at “00”)
#921-C: 1. Vat shift operation timing duaring at transaction
#921-D: Not used (Fixed at “0”)
[JOB#922] ER-A410: MRS = 0000
ER-A420: MRS = 0000
#922-A: Not used (Fixed “0”)
#922-B: 1. Jornal print after SLIP/GC.RCPT
#922-C, D: Not used (Fixed “00”)
[JOB#923] NOT USED ER-A410: MRS = 0000
ER-A420: MRS = 0000
[JOB#924] NOT USED ER-A410: MRS = 0000
ER-A420: MRS = 0000
[JOB#925] NOT USED ER-A410: MRS = 0000
ER-A420: MRS = 0000
[JOB#926] ER-A410: MRS = 0400
ER-A420: MRS = 0400
#926-A: Not used (Fixed at “0”)
#926-B: 1. Program reset at PGM2 mode
#926-C: Not used (Fixed at “0”)
#926-D: 1.Check VP
1. Printting of text of a
tied PLU in set PLU 2. Direct non-tendering finalization after previ-
ous tender enter 918-A
YES Disable 0 ★
Enable 2
NO Disable 4
Enable 6
1. Printing of Z1/Z2 counter in Z reports 918-C
Yes 0 ★
No 4
1. Checking of casher #
on guest check when
a reorder is made
2. Guest check No. 919-B
YES Auto generation 0 ★
Manual 1
NO Auto generation 4
Manual 5
1. PBLU entry 2. Amount printing when
PLU unit price is 0 919-C
Non compulsory No 0 ★
Yes 1
Compulsory No 2
Yes 3
1. Conversion SBTL print of native SBTL 919-D
Yes 0 ★
No 4
1. Vat shift operation timing duaring at trans-
action 921-C
Only at the start of transaction 0 ★
During a transaction 2
1. Jornal print after SLIP/GC.RCPT 922-B
NO 0 ★
YES 2
1. Program reset at PGM2 mode 926-B
Disable 0
Enable 4 ★
1. Check VP 926-D
Normal 0 ★
CHEQUE EURO 2

ER-A410/ER-A420 SERVICE (SRV) MODE
1 – 10
[JOB#927] ER-A410: MRS = 0000
ER-A420: MRS = 0000
#927-A: 1. Rounding up of the units digit of amount
#927-B: 1. Rounding down of the units digit of amount
#927-C: 1. Difference memory (Difference between before-rounding
and after-rounding)
2. Limit on the least sighificant digit in entering the amount on
item
#927-D: 1. Application of rounding
2. Limit on the least significant digit in entering the amount of
payment
[JOB#928] ER-A410: MRS = 0000
ER-A420: MRS = 0000
#928-A: 1. Printing of slip LOGO text
#928-B: 1. VP massage printing on slip
2. Header line on slip paper when a reorder is made printed
#928-C: 1. Printing of PLU on slip when it is 0
2. Printing of text of a tied PLU in set PLU on slip
#928-D: 1. Printing of PB/NBAL on slip
2. Compulsory slip print system
1. Rounding the units digit of amount 927-AB
Common destination 00 ★
Netherland/Switzerland 82
Norway 54
1. Difference memory 2. Limit on the least sigh-
ificant digit in entering
the amount on item 927-C
No
Arbitary 0 ★
0 only 1
0 and 5 only 2
Yes
Arbitary 4
0 only 5
0 and 5 only 6
1. Application of round-
ing 2. Limit on the least sig- nificant digit in enter-
ing the amount of
payment
927-D
Item & Payment
Arbitary 0 ★
0 only 1
0 and 5 only 2
Payment
Arbitary 4
0 only 5
0 and 5 only 6
1. Printing of slip LOGO text 928-A
No 0 ★
Yes 1
1. VP massage printing
on slip 2. Header line on slip paper when a reorder
is made printed 928-B
Check only Printed 0 ★
Not 1
Check & Credit Printed 2
Not 3
1. Printing of PLU on slip
when it is 0 2. Printing of text of a tied PLU in set PLU on
slip 928-C
YES YES 0 ★
NO 2
NO YES 4
NO 6
1. Printing of PB/NBAL
on slip 2. Compulsory slip print system 928-D
YES
According to each
media’s preset (Slip print-
ing at [FINAL] in PBLU
system isn’t always com-
pulsory.)
0★
Compulsory for every
entry 1
Compulsory for PB 2
NO
According to each
media’s preset (Slip print-
ing at [FINAL] in PBLU
system isn’t always com-
pulsory.)
4
Compulsory for every
entry 5
Compulsory for PB 6

ER-A410/ER-A420 SERVICE (SRV) MODE
1 – 11
[JOB#929] ER-A410: MRS = 0000
ER-A420: MRS = 0000
#929-A: Not Used (Fixed at “0”)
#929-B: 1. Message LOGO print on Journal
2. Z1 RESET of cashier with OPEN PBLU
#929-C: Not used (Fixed at “0”)
#929-D: 1. Taxable status of PLU which is set at “Non-taxable” by PGM.
[JOB#980] ER-A410: MRS = 0002
ER-A420: MRS = 0002
#918-A: Not used (Fixed at “0”)
#980-B: 1. Australia rounding (Rounding only CASH finalize and
change amount)
*This selection is not effective at Manual Tax 1-4 system.
#980-C: Not used (Fixed at “0”)
#980-D: 1. VAT/TAX assignment print
[JOB#930~939] ER-A410: MRS = 0000
ER-A420: MRS = 0000
RESET REPORT COUNTER
[JOB#942, 943] ER-A410: MRS = 0000000000000
ER-A420: MRS = 0000000000000
GT COUNTER PRESETTING
Note: GT1 is obtained by calculation
Equation: GT1=GT2-GT3
[JOB#944] ER-A410: MRS = 0000
ER-A420: MRS = 0000
PGM2 mode secret code presetting
Note: When the secret code “0” is programmed, the secret code entry
is inhibited.
[JOB#948] ER-A410: MRS = 00
ER-A420: MRS = 00
PROGRAMMING OF TRAINING CASHIER NO.
XX: Cashier No.
[JOB#949] ER-A410: MRS = “**TRAINING**”
ER-A420: MRS = “**TRAINING**”
THE TRAINING MODE’S TITLE
[JOB#950] MRS = STANDARD KEY LAYOUT
Free key layout (Except for department keys and direct PLU keys.)
1. Message LOGO print
on Journal 2. Z1 RESET of cashier with OPEN PBLU 929-B
No Disable 0 ★
Enable 1
Yes Disable 2
Enable 3
1. Taxable status of PLU which is set at
“Non-taxable” by PGM. 929-D
According to its associated department 0 ★
Non taxable 2
1. Australia rounding 980-B
No (Not Rounding) 0 ★
Yes (Rounding) 2
1. VAT/TAX assignment print 980-D
Print 0
Not 2 ★
JOB # Function
930 Z1 report counter
932 Clerk Z1 report counter
933 Hourly Z1 report counter
934 PLU Z1 report counter
935 Cashier Z1 report counter
936 PBLU Z1 report counter
937 Z2 report counter
939 Daily net Z2 report counter
Job# XXXX
Initial value of Z counter
"0"
TL
JOB # Function
942 GT2 (Positive GT)
943 GT3 (Negative GT)
XXX: 1 to 75
999 (for inhibit key)
Job# 0000000000000
13 digits
0
TL
944 XXXX
4 digits
0
TL
948 XX TL
0
949 Character Key
(12 chara.)
Space
TL
950 Free key
Key number automatic
increment
Key number manual
increment
Initial setting
XXX
Key No.TL
Inhibit
Increment Key No.
ST

ER-A410/ER-A420 SERVICE (SRV) MODE
1 – 12
[JOB#951] MRS = STANDARD KEY LAYOUT
Free key layout (department keys and direct PLU keys)
• Programming of the keys to be dept keys or direct PLU keys on the
keyboard.
• Key No. is assigned to each key which is supposed to be dept. Key or
direct PLU key by depressing the key after entering the key No.
• Those keys programmed by this job No. will be dept. keys if dept.
code is assigned, and will be direct PLU keys if PLU code is assigned
in the PGM2 mode.
FUNCTION KEY LIST
XXX: 1 to 119
999 (for inhibit key)
Key No. KEY KEY TEXT
123456
1 0 KEY 0 KEY
2 1 KEY 1 KEY
3 2 KEY 2 KEY
4 3 KEY 3 KEY
5 4 KEY 4 KEY
6 5 KEY 5 KEY
7 6 KEY 6 KEY
8 7 KEY 7 KEY
9 8 KEY 8 KEY
10 9 KEY 9 KEY
11 00 KEY 00 KEY
12 000 KEY 000 KEY
13 DECIMAL POINT . KEY
14 CLEAR CLEAR
15 yu
16 SUB TOTAL SBTL
17 TOTAL TOTAL
18 # #
19 NO SALE NS
20 PLU PLU
21 G. C. COPY GCCOPY
22 L1 L1
23 L2 L2
24 L3 L3
25 PRICE SHIFT P.SFT
26 PRINT VP
27 SLIP SLIP
28 RCPT RCPT
29 VOID VOID
30 REFUND RFND
31 %1 %1
951 Free keyXXX
Key No.
Key number automatic
increment
Key number manual increment
To inhibit
TL
Increment Key No.
ST
32 %2 %2
33 %3 %3
34 %4 %4
35 (-) 1 (-) 1
36 (-) 2 (-) 2
37 (-) 3 (-) 3
38 (-) 4 (-) 4
39 VAT VAT
40 AUTO AUTO
41 AUTO2 AUTO2
42 AUTO3 AUTO3
43 AUTO4 AUTO4
44 AUTO5 AUTO5
45 CASH2 CA2
46 CHECK CHECK
47 CHECK2 CHECK2
48 CHECK3 CHECK3
49 CHECK4 CHECK4
50 CREDIT1 CR1
51 CREDIT2 CR2
52 CREDIT3 CR3
53 CREDIT4 CR4
54 EX1 EX 1
55 EX2 EX 2
56 EX3 EX 3
57 EX4 EX 4
58 RA RA
59 RA2 RA2
60 PO PO
61 PO2 PO2
62 1/21/2 KEY
63 AMT AMT
64 VAT SHIFT VAT SF
65 DIFFER ST DIF ST
66 CASHIER NO. CASH #
67 CLERK NO. CLK #
68 DEPT. NO. DEPT#
69 PBLU PBLU
70 NBAL NBAL
71 FINAL FINAL
72 DEPOSIT DEPO
73 DEPOSIT RFND DEP. RF
74 G.C. RCPT GC RCP
75 CHECK PRINT CHKPR
999 INHIBIT
Key No. KEY KEY TEXT
123456

ER-A410/ER-A420 SERVICE (SRV) MODE
1 – 13
ER-A410/A420 KEY POSITION
[JOB#975] MAX. Number programming
[JOB#996, 998] RAM DATA BACKUP function
(ECR 0ECR; 01FD/02FD Protocol)
• Sending ECR RAM data
• Receiving ECR RAM data
*Baud-rate is decided by SRV#903_A. It is not support auto baud-rate
function.
[Signal connection chart]
X YYYY MRS
MAX. Number of Department 1 1-99 (2 digit) ER-A410 = 20,
ER-A420 = 6
MAX. Number of PLU Record 2 0-1800 (4 digit) 500
MAX. Number of PBLU Record 3 0-1000 (4 digit) 0
MAX. Number of Clerk 4 0-20 (2 digit) 20
MAX. Number of Cashier 5 1-20 (2 digit) 20
:FIXED KEY (NOT TO CHANGE)
:FIXED KEY (NOT TO CHANGE)
05 10 15 21 27 33 39 45 51 57 63 69 75 81
04 09 14 20 26 32 38 44 50 56 62 68 74 80
03 08 13 19 25 31 37 43 49 55 61 67 73 79
02 07 12 18 24 30 36 42 48 54 60 66 72 78
58 64 70 76 82
52464034282216
RECEIPT JOURNAL
01 06 11 17 23 29 35 41 47 53 59 65 71 77
ER-A410
RECEIPT JOURNAL
06 13 41 48 55 62 69 76 83 90 97 104 111 118
07 14 42 49 56 63 70 77 84 91 98 105 112 119
05 12 40 47 54 61 68 75 82 89 96 103 110 117
04 11 39 46 53 60 67 74 81 88 95 102 109 116
03 10 38 45 52 59 66 73 80 87 94 101 108 115
02 09 37 44 51 58 65 72 79 86 93 100 107 114
01 08 36
34
35
33
32
31
30
29
27
28
26
25
24
23
22
20
21
19
18
17
16
15 43 50 57 64 71 78 85 92 99 106 113
ER-A420
975XYYYY TL
996TL
0
SSR only
998TL SD:
RD:
DTR:
DSR:
RTS:
DCD:
CTS:
FG:
TRANSMITTED DATA
RECEIVED DATA
DATA TERMINAL READY
DATA SET READY
REQUEST TO SEND
DATA CARRIER DETECTOR
CLEAR TO SEND
FRAME GROUND
SD 2 SD
RD
CTS
RD
3
6
5
3
2
6
8
75
SG
1 FG
RTS
4
DCD
8
DTR 20
DSR
7
1
4
CTS
SG
RTS
DCD
DTR
DSR
25PIN D-S ECR UB 9PIN D-SUB
SD 3 SD
RD
CTS
RD
2
6
8
3
2
6
8
55
SG
RTS
7
DCD
1
DTR 4
DSR
7
1
4
CTS
SG
RTS
DCD
DTR
DSR
9PIN D-S ECRECR UB 9PIN D-SUB
FRAME GROUND is connected to
the shield of the cable.

ER-A410/ER-A420 SERVICE (SRV) MODE
1 – 14
Display during transmission
At the end of the job, one of the following messages is printed.
• Normal termination of a send operation
• Communication Error in a send operation
• Time-out in a send operation
• Normal termination of a receive operation
• Communication Error in a receive operation
• Data format Error in a receive operation
• Time-out in a receive operation
*All error message are fixed.
*ERROR CODE:
[JOB#985]
Euro symbol programming for TM-295
MRS = 0 (Space)
[JOB#986] ER-A410: MRS = “ *”
ER-A420: MRS = “ *”
Domestic currency symbol programming
Characters can be entered by using character keys or numeric keys.
Please refer to section 4.
This symbol is printed with (+) amount of domestic currency. The pro-
grammed characters is printed at left side of amout.
If some space characters are programmed at the left side of symbol
(like “ *”), they are not counted as the number of character of the cur-
rency symbol. (In case of “ DM”, the number of character is 2.)
[JOB#987] ER-A410: MRS = 0
ER-A420: MRS = 0
Text Changing (To Default text)
X: 0 = English text
1 = German text
2 = French text
3 = Spanish text
When this job is executed, below s are set as default data.
(a) Function text
(b) Each message text (LOGO, etc..)
[JOB#989]
Resetting of all counter and totalizer
*All counter, totalizer, all GTs, and all Z counter are reset.
#996 SEND OK JOB#, ERROR MESSAGE
#996 COM. ERROR 01 JOB#, ERROR, MESSAGE,
ERROR CODE
#996 TIME OUT JOB#, ERROR MESSAGE
#998 RECEIVE OK JOB#, ERROR MESSAGE
#998 COM. ERROR 01 JOB#, ERROR MESSAGE,
ERROR CODE
#998 DATA ERROR 15 JOB#, ERROR MESSAGE,
ERROR CODE
#998 TIME OUT JOB#, ERROR MESSAGE
01= ID No. error (ID No. in IDENQ is not correct.)
02= Parity error
03= Check sum error
04= Data size error
05= Hardware error
06= Power off error
07= Time out error
08 = DSR off error
11= Transmit data size error
12= Block sequence error (Irregular sequence No. has been
received.)
13= NAK code error (NAK code has been received.)
15= ECR TYPE error (Models of two ECR is different.)
996
SRV TEXT, MODE
JOB#, PACKET NO.
998
SRV TEXT, MODE
JOB#, PACKET NO.
X: 0 = Space
1 = Euro symbol
Ex) Case of “DM”:
DEPT.01 DM1.00
Programmed symbol
Ex) Case of “ DM”: (The currency symbol means “DM”)
DEPARTMENT01 DM10.00
Programmed symbol
985 A
0
TL
986 Character Key
(4 chara.)
Space
TL
987 XTL
0
989
TL

ER-A410/ER-A420 PROGRAM (PGM2/PGM1) MODE
2 – 1
CHAPTER 2. PROGRAM (PGM2/PGM1) MODE
1. READING OF THE PGM MODE PROGRAM
[JOB#1100] : DEPT reading
key operation
[JOB#2119] : DIRECT KEY READING REP.
Key operation
1100
XX
Start No. XX End No.
Single item
All
TL
Date/Time/Cashier code
Machine No./CC.No./Cashier name
Clerk code/Clerk name
(Printing at cashier & clerk system)
Start code/End code (Range)
JOB #/Mode title
Dept. code/Taxable/Sign. price
Text/Group
HALO limit.
Commission group
Function
programming
Tax status
003
Type of unit
price entry
Type
(SIF/SICS/Normal)
Item validation
Minus department
2119 TL
JOB #/Mode title
Key No./DEPT code or PLU code
Date/Time/Cashier code
Machine No./CC.No./Cashier name
Clerk code/Clerk name
(Printing at cashier & clerk system)
Inhibit

ER-A410/ER-A420 PROGRAM (PGM2/PGM1) MODE
2 – 2
[JOB#1200] : PLU reading
Key operation
[JOB#2220] : LINK PLU PRESET OR READING
Key operation
[JOB#2221]
Key operation
1200 Start No. End No.
Single item
XXXXXX XXXXXX
All
TL
JOB #/Mode title
PLU code/Associated dept. code
Type/Base Q'ty
Item label
Unit price (L2)
Tax status
Unit price
Start code/End code (Range)
Base q'ty
3Mode parameter
Commission group
Link PLU
Set PLU
2220 Start No. End No.
Single item
XXXXXX XXXXXX
All
TL
PLU code/Link PLU code
Start code/End code (Range)
JOB #/Mode title
(1 - 999999) Tied PLU code
(1 - 999999)
To program for another set PLU
Cancellation
To repeat up to 5 times
To program for the following PLU
PLU code TLST
ST
ST
2221
Start code/End code (Range)
JOB #/Mode title
PLU code/Link PLU code

ER-A410/ER-A420 PROGRAM (PGM2/PGM1) MODE
2 – 3
[JOB#2250] : PLU MIX & MACH PRESET OR READING
Key operation
[JOB#1300] : FUNCTION PRESET READING REP.
Key operation
2250 TL
JOB #/Model title
Table No.
Text/Discount amount/Trip level/
PLU code
1300
TL
JOB #/Model title
Function No./Text
Type/Sign.amount
/HALO
/RATE
/HALO
Item
SBTL
HALO
HALO
HALO
HALO
HALO
HALO
PGM
HALO
PGM
Currency Symbol for exchange
Tab, RATE

ER-A410/ER-A420 PROGRAM (PGM2/PGM1) MODE
2 – 4
[JOB#1400]
Key operation
[JOB#1500] : CASHIER READING REP.
Key operation
[JOB#2600] : READING OF OTHER
Key operation
Sentinel
HALO
RATE
1400 TL
Clerk no. /Clerk name/
Clerk code
JOB #/Mode title
1500
TL
No./Cashier name/Cashier code
PBLU/PGM/Drawer No.
JOB #/Mode title
2600
TL
Logo message
JOB #/Mode title
Optional feature selection
Slip initial feed/Slip max line
VP count/Differ ST feed
Optional feature
Stacked report
Serect code PGM1
Serect code X1/Z1
Serect code X2/Z2
RS-232C channel data
Hourly report format/start
hour
Drawer alarm
Drawer no. for the drawer
for foreign currency
Power saving
EURO time
EURO date
EURO function

ER-A410/ER-A420 PROGRAM (PGM2/PGM1) MODE
2 – 5
[JOB#2640] : SLIP TEXT PROGRAMMING READING
Key operation
[JOB#2700]
[JOB#2900] : AUTO KEY READING
Key operation
[JOB#2990] : THERMAL PRINTER REPORT
Key operation
[JOB#6110] : ONLINE PROGRAMMING READING REP.
Key operation
2640 TL
JOB #/Mode title
Message text
Text No./Message text
(There are printed the
available message only)
VP text
Slip text
Payee name for english check
Table No./RATE
Lowest taxable amount
JOB #/Mode title
2900
TL
JOB #/Mode title
(DEPT)
(PLU)
2990
TL
Printing density
Entered Value
Printing density example
JOB #/Mode title
6110 TL
JOB #/Mode title
