Sharp Docomo SH-05D User manual

’11.●
ɜġIf you lose your FOMA terminal or have it stolen, immediately take the steps necessary for suspending the use of the
FOMA terminal.
ɜġIf the FOMA terminal you purchased is damaged, bring your FOMA terminal to a repair counter specified by DOCOMO
after returning to Japan.
To prevent damage to the environment,
bring used battery packs to a docomo
service counter, a docomo agent or a
recycle center.
Sales:
Manufacturer:SHARP Corporation
Don’t forget your mobile phone… or your manners!
When using your mobile phone in a public place, don’t forget to show common courtesy and consideration for
others around you.
Universal number
international prefix
International call access code
for the country you stay
-81-3-6718-1414* (toll free)
-8005931-8600*
From land-line phones
From DOCOMO mobile phones
Failures encountered overseas
<Network Support and Operation Center>
<Universal number>
*You might be charged a domestic call fee according to the call rate for the
country you stay.
ɦ
For international call access codes for major countries and universal number
international prefix, refer to DOCOMO International Services website.
* You are charged a call fee to Japan when calling from a land-line phone, etc.
ɦIf you use SH-10C, you should dial the number [phone]
(to enter “+”, press and hold the “0” key for at least one second).
*You might be charged a domestic call fee according to the call rate for the
country you stay.
ɦ
For international call access codes for major countries and universal number
international prefix, refer to DOCOMO International Services website.
* You are charged a call fee to Japan when calling from a land-line phone, etc.
ɦIf you use SH-10C, you should dial the number [phone]
(to enter “+”, press and hold the “0” key for at least one second).
-8000120-0151*
Universal number
international prefix
-81-3-6832-6600* (toll free)
International call access code
for the country you stay
Loss or theft of FOMA terminal or
payment of cumulative cost overseas
<docomo Information Center>
From DOCOMO mobile phones
From land-line phones
<Universal number>
(available 24 hours a day)(available 24 hours a day)
ɦ
Unavailable from land-line phones, etc.
ɡFrom DOCOMO mobile phones
(In Japanese only)
ɦ Unavailable from land-line phones, etc.
(No prefix) 151(toll free)
ɡ
From DOCOMO mobile phones
(In Japanese only)
Repairs
(Business hours: 24 hours (open all year round))(Business hours: 9:00 a.m. to 8:00 p.m.)
ɦUnavailable from part of IP phones.
0120-800-000(toll free)
ɡFrom land-line phones
(In Japanese only)
0120-005-250(toll free)
ɦService available in: English, Portuguese, Chinese, Spanish, Korean.
(Business hours: 9:00 a.m. to 8:00 p.m. (open all year round))
ɦUnavailable from part of IP phones. (No prefix) 113 (toll free)
General Inquiries
<docomo Information Center>
ɜPlease confirm the phone number before you dial.
ɜ
For Applications or Repairs andAfter-Sales Service, please contact the above-mentioned information center or the docomo Shop etc. near you on
the NTT DOCOMO website or the i-mode site.
i-mode siteȁiMenuȁݖအ΍εȜΠ (user support)ȁΡ΋κΏοΛίġ
(docomo Shop) ɦIn Japanese only
NTT DOCOMO websiteȁhttp://www.nttdocomo.co.jp/english/
ɦUnavailable from part of IP phones.
ɡFrom land-line phones
(In Japanese only)
0120-800-000(toll free)
INSTRUCTION MANUAL
SH-10C
’11.5 (1st Edition)
11E SM118
’11.5
1
1
t
,
Sa
Ma
1

109
ఈ
Use only the battery packs and adapters specified
by NTT DOCOMO for use with the FOMA terminal.
May cause fires, burns, bodily injury or electric shock.
Do not throw the battery pack into a fire.
The battery pack may catch fire, explode, overheat or
leak.
Do not dispose of used battery packs in ordinary
garbage.
May cause fires or damage to the environment. Place
tape over the terminals to insulate unnecessary battery
packs, and take them to a docomo Shop, retailer or
institution that handles used batteries in your area.
Avoid using the handset in extremely high or low
temperatures.
Use the FOMA terminal within the range of a
temperature between 5°C and 40°C (for temperatures
of 36°C or higher, such as in a room with a bath, limit
usage to a short period of time) and a humidity between
45% and 85%.
Charge battery in areas where ambient temperature
is between 5°C and 35°C.
1Set docomo mini UIM card into
docomo mini UIM card slot with
the IC (gold) side turned down
(1)
Insert docomo mini UIM card
securely (2).
Quick Manual
CAUTION
Before Using
Inserting docomo mini UIM card
Note that pulling forcibly or adding forces on the
lever may damage it.
Note that inserting or removing the docomo mini
UIM card forcibly may damage the docomo mini
UIM card.
Notch
IC (gold)
Notch
2

110 ఈ
Perform with the FOMA terminal turned off and
closed while holding with your both hands.
The battery pack is not waterproof/dust-proof.
1Slide the back cover lever in the direction of the
arrow (1) to unlock and remove the back cover
(2)
The FOMA terminal has a slot to remove the
back cover. Securely hold the FOMA terminal as
shown in the illustration to prevent excessive
force on the back cover and hook a nail on the
slot and remove the back cover upward.
2Attach the battery
pack
Turn the recycle
mark side of the
battery pack up,
match tabs and
attach the
battery pack.
3Insert the tab of the top of the back cover into
the FOMA terminal slot (1), attach it in the
direction of the arrow (2) and securely push
down with both hands (3)
The back of the back cover has also eight tabs to
insert the back cover. Securely push tab areas
down with both hands so that gaps are not left
between the FOMA terminal and the back cover.
4Slide the back cover lever in the direction of the
arrow (4) to lock
Attaching battery pack
Slot
Tabs
With a recycle mark
side up
Using unnecessary force when attaching or
removing the battery pack may damage the
connector terminal for the battery pack (charger
terminal) on the FOMA terminal.
Back cover
Slot
Tab
Securely push
tab areas down
with both hands
Lever
3

31
Basic Operation
Read the user’s guide of FOMA AC Adapter 01/
02 (sold separately).
1Open the external connector
terminal cover and insert the AC
adapter horizontally into the
external connector terminal (1)
2When inserting the AC adapter
power plug into an outlet, charge
alert is heard, charging LED
illuminates, and charging starts
3When charge alert is heard and
charging LED turns off, charging is
complete
When removing the connector, always hold
the release buttons on both sides (1) and
unplug it horizontally (2).
1H(for at least 2 seconds)
Stand-by display appears when initial
settings are complete.
Press Hfor at least 2 seconds to turn the
power off.
1In the Normal menu, [ུఘ୭೰]
(Setting)/[໲লນা/වႁ] (Text
display/input)/[Select
language]/[English]
Charging by using AC adapter
Charging LED
Connector (with the arrow
side up)
External connector
terminal cover
External
connector
terminal
100V AC
outlet
Do not forcibly insert or remove. May cause
damage to the external connector terminal and
the connector or result in malfunction.
Turning power on
Changing screen display to
English
Release buttons
4

113
ఈ
Part Names and Functions
1Earpiece
2Air vent
3Main display
4z: MENU/Operation
guidance key
5m: Mail/Operation guidance
key
6s: Start/Hands-free key
71to 9, *, 0and #:
Dial/Character entry keys
8$: Multi/VeilView key
9wt: Multi-guide key
aC: Camera/Operation
guidance key
bi(,): i-mode/Operation
guidance key
cc(J): i-Channel/Clear key
dH: Power/End key
ey: Bright/TV key
fMouthpiece/Microphone
gExternal connector terminal
hSub display
iCalled/Charging LED
jmicroSD Card slot
kSpeaker
l&: Side key
mStrap hole
nFOMA antenna
oCamera
pInfrared port
qBack cover
r@mark
sBluetooth/Wi-Fi antenna
tBack cover lever
Key illustrations may look different from actual keys.
5

114 ఈ
Main icons
1H(for at least 2 seconds)
Press Hfor at least 2 seconds to turn the power
off.
1In the Normal menu, [
ུఘ୭೰
] (Setting)/[
໲লນ
া
/
වႁ
] (Text display/input)/[Select
language]/[English]
1[Date and time setting]/set the date and time
2[Password]/register a terminal security code
3[Keypad sound]/set the keypad sound
4[Text size]/set the font size collectively
5C
1In the Normal menu, [Profile]
Viewing display
Battery level
bbbb
(High Low)
Signal status
bbb
(
Strong Weak )
When [ ] appears, the handset is
outside the service area or in a
place with no signal.
i-mode
Wi-Fi
Ir communication
Hands-free
i-mode mail/SMS/Area Mail/
Information received
i-Dppli
Alarm/Schedule
Software update
microSD Card
Public mode (Drive mode)
Silent/Vibrator
Manner mode
Keypad dial lock
Record message
VeilView
Icon display area
docomo mini UIM card error
Self mode
Music&Video Channel program
reservation
Brightmode
3G
Bluetooth
Music&Video Channel
Personal data lock
1Seg recording
USB connection
Basic Operations
Turning power on
Changing screen display to English
Making initial setting
Checking your own phone number
6

115
ఈ

Switching entry modes
1In the character entry screen, m
2Select the entry mode

Entering characters
Ex.) When entering “ഩდ”
1In the character entry screen, enter “

”
: 4(four times)/*(once)/0(three
times)/r/0(once)
To enter multiple characters assigned to the
same key: Enter a character/r/enter a
character
2C
3t

Entering pictograms/symbols
1In the character entry screen, C
To switch between pictogram/Deco-mail
pictogram/Deco-mail picture: C
To switch between single- and double-byte
symbols: z
2Select a pictogram/symbol

Entering emoticons
1In the character entry screen, z/[Pict/Symbol/
Smiley]/[Smiley]
For a mail message: In the character entry
screen, z/[Quote phrase/data]/[Pict/Symbol/
Smiley]/[Smiley]
2Select a category/select an emoticon
1In the Normal menu, [Setting]/[Sound/
Vibration/Manner]/[Ring tone]
2Select an item
;[Call ring tone]
;[Videophone]
;[Mail]/select an item
3Set each item/C
1In the Normal menu, [Setting]/[Lock/
Security]/[Change security code]/enter the
current terminal security code
2Enter the new terminal security code
3Enter the new terminal security code again
4C
1In stand-by, i/[
ݖအ΍εȜΠ
] (user
support)/[
ڎ୭೰
(
ږ෇Ȇ་ࢵȆ၌ဥ
)] (settings
(check/change/use))/[
ΥΛΠχȜ·ճબ๔࣢་
ࢵ
] (change network security code)
1In stand-by, i/[English]/[Options]/
[Change i-mode Password]
1In the Normal menu, [Setting]/[Lock/
Security]/[UIM setting]
2Select an item
;[Change PIN1 code]/enter the terminal security
code/enter the current PIN1 code/enter the
new PIN1 code/enter the new PIN1 code
again/C
;[Change PIN2 code]/enter the terminal security
code/enter the current PIN2 code/enter the
new PIN2 code/enter the new PIN2 code
again/C
;[PIN1 entry ON/OFF]/[ON]/enter the PIN1
code
Character entry
Changing ring tone
Lock/Security
Changing terminal security code
Changing network security code
Changing i-mode password
Setting PIN code
7

116 ఈ

All lock
1In the Normal menu, [Setting]/[Lock/
Security]/[Lock settings]/[All lock]/enter the
terminal security code

Omakase Lock
Omakase Lock is a service to lock the personal data in
case of loss, etc. by only your request to DOCOMO via
phone.
Refer to “Mobile Phone User’s Guide [Basic Usage]”
for details on Omakase Lock.
Set/Release Omakase Lock
s0120-524-360
ȁ
Office hours: 24 hours (in
Japanese only) (open all year round)
ɦUnavailable from part of IP phones.
ɦOmakase Lock can also be set/released from the
My docomo website using PCs.

Self mode
1In the Normal menu, [Setting]/[Other setting]/
[Self mode]/select the setting/[Yes]

Personal data lock
1In the Normal menu, [Setting]/[Lock/
Security]/[Lock settings]/[Personal data
lock]/enter the terminal security code/select
the setting

Keypad dial lock
1In the Normal menu, [Setting]/[Lock/
Security]/[Keypad dial lock]/enter the
terminal security code/select the setting

Auto-key lock
1In the Normal menu, [Setting]/[Lock/
Security]/[Lock settings]/[Auto-key lock]/
select the lock type/enter the terminal security
code/set each item/C

Setting response to a call with no caller ID
1In the Normal menu, [Setting]/[Lock/
Security]/[Call rejection setting]
2Select an item
;[Anonymous]/enter the terminal security code
/set each item/C
;[Payphone]/enter the terminal security code/
set each item/C
;[Unavailable]/enter the terminal security code
/set each item/C

Rejecting a call from a caller unset in phonebook
1In the Normal menu, [Setting]/[Lock/
Security]/[Call rejection setting]
2[Unregistered caller]/enter the terminal
security code/select the setting
1In stand-by, enter a phone number
2s(Phone)/C(V.phone)
3Hto end the call
1When a call is received, the ring tone sounds
and the called LED flashes
2s
3Hto end the call
1In the Normal menu, [TEL function]/[Dialed/
Received calls]/[Received calls]/[Redial]
2Point the cursor to the history
3s(Phone)/i(V.phone)
Various lock functions Incoming call restriction
Voice/Videophone Calls
Making a voice/videophone call
Receiving a voice/videophone call
Making a call with redials/received
calls
8

117
ఈ

Making a call to outside the country you stay in
(including Japan)
1In stand-by, enter “+” (0for at least 1 second),
country code, area code (city code) and other
party’s phone number
When the area code (city code) begins with “0”,
omit the “0” when dialing (Include “0” when
making a call to some countries or regions such
as Italy).
2s(Phone)/C(V.phone)

Making a call in country you stay
1In stand-by, enter a phone number
2s(Phone)/C(V.phone)

Making a call to WORLD WING user overseas
When you make a call to a WORLD WING user
overseas, you make a call as an international call to
Japan regardless of your country of stay.
1In stand-by, enter “+” (0for at least 1 second),
country code “81” (Japan) and the other party’s
mobile phone number excluding the first “0”
2s(Phone)/C(V.phone)
1In stand-by, m/[Compose message]
2[<No address>]/enter an address
3Select the SUB field/enter a subject
4[Message]/enter a message
5C
1In stand-by, m/[Check new mail/message]
1In the received mail details screen, z/[Reply/
Forward]
2Select the reply method
3Compose and send a mail
1In stand-by, m
2Select a box
3Select a mail
1In the Normal menu, [TEL function]/
[Phonebook]/[Add to phonebook]/[UIM
operation]
2Set each item/C
Using overseas Mail
Sending i-mode mail
Checking new i-mode mail
Replying to i-mode mail
Displaying a mail in Inbox/Outbox/
Unsent box
Phonebook
Adding phonebook entries
9

118 ఈ
1In stand-by, C
2t/&
3t/&
1In the Normal menu, [CAMERA/TV/MUSIC]/
[Camera]/[Movie shooting]
2t/&
3t/&to end shooting
4[Save]
1In the Normal menu, [Data box]/[My picture]
2[Camera] folder/select a still picture
1In the Normal menu, [Data box]/[i-motion/
Movie]
2[Camera] folder/select a moving picture
1In the Normal menu, [CAMERA/TV/MUSIC]/
[1Seg]/[Channel setting]
When the confirmation screen appears: [Yes]/
proceed to step 3
2z/[Create]
3Select the registration method
;[Use preset]
;[Auto setting]/[Yes]
ƦIf you do not select an area: [No]/proceed to
step 6
4Select an area
5Select a prefecture/district
6[Yes]
1In the Normal menu, [CAMERA/TV/MUSIC]/
[1Seg]/[Activate 1Seg]
1In the Normal menu, [Data box]/[1Seg]
2[Video] folder/select a video
The Music&Video Channel service is provided in
Japanese.
1In the Normal menu, [CAMERA/TV/MUSIC]/
[Music&Video Channel]
2Select a program
1In the Normal menu, [Data box]/[MUSIC]
2Select music data
Voice Mail Service is a paid option (monthly fees apply)
that requires subscription.
1In the Normal menu, [TEL function]/[Voice mail
service]
2[Activate]/[Yes]/[Yes]/enter the ringing
time/[OK]
Call waiting service is a paid option (monthly fees apply)
that requires subscription.
1In the Normal menu, [TEL function]/[Other
network service]/[Call waiting]
2[Activate]/[Yes]/[OK]
Camera
Shooting still pictures
Shooting moving pictures
Displaying shot still pictures
Playing shot moving pictures
Watching 1Seg
Setting channels
Watching 1Seg
Playing recorded videos
Music Playback
Using Music&Video Channel
Using MUSIC Player
Network Services
Setting Voice Mail Service
Setting Call waiting service
10

119
ఈ
Call Forwarding Service is a free option (no monthly
fees) that requires subscription.
1In the Normal menu, [TEL function]/[Other
network service]/[Call forwarding]
2[Activate]/[Yes]/[Yes]/enter a phone
number/C/[Yes]/enter the ringing time/
[OK]
The Bluetooth word mark and logos are owned by
the Bluetooth SIG, INC. and any use of such marks
by NTT DOCOMO, INC. is under license.
Other trademarks and trade names are those of their
respective owners.
Switch the other party’s Bluetooth device to the
registration stand-by status in advance.
1In the Normal menu, [Tool]/[Bluetooth]/[List/
cnnct/discnct]
The device list screen appears when registered
device exists. Press Cand proceed to step 3.
2[Yes]
3Point the cursor to the Bluetooth device to
register/z/[Register Devices]
4Enter the Bluetooth passkey
1In the Normal menu, [Tool]/[Bluetooth]/[List/
cnnct/discnct]
2Select a Bluetooth device to connect to
Battery Pack SH34
FOMA AC Adapter 01 for Global use
FOMA AC Adapter 01/02
Wireless Charger SH01
* Approximate value
Setting Call Forwarding Service
Bluetooth function
Registering Bluetooth devices on
FOMA terminal
Connecting with Bluetooth devices
General Notes
Options and related devices
Main specifications
Size
110 (H) × 50 (W) ×
17.3 (D) mm (18.1 mm
at thickest point) (when
folded)*
Weight 132 Ũ(with battery
pack attached)*
Continuous
talk time FOMA/3G Voice call: 270 min*
Videophone: 130 min*
Continuous
stand-by
time FOMA/3G At rest : 770 hr*
Charge
time
FOMA AC
Adapter 01/02 ɜɜ min*
FOMA DC
Adapter 01/02 ɜɜ min*
Wireless
Charger SH01 220 min*
11

79
More Convenient
To register a Bluetooth device, the Bluetooth
passkey must be entered. Before starting the
registration, enter the same user-specified 4- to
16-digit number on the FOMA terminal and the
other party’s Bluetooth device.
Switch the other party’s Bluetooth device to the
registration stand-by status in advance.
1In the Normal menu, [Tool]/
[Bluetooth]/[List/cnnct/discnct]
The device list screen appears when
registered device exists. Press Cand
proceed to step 3.
2[Yes]
3Point the cursor to the Bluetooth
device to register/z/[Register
Devices]
4Enter the Bluetooth passkey
1In the Normal menu, [Tool]/
[Bluetooth]/[List/cnnct/discnct]
2Select a Bluetooth device to
connect to
The FOMA terminal supports Wi-Fi and
allows you to connect to the Internet using
Full Browser via the access point at home or
public wireless LAN service.
Set the FOMA terminal to the access point (base
unit) and connect the Wi-Fi compatible device (sub
unit) to use services such as playing games.
Also, use the FOMA terminal as an access point to
connect Wi-Fi compatible devices within local area
network.
An access point mode is not available overseas.
The Internet service provider, compatible with
Wi-Fi connection such as mopera U, is used for
an access point mode.
Packet communication charges when using an
access point mode are same as when
connecting a PC or PDA, etc. Note that making
a communication with large-volume data will
lead to higher communication charges.
Registering Bluetooth devices on
FOMA terminal
Entering the Bluetooth passkey may not be
required depending on the other party’s
Bluetooth device.
Connecting with Bluetooth devices
Using Wi-Fi
IEEE 802.11n
5.2GHz/5.3GHz/5.6GHz (W52/W53/W56) is
not supported.
MIMO (Multiple Input Multiple Output) is not
supported.
40MHz radio-frequency bandwidth system
(HT40) is not supported.
Using access point mode
11
12

80 More Convenient
C
Setting use of access point mode
1In the Normal menu, [Tool]/
[Wi-Fi]/[AP mode (base unit)]
The access point mode screen appears.
2Select an item
;[Start AP mode]/[Start AP mode (local)]
;[Cnncted dev(sub) list]/select the Wi-Fi
compatible device/set each item/C
;[Stop AP mode]/[Yes]
C
Setting access point mode
1In the access point mode screen,
i
2Select an item
;[Wireless setting]/enter the terminal
security code/set each item/C
;[Host (APN) list]
;[External device list]/select a Wi-Fi
compatible device/set each item/C
;[Set local transmission]/select the
setting
;[Reset settings]/enter the terminal
security code/[Yes]
You can connect to the access point at home or
public wireless LAN service via Wi-Fi and use the
Internet.
C
Setting use of client mode
1In the Normal menu, [Tool]/
[Wi-Fi]/[Client mode (sub)]
2Select an item
;[Connection(automatic)]
;[Register new host]/select the
registration method
;[Host list]/point the cursor to the
access point/C/set each item/C
;[Disconnect/Stop]
Display an electronic compass to check the
direction that the FOMA terminal is headed to.
1In the Normal menu, [Tool]/
[Compass]
Using client mode
Checking azimuth
12
13

84 More Convenient
Example: Phonebook
1In stand-by, p
2Point the cursor to the name/
z/[Send data]/
[iC transmission]
3Select the sending method
;[Send]
;[Send all]/enter the terminal security
code/enter the authentication
password
4[Yes]
5Place the bmark on that of the
other party’s FOMA terminal
1In stand-by, place the bmark on
that of the other party’s FOMA
terminal
2[Yes]
By connecting the FOMA terminal and your
PC, exchange WMA files and images in the
microSD Card. In addition, connect to the
Internet and perform data communication.
FOMA USB Cable with Charge Function 02
(sold separately) or FOMA USB Cable (sold
separately) is required.
For a data communication, installation of the
“FOMA communication configuration file”
(Driver) is required.
Refer to “Manual for PC Connection” for details.
You can download “FOMA communication
configuration file” and “Manual for PC
Connection” from the DOCOMO website.
http://www.nttdocomo.co.jp/support/ (in
Japanese only)
“DOCOMO Connection Manager” is a software
which is convenient for using data communication
of DOCOMO. Easily set the PC depending on the
subscription. In addition, use the charge counter
function to check the approximate amounts of data
communication or usage fee.
Refer to the DOCOMO website for details.
http://www.nttdocomo.co.jp/support/utilization/
application/service/connection_manager/ (in
Japanese only)
Sending data
Receiving data
Connecting to PC
DOCOMO Connection Manager
14
14

120 ఈ
This model SH-05D mobile phone complies with
Japanese technical regulations and international
guidelines regarding exposure to radio waves.
This mobile phone was designed in observance of
Japanese technical regulations regarding exposure to
radio waves (*1) and limits to exposure to radio waves
recommended by a set of equivalent international
guidelines. This set of international guidelines was set
out by the International Commission on Non-Ionizing
Radiation Protection (ICNIRP), which is in collaboration
with the World Health Organization (WHO), and the
permissible limits include a substantial safety margin
designed to assure the safety of all persons, regardless
of age and health condition.
The technical regulations and international guidelines
set out limits for radio waves as the Specific Absorption
Rate, or SAR, which is the value of absorbed energy in
any 10 grams of tissue over a 6-minute period. The
SAR limit for mobile phones is 2.0 W/kŨ. The highest
SAR value for this mobile phone when tested for use at
the ear is ɜɜ W/kŨ. There may be slight differences
between the SAR levels for each product, but they all
satisfy the limit.
The actual SAR of this mobile phone while operating
can be well below that indicated above. This is due to
automatic changes to the power level of the device to
ensure it only uses the minimum required to reach the
network. Therefore in general, the closer you are to a
base station, the lower the power output of the device.
This mobile phone can be used in positions other than
against your ear. This mobile phone satisfies the
international guidelines when used with a carrying case
or a wearable accessory approved by NTT DOCOMO,
INC. (*2). In case you are not using the approved
accessory, please use a product that does not contain
any metals, and one that positions the mobile phone at
least 1.5 cm away from your body.
The World Health Organization has stated that “a large
number of studies have been performed over the last
two decades to assess whether mobile phones pose a
potential health risk. To date, no adverse health effects
have been established as being caused by mobile
phone use.”
Please refer to the WHO website if you would like more
detailed information.
(http://www.who.int/docstore/peh-emf/publications/
facts_press/fact_english.htm)
Please refer to the websites listed below if you would
like more detailed information regarding SAR.
Specific Absorption Rate (SAR) of
Mobile Phone
Ministry of Internal Affairs and Communications
Website:
(http://www.tele.soumu.go.jp/e/sys/ele/index.htm)
Association of Radio Industries and Businesses
Website:
(http://www.arib-emf.org/index02.html)(in Japanese
only)
NTT DOCOMO, INC. Website:
(http://www.nttdocomo.co.jp/english/product/sar/)
SHARP Corporation Website:
(http://www.sharp.co.jp/products/menu/phone/cellular/
sar/index.html)
(in Japanese only)
*1 Technical regulations are defined by the Ministerial
Ordinance Related to Radio Law (Article 14-2 of
Radio Equipment Regulations).
*2 Regarding the method of measuring SAR when
using mobile phones in positions other than against
the ear, international standards (IEC62209-2) were
set in March of 2010. On the other hand, technical
regulation is currently being deliberated on by
national council (As of January, 2012).
t
h
e
ea
r i
s
There
ma
15

121
ఈ
* The tests are carried out in accordance with
international guidelines for testing.
Information to User
This equipment has been tested and found to comply
with the limits of a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not
occur in a particular installation; if this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
European RF Exposure Information
Your mobile device is a radio transmitter and receiver. It
is designed not to exceed the limits for exposure to
radio waves recommended by international guidelines.
These guidelines were developed by the independent
scientific organization ICNIRP and include safety
margins designed to assure the protection of all
persons, regardless of age and health.
The guidelines use a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit for
mobile devices is 2 W/kŨand the highest SAR value for
this device when tested at the ear was ɜɜ W/kŨ*.
As SAR is measured utilizing the devices highest
transmitting power the actual SAR of this device while
operating is typically below that indicated above. This is
due to automatic changes to the power level of the
device to ensure it only uses the minimum level
required to reach the network.
The World Health Organization has stated that present
scientific information does not indicate the need for any
special precautions for the use of mobile devices. They
note that if you want to reduce your exposure then you
can do so by limiting the length of calls or using a
hands-free device to keep the mobile phone away from
the head.
Declaration of Conformity
This declaration relates to the handset only.
In some countries/regions, such as France, there are
restrictions on the use of Wi-Fi. If you intend to use
Wi-Fi on the handset abroad, check the local laws
and regulations beforehand.
FCC Notice
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by
the manufacturer responsible for compliance could
void the user’s authority to operate the equipment.
Hereby, Sharp Telecommunications of Europe
Ltd, declares that this SH-05D is in compliance
with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
A copy of the original declaration of conformity
can be found at the following Internet address:
(http://www.sharp.co.jp/k-tai/)(in Japanese only)
s
16

122 ఈ
1. Reorient/relocate the receiving antenna.
2. Increase the separation between the equipment and
receiver.
3. Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio/TV
technician for help.
FCC RF Exposure Information
Your handset is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF)
energy set by the Federal Communications
Commission of the U.S. Government.
The guidelines are based on standards that were
developed by independent scientific organizations
through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety
margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless handsets employs
a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit set by the FCC
is 1.6 W/kŨ.
The tests are performed in positions and locations (e.g.,
at the ear and worn on the body) as required by the
FCC for each model. The highest SAR value for this
model handset when tested for use at the ear is ɜɜ
W/kŨand when worn on the body, as described in this
user guide, is ɜɜ W/kŨ.
Body-worn Operation; This device was tested for typical
body-worn operations with the back of the handset kept
1.5 cm from the body. To maintain compliance with
FCC RF exposure requirements, use accessories that
maintain a 1.5 cm separation distance between the
user’s body and the back of the handset. The use of
beltclips, holsters and similar accessories should not
contain metallic components in its assembly.
The use of accessories that do not satisfy these
requirements may not comply with FCC RF exposure
requirements, and should be avoided.
The FCC has granted an Equipment Authorization for
this model handset with all reported SAR levels
evaluated as in compliance with the FCC RF emission
guidelines. SAR information on this model handset is on
file with the FCC and can be found under the Display
Grant section of (http://www.fcc.gov/oet/ea/fccid/)after
searching on FCC ID APYHRO00ɜɜ.
Additional information on Specific Absorption Rates
(SAR) can be found on the Cellular
Telecommunications & Internet Association (CTIA)
Website at (http://www.ctia.org/).
(Business hours: 9:00 a.m. to 8:00 p.m.)
s0120-005-250 (toll free)
ɦService available in: English, Portuguese, Chinese,
Spanish, Korean.
ɦUnavailable from part of IP phones.
(Business hours: 9:00 a.m. to 8:00 p.m. (open all year
round))
From DOCOMO mobile phones
(In Japanese only)
r(No prefix) 151 (toll free)
ɦUnavailable from land-line phones, etc.
From land-line phones
(In Japanese only)
s0120-800-000 (toll free)
ɦUnavailable from part of IP phones.
Please confirm the phone number before you dial.
Inquiries
General inquiries
<docomo Information Center>
ea
r
i
s
is
17

123
ఈ
(Business hours: 24 hours (open all year round))
From DOCOMO mobile phones
(In Japanese only)
r(No prefix) 113 (toll free)
ɦUnavailable from land-line phones, etc.
From land-line phones
(In Japanese only)
s0120-800-000 (toll free)
ɦUnavailable from part of IP phones.
Please confirm the phone number before you dial.
For Applications or Repairs and After-Sales Service,
please contact the above-mentioned information
center or the docomo Shop etc. near you on the NTT
DOCOMO website or the i-mode site.
NTT DOCOMO website:
(http://www.nttdocomo.co.jp/english/)
i-mode site: iMenu/ݖအ΍εȜΠ (user
support)/Ρ΋κΏοΛί (docomo Shop) (In
Japanese only)
(available 24 hours a day)
From DOCOMO mobile phones
* You are charged a call fee to Japan when calling
from a land-line phone, etc.
ɦIf you use SH-05D, you should dial the number
[phone]
(to enter “+”, press the “0” key for at least 1
second).
From land-line phones
<Universal number>
* You might be charged a domestic call fee
according to the call rate for the country you
stay.
ɦFor international call access codes for major
countries and universal number international prefix,
refer to DOCOMO International Services website.
(available 24 hours a day)
From DOCOMO mobile phones
* You are charged a call fee to Japan when
calling from a land-line phone, etc.
ɦIf you use SH-05D, you should dial the number
[phone]
(to enter “+”, press the “0” key for at least 1
second).
From land-line phones
<Universal number>
* You might be charged a domestic call fee
according to the call rate for the country you
stay.
ɦFor international call access codes for major
countries and universal number international prefix,
refer to DOCOMO International Services website.
If you lose your FOMA terminal or have it stolen,
immediately take the steps necessary for
suspending the use of the FOMA terminal.
If the FOMA terminal you purchased is damaged,
bring your FOMA terminal to a repair counter
specified by DOCOMO after returning to Japan.
Repairs
Loss or theft of FOMA terminal or
payment of cumulative cost overseas
<docomo Information Center>
International call access
code for the country you
stay
-81-3-6832-6600*
(toll free)
Universal number
international prefix -8000120-0151*
Failures encountered overseas
<Network Support and Operation Center>
International call access
code for the country you
stay
-81-3-6718-1414*
(toll free)
Universal number
international prefix -8005931-8600*
18

109
ఈ
Use only the battery packs and adapters specified
by NTT DOCOMO for use with the FOMA terminal.
May cause fires, burns, bodily injury or electric shock.
Do not throw the battery pack into a fire.
The battery pack may catch fire, explode, overheat or
leak.
Do not dispose of used battery packs in ordinary
garbage.
May cause fires or damage to the environment. Place
tape over the terminals to insulate unnecessary battery
packs, and take them to a docomo Shop, retailer or
institution that handles used batteries in your area.
Avoid using the handset in extremely high or low
temperatures.
Use the FOMA terminal within the range of a
temperature between 5°C and 40°C (for temperatures
of 36°C or higher, such as in a room with a bath, limit
usage to a short period of time) and a humidity between
45% and 85%.
Charge battery in areas where ambient temperature
is between 5°C and 35°C.
1Set docomo mini UIM card into
docomo mini UIM card slot with
the IC (gold) side turned down
(1)
Insert docomo mini UIM card
securely (2).
Quick Manual
CAUTION
Before Using
Inserting docomo mini UIM card
Note that pulling forcibly or adding forces on the
lever may damage it.
Note that inserting or removing the docomo mini
UIM card forcibly may damage the docomo mini
UIM card.
Notch
IC (gold)
Notch
2
19

6Introduction
nStrap hole
oFOMA antenna*
pCamera
Use to shoot still pictures or moving pictures.
qInfrared port (nP. 80)
rBack cover (nP. 23)
s@mark
When charging, place the FOMA terminal
slowly so that @mark of the wireless charger
faces that of the FOMA terminal.
tBluetooth/Wi-Fi antenna*
uBack cover lever (nP. 23)
* The antenna is built in the terminal. Covering the
antenna area with your hand may influence the
quality.
Before use, read these “Precautions” carefully and
use your FOMA terminal properly.
Keep this manual in a safe place for future
reference.
These precautions contain information intended to
prevent bodily injury to the user and to surrounding
people, as well as damage to property, and must be
observed at all times.
The following symbols indicate the different
degrees of injury or damage that may occur if
information provided is not observed and the
FOMA terminal is used improperly.
The 1Seg antenna is built in the terminal. The
whole FOMA terminal works as the antenna.
Precautions (Always follow
these directions)
Danger
This symbol indicates
that “death or serious
bodily injury may
directly and
immediately result
from improper use”.
Warning
This symbol indicates
that “death or serious
bodily injury may
result from improper
use”.
Caution
This symbol indicates
that “minor injury and/
or property damage
may result from
improper use”.
20
