ENGLISH
MODEL
HT-SB603
SOUND BAR HOME THEATER SYSTEM
OPERATION MANUAL
Thank you for purchasing this SHARP product. To obtain the best performance from this product, please
read this manual carefully. It will guide you in operating your SHARP product.
Note:
This product is recommended for 60" or larger flat panel TV (LED, LCD and Plasma).
HT-SB603 consisting of Sound Bar Home Theater System (Sound Bar) and CP-SW603 (Active Subwoofer
System).
TINSEA526AWZZ 18C R KI 1
B
arcodesof
t
http://www.barcodesoft.com
Barcode Symbology: Code 93; Font Facename: Code93
M
H
r
Data To Encode: TINSEA526AWZZ
Point Size 8 :
*TINSEA526AWZZ5M*|
Point Size 10 :
*TINSEA526AWZZ5M*|
Point Size 12 : *TINSEA526AWZZ5M*|
Point Size 14 :
*TINSEA526AWZZ5M*|
●This audio system supports NFC-enabled devices with Android 4.1, Jelly Bean and higher.
●For device with a lower Android version, refer the operation manual of the device for recommended app (application).

E-1
Accessories
The following accessories are included.
Remote Control x 1 Subwoofer Stand x 2 IR Transmitter x 1 HDMI Cable x 1 Wall Mount Angle x 2
Pattern Paper x 1 “AA” size battery (UM-3, R6,
HP-7 or similar) x 2 NFC tag x 1 Velcro tape (hook type) x 1 Velcro tape (loop type) x 2
Manufactured under license from Dolby Laboratories.
Dolby, Dolby Audio, and the double-D symbol are
trademarks of Dolby Laboratories.
The terms HDMI and HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing LLC in the
United States and other countries.
The Bluetooth
®
word mark and logos are registered
trademarks owned by the Bluetooth SIG, Inc. and
any use of such marks by SHARP is under license.
Other trademarks and trade names are those of their
respective owners.
The N-Mark is a trademark or registered trademark
of NFC Forum, Inc. in the United States and in other
countries.
Supply of this product does not convey a license nor imply any
right to distribute content created with this product in revenue-
generating broadcast systems (terrestrial, satellite, cable and/
or other distribution channels), revenue-generating streaming
applications (via Internet, intranets and/or other networks), other
revenue-generating content distribution systems (pay-audio or
audio-on-demand applications and the like) or on revenue-gen-
erating physical media (compact discs, digital versatile discs,
semiconductor chips, hard drives, memory cards and the like).
An independent license for such use is required. For details,
please visit http://mp3licensing.com
MPEG Layer-3 audio coding technology licensed from Fraun-
hofer IIS and Thomson.
Warning:
●When the ON/STANDBY button is set at STANDBY po-
sition, mains voltage is still present inside the unit.
When the ON/STANDBY button is set at STANDBY
position, the unit may be brought into operation by the
timer mode or remote control.
●This unit contains no user serviceable parts. Never re-
move covers unless qualied to do so. This unit con-
tains dangerous voltages, always remove mains plug
from the socket before any service operation and when
not in use for a long period.
●To prevent re or shock hazard, do not expose this ap-
pliance to dripping or splashing. No objects lled with
liquids, such as vases, shall be placed on the appa-
ratus.
Special Notes

E-2
Precautions
General
zPlease ensure that the equipment is positioned in a
well ventilated area and ensure that there is a free
space along the sides, top and back of the equipment
as below.
10 cm
10 cm
10 cm
10 cm
10
cm
10 cm
0 cm
10 cm
Table/floor
10 cm
1.5 cm
Wall mount
bracket
10 cm
10 cm
10 cm
Wall mount
zUse the unit on a firm, level surface free from vibration.
zKeep the unit away from direct sunlight, strong
magnetic fields, excessive dust, humidity and
electronic/electrical equipment (home computers,
facsimiles, etc.) which generate electrical noise.
zDo not place anything on top of the unit.
zDo not expose the unit to moisture, to temperatures
higher than 60°C (140°F) or to extremely low
temperatures.
zIf the unit does not work properly, unplug and plug it in
again. Then turn on the unit.
zIn case of an electrical storm, unplug the unit for
safety.
zHold the AC power plug by the head when removing it
from the wall socket, as pulling the lead can damage
internal wires.
zThe AC power plug is used as a disconnect device
and shall always remain readily operable.
zDo not remove the outer cover, as this may result
in electric shock. Refer internal service to your
local SHARP service facility.
zThis unit should only be used within the range of 5°C -
35°C (41°F - 95°F).
zSHARP are not responsible for damage due to
improper use. Refer all servicing to a SHARP
authorised service centre.
Warnings:
zThe voltage used must be the same as that specified
on this unit. Using a higher voltage is dangerous and
may result in a fire or other type of accident causing
damage. SHARP will not be held responsible for any
damage resulting from such usage.
zIn case of repairing, please bring the entire system set
to the service centre.
Volume control
The sound level at a given volume setting depends on
speaker efficiency, location and various other factors.
It is advisable to avoid exposure to high volume levels,
which occurs while turning the unit on with the volume
control setting up high, or while continually listening at
high volumes.
Controls and indicators
Sound Bar Front Panel
1
4 5 63 987 10 11
2
1. Left Channel Speakers
2. Right Channel Speakers
3. On/Standby/Pairing/Input indicator
4. On/Standby Button
5. INPUT Button
6. Pairing Button
7. NFC detection area
8. Remote Sensor
9. Sound Mode Button
10. Volume Down Button
11. Volume Up Button
Table/floor
Wall mount
Wall
mount
bracket

E-3
4
2
3
1
5
FRONT VIEW REAR VIEW
1. Power/Pairing Indicator
2. Bass Reflect Duct
3. Woofer
4. SW LINK (Subwoofer Link) button
5. AC Power Lead
Front view Rear view
Controls and indicators (continued)
Sound Bar Rear Panel
8
7
6
5
4
2
1
3
1. IR OUT Terminal
2. HDMI OUT (TV ARC) Socket
3. USB terminal
4. HDMI IN 1 Socket
5. HDMI IN 2 Socket
6. Optical IN Socket
7. Audio IN Terminal
8. AC Power Lead
Subwoofer

E-4
Controls and indicators (continued)
10
18171615131211
12
34 5678919
14
Remote Control
1. TV Operation Button
2. Bluetooth®Pairing Button
3. Display
4. Remote Control Transmitter
5. Sound Mode Button
6. Cursor Left/Fast Reverse/Skip Down button
7. Cursor Up/Play Mode Button
8. Cursor Right/Fast Forward/Skip Up Button
9. ON/STANDBY Button
10. Volume Up Button
11. Speaker Select Button
12. Menu Button
13. Input Select Button
14. Mute Button
15. Bass/Treble Button
16. Cursor Down/Display Button
17. Play/Pause Button
18. Volume Down Button
19. DC IN Terminal
Display remote control
To control the sound bar
HT-SB603 comes with a wireless display remote control
which uses Bluetooth to communicate instead of infra red
which requires direct line of sight. You can control the
sound bar from any direction or angle within 10 metres
(32 feet).
To control SHARP TV
This remote control still uses infra red to control SHARP
TV. Point the remote control at the TV remote sensor to
operate the TV.
NOTE:
zIn case the remote control is lost or needs repairing,
bring the entire system set to the service centre.
Connecting the remote control
The remote control and sound bar will link automatically
(wirelessly) as it is already pre-linked at the factory.
If the link cannot be established, please set the
connection by the following method.
1. Bring the remote control near to the sound bar and
select PAIRING from the remote control menu. (Refer
‘To select a menu on the remote control’ on page 12)
2. Set the sound bar to standby mode (Eco mode off).
3. Press and hold the INPUT button on the sound bar until
“CONNECTED!” appears on the display.
Note:
If the AC power lead of the sound bar is unplugged or
if a power failure happened, the remote control will be
disconnected. Press any key on the remote control to
reactivate the connection.
TV code selection
The default TV code for the remote control is TV CODE
1. In case SHARP TV is not responding to TV operation
button, change the code by selecting TV CODE from the
remote control menu (Refer ‘To select a menu on the
remote control on page 12).
TV Operation Buttons (Only SHARP TV):
On/Standby
Button
Sets the
TV power
to “ON” or
“STANDBY”.
Input Select
Button (TV)
Press the
button to
switch the
input source.
Channel Up
and Down
Buttons
Switch up/
down the TV
channels.
Volume Up
and Down
Buttons
Turn up/
down the TV
volume.
Note:
Some models of SHARP TV may not be operable.

E-5
Sound bar preparation
To mount the sound bar on the wall
Caution:
z
Be very careful to prevent the sound bar [3.7 kg (7.9 lbs.)]
from falling when mounting on the wall.
z Before mounting, check the wall strength. (Do not put on
the veneer plaster or whitewashed wall. The sound bar
may fall.) If unsure, consult a qualified service technician.
z Mounting screws are not supplied. Use appropriate ones.
z Check all wall mount angle screws for looseness.
z Select a good location. If not, accidents may occur or the
sound bar may get damaged.
z SHARP are not responsible for accidents resulting
from improper installation.
Driving screws
SHARP designed the sound bar so you may hang them
on the wall. Use proper screws (not supplied). See below
for size and type.
3.2 mm
9 mm
Min. 22 mm
5
mm
Fixing wall mount angle
(Horizontal position)
1 Fix the pattern paper to the wall in horizontal
position as below.
Wall surface
Pattern paper
44 mm
44 mm
29 mm
29 mm
926 mm
2 Make a hole on the wall following the screw
point marks on the pattern paper by using a
drill.
Wall surface
32 mm
8-9 mm
3 Fix a wall mount plug (not supplied) into the
hole using a hammer, until it is flush with the
wall surface.
Wall surface
32 mm
8-9 mm
4 Screw the wall mount angle to the wall as shown
in the illustration. (Total screw is 8 pieces)
Wall mount angle
Wall mount
angle Wall
mount
angle
(screws x 4)
(screws x 4)
Wall surface
Wall surface
Wall
surface
Note:
Make sure all screws are fully tightened. (screws are not
supplied)
Installing the sound bar
1 Align the wall mount slot at the sound bar to the
wall mount angle.
2 Slot the sound bar into the wall mount angle.
3 Fix them securely.
Wall surface

E-6
Falling prevention
zSafety wires (not supplied) are useful to prevent the sound bar from falling off.
z2 persons are required to perform this procedure.
When mounting on the wall
1 Loop the safety wires (not supplied) into each
hole of the wall mount angle as shown.
Wall surface
Holes
2 Loop the safety wires from wall mount angle
into each hole of sound bar as shown.
Wall surface
3 Align and fix the sound bar to wall mount angle.
Wall surface
4 Tie the safety wires tightly.
Wall surface
When placing on the shelf/table
Loop the safety wires (not supplied) into each hole as shown
and tie the safety wires to the TV stand.

E-7
Placing the system
Installation image:
TV
Digital Tuner BD player Subwoofer
Sound Bar
Place the system as shown.
Remove the protective film covering the subwoofer
before turn on the system.
Notes:
zThe front panel of the sound bar is not removable.
zThe maximum transmission distance of the wireless
signal between the subwoofer and sound bar is about
10 metres (32 feet), but may vary depending on your
operating environment. If a steel-concrete or metallic
wall is between the subwoofer and the sound bar, the
system may not operate at all, because the wireless
signal cannot penetrate metal.
Caution:
zDo not change the installation direction when the
sound bar is turned on.
zDo not stand or sit on the sound bar and subwoofer as
you may be injured.
zDo not allow any objects to fall into or to be placed in
the bass reflex duct.
Placing the subwoofer stand
Place the stand as shown.
Stand
System connections
Make sure to unplug the AC power lead before making any connections.
Wall socket
100 - 240 V ~
50/60Hz
Wall socket
100 - 240 V ~
50/60Hz
Sound Bar
Subwoofer

E-8
System connections (continued)
IR (Infrared) transmitter connection
If the TV’s remote sensor is blocked by the sound bar, use the IR transmitter to relay the signal to the TV.
1. Connect the IR transmitter to IR out terminal to allow the TV’s remote signal to pass through.
2. Place the infrared emitter near TV’s remote sensor (refer the operation manual of the TV for the location of the
sensor ).
Point the TV’s remote control at the sound bar remote sensor and operate the TV.
You may need to move the IR transmitter until the TV operates correctly.
Then secure the IR transmitter onto the sound bar using the double sided tape provided.
Note:
zDo not use the IR transmitter if the TV’s remote control sensor is not blocked by the sound bar.
TV remote sensor
Infrared emitter
TV
remote
control
Double sided tape
(Peel off the double sided
tape separator before fixing)
Rear view
TV
HDMI Connection
Caution:
Turn off all other equipment before making this connection.
The illustration below shows the flows of the signals.
HDMI IN 2 HDMI IN 1
Audio and Video signal
TV
TV
DVD/Blu-ray
1. Method 1
This connection is for HDMI TV with ARC (Audio Return Channel).
To HDMI input terminal
Sound Bar
To HDMI output
terminal
To HDMI (TV ARC) input terminal
To HDMI OUT (TV ARC) output terminal
DVD, Blu-ray disc
player or similar
Digital tuner

E-9
System connections (continued)
HDMI IN 2HDMI IN 1
TV
To HDMI input terminal
To audio output terminal
To Headphone
terminal
2. Method 2
This connection is for HDMI TV without ARC (Audio Return Channel).
To HDMI input terminal
Sound Bar
To HDMI output
terminal
To HDMI OUT (TV ARC) output terminal
DVD, Blu-ray disc
player or similar
To select HDMI 1, 2 or TV ARC function (Source):
Press INPUT button repeatedly on the sound bar or remote control to select “HDMI 1”, “HDMI 2” or “TV ARC”.
Notes:
z
This sound bar supports HDMI which enables ARC (Audio Return Channel).
z To enable ARC make sure to use High Speed HDMI™ cable (with ARC).
z This ARC feature requires TV that supports ARC. Refer the operation manual of the TV to determine which terminal supports ARC.
z To listen to the sound from a non-ARC-compatible TV, connect the audio output from TV to this system’s. (refer figure above)
z This sound bar can be operated (power on/off or volume up/down) via a TV or similar component which supports HDMI CEC
(Consumer Electronics Control). If this does not work, it does not mean this system is faulty. Refer to the operation manual of the
respective component on how to activate the CEC.
Example: Go to the Menu of the component to search and enable the CEC. Different brands may have different naming for the CEC.
For SHARP LCD TV, it is named as AQUOS LINK.
z The system will automatically power off if TV or similar component which supports HDMI CEC, is turned off.
z CEC is not available during Low power consumption mode (Eco mode on).
z To listen to the sound from this system, you will need to select menu (refer page 13) or adjust the speaker
output settings within the TV menu.
For details, refer to the operation manual of the TV.
z If you are unable to select external speaker setting from the TV menu (E.g. For SHARP LCD TV, it is named as AQUOS
AUDIO SP), turn the CEC OFF and ON again.
z To enjoy 3D images or 4K content, this system must be connected to a 3D or 4K-compatible TV and components (3D BD player,
etc.) via High Speed HDMI cables. Put on the 3D glasses (for 3D-compatibile TV and components), otherwise 3D images or 4K
content may not be viewed properly.
z If you want to use HDMI IN 1 socket, please use the supplied HDMI cable.
Audio connections to TVs, DVD players, VCRs, etc.
Other connection (without HDMI)
The illustration below shows the flows of audio and video signals.
DVD/Blu-ray
Disc Player
Digital tuner, etc.
TV
Audio signal
Video signal
Notes:
zRefer to the operation manual of the equipment to be connected.
zFully insert the plugs to avoid fuzzy pictures or noises.
zConnecting via this method may disable TV internal speakers.
zIn some cases, a small background noise could emit from the sound bar, when you use the RCA audio output
terminal connection from a TV-Set/DVD/Blu-ray Disc Player. In such case, please change the connection to the
HDMI/ARC or headphone terminal connection. This effect depends on the used TV/DVD/Blu-ray Disc Player-
Brand, model and age, and it is not a quality matter from the sound bar.
