Sharp HT-CN650DVW User manual

61
HTCN650DVW_AUS.fm03/10/29
F
S
V
I
N
P
E
E
HT-CN650DVW
ON STAND-BY OPEN CLOSE
PRESET MUTE PRESET
OSDPLAYSLOW
TUNING TUNINGSTOP
PAUSE
TITLE
SETUP
ENTER
FUNCTION
MENU
PBC RETURN
LISTENING
EQUALIZER PROG
MODE
ECHO
MIC
VOLUME
ANGLEZOOMSUBTITLEAUDIO
SLEEP DIRECT REPEAT A-B
123
456
78
0
9
MODEL
HT-CN650DVW
OPERATION MANUAL
HOME THEATER WITH DVD

2
HTCN650DVW_AUS.fm03/10/29
HT-CN650DVW
Important Instruction
- Introduction / Special notes -
Introduction

HT-CN650DVW Home Theater with DVD consisting of HT-CN650DVW (main unit),
CP-CN650F (front speakers), CP-CN650C (centre speaker), CP-CN650R (surround
speakers) and CP-CN650SW (subwoofer).
Special notes
WARNING
 When the ON/STAND-BY button is set at STAND-BY position, mains voltage is still
present inside the unit. When the ON/STAND-BY button is set at STAND-BY
position, the unit may be brought into operation by the remote control.
 This unit contains no user serviceable parts. Never remove covers unless qualified
to do so.This unit contains dangerous voltages, always remove mains plug from the
socket before any service operation and when not in use for a long period.
 To prevent fire or shock hazard, do not expose this appliance to dripping or
splashing. No objects filled with liquids, such as vases, should be placed on the
apparatus.
Note for users in Australia:
Copyright may exist in material you wish to record. Copying or broadcasting such
material without permission of the relevant licensees or owners of the copyright is
prohibited by law. SHARP is not in a position to authorise the copying or broadcasting
of copyright materials and nothing in this OPERATION MANUAL should be implied as
giving that authority.
For other countries:
Audio-visual material may consist of copyrighted works which must not be recorded
without the authority of the owner of the copyright. Please refer to the relevant laws in
your country.
COPYRIGHT
CAUTION
Thank you for purchasing this SHARP product. To obtain the best performance from
this product, please read this manual carefully. It will guide you in operating your
SHARP product.
Copyright Information:

Unauthorised copying, broadcast, public display, transmission, public
performance and rental (regardless of whether or not such activities are for profit)
of disc contents are prohibited by law.

This system is equipped with copy protection technology that causes substantial
degradation of images when the contents of a disc are copied to a video tape.
Copyright Protection:
This unit supports Macrovision copy protection.
On DVD discs that include a copy protection code, if the contents of the DVD disc are
copied using a VCR, the copy protection code prevents the video tape copy from
playing normally.
Apparatus Claims of U.S. Patent Nos. 4,631,603, 4,577,216, 4,819,098, and
4,907,093, licensed for limited viewing uses only.
 This product is classified as a CLASS 1 LASER product.

This product contains a low power laser device. To ensure continued safety, do not
remove any cover or attempt to gain access to the inside of the product. Refer all
servicing to qualified personnel.
This product incorporates copyright protection technology that is protected by
method claims of certain U.S. patents and other intellectual property rights owned
by Macrovision Corporation and other rights owners.
Use of this copyright protection technology must be authorised by Macrovision
Corporation, and is intended for home and other limited viewing uses only unless
otherwise authorised by Macrovision Corporation.
Reverse engineering or disassembly is prohibited.
“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.
Manufactured under license from Dolby Laboratories, “Dolby” and the double-D
symbol are trademarks of Dolby Laboratories.

3
HTCN650DVW_AUS.fm03/10/29
F
S
V
I
N
P
E
E
HT-CN650DVW
General Information
- Contents -
Contents
Page
 General Information
Types of playable discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Description of discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 11
 System Connections
Speaker connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 - 13
Aerial connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Connections to TV, VCR, etc. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 - 17
 Preparation for Use
System installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Battery installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Turning the power on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Changing the setup menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 - 25
General control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
 DVD Operation
DVD playback
Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 - 28
To resume playback after stopping (resume play) . . . . . . . . . . . . . . . . . . . . . . .28
DVD mode operation indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Basic operation
To locate the beginning of a chapter (track) (skip) . . . . . . . . . . . . . . . . . . . . . . .29
Fast forward/Fast reverse (search) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
To start playback from the desired point (direct play) . . . . . . . . . . . . . . . . . . . .30
Useful operation
Slow-motion play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
To change the angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
To zoom images (zoom) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
To play repeatedly (repeat play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
To play the contents between the specified points repeatedly (A-B repeat) . .34
To select a title from the top menu of the disc . . . . . . . . . . . . . . . . . . . . . . . . . .34
To select a subtitle or audio language from the disc menu . . . . . . . . . . . . . . . .34
Page
Various settings
To change the subtitle language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
To change the audio channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
To change the display on TV screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
 Video CD and Super Video CD Operation
Video CD and Super Video CD playback
Playback of a video CD (super video CD) with P.B.C. . . . . . . . . . . . . . . . . . . . .37
To play without activating the playback control function . . . . . . . . . . . . . . . . .38
To start playback from the desired point (direct play) . . . . . . . . . . . . . . . . . . . . 38
 CD, CD-R and CD-RW Operation
CD operation
To play in the desired order (programmed play) . . . . . . . . . . . . . . . . . . . . . . . .39
To start playback from the desired point (direct play) . . . . . . . . . . . . . . . . . . . . 39
MP3/WMA, JPEG and DivX disc operation
To start playback from the desired point (direct play) . . . . . . . . . . . . . . . . . . . . 40
Playback on the menu screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 - 41
Rotating a picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
 USB Memory Device Playback
USB memory device operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
 Radio Operation
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 - 45
 Advanced Features
Enjoying various sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 - 47
Adjusting channel delay/speaker level . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 - 49
Sleep operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Playing karaoke . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
 References
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 - 53
Error indicators and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 - 56

4
HTCN650DVW_AUS.fm03/10/29
HT-CN650DVW
General Information
- Types of playable discs -
Types of playable discs
The DVD player can play back discs bearing any of the following marks:
 For unplayable discs, see page 7.
Types of playable DVD discs vary depending on the region. This unit can play back
only DVDs with the same region number are written on the back of the unit.
Disc type Disc contents Disc size
DVD Video Disc Audio and video
(movies)
12 cm (5")
8 cm (3")
Super Video CD Audio and video
(movies)
12 cm (5")
8 cm (3")
Video CD Audio and video
(movies)
12 cm (5")
8 cm (3")
Audio CD Audio 12 cm (5")
8 cm (3")
CD-R/CD-RW (*1) Audio and picture 12 cm (5")
8 cm (3")
Or CD-R/CD-RW recorded in MP3 format
(*2), JPEG format (*3) (*4) (*5)
DivX
®
Video disc (Ver 5.2 and below) Audio and video
(movies)
12 cm (5")
8 cm (3")
(*1): The CD-R/CD-RW may not be played back properly depending on the recording
equipment or the disc.
(*2): If the sampling frequency is 44.1 or 48.1 kHz and the fixed bit rate is 128 kbps
or higher, MPEG 1 Audio Layer 3 (MP3) files can be played. However, some of
them may not be played depending on their conditions or formats.
(*3): This unit also can recognise .AVI, .DIV, .MPG, .MPEG and .XVID. Bitrate can go
up to 4.8 Mbps.
(*4): JPEG or JPG picture discs also play on this unit. However, pictures may not be
clear (depends on resolution and recording method).
(*5): JPEG maximum resolution limit at 2M file size.
If photo bigger than this size, a dialog box will appear to display “over file size”
and go to next picture.
Icons used in this operation manual
Some functions may not be available depending on discs. The following icons indicate
the discs that can be used in the section.
... Indicates DVDs.
... Indicates Super video CDs.
... Indicates video CDs.
... Indicates audio CDs.
... Indicates CD-R/RW with MP3 recording.
... Indicates CD-R/RW with JPEG recording.
... Indicates DivX
®
video.
 Some operations may not be performed depending on discs even if they are
described in this manual.

During operation, “ ” may be displayed on the screen. This means that the
operations described in this manual are not possible.
Copyright Information:
 Unauthorised copying, broadcast, public display, transmission, public performance
and rental (regardless of whether or not such activities are for profit) of disc
contents are prohibited by law.
 This system is equipped with copy protection technology that causes substantial
degradation of images when the contents of a disc are copied to a videotape.
 This system is protected by U.S. patents and other intellectual property rights, the
copyright for which belongs to Macrovision Corporation. The use of Macrovision’s
copy protection technology in the system is authorised by Macrovision and is
intended for home use only, unless otherwise authorised in writing by Macrovision.
Reverse engineering or disassembly is prohibited.
43
or
2
or or
5

5
HTCN650DVW_AUS.fm03/10/29
F
S
V
I
N
P
E
E
HT-CN650DVW
General Information
- Accessories -
Accessories
Please confirm that the following accessories are included.
Remote control × 1 “AAA” size battery
(UM-4, R03, HP-16 or similar) × 2
Audio/Video cable × 1 FM aerial × 1
Speaker connection lead × 5
Green and Black
(for centre speaker)
approx. 3 m
Blue and Black
(for left surround speaker)
approx. 8 m
Grey and Black
(for right surround speaker)
approx. 8 m
Red and Black
(for right front speaker)
approx. 3 m
White and Black
(for left front speaker)
approx. 3 m
Note:
Only the above accessories are included.

6
HTCN650DVW_AUS.fm03/10/29
HT-CN650DVW
General Information
- Precautions -
Precautions
 General
 Please ensure that the equipment is positioned in a well ventilated area and that
there is at least 10 cm (4") of free space along the sides and back.There must also
be a minimum of 15 cm (6") of free space on the top of the unit.
 No naked flame sources, such as lighted candles, should be placed on the
apparatus.
 Attention should be drawn to the environmental aspects of battery disposal.
 This unit should only be used within the range of 5˚C - 35˚C (41˚F - 95˚F).
Warning:
The voltage used must be the same as that specified by this unit. Using this product
with a higher voltage other than that specified is dangerous and may result in a fire or
other types of accident, causing damage. SHARP will not be held responsible for any
damage resulting from the use of this unit with a voltage other than that specified.
 Volume control
The sound level at a given volume setting depends on speaker efficiency, location, and
various other factors. It is advisable to avoid exposure to high volume levels. Do not
turn the volume on to full at switch on and listen to music at moderate levels.
 Care of DVD/CD discs
DVD/CD discs are fairly resistant to damage, however mistracking can occur due to
an accumulation of dirt on the disc surface. Follow the guidelines below for maximum
enjoyment from your DVD/CD collection and player.
 Do not write on either side of the disc, particularly the non-label side from which
signals are read. Do not mark this surface.
 Keep your discs away from direct sunlight, heat, and excessive moisture.
 Always hold the DVD/CDs by the edges. Fingerprints, dirt, or water on the DVD/
CDs can cause noise or mistracking. If a DVD/CD is dirty or does not play properly,
clean it with a soft, dry cloth, wiping straight out from the centre, along the radius.
 Use the unit on a firm, level surface free from
vibration.
 Keep the unit away from direct sunlight, strong
magnetic fields, excessive dust, humidity and
electronic/electrical equipment (home computers,
facsimiles, etc.) which generates electrical noise.
 Do not place anything on top of the unit.
 Do not expose the unit to moisture, to temperatures higher than 60˚C (140˚F) or to
extremely low temperatures.
 If the unit does not work properly, unplug and plug it in again. Then turn on the unit.
 In case of an electrical storm, unplug the unit for safety.
 Hold the AC power plug by the head when removing it from the wall socket, as
pulling the lead can damage internal wires.
 The AC power plug is used as disconnect device and shall always remain readily
operable.
 Do not remove the outer cover, as this may result
in electric shock. Refer internal service to your
local SHARP service facility.
10 cm (4") 10 cm (4")
10 cm (4")
15 cm (6")
 The ventilation should not be impeded by covering
the ventilation openings with items, such as
newspapers, tablecloths, curtains, etc.
NO YES
Correct

7
HTCN650DVW_AUS.fm03/10/29
F
S
V
I
N
P
E
E
HT-CN650DVW
2
2
General Information
- Description of discs -
Description of discs
Discs that cannot be played
The discs above cannot be played at all, or no sound is heard although images
appear on the screen or vice versa.
Incorrect operation may damage the speakers and can have an negative effect on
your hearing when played at high volume settings.
You cannot play illegally produced discs.
Notes:
A disc with has scratches or fingerprints may not play properly. Refer to “Care of
DVD/CD discs (page 6)” and clean the disc.
Do not play the discs of special shapes (heart or octagon shaped) as they can be
ejected whilst rotating and cause injury.
Title, chapter and track
DVDs are divided into “titles” and “chapters”. If the disc has more than one movie on
it, each movie is a separate “title”. “Chapters” are subdivisions of titles.
Audio CDs consist of “tracks”.
A “track” is each tune on an audio CD.
Note:
Title, chapter, or track numbers may not be recorded on some discs.
Icons used on DVD discs
Check the icons on the DVD case before playing your discs.
DVDs without the region number on
the back of the unit or “ALL”.
CDG
CDV
DVDs with SECAM system Photo CD
DVD-ROM CD-ROM
DVD-RAM SACD
DVD-Audio Discs recorded in special formats, etc.
Chapter 1
Title 1 Title 2
Chapter 2 Chapter 3 Chapter 1 Chapter 2
Track 1 Track 2 Track 3 Track 4 Track 5
Display Description
Region number (playable area number) DVD discs are programmed with region
numbers indicating countries in which
they can be played. This system can play
discs with region number on the back of
the unit.
Format recorded on the DVD To adopt the video format to the
connected TVs (“wide-screen TV” or “4:3
size TV”).
Recorded in 4:3.
You can enjoy wide images on a wide-screen TV, and letterbox size
images on the 4:3 size TV.
You can enjoy wide images on a wide-screen TV and 4:3 images
with the side edges cut on the 4:3 size TV.
Type of subtitles recorded Recorded subtitle languages.
Example: Language can be selected with the
SUBTITLE button.
1: English
2: French
Number of camera angles Number of angles recorded on the DVD.
Angles can be selected with the ANGLE
button.
Number of audio tracks and audio
recording systems
The number of audio tracks and audio
recording systems are indicated.
Example:
1: Original <English>
(DTS 5.1 Surround)
The audio recorded on the DVD can
be switched by using the AUDIO
button.
The number of audio tracks and
recording systems vary depending on
the DVD. Check them in the DVD's
manual.
2: English (Dolby Digital
5.1 Surround)
4 52 3

8
HTCN650DVW_AUS.fm03/10/29
HT-CN650DVW
General Information
- Controls and indicators -
Controls and indicators
Main unit (front panel)
Reference page
1.On/Stand-byButton . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19, 20
2.DiscTray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.DiscTray Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.Remote Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.Function Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20, 27, 43
6.Speaker Level Mode Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 26, 49
7.Chapter (track) Skip Down or Preset/Tuning Down Button . . 29, 44
8.Chapter (track) Skip Up or Preset/Tuning Up Button . . . . . . . 29, 44
9.Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28, 37
10.Play or Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27, 28, 31
11.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . 26, 51
12.USB Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
13.Microphone Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
14.Speaker Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
15.DVD Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27, 28, 29, 30
Reference page
16.JPEG Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
17.P-SCAN Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15,16, 21
18.Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27, 28, 30
19.Pause Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
20.Dolby Digital Signal Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
21.SVCD/VCD/CD Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37, 38
22.MP3 Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
23.DTS Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
24.Dolby Pro Logic Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
25.Stereo (2-ch) or FM Stereo Receiving Indicator. . . . . . . . . . . . .44, 45
26.Title Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28, 29, 46
27.Track Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
28.Chapter Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28, 29, 46
29.Programme Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
30.Sleep Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
31.Repeat Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
32.A-B Repeat Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
2 4 5 6 7 8 9 10 3
1
11
14
21 22 23 24 25 26 27 28 29 30 31 32
15 16 17 18 19 20
13 12
(1) Left Front Speaker Indicator (4) Left Surround Speaker Indicator
(2) Centre Speaker Indicator (5) Subwoofer Indicator
(3) Right Front Speaker Indicator (6) Right Surround Speaker Indicator

9
HTCN650DVW_AUS.fm03/10/29
F
S
V
I
N
P
E
E
HT-CN650DVW
General Information
- Controls and indicators -
Main unit (rear panel)
Reference page
1. AC Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
2. Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
3. Audio Input Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
4. Audio Output Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14, 15
5. Video Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
6. Component Video Output Sockets . . . . . . . . . . . . . . . . . . . . . . . . . .15
7. Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
8. S-Video Output Socket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
9. HDMI Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
10.FM 75 Ohms Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Cooling fan
This unit is fitted with a cooling fan at the rear for improved cooling. Do not cover the
opening in this section with any obstacles.
1 2 5
8 97 10
63
<The spec label is located at the bottom of the unit>
4
Caution:
 The unit will get warm whilst being used. Do not touch the warm areas of the unit for
prolonged periods to avoid damage to you.
This unit is equipped with a special function which protects the amplifier circuit from
damages. When it is activated, the sound switch is turned off. In this case, unplug
the unit and, after 15 minutes or more, plug it in again.
Cooling fan

10
HTCN650DVW_AUS.fm03/10/29
HT-CN650DVW
General Information
- Controls and indicators -
Controls and indicators (continued)
Remote control
Reference page
1. Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
2. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
3. Mute Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
4. Chapter (track) Skip Down or Preset Down Button . . . . . .29, 37, 44
5. Slow Motion Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
6. Fast Reverse or Tuning Down Button . . . . . . . . . . . . . . . . . . . . .29, 44
7. Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
8. Function Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20, 27, 44
9. Cursor Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
10.Menu/Playback Control On/Off Button . . . . . . . . . . . . . . . . .33, 38, 41
11.Key Control Button (Lower) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
12.Key Control Button (Normal) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
13.Direct Number Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29, 33, 44
14.EQ (equaliser) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
15.MIC Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
16.Echo Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
17.Speaker Level Mode Button . . . . . . . . . . . . . . . . . . . . . . . . . . . .26, 49
18.Audio Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
19.Sleep Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
20.Subtitle Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
21.Direct Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30, 38
22.Disc Tray Open/Close Button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
23.Chapter (track) Skip Up or Preset Up Button . . . . . . . . . . . .29, 37, 44
24.On Screen Display On/Off Button . . . . . . . . . . . . . . . . . . . . . . . . . .36
25.Play or Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27, 28
26.Fast Forward or Tuning Up Button . . . . . . . . . . . . . . . . . . . . . . .29, 44
27.Setup Menu Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
28.Enter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
29.Title Select/Return Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34, 37
30.Key Control Button (Highest) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
31.Programme Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39, 41, 42
32.Surround/Stereo (2-ch) Listening Mode Button . . . . . . . . . . . .46, 47
33.Volume Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26, 51
34.Volume Down Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26, 51
35.Angle Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
36.A - B Repeat Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
37.Zoom Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
38.Repeat Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33, 39
ON STAND-BY OPEN CLOSE
PRESET MUTE PRESET
OSDPLAYSLOW
TUNING TUNINGSTOP
PAUSE
TITLE
SETUP
ENTER
FUNCTION
MENU
PBC RETURN
LISTENING
EQUALIZER PROG
MODE
ECHO
MIC
VOLUME
ANGLEZOOMSUBTITLEAUDIO
SLEEP DIRECT REPEAT A-B
123
456
78
0
9
1
3
4
6
7
2
5
9
10
11
12
13
23
24
22
26
27
25
29
30
28
38
35
36
34
37
33
32
31
15
17
18
19
21
16
20
14
8

11
HTCN650DVW_AUS.fm03/10/29
F
S
V
I
N
P
E
E
HT-CN650DVW
General Information
- Controls and indicators -
Front/surround speakers
Reference page
1. Speaker
2. Super Tweeter
3. Speaker Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Centre speaker
Reference page
1. Speaker
2. Super Tweeter
3. Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Subwoofer
Reference page
1. Bass Reflex Duct
2. Woofer
3. Speaker Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Speaker functions
Notes:
Do not allow any objects to fall into or to be placed in the bass reflex ducts.
Front and centre speakers are magnetically shielded.
13
2
1 31
2
Front speaker:
Reproduces left and right sound (stereo mode) or front surround sound.
Centre speaker:
Reproduces centre surround sound.
Surround speaker:
Reproduces rear surround sound.
Subwoofer:
Reproduces bass sound.
21 3

12
HTCN650DVW_AUS.fm03/10/29
HT-CN650DVW
System Connections
- Speaker connection -
Speaker connection
Speaker terminals on the main unit and speakers, and speaker wires are distinguished by colours.
Connect the speaker and the unit by matching the colours.
(For speaker installation, see page 18.)
92LXXXXXXXXXXX
Purple
(+)
Green
(+)
Red
(+)
Front speaker
(right)
Centre speaker
Surround speaker
(left)
Subwoofer
Surround speaker
(right)
Front speaker
(left)
Grey
(+)
Blue
(+)
White
(+)
Black
Black
Black
Black
Black
Black

13
HTCN650DVW_AUS.fm03/10/29
F
S
V
I
N
P
E
E
HT-CN650DVW
System Connections
- Speaker connection / Aerial connection -
Connecting speaker wires
To prevent accidental short circuits between and terminals, connect the
speaker wires to the speakers first and then to the unit.
Aerial connection
External FM aerial:
Use an external FM aerial if you require better reception. Consult your dealer.
Make sure to leave the AC power lead disconnected when connecting the
speakers.
Caution:
 The supplied speakers for HT-CN650DVW is designed exclusively for
HT-CN650DVW. Do not connect speakers for HT-CN650DVW to other equipment.
Also, do not connect other speakers to HT-CN650DVW. It may cause malfunction.
Do not mistake the and , and right and left terminals of the speaker wires. (The
right speaker is placed on the right when you face the unit.)
Do not let the bare speaker wires touch each other.
Do not stand or sit on the speakers. You may be injured.
Do not short-circuit the speaker wires. If the power is
turned on, malfunction may occur.
When disconnecting the speaker wires, unplug the AC
power lead, and then disconnect the speaker wires from
the main unit.
Black
()
1Connect the wires to the speakers.
2Connect the other end to the main
unit.
Red
(+)
Red
(+)Red
Black
() Black
Incorrect
Supplied FM aerial:
Connect the FM aerial wire to the FM 75 OHMS
socket and position the FM aerial wire in the
direction where the strongest signal can be
received.
Note:
Placing the aerial on the unit or near the AC
power lead may cause noise pickup. Place the
aerial away from the unit for better reception.
FM aerial
External FM aerial

14
HTCN650DVW_AUS.fm03/10/29
HT-CN650DVW
System Connections
- Connections to TV, VCR, etc. -
Connections to TV, VCR, etc.
 Connecting to a TV with a video input socket
 Connecting to a TV with an S-video input socket
Audio connection from TV or VCR
You can enjoy surround sound from TV or VCR by connecting them to the unit as
shown.
Connecting to a TV with HDMI socket
Note:
Please follow the below steps before turn on the power.
1. If your TV has the HDMI input socket, connect the DVD player with the HDMI cable
(the VIDEO OUT, S-VIDEO and COMPONENT VIDEO OUT sockets connection
are not necessary). You can enjoy clearer picture playback.
2. You no need to connect the left and right audio cables to the AUDIO OUT socket of
DVD player and the AUDIO INPUT socket of TV.
Caution:
Turn off all other equipment before making any connections.
To video
input socket
To audio
input sockets
TV
Video cable (supplied)
Video
signal
Audio cable (supplied)
Audio signal
To S-video
input socket
To audio
input sockets
TV
S-video cable
(commercially available)
Video signal
Audio cable (supplied)
Audio signal
TV
VCR
To audio
output sockets
Audio cable (supplied)
Audio signal
Audio cable (supplied)
To audio output sockets
Audio signal
TV
To HDMI
input socket
HDMI cable
(commercially available)

15
HTCN650DVW_AUS.fm03/10/29
F
S
V
I
N
P
E
E
HT-CN650DVW
System Connections
- Connections to TV, VCR, etc. -
Connecting to a TV with Progressive-scan capability
Your TV must be capable of handling progressive scanning and have component video input capability.
* Please consult your local audio/video dealer.
1. Connect the DVD main unit to the component video input sockets of the TV. (The VIDEO INPUT or S-VIDEO OUT sockets connection is not encourage.)
2. You also need to connect the left and right audio cables to the AUDIO OUT sockets of DVD main unit and the Audio input sockets of the TV.
3. Set the DVD main unit to the PROGRESSIVE position. (See page 22)
AUDIO INPUT COMPONENT VIDEO INPUT
LYPBPRR
Green
White
Red
Blue Red
TV with
progressive-scan
capability
To COMPONENT
VIDEO INPUT sockets
To audio
input sockets
Audio cable
(supplied)
Red Blue
Green
*Component video cable
(not supplied)

16
HTCN650DVW_AUS.fm03/10/29
HT-CN650DVW
System Connections
- Connections to TV, VCR, etc. -
Connections to TV, VCR, etc. (continued)
Progressive Scanning
Whilst interlaced scanning produces one frame of video in two fields, progressive scanning creates one frame in one field.
Conventional interlaced scanning constitutes one second with 30 frames (60 fields), but progressive scanning constitutes it with 60 frames from scratch.
Progressive scanning can reproduce sharper picture with high resolution for still image or other picture containing long texts or horizontal lines.
This model has compliance with 525p (progressive) system.
Notes:
Please refer to your TV instruction manual.
When you connect the DVD main unit to your TV, be sure to turn off the power and disconnect both units from the wall socket until all the connections have been made.
Do not connect the DVD main unit to a VCR directly. The playback picture will be distorted because DVD video discs are copy protected.
I
nterlaced scannin
g
Progressive scanning

17
HTCN650DVW_AUS.fm03/10/29
F
S
V
I
N
P
E
E
HT-CN650DVW
System Connections
- Connections to TV, VCR, etc. -
To listen to TV or VCR sound via the speakers of this unit:
Audio connection to other equipment Connecting the AC power lead
After checking all the connections have been made correctly, plug the AC power lead
of this unit into the wall socket.
Notes:
Plug the AC power lead into the wall socket, after any connections.
Unplug the AC power lead from the wall socket if the unit will not be in use for a
prolonged period of time.
Use only the supplied AC power lead. Using other power leads may cause an
electric shock or fire.
AC Plug Adaptor
In areas (or countries) where a wall socket as shown in illustration is used, connect
the unit using the AC plug adaptor supplied with the unit, as illustrated. The AC plug
adaptor is not included in areas where the wall socket and AC power plug can be
directly connected (see illustration ).
Note:
An AC plug adaptor is not supplied if the lead has an Australian Standard plug.
Press the FUNCTION button repeatedly to select the desired audio
input.
Unit display
“AUX 1” or “AUX 2”.
Notes:
Change the TV input in accordance with the connected socket.
Do not connect other equipment (VCR, etc.) between the TV and this unit.
Pictures may be distorted.
Refer to the operation manual of the equipment to be connected.
Insert the plugs fully to avoid fuzzy pictures or noise.
ON STAND-BY OPEN CLOSE
PRESET MUTE PRESET
OSDPLAYSLOW
TUNING TUNINGSTOP
PAUSE
SETUP
ENTER
FUNCTION
FUNCTION
A-B REPEAT 1SLEEPPROGCHPESET
KHz
MHz
To audio
input socket MD recorder
Audio signal
Audio cable
1
2
Wall socket
(AC 220 ~ 240 V, 50/60 Hz)
2
1

18
HTCN650DVW_AUS.fm03/10/29
HT-CN650DVW
Preparation for Use
- System installation -
System installation
Placing the speaker system
The best surround effect will be achieved by placing each speaker at the same
distance from the listening position.
It is recommended to arrange the speakers as shown below.
Notes:
Place the TV halfway between the front speakers.
It is recommended that the centre speaker be placed near the television.
Place the surround speakers at a position just above the height of your ears.
The subwoofer vibrates whilst reproducing bass. Place it on a stable, sturdy
surface.
The bass sound from the subwoofer is non-directional, however, it is recommended
to place it as close as left and right speakers.
Magnetically shielded speakers
The front and centre speakers may be placed beside or near the TV as they are
magnetically shielded. However, discolouration may occur depending on the TV type.
If colour variation occurs...
Turn off the TV (with the power switch).
After 15 - 30 minutes, turn the TV on again.
If the colour variation is still present...
Move the speakers further away from the TV.
Refer to the manual of the TV for details.
Note:
The surround speakers and subwoofer are not magnetically shielded.
Note:
If speakers cannot be placed at equal distances, refer to “Channel delay setting”
(see page 49).
Installation image:
Front
speaker (left)
Subwoofer
Front
speaker (right)
Surround
speaker (left)
Surround
speaker (right)
Centre
speaker
Front speaker (left)
Same distance
Front speaker (right)
Centre speaker
Same distance

19
HTCN650DVW_AUS.fm03/10/29
F
S
V
I
N
P
E
E
HT-CN650DVW
Preparation for Use
- Battery installation / Turning the power on -
Battery installation
Precautions for battery use:
Replace all old batteries with new ones at the same time.
Do not mix old and new batteries.
Remove the batteries if the unit is not to be used for long periods of time. This will
prevent potential damage due to battery leakage.
Caution:
Do not use rechargeable batteries (nickel-cadmium battery, etc.).
Incorrect installation may cause the unit to malfunction.
Battery (battery pack or batteries installed) shall not be exposed to excessive heat
such as sunshine, fire or the like.
Notes concerning use:
Replace the batteries if the operating distance is reduced or if the operation
becomes erratic. Purchase 2 “AAA” size batteries (UM-4, R03, HP-16 or similar).
Periodically clean the transmitter on the remote control and the sensor on the unit
with a soft cloth.
Exposing the sensor on the unit to strong light may interfere with operation. Change
the lighting or the direction of the unit.
Keep the remote control away from moisture, heat, shock, and vibrations.
Turning the power on
Test of the remote control
Check the remote control operation after making all the connections (see pages 12 -
18).
Point the remote control directly at the remote sensor on the unit.
The remote control can be used within the range shown below:
Press the ON/STAND-BY button. Does the power turn on? Now, you can enjoy your
system.
To turn the power on
Press the ON/STAND-BY button.
If the power does not turn on, check the AC power lead is plugged in properly.
1 Open the battery cover.
2 Insert the supplied batteries according to the direction indicated in
the battery compartment.
When inserting or removing the batteries, push them towards the battery
terminals.
3 Close the cover.
ON STAND-BY OPEN CLOSE
PRESET MUTE PRESET
OSDPLAYSLOW
TUNING TUNINGSTOP
PAUSE
SETUP
ENTER
FUNCTION
Remote sensor
0.2 m - 6 m
(8" - 20')
ON STAND-BY
Power stand-by indicator

20
HTCN650DVW_AUS.fm03/10/29
HT-CN650DVW
Preparation for Use
- Changing the setup menu -
Changing the setup menu
Turn on the TV, and switch the input to the “VIDEO 1”, “VIDEO 2”, etc.
accordingly.
Notes:
During playback, “PREFERENCES” settings cannot be changed.
Settings are stored even if the unit is set to the stand-by mode.
The backup function protects the stored settings for a few hours should there be a
power failure or the AC power lead disconnection.
If the startup screen is blurred, change the TV type in the setup menu.
1Press the ON/STAND-BY button to turn the
power on.
The startup screen appears.
The startup screen does not appear when the
input is not set to the disc mode. Press the
FUNCTION button to select DVD mode.
ON STAND-BY OPEN CLOSE
PRESET MUTE PRESET
OSDPLAYSLOW
TUNING TUNINGSTOP
PAUSE
TITLE
SETUP
ENTER
FUNCTION
MENU
PBC RETURN
LISTENING
EQUALIZER PROG
MODE
MIC
ECHO VOLUME
ANGLEZOOMSUBTITLEAUDIO
SLEEP DIRECT REPEAT A-B
123
456
78
0
9
SETUP
ON STAND-BY
FUNCTION
ENTER
2Press the SETUP button.
3Press the / or -button to select a menu
and press the ENTER button.
See the list on pages 21 - 25 for setup menu.
4Press the 8, 9, ; or :button to change the
setting and press the ENTER button.
See the list on pages 21 - 25 for the selectable
parameters.
5Press the SETUP button.
The setting is completed.
To change other settings, begin from step 2.
