Sharp AN-SS2 User manual

SOUND PARTNER
OPERATION MANUAL
MODEL
AN-SS2
ENGLISH

Introduction
Thank you for purchasing this SHARP product. To obtain the best performance from
this product, please read this manual carefully. It will guide you in operating your SHARP
product. AN-SS2 consists of Sound Partner and Bluetooth Transmitter.
Special Notes
FCC Notice
Supplier’s Declaration Of Conformity
SHARP SOUND PARTNER, MODEL AN-SS2
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and (2) this device must ac-
cept any interference received, including interference that may cause undesired
operation.
Responsible Party:
MIZARI ENTERPRISES, INC.
5455 WILSHIRE BOULEVARD, SUITE 1410, LOS ANGELES, CA 90036
TEL: 1-800-BE-SHARP
NOTE
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
z Reorient or relocate the receiving antenna.
z Increase the separation between the equipment and receiver.
z Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
z Consult the dealer or an experienced radio/TV technician for help.
Warning:
responsible for compliance could void the user’s authority to operate the equipment.

FCC RF Radiation Exposure Statement
1. This device must not be co-located or operating in conjunction with any other antenna
or transmitter.
For Bluetooth Transmitter:
2. This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with a
minimum distance of 20 centimeters between the radiator and person’s body.
For Speaker:
2. For body worn operation, this device has been tested and meets FCC RF exposure
guidelines. When used with an accessory that contains metal may not ensure compliance
with FCC RF exposure guidelines.
IC Radiation Exposure Statement (For Users In Canada)
This Class B digital apparatus complies with Canadian ICES-003 and RSS-210.
This device complies with Innovation, Science and Economic Development Canada’s
license-exempt RSS standard(s).
Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that may cause
undesired operation of the device.
Caution: Exposure to Radio Frequency Radiation:
1. To comply with the Canadian RF exposure compliance requirements, this device and its
antenna must not be co-located or operating in conjunction with any other antenna or
transmitter.
For Bluetooth Transmitter:
2. To comply with RSS 102 RF exposure compliance requirements, a separation distance
of at least 20 cm must be maintained between the antenna of this device and all persons.
For Speaker:
2. For body worn operation, this device has been tested and meets RF exposure
guidelines when used with an accessory that contains no metal. Use of other accessories
may not ensure compliance with RF exposure guidelines.
Special Notes (continued)

Special Notes (continued)
Additional Information
1. Radio frequency exposure
Sound Partner AN-SS2 is a radio transmitter and receiver. When in operation it
communicates with a Bluetooth
®
equipped mobile device by receiving and transmitting
to 2.48 GHz. This product is designed to operate in compliance with the RF exposure
guidelines and limits set by national authorities and international health agencies when
using compatible mobile phone.
Canada, Industry Canada (IC) Statement
Cet appareil numérique de classe B est conforme aux normes canadiennes ICES-003 et
RSS-247.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme
aux CNR d’Innovation, Sciences et Développement économique Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions
suivantes :
1. l'appareil ne doit pas produire de brouillage, et, and
2. l'utilisateur de l'appareil doit accepter tout brouillage radioelectrique subi, meme si le
brouillage est susceptible d'en compromettre le fonctionnement.
Attention: exposition aux rayonnements radiofréquences:
1. Pour se conformer aux exigences de conformité RF canadienne l'exposition, cet
appareil et son antenne ne doivent pas être co-localisés ou fonctionnant en conjonction
avec une autre antenne ou transmetteur.
Pour l'émetteur Bluetooth:
2. Pour se conformer aux exigences de conformité CNR 102 RF exposition, une
distance de séparation d'au moins 20 cm doit être maintenue entre l'antenne de cet
appareil et toutes les personnes.
Pour le président:
2. Pour une utilisation sur le corps, cet appareil a été testé et respecte les directives sur
l'exposition aux RF lorsqu'il est utilisé avec un accessoire sans métal. L'utilisation
d'autres accessoires peut ne pas garantir la conformité aux directives d'exposition aux
RF.

2. Battery information
-A rechargeable battery has a long service life if treated properly.
-A new battery or one that has not been used for a long period of time could have
temperatures, never above 122°F (50°C) or below 14°F (-10°C).
-For maximum battery capacity, use the battery at room temperature.
-If the battery is used in low temperatures, the battery capacity will be reduced. The
battery can only be charged in temperatures between 41°F (5°C) and 104°F (40°C).
-RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
- In case this product contains a battery incorporated within the product which cannot be
remove the battery, either for replacement or for recycling at the end of this product’s
working life. To prevent damage to the product, and for their own safety, users should
not attempt to remove the battery and should contact authorized independent service
providers for advice or call 1-800-BE-SHARP.
CAUTION:
Internal lithium battery in the unit should not be replaced by end users due to danger of
explosion if battery is incorrectly replaced and must be replaced with the exact type battery
by authorized service providers.
Special Notes (continued)
Recycling lithium-ion batteries
Lithium-Ion batteries are recyclable.
You can help preserve our environment by returning your used
rechargeable batteries to the collection and recycling location
nearest you.
For more information regarding recycling of rechargeable batteries,
call toll free
1-800-822-8837, or visit http://www.call2recycle.org/
Caution: Do not handle damaged or leaking Lithium-Ion batteries.
3. Removal of waste batteries and accumulators
(Product with embedded battery ONLY)

Special Notes (continued)
Avoiding hearing damage
If volume on the headset is too high, permanent hearing loss may occur. Please set the
volume to a safe level. You can become habitual to hear at high volume that may sound
speech, stop listening and have your ears checked by the specialist doctor. The louder
the volume, the more quickly the hearing can be damaged.
Hearing experts suggest how to protect your hearing
• Limit the amount of time you use the headset at high volume.
• Avoid the habit of increasing the volume so that you do not hear the loud noises around you.
• Turn the volume down if you cannot hear people speaking around you.
For setting the maximum volume limit of the connection device, refer to the instruction
manual supplied with the connection device.
Class B equipment (home-use broadcasting communication equipment):
This equipment is intended for home-use (Class B) electromagnetic compatibility
equipment and can be used in all areas.
FOR YOUR RECORDS
For your assistance in reporting this unit in case of loss or theft, please
record below the model number and serial number which are located on
the unit. Please retain this information.
Model number ..............................
Serial number ..............................
Date of purchase ..............................
Place of purchase ..............................
The Bluetooth
®
word mark and logos are registered trademarks owned by Bluetooth SIG,
Inc. and any use of such marks by SHARP is under license. Other trademarks and trade
names are those of their respective owners.
Qualcomm
®
aptX™ is a product of Qualcomm Technologies, Inc. and/or its subsidiaries.
Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and
other countries. aptX is a trademark of Qualcomm Technologies International, Ltd. registered
in the United States and other countries.

IMPORTANT SAFETY INSTRUCTIONS
Electricity is used to perform many useful functions, but it can also cause personal injuries and
property damage if improperly handled. This product has been engineered and manufactured
with the highest priority on safety. However, improper use can result in electric shock and/
installing, operating and cleaning the product. To ensure your safety and prolong the service
life of this product, please read the following precautions carefully before use.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11)
12)
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14)
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.
Additional Safety Information
15) Power Sources - This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply to your
home, consult your product dealer or local power company. For product intended to
operate from battery power, or other sources, refer to the operating instructions.
16) Overloading - Do not overload wall outlets, extension cords, or integral convenience
ck.

IMPORTANT SAFETY INSTRUCTIONS (continued)
17) Object and Liquid Entry - Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or short-out parts that could
n the apparatus.
18) Damage Requiring Service - Unplug this product from the wall outlet and refer servicing
a. When the AC cord or plug is damaged,
b. If liquid has been spilled, or objects have fallen into the product.
c. If the product has been exposed to rain or water
d. If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered the operating instructions as an improper
adjustment of other controls may result in damage and will often require extensive
mal operation,
e. If the product has been dropped or damaged in any way, and
f. When the product exhibits a distinct change in performance - this indicates a need
for service.
19) Replacement Parts - When replacement parts are required, be sure the service
shock, or other hazards.
20) Safety Check - Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks to determine that the product is in proper operating
condition.
21) Wall or ceiling mounting - When mounting the product on a wall or ceiling, be sure to
install the product according to the method recommended by the manufacturer.
22) Power Lines - An outside antenna system should not be located in the vicinity of overhead
power lines or other electric light or power circuits, or where it can fall into such power
lines or circuits. When installing an outside antenna system, extreme care should be
taken to keep from touching such power lines or circuits as contact with them might be
fatal.
23) Protective Attachment Plug - The product is equipped with an attachment plug having
overload protection. This is a safety feature. See Instruction Manual for replacement or
resetting of protective device. If replacement of the plug is required, be sure the service
same overload protection as the original plug.
24) Stand - Do not place the product on an unstable cart, stand, tripod or table. Placing the
product on an unstable base can cause the product to fall, resulting in serious personal
injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or
table recommended by the manufacturer or sold with the product. When mounting
the product on a wall, be sure to follow the manufacturer’s instructions. Use only the
mounting hardware recommended by the manufacturer.

Accessories
The following accessories are included.
Bluetooth Transmitter x 1
(AN-WD3)
Micro USB Charging Cable
x 1 (approx. 30 cm)
Micro USB Charging
Cable x 1
(approx. 1 m)
Audio Cable x 1
General
zDo not drop the product from a
high place.
zDo not place anything heavy on
the unit.
zDo not replace the battery, the
unit may explode.
zThis device is not a medical
device.
zIf you have a medical device
implanted, contact your doctor
before using this unit.
zKeep the unit away from direct
excessive dust, humidity and
electronic / electrical equipment
which generate electrical noise.
zDo not expose the unit
to moisture, to higher
temperatures or to extremely
low temperatures.
zDo not repair or disassemble
the unit. Refer internal service to
your local SHARP service facility.
z
lighted candles, should be
placed on the apparatus.
zMake sure that an infant or a
child does not swallow a small
components of the product.
zIf the unit is exposed to a large
amount of sweat, wipe the
product clean.
zThe apparatus is designed for
use in moderate climates.
zAttention should be drawn to the
environmental aspects of battery
disposal.
zThe ventilation should not
be impeded by covering the
ventilation openings with items,
such as newspapers, tablecloths,
curtains, etc.
z
do not expose this appliance to
dripping or splashing. No object
shall be placed on the apparatus.
Precautions

9
Audio In
Optical In
DC IN
Microphone
Bluetooth
Button
Power Button
Power Indicator
Optical/Audio Switch
Pairing Button
CLEAR
VOICE
Play/Pause/Mode Button
CLEAR
VOICE
Controls and indicators
Sound partner
Volume/Music Select Button
Bluetooth Transmitter
Clear Voice Button
USB terminal for charge
Speaker

Controls and indicators (continued)
Sound partner indicator status
Status Power indicator (Blue/Purple/Red)
Power Off Turns off.
Battery status
When the power is turned on, the power indicator
blinks three times according to the battery status.
zBlue : approximately 70% charge
zPurple : approximately 70% - 20% charge
zRed : approximately 20% remaining
Clear voice ON : blinks in purple once
OFF : blinks in purple twice
Power Indicator
Status Power indicator (Blue)
Connected Blinks once every 5 seconds
Connected Blinks in blue once every 5 seconds
Unconnected Blinks twice in about 5 seconds.
Unconnected Blinks in blue twice in about 5 seconds
No power source Turns off.
During pairing Blinks once in every seconds.
During pairing Blinks in purple once in every seconds.
Successful pairing Lights up for about 3 seconds.
Bluetooth transmitter
Indicator
Bluetooth transmitter indicator status
Charging Blinks once every seconds.(The power indicator
color changes according to the remaining
battery charge )
Fully charged Turns off.

Power Indicator Blinks in red
Battery status 20% remaining
Blinks in purple
20% - 70 %
Blinks in purple
approximately 70%
Cautions:
zAt extremely high or low temperatures, the battery may not be fully
charged.
zFor safety of the built-in battery, the function to stop charging works
depending on the ambient temperature. Charge the battery at room
temperature 5 ° C or above.
zTo maintain functionality, the device needs to be charged at least once
every six months.
zBattery of the device has limited life, as with any other rechargeable
batteries.
zCapacity may gradually be decreased over time of which extent may
vary depending on the conditions of use and external environment.
zThere are multiple factors such as volume level, external environment
etc that may affect the time of device power turning off, other than the
percentage of battery left.
zUse this product only with an agency approved power supply which
meets local regulatory requirements.
zThe equipment shall be connected only to a power supply with limited
power source.
Charging the Sound Partner
Charging the battery
1. Open the micro USB charging terminal cover and then connect the
micro USB charging cable.
2. Plug the other end of micro USB charging cable into a computer or USB
AC adaptor (5V, 1A) that is powered on.
Note: The sound partner does not operate while charging.
Charging Indication:
To computer or
USB AC adaptor
(commercially
available)

Bluetooth transmitter connections to TVs
Supplying power to the Bluetooth transmitter
Bluetooth transmitter connections
If you attach the included Bluetooth transmitter to your TV, you can enjoy
the sound of the TV with your sound partner.
Caution:
Turn off all other equipment before making any connections.
Notes:
zRefer the operation manual of the equipment to be connected.
zFully insert the plugs to avoid noises.
zIf you want to hear sound from both the television speaker and the sound
partner, see the instruction manual for the television.Some TVs may not
be able to output audio from both.
OPTICA L A UDIO
Optical cable connection:
Audio cable connection:
USB AC adaptor
(commercially
available)
Input selector
switch to OPTICAL
Optical digital
audio cable
(commercially
available)
OPTICAL AUDIO
Audio cable
zIf the TV/monitor does not have the optical output connect it to
the headphone socket.
zPower supply can be
obtained from USB
AC adaptor or TV/
monitor using micro
USB charging cable.

Connecting with Bluetooth transmitter (pairing)
Pairing with Bluetooth transmitter
1. Connect the Bluetooth transmitter to a TV
etc. Set the “input select” switch to the
connected audio cable or optical cable.
2. Press and hold the PAIRING button on the
Bluetooth transmitter for about 2 seconds.
Bluetooth transmitter indicator blinks blue.
3. Press and hold the POWER button on
the sound partner for about 2 seconds to
turn it on.
zWhen pairing is completed, you can hear the sound “CONNECTED”
from sound partner.
zIf you cannot pair automatically, please keep pressing the “Bluetooth”
button of the sound partner for about 2 seconds.
Notes:
zThe Bluetooth transmitter is only for the sound partner (AN-SS2 ). It
cannot connect to other devices.
zIf the connection between the supplied Bluetooth transmitter and
the sound partner does not work well, press and hold the Bluetooth
transmitter PAIRING button for about 10 seconds to reset, and try
again.
Indicator status:
Status Status indicator (Blue)
During pairing Blinks once in every seconds.
Successful pairing Lights up for about 3 seconds.
Connected Blinks once every 5 seconds.
Unconnected Blinks twice every 5 seconds.
OPTICAL AUDI O P AIRING
Bluetooth transmitter
Indicator
Pairing Button

Listening to the TV sound
1. Connect the paired Bluetooth transmitter to the TV
2. Set the Bluetooth transmitter’s input selector switch to the connected
audio cable or optical cable.
3. Turn on the TV and hold the POWER button on the sound partner’s for
2 seconds to turn it on.
If the sound partner does not connect, make the connection again follow
the procedure on page 11.
Volume control
Press the button to increase the volume
and press the button to decrease the
volume.
– When the volume level is set to maximum
– The volume does not change when press
quickly and continuously.
Muting
The volume is muted temporarily when pressing the button.
Press again to restore the volume.
Notes:
zWhen you are listening to audio by connecting an audio cable to the
headphone socket, the sound of the TV may be lower even if you
increase the volume of the sound partner unit, please increase the
headphone volume on the TV.
– If you want to output audio from both the TV speakers and the sound
partner, please refer to the TV instruction manual.
– If the product does not output audio from the TV’s speaker with the
audio cable connected, disconnect the audio cable from the
headphone socket before listening to audio using the TV’s speaker.
zTwo sound partner units can be connected to one supplied Bluetooth
transmitter. If you want to connect a second device, turn off the power
of the first sound partner, and then hold the Bluetooth transmitter's
PAIRING button for about 2 seconds to pair it. Turn on the second
sound partner unit and hold the “Bluetooth” button for about 2 seconds.
When the second pairing is complete, please power on the first sound
partner.
LEAR
VOICE
Volume / Song Selection Button
Play / Pause / MODE Button

Listening to Bluetooth enabled devices
Bluetooth
Bluetooth wireless technology is a short-range radio technology that enables
wireless communication between various types of digital devices, such as
mobile phone or computer. It operates within a range of about 10 meters (30
feet) without the hassle of having to use cables to connect these devices.
AN-SS2 supports the following:
Communication System: Bluetooth
(Advance Audio Distribution Profile), and AVRCP (Audio/Video Remote
Qualcomm® aptX™ audio
Qualcomm® aptX™ audio is a Bluetooth wireless technology that prevents
loss of sound and provides CD-quality audio. You can enjoy clear audio sound
when listening to music and watching movies. Qualcomm® aptX™ audio
works automatically only on the phones or the audio devices that support
Qualcomm® aptX™ audio.
zQualcomm aptX and Qualcomm cVc are products of Qualcomm
Technologies, Inc. and/or its subsidiaries.
zQualcomm is a trademark of Qualcomm Incorporated, registered in the
United States and other countries.
zaptX and cVc are trademarks of Qualcomm Technologies International,
Ltd., registered in the United States and other countries.
Notes when using unit with a mobile phone
zPlease refer to the operating manual supplied with the mobile phone for
details on operation of your mobile phone while transmitting the sound using
a Bluetooth connection.
Bluetooth
data. This unit can memorise up to a maximum of 8 devices. Once paired, it is
not necessary to pair them again unless:
zpairing is made with more than 8 devices. Pairing can only be made one
device at a time. If subsequent device is paired, the oldest device paired will
be deleted and replaced with the new one.

1. Press the POWER button to turn on the sound
partner.
2. Press and hold the Bluetooth button for about
2 seconds.
The power indicator is turned on
and blinks in blue.
3. Perform pairing procedure on the source device
to detect this sound partner. “AN-SS2 SHARP”
will appear in the detected devices list (if
available) in the source device. (Refer the
source device operating manual for details).
4. When pairing is completed the voice prompts
Notes:
zTo pair with other device, repeat steps 1-4 for each device.
During pairing mode the power indicator turns purple.
zDue to the security feature of the Bluetooth device, some devices may not
be able to be paired.
zMake the Bluetooth connection again if the source device is not turned on,
or its Bluetooth functionality is off or is in sleep mode.
zOnce a device is ousted or deleted from the pairing list, the pairing
information for the device is also deleted. To listen to the sound from the
device again, it needs to be re-paired. Perform steps 1-4 to pair the device
again.
zThis sound partner can be paired to a maximum of 8 devices. If subsequent
device is paired, the oldest device paired, will be deleted and replaced with
the new one.
Listening to Bluetooth enabled devices (continued)
Pairing Bluetooth devices
AN-SS2 SHARP

Listening to Bluetooth enabled devices (continued)
Listening to the sound
Check that:
zThe source device Bluetooth functionality is ON.
zPairing of this sound partner and the source device is completed.
zThe transmission distance of the wireless signal between the device
and the sound partner is about 10 meters (30 feet).
1. Press the POWER button to turn on the sound
2.
partner.
During connecting the power indicator blinks in
blue.
Sound partner is in connected mode.
When connected the power indicator will
blinking once every 5 seconds.
3.Press the button on the source device to
start Bluetooth streaming playback.
Function Operation
Volume up Press the button.
Volume down Press the button.
Skip up
Press and hold the button for about 2 seconds.
Reverse
Press and hold the button for about 2 seconds.
VOICE
Play / Pause / MODE Button

Listening to Bluetooth enabled devices (continued)
About playback operation
Function Operation
Play/Pause or
mute Press the button.
Volume up Press the button.
Volume down Press the
Press the CLEAR VOICE button to switch to
On/Off the function.
( It's a mode to listen to the voice of a person
with a clear voice )
button.
Skip Up
Press and hold the button for about 2 seconds.
Reverse
Press and hold the
Press and hold the Bluetooth and for about 5
seconds.
Pairing will be canceled for 10 seconds, so please
pair with the device you want to switch to in the
meantime.
button for about 2 seconds.
CLEAR VOICE
on/off
Enable
Switching a
paired device
Bluetooth
device Voice
Control
Press Bluetooth button.
zYou can access voice controls on mobile devices
to make calls, play music, ask for weather, check
sports scores, etc.
zThis function does not work when the mobile
device is not compatible.
Notes:
Some Bluetooth devices may not be able to perform the above operations,
such as limited playback operations.
zVoice Control supports looge Assistant / Siri. Other applications are
not supported.

Call functions
You can receive a call through this sound partner when
it is connected to a mobile device such as a smartphone via Bluetooth .
About call operation
Function Operation
Answer a call Press the button.
End a call Press and hold the button for about 2 seconds.
Switch voice to
smartphone
Press and hold the button for about 2 seconds.
zPress and hold the button for about 2 seconds
again to switch the sound to sound partner.
Mute a call Press and hold the button for about 2 seconds.
Unmute a call Press and hold the button for about 2 seconds.
Decline an
Japanese English Chinese Off
incoming call Press and hold the button for about 2 seconds.
Note:
Some mobile devices do not support the Call Function feature.
Thus, this operation may not work.
Disable or change language of voice prompts
The sound partner performs voice prompts according to the operation.
If you want to disable or change language of voice prompts, use the
following procedure.
Press and hold the CLEAR VOICE button and button simultaneously
for about 5 seconds.
