Sharp EC-SC85H-H User manual

EC-SC85H-H
Read this carefully before first
use. Keep this manual for further guidance in case.
Operation
Manual
Cordless Vacuum Cleaner
operation manual

EN-1
Contents
……………………………………………………………………............... EN-1
Introduction of Product Components
…………………………………………………… EN-3
Operation Method
…………………………………………………………………………………….…… EN-4
Troubleshooting ……………………………………………………………………………………………… EN-7
Safety Operation Guide
Safety Operation Guide
Specifications ……………………………………………………………………………………..........……… EN-7

EN-2
Battery Safety:
Service:
Handle Latch
Aluminium Tube
Latch
Charger
Long Crevice Nozzle
Bristle Brush Nozzle
Hanger Carpet Rolling Brush
EN-3
Introduction of Product Components
Safety Operation Guide
Power Rolling Nozzle
On/Off Button
Dust Cup
Aluminium Tube Latch

4.Press the On/Off button to start the machine.
Two suction speeds control.
a. Turn on the On/Off button to use the low speed mode.
b. Press the On/Off button again to change to
high speed mode.
c. Press the On/Off button again to stop the machine.
II. How to use as a handheld vacuum:
Insert the accessory(bristle brush or long crevice ) to the main part as
shown below until hearing the click sound
I.Use as the stick vacuum cleaner:
1.Assemble the battery into the dust cup, make sure the battery bolt head is inserted
into the dust cup slot rightly as below.
2.Attach the aluminium tube to the main part as below until hearing the click sound.
3.Attach the head to the tube as shown below.
Operation Method Operation Method
Battery Bolt head
On/Off Button
Dust Cup Slot
Power on
Power off
High speed
（+） Low speed
III. How to charge:
Note： Hanger installation method
1. Use expansion screws to hang the vacuum cleaner on the wall.
Blinking
Wall
EN-5EN-4
1) When only one indicator light is blinking, please turn off the appliance. Hang up the
machine and then plug in charger power cable into the main body for charging.
When charging, the indicate lights will become flashing white.

2) It will have 3 White lights on after fully charged.
IV. Dust cup cleaning method
Operation Method Troubleshooting/Specifications
1）Press the handle latch
remove the battery from dust cup.
3）Take out the filter case, then
take out the filter.
5）Please dry the filter and the filter
case completely before assembling back.
7）Put the filter case back to the
dust cup.
※Troubleshooting:
※Specifications:
8）Assemble the top cover to the
dust cup.
6）After drying, assemble the filter
to the case.
Wash the filter case and the filter）4
by water.
2）Separate and remove the top cover
as shown below.
Suction gets weak
1. Empty the dust cup
2. Check if the dust cup is installed correctly
3. Check if the filter case and the filter are installed
correctly
4. Clean the filter
Stop working 1. Charge the vacuum
2. Clean the rolling brush and the bearing thoroughly
Battery doesn t hold
a charger
1. Check if the plug has been inserted already
2. Check if the socket is useful
4～5
hours
Power supply Input 100-240V~50-60Hz (Charger)
Power supply method Rechargeable type ( lithium ion battery,22.2V )
Electric power consumption While charging : Approx. 11.7W;
After charging : Approx. 0W
Continuous operation time
High: Approx. 15 mins
Dust collecting capacity 0.5L
Charging time 4-5 hrs
Weight(Charger) 88g
Base unit dimensions 255mm W × 1040mm H × 220mm D
Charger dimensions 51mm W × 36mm H ×77mm D
Cord length（Charger） 180cm
2.7kg
Weight(Suction head,pipe,
base unit and battery included)
EN-7EN-6
Low: Approx. 40 mins
to

SHARP CORPORATION
