Super Charged Twin EnergyTM
Cleaning System
Sharp vacuum cleaners are now more power-
ful than ever—for better Combined Cleaning
Performance than other models! Three
revolutionary innovations loosen deep-down
dirt, increase air flow, and strengthen suction
power for more thorough and effective cleaning!
Loosens Deep Down Dirt
Optimal carpet agitation removes deeply
embedded dirt better than ever! Because the
agitator is twisted 540-degrees, three brushes
are in contact with the floor at all times instead
of two like on conventional models.
Maximizes Air Flow
Air flow is necessary to effectively remove dirt.
The Super Charged suction system uses a
smaller diameter brush with deeper agitator fins
to maximize air flow across the nozzle and
produce 6 times more air flow than other models!
Strengthens Suction Power
The power of the Sharp Twin EnergyTM motor
pulls up to 80” of water lift for strong effective
suction that cleans carpets like never before!
Combined Cleaning Performance
Powerful, Total Cleaning Performance
EC-T2840
Upright Vacuum Cleaner
EC-T2840 Upright A Upright B
EC-T2840 Upright A Upright B
EC-T2840 Upright A Upright B
100
90
80
70
60
50
40
30
20
10
0
2
1.8
1.6
1.4
1.2
1
0.8
0.6
0.4
0.2
0
92%
90%
86%
84%
82%
80%
76%
74%
72%
70%
68%
Vacuum
Pressure
(in. H20)
Air Flow
(m/s)
Superior
Cleaning
Performance
(% of cleaning
efficiency)
And
Results In
Twin Energy Motor
The Twin Energy motor creates a more powerful
vacuum to pull out deeply buried dust and dirt.
Easy-to-Remove Metal Bottom Plate
Metal bottom plate removes easily if belt or
agitator needs replacement.
Six-Stage Filtration with HEPA-Type Filters
A six-stage filtration system keeps the exhaust
air clean. First, the highly efficient top fill Twin
Ply paper bag captures over 99% of fine dust
and pollen down to 5 microns. A secondary
filter traps fine dust particles. The Twin HEPA-
type motor exhaust filters with bonded micron
filters trap super fine particles and provide
final air purification.
Automatic Carpet Height Adjustment
You can move the vacuum cleaner from one
carpet area to another without having to make
adjustments.
Convenient Full-Time On Board Tools
Now, all on board tools are permanently
attached to the vacuum cleaner, providing
greater convenience from floor to ceiling
cleaning. Detach the tools from the front and
you can clean anywhere effortlessly.
Library QuietTM
Talk on the telephone while vacuuming! Sharp’s
Twin Energy vacuum cleaners are library quiet
at 69 decibles.
Comparative Noise Levels (db)
Protective Motor By-Pass System
Powerful suction pulls dirt through an outer
hose, by-passing the motor. Protects motor
fan from damage if coins or other hard
objects are picked up.
Rock Music
Snow Mobile
Lawn Mower
Standard Vacuum Cleaner
Alarm Clock
Busy Traffic
Sharp Vacuums
Dishwasher
Average TV/Radio
Whisper
Specifications
Power Supply AC 120V, 60Hz
Motor Amp 12.0 Amps
Motor Wattage 1,300 W
Filter System 6-Stage Filtration with
HEPA Type Filters
Agitator 12” (Acrylic)
Microfiltration Paper Bag Yes, Twin Ply
Replaceable Brushes No
Dust Indicator No
Power Control No
Headlight Yes
Rug/Floor Selector No
Edge Cleaning Yes
Height Adjustment Automatic
Power Cord 24 ft.
Body Color Bright Wine Red
Dimensions (W x D x H) 14-3/4” x 13-1/2” x 45-1/2”
Shipping Volume 2.64 cu. ft.
Net Weight 16.6 lbs.
Shipping Weight 19.7 lbs.
Pedal Release Yes
O.B.T.* Yes (Full-Time)
Warranty: One-year limited warranty on parts and labor.
See operation manual for complete details.
UPC Code: 074000681293
*O.B.T. include Two Plastic Wands, Crevice Tool and Combination Soft Brush
**Optional Deluxe On Board Tool Kit, EC-07AU2
Specifications are subject to change without notice.
VM-02-087
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
Sharp Electronics Corporation
Sharp Plaza, Mahwah, NJ 07430-2135
1-800-BE-SHARP
www.sharp-usa.com
Twin PlyTM
Paper Bag Secondary
Filter Motor
Filter
Twin HEPA-Type
Filters with
Micron Filters
