Sharper Image HF767 User manual

Programmable
Percussion
Massager
with Heat &
Adjustable Width
HF767 Instructions
Read and save these instructions.
HF767 IM_v1 0607.indd 1 7/2/07 4:34:50 PM

Table of Contents
Warnings ...................................................................................3
Quick Start ................................................................................8
General Instructions...................................................................9
Operation ..............................................................................9
Auto-Spacing Feature...........................................................12
Massage Head Attachments..................................................13
Massage with Thermal Heats................................................14
Maintenance........................................................................15
HF767 IM_v1 0607.indd 2 7/2/07 4:34:50 PM

IMPORTANT SAFEGUARDS
WHEN USING ELECTRICAL PRODUCTS, ESPECIALLY WHEN
CHILDREN ARE PRESENT, BASIC SAFETY PRECAUTIONS
SHOULD ALWAYS BE OBSERVED, INCLUDING THE
FOLLOWING:
READ ALL INSTRUCTIONS BEFORE USING.
DANGER – TO REDUCE THE RISK OF ELECTROCUTION:
•Always unplug the appliance from the electrical outlet
immediately after using and before cleaning.
•Do not reach for an appliance that has fallen into water.
Unplug it immediately.
•Do not use while bathing or showering.
•Do not place or store appliance where it can fall or be pulled
into a tub or sink.
•Do not place in or drop into water or other liquid.
WARNING – TO REDUCE THE RISK OF BURNS, ELECTROCU-
TION, FIRE OR INJURY TO PERSONS:
•An appliance should never be left unattended when plugged in.
Warnings
3
HF767 IM_v1 0607.indd 3 7/2/07 4:34:50 PM

•Unplug from outlet when not in use and before putting on or
taking off parts or attachments.
•Close supervision is necessary when this appliance is used by,
on or near children, invalids or disabled persons.
•Do not use outdoors.
•Use this appliance only for its intended use as described in
this manual.
•Do not use attachments not recommended by manufacturer;
specifically any attachments not provided with the unit.
•Never operate this appliance if it has a damaged cord or plug, if
it is not working properly, if it has been dropped or damaged, or
dropped into water.
•Use heated surfaces carefully. May cause serious burns.
DO NOT use over sensitive skin areas or if you have poor
circulation. The unattended use of heated unit by children or
incapacitated persons may be dangerous.
•Keep the cord away from heated surfaces.
•Never block the air openings of the appliance or place it on a
soft surface, such as a bed or couch, where the air openings
may be blocked. Keep air openings free of lint, hair, etc.
Warnings
HF767 IM_v1 0607.indd 4 7/2/07 4:34:50 PM

•Never use while sleeping or fall asleep while using the massager.
•Never drop or insert any object into any opening.
•Do not operate where aerosol (spray) products are being used
or where oxygen is being administered.
•Do not use on or near eyes, temples or other highly
sensitive areas.
•Do not operate under a blanket or pillow. Excessive heating can
occur and cause fire, electrocution or injury to persons.
•Do not carry this appliance by the supply cord or use the cord
as a handle.
•Do not use the percussion action massager directly on one
concentrated area of the body. Percussion action massagers
are designed to be used in a continuous motion, constantly
changing the massage area.
•To disconnect, turn all controls to the OFF position, then
remove the plug from the outlet.
•This appliance is designed for household use only.
SAVE THESE INSTRUCTIONS.
Warnings
5
HF767 IM_v1 0607.indd 5 7/2/07 4:34:50 PM

Caution: Please read all instructions carefully before operating.
•If you have any concerns regarding your health, consult your
doctor before using this product.
•Individuals with pacemakers should consult a doctor before use.
•Never leave the appliance unattended, especially if children
are present.
•Never cover the appliance when it is in operation.
•Do not use this product for more than 15 minutes at a time.
Extensive use could lead to the product’s excessive heating and
its shorter life. Should this occur, discontinue use and allow the
unit to cool before operating.
•Never use this product directly on swollen or inflamed areas or
skin eruptions.
•This product is a nonprofessional appliance designed to provide
soothing massage to worn muscles. Do not use this product as a
substitute for medical attention.
•Do not use this product before bed. The massage has a stimu-
lating effect and can delay sleep.
Warnings
6
HF767 IM_v1 0607.indd 6 7/2/07 4:34:50 PM

•Never use this product while in bed.
•This product should never be used by any individual suffering
from any physical ailment that would limit the user’s capacity to
operate the controls.
•This unit should not be used by children or invalids without
adult supervision.
Caution: In case of pregnancy, diabetes or illness, consult your
doctor before using massager.
Caution: Never use the heat feature without the proper
attachment.
Warnings
7
HF767 IM_v1 0607.indd 7 7/2/07 4:34:51 PM

1. Plug the unit into a polarized wall outlet.
2. Select and attach the desired massage head.
3. To turn the unit on, press the POWER button located above
the handle.
4. For steady massage, press the MASSAGE button on the
control panel. To increase or decrease the intensity level,
press the up or down arrows.
5. For a programmed massage, press the PROGRAM button until
the desired program is lit. To select the interval level, press the
INTERVAL button until desired interval is lit.
Note: When using the red heat-massage heads, press the HEAT
button to activate heat in any massage mode. Do not use the
heat function with any other massage head.
6. Gently apply massage heads to the area you wish to treat and
slowly move in a circular motion. Treat for a short period of
time and then move to another area. Never treat the same
area for longer than three minutes.
Note: A massage session longer than 15 minutes is not
recommended.
Quick Start
8
HF767 IM_v1 0607.indd 8 7/2/07 4:34:51 PM

7. When treatment is complete, turn the unit off and unplug it
from the outlet. Store it in a cool, dry place.
General Instructions
Operation
To reduce the risk of electric shock, this appliance has a polar-
ized plug (one blade is wider than the other). This plug fits in a
polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet. Do not alter the plug in
any way.
1. This unit is powered by the included UL-approved cord.
To power the unit untie the cord strap, extend cord and
insert the plug into a 120V household electrical outlet.
2. Select and attach the desired massage head. (See Massage
Head Attachments.)
3. To turn the unit on, press the POWER button located above
the handle. A corresponding LED light illuminates to indicate
unit is on.
Quick Start
9
HF767 IM_v1 0607.indd 9 7/2/07 4:34:51 PM

4. Choose the desired massage option: steady or program.
(See 5. & 6.)
5. For steady massage, press the MASSAGE button. To increase
or decrease the massage intensity level, press the up or
down arrows on each side of the MASSAGE button in the
center of the control panel.The number of LEDs lit above the
MASSAGE button (1-5) indicates the intensity level.
6. For a programmed massage, press the PROGRAM button on
the upper right-hand side of the control panel until the desired
program is lit. Choose any of the three program options:
• Program 1 provides slow, steady percussion action to relax
and revitalize. (Bottom Program LED is lit.)
•
Program 2 provides intense massage action to penetrate
and soothe. (Center Program LED is lit.)
•
Program 3 provides short, quick bursts for energizing
stimulation. (Top Program LED is lit.)
Operation
Program 1 Program 2 Program 3
HF767 IM_v1 0607.indd 10 7/2/07 4:34:51 PM

Note: In the programmed massage mode, an interval level
may be chosen by pressing the INTERVAL button on the upper
right side of the control panel. There are three interval options:
Interval 1 = low (bottom LED), Interval 2 = moderate
(center LED), and Interval 3 = high (top LED).
7. Gently apply massage heads to the area you wish to treat and
slowly move in a circular motion.
8. Treat the target area for a short period of time, then move
to another area. Never treat the same area for longer than
three minutes.
Caution: As stated in the Warnings section of this manual, never
use this appliance on or near the eyes, temples or other highly
sensitive areas.
9. A massage session longer than 15 minutes is not recommended.
10.When treatment is completed, turn the unit off and unplug it
from wall outlet. Properly store the unit in a cool, dry place.
Note: For added protection, if the power is on but a function
is not selected, or the Heat function has been selected with
no massage function, the unit automatically shuts off after
15 minutes.
Operation
11
HF767 IM_v1 0607.indd 11 7/2/07 4:34:51 PM

Auto-Spacing Feature
The spacing between the massage heads can be adjusted to fit
various body frames and areas. (See Figure 2.)
Figure 2
1. To adjust the spacing between the massage heads, turn the
unit on and push and hold the button on the underside of the
massager. (See Figure 3.) Heads continue to cycle in and out
as long as the button is held down.
Figure 3
12
Button
HF767 IM_v1 0607.indd 12 7/2/07 4:34:52 PM

2. As soon as you find the desired spacing for maximum
comfort, release the button.
Massage Head Attachments
Your massager comes with four custom massage head
attachments. Each set has a different level of firmness:
Hard = light grey Soft = black
Medium = medium grey Heat = red
1. To remove the massage heads from the unit, rotate each
counterclockwise.
2. To attach the massage heads, rotate clockwise. (See Figure 4.)
Figure 4
Auto-Spacing Feature
13
HF767 IM_v1 0607.indd 13 7/2/07 4:34:52 PM

1. Locate the two red (heat) attachments. Attach one to each
massage head by turning clockwise to secure. (See Figure 4.)
2. Choose the desired massage option and press the HEAT button.
3. The heat feature works only in conjunction with the heat
massage attachments. The heat indicator illuminates when
used with other attachments, but heat will not be felt.
Note: To eliminate the risk of being burned, never use the heat
function without the heat attachments. Do not use the thermal
heat continuously for more than 15 minutes. Do not use the
thermal heat if you have sensitive skin, poor circulation,
discolored areas, swelling, burning, inflammation or an area
where skin eruptions or sores are present. Heat should be
pleasant and comfortable. Should pain or discomfort result,
discontinue use and consult your physician.
Massage with Thermal Heats
14
HF767 IM_v1 0607.indd 14 7/2/07 4:34:53 PM

Maintenance
To Clean
Be sure to unplug the unit and allow it to cool before cleaning.
To wipe clean, use a soft, slightly damp cloth. Never allow water
or any liquids to come into contact with the handle.
To Store
Unplug the massager from the outlet and allow it to cool
before storing in its box or a clean, dry place. Coil the cord
and secure it with the included fastener. Do not hang the
unit by the power cord.
15
HF767 IM_v1 0607.indd 15 7/2/07 4:34:53 PM

Warranty
What Is Covered
This warranty covers any defects in materials or workmanship, with the exceptions stated below.
How Long Coverage Lasts
This warranty runs for 90 days from the date of original purchase.
What Is Not Covered
This warranty does not cover damage caused by misuse or use other than as intended and described
in the product instruction manual, or loss or damage to batteries or removable parts.
What The Sharper Image Will Do
The Sharper Image warrants this product against defects in materials and workmanship. When repair is
not practical, The Sharper Image will have the option to replace the defective product with one that is
the same or has similar functionality.
How to Obtain Service
Return the product and receipt, along with a brief explanation of the problem, to:
T.S.I. - Returns Department
2901 West 60th Street
Little Rock, AR 72209
If you have questions, please feel free to contact our customer service representatives at
1-800-344-5555 or by email at [email protected].
This warranty gives you specific legal rights, and you may have other legal rights that vary from state to state.
© 2007 Sharper Image Corporation
Sharper Image Corporation
350 The Embarcadero, Sixth Floor
San Francisco, CA 94105-1218
Shop online:
Actual product may differ slightly from the product described herein.
V1 06/07
HF767 IM_v1 0607.indd 16 7/2/07 4:34:53 PM
