Shire GSHE0706DSL-1AA User manual

© Gazebo Summerhouse 2020
Version 426/04/2021 Julian Shepherd
These instructions are for your safety. Please read through them thoroughly before use.
PLEASE KEEP THIS LEAFLET FOR FUTURE REFERENCE
GSHE0706DSL-1AA 5060437982039
PT GSHE0606PSL-1AA 5060490133447
Batch No
xxxx

Let’s
get started...
GB
IE
Important information...
Safety 03
Preparation of base 04
Warranty 04
Care, maintenance & Recycling 05
[e-mail]
Brigstock Road Wisbech Cambridgeshire PE13 3JJ
Tel [phone]
F Pour obtenir un exemplaire des instructions ou une copie dans une autre
langue s'il vous plaît envoyez un e-mail ou écrire à l'adresse ci-dessous.
PL Na kopii instrukcji lub kopii w innym języku prosimy o wysłanie maila
lub pisaćna adres podany poniżej.
RUS Для получения копии инструкции или копия на другом языке, пожалуйста, отправьте по электронной почте или написать по
указанному ниже адресу.
TR Başka bir dilde talimatlarıveya bir kopyasınıbir kopyasıiçin bir e-posta
gönderebilir veya aşağıdaki adrese yazınız.
EN For a copy of the instructions or a copy in another language please send
an email or write to the address below.
I Per richiedere una copia del libretto di istruzioni, in italiano, o in un’altra
lingua, per favore, invia una e-mail o scrivi a l’indirizzo sottostante.
02
In more detail...
Parts List 06
Hardware chart 08
Before you start 09
12-28Assembly instructions
Detailed Technical Drawing 10-11
Fascia & Nail List 07

We advise the use of non slip protective gloves throughout
the assembly process.
We advise the use of steel capped protective footwear
throughout the assembly process.
We advise the use of protective headwear and safety
goggles throughout the assembly process.
Where a ladder is in use another person must hold the
ladder.
Do not attempt to work in windy conditions.
We advise the use of a scaffold tower when fitting the roof,
for felting or if you cannot reach from the ground.
Do not allow children near the tools and work area.
Follow any safety precautions quoted by the manufacturer
for any equipment you use.
We advise that you use a helper to hold the glass in position
whilst you nail the beading in place.
Check all parts before assembly.
Only use child and animal safe wood preservative.
Do not use creosote.
Allow the wood preservative to fully dry before use.
Regularly check the building for wear and tear.
Getting Started…..
GB
IE
EVERY PRECAUTION IS TAKEN TO ENSURE THAT YOUR BUILDING HAS NO
ELEMENT INCORRECTLY PLACED OR POSSIBLY HAZARDOUS, HOWEVER
PRIOR TO USE PLEASE CHECK ALL SURFACES FOR THE FOLLOWING:
(1) RAISED GRAIN, SPLINTERS: Sand down timber to smooth finish
(2) NAIL/SCREW/PIN HEADS PROUD: Tap home to be flush with surface of
timber
(3) DAMAGED SCREW HEADS RESULTING IN SHARP SPLINTERS OF
METAL: Replace
(4) SHARP ENDS OF NAILS/ SCREWS/ PINS PROTRUDING THROUGH THE
PANEL: Remove and reposition
(5) ENSURE ALL PARTS ARE SECURED AGAINST REASONABLE FORCE:
Remove and refit
(6) ENSURE THERE ARE NO LOOSE PARTS: Remove and refit/discard
Important!
Safety
IMPORTANT ! For your safety please read
carefully the safety warnings
Check that you have noted all the following instructions:
03

Getting Started…..
GB
IE Base and Warranty
The following are also excluded:
 Damage resulting from poor assembly
 Poor treatment application
 Poor care and maintenance
 Changes to the design
 Misuse
 General wear and tear.
Warranty...
10 Year anti rot warranty subject to the following:
 The building must be raised so it is not in contact with any water
retaining base surface (for example grass)
 This can be achieved using a timber, concrete or slab base
 When using a concrete or slab base use damp proofing strips
under the bearers
 The building must have been completely treated and sealed
immediately prior to or after assembly
 The building must have been re-treated and re-sealed annually
NOTE: Wood is a natural product and therefore the following are
excluded from the warranty:
- Colour change
- Warping
- Splitting.
Preparation of base...
We recommend that the base onto which your building will stand should be at least
75mm larger in each direction than the total floor size of the building.
Actual floor area of the building: 2156mm x 1867mm
Total height clearance: 2675mm
Roof size: 2410mm wide x2080mm long
The chosen position in your garden for your building should be excavated to a depth
of 75mm to allow a base of sand, on to which paving slabs can be evenly laid.
You may also use an adjustable timber base or a concrete base. Whatever base you
decide upon IT MUST BE LEVEL AND FIRM.
04

Care, Maintenance and Recycling
1. Pallet and timber widely recycled
2. Cardboard widely recycled
3. Plastic strapping subject to local regulations
4. Plastic sheeting subject to local regulations.
(1) Visually check for weather damage.
(2) Check and replace if necessary any Silicone sealant if used on your
building.
(3) Check the roofing material for wear.
(4) The doors and windows may require periodical adjustment.
(5) Ensure your building is well ventilated especially during hot weather.
(6) During extremely hot periods humidify your building to prevent the timber
from drying out.
The 5 golden rules of care:
The 6 golden rules of maintenance:
1. Timber widely recycled
2. Metal fixings widely recycled
3. Glass widely recycled
4. Roofing felt not currently recycled.
packaging
Building
(1) Ensure your base is level and firm.
(2) Ensure the building is not sitting directly on the ground using damp proof
membrane or the optional timber base.
(3) Ensure every piece of timber and surface, especially that is hidden upon
assembly is treated with a top quality wood preservative at least twice
(before assembly). Turn the panels upside down whilst painting so the
treatment runs into the seams.
(4) Garden buildings are not waterproof, therefore we recommend you seal
between all the panels with a silicone based sealant.
(5) Regularly check your roofing felt for weather damage and leaks.
Getting Started…..
GB
IE
05
Recycling and disposal:

Stacked Parts List
Description
(part No ) - Qty
06

Fascia Bag Parts List
Description
(part No ) - Qty
Nail Bag Parts List
Description
(part No ) - Qty
07

08
Hardware Chart
Scale 1:1
(A0266) x350
8mmFelt Nail
(A0025) x24
40mmRound head nail
(A0032) x41
25mm Posi-drive screw
(A0035) x46
60mmPosi-drive screw
(A0036) x06
80mm Posi-drive screw
Nail bag contents
8mm
Description
(part No ) - Qty
(A0557) x18
50mm Posi-drive screw
50
(A0031 ) x10
Posi-drive screw
Black 25mm
(A0024) x144
16mm Panel Pin

09
Before you start...
Things to check before you start:
Check all parts as listed in the parts lists
Read the instructions fully before starting work
Follow all the health and safety guidelines.
Ensure your base is ready – See page 4
You will need:
Hammer
Spirit level
Ladder
3mm 5mm drill bit
Drill
Tape measure & Ruler
Sand paper
Gloves
Saw
Pencil
Goggles
A helper for some
tasks
 Screwdriver
 Sharp knife
Pliers
When you see the drill icon
Only ever drill through the first
piece of framework which will be a
pilot hole for the screw to attach the
second piece of framework
The required drill bit size is
shown with the icon.
6mm
In more detail…..
GB
IE

10
In more detail…..
GB
IE

11
In more detail…..
GB
IE

Assembly
These instructions are for your safety. Please read through them thoroughly before use .
Treat all the parts before assembly –see page 5
(part No ) qty
Description
GB-IE Get a helper to hold the window in the open position. Put one screw in each hinge first and check the
window closes correctly before adding the remaining screws.
Casement stay and pins ”A0038” must fit together loosely. Position as shown.
Fix the casement stay to the window insert first. Then mark and fix the pins .
0
1
Window panel
(A4070)x02
Window Insert
(B0025)x02
GB-IE The hinges fit the top of the window. Try the window in position to check that you have it the correct way
around.
Hinges
(A0013) x04
25mmScrews
(A0032)x08
02
25mmScrews
(A0032)x12
Step 1 x 02
Casement set
(A0038) x02
12

13
GB-IE Lay the door B0055p face down and carefully place the door panel A4071 over the top of it, outer face down.
Position the door with an even gap and fix at each hinge with the one visible screw.
Carefully turn the assembly over, open the door and add the remaining screws.
04
03
Door
(B0055p)x01
GB-IE Position 3 hinges on the door and fix at the 2 inner holes.
Hinges
(A0013) x03
25mmScrews
(A0032)x06
3mm
Door
(B0055p)x01
25mmScrews
(A0032)x15
Door Panel
(A4071)x01

14
Step 4
GB-IE Position the Gate latch “A0015" on the outside over the door”A0012” framework.
Mark the screw holes as shown. Drill the middle hole only and fit the "SQUARE SHAFT" in the hole,
locate the two ring handles onto the shaft and fix to the door.
Align and pre drill the catch plate with the latch block and fit to the adjacent panel.
05
GB-IE
Drill through the frame on the long edge of one floor only.
Push the floors together and fix.
Carefully turn the floors over and position on your base.
06
5 mm
Floor Half
(A3957)x02
60mmScrew
(A0035)x04
5 mm
25mmBlack screw
(A0031)x10
Latch Block
(A1172) x07
44mm
12mm
Outside
Gate latch
(A0015) x01

15
GB-IE Drill 3 holes through each side of the Plain panels A5633 framework and two for the floor.
The bottom of the panels have an overhang which fits flush to the floor.
The widest part of the post must be on the outside. The widest part must be flush with the outside
cladding. The post is 10mm shorter than the panel. Fix using the holes just drilled.
07
Do not screw to the
floor until asked
5 mm
60mmScrew
(A0035)x06
Plain Panel
(A5633) x02
44mm
Corner Post
(A4069)x01

GB-IE
16
Position and fix the last plain panel to the RH post.
Fix another post to the plain panel that you just fitted.
09
GB-IE
Position and fix two posts as before.
08
60mmScrew
(A0035)x06
44mm
Corner Post
(A4069)x02
60mmScrew
(A0035)x06
Plain Panel
(A5633) x01
44mm
Corner Post
(A4069)x01

17
GB-IE Using the holes drilled previously fix the window panel to the LH post.
Fix another post to the window panel as before.
11
GB-IE .
Pre drill both of the window panel assemblies
Drill three holes in each side at an angle so you can get the screw in and two at the bottom.
10
Window panel
Step 2 x 02
5 mm
Window panel
Step 10 x 01
60mmScrew
(A0035)x06
44mm
Corner Post
(A4069)x01

GB-IE
18
Door Panel
Step 05 x 01
Pre drill f the door panel assembly.
Drill three holes in each side at an angle so you can get the screw in and two at the bottom.
13
GB-IE
Repeat with the other window panel.
12
Window panel
Step 10 x 01
44mm
Corner Post
(A4069)x01
60mmScrew
(A0035)x06
5 mm

19
GB-IE
Roll out felt on a clean, flat surface (Back side up). Place one of the six triangular roof panel sections onto
this as in the picture (framework upwards).
You must allow for a 50mm overhang of felt along the bottom edge (the shortest side 1183mm) of the
panel. Cut out felt to triangles not forgetting the overhang.
15
GB-IE
Position and fix the door panel to the posts.
14
Door Panel
Step13x 01
Roof Panel
(A4080)x 01
8.0m Felt Roll
(A4081)x01
60mmScrew
(A0035)x06

GB-IE
20
Position the next roof panel on the felt rotated 180 degrees to the first one, again with the 50mm
overhang. Mark and cut as before then nail as above.
Repeat with other 4 roof panels.
17
GB-IE
Fix the felt overhang to the bottom edge of the roof panel using 11 x felt nails (as below drawing).
Turn the roof panel over and fix the felt to the long edges using 6 x felt nails per edge.
16
08mm Felt Nails
(A0266) x25
8
Roof Panel
(A4080)x 01
8.0m Felt Roll
(A4081)x01
Roof Panel
(A4080)x 05
8.0m Felt Roll
(A4081)x01
08mm Felt Nails
(A0266) x125
8
