Installation Instructions - GustBuster™ Tarp Cords P/N 1126168 Rev. C
Item Part # Description
1125679 GustBuster™ Kit - 8' to 9' -
One Cord
1125680 GustBuster™ Kit - 8' to 9' -
Two Cords
1125681 GustBuster™ Kit - 8' to 9' -
Three Cords
1126741 GustBuster™ Kit - 10' to 11' -
Two Cords
1126742 GustBuster™ Kit - 11' to 12' -
Two Cords
1126743 GustBuster™ Kit - 12' to 13'
Two Cords
1. 1705638 GustBuster™ Bolt On - 8' to 9'
1126738 GustBuster™ Bolt On - 10' to 11'
1126739 GustBuster™ Bolt On - 11' to 12'
1126740 GustBuster™ Bolt On - 12' to 13'
2. 1700400 Self-Tapping Screw - 3/8" x 1"
3. 1705992 Aluminum Spacer - 1/2" x 3/8" x 1/4"
4. 1704371 Flanged Hex Nut - 3/8”
STEP 1: Roll tarp open against tarp stops. Place mark below top
rail at 1/4 length and 3/4 length of trailer. If installing a
third cord, mark 1/2 length also.
STEP 3: Roll tarp toward latchplate side and let roll tube hang at
its lowest point. On latchplate side, locate row of rivets
directly across trailer from selected row of rivets on tarp
stop side. Drill hole between two rivets, just below lower
edge of tarp.
STEP 2: On tarp stop side of trailer, determine vertical rows of
rivets nearest to marks below top rail. Drill hole between
two rivets, just below trailer frame.
TIP: To conrm selected rows of rivet placement directly across
from each other on trailer, count rivet rows from front-passenger
side of trailer to selected row. Count an equal number of rows
from front-driver side.
2
4
1
NOTE: Where 3/8" x 1" self-tapping screws 2 are used,
use nuts on interior side, if possible, and drill 13/32" holes. If
interior side of trailer is not accessible, self-tapping screws
used without nuts require minimum wall thickness of 3/16".
Drill 5/16" holes.
3/4 length
1/2 length
1/4 length
rivets
drill hole
between
rivets
1/4 length
mark
drill hole
between
rivets
NOTE: Tarp will open and close freely under GustBuster™ Tarp Cord.
rivets
3
not to scale

P/N 1126168 Rev. C
Installation Instructions - GustBuster™ Tarp Cords - continued
STEP 4: Drape GustBuster™
1
over closed tarp. If drilled hole is
accessible from inside of trailer, fasten cord to trailer with
screws
2
, spacers
3
and nuts
4
. If drilled hole is not
accessible from inside of trailer and wall thickness is at
least 3/16", fasten cord with screws
2
and spacers
3
.
2
1
4
INTERIOR OF DRILLED HOLE
IS ACCESSIBLE
INTERIOR OF DRILLED HOLE
IS NOT ACCESSIBLE
2
1
5/16"
drilled
hole
13/32"
drilled
hole
33
ONE-GROMMET END - LATCHPLATE SIDE
TWO-GROMMET END ON 102" WIDE TRAILER - TARP STOP SIDE
TWO-GROMMET END ON 96" WIDE TRAILER - TARP STOP SIDE
2
1
4
INTERIOR OF DRILLED HOLE
IS ACCESSIBLE
INTERIOR OF DRILLED HOLE
IS NOT ACCESSIBLE
2
1
5/16"
drilled
hole
13/32"
drilled
hole
33
2
1
4
INTERIOR OF DRILLED HOLE
IS ACCESSIBLE
INTERIOR OF DRILLED HOLE
IS NOT ACCESSIBLE
2
1
5/16"
drilled
hole
13/32"
drilled
hole
33
