BURY EasyTouch User manual

BURY EasyTouch
Index
Introductory information 2
1. General 2
2. Security guidelines 3
Installation of the system 6
3. Scope of supply 6
4. Instructions on battery 8
5. Positioning and mounting 9
First steps 12
6. Using the hands-free car kit for the first time 12
7. Establishing a
Bluetooth connection 13
Operating guidelines 15
8. Accepting, making, ending calls 15
9. Other operating options 19
Further Information 22
10. Service 22
11. Appropriate use of this system 23
12. Approvals and declaration of conformity 24

2Introductory information
1. General
Dear customer,
Congratulations on purchasing a BURY hands-free car kit. You have chosen a high quality product
that is extremely easy to use.
Please read the operating manual carefully so that you can fully enjoy your BURY hands-free car kit.
If you have any further questions concerning installation or operation of your car kit, please contact
your dealer. He will be happy to give you reliable advice.
You can also contact our hotline. Our phone and fax numbers are listed in the chapter Service at
the end of the operating instructions.
Have a good trip!

3
2. Security guidelines
Installation - who and where
The installation of this system can be carried out by yourself but
please observe any installation requirements issued by the
automotive manufacturer. During the installation, park the car at a
place where the road traffic is not impaired.
Power supply
This hands-free car kit is designed for use in vehicles independent
of the available power supply, whether 12 or 24 volts. The system‘s
battery can, however, be charged from both power networks via the
cigarette lighter plug (car and HGV). The supply voltage is
appropriately adjusted.
Exclusion of Liability:
Please comply with the laws and regulations concerning the
e-certification and the use and installation of electronic systems in
vehicles which are particular to your country. If you do not know
these, please inform yourself of them appropriately. In case of
doubt, only charge the battery of the hands-free car kit using the
car cigarette lighter plug when the vehicle is stationary. Please do
not hesitate to call our hotline if you have any questions concerning
these matters.

Introductory information
4
Position, volume
Install the components of the device in the vehicle so that your field
of vision is not impaired and the components are not mounted in the
impact zone of the passenger compartment or in the airbag inflation
zones.
Intended use
We shall not be liable for damages or malfunctions due to improper
use of the hands-free system. Therefore, do not expose the device
to moisture, extreme temperatures or shocks and carefully follow
the procedure described in the installation and operating
guidelines.
Use while driving
Operate the system only when the situation allows it and when you
do not endanger, harm, constrain, or annoy other road users. The
volume of the device has to be set in a way that exterior noise is still
audible.
Faults
Do not commission the device if you detect or assume a defect. In
this case, contact a Bury specialised dealer or our hotline. Improper
repair efforts can be dangerous for you. Therefore, only skilled
personnel may perform inspections.

5
Important:
The driver is ultimately responsible for the safe opera-X
tion and control of their vehicle at all times. You should
never use a hand held phone, including sending or rea-
ding text or picture messages, while driving.
Research indicates that there is a risk to safety whenX
the driver of a motor vehicle is distracted and using a
mobile phone while driving can be a distraction.
The manufacturer strongly recommends that you useX
a hands-free solution for making telephone calls whilst
driving.

6Installation of the system
3. Scope of supply

7
The hands-free car kit (HFCK) is supplied with various components depending on the sales region.
However, the operating instructions apply to all variants.
Description of the components:
1) Hands-free car kit
2) Sun visor clip
3) Mini USB / USB cable
4) 12V/24V Cigarette lighter plug
5) Detailed operating instructions are available in the internet
6) Printed quick user guide
Note:
If certain components are added or omitted you will receive the corresponding infor-X
mation on a separate enclosure.
The BURY EasyTouch hands-free car kit has touch keys, an integrated battery, an on-off switch on
the right side, a mini USB port on the right side, a locking device for the sun visor clip and an
integrated, pull-out microphone.

Installation of the system
8
4. Instructions on battery
The hands-free car kit (HFCK) has an integrated rechargeable battery which remains activated for
approx. 350 hours when fully loaded. The battery guarantees up to 7 hours of hands-free talking
without the need for recharging. These values may differ depending on the settings and the use of
the hands-free car kit.
Please avoid charging the battery inside the vehicle in direct sunlight and the high interior
temperatures which can rapidly be reached in parked vehicles. In such cases, please remove the
HFCK and place it either in the door glove pocket or the glove box.
Please comply with the following temperature levels:
- Storage between -20 and +60 degrees Celsius
- Charging between 0 and +45 degrees Celsius
- Use between -20 and +60 degrees Celsius
If you do not comply with these temperature levels then the battery can get damaged and then it
is possible that the HFCK will fail to work.

9
Mounting on the sun visor
Depending on how you would like to attach the HFCK to the sun visor in the vehicle, you must slide
the sun visor clip onto the locking device on either side. Press the fastener on the locking device to
completely slide in the sun visor clip. The clip snaps into place with a click sound, as long as it has
been correctly slid into place.
Variant A:
Push the sun visor clip upwards and away from you onto the sun visor.
5. Positioning and mounting

Installation of the system
10
Variant B:
Push the sun visor clip downwards and towards you onto the sun visor.
Pulling out the microphone
Now pull out the integrated microphone from the hands-free car kit for optimal speech input.

11
Opening and shutting the sun visor
Note:
Flipping down the sun visor does not effect the function of the HFCK.X
The sun visor can sometimes not be fully opened.X
Depending on the type / thickness of the sun visor, you should try both installation types once.
Check whether the system can be used comfortably and that it does not restrict your view of the
road.
To disconnect the clip from the locking device, press down the fastener and then remove the clip.

12 First steps
Power supply
Connect the BURY EasyTouch via the USB cable to the cigarette lighter plug and plug this into the
corresponding connection inside the car.
Charging the BURY EasyTouch battery
Option 1: Charge the BURY EasyTouch battery via the USB cable and the cigarette lighter plug
inside the car.
Option 2: Charge the BURY EasyTouch battery via the USB cable on your PC / laptop.
6. Using the hands-free car kit for the first time
Turn on the device using the on-off button on the right side. The BURY EasyTouch telephone list is
empty, automatic connection is turned off. The device says: Choose language. The device reads
out the available languages in the national language. Press one of the buttons to select the desired
language. The language is loaded. The list of the languages available is read out three times. If you
do not choose a language, English is automatically selected.
Then link your mobile phone to BURY EasyTouch. If a telephone has been linked to BURY EasyTouch
the device says: Phone is connected.

13
7. Establishing a Bluetooth connection
If you wish to establish a Bluetooth connection between your mobile and the HFCK for the first
time, you have to activate the Bluetooth function of your mobile phone and search for
Bluetooth
devices. In this case, search for a device labelled „BURY EasyTouch“.If several devices were identi-
fied, please select the HFCK and enter the PIN number „1234“. The
Bluetooth connection (pai-
ring) will then be established between your mobile phone and the HFCK. It is possible that you will
also have to click on ‚connect‘ or ‚allow data transfer‘ on your mobile phone if you want to be able
to make a connection.
If it is not possible to establish a connection, please check and update the software release (firm-
ware) of your mobile phone or of the HFCK. You will find an overview dealing with this subject on
the Internet at www.bury.com.
In addition it is possible that you must delete all devices connected to your mobile phone first in
order to enable a correct identification of the HFCK and the establishment of a connection.
Note:
If the rechargeable battery of the mobile phone is low, it is sometimes not possibleX
to establish a
Bluetooth connection.
In the internet you can find an overview with a large number of mobile telephonesX
which have been tested with this hands-free car kit. Please note, however, the use
of firmware which deviates from the list and is installed on a listed mobile telephone
can lead to the fact that certain displays and functions are no longer possible or only
possible to a limited extent.

14 First steps
If you wish to cancel a Bluetooth connection, you can either disconnect it conveniently at the
HFCK or at your mobile phone. In addition, the connection is disconnected, if you move too far
away from the vehicle while taking your mobile phone with you and thus leave the reception
radius of the HFCK. If you return to your vehicle within 15 minutes, your telephone will be
automatically reconnected to BURY EasyTouch.
Please note that the capacity of your mobile phone‘s storage battery can quickly decrease
when the
Bluetooth function is active. If you do not want to use the Bluetooth function anymo-
re, e.g. if you leave the vehicle for a longer period, it is recommended to deactivate this func-
tion.
The HFCK has a memory for the storage of the identification of up to 8 mobile phones. In case a
ninth mobile phone is connected, the oldest entry in the HFCK memory will be cancelled.
If you have changed some settings and the HFCK does not function as you would like since, you can
reset the HFCK to factory status.

15
The BURY EasyTouch is operated using the key buttons on the
device. The function of the buttons can vary according to the menu
item.
Note:
Please comply with the country-specific laws concer-X
ning in-car telephone calls.
Making calls
Press the call button. The device says: Enter voicetag. Give your
voicetag loud and clearly.
Your BURY EasyTouch offers you three ways of using voicetags:
8. Accepting, making, ending calls
Operating guidelines

Operating guidelines
16
Option 1: Creating and using voicetags
To make a phone call you must set voicetags on your mobile phone. You can only set voicetags on
your mobile phone for contacts already saved in your address book (not on your SIM card!).
Please note:
Copy your contacts from your SIM card into your telephone address book. Then onlyX
use contacts from your address book.
When you call up a contact from your address book, choose under Options „Add call name“. The
menu item depends on the manufacturer and may have another name. In this menu you can set,
change or delete the voicetag for a contact. You can find further information in the operating
instructions for your mobile phone.
In your address book you can see which contacts you have already saved a voicetag for. A symbol
is shown behind the name. This varies depending on your mobile phone but is usually a Pacman.
Option 2: Reading out the phonetics
For some mobile phones, you can open up the mobile phone directory by pressing down the BURY
EasyTouch call button. The device says: Enter voicetag. The voicetag you enter (contact name) is
compared with the contacts saved in the mobile phone directory using phonetic technology and
selected if there is a match.

17
Option 3: Using your smartphone‘s voice dialling function
Most smartphones have a voice dialling function which you can
activate using BURY EasyTouch. You can then use your smartphone‘s
voice dialling function via BURY EasyTouch.
Please make sure that you repeat the smartphone‘s precise voicetag
which you can find in the your smartphone‘s operating instructions.
Using the voicetag, in addition to making calls you can also play
music via BURY EasyTouch.
Tip:
You can only stop the music play back via your smart-X
phone.
In the event of incoming and outgoing calls, the musicX
play back will be automatically interrupted.
If you press the call button on the BURY EasyTouch, the device says:
Enter voicetag. Some smartphones may then release a signal
sound after one to three seconds. Only then can you enter the
voicetag.

Operating guidelines
18
Outgoing call
Briefly press down on the call button to activate the voicetag
function. The device says: Enter voicetag. Begin the call with a
voicetag. If the number dialled is busy, you can begin to redial. To
do so, hold down the call button (for two seconds). The device says:
Redial.
If you announce a non-saved voicetag then the device says:
Voicetag is not available. BURY EasyTouch returns to standby
mode.
Briefly press down on the end call button to end the voicetag func-
tion, the active call or the redialling.
If you make a call and briefly press down on the call button, the
private mode is then started. The call is then forwarded to the mo-
bile phone.
Incoming call
The backlight to the sensor keys is activated. In addition to this, a
ring tone sounds which alerts to an incoming call. If the mobile
phone transfers its own ring tone to the hands-free car kit (depending
on the mobile phone), then this will sound. If the caller has hidden
their number, then the device says: Unknown caller.
Briefly press down on the end call button to refuse the call. The
device returns to standby mode.
Briefly press down on the call button to accept the incoming call.

19
Setting the volume
Press down the vertical buttons to gradually increase (top buttons)
or decrease the sound (lower buttons) the sound during an active
conversation. A high signal tone sounds when the maximum volume
has been reached. A low signal tone sounds when the minimum
volume has been reached.
But you can also go over the buttons with your fingers (both
directions).
9. Other operating options
Connecting a telephone
At least one telephone is listed in the BURY EasyTouch telephone
list. Automatic connection is on and the last connected telephone is
searched for three times, each attempt lasts 5 seconds. If this
telephone is not found, the next telephone in the list is searched for
(for 5 seconds). After this, the list is searched through entirely three
times before the automatic connection is interrupted. The device
then returns to standby mode. Eight telephones can be linked. If a
ninth telephone is linked, the last telephone in the list is deleted
(first in/first out). The last telephone connected is always in first
position on the list.

Operating guidelines
20
While already linked phones are searched for by BURY EasyTouch,
you cannot link and connect any other telephone yourself.
To link and connect another mobile phone, briefly press down the
end call button to interrupt the automatic connection.
Hold down (for five seconds) the end call button to reload the factory
settings. The device then switches off.
Press down on the call button to start the automatic connection.
Disconnecting a telephone
Hold down (for three seconds) the end call button to disconnect the
telephone. The device says: No phone connected.
Standby mode
After 30 seconds the BURY EasyTouch light goes off. Press down on
the aim point, to return to active status.
