Shuttle WLN-M Installation instructions

Product Specifications
w w w . s h u t t l e . e u
Shuttle Computer Hand e l s GmbH
Fr itz -St rassman n-S tr. 5
25337 Elmsh orn | Ger many
Tel. [phone]
Fax [phone]
sale s@shu ttl e.eu
Page 1 17 January 2022
© 2021 by Shuttle ComputerHandels GmbH (Germany).All information subjectto change without notice . Pictures for illustration purposes only.
Universal WLAN-ac / Bluetooth
Combo Kit with M.2 card
The Shuttle XPC Accessory WLN-M is a wireless LAN kit consisting of
a M.2-2230 card, two antennas and appropriate cables. The WLN-
M is intended for certain Shuttle barebones of the XPC cube and
XPC slim series to equip them with the wireless LAN standard
according to IEEE 802.11n/ac at 2.4 / 5 GHz. At the same time, his
combo device also supports Bluetooth 4.2.
Feature Highlights
Contents
M.2-2230 (NGFF) WLAN card
2 antenna cables for XPCs slim (21 & 29 cm)
2 antenna cables for XPCs cube (53 cm)
Connectors: I-PEX4 / MHF4 and RP-SMA male
2 dipole antennas (2.4 / 5 GHz band, 108 mm)
Quick Guide (English, German, French)
Windows driver DVD
Compati-
bility
Compatible with the following Shuttle products:
Shuttle XPC nano Barebone PCs: NC02U series,
NC03U series, NC10U series
Shuttle XPC slim Barebone PCs: DH110(SE),
DH270, DH310(S), DH310V2, DH370, DH410(S),
DH470, DH610(S), DH670, XH110(V), XH110G,
XH270, XH310(V), XH310R(V), XH410G,
XH510G(2), XH610(V), XC60J, DX30, DL10J,
DL20N(6), DH02Ux
Shuttle XPC cube Barebone PCs: SH110R4,
SZ170R8V2, SZ270R8, SZ270R9, SH310R4(V2),
SH370R6(V2)(Plus), SH370R8, SH510R4,
SH570R6 (Plus), SH570R8, SW580R8
Shuttle Edge: EN01J3, EN01J4, EN01E, EN01B
(in combination with Shuttle Accessory LN007)
OS Support
Supports Windows 7, 8.1, 10, 11, Linux
Adapter
card
Model: AzureWave AW-CB304NF
Chipset: Realtek RTL8821CE
Format: M.2-2230 (NGFF) card
Supports WLAN IEEE 802.11b/g/n/ac,
2.4 / 5 GHz band, 1T1R
Maximum PHY data rate: 72.2 / 150 Mbps using
20 / 40 MHz bandwidth in n-mode and 433.3
Mbps using 80 MHz bandwidth in ac-mode
Supports WPA2 (with AES) and WPA encryption
Supports Bluetooth 4.2, 2.4 GHz band
Operating temperature: 0~70°C
Shuttle Accessory
WLN-M
WLAN kit
Note: What are the advantages of WLN-M over a conventional WLAN USB stick?
1) The M.2 card sits in the case and is better protected from tampering and theft.
2) The integrated solution is more appealing.
3) For the best possible efficiency the antenna should be at least 6cm long (half a wavelength at 2.4 GHz)
which is a big advantage over the USB stick.
4) This WLAN card is a Combo card which supports both WLAN and Bluetooth.
5) The transmission protocol of the PCI-Express interface is less complex as compared to USB which helps keep
processor load lower.
Shuttle XPC slim and XPC cube
with WLN-M installed
Images for illustration purposes only.
