Shuttle AN35 Ultra User manual

AN35 Ultra/AN35N Ultra
AMD Athlon XP/Athlon/Duron
462-pinProcessor
with 200/266/333/400 MHz FSB
Based DDR MAINBOARD
AN35-400/AN35N-400
AMD Athlon XP/Athlon
462-pinProcessor
with 266/333/400 MHz FSB
Based DDR MAINBOARD
User's Manual

Ifyou’vechangedyourCPUoroverclockedyoursystem,thesystemmayfailtobootup,
even with a Clear CMOS jumper physically resetted. The reason is that NVIDIA’s new
nForce2 chipset introduces a way to reset a Clear CMOS jumper without removing a
chassis.Pleasefollowthestepslistedbelow:
1. Turnoff yourcomputerandunplug thepowercable.Reconnect itafter30 seconds;
2. Press<Insert>andthenpressyourcomputer’s startbutton. Continueholding<Insert>
untilthe systembeginsthePOST (Power-OnSelfTest);
3. Immediatelypress <Del> toentertheBIOS;
4. Select ‘Load Optimized Defaults’ to return your system to a bootable condition; then
select ‘SAVE to CMOS and EXIT’;
5. Rebootyour system.
Moreover, if your system fails to boot up after you reset the CPU FSB, select “SAVE to
CMOS and EXIT” in the BIOS.After the system restarts, there is on screen a message
warningyou nottoreset orturnoffyourcomputer:
Warning! New setting is updating now
Do not Reset or Shutdown the system
Yoursystemworks after the BIOS is updated.
NOTICE

Thermalissueis highly essential for processors withaspeedof600MHz and above.
Hence,werecommend you to usetheCPUfan qualified byAMDormotherboard
manufacturer.Meanwhile,pleasemakesure CPUandfanaresecurelyfastenedwell.
Otherwise,improper fan installation notonlygetssystem unstable butalsocould
damageboth CPU andmotherboardbecauseinsufficient thermal dissipation.
Ifyouwould like to knowmoreaboutthermal topic please see AMD website for
detailedthermal requirementthroughtheaddress:
http://www.amd.com
WARNING

M801
Shuttle®AN35 Ultra/AN35N Ultra
AN35-400/AN35N-400
AMD Athlon XP/Athlon/Duron (AN35 Ultra/AN35N Ultra only)
462-pin Processor
with 200 (AN35 Ultra/AN35N Ultra only)/266/333/400 MHz FSB
Based DDR Mainboard
Manual Version 1.0
Copyright
Copyright©2003 by Shuttle®Inc. All Rights Reserved.
This publication, including all photos, illustrations, and software, is protected under interna-
tional copyright laws, with all rights reserved. Reproducing any of the material contained
herein is prohibited without the consent of the publisher.
Disclaimer
Shuttle®Inc. shall not be liable for any incidental or consequential damages resulting from the
performance or use of this product.
This company makes no representations or warranties regarding the contents of this manual.
Information in this manual has been carefully checked for reliability; however, no guarantee is
given as to the correctness of the contents. In the interest of continued product improvement,
this company reserves the right to revise the manual or include changes in the specifications
of the product described within it at any time without notice and without obligation to notify any
person of such revision or changes. The information contained in this manual is provided for
general use by the customers.
Trademarks
Shuttle is a registered trademark of Shuttle Inc.
NVIDIAis a registered trademark ofNVIDIA Corporation.
AMD,Athlon, and Duronare registered trademarksofAMD Corporation.
PS/2 is a registered trademark of IBM Corporation.
AWARD is a registered trademark of Award Software Inc.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
General Notice: Other product names used in this manual are ascribed to their respective
owners and acknowledged.

Statement of Shuttle Mainboard via the EMI Test
Shuttle mainboards have been via the EMI test in terms of series of regulations: EN55022/
CISPR22/AS/NZS3548Class B,EN55024 (1998/AS/NZS), EN4252.1 (1994), EN61000,ANSI
C63.4 (1992), CFR47 Part 15 Subpart B, and CNS13438 (1997). The items tested are illus-
trated as follows:
(A)Voltage:AC110V/60HZ &AC230V/50HZ
(B) Tested Product Information:
Product Name: PC Mainboard
Status: Sample
ModelName:AN35NUltra/AN35Ultra/AN35N-400/AN35-400
S/N:N/A
CPU:
External Frequency: 200 MHz
AMDAthlonXP3000+
External Frequency: 166 MHz
AMDAthlonXP2700+/2800+
External Frequency: 133 MHz
AMDAthlonXP1500+/1600+/1700+/1800+/1900+/2000+/2100+/2400+/2600+
AMDAthlon1.00/1.13/1.20/1.33/1.40GHz
External Frequency: 100 MHz
AMDAthlon750/800/850/900/950MHz,1.00/1.10/1.20/1.30/1.40GHz
AMDDuron 750/800/850/900/950 MHz,1.00/1.10/1.20/1.30 GHz
Mouse Port: one port with 6 pins
Keyboard Port: one port with 6 pins
Parallel Port: one port with 25 pins
Serial Port: two ports with 9 pins respectively
MIDI/Game Port: one port with 15 pins
Line-Out & Line-In & Mic-In Ports: one port for each
LANPort: one port with 8 pins (10Mbps/100Mbps)(AN35N Ultra &AN35N-400 Only)
USB 2.0 Port: two ports with 4 pins respectively
DIMMMemory (optional): 512MB *2
All CPUs have completely been tested, and values offered by the worst EMI combination of
CPU external frequency are listed as follows:
Test Mode
1
2
3
4
5
6
7
8
9
10
11
12
External Frequency
200 MHz
200 MHz
166 MHz
166 MHz
133 MHz
133 MHz
133 MHz
133 MHz
100 MHz
100 MHz
100 MHz
100 MHz
CPU
AthlonXP3000+
AthlonXP3000+
AthlonXP2800+
AthlonXP2800+
AthlonXP2600+
AthlonXP2600+
Athlon 1.4 GHz
Athlon 1.4 GHz
Athlon 1.4 GHz
Athlon 1.4 GHz
Duron 1.2 GHz
Duron 1.2 GHz
Case Open/Closed
Closed
Open
Closed
Open
Closed
Open
Closed
Open
Closed
Open
Closed
Open

(C) Remedy for the Tested Product & Its EMI Interference:
Remedy:N/A
EMIInterference:
Crystal:14.300MHz(Y1)/32.768 KHz(Y2)/12.000 MHz(Y3)/24.576MHz(Y4)/
25.000 MHz(X5)
Clock Generator: N/A
(D)DifferenceamongAN35NUltra/AN35Ultra/AN35N-400/AN35-400:
Todiscriminate AN35NUltra from AN35 Ultra liesin theextent thatchips in AN35N Ultra
support LAN, and the combination for testing is based onAN35NUltra.
Todiscriminate AN35N-400 from AN35-400 liesin the extent that chipsin AN35N-400 support
LAN, and the combination for testing is based onAN35N-400.
(E) Supported Host Peripherals:
(F) Notices for Assembling Computers:
1. Cases should be made of iron or other metal that has good electric conductivity.
2. Cylinders in a case should be made of metal, and as having a mainboard mounted
in a case, make sure screws are all utilized and fastened on a mainboard.
3.An I/O shielding should be contacted with I/O metallic parts of a mainboard.
4. Cables should appropriately be arranged and fixed in a case. Follow instructions:
Ø Leave IDE cables not crossed upon CPU and SDRAM;
Ø Leave power cables minimum in length, and not crossed upon a mainboard;
Ø Leave CPU fan cables minimum in length, and not near CPU;
Ø Leave cables on panels and other spare cables tied in a computer case.
5.Make sure an EMI shielding attached to a case has properly been installed.
6. Make sure a 5.25" or 3.5" FDD and screws are fastened to an EMI shielding.
7. Make sure a case is closely in contact with EMI connected points.
8. Make sure there is no cleft in a case which is not deformed.
9. Make sure a PCI orAGP door is bound to a case.
10. Make sure cables of other devices (fans or some others) are fixed in a case.
Host Peripheral Product Name Model Name S/N FCC ID
#1 Case KF45A N/A
#2 Power Supply (300W) ENP-0730 (ATX12V) 1000002885
#3 IBM HDD (30.7GB) 91024UB YKFY7981 3892I168
#4 MITSUMI FDD D353M
#5 SONY VCD Player CDU4811 3892A291
#6 AGP Card Winfast Geforce 2 MX 3892C520
#7 Power Cable Detachable and Shielded

- 1 -
TABLE OF CONTENTS
WHAT'S IN THE MANUAL.................................................................... 4
Quick Reference............................................................................................... 4
About This Manual ........................................................................................... 4
1 INTRODUCTION................................................................................ 5
1.1 TO DIFFERENT USERS ............................................................................. 5
FIRST-TIMEDIYSYSTEMBUILDER............................................................ 5
EXPERIENCEDDIY USER ......................................................................... 5
SYSTEMINTEGRATOR............................................................................... 5
1.2 ITEM CHECKLIST: ...................................................................................... 6
2 FEATURES ........................................................................................ 7
2.1 SPECIFICATIONS ....................................................................................... 7
3 HARDWARE INSTALLATION.......................................................... 10
3.1 STEP-BY-STEP INSTALLATION............................................................... 10
STEP1InstalltheCPU ...............................................................................11
STEP 2 Set Jumpers ................................................................................. 12
STEP3InstallDDRSDRAMSystemMemory............................................ 12
STEP4 Install InternalPeripheralsinSystem Case .................................... 13
STEP5MounttheMainboardonthe Computer Chassis............................ 14
STEP6ConnectFront Panel LEDs/Switches/USBs .................................. 15
STEP 7 Connect IDE and Floppy Disk Drives ............................................ 16
STEP8 ConnectOtherInternalPeripherals................................................ 17
STEP9Connectthe Power Supplies......................................................... 18
STEP10InstallAdd-onCardsin Expansion Slots ...................................... 19
STEP11 Connect External Peripherals to Back Panel ............................... 20
STEP12System Boot Up For the First-Time ............................................. 21
STEP13InstallDrivers & Software Components ....................................... 22
3.2 JUMPER SETTINGS ................................................................................. 23
JUMPERS&CONNECTORS GUIDE........................................................ 24
Jumpers
Clear CMOS Setting (JP1)........................................................................ 27

- 2 -
Back Panel Connectors
PS/2Mouse & PS/2 Keyboard Port Connectors ........................................ 28
ParallelPort Connector .............................................................................. 28
COM1/COM2Port Connectors .................................................................. 28
MIDI/GamePortConnector ........................................................................ 28
Line-OutPort Connector ............................................................................ 29
Line-In(Rear-Out)PortConnector .............................................................. 29
Mic-In(Center/Bass-Out)PortConnector ................................................... 29
LANPort Connector (AN35N Ultra/AN35N-400Only) ................................. 29
USB1/USB2Port Connectors .................................................................... 29
Front Panel Connectors
HDD LED Connector (HLED) .................................................................... 30
GreenLED Connector (GLED) .................................................................. 30
HardwareResetConnector (Reset) ........................................................... 31
ATXPower On/OffSwitchConnector(PWON) ........................................... 31
EPMIConnector (EPMI)............................................................................. 32
Power LED Connector (PLED) .................................................................. 32
SpeakerConnector(Speaker) ................................................................... 32
FrontPanelAudio Header (JP9) ................................................................ 33
ExtendedUSBHeaders(JP2/JP3) ............................................................ 34
Internal Peripheral Connectors
EnhancedIDEand Floppy Connectors (IDE1/IDE2 & FLP1) ...................... 35
Other Connectors
ATXPowerSupplyConnectors(CN2/CN3)................................................ 36
CPUandSystem Fan Connectors (FAN1/2/3)............................................ 37
IRHeader (JP4)......................................................................................... 37
Audio CD_INConnectors (JP6/JP8) .......................................................... 38
AudioAUX_INConnector(JP10) ............................................................... 38
AudioRear_OutHeader(JP20)................................................................. 39
AudioCenter/Bass Header (JP5)............................................................... 39
SPDIFExt. Header (JP7)........................................................................... 40
AGP Proof LED (D1) ................................................................................. 40
CPUOverheat LED (D30) ......................................................................... 40

- 3 -
3.3 SYSTEM MEMORY CONFIGURATION ..................................................... 41
INSTALLMEMORY .................................................................................... 41
UPGRADEMEMORY ................................................................................ 41
4 SOFTWARE UTILITY ......................................................................42
4.1 Mainboard CD Overview ......................................................................... 42
4.2 Install NVIDIA Chipset Driver .................................................................. 43
4.3 Install USB 2.0 Driver (for Win9x/ME only) ............................................ 43
4.4 View the User's Manual .......................................................................... 44
5 BIOS SETUP ................................................................................... 45
5.1 ENTER BIOS ............................................................................................. 45
5.2 THE MAIN MENU ...................................................................................... 46
STANDARD CMOS FEATURES ............................................................... 48
ADVANCED BIOS FEATURES................................................................. 50
ADVANCED CHIPSET FEATURES .......................................................... 53
INTEGRATEDPERIPHERALS .................................................................. 56
POWERMANAGEMENTSETUP.............................................................. 59
PNP/PCICONFIGURATIONS .................................................................... 62
PCHEALTH STATUS................................................................................ 63
CPURatio/Voltage Control ........................................................................ 64
LOAD FAIL-SAFE DEFAULTS .................................................................. 65
LOADOPTIMIZED DEFAULTS ................................................................. 65
SETSUPERVISOR/USER PASSWORD................................................... 66
Save & Exit Setup...................................................................................... 67
ExitWithoutSaving.................................................................................... 67

- 4 -
Quick Reference
Hardware Installation >> Step-by-Step ................................................Page 10
Jumper Settings >> A Closer Look.......................................................Page 23
Software Utility >> How to Install..........................................................Page 42
BIOS Setup >> How to Configure.........................................................Page 45
About This Manual
For First-Time DIY System Builder .........................................................Page 5
For Experienced DIY User ......................................................................Page 5
For System Integrator .............................................................................Page 5
WHAT'S IN THE MANUAL

- 5 -
1.1 To Different Users
First-Time DIY System Builder
Welcome to the DIY world! Building your own computer system is not as diffi-
cult as you may think. To make your first computer DIY experience successful,
right from the start, we have designed Chapter 3 Hardware Installation in a
step-by-step fashion for all the first-time DIY system builders. Prior to installa-
tion, we suggest you read the whole manual to gain a complete understanding
of your new AN35 Ultra/AN35N Ultra/AN35-400/AN35N-400 mainboard.
Experienced DIY User
Congratulate on your purchase of the AN35 Ultra/AN35N Ultra/AN35-400/
AN35N-400 mainboard. You will find installing your new AN35 Ultra/AN35N
Ultra/AN35-400/AN35N-400 mainboard is quite easy. Bundled with an array
of onboard functions, the highly-integrated AN35 Ultra/AN35N Ultra/AN35-
400/AN35N-400 mainboard provides you with a total solution to build the
stablest and most reliable system. Referring to section 3.2 Jumper Settings
and Chapter 4 Software Utility, you will find how to work out your new
mainboard. Chapter 5 BIOS Setup also contains the relevant information
on how to tune up your system to achieve higher performance.
System Integrator
You have wisely chosen AN35 Ultra/AN35N Ultra/AN35-400/AN35N-400 to
construct your system. AN35 Ultra/AN35N Ultra incorporates all the state-of-
the-art technology of the nForce2 Ultra 400 chipset from NVIDIA. AN35-400/
AN35N-400 incorporates all the state-of-the-art technology of the nForce2 400
chipset from NVIDIA. Each integrates the most advanced functions you've ever
found in a compact ATX board.
This manual is all-purpose for four kinds of mainboards: AN35 Ultra/
AN35N Ultra/AN35-400/AN35N-400. The main difference among
them is that AN35N Ultra or AN35N-400 is equipped with an onboard
LAN. In the manual, if there are some standards, characteristics, equip-
ment, or software adopted only by AN35N Ultra or AN35N-400, it will
be highlighted in brackets.
1INTRODUCTION

- 6 -
1.2 Item Checklist:
Check all items with your AN35 Ultra/AN35N Ultra/AN35-400/AN35N-400
mainboard to make sure nothing is missing. A complete package should
include:
-One Shuttle AN35 Ultra/AN35N Ultra/
AN35-400/AN35N-400 Mainboard
-One ATA 133/100/66/33 Ribbon Cable
-One Floppy Ribbon Cable
-One Twin-Port USB Cable (optional)
-AN35 Ultra/AN35N Ultra/AN35-400/
AN35N-400 User's Manual
-I/O Shielding (AN35N Ultra/AN35N-400 Only)
-One Bundled CD-ROM, including:
ØAN35 Ultra/AN35N Ultra/AN35-400/
AN35N-400 user's manual in PDF format
ØNVIDIA Chipset Driver
ØUSB 2.0 Driver (for Win9x/ME only)
ØAward Flashing Utility
W49V002AP
223503101
207GFSA
W
i
n
b
o
n
d
+
+
+
-
-
-
Reset
HLED
GLED
Speaker
EPMI
PWON
PLED
IR
JP4
1
CN1
COM1
PRN1
AUDIO1
LAN1
FAN1
1
DIMM1
DIMM2
DIMM3
FLP1
1
ATXPWR
1
FAN2
1
IDE2
IDE1
1 1
1
JP13
1
JP1
CMOS
1
JP2
USB3&4
JP3
USB5&6
T
A
I
W
A
N
n
V
I
D
I
A
n
F
O
R
C
E
2
M
C
P
JP8
1
CD_IN
CD_IN
JP6
1
JP5
1
ALC650
FrontAudio
JP9
1
REALTEK
RTL8201BL
TAIWAN
PCI1
AGP1
FAN3
1
1
CN2
ATX12V
JP3
1
Attansic
ATXP1
COM2
USB1
CN3
PCI2
PCI3
PCI4
PCI5
SPDIF Ext.
JP7
1
CENTER/BASS
JP20
1
REAR_OUT
JP10
1
AUX_IN
+
-
D1
AGP proof
+
-
D30
CPU overheat
+
-
D26
DIMMpower

- 7 -
AN35 Ultra/AN35N Ultra/AN35-400/AN35N-400 mainboard is dedicatedly designed for
demanding PC users who desire high performance and maximum intelligent features in a
compact package.
2.1 Specifications
-CPU Support
AMD Athlon XP/Athlon/Duron, 462-pin processors with 200/266/333/400
MHz FSB for AN35 Ultra/AN35N Ultra.
AMD Athlon XP/Athlon, 462-pin processors with 266/333/400 MHz FSB for
AN35-400/AN35N-400.
-Chipset
Features NVIDIA nForce2 Ultra 400 N.B. and NVIDIA MCP S.B. for AN35
Ultra/AN35N Ultra.
Features NVIDIA nForce2 400 N.B. and NVIDIA MCP S.B. for AN35-400/
AN35N-400.
-Onboard 10/100Mb/s LAN (AN35N Ultra/AN35N-400 Only)
The Realtek 8201BL incorporated in the chipset provides the mainboard with
integrated Fast Ethernet capabilities.
-AC'97 Audio
Realtek ALC650 Supports 18-bit ADC and DAC resolutions, and 6 channel
selectable DAC output for multi-channel applications.
Compliant with AC'97 2.2 specifications.
-Versatile Memory Support
Features the dual-channel mode of 128-bit data transfer rate. (AN35 Ultra/
AN35N Ultra only)
Three 184-pin DDR SDRAM DIMM slots maximumly accommodate 3GB
of PC1600/2100/2700/3200 for AN35 Ultra/AN35N Ultra.
Three 184-pin DDR SDRAM DIMM slots maximumly accommodate 3GB
of PC2100/2700/3200 for AN35-400/AN35N-400.
-PCI Expansion Slots
Provide five 32-bit PCI slots.
2 FEATURES

- 8 -
-AGP Expansion Slot
Provides one AGP3.0 compliant slot that supports up to 8X AGP device.
-6 USB 2.0 Interface Onboard
Ø2 x USB ports on back panel and two extended USB headers (4 ports) on
front panel.
-I/O Interface
Provides a variety of I/O interfaces:
Ø1 x PS/2 Mouse
Ø1 x PS/2 Keyboard
Ø1 x Parallel port
Ø2 x Serial ports
Ø1 x MIDI/Game port
Ø1 x Line-Out port
Ø1 x Line-In (shared with Rear-Out) port
Ø1 x Mic-In (shared with Center/Bass-Out) port
Ø1 x LAN port (AN35N Ultra/AN35N-400 only)
Ø2 x USB ports
-PCI Bus Master IDE Controller Onboard
Two ultra DMA 133 bus master dual-channel IDE ports support up to four IDE
devices (one Master and one Slave per channel).
The IDE bus implements data transfer speeds to 133/100/66/33MB/sec and sup-
ports enhanced PIO modes.
80-pin cable backward compatible legacy ATAPI devices, ATAPI IDE CD-ROM,
CD-R, CD-RW, and LS-120 supports.
-ATX Power Supply Connector
ATX power supply unit can be connected to the onboard 20-pin ATX power
connector, and 4-pin ATX power connector. The unit supports Suspend and
Soft-On/Off modes by the dual-function power button.

- 9 -
-Advanced Configuration and Power Interface
Features four power-saving modes: S1 (Snoop), S3 (Suspend to RAM), S4
(Suspend to DISK), and S5 (Soft-Off). ACPI provides more efficient energy-
saving features controlled by your operating system that supports OS Direct
Power Management (OSPM) functionality.
-System BIOS
Provides licensed Award BIOS V6.0 PG on the 2Mb Flash ROM, and sup-
ports Green PC, Desktop Management Interface (DMI).
-Form Factor
System board conforms to the ATX specification.
Board dimension: 305mm x 244mm.
-Advanced Features
ØLow EMI - Built in spread spectrum. Unused PCI/SDRAM slots are shut off
by the automatic clock for reducing EMI.
ØDual Function Power Button - The system can be in any of the two
states: one is Suspend mode and the other is Soft-Off mode. Pushing the
power button for less than 4 seconds places the system into Suspend
mode. When the power button is pressed for longer than 4 seconds, the
system will enter Soft-Off mode.
ØModem Ring Power-On - The system can be powered on automatically
by the activation of modem ringing.
ØCPU Multiplier Setting - This item allows users to adjust CPU Multiplier
in BIOS.
ØCPU/RAM/AGP Voltage Setting - These items allow users to adjust
CPU/RAM/AGP Voltage in BIOS.
-Intelligent Features
ØVoltage Monitoring - Monitors various voltages of key elements, such as
the CPU, and other critical system voltage levels to ensure a stable current
passing through mainboard components.
ØFan Status Monitoring -To prevent the CPU from overheating, the CPU
fan is monitored by RPM, with which the cooling fan is required.
ØTemperature Monitoring -This item allows users to make sure whether
the CPU or system runs under a suitable temperature.

- 10 -
Before removing/installing any of these devices: CPU, DIMMs, Add-On
Cards, and Cables, please unplug the onboard power connector.
This section outlines how to install and configure your mainboard. Referring to the follow-
ing mainboard layout helps you identify various jumpers, connectors, slots, and ports.
3.1 Step-by-Step Installation
AccessoriesOfAN35 Ultra/AN35N Ultra/AN35-400/
AN35N-400
3HARDWAREINSTALLATION
W49V002AP
223503101
207GFSA
W
i
n
b
o
n
d
+
+
+
-
-
-
Reset
HLED
GLED
Speaker
EPMI
PWON PLED
IR
JP4
1
CN1
COM1
PRN1
AUDIO1
LAN1
FAN1
1
DIMM1
DIMM2
DIMM3
FLP1
1
ATXPWR
1
FAN2
1
IDE2
IDE1
1 1
1
JP13
1
JP1
CMOS
1
JP2
USB 3&4
JP3
USB 5&6
T
A
I
W
A
N
n
V
I
D
I
A
n
F
O
R
C
E
2
M
C
P
JP8
1
CD_IN
CD_IN
JP6
1
JP5
1
ALC650
Front Audio
JP9
1
REALTEK
RTL8201BL
TAIWAN
PCI1
AGP1
FAN3
1
1
CN2
ATX12V
JP3
1
At tansic
ATXP1
COM2
USB1
CN3
PCI2
PCI3
PCI4
PCI5
SPDIF Ext.
JP7
1
CENTER/BASS
JP20
1
REAR_OUT
JP10
1
AUX_IN
+
-
D1
AGP proof
+
-
D30
CPU overheat
+
-
D26
DIMM power
PS/2 Mouse &
PS/2 Keyboard
Port Connectors
Serial Port
Connector
Parallel Port
Connector
Serial Port
Connector
MIDI/Game &
Line-Out/
Line-In/Mic-In
Port Connectors
LAN Port (AN35N
Ultra/AN35N-400
Only) & USB Port
Connectors
ATX12V Power
Connector - CN2
FAN3
AGP Proof
LED - D1
One AGP Slot
Five PCI Slots
Audio CD_IN
Connector - JP6
Audio CD_IN
Connector - JP8
Audio AUX_IN
Connector - JP10
Audio Rear_Out
Header - JP20
Audio Center/
Bass Header - JP5
SPDIF Ext. Header - JP7
Front Panel Audio Header - JP9
Front Panel Header - JP13
Extended USB Headers- JP2(USB 3&4/JP3(USB 5&6)
C
l
e
a
r
C
M
O
S
J
u
m
p
e
r
-
J
P
1
n
F
o
r
c
e
2
M
C
P
C
h
i
p
s
e
t
T
w
o
I
D
E
C
o
n
n
e
c
t
o
r
s
F
A
N
2
A
T
X
P
o
w
e
r
C
o
n
n
e
c
t
o
r
-
C
N
3
IR Header - JP4
Socket 462
C
P
U
O
v
e
r
h
e
a
t
L
E
D
-
D
3
0
Floppy Connector
nForce2 Ultra 400 Chipset (for AN35/N Ultra)/
nForce2 400 Chipset (for AN35/N-400)
Three DIMM Slots
FAN1
V-DIMM Power LED - D26

- 11 -
Step 1
Install the CPU:
1. Locate the CPU ZIF (Zero Insertion Force) socket on the upper-right sector
of your mainboard (between the back panel connectors and the DIMM
memory slots).
2. Pull the CPU ZIF socket lever slightly sideways away from the socket to
unlock the lever, and then bring it to an upwardly vertical position.
3. Place your AMD AthlonXP/Athlon/Duron processor in the socket A. Note
that the CPU's edges have been purposely designed non-symmetrically to
prevent from inserting the processor in the wrong direction. The following
diagram demonstrates the correct placement of the CPU in the ZIF socket.
You can see that the two blunt-edged corners should face towards the socket
lever.
4. Slightly push the AMD AthlonXP/Athlon/Duron processor into the socket
without applying excessive force while making sure there is no gap between
CPU and socket. Then lower the socket-lever all the way down to its hori-
zontal position and lock it to secure the CPU in place.
5. The AMD AthlonXP/Athlon/Duron processor requires a set of heatsink/fan
to ensure proper cooling of the processor. If heatsink/fan have not been al-
ready mounted on your CPU, you must purchase the heatsink/fan separately
and have it installed. Plug the cable throught the heatsink/fan in the CPU fan
power connector located nearby. Note that there are several types of CPU
fan connectors. Normally, if your mainboard supports the hardware moni-
toring function, a 3-pin fan power connector should allow your system to
detect the CPU fan's speed. The CPU fan can also run with a 2-pin fan power
connector, however, detection of CPU fan's speed is not supported. An-
other type of CPU fan may feature a large 4-pin fan power connector, which
does not support CPU fan's speed detection and must be directly connected
to the system's power supply unit. Please refer to the following diagram.
Notch
AMD CPU
S
O
C
K
E
T
4
6
2
A
S
S
E
M
B
L
E
D
I
N
M
A
L
A
Y
S
I
A
Lever
Blank
S
O
C
K
E
T
4
6
2
Blank

- 12 -
Step 2.
Set Jumpers
The default jumper settings have been set for the common usage standard of
this mainboard. Therefore, you need not to reset the jumpers unless you re-
quire special adjustments as the following case:
Clear CMOS Setting
For first-time DIY system builders, we recommend that you not change the
default jumper settings if you are not quite familiar with the mainboard con-
figuration procedures. The factory-set default settings are tuned for optimum
system performance. For advanced users who prefer to customize their sys-
tem, section 3.2 Jumper Settings provides the detailed information on how
to configure your mainboard manually.
Step 3
Install DDR SDRAM System Memory
To install memory, insert DDR SDRAM memory module(s) in the DIMM
banks. Note that DDR SDRAM modules are directional and will not go in the
DIMM banks if they are not properly oriented. After the module is fully in-
serted into the DIMM bank, lift the clips of both sides of the DIMM bank to
lock the module in place.
DDR SDRAM

- 13 -
Step 4
Install Internal Peripherals in System Case
Before you place the mainboard into your system case, we recommend that
you first assemble all the internal peripheral devices into the computer hous-
ing, including, but not limited to, the hard disk drive (IDE/HDD), floppy disk
drive (FDD), CD-ROM drive, and ATX power supply unit.
To install IDE & FDD drives, follow these procedures:
1. Set the required jumpers on each device according to the instructions pro-
vided by the manufacturer. (IDE, HDD, and CD-ROM have to set jumpers
to Master or Slave mode depending on whether you install more than one
device of each kind.)
2. Connect the IDE cable and FDD cable on the back panel of the internal
peripheral devices to the corresponding headers on board. Note that the
cable should be oriented with its colored stripe (usually red or magenta)
connected to pin#1 of the IDE or FDD connector on the mainboard and
on the device as well.
3. Connect an available power cable from your system power supply unit to
the back panel of each peripheral device. Note that the power cable is di-
rectional and cannot fit in if not properly positioned.

- 14 -
Step 5
Mount the Mainboard on the Computer Chassis
1. You may find there are a lot of mounting holes on your computer chassis
and mainboard. To match the holes on both properly, the key point is to
make the back panel of the mainboard in a close fit with your system case,
as shown below.
2. Position the studs between the chassis and the mainboard. The studs are
used to fix the mainboard and to keep a certain distance between them,
for avoiding any electrical shorts in-between.
(If your computer case is already equipped with mounting studs, you need
to tighten the screws to attach the mainboard.)
Note: In most computer housings, you can find 4 or more holes to place
studs for fixing the mainboard. If there aren't enough matching holes,
screw at least 4 studs to ensure the proper attachment of the main-
board.
