SI Nano Roll User manual

INSTALLERS: Please leave this manual with the owner.
Narrow Wirefree - Zigbee
Nano Roll
Installation Instructions
Doc. # 400091

1
PARTS LIST - NANO ROLL (NARROW) - WIREFREE
Wall Brackets
Ceiling Brackets
Screws Included
(3 per bracket)
ChargerShades (275 Roll)
Leveling Shims
(included)
Spacer Blocks
(included)
Please note all the QR CODES on your Shade motors.
See the last page on these instructions.
Situo Remotes
(Optional)
1 channel 4 channels

2
NARROW SHADE - INITIAL CONSIDERATIONS
1a. Install 4 Spacer Blocks per bracket, to accommodate for external battery.
1b. Install shade brackets at least 1” from back plane (glass or wall) to accommodate for
external battery.
Wall Mount only
Ceiling Mount only

3
SPACER BLOCKS AND LEVELING SHIMS (OPTIONAL)
Spacer Blocks - used to clear an obstruction in the fabric path.
Connect spacer blocks to shade brackets before installation
Leveling Shims - used if the window frame is out of level.
Connect to shade brackets before installation
NOTE: Do not use more than 2 leveling
shims per bracket.
NOTE: Do not use more than
4 Spacer blocks per bracket.

4
BRACKET INSTALLATION
1b. Install the wall bracket / end cap assemblies with the supplied screws
1a. Install the wall bracket / end cap assemblies with the supplied screws
Use 1/4” magnetic
driver (incl.)
for Ceiling Mount
Motor
side
Idler
side
Wall Mount only
Ceiling Mount only

5
MEASURE - NANO ROLL
Measure the end cap to end cap width and verify it matches the ordered width. Adjust accordingly
Brackets must be level before the
shade is installed!

6
BATTERY INSTALLATION - WALL MOUNT
1. Install the external battery brackets to the dimensions listed below
2. Fasten each bracket with the included hardware (use drywall anchors if necessary)
3. Connect the magnet wire to the external battery and install into the brackets as shown below.

7
BATTERY INSTALLATION - CEILING MOUNT
1. Install the external battery brackets to the dimensions listed below
2. Fasten each bracket with the included hardware (use drywall anchors if necessary)

8
BATTERY INSTALLATION - CEILING MOUNT
3. Connect the magnet wire to the external battery and install into the brackets as shown below.
4. Install wire clips as shown (optional)

9
1. Remove the idler end cap with flat bladed screw driver
2. Insert motor side completely.
NOTE: When installing, the shade should be
at the upper limit.
SHADE INSTALLATION - NANO ROLL

10
3. Then, while supporting motor side, put idler end cap over the idler and snap into place.
There will be an audible click.
SHADE INSTALLATION - NANO ROLL

11
CONNECT BATTERY - WALL MOUNT
1. Connect Shade to External Battery as shown below.
NOTE: After connecting shade to battery, tuck wires up
and away from shade.

12
CONNECT BATTERY - WALL MOUNT
1. Connect Shade to External Battery as shown below.
NOTE: After connecting shade to battery, tuck wires up
and away from shade.

13
PROGRAMMING - ZIGBEE
The lower limit of every shade is preprogrammed to 1/2” from the bottom of the window. After
installing each shade, follow these steps to adjust the lower limit:
STEP 2 - Assign shades to groups :
All grouping of devices is completed within the TaHoma application:
1. Open the TaHoma application and navigate to the conguration tab.
2. Press the + symbol in the upper right corner.
3. Choose the Zigbee device type.
4. Select “Add Zigbee Group”.
5. Label the group.
6. Select the devices you would like to be included in this group.
STEP 3 - Pair devices or groups with a remote:
All pairing of devices and groups to remotes is completed within the TaHoma application. In
order to pair more than one shade to a channel, a group must be created rst.
1. Open the TaHoma application and navigate to the conguration tab.
2. Press the chain/link button next to the remote being congured.
3. Select the shade or group to pair from the list and deselect any other devices.
4. Quick press the programming button on the back of the remote and click OK in the application
to conrm.
NOTE: Each Zigbee Situo remote channel will be capable of pairing to a group containing up to 20 motors.
PROGRAMMING STEPS
(TaHoma/LinkPro Z must be plugged in and on the network)
Step 1: Fine tune lower limit.
Step 2: Assign shades to groups and remotes.
Step 3: Pair devices and groups with remotes.
STEP 1 - Fine tuning lower limit :
1. Click on the 3 dots in the lower right hand corner of the TaHoma app.
Note: You may see a pop-up warning window which could damage the shade.
2. In settings click on advanced settings.
3. Select the shade you want to set the limits to.
4. You only want to select and adjust the lower limit.
Note: Do not set upper limit or change rotation.
5. Press the down button in the app to move the shade to the Factory set lower limit.
6. Click Next.
7. Now make up or down adjustments to shade using the Up / Down increments. Each (button
press) adjustment can take a couple seconds, to execute. Once you are satised with the new
lower limit, press save Limit.

14
TROUBLESHOOTING - ZIGBEE
For Zigbee
Technical Support: 512.832.6939 screeninnovations.com
Hours of Support: 7:30am - 5pm CST [email protected]
Please use this QR Code
to access the updated
installation instructions
Problem Possible Cause Action to Take
TaHoma LED is Red. No internet
connectivity.
Check network connection to the internet, and ensure
the TaHoma is properly connected via ethernet or
Wi.
Shade won’t operate. Motor battery is low/
drained.
Check the battery level of a motor via the TaHoma
application. If the battery level is below 20%, the
charging cord can be plugged in and the shade will
operate while charging.
The remote battery
may be low.
Check that the green LED on the remote flashes when
a button is pressed. If the LED does not flash at all,
the remote may need a new CR2430 battery.

15
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
NOTES

16

17
MOTOR SERIAL NO.S
Please keep a note of all the Serial No.s on your shade motors. OR for larger shade orders,
refer to your Sales Order document for the list.
Room
Room
Shade 1
Shade 1
Shade 3
Shade 3
Shade 5
Shade 2
Shade 2
Shade 4
Shade 4
Shade 6

Screen Innovations
9715-B Burnet Rd, Suite 400 Austin, TX 78758
512.832.6939
www.screeninnovations.com
400086 v. 1.3 13 November 2019
