SI Nano Roll User manual

Screen Innovations
9715-B Burnet Rd, Suite 400 Austin, TX 78758
512.832.6939
www.screeninnovations.com
®
400033 v. 1.3 25 April 2022

INSTALLERS: Please leave this manual with the owner.
Nano Roll
Manual Operation Instructions

Shade
End Caps
Wall Brackets
275 Roll
Parts list - Nano Roll - Manual Pg 1
PARTS LIST – Nano Roll – Manual Operation
Screws included
(3 per bracket)

Pre-Tension Tool
Spanner Wrench
Additional Accessories list - Nano Roll - Manual Pg 2
Set Screw Hex Tool
ADDITIONAL ACCESSORIES LIST – Nano Roll – Manual
Note: For more information about these tools and their use, please call Tech Support at
512.832.6939 Opt. 1

SHADE ORIENTATION - Standard Roll
Spring side
Idler side
Before installing the shades, verify whether the shade was ordered as standard roll or reverse roll. The
illustrations in this manual show standard roll shades, but the installation procedure for reverse roll
shades is very similar.
Shade Orientation - Nano Roll - Standard Roll Pg 3

SHADE ORIENTATION - Reverse Roll
Spring side
Idler side
Shade Orientation - Nano Roll - Reverse Roll Pg 4

Before installing a Nano manual shade, the spring tension must be set. The amount of pre-tensions
required for each shade varies and can be found on the attached shade list.
1. Insert the pre-tension tool into the spring control, and rotate counter-clockwise until the correct
number of pre-tension rotations are set.
NOTE: For reverse roll shades, the
tension direction will be opposite.
Pre - Tension - Nano Roll - Manual Pg 5
PRE-TENSION – Nano Roll – Manual Operation
NOTE: Start with arrows and small
rib facing up.

2. Turn the spring control an extra 1/4 turn and slowly release it to lock the shade spring in place.
1/4 Turn
Pre - Tension - Nano Roll - Manual Pg 6
PRE-TENSION – Nano Roll – Manual Operation

3. Measure the bracket to bracket width and verify it matches the width as ordered.
Remove the end caps.
1. Hold the wall bracket/end cap assembly against the wall and mark the hole locations.
2. Remove the end cap, fasten the bracket with the supplied screws, and replace the end cap.
NOTE: Nano manual shade brackets are intended to be wall mounted.
They may be ceiling mounted, but the appearance is degraded.
Installation - Nano Roll - Manual Pg 7
NOTE: Make sure to leave
enough space for the end cap.
INSTALLATION – Nano Roll – Manual Operation
Brackets must be
level before the
shade is installed!

4. Insert the idler side, making sure the four small pins are engaged with the bracket.
5. Install the spring side with the small rib and arrows facing upwards.
Installation - Nano Roll - Manual Pg 8
NOTE: Shade should be oriented with weight
bar approximately at upper limit.
INSTALLATION – Nano Roll – Manual Operation

1. Pull the shade down approximately halfway.
2. Pull the shade down a small amount (~1/2”) and release. The shade will run to the upper limit.
Pg 9
Verify Spring Tension and Upper Limit
VERIFY – Spring Tension and Upper Limit

3. If the shade moves too slowly, remove from bracket and add one pre-tension turn at a time
until the desired speed is achieved.
4. If the shade moves too quickly, remove from bracket and reduce one pre-tension turn at a time
until the desired speed is achieved.
Verify Spring Tension and Upper Limit Pg 10
VERIFY – Spring Tension and Upper Limit

6. Install the end caps and lock them in place with the set screw.
5. Adjust the shade limiter using the included spanner wrench as shown below.
a. Turn the shade limiter counter-clockwise to
lower the upper limit.
b. Turn the shade limiter clockwise to raise
the upper limit.
Verify Spring Tension and Upper Limit Pg 11
VERIFY – Spring Tension and Upper Limit

TROUBLESHOOTING
Problem Cause Solution
Shade is slow or jerky
when moving up
Spring does not have
enough pre-tension turns
Add one pretension turn at a time until the shade
operates smoothly.
Shade abruptly stops
at upper limit
Spring has too many
pre-tension turns
Remove one pre-tension turn at a time until shade
stops at upper limit smoothly.
Shade doesn’t stop at
upper limit
Limit incorrectly set. Use the included spanner wrench to adjust the upper
limit. Turn clockwise to move limit down, turn counter
clockwise to move limit up.
Troubleshooting Pg 12
Tech Support: 512.832.6939
Technical Support: 512.832.6939 screeninnovations.com
Hours of Support: 7:30am - 5pm CST shadesupport@screeninnovations.
com
Please use this QR Code
to access the updated
installation instructions
and related documents.
