Siare Morpheus Series User manual

Anaesthesia Unit
User's Manual – Morpheus LT / RMI

User’s Manual, DU3310103-MRI / rev. 3 - 02.05.2019 III
GENERAL INFORMATION
The information contained in this manual are the exclusive property of
SIARE ENGINEERING INTERNATIONAL GROUP s.r.l. and may not be
reproduced in any way without authorisation. SIARE ENGINEERING
INTERNATIONAL GROUP s.r.l. reserves the
right to modify or replace this
manual at any time without prior notice.
It is however recommended that you make sure you have the most recent
version of the manual. In the event of doubt, contact SIARE ENGINEERING
INTERNATIONAL GROUP s.r.l. (see the addr
ess on page IX). The
information contained herein can be considered correct, but do not
exclude professional knowledge by the user of the equipment.
The operation and maintenance must be entrusted to qualified technical
personnel only. The responsibility
of SIARE ENGINEERING
INTERNATIONAL GROUP s.r.l. as regards the anaesthesia unit and its use
is limited to what is indicated in the guarantee supplied with the equipment.
The contents of this manual do not in any way limit the right of SIARE
ENGINEERING IN
TERNATIONAL GROUP s.r.l. to revise, change or modify
without prior notice the equipment (including the relative software) described
herein.
Unless otherwise specifically agreed in writing, SIARE ENGINEERING
INTERNATIONAL GROUP s.r.l. is not obliged to sup
ply such revisions,
changes or modifications to the owner or user of the equipment (including
the relative software) described herein.
The information contained in this manual refers to the versions of
MORPHEUS anaesthesia unit produced or updated after May 2019
. It is
possible that some information may not apply to previous versions. Contact
SIARE ENGINEERING INTERNATIONAL GROUP s.r.l. if you have any
doubts.
User’s Manual, version DU3310103-MRI
Revision 3 - 02.05.2019

IV MORPHEUS MRI
Observations
SIARE ENG
INEERING INTERNATIONAL GROUP s.r.l. wishes to thank you
for purchasing one of its products.
Any comments on the accuracy and usefulness of this User’s Manual would
be very helpful in allowing us to guarantee current and future users of the
high quality lev
el of our manuals. We would be grateful if you would send
your comments to the following address:
SIARE ENGINEERING INTERNATIONAL GROUP s.r.l.
Tel.: [phone] - Fax: [phone]
E mail: [e-mail]
Web: www.siare.it
The SIARE trademark is used
throughout this manual as an abbreviation for
the manufacturer: SIARE ENGINEERING INTERNATIONAL GROUP s.r.l.
Directive 93/42 EEC

User’s Manual, DU3310103-MRI / rev. 3 - 02.05.2019 V
Definitions
Three symbols are used in this User’s Manual to indicate particularly important
information.
WARNING!
This indicates a condition of danger for the patient or for the
operator.
CAUTION
This indicates the possibility of danger to the equipment.
N.B.
This indicates information worthy of note, making the operation
of the of MORP
HEUS anaesthesia unit more efficient or
practical.

VI MORPHEUS MRI
Warnings, cautions and notes
You are advised to carefully read the information given alongside the three
symbols shown on the previous page, since it contains considerations on
the saf
ety, the special requirements for the use MORPHEUS anaesthesia
unit and the relative safety regulations.
•
In order to understand how the MORPHEUS anaesthesia unit works
and how to use it correctly to ensure patient and user safety, the
recommendations and i
nstructions contained in this manual must be
read with care and understood.
•
The anaesthesia unit must only be used for the purposes specified
herein and the safety of the equipment is therefore only guaranteed if it
is used in accordance with the instructions given in this User’s Manual.
•
The materials used were carefully selected during the design stage after
specific checks, tests and comparative trials: these materials are also
constantly inspected during the production cycle to achieve the best
results i
n terms of reliability and safety for the patient and the operator.
Any part of circuit must therefore only be replaced with original spare
parts supplied or checked by SIARE.
•
The anaesthesia unit must only be used by qualified personnel and only
in equipp
ed and dedicated rooms, according to the regulations in force
in the country where the equipment is installed.
•
To ensure correct technical assistance and avoid possible physical
damage to the patient, the maintenance schedule foreseen in this
manual must b
e respected; qualified personnel must only carry out
maintenance of the anaesthesia unit or authorised modifications to the
equipment. The user of this product is solely responsible for any
operating defect caused by improper use or interventions carried o
ut by
third parties other than specialised SIARE personnel.
•
For any repairs to anaesthesia unit (due to malfunctioning, defects or
failures), the user must contact SIARE or the authorised local Technical
Service Centre; it is advisable to specify the data
on the identification
label (model, serial number, ……) when requesting intervention.
•
SIARE recommends establishing a maintenance and service contract
with SIARE or the local authorised service dealer in order to guarantee
the scheduled maintenance required
to operate the anaesthesia unit in
a safe and correct manner.

User’s Manual, DU3310103-MRI / rev. 3 - 02.05.2019 VII
•
To prevent the risk of fire, keep the lung ventilator and/or the oxygen
tubes of the equipment away from matches, lit cigarettes and
inflammable material, such as anaesthetic gases and/or so
urces of
heat.
•
Do not connect the anaesthesia unit to the patient by flexible
connectors, and antistatic or conductive tubes to prevent patient
burnings during the use of high frequency surgical equipment, specially
dangerous with antistatic tubes. The use
of flexible connectors,
antistatic or conductive tube is never permitted with MORPHEUS
anaesthesia unit.
•
Do not use worn and consumed tubes or tubes contaminated by
flammable substances like grease or oil to deliver oxygen; (fabrics, oil
and other fuels c
an easy ignite and they intensively burn in air with high
concentration of oxygen.
•
In the event of fire or an unpleasant smell (e.g. a smell of burning), the
lung ventilator should immediately be disconnected from the electrical
power supply and from the battery (if fitted).
•
When coming into contact with any component of the anaesthesia unit,
the hospital procedures for the handling of infected material should
always be respected.
•
SIARE is aware that cleaning, sterilisation and disinfection procedures
vary
considerably from one health structure to another. SIARE cannot
be held responsible for the efficacy of the cleaning and sterilisation
procedures, nor for the other procedures carried out while the patient is
being treated. As regards cleaning, sterilisat
ion and disinfection of the
product components, it is therefore recommended that the regulations
currently in force in the country where the equipment is installed be
taken into consideration.
•
The MORPHEUS anaesthesia unit was not designed as a total
monit
oring device: some conditions of danger for the patients treated
with vital support equipment will not trigger any alarm.
•
Before using the anaesthesia unit or any connected component,
carefully check that the equipment is functioning correctly; when
needed, the auto-
diagnostic test must be performed as described in the
present User’s Manual.
•
Do not use pointed instruments, such as pencils, screwdrivers or the
like to make selections or settings as they could damage the surface
of the panel.
•Check the anaest
hesia unit periodically as described in the relative
“Maintenance” chapter and do not use it if it is faulty or malfunctioning.
Replace any broken, missing, obviously worn, deformed or
contaminated parts immediately, with spare parts supplied by SIARE.

VIII MORPHEUS MRI
•D
o not connect external devices NOT manufactured or NOT authorized
by SIARE to the equipment (example
: scavenging systems, patient
simulators, etc…..), and not described in the present user’s manual: in
case of need contact SIARE.
•The correct functioning
of the anaesthesia unit can be impaired if
original SIARE spare parts and accessories are not used; the use of
other accessories is however allowed only if formally authorised by
SIARE in accordance with current safety regulations.
•SIARE assumes all forese
en legal liability if the anaesthesia unit is used
and periodically maintained according to the instructions contained in
this manual: the Technical Assistance Report, drawn up and signed by
the authorised SIARE technician, is proof of the completion of th
e
scheduled maintenance.
•
Notwithstanding the MORPHEUS anaesthesia unit is equipped with a
safety valve which allows to the patient to breathe spontaneously the
ambient air even in case of gas supply failure, the auxiliary ventilation
system must be always
promptly available; such a component is part of
SIARE ENGINEERING INTERNATIONAL GROUP s.r.l. products range.

User’s Manual, DU3310103-MRI / rev. 3 - 02.05.2019 IX
WARNING !!
This equipment is not approved for operation in places where
there is any risk of explosion.
WARNING !!
Do not use the equipment in the presence of flammable gases.
WARNING !!
The equipment cannot be used in the presence of explosive
gases.
WARNING !!
Before connecting the anaesthesia unit
to other electrical
equipment not described in this manual
, a request for
authorisation should be sent to Siare.
WARNING !!
Qualified staff must make the regulation of ventilation
parameters.
WARNING !!
An auxiliary ventilation system is suggested for the patients for
which the ventilator represents a life support.
WARNING !!
Independent ventilation tools
should be available (i.e. manual
resuscitator bag equipped with face
mask) each time the
ANESTHESIA UNIT is in use.

X MORPHEUS MRI
SIARE declines all civil and penal responsibility in the
following cases:
•
If the anaesthesia unit is used in conditions and for
purposes not stated or described in this manual.
•If the anaesthesia unit is used by non-qualified personnel.
•
If periodic maintenance as foreseen by this manual has not
been carried out correctly or has been skipped.
•
If personnel not officially authorised by SIARE have
performed maintenance.
•If non-
original SIARE spare parts or components not
checked by SIARE have been used.
•
If the anaesthesia unit has been connected to equipment
not complying with the safety norms for the intended use.
•
Direct or indirect damage to persons or things caused by
unauthorised technical intervention or by improper use of
the anaesthesia unit not in accordance with the instructions
contained in the users and maintenance manual.

User’s Manual, DU3310103-MRI / rev. 3 - 02.05.2019 XI
Year of manufacture
Check the identification data label of the equipment in the relative chapter.
Manufacturer
SIARE ENGINEERING INTERNATIONAL GROUP s.r.l.
Via Giulio Pastore , 18 - Località Crespellano,
40053 Valsamoggia (Bologna), ITALY
Tel.: [phone] - Fax: [phone]
E-mail: [e-mail] - Web: www.siare.it
Electromagnetic Compatibility
The MORPHEUS anaesthesia unit is designed to operate in the specified
electromagnetic environment (see warning below).
The customer or the user of MORPHEUS anaesthesia unit should ensure that
it is used in such an electromagnetic environment.
The MORPHEUS anaesthesia unit complies with the EN 60601-
1-2 regulations on Electromagnetic Compatibility of electro-
medical equipment. It is in any case highly recommended not to
use the anaesthesia unit adjacent to high-powered equipment
or to units, which emit strong electro-magnetic fields. Mobile
phones, cordless phones or other radio transmitters used in the
vicinity of the equipment could influence its operation.
Whenever the anaesthesia unit should be necessarily used
nearby to such equipment, it will be required to supervise its
normal operation.
In general, as regards the regulations regarding
“electromagnetic emissions”, “electromagnetic immunity”
and “recommended separation distances between portable
and mobile RF equipment and the device”, always refer to
what is described in the MORPHEUS anaesthesia unit user’s
manual.
Requirements appli
cable to cables, transducers and other
ACCESSORIES that could affect compliance with the
requirements of 6.1 and 6.2

XII MORPHEUS MRI

Index
User’s Manual, DU3310103-MRI / rev. 3 - 02.05.2019 III
Table of contents
GENERAL INFORMATION..............................................................................................III
Observations...................................................................................................................................IV
Definitions ........................................................................................................................................V
Warnings, cautions and notes ........................................................................................................VI
Table of contents .............................................................................................................................III
1 INTRODUCTION.....................................................................................................1-1
1.1 Foreseen use ........................................................................................................................ 1-1
1.2 Versions ................................................................................................................................ 1-1
1.3 Main technical characteristics............................................................................................... 1-2
1.3.1 Trolley........................................................................................................................................1-2
1.3.2 Valves group .............................................................................................................................1-2
1.3.3 Flowmeter box...........................................................................................................................1-3
1.3.4 Ventilator section ......................................................................................................................1-3
1.4 Correct operation .................................................................................................................. 1-5
1.5 Applicable norms................................................................................................................... 1-6
2 DESCRIPTION........................................................................................................2-1
2.1 MORPHEUS LT/MRI............................................................................................................. 2-2
2.2 Trolley.................................................................................................................................... 2-3
2.2.1 Support for vaporizers...............................................................................................................2-3
2.2.2 Control panel for manual ventilation ( 9 )...................................................................................2-4
2.3 Side view............................................................................................................................... 2-6
2.3.1 Valves group ( 10 )....................................................................................................................2-7
2.3.2 Connections for scavenger ( 21 ) ..............................................................................................2-9
2.3.3 Electric power supply module ( 22 ) ..........................................................................................2-9
2.4 Back view............................................................................................................................ 2-10
2.4.1 Gas supply group ( 23 )...........................................................................................................2-11
2.4.2 Connectors for services ( 24 ) .................................................................................................2-12
2.4.3 Equipment identification ..........................................................................................................2-13

Index
IV MORPHEUS MRI
3 VALVES GROUP MODULE....................................................................................3-1
3.1 Introduction............................................................................................................................ 3-2
3.2 Valves group ......................................................................................................................... 3-3
3.2.1 Main features.............................................................................................................................3-3
3.3 Description ............................................................................................................................ 3-4
3.3.1 Patient circuit view.....................................................................................................................3-4
3.3.2 Electric connexion view.............................................................................................................3-5
3.3.3 Upper view ................................................................................................................................3-6
3.4 Use........................................................................................................................................ 3-7
3.4.1 CO2 soda lime absorber canister..............................................................................................3-7
3.4.2 Connections to valves group...................................................................................................3-10
4 DESCRIPTION........................................................................................................4-1
4.1 Introduction............................................................................................................................ 4-2
4.2 Anaesthesia module with mechanical flowmeters box ......................................................... 4-3
4.2.1 Main features.............................................................................................................................4-3
4.3 Description of S5 version ...................................................................................................... 4-6
4.3.1 Notes.........................................................................................................................................4-8
5 LUNG VENTILATOR MODULE ............................................................................5-1
5.1 Description ............................................................................................................................ 5-2
5.2 Monitoring areas and functional areas.................................................................................. 5-6
5.2.1 User’s controls area and operative mode selection...................................................................5-7
5.2.2 Controls for Preliminary checks.................................................................................................5-8
5.2.3 PRESET Area .........................................................................................................................5-12
5.2.4 Alarm area...............................................................................................................................5-13
5.2.5 Ventilation parameters setting area.........................................................................................5-14
5.2.6 Ventilation parameters monitoring area...................................................................................5-17
5.3 Flow sensor calibration ...................................................................................................... 5-20
6 PREPARATION TO USE........................................................................................6-1
6.1 General warnings.................................................................................................................. 6-2
6.2 Before the use....................................................................................................................... 6-5
6.2.1 Assembling of O2 cell................................................................................................................6-5
6.2.2 Flow sensor assembling............................................................................................................6-6
6.2.3 Assembling of absorber canister...............................................................................................6-7
6.2.4 Battery charger..........................................................................................................................6-9

Index
User’s Manual, DU3310103-MRI / rev. 3 - 02.05.2019 V
6.3 Preparation to use............................................................................................................... 6-11
6.3.1 Medical gas connection...........................................................................................................6-11
6.3.2 Connection of anesthetic gases scavenging system...............................................................6-14
6.3.3 Patient circuit connections.......................................................................................................6-15
6.3.4 Fresh gases exit - TO and FRO patient circuit ........................................................................6-17
6.3.5 Connection of circuit for manual ventilation.............................................................................6-18
6.3.6 Use of antibacterial filter..........................................................................................................6-19
6.3.7 Mains power supply.................................................................................................................6-20
6.3.8 Protection fuses.......................................................................................................................6-24
6.3.9 Connection to other equipments..............................................................................................6-25
6.3.10 Table of predisposition sequence for use................................................................................6-26
6.4 Preliminary tests - Introduction............................................................................................ 6-27
6.4.1 Verification activity - “ SELF TEST “........................................................................................6-29
6.5 Preliminary checks - Operating phase................................................................................ 6-34
6.5.1 Preliminary checks..................................................................................................................6-35
6.5.2 Preliminary checks - Flowmeter box........................................................................................6-39
6.5.3 Preliminary tests - Lung Ventilator...........................................................................................6-44
6.5.4 Preliminary tests - Alarms........................................................................................................6-48
6.5.5 Preliminary tests sequence table.............................................................................................6-51
7 USE OF LUNG VENTILATOR ...............................................................................7-1
7.1 Introduction............................................................................................................................ 7-2
7.2 Flowmeter box....................................................................................................................... 7-3
7.2.1 Dosing and administration of fresh gas.....................................................................................7-3
7.2.2 Administration of fresh gas in the "TO and FRO" system..........................................................7-6
7.2.3 Mechanical flowmeter box pre-setting.......................................................................................7-7
7.3 Lung ventilator ....................................................................................................................... 7-9
7.4 Operative modes...............................................................................................................................7-12
7.4.1 STAND-BY..............................................................................................................................7-13
7.4.2 PCV.........................................................................................................................................7-14
7.4.3 VAC.........................................................................................................................................7-16
7.4.4 MAN ........................................................................................................................................7-18
7.5 Respiratory physiological parameters [ PRF ]...................................................................................7-21
7.5.1 Ventilation parameters.............................................................................................................7-21
7.6 Monitoring.........................................................................................................................................7-25
7.6.1 Ventilation parameters monitoring area...................................................................................7-25
7.7 Power supply......................................................................................................................................7-27

Index
VI MORPHEUS MRI
8 ALARMS.................................................................................................................8-1
8.1 Definitions.............................................................................................................................. 8-2
8.2 General.................................................................................................................................. 8-3
8.3 Alarms visualization .............................................................................................................. 8-5
8.4 List of alarms and priorities................................................................................................... 8-7
8.4.1 Regulations and default values table.........................................................................................8-8
8.5 Description ............................................................................................................................ 8-9
8.6 Setting of alarm parameters................................................................................................ 8-12
9 TROUBLESHOOTING............................................................................................9-1
10 MAINTENANCE....................................................................................................10-1
10.1Cleaning, disinfection and sterilisation................................................................................ 10-3
10.2General instructions ............................................................................................................ 10-4
10.2.1 Cleaning..................................................................................................................................10-4
10.2.2 Disinfection and sterilisation....................................................................................................10-5
10.2.3 Disinfection by immersion (chemical)......................................................................................10-6
10.2.4 Cleaning, disinfection and sterilisation table............................................................................10-7
10.2.5 Periodic maintenance............................................................................................................10-10
10.2.6 Maintenance operations........................................................................................................10-10
10.3Repairs and spare parts.................................................................................................... 10-13
10.3.1 Annual kit for MORPHEUS LT/MRI anaesthesia unit............................................................10-13
10.4Repackaging and shipment............................................................................................... 10-13
10.5Disposal............................................................................................................................. 10-14
10.6Storage.............................................................................................................................. 10-14
11 APPENDIX............................................................................................................11-1
11.1Technical sheet................................................................................................................... 11-2
11.2Table for Identification of medical gas hose colours........................................................... 11-8
11.3Glossary.............................................................................................................................. 11-9
11.4Electromagnetic compatibility tables................................................................................. 11-14
11.4.1 Annex A: Table 1...................................................................................................................11-14
11.4.2 ANNEX B: Table 2.................................................................................................................11-15
11.4.3 ANNEX C: Table 3 ................................................................................................................11-16
11.4.4 ANNEX E: Table 5.................................................................................................................11-17
11.5Preliminary tests................................................................................................................ 11-19

Introduction
User’s Manual, DU3310103-MRI / rev. 3 - 02.05.2019 1-1
1 PRESENTATION
SIARE ENGINEERING INTERNATIONAL GROUP s.r.l. is glad to introduce this new
product, result of 40 years of experience and investment in technological innovation
that we are implementing in recent years.
Siare has focused heavily on innovation of materials, ergonomics and ease of use. All
routine operations have been simplified and the operational procedures are
“foolproof”, in this way there is no margin for the user to make incorrect or inadequate
manoeuvres.
Even the maintenance procedures have been simplified and the parts subject to wear
or deterioration have substantially decreased. Siare invested much on this project
because we firmly believe that it will be a winning product.
1.1 Foreseen use
The MORPHEUS LT/MRI is an anaesthesia unit that can be used on adult, children
and newborn patients. The MORPHEUS LT/MRI is an anaesthesia machine
compatible for Magnetic Resonance rooms from 1,5 T (15000 G) and from 3 T (30000
G) and positionable at a min. distance from the magnet corresponding to a field of 20
mT (200 G).
The MORPHEUS LT/MRI is suitable for administration of Oxygen - Air - Nitrous Oxide
- Halothane - Enflurane - Isoflurane - Sevoflurane - Desflurane mixtures. The fraction
of inspired oxygen can vary from 21% to 99%.
1.2 Versions
To respond to the several requirements and market requirements, the MORPHEUS
LT/MRI anaesthesia unit foresees a unique trolley configurable for MRI.
The basic trolley is composed by the following modules:
•mechanic structure of the trolley,
•work-shelf,
•valves group,
•electric power supply module,
•electronic lung ventilator with DISPLAY,
•flowmeter box at 3 gas and 5 rotameters.

Introduction
1-2 MORPHEUS MRI
1.3 Main technical characteristics
1.3.1 Trolley
The mechanic structure of the trolley is made of completely non-magnetic materials.
The pedestal base is made of a shockproof ABS and polyester coated. This ensures
an excellent impact resistance thanks to its flexibility and excellent abrasion
resistance.
Its dimensions and weight are very reduced and allow its installation also in small
rooms or small working areas or combined with pendant lifting systems.
The work-shelf is mono-bloc, made of a unit PUR mould. The shelf also includes the
housing for the valves group and the manual ventilation controls. The shelf is very
wide and the large handle below the perimeter allows to hold and easily move the
unit.
On the left side a steel rod at full height is provided for fixing the patient monitor and
other accessories like for example the supporting arm for patient circuit, infusion
pumps, etc.
The lateral uprights are provided with a vertical guide for fixing the accessories or
lateral devices, e.g. the pendant lifting system, lateral lectern or PC support for
medical record writing.
On the back side are the medical gas intakes, which are positioned in a rational and
easily visible way. The intake for main supply system and pressure reducer-cylinder
are also provided, with a non return valve and automatic change. In case of main gas
failure just open the cylinder and the gas will be immediately available for use without
additional manoeuvres.
1.3.2 Valves group
Completely renewed and performing, it presents the following definite advantages.
•Extraction from above and perfect integration with the work-shelf.
•Automatic connections with double seal gaskets against accidental leaks.
•Mono-bloc, fully sterilizable in autoclave
•Automatic flow sensor and oxygen sensors calibration procedure activated by
operator
•The access to flow sensor and O2sensor is simple and immediate.

Introduction
User’s Manual, DU3310103-MRI / rev. 3 - 02.05.2019 1-3
•The CO2absorber canister is located in the upper side and it easy to disconnect
by apposite unlock lever. With canister inserted the system makes automatic
configuration in rebreathing modality; with taken off canister, the system makes
automatic configuration in non rebreathing modality (real open circuit). It is
possible to put and take off the canister during intervention. The canister is
available in version for reuse and disposable version including soda lime
granules.
•Low periodic and extraordinary maintenance operations; easy training of
technical personnel thanks to the extreme rationality of the system and to the
drastic reduction of accidental leaks.
1.3.3 Flowmeter box
The flowmeter box is available at five rotameters; it is characterized by the complete
absence of mechanical controls; replaced by a small control panel located on the left
side of the work-shelf to manage all manual ventilation operations. This solution
allows the presence of audible and visual alarms of strong impact and without
duration limits.
1.3.4 Lung ventilator module - DISPLAY
The lung ventilator module, through user’s interface, allows to set and display the
main respiratory parameters useful for the operator to use the MORPHEUS LT/MRI
anaesthesia unit.
The lung ventilator module foresees the following operative modes: MANUAL, VC-
VAC, PCV-APCV. This ventilator type is characterized by a very simple user’s
interface and by an important novelty relevant to the presence of PRESET programs
for adults, children and newborns.
The passage from MANUAL to AUTOMATIC ventilation is made by simple pressure
on the push-button on the keyboard alongside the DISPLAY.
The valves group is automatically configured for the selected modality without any
manual procedures, avoiding errors or inadequate manoeuvres.
The lung ventilator module, foresees the possibility to ad just the end expiration
positive pressure (PEEP), the trigger sensitivity and is equipped with the FiO2
monitoring with automatic calibration and leak test.

Introduction
1-4 MORPHEUS MRI
For the controlled ventilation of newborn patients, make reference to
the chapter 7.4, about use with premature patients.
For a correct comprehension of MORPHEUS LT/MRI anaesthesia
unit operation and for a correct and safe use both for the patient and
user, the knowledge of recommendations and instructions indicated
in the present User’s Manual is required.
For anyone who already has basic knowledge of anaesthesia unit
functioning and of lung ventilation in general, the use of the user
interface is intuitive and it will be sufficient to consult this user’
s
manual
in order to use the MORPHEUS LT/MRI anaesthesia unit
correctly.
The lung ventilator module, incorporate a series of sensors for continuous patient
monitoring, the most important of which are:
•the flow sensor on the expiratory line, used to measure the expiratory volumes of
the patient;
•the pressure sensors, used to control the pressure of the airways or of the
medical gases;
•the oxygen sensor, used to measure the concentration of oxygen in the gas
inspired by the patient.
The operator must check the functioning of all these sensors before
using the device in order to prevent incorrect assessments of the
patient’s condition.
