Stryker Power-PRO TL Cot Fastener Series User manual

PPoowweerr--PPRROO™™ TTLL CCoott FFaasstteenneerr
MMaaiinntteennaannccee MMaannuuaall
6385
6386
6387
6388
6389
EN
6385-009-002 Rev A.5 2019/09

SSyymmbboollss
Operating instructions/Consult instructions for use
General warning
Catalogue number
Authorized representative in the European Community
European medical device
Manufacturer
CE mark
 
For US Patents see www.stryker.com/patents
6385-009-002 Rev A.5 EN

TTaabbllee ooff CCoonntteennttss
Warning/Caution/Note Definition ..............................................................................................................................2
Summary of safety precautions ................................................................................................................................2
Introduction ...............................................................................................................................................................3
Product description .................................................................................................................................................3
Indications for use...................................................................................................................................................3
Expected service life ...............................................................................................................................................3
Disposal/recycle .....................................................................................................................................................3
Contraindications....................................................................................................................................................3
Specifications .........................................................................................................................................................3
Product illustration ..................................................................................................................................................4
Contact information.................................................................................................................................................5
Serial number location.............................................................................................................................................5
Date of manufacture................................................................................................................................................5
Preventive maintenance ..........................................................................................................................................5
Maintenance record ................................................................................................................................................6
Training record .......................................................................................................................................................7
Model 6385 cot fastener assembly...........................................................................................................................8
Model 6386 cot fastener assembly...........................................................................................................................9
Model 6387 cot fastener assembly.........................................................................................................................10
Model 6388 cot fastener assembly.........................................................................................................................11
Model 6389 cot fastener assembly.........................................................................................................................12
Foot end fastener assembly ...................................................................................................................................13
6385-009-002 Rev A.5 1 EN

WWaarrnniinngg//CCaauuttiioonn//NNoottee DDeeffiinniittiioonn
The words WWAARRNNIINNGG,CCAAUUTTIIOONN, and NNOOTTEE carry special meanings and should be carefully reviewed.
WWAARRNNIINNGG
Alerts the reader about a situation which, if not avoided, could result in death or serious injury. It may also describe
potential serious adverse reactions and safety hazards.
CCAAUUTTIIOONN
Alerts the reader of a potentially hazardous situation which, if not avoided, may result in minor or moderate injury to the
user or patient or damage to the product or other property. This includes special care necessary for the safe and effective
use of the device and the care necessary to avoid damage to a device that may occur as a result of use or misuse.
NNoottee -- Provides special information to make maintenance easier or important instructions clearer.
SSuummmmaarryy ooff ssaaffeettyy pprreeccaauuttiioonnss
Always read and strictly follow the warnings and cautions listed on this page. Service only by qualified personnel.
CCAAUUTTIIOONN
• Improper usage of the product can cause injury to the patient or operator. Operate the product only as described in this
manual.
• Do not modify the product or any components of the product. Modifying the product can cause unpredictable operation
resulting in injury to patient or operator. Modifying the product also voids its warranty.
EN 2 6385-009-002 Rev A.5

IInnttrroodduuccttiioonn
This manual assists you with the operation or maintenance of your Stryker product. Read this manual before operating or
maintaining this product. Set methods and procedures to educate and train your staff on the safe operation or maintenance
of this product.
CCAAUUTTIIOONN
• Improper usage of the product can cause injury to the patient or operator. Operate the product only as described in this
manual.
• Do not modify the product or any components of the product. Modifying the product can cause unpredictable operation
resulting in injury to patient or operator. Modifying the product also voids its warranty.
NNoottee
• This manual is a permanent part of the product and should remain with the product even if the product is sold.
• Stryker continually seeks advancements in product design and quality. This manual contains the most current product
information available at the time of printing. There may be minor discrepancies between your product and this manual. If
you have any questions, contact Stryker Customer Service or Technical Support at 1-800-327-0770.
PPrroodduucctt ddeessccrriippttiioonn
The PPoowweerr--PPRROO™ TL Cot Fastener is designed to hold a compatible ambulance cot in an emergency vehicle for patient
transport purposes. The cot fastener performs this function after the user manually loads the compatible cot into the
emergency vehicle and guides it into the fastener.
IInnddiiccaattiioonnss ffoorr uussee
The Model 6385, 6386, 6387, 6388, and 6389 PPoowweerr--PPRROO TL Cot Fastener System is intended to restrict movement of an
ambulance cot being transported in the patient compartment of an ambulance under normal conditions.
Usage of this product in any other way becomes the complete responsibility of the owner/user. Caution must be used at all
times during placement of the cot into the ambulance. The Model 6550 PPoowweerr--PPRROO TL Cot in combination with a Model
6385, 6386, 6387, 6388, and 6389 PPoowweerr--PPRROO TL Cot Fastener system is designed in accordance to BS EN 1789,
Medical Vehicles and their Equipment - Road Ambulances.
EExxppeecctteedd sseerrvviiccee lliiffee
Cot fasteners have a seven year expected service life under normal use conditions and with appropriate periodic
maintenance.
DDiissppoossaall//rreeccyyccllee
Always follow the current local recommendations and/or regulations governing environmental protection and the risks
associated with recycling or disposing of the equipment at the end of its useful life.
CCoonnttrraaiinnddiiccaattiioonnss
None known.
SSppeecciiffiiccaattiioonnss
Model 6385 - cot fastener floor plate mounting (6385-000-000)
6385-009-002 Rev A.5 3 EN

6386 - cot fastener 255mm floor track mounting (6386-000-000)
6387 - cot fastener 300mm floor track mounting (6387-000-000)
6388 - cot fastener 255mm floor track mounting (6388-000-000)
6389 - cot fastener 300mm floor track mounting (6389-000-000)
Cot compatibility Model 6550 PPoowweerr--PPRROO TL ambulance cot
Certifications BS EN: 1789
EEnnvviirroonnmmeennttaall ccoonnddiittiioonnss OOppeerraattiioonn
Temperature
130 °F
(54 °C)
-30 °F
(-34 °C)
Relative humidity
93%
0%
Atmospheric pressure
1060 hPa
700
PPrroodduucctt iilllluussttrraattiioonn
AB
FFiigguurree 11 –– MMooddeell 66338855 PPoowweerr--PPRROO TTLL CCoott FFaasstteenneerr
NNoottee -- The Cot Fastener System consists of a head end and foot end fastener.
AHead end fastener
B Foot end fastener
EN 4 6385-009-002 Rev A.5

CCoonnttaacctt iinnffoorrmmaattiioonn
Contact Stryker Customer Service or Technical Support at: 1-800-327-0770.
Stryker Medical
3800 E. Centre Avenue
Portage, MI 49002
USA
NNoottee -- The user and/or the patient should report any serious product-related incident to both the manufacturer and the
Competent authority of the European Member State where the user and/or patient is established.
To view your operations or maintenance manual online, see https://techweb.stryker.com/.
Have the serial number (A) of your Stryker product available when calling Stryker Customer Service or Technical Support.
Include the serial number in all written communication.
SSeerriiaall nnuummbbeerr llooccaattiioonn
A
DDaattee ooff mmaannuuffaaccttuurree
The year of manufacture is the first 2 digits of the serial number.
PPrreevveennttiivvee mmaaiinntteennaannccee
FFaasstteenneerr lluubbrriiccaattiioonn
NNoottee
• Tri-Flow™ with Teflon® lubricant may be used to reduce the force required to secure and release the cot, minimize
wear, or if the pedal does not stay down with the cot removed.
• Do not use silicone, WD-40®, or lithium grease. They could harm the moving parts of the cot fastener system.
TToo lluubbrriiccaattee tthhee ffaasstteenneerr::
1. Remove the back fastener cover.
2. Spray Tri-Flow™ with Teflon® lubricant (6082-199-012) onto the area indicated below (A) (Figure 2).
6385-009-002 Rev A.5 5 EN

A
FFiigguurree 22 –– FFaasstteenneerr lluubbrriiccaattiioonn
RReegguullaarr iinnssppeeccttiioonn aanndd aaddjjuussttmmeennttss
The following schedule is a general guide to maintenance. Factors such as weather, terrain, geographical location, and
individual usage will alter the required maintenance schedule. If you are unsure how to perform these checks, contact your
Stryker Service Technician. If you are in doubt as to what intervals to follow in maintaining your product, consult your
Stryker Service Technician. Check each routine and replace worn parts if necessary.
RRoouuttiinnee EEvveerryy
1 month 3 months 6 months 12 months
Cot and cot fastener
fit and function
X
All fasteners are
secure
X
Lubricate the lock
(see
Fastener
lubrication
above)
As needed
MMaaiinntteennaannccee rreeccoorrdd
DDaattee MMaaiinntteennaannccee ooppeerraattiioonn
ppeerrffoorrmmeedd
BByy HHoouurrss
EN 6 6385-009-002 Rev A.5

DDaattee MMaaiinntteennaannccee ooppeerraattiioonn
ppeerrffoorrmmeedd
BByy HHoouurrss
TTrraaiinniinngg rreeccoorrdd
TTrraaiinniinngg ddaattee
TTrraaiinneeee nnaammee BBaassiicc ttrraaiinniinngg RReeffrreesshheerr uuppddaattee OOwwnneerr’’ss mmaannuuaall,, iinn--
sseerrvviiccee,, ffoorrmmaall ccllaassss,, eettcc..
6385-009-002 Rev A.5 7 EN

MMooddeell 66338855 ccoott ffaasstteenneerr aasssseemmbbllyy
6385-001-010 Rev C (Reference only)
IItteemm NNuummbbeerr NNaammee QQuuaannttiittyy
A 0003-109-000 Hex head cap screw 2
B 0003-112-000 Hex head cap screw 7
C 0012-058-001 Lock washer 7
D 6360-030-012 Floor plate, small 7
E 6385-001-012
Foot end fastener assembly (page 13) 1
F 6385-001-013 Antler assembly 1
G 6385-001-080 Back cover 1
H 6385-001-100 Cot fastener specification label 1
J 6385-001-926 6385 tag, serial number 1
K 0025-079-000 Dome head rivet 2
EN 8 6385-009-002 Rev A.5

MMooddeell 66338866 ccoott ffaasstteenneerr aasssseemmbbllyy
6386-001-010 Rev E (Reference only)
Torque items A and D
to 30 ± 5 ft-lb
IItteemm NNuummbbeerr NNaammee QQuuaannttiittyy
A 0001-184-000 Flat head socket screw 7
B 0003-109-000 Hex head cap screw 2
C 0011-014-000 Flat washer 7
D 0016-401-000 Nylock hex nut 7
E 6385-001-012
Foot end fastener assembly (page 13) 1
F 6385-001-013 Antler assembly 1
G 6385-001-080 Back cover 1
H 6386-001-926 6386 tag, serial number 1
J 6385-001-106 Lock down base plate 2
K 6386-001-100 Cot fastener specification label 1
L 0025-079-000 Dome head rivet 2
6385-009-002 Rev A.5 9 EN

MMooddeell 66338877 ccoott ffaasstteenneerr aasssseemmbbllyy
6387-001-010 Rev E (Reference only)
Torque items A and D
to 30 ± 5 ft-lb
IItteemm NNuummbbeerr NNaammee QQuuaannttiittyy
A 0001-184-000 Flat head socket screw 7
B 0003-109-000 Hex head cap screw 2
C 0011-014-000 Flat washer 7
D 0016-401-000 Nylock hex nut 7
E 6385-001-012
Foot end fastener assembly (page 13) 1
F 6385-001-013 Antler assembly 1
G 6385-001-080 Back cover 1
H 6387-001-926 6387 tag, serial number 1
J 6385-001-107 Lock down base plate 2
K 6387-001-100 Cot fastener specification label 1
L 0025-079-000 Dome head rivet 2
EN 10 6385-009-002 Rev A.5

MMooddeell 66338888 ccoott ffaasstteenneerr aasssseemmbbllyy
6388-001-010 Rev B (Reference only)
Torque items A and D
to 30 ± 5 ft-lb
IItteemm NNuummbbeerr NNaammee QQuuaannttiittyy
A 0001-184-000 Flat head socket screw 7
B 0003-109-000 Hex head cap screw 2
C 0011-014-000 Flat washer 7
D 0016-401-000 Nylock hex nut 7
E 6385-001-012
Foot end fastener assembly (page 13) 1
F 6385-001-013 Antler assembly 1
G 6385-001-080 Back cover 1
H 6388-001-100 Cot fastener specification label 1
J 6388-001-106 Lock down base plate 2
K 6388-001-080 Lock down washer (not shown) 8
L 6388-001-926 6388 tag, serial number 1
M 0025-079-000 Dome head rivet 2
6385-009-002 Rev A.5 11 EN

MMooddeell 66338899 ccoott ffaasstteenneerr aasssseemmbbllyy
6389-001-010 Rev B (Reference only)
Torque items A and D
to 30 ± 5 ft-lb
IItteemm NNuummbbeerr NNaammee QQuuaannttiittyy
A 0001-184-000 Flat head socket screw 7
B 0003-109-000 Hex head cap screw 2
C 0011-014-000 Flat washer 7
D 0016-401-000 Nylock hex nut 7
E 6385-001-012
Foot end fastener assembly (page 13) 1
F 6385-001-013 Antler assembly 1
G 6385-001-080 Back cover 1
H 6389-001-100 Cot fastener specification label 1
J 6388-001-107 Lock down base plate 2
K 6389-001-080 Lock down washer (not shown) 8
L 6389-001-926 6389 tag, serial number 1
M 0025-079-000 Dome head rivet 2
EN 12 6385-009-002 Rev A.5

FFoooott eenndd ffaasstteenneerr aasssseemmbbllyy
6385-001-012 Rev AA (Reference only)
6385-009-002 Rev A.5 13 EN

IItteemm NNuummbbeerr NNaammee QQuuaannttiittyy
A 0003-109-000 Hex head cap screw 4
B 0003-113-000 Hex head cap screw 1
C 0003-390-000 Hex head cap screw 4
D 0011-077-000 Washer 4
E 0016-028-000 Fiberlock hex nut 6
F 0025-079-000 Dome head rivet 4
G 638500010015 Spring retaining bracket 1
H 0038-590-000 Extension spring 4
J 0038-591-000 Extension spring 1
K 0055-100-076 Riv nut 2
L
M 6060-090-114 Label, warning 2
N 6385-001-050 Plate, bottom, weldment 1
P
R 6385-001-082 Inside hook 2
T 6385-001-085 Main link 1
U 6385-001-086 Flange bearing 2
V 6385-001-087 Pedal spacer 2
W 6385-001-088 Pedal 1
Y 6385-001-090 Main rod 1
AA 6385-001-091 Rod spacer 1
AB 6385-001-092 Top rod 1
AC 6385-001-093 Bottom slide 1
AD 6385-001-094 Bottom roller 2
EN 14 6385-009-002 Rev A.5

IItteemm NNuummbbeerr NNaammee QQuuaannttiittyy
AE 6385-001-095 Link stop 1
AF 6385-001-097 Slide bushing 2
AG 6385-001-098 Lock pin 1
AH 6385-001-099 Slot cover 2
AJ 6080-090-023 RRUUGGGGEEDD label 1
6385-009-002 Rev A.5 15 EN

Stryker Medical
3800 E. Centre Avenue
Portage, MI 49002
USA
6385-009-002 Rev A.5
WCR: AA.13
2019/09
