SICK InspectorP62 Series User manual

OPERATING INSTRUCTIONS
InspectorP62x
2D machine vision

Described product
InspectorP62x
Manufacturer
SICK AG
Erwin-Sick-Str. 1
79183 Waldkirch
Germany
Legal information
This work is protected by copyright. Any rights derived from the copyright shall be
reserved for SICK AG. Reproduction of this document or parts of this document is
only permissible within the limits of the legal determination of Copyright Law. Any modi‐
fication, abridgment or translation of this document is prohibited without the express
written permission of SICK AG.
The trademarks stated in this document are the property of their respective owner.
© SICK AG. All rights reserved.
Original document
This document is an original document of SICK AG.
25
2O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 8024439/1EJ6/2022-02 | SICK
Subject to change without notice

Contents
1 About this document........................................................................ 5
1.1 Information on the operating instructions.............................................. 5
1.2 Scope......................................................................................................... 5
1.3 Explanation of symbols............................................................................ 5
1.4 Further information................................................................................... 6
2 Safety information............................................................................ 7
2.1 Intended use............................................................................................. 7
2.2 Improper use............................................................................................. 8
2.3 Limitation of liability................................................................................. 8
2.4 Modifications and conversions................................................................ 8
2.5 Cybersecurity............................................................................................ 9
2.6 Requirements for skilled persons and operating personnel.................. 9
2.7 Operational safety and particular hazards.............................................. 10
3 Product description........................................................................... 12
3.1 Scope of delivery....................................................................................... 12
3.2 Product ID.................................................................................................. 12
3.3 Product characteristics............................................................................ 14
3.4 SICK AppSpace......................................................................................... 18
4 Transport and storage....................................................................... 20
4.1 Transport................................................................................................... 20
4.2 Unpacking.................................................................................................. 20
4.3 Transport inspection................................................................................. 20
4.4 Storage...................................................................................................... 20
5 Mounting............................................................................................. 21
5.1 Mounting instructions............................................................................... 21
5.2 Preparation for mounting......................................................................... 21
5.3 Mounting location..................................................................................... 22
5.4 Mounting the device................................................................................. 24
5.5 Mounting an external trigger sensor (optional)...................................... 25
6 Electrical installation........................................................................ 26
6.1 Wiring instructions.................................................................................... 26
6.2 Prerequisites for safe operation of the device........................................ 27
6.3 Note on the swivel connector................................................................... 29
6.4 Connection diagrams............................................................................... 30
6.5 Pin assignments of electrical connections............................................. 31
6.6 Connecting the device.............................................................................. 32
7 Commissioning.................................................................................. 37
7.1 PC Software............................................................................................... 37
7.2 Network communication settings............................................................ 37
CONTENTS
8024439/1EJ6/2022-02 | SICK O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 3
Subject to change without notice

7.3 Default SensorApp: Quality Inspection.................................................... 38
7.4 Installing SensorApps............................................................................... 38
7.5 Programming the device.......................................................................... 39
8 Maintenance...................................................................................... 41
8.1 Maintenance plan..................................................................................... 41
8.2 Cleaning..................................................................................................... 41
9 Troubleshooting................................................................................. 44
9.1 SICK service.............................................................................................. 44
9.2 Repairs...................................................................................................... 44
9.3 Returns...................................................................................................... 44
10 Decommissioning............................................................................. 45
10.1 Disposal..................................................................................................... 45
11 Technical data.................................................................................... 46
11.1 Features.................................................................................................... 46
11.2 Mechanics and electronics...................................................................... 47
11.3 Performance............................................................................................. 47
11.4 Interfaces.................................................................................................. 47
11.5 Ambient data............................................................................................. 48
12 Accessories........................................................................................ 49
13 Annex.................................................................................................. 50
13.1 EU declaration of conformity / Certificates............................................. 50
13.2 Signal assignment of cables with open cable end at one end.............. 50
13.3 Connection diagrams of connection module CDB650-204.................. 52
13.4 Connection diagrams of connection module CDM420-0006............... 59
13.5 Copyright notices...................................................................................... 69
14 Abbreviations used............................................................................ 70
CONTENTS
4O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 8024439/1EJ6/2022-02 | SICK
Subject to change without notice

1 About this document
1.1 Information on the operating instructions
These operating instructions provide important information on how to use devices from
SICK AG.
Prerequisites for safe work are:
•Compliance with all safety notes and handling instructions supplied.
•Compliance with local work safety regulations and general safety regulations for
device applications
The operating instructions are intended to be used by qualified personnel and electrical
specialists.
NOTE
Read these operating instructions carefully before starting any work on the device, in
order to familiarize yourself with the device and its functions.
The instructions constitute an integral part of the product and are to be stored in the
immediate vicinity of the device so they remain accessible to staff at all times. Should
the device be passed on to a third party, these operating instructions should be handed
over with it.
These operating instructions do not provide information on operating the machine
or system in which the device is integrated. For information about this, refer to the
operating instructions of the specific machine.
1.2 Scope
These operating instructions serve to incorporate the device into a customer system.
Instructions are given by stages for all actions required.
These operating instructions apply to all available device types of the product. To obtain
more detailed information on identifying your device type, see "", page 13.
Available device types are listed on the online product page:
•www.sick.com/InspectorP62x
A number of device types are used as examples for commissioning and based on the
default parameter settings for the relevant device.
1.3 Explanation of symbols
Warnings and important information in this document are labeled with symbols. The
warnings are introduced by signal words that indicate the extent of the danger. These
warnings must be observed at all times and care must be taken to avoid accidents,
personal injury, and material damage.
DANGER
… indicates a situation of imminent danger, which will lead to a fatality or serious
injuries if not prevented.
WARNING
… indicates a potentially dangerous situation, which may lead to a fatality or serious
injuries if not prevented.
ABOUT THIS DOCUMENT 1
8024439/1EJ6/2022-02 | SICK O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 5
Subject to change without notice

CAUTION
… indicates a potentially dangerous situation, which may lead to minor/slight injuries if
not prevented.
NOTICE
… indicates a potentially harmful situation, which may lead to material damage if not
prevented.
NOTE
… highlights useful tips and recommendations as well as information for efficient and
trouble-free operation.
1.4 Further information
NOTE
Further documentation for the device can be found on the online product page at:
•www.sick.com/InspectorP62x
There, additional information has been provided depending on the product, such as:
•Model-specific online data sheets for device variants, containing technical data,
dimensional drawing, and specification diagrams
•EU declarations of conformity for the product family
•Dimensional drawings and 3D CAD dimension models in various electronic for‐
mats
•This documentation, in English and German and other languages if applicable
•Other publications related to the devices described here
•Publications dealing with accessories
1 ABOUT THIS DOCUMENT
6O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 8024439/1EJ6/2022-02 | SICK
Subject to change without notice

2 Safety information
2.1 Intended use
The InspectorP6xx is a programmable vision sensor for industrial use for tasks which
require high-resolution images at long distances.
The device is programmed on a PC by using the development environment software
SICK AppSpace. Depending on the application, a browser-based, graphical user inter‐
face (HMI) can be created, which provides opportunities defined by the application
developer to influence an application at operator level. The device offers various inter‐
faces for controlling, programming, and operating purposes, which can be activated
as necessary via development environments, control systems (programmable logic
controllers), or applications. However, configuration, programming, and control requires
various technical skills, depending on how the device is connected and used.
The devices are primarily designed for use in industrial and logistics areas, and they
meet the requirements for industrial ruggedness, interfaces and data processing. They
are not safety components as per the Machinery Directive 2006/42/EC. They are
not intended and not permitted to be used in areas with explosive atmospheres, in
corrosive environments, or in extreme ambient conditions.
2.1.1 Operating restrictions
NOTICE
Radio interference may occur when the device is used in residential areas!
■Only use the device in industrial environments (EN 61000-6-4).
2.1.2 Conditions for specified enclosure rating
To ensure compliance with the specified enclosure rating of the device during opera‐
tion, the following requirements must be met: If these requirements are not met, the
device does not fulfill any specified enclosure rating.
•The cables plugged into the electrical connections must be screwed tight.
•Any electrical connections that are not being used must be sealed with a tightly-
fastened protective cap (as in the delivery condition).
•The foldable cover must be flush with the device and screwed tight.
2.1.3 Cover on the device
NOTICE
Risk of product damage if cover is open!
In open state, the device does not conform to a specified enclosure rating.
If necessary, only operate the device for a short time with an open cover for the
activities listed in the following: During this time, protect the device against moisture
and dust.
Briefly open the cover for the following activities:
•Inserting or removing the optional memory card
For further warranty provisions, see the General Terms and Conditions of SICK AG, e.g.,
on the delivery note of the device.
SAFETY INFORMATION 2
8024439/1EJ6/2022-02 | SICK O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 7
Subject to change without notice

2.2 Improper use
Any use outside of the stated areas, in particular use outside of the technical specifica‐
tions and the requirements for intended use, will be deemed to be incorrect use.
•The device does not constitute a safety component in accordance with the respec‐
tive applicable safety standards for machines.
•The device must not be used in explosion-hazardous areas, in corrosive environ‐
ments or under extreme environmental conditions.
•The device must not be operated in the temperature range below 0 °C.
•Any use of accessories not specifically approved by SICK AG is at your own risk.
WARNING
Danger due to improper use!
Any improper use can result in dangerous situations.
Therefore, observe the following information:
■Device should be used only in accordance with its intended use.
■All information in these operating instructions must be strictly observed.
2.3 Limitation of liability
Applicable standards and regulations, the latest state of technological development,
and our many years of knowledge and experience have all been taken into account
when assembling the data and information contained in these operating instructions.
The manufacturer accepts no liability for damage caused by:
■Failing to observe the operating instructions
■Incorrect use
■Use by untrained personnel
■Unauthorized conversions
■Technical modifications
■Use of unauthorized spare parts, consumables, and accessories
With special variants, where optional extras have been ordered, or owing to the latest
technical changes, the actual scope of delivery may vary from the features and illustra‐
tions shown here.
2.3.1 Programmable product
For programmable products, the respective programmer is responsible for his/her pro‐
gramming performance and the resulting working principle of the product.
The liability and warranty of SICK AG is limited to the product specification (functionality
and any programming interfaces) according to the agreed conditions.
Therefore, SICK AG is not liable, among other things, for damages that are caused by
programming of the customer or third parties.
2.4 Modifications and conversions
NOTICE
Modifications and conversions to the device may result in unforeseeable dangers.
Interrupting or modifying the device or SICK software will invalidate any warranty claims
against SICK AG. This applies in particular to opening the housing, even as part of
mounting and electrical installation.
2 SAFETY INFORMATION
8O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 8024439/1EJ6/2022-02 | SICK
Subject to change without notice

2.5 Cybersecurity
To protect against cybersecurity threats, it is necessary to continuously monitor and
maintain a comprehensive and holistic cybersecurity concept. A suitable concept com‐
prises organizational, technical, procedural, electronic, and physical levels of defense
and provides suitable measures for different types of risks. SICK's products and solu‐
tions must be viewed as a component of this concept.
Information on Cybersecurity can be found at: www.sick.com/psirt .
2.6 Requirements for skilled persons and operating personnel
WARNING
Risk of injury due to insufficient training.
Improper handling of the device may result in considerable personal injury and material
damage.
■All work must only ever be carried out by the stipulated persons.
This product documentation refers to the following qualification requirements for the
various activities associated with the device:
■Instructed personnel have been briefed by the operator about the tasks assigned
to them and about potential dangers arising from improper action.
■Skilled personnel have the specialist training, skills, and experience, as well as
knowledge of the relevant regulations, to be able to perform tasks delegated to
them and to detect and avoid any potential dangers independently.
■Electricians have the specialist training, skills, and experience, as well as knowl‐
edge of the relevant standards and provisions, to be able to carry out work on
electrical systems and to detect and avoid any potential dangers independently.
The electrician must comply with the provisions of the locally applicable work
safety regulation.
The following qualifications are required for various activities:
Table 1: Activities and technical requirements
Activities Qualification
Mounting, maintenance ■Basic practical technical training
■Knowledge of the current safety regulations in the workplace
Electrical installation,
device replacement
■Practical electrical training
■Knowledge of current electrical safety regulations
■Knowledge of the operation and control of the devices in their
particular application
Commissioning, configura‐
tion
■Basic knowledge of the computer operating system used
■Basic knowledge of the design and setup of the described
connections and interfaces
■Basic knowledge of data transmission
■Knowledge of the programming of image-processing systems
and network components
Operation of the device for
the particular application
■Knowledge of the operation and control of the devices in their
particular application
■Knowledge of the software and hardware environment for the
particular application
SAFETY INFORMATION 2
8024439/1EJ6/2022-02 | SICK O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 9
Subject to change without notice

2.7 Operational safety and particular hazards
Please observe the safety notes and the warnings listed here and in other chapters
of this product documentation to reduce the possibility of risks to health and avoid
dangerous situations.
The product is fitted with LEDs in risk group 0. The accessible radiation from these
LEDs does not pose a danger to the eyes or skin.
The product is fitted with LEDs of risk group 0 or 1 for object illumination, depending on
type.
CAUTION
Optical radiation: LED risk group 1, visible radiation, 400 nm to 780 nm
The LEDs may pose a danger to the eyes in the event of incorrect use.
■Do not look into the light source intentionally.
■Do not open the housing. Opening the housing will not switch off the light source.
Opening the housing may increase the level of risk.
■Comply with the current national regulations on photobiological security of lamps
and lamp systems.
If the product is operated in conjunction with external illumination systems, the risks
described here may be exceeded. This must be taken into consideration by users on a
case-by-case basis.
Laser alignment aid
CAUTION
Optical radiation: Class 1 Laser Product
The accessible radiation does not pose a danger when viewed directly for up to 100
seconds. It may pose a danger to the eyes and skin in the event of incorrect use.
■Do not open the housing. Opening the housing may increase the level of risk.
■Current national regulations regarding laser protection must be observed.
For both radiation types:
It is not possible to entirely rule out temporary disorienting optical effects, particularly
in conditions of dim lighting. Disorienting optical effects may come in the form of
dazzle, flash blindness, afterimages, photosensitive epilepsy, or impairment of color
vision, for example.
WARNING
Electrical voltage!
Electrical voltage can cause severe injury or death.
■Work on electrical systems must only be performed by qualified electricians.
■The power supply must be disconnected when attaching and detaching electrical
connections.
■The product must only be connected to a voltage supply as set out in the require‐
ments in the operating instructions.
■National and regional regulations must be complied with.
■Safety requirements relating to work on electrical systems must be complied with.
2 SAFETY INFORMATION
10 O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 8024439/1EJ6/2022-02 | SICK
Subject to change without notice

WARNING
Risk of injury and damage caused by potential equalization currents!
Improper grounding can lead to dangerous equipotential bonding currents, which may
in turn lead to dangerous voltages on metallic surfaces, such as the housing. Electrical
voltage can cause severe injury or death.
■Work on electrical systems must only be performed by qualified electricians.
■Follow the notes in the operating instructions.
■Install the grounding for the product and the system in accordance with national
and regional regulations.
SAFETY INFORMATION 2
8024439/1EJ6/2022-02 | SICK O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 11
Subject to change without notice

3 Product description
3.1 Scope of delivery
The delivery of the device includes the following components:
Table 2: Scope of delivery
No. of
units
Component Remarks
1 Device in the version ordered M12 female connector for Ethernet sealed with
tightly-fastened protective cap
Without bracket and optional connecting cables
2 Sliding nut, 5.5 mm deep, with
M5 threaded fixing hole
Alternative mounting option for the device instead
of the threaded mounting hole
Use in pairs
1 Printed safety notes, multilin‐
gual
Brief information and general safety notes
Quality Inspection SensorApp Pre-installed on the device
Associated components not contained in the delivery:
Table 3: Other components
Component Remarks
SOPAS ET configuration software Available online at:
•www.sick.com/SOPAS_ET
SICK AppStudio software Available online at:
•www.sick.com/SICK_AppStudio
SICK AppManager software Available online at:
•www.sick.com/SICK_AppManager
This documentation, available in English
and German, and in other languages if
necessary
Available online at:
•www.sick.com/InspectorP62x
Accessories
Accessories are only supplied if you order them separately, see "Accessories",
page 49.
3.2 Product ID
3.2.1 Type label
The type label gives information for identification of the device.
3 PRODUCT DESCRIPTION
12 O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 8024439/1EJ6/2022-02 | SICK
Subject to change without notice

5
6
7
1
2
3
4
Figure 1: Structure of the type label
1Type designation according to type code
2Part number
3Serial number
4Supply voltage, power consumption and maximum current consumption
5Certificates and symbols
6MAC address (placeholder)
7Production date
3.2.2 Type code
The devices of the InspectorP621 product family are arranged according to the follow‐
ing type code:
V2D6xyz-abcdefg
V 2 D 6 x y z - a b c d e f g
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Position Description
1 ... 5 Product family
V2D62 InspectorP62x
4 ... 6 Image sensor resolution
1: 1.3 Mpx (1280 px x 1024 px)
7 Function
P: Programmable
8 Generation
2: 2nd generation
9 Image sensor type
M: Monochrome
10 Integrated illumination unit 1) /
aiming laser
S: red left, blue right / aiming
laser
D: left IR 2) , right IR 2) / aiming
laser
11 Parameter set
F: Full Feature Set for variant
InspectorP621
PRODUCT DESCRIPTION 3
8024439/1EJ6/2022-02 | SICK O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 13
Subject to change without notice

Position Description
12 Focal length
B: 9.6 mm
F: 17, 1 mm
G: 17, 1 mm with visible block
filter
13 Connectivity package
B: Ethernet, serial, CAN, I/O,
USB, memory card slot
14 IP Protection class
5: IP 65
1) Front view
2) IR = Infrared light
NOTE
Not all combinations are possible according to the type code. The available device
variants can be found online at:
•www.sick.com/InspectorP62x
3.3 Product characteristics
3.3.1 Device view
NOTICE
Damage to the swivel connector from over-rotation
•The swivel connector may be moved up to a maximum of 180° from end point to
end point. Do not exceed the respective limit position.
•Carry out the rotational movement slowly.
8
6
4
Ready Read Diagn Result TeachIn LED Auto-Setup Data Autofocus LNK TX Userdefined
300 200 100
70
40
100 0
[mm] [%]
2
3
a
ß
7
9
35.6 (1.40)
6(0.24)
10 (0.39)
5
1
26.5
(1.04)
71 (2.80)
17.44
(0.69)
4.8 (0.19)
21.5
(0.85)
26
(1.02)
43 (1.69)
Ø 10
(0.39)
1
á
ã
à
Figure 2: Structure and dimensions, unit: mm (inch), decimal separator: period
14 threaded mounting holes, M5: blind tapped hole; 5 mm deep; max. depth of thread
5 mm
3 PRODUCT DESCRIPTION
14 O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 8024439/1EJ6/2022-02 | SICK
Subject to change without notice

2“Ethernet” connection (female connector, M12, 4-pin, D-coded)
3“Power/Serial Data/CAN/I/O” connection (male connector, M12, 17-pin, A-coded)
42 sliding nuts, M5; 5.5 mm deep; as an alternative method of mounting the device
5Viewing window with four LEDs, integrated illumination unit
6Swivel connector (swivel range 180°)
7Bar graph display
8Beeper (under housing cover)
95 status LEDs (2 levels)
ß2 function keys
àCover (flap) with two fixing screws (TX6 key, captive)
áUSB port (female connector, type Micro-B, 5-pin)
âCard slot for microSD memory card
ãStatus LED, status indicator for the microSD memory card
3.3.1.1 Illumination unit
1
3
2
1
1
1
Figure 3: Illumination unit (integrated illumination unit)
14 LEDs (color: visible red light, visible blue light; position: 2 on the left, 2 on the right)
2Feedback LED (color: visible green light)
3Laser alignment aid (color: visible red light)
NOTE
To avoid being dazzled by the integrated illumination unit, do not look into the viewing
window of the device.
3.3.2 Display and operating elements
Ready
Read Diagn
Result
TeachIn
LED
Auto-Setup
Data
Autofocus
LNK TX
Userdefined
300
200
100
70
40
100
0
[mm] [%]
O
O
O
O
O
Figure 4: LED status displays, bar graph display and function keys on the top of the device
PRODUCT DESCRIPTION 3
8024439/1EJ6/2022-02 | SICK O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 15
Subject to change without notice

Status displays
Display LED API name1Color Status
Ready Steady - green Device is ready
Steady - red Hardware or software
error
Steady - yellow Firmware or SensorApps
are being installed on
the device. Do not dis‐
connect the power to the
device.
Flashing
(about 1 Hz)
- green/yellow Profinet is configured,
but no successful con‐
nection to a PLC is estab‐
lished.
If there are additional
errors related to the Sen‐
sorApp, the LED flashes
with red color.
Result Programmable RESULT_LED red, green, blue,
fuchsia, yellow,
aqua, white
Function defined by user
Light
(LED)
Programmable LIGHT_LED red, green, blue,
fuchsia, yellow,
aqua, white
Function defined by user
Function
(Data)
Programmable FUNCTION_LED red, green, blue,
fuchsia, yellow,
aqua, white
Function defined by user
LNK TX Flashing - green The device is connected
to a network
LED bar
(0..9)
Programmable BAR0_LED
BAR1_LED
BAR2_LED
BAR3_LED
BAR4_LED
BAR5_LED
BAR6_LED
BAR7_LED
BAR8_LED
BAR9_LED
green Function for each LED
defined by user
1For programmable LEDs only
Status display of the microSD memory card
â
ã
Figure 5: Display under flap on rear of device
áUSB interface
âSlot for microSD memory card
ãDisplay for microSD memory card
3 PRODUCT DESCRIPTION
16 O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 8024439/1EJ6/2022-02 | SICK
Subject to change without notice

Table 4: Status display of the microSD memory card
Display LED Color Status
MicroSD Lights up Green The device writes data to the correctly installed memory
card.
Read access to the card is not signaled.
3.3.3 Acoustic status indicator
The beeper (buzzer) is located under the cover on the top of the device, see "Device
view", page 14. The API contains functionality for setting the beep duration, the pitch,
the tone sequence and the volume level.
3.3.4 Memory card
The device has a card slot integrated in the housing. The card slot accommodates a
memory card in microSD format.
NOTE
The microSD memory card is optional and not included in the scope of delivery of the
device. The device supports memory cards up to max. 32 GB.
Only use types (industrial standard) approved by SICK to ensure reliable function of the
memory card. You can find these as accessories online at:
•www.sick.com/InspectorP62x
The memory card has no write protection that can be activated.
Inserting the memory card in the device:
DANGER
Risk of injury due to hot device surface.
The surface of the device can become hot during operation.
•Before performing work on the device (e.g. mounting, cleaning, disassembly),
switch off the device and allow it to cool down.
•Ensure good lost heat transfer from the device.
NOTICE
Risk of damage to the memory card!
bTo avoid damaging the microSD memory card, make sure the device is de-ener‐
gized when you insert or remove the card. For this purpose, disconnect the device
from the supply voltage.
Access to the card slot
The card slot for the memory card is located under the hinged cover on the rear side of
the device.
1. 3.
LNK TX
Userdefined
100
70
40 0
[mm] [%]
LNK TX
Userdefined
100
70
40 0
[mm] [%]
2.
PRODUCT DESCRIPTION 3
8024439/1EJ6/2022-02 | SICK O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 17
Subject to change without notice

1. Switch off the supply voltage to the device.
2. Undo the screws (Torx TX6, captive) on the hinged cover and open the cover as
follows:
°Carefully pull the upper edge of the cover away from the housing a little at the
level of the hinges on the side. Use both of the recesses on the inside of the
cover to do this.
°Fold the cover upwards starting from the bottom edge.
3. Making sure it is in the correct position, insert the memory card into the slot until
it locks into place. When doing this, position the contacts so that they are facing to
the rear and upwards, see the card symbol on the device.
4. Close the hinged cover. Make sure that the cover is completely flush with the
housing.
5. Tighten the screws on the hinged cover again.
6. Switch on the supply voltage for the device.
Removing the memory card from the device:
NOTICE
Risk of damage to the memory card!
bTo avoid damaging the microSD memory card, make sure the device is de-ener‐
gized when you insert or remove the card. For this purpose, disconnect the device
from the supply voltage.
1. Switch off the supply voltage to the device.
2. Undo the screws on the hinged cover.
3. Making sure it is in the correct position, push the memory card into the slot until
it is released. When doing this, position the contacts so that they are facing to the
rear and upwards, see the card symbol on the device.
4. Remove the memory card.
5. Close the hinged cover. Make sure that the cover is completely flush with the
housing.
6. Tighten the screws on the hinged cover.
7. Switch on the supply voltage for the device.
3.4 SICK AppSpace
The InspectorP6xx product family is part of the SICK AppSpace ecosystem, which
consists of software tools and programmable sensors or devices. See figure 6 for an
overview of SICK AppSpace.
Support
Portal
PROGRAMMABLE DEVICES
TOOLS
APP DEVELOPERS
Sensor
AppPool
SensorApps
AM
AppManagerAppStudio
AS
Conference Sensor Integration
Machine
Figure 6: SICK AppSpace
3 PRODUCT DESCRIPTION
18 O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 8024439/1EJ6/2022-02 | SICK
Subject to change without notice

SICK AppSpace includes the following components and resources:
•SICK AppManager: A software tool used for the installation and management of
SensorApps and device firmware updates.
•SICK AppPool: A cloud-based repository for storing and sharing SensorApps. SICK
AppPool can be accessed directly from SICK AppManager, SICK AppStudio, and
from the web.
•SICK AppStudio: A Software Development Kit (SDK) for developing SensorApps
on programmable SICK devices. Its user interface for machine operators can be
created individually as a web GUI.
•The SICK Support Portal (supportportal.sick.com) contains tutorials and instruc‐
tions for programming the InspectorP6xx in SICK AppStudio.
For more information about downloading SensorApps and programming the device, see
"Commissioning", page 37.
For more information about SICK AppSpace, see www.sick.com/SICK_AppSpace.
PRODUCT DESCRIPTION 3
8024439/1EJ6/2022-02 | SICK O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 19
Subject to change without notice

4 Transport and storage
4.1 Transport
For your own safety, please read and observe the following notes:
NOTICE
Damage to the product due to improper transport.
■The device must be packaged for transport with protection against shock and
damp.
■Recommendation: Use the original packaging as it provides the best protection.
■Transport should be performed by trained specialist staff only.
■The utmost care and attention is required at all times during unloading and
transportation on company premises.
■Note the symbols on the packaging.
■Do not remove packaging until immediately before you start mounting.
4.2 Unpacking
•To protect the device against condensation, allow it to equilibrate with the ambient
temperature before unpacking if necessary.
•Handle the device with care and protect it from mechanical damage.
4.3 Transport inspection
Immediately upon receipt in Goods-in, check the delivery for completeness and for any
damage that may have occurred in transit. In the case of transit damage that is visible
externally, proceed as follows:
■Do not accept the delivery or only do so conditionally.
■Note the scope of damage on the transport documents or on the transport compa‐
ny's delivery note.
■File a complaint.
NOTE
Complaints regarding defects should be filed as soon as these are detected. Damage
claims are only valid before the applicable complaint deadlines.
4.4 Storage
Store the device under the following conditions:
■Recommendation: Use the original packaging.
■Electrical connections are provided with protective caps and plugs (as they are on
delivery).
■Do not store outdoors.
■Store in a dry area that is protected from dust.
■So that any residual damp can evaporate, do not package in airtight containers.
■Do not expose to any aggressive substances.
■Protect from sunlight.
■Avoid mechanical shocks.
■Storage temperature: see "Technical data", page 46.
■Relative humidity: see "Technical data", page 46.
■For storage periods of longer than 3 months, check the general condition of all
components and packaging on a regular basis.
4 TRANSPORT AND STORAGE
20 O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 8024439/1EJ6/2022-02 | SICK
Subject to change without notice
