SICK Lector64x Flex User manual

OPERATING INSTRUCTIONS
Lector64x/Lector65x
Image-based code reader

Described product
Lector64x Flex
Lector65x Flex
Lector65x Dynamic Focus
Manufacturer
SICK AG
Erwin-Sick-Str. 1
79183 Waldkirch
Germany
Legal information
This work is protected by copyright. Any rights derived from the copyright shall be
reserved for SICK AG. Reproduction of this document or parts of this document is
only permissible within the limits of the legal determination of Copyright Law. Any modi‐
fication, abridgment or translation of this document is prohibited without the express
written permission of SICK AG.
The trademarks stated in this document are the property of their respective owner.
© SICK AG. All rights reserved.
Original document
This document is an original document of SICK AG.
2O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 8016185/1H7Q /2023-04-27 | SICK
Subject to change without notice

Contents
1 About this document........................................................................ 5
1.1 Information on the operating instructions.............................................. 5
1.2 Explanation of symbols............................................................................ 5
1.3 Related applicable documents................................................................ 6
1.4 Further information................................................................................... 6
2 Safety information............................................................................ 7
2.1 Intended use............................................................................................. 7
2.2 Improper use............................................................................................. 7
2.3 Cybersecurity............................................................................................ 7
2.4 Limitation of liability................................................................................. 8
2.5 Modifications and conversions................................................................ 8
2.6 Requirements for skilled persons and operating personnel.................. 8
2.7 Operational safety and specific hazards................................................. 9
2.8 UL conformity............................................................................................ 10
2.9 Warning labels on the product................................................................. 11
3 Product description........................................................................... 12
3.1 Product variants........................................................................................ 12
3.2 Scope of delivery....................................................................................... 12
3.3 Product ID.................................................................................................. 13
3.4 Product overview....................................................................................... 15
3.5 Integrated illumination unit...................................................................... 16
3.6 Display and control elements.................................................................. 16
4 Transport and storage....................................................................... 19
4.1 Transport................................................................................................... 19
4.2 Unpacking.................................................................................................. 19
4.3 Transport inspection................................................................................. 19
4.4 Storage...................................................................................................... 19
5 Mounting............................................................................................. 20
5.1 Mounting instructions............................................................................... 20
5.2 Mounting location..................................................................................... 20
5.3 Mounting the lens and illumination......................................................... 21
5.4 Assembling the product........................................................................... 23
6 Electrical installation........................................................................ 24
6.1 Wiring instructions.................................................................................... 24
6.2 Prerequisites for safe operation of the device........................................ 25
6.3 Connection principle................................................................................. 28
6.4 Connections and pin assignment............................................................ 28
6.5 Connecting................................................................................................ 31
7 Commissioning.................................................................................. 39
CONTENTS
8016185/1H7Q /2023-04-27 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 3
Subject to change without notice

7.1 Start SOPAS ET......................................................................................... 39
7.2 Configuration with SOPAS ET................................................................... 39
7.3 Configuring the product with operating buttons..................................... 41
7.4 Saving the parameter set......................................................................... 43
7.5 External data back-up............................................................................... 43
7.6 MicroSD memory card.............................................................................. 44
7.7 Inserting and removing memory card..................................................... 45
8 Maintenance...................................................................................... 46
8.1 Maintenance plan..................................................................................... 46
8.2 Cleaning..................................................................................................... 46
9 Troubleshooting................................................................................. 48
9.1 General faults, warnings, and errors....................................................... 48
9.2 System information................................................................................... 48
9.3 Displaying the status log.......................................................................... 48
9.4 Repairs...................................................................................................... 49
9.5 Returns...................................................................................................... 49
9.6 Replacing the product.............................................................................. 49
10 Decommissioning............................................................................. 51
10.1 Disposal..................................................................................................... 51
11 Technical data.................................................................................... 52
11.1 Features.................................................................................................... 52
11.2 Mechanics and Electronics...................................................................... 54
11.3 Dimensional drawing................................................................................ 55
11.4 Performance............................................................................................. 55
11.5 Interfaces.................................................................................................. 56
11.6 Ambient data............................................................................................. 57
11.7 Field of view diagrams.............................................................................. 58
12 Accessories........................................................................................ 61
13 Annex.................................................................................................. 62
13.1 Declarations of conformity and certificates............................................ 62
13.2 Connection diagrams of connection module CDB650-204.................. 62
13.3 Connection diagrams of connection module CDM420-0006............... 75
13.4 Licenses.................................................................................................... 88
CONTENTS
4O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 8016185/1H7Q /2023-04-27 | SICK
Subject to change without notice

1 About this document
1.1 Information on the operating instructions
These operating instructions provide important information on how to use devices from
SICK AG.
Prerequisites for safe work are:
•Compliance with all safety notes and handling instructions supplied.
•Compliance with local work safety regulations and general safety regulations for
device applications
The operating instructions are intended to be used by qualified personnel and electrical
specialists.
NOTE
Read these operating instructions carefully to familiarize yourself with the device and its
functions before commencing any work.
The operating instructions are an integral part of the product. Store the instructions
in the immediate vicinity of the device so they remain accessible to staff at all times.
Should the device be passed on to a third party, these operating instructions should be
handed over with it.
These operating instructions do not provide information on the handling and safe
operation of the machine or system in which the device is integrated. Information on
this can be found in the operating instructions for the machine or system.
1.2 Explanation of symbols
Warnings and important information in this document are labeled with symbols. Sig‐
nal words introduce the instructions and indicate the extent of the hazard. To avoid
accidents, damage, and personal injury, always comply with the instructions and act
carefully.
DANGER
…indicates a situation of imminent danger, which will lead to a fatality or serious
injuries if not prevented.
WARNING
…indicates a potentially dangerous situation, which may lead to a fatality or serious
injuries if not prevented.
CAUTION
…indicates a potentially dangerous situation, which may lead to minor/slight injuries if
not prevented.
NOTICE
…indicates a potentially harmful situation, which may lead to material damage if not
prevented.
NOTE
…highlights useful tips and recommendations as well as information for efficient and
trouble-free operation.
ABOUT THIS DOCUMENT 1
8016185/1H7Q /2023-04-27 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 5
Subject to change without notice

1.3 Related applicable documents
Related applicable documents from SICK
Document Title Part number Source
Technical
information
VI83I-xxxxxxMx illumination
unit
8017270 www.sick.com/8017270
1.4 Further information
More information can be found on the product page.
The call is made via the SICK Product ID: pid.sick.com/{P/N}/{S/N}
{P/N} corresponds to the part number of the product, see type label.
{S/N} corresponds to the serial number of the product, see type label (if indicated).
The following information is available depending on the product:
•Data sheets
•This document in all available language versions
•CAD files and dimensional drawings
•Certificates (e.g., declaration of conformity)
•Other publications
•Software
•Accessories
1 ABOUT THIS DOCUMENT
6O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 8016185/1H7Q /2023-04-27 | SICK
Subject to change without notice

2 Safety information
2.1 Intended use
The Lector64x/Lector65x image-based code reader is an intelligent SICK-4Dpro sensor.
The product is used for automatic, stationary identification and decoding of codes on
moving or stationary objects. The product reads all commonly used 1D codes (barco‐
des, stacked codes) and 2D codes (matrix codes). In read mode, the product transmits
the read results via the host interface to a higher-level computer (e.g., PLC) for further
centralized processing.
Only the VI83I illumination units from SICK intended for integration in this application
can be used as an illumination unit.
The product is designed for use in industrial and logistics areas, and meets the require‐
ments for industrial ruggedness, interfaces and data processing.
Use products with type code V2D6xxx-xxxxxHx only in industrial environments (EN
61000-6-4).
Incorrect use, improper modification, or tampering with the product will invalidate any
warranty offered by SICK AG. Furthermore, SICK AG shall not accept any responsibility
or liability for any resulting damage and consequential damage.
2.2 Improper use
Any use outside of the stated areas, in particular use outside of the technical specifica‐
tions and the requirements for intended use, will be deemed to be incorrect use.
•The device does not constitute a safety component in accordance with the respec‐
tive applicable safety standards for machines.
•The device must not be used in explosion-hazardous areas, in corrosive environ‐
ments or under extreme environmental conditions.
•The device must not be operated in the temperature range below 0°C.
•Any use of accessories not specifically approved by SICK AG is at your own risk.
WARNING
Danger due to improper use!
Any improper use can result in dangerous situations.
Therefore, observe the following information:
■Product should be used only in accordance with its intended use.
■All information in the documentation must be strictly observed.
■Shut down the product immediately in case of damage.
2.3 Cybersecurity
Overview
To protect against cybersecurity threats, it is necessary to continuously monitor and
maintain a comprehensive cybersecurity concept. A suitable concept consists of organi‐
zational, technical, procedural, electronic, and physical levels of defense and considers
suitable measures for different types of risks. The measures implemented in this
product can only support protection against cybersecurity threats if the product is used
as part of such a concept.
SAFETY INFORMATION 2
8016185/1H7Q /2023-04-27 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 7
Subject to change without notice

You will find further information at www.sick.com/psirt, e.g.:
•General information on cybersecurity
•Contact option for reporting vulnerabilities
•Information on known vulnerabilities (security advisories)
2.4 Limitation of liability
Relevant standards and regulations, the latest technological developments, and our
many years of knowledge and experience have all been taken into account when
compiling the data and information contained in these operating instructions. The
manufacturer accepts no liability for damage caused by:
■Non-adherence to the product documentation (e.g., operating instructions)
■Incorrect use
■Use of untrained staff
■Unauthorized conversions or repair
■Technical modifications
■Use of unauthorized spare parts, consumables, and accessories
2.5 Modifications and conversions
NOTICE
Modifications and conversions to the device may result in unforeseeable dangers.
Interrupting or modifying the device or SICK software will invalidate any warranty claims
against SICK AG. This applies in particular to opening the housing, even as part of
mounting and electrical installation.
2.6 Requirements for skilled persons and operating personnel
WARNING
Risk of injury due to insufficient training.
Improper handling of the device may result in considerable personal injury and material
damage.
■All work must only ever be carried out by the stipulated persons.
The following qualifications are required for various activities:
Table 1: Activities and technical requirements
Activities Qualification
Mounting, maintenance ■Basic practical technical training
■Knowledge of the current safety regulations in the workplace
Electrical installation,
device replacement
■Practical electrical training
■Knowledge of current electrical safety regulations
■Knowledge of the operation and control of the devices in their
particular application
Commissioning, configura‐
tion
■Basic knowledge of the computer operating system used
■Basic knowledge of the design and setup of the described
connections and interfaces
■Basic knowledge of data transmission
■Basic knowledge of 1D technology (bar code) or 2D technology
(matrix code)
2 SAFETY INFORMATION
8O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 8016185/1H7Q /2023-04-27 | SICK
Subject to change without notice

Activities Qualification
Operation of the device for
the particular application
■Knowledge of the operation and control of the devices in their
particular application
■Knowledge of the software and hardware environment for the
particular application
2.7 Operational safety and specific hazards
Please observe the safety notes and the warnings listed here and in other sections
of this product documentation to reduce the possibility of risks to health and avoid
dangerous situations.
Danger due to visible radiation is product-specific. See the technical data for more
information.
CAUTION
Optical radiation: LED risk group 1, visible radiation, 400nm to 780nm
The LEDs may pose a danger to the eyes in the event of incorrect use.
■Do not look into the light source intentionally.
■Do not open the housing. Opening the housing will not switch off the light source.
Opening the housing may increase the level of risk.
■Comply with the current national regulations on photobiological security of lamps
and lamp systems.
CAUTION
Warning! Optical radiation: LED risk group 2, visible radiation, 400nm to 780nm
Potentially dangerous optical radiation. Can be damaging to the eyes.
■Do not look into the light source for extended periods of time.
■Never point the light source at people.
■Avoid any reflections on people from reflective surfaces. Be particularly careful
during mounting and alignment work.
■Do not open the housing. Opening the housing will not switch off the light source.
Opening the housing may increase the level of risk.
■Comply with the current national regulations on photobiological security of lamps
and lamp systems.
If the product is operated in conjunction with external illumination units, the risks
described here may be exceeded. This must be taken into consideration by users on a
case-by-case basis.
CAUTION
Optical radiation: Class 1 Laser Product
The accessible radiation does not pose a danger when viewed directly for up to 100
seconds. It may pose a danger to the eyes and skin in the event of incorrect use.
■Do not open the housing. Opening the housing may increase the level of risk.
■Current national regulations regarding laser protection must be observed.
Caution – Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
For both radiation types:
SAFETY INFORMATION 2
8016185/1H7Q /2023-04-27 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 9
Subject to change without notice

It is not possible to entirely rule out temporary disorienting optical effects, particularly
in conditions of dim lighting. Disorienting optical effects may come in the form of
dazzle, flash blindness, afterimages, photosensitive epilepsy, or impairment of color
vision, for example.
CAUTION
Risk of injury due to hot device surface.
The surface of the device can become hot.
•Before performing work on the device (e.g. mounting, cleaning, disassembly),
switch off the device and allow it to cool down.
•Ensure good dissipation of excess heat from the device to the surroundings.
WARNING
Electrical voltage!
Electrical voltage can cause severe injury or death.
■Work on electrical systems must only be performed by qualified electricians.
■The power supply must be disconnected when attaching and detaching electrical
connections.
■The product must only be connected to a voltage supply as set out in the require‐
ments in the operating instructions.
■National and regional regulations must be complied with.
■Safety requirements relating to work on electrical systems must be complied with.
WARNING
Risk of injury and damage caused by potential equalization currents!
Improper grounding can lead to dangerous equipotential bonding currents, which may
in turn lead to dangerous voltages on metallic surfaces, such as the housing. Electrical
voltage can cause severe injury or death.
■Work on electrical systems must only be performed by qualified electricians.
■Follow the notes in the operating instructions.
■Install the grounding for the product and the system in accordance with national
and regional regulations.
2.8 UL conformity
The UL certification is dependent on the type. Any existing UL certification can be found
on the type label.
NFPA79 applications only. Adapters including field wiring cables are available.
More information can be found on the product page:
The call is made via the SICK Product ID: pid.sick.com/{P/N}/{S/N}
{P/N} corresponds to the part number of the product, see type label.
{S/N} corresponds to the serial number of the product, see type label (if indicated).
2 SAFETY INFORMATION
10 O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 8016185/1H7Q /2023-04-27 | SICK
Subject to change without notice

2.9 Warning labels on the product
Products and illumination units with LEDs in risk group RG2 are provided with the
following warning label.
Figure 1: Risk Group 2: CAUTION - Possibly hazardous optical radiation emitted from this product.
Do not look into the lamp during operation. This could damage your eyes. IEC 62471:2006-07;
EN62471:2008-09
For the products, the label is located on the exterior of the housing. For the illumination
units, the warning label is located on the outer ring.
The mounted optics protection hood covers the warning label on the illumination unit.
The integrated illumination unit types in risk group RG2 therefore contain an additional
warning label for risk group RG2.
Apply the additional warning label on the outside of the optics protection hood in a well
visible location near the light emission. If the device itself is, for example, integrated
into a machine in such a way that the attached warning label is obscured, attach
further clearly visible labels to the machine close to where the light is emitted.
SAFETY INFORMATION 2
8016185/1H7Q /2023-04-27 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 11
Subject to change without notice

3 Product description
3.1 Product variants
Flex product variant
The Flex product variant is a camera housing with a C-mount thread. The product
can be assembled from individual components to suit the particular application. The
individual components can be ordered separately as accessories. Only certain lenses
and illumination units are compatible depending on the product type. Use only products
from SICK.
Dynamic Focus product variant
The Dynamic Focus product variant is a complete device. The product is already equip‐
ped with a pre-assembled lens and a pre-assembled integrated illumination unit.
3.2 Scope of delivery
Product
Table 2: Scope of delivery of the product
No. of
units
Component Remarks
1 Product in the ordered type
(complete device or basic
device)
Complete device:
•Components are assembled at the factory (cam‐
era housing and optics accessories).
•Optics protection hood is provided with a seal.
Basic device:
•Mount camera housing with C-mount threaded
connection and individual componentson your
own.
•Order individual components separately as
accessories.
•Light inlet is sealed with a protective cap.
All products:
•Electrical connections are sealed with protective
caps.
•Without holders and connecting cables
2 Sliding nut, 5.5mm deep, with
M5 threaded fixing hole
•Alternative mounting option for the product
instead of the threaded mounting hole
•Use in pairs.
1 Hexagon key WAF2 •Basic device: mount integratable VI83I illumina‐
tion.
•Open and close foldable cover (access to the
microSD card slot).
1 or 2 LED warning label RG2 (self-
adhesive)
•Complete device: 1 LED warning label (French)
for integrated RG2 ring illumination unit
included with delivery of the product.
•Basic device: 2 LED warning labels in English
and French included in the scope of delivery
of the separately-ordered integratable ring illu‐
mination unit RG2.
1 Laser warning label (self-adhe‐
sive)
Basic device: laser warning label (French) for the
laser output aperture in the camera housing
1 SICK lens cloth Basic device: clean optical surfaces (e.g. front
screen in the optics protection hood).
3 PRODUCT DESCRIPTION
12 O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 8016185/1H7Q /2023-04-27 | SICK
Subject to change without notice

No. of
units
Component Remarks
1 Printed safety notes, multilin‐
gual
Brief information and general safety notes
The actual scope of delivery may differ for special designs, additional orders or due to
the latest technical changes.
Optic kit
The optic kit is an optional accessory that can be ordered for the basic unit (Flex
product variant).
Table 3: Optic kit scope of delivery
No. of
units
Component Note
1 Lens Application-specific
1 Integratable illumination unit
(VI83I ring illumination unit)
Application-specific
Luminous field appropriate for focal distance of
lens
2 Spacer One with a plated-through connection for the electri‐
cal connection
4 M2, 5 x 6mm Hexagon cylinder head, size2
4 M2, 5 x 12mm Hexagon cylinder head, size2
1 Protective cover for optics IP65
With screw thread and viewing window
3.3 Product ID
3.3.1 Type label
The type label contains information for identifying the product.
The UL certification is dependent on the type. Any existing UL certification can be found
on the type label. The corresponding UL logo is then printed on the label.
DE 79276
-Reute
Made in Germany
V2D654R-MEWHA6
P/N: 1060893
2201 0001
S/N:
DC 24V
00:06:77:05:2E:11
00:06:77:05:2E:11
Manufactured: January 2022
MAC P1
MAC P3
±20% 20W Imax=2.0A
Exchange
1
2
3
3
3
45
6
7
1Part number
2Type designation according to type code
3Conformity mark and certification mark
4Serial number
5Supply voltage, power consumption, current consumption
6MAC addresses
7Date of manufacture
PRODUCT DESCRIPTION 3
8016185/1H7Q /2023-04-27 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 13
Subject to change without notice

3.3.2 Type code
Type code structure
V2D a b c d – e f g h i j k
Position Description Characteristic
a Product family 6: series 6xx
b Platform, housing 4: Advanced Line small
5: Advanced Line
c Resolution of the image sensor 2: 2megapixels (2048px x 1088px)
•Lector642: 1.7megapixel (1,600px x
1,088px)
•Lector652: 2.1megapixel (2,048px x
1,088px)
4: 4.2 megapixels (2,048px x2,048px)
d Function R: Read, standard decoder (1D, 2D)
D: Read, standard decoder (1D, 2D), DPM
decoder, OCR decoder
e generation “Empty”: 1. Generation
f Image sensor type, color M: Monochrome (black-and-white)
g Optics/Focusing system C: C-mount thread
E: Electrical focus (dynamic, auto, teach-
auto)
h Color of the illumination
Possible aperture angle: narrow,
wide, medium
X: without illumination unit
R: Red/Amber
W: White
B: Blue
i Focal distance (lens unit) X: No lens installed
H: 54mm
K: 40mm
j Connection variant1) A: USB; CAN, serial, IO; Enet 1; Enet 2
(connection variant 1, stand-alone solu‐
tion)
F: CAN IN, IO; CAN OUT, IO; Enet 1; Enet 2;
illumination unit (connection variant 2, for
system)
H: USB; CAN, serial, IO; Enet 1; Enet
2:Fieldbus IN - PROFINET; Enet 3:Fieldbus
OUT - PROFINET (connection variant 3,
with Dual Port PROFINET)
k IP protection class and viewing win‐
dow
5: IP65, plastic viewing window
6: IP65, glass viewing window
1) see "Connections and pin assignment", page 28
3 PRODUCT DESCRIPTION
14 O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 8016185/1H7Q /2023-04-27 | SICK
Subject to change without notice

3.4 Product overview
Product overview
6
8
7
12
3
4
5
æ
ã
áâ
ä
à
9
ß
1Connection P1, function and design dependent on type
2Connection P3, function and design dependent on type
3Connection X2, function and design dependent on type
4Connection P2, function and design dependent on type
5Connection X1, function and design dependent on type
6Reference point for working distance from product to object
7Protective cover for optics
8Cover at the rear of the device, access to the microSD memory card
94 threaded mounting holes, M5: blind tapped hole; 5.5mm deep; max. depth of thread
5mm
ß
àFeedback LED: visible green light
áVI83I illumination unit (11 LEDs)
âLens
ãOutlet opening for light beam from laser alignment aid
ä10bar graph LEDs
å2 function keys
æ10 status LEDs (2 levels)
Further topics
•Dimensional drawing
PRODUCT DESCRIPTION 3
8016185/1H7Q /2023-04-27 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 15
Subject to change without notice

3.5 Integrated illumination unit
Overview
The Dynamic Focus product variant has an integrated illumination unit. With the Flex
product variant, the illumination unit can be ordered separately and mounted on its
own.
1
1
1
3
1
1
2
Figure 2: VI83I illumination unit
1Illumination unit = 11 LEDs
21 feedback-LED (color: visible green light, e.g. for Good Read)
31 opening for the laser alignment aids for aligning the product (color: visible red light)
Feedback LED
The function of the feedback LED can be set using SOPASET. With the default settings,
for example, the green feedback LED briefly produces a green feedback spot within the
field of view of the product after a successful read.
Laser alignment aid
The laser alignment aid produces a red spot (laser spot) in the field of view of the
product. The alignment aid can be switched off.
3.6 Display and control elements
Overview
0% 100%
Ready Result FB|ERR|MS
|Tst |Tch |Usr |A-S
SF|RUN|NS L/A P1 FB L/A P2 FB L/A P1 GbE L/A P3 GbE Funct Light
2 3
1 4
Figure 3: Status LEDs, bar graph and function keys
1Status LEDs
2Return pushbutton
3Arrow pushbutton
4Bar graph display
Status indicators on the first display level
Display LED Color Status
Ready OGreen Product is ready for operation
ORed Hardware or software error
Result OGreen Read is successful
ORed Read is unsuccessful
Light OGreen Operation: Illumination on, internal trigger active
O = illuminated; Ö = flashing
3 PRODUCT DESCRIPTION
16 O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 8016185/1H7Q /2023-04-27 | SICK
Subject to change without notice

PROFINET operation (single port)
The Ready status LED signals the product status in the PROFINET network.
Table 4: LEDs in PROFINET operation (single port)
Ready LED Product status Remarks
Green com‐
ponents
Red compo‐
nents
OoThe product is ready for
operation.
OÖ
Flashes
every 7sec‐
onds.
Network detection in the
product is active.
The duration of network detection
can be configured in SOPAS ET
(default: 3minutes).
OÖ
Flashes
every
0.5seconds.
PROFINET is activated in
the product. The product is
not connected to the PRO‐
FINET IO controller (PLC) or
the product is not config‐
ured.
To not use PROFINET, deactivate
PROFINET.
In the default configuration of the
product, automatic PROFINET net‐
work detection is activated. This
detects during startup whether the
product is in a PROFINET environ‐
ment and activates PROFINET auto‐
matically.
To prevent this, deactivate PROFINET
network detection or set the product
name or IP address different from
the default.
To apply the changed settings, per‐
manently save the changes and
restart the product.
ÖÖThe flashing function is acti‐
vated via the configuration
software.
The red and green components of
the LED flash alternately.
Prerequisite: PROFINET is activated
in the product.
O = lights up; Ö = flashes; o = does not light up
Status indicators on the second display level
Display LED Color Status
Tst (Test) OBlue Test (reading diagnostics) selected
ÖBlue Test started
Tch
(Teach-in)
OBlue Teach-in selected (default: Match code)
ÖBlue Teach-in started
OGreen Teach-in successful
ORed Teach-in unsuccessful
Match code default setting: unable to teach in code
A-S (Auto-
Setup)
OBlue Set-up selected
ÖBlue Set-up started
OGreen Set-up successfully quit
OYellow Set-up partially successful, in at least one of the 3param‐
eter modules
ORed Setup unsuccessful
PRODUCT DESCRIPTION 3
8016185/1H7Q /2023-04-27 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 17
Subject to change without notice

Display LED Color Status
Usr (User) OGreen Function can be defined by user
OYellow Function can be defined by user
OBlue Function can be defined by user
ORed Function can be defined by user
O = illuminated; Ö = flashing
Functions
Table 5: Function overview
Function Description
Test (read diagnostics) Percentage analysis: The product records a series of images and uses
the current reading performance settings to decode them. With the
0 ... 100% bar graph, the product shows the read rate of the last 10%
(90% to 100%).
The bar graph display is activated in standard read mode.
Teach Teaching in a match code: the product reads the code that is presented
and saves the code permanently as a target code for future code
comparisons during read mode. For Pharmacodes, the Code type & code
length function must first be defined in SOPAS ET.
Auto-Setup The product adjusts itself automatically to suit the lighting conditions,
working distance 1), and quality of the code presented. The product
permanently stores the acquired values as per the default setting.
1) Only applies for Dynamic Focus.
3 PRODUCT DESCRIPTION
18 O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 8016185/1H7Q /2023-04-27 | SICK
Subject to change without notice

4 Transport and storage
4.1 Transport
NOTICE
Damage due to improper transport!
■The product must be packaged with protection against shock and damp.
■Recommendation: Use the original packaging.
■Note the symbols on the packaging.
■Do not remove packaging until immediately before you start mounting.
4.2 Unpacking
•To protect the device against condensation, allow it to equilibrate with the ambient
temperature before unpacking if necessary.
•Handle the device with care and protect it from mechanical damage.
•To avoid ingress of dust and water, only remove the protective elements, e.g.
protective caps of the electrical connections just before attaching the connecting
cable.
4.3 Transport inspection
Immediately upon receipt in Goods-in, check the delivery for completeness and for any
damage that may have occurred in transit. In the case of transit damage that is visible
externally, proceed as follows:
•Do not accept the delivery or only do so conditionally.
•Note the scope of damage on the transport documents or on the transport compa‐
ny's delivery note.
•File a complaint.
NOTE
Complaints regarding defects should be filed as soon as these are detected. Damage
claims are only valid before the applicable complaint deadlines.
4.4 Storage
•Electrical connections are provided with a protective cap.
•Do not store outdoors.
•Store in a place protected from moisture and dust.
•Recommendation: Use the original packaging.
•To allow any residual dampness to evaporate, do not package in airtight contain‐
ers.
•Do not expose to any aggressive substances.
•Protect from sunlight.
•Avoid mechanical shocks.
•Storage temperature: see "Technical data", page 52.
•Relative humidity: see "Technical data", page 52.
•For storage periods of longer than 3months, check the general condition of all
components and packaging on a regular basis.
TRANSPORT AND STORAGE 4
8016185/1H7Q /2023-04-27 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 19
Subject to change without notice

5 Mounting
5.1 Mounting instructions
•Observe the technical data.
•Protect the sensor from direct and indirect sunlight.
•To prevent condensation, avoid exposing the device to rapid changes in tempera‐
ture.
•The mounting site has to be designed for the weight of the device.
•Mount the product in a shock and vibration insulated manner.
•In application areas with severe vibrations or shocks caused by vibrations, jolts
or abrupt changes in directions (e.g., when mounted to a manned forklift truck),
mounting with vibration dampers is to be carried out. Mount the device in a freely
suspended manner.
•Ensure a good dissipation of excess heat from the device to the surroundings, in
particular at higher ambient temperatures. Good heat transfer from the device can
be achieved, for example, by using a bracket on the mounting base or by ensuring
that the back of the device is located at a sufficient distance from the wall of an
enclosure.
•Make sure the device has a clear view of the codes of the objects to be scanned.
5.2 Mounting location
5.2.1 Work area
Working range
Depending on the product type, the working range is between 50mm and 2,200mm.
Working distance and field of view size
The field of view size is determined by the focus position, the focal length of the lens,
and the working distance. The necessary working distance can be determined from the
field of view diagram, see "Field of view diagrams", page 58.
Focus setting
•Dynamic Focus product variant: You can use the Auto Setup function to automati‐
cally set the focus position to the working distance.
•Flex product variant: The focus position can be adjusted manually on the lens.
The focus position is valid for one working distance. The product does not perform auto‐
matic tracking (auto focus) if, for example, the working distance changes significantly.
5.2.2 Mounting angle and reflection prevention
In order to avoid reflections from the surfaces to be scanned, mount the product so
that it is tilted from the perpendicular to the surface.
5 MOUNTING
20 O P E R A T I N G I N S T R U C T I O N S | Lector64x/Lector65x 8016185/1H7Q /2023-04-27 | SICK
Subject to change without notice
