SCALANCE W788C-2
___________________
___________________
___________________
___________________
___________________
___________________
___________________
SIMATIC NET
Industrial Wireless LAN
SCALANCE W788C-2
Operating Instructions
11/2014
A5E03692120
-07
Information on the Internet
1
Introduction
2
Description
3
Mounting
4
Connection
5
Technical data
6
Approvals
7

Siemens AG
Division Process Industries and Drives
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E03692120-07
Ⓟ
11/2014 Subject to change
Copyright © Siemens AG 2011 - 2014.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SCALANCE W788C-2
Operating Instructions, 11/2014, A5E03692120-07 3
Table of contents
1 Information on the Internet ...................................................................................................................... 5
2 Introduction............................................................................................................................................. 7
2.1 Information on the Operating Instructions ................................................................................7
2.2 Structure of the type designations ............................................................................................8
3 Description.............................................................................................................................................. 9
3.1 Components of the product ......................................................................................................9
3.2 Description of the device ........................................................................................................10
3.3 LED display.............................................................................................................................12
4 Mounting............................................................................................................................................... 13
4.1 Securing the housing ..............................................................................................................14
4.2 Wall mounting .........................................................................................................................15
4.3 Installing on the S7-300 standard rail .....................................................................................16
4.4 Installing on a DIN rail.............................................................................................................17
5 Connection ........................................................................................................................................... 19
5.1 Lightning protection, power supply and grounding .................................................................19
5.2 Power supply and Ethernet.....................................................................................................22
5.3 Antenna connectors ................................................................................................................23
5.4 Suitable antenna cables and antennas...................................................................................24
6 Technical data ...................................................................................................................................... 27
6.1 Dimension drawings................................................................................................................30
7 Approvals.............................................................................................................................................. 33
Index..................................................................................................................................................... 35

Table of contents
SCALANCE W788C-2
4Operating Instructions, 11/2014, A5E03692120-07

SCALANCE W788C-2
Operating Instructions, 11/2014, A5E03692120-07 5
Information on the Internet
1
Bitte beachten Sie die Warnhinweise und zusätzlichen Informationen in der
Kompaktbetriebsanleitung in Ihrer Sprache im Internet:
http://support.automation.siemens.com/ww/view/at/10806097
http://support.automation.siemens.com/ww/view/ch/10806097
http://support.automation.siemens.com/ww/view/de/10806097
http://support.automation.siemens.com/ww/view/li/10806097
http://support.automation.siemens.com/ww/view/lu/10806097
Please observe the warnings and additional information in the compact operating
instructions in your language in the Internet:
http://support.automation.siemens.com/ww/view/au/10806097
http://support.automation.siemens.com/ww/view/ca/10806097
http://support.automation.siemens.com/ww/view/gb/10806097
http://support.automation.siemens.com/ww/view/ie/10806097
http://support.automation.siemens.com/ww/view/us/10806097
http://support.automation.siemens.com/ww/view/za/10806097
Veuillez tenir compte des avertissements et informations supplémentaires de la notice de
service dans votre langue sur Internet:
http://support.automation.siemens.com/ww/view/be/10806097
http://support.automation.siemens.com/ww/view/ch/10806097
http://support.automation.siemens.com/ww/view/fr/10806097
http://support.automation.siemens.com/ww/view/lu/10806097
Si prega di tenere conto delle avvertenze e ulteriori informazioni nell’istruzione operativa
compatta nella relativa lingua in Internet:
http://support.automation.siemens.com/ww/view/it/10806097
Se ruega tener en cuenta las advertencias y las informaciones complementarias contenidas
en las instrucciones de servicio (resumen) en español en Internet:
http://support.automation.siemens.com/ww/view/cl/10806097
http://support.automation.siemens.com/ww/view/es/10806097
Dbejte prosím na výstražné pokyny a doplňkové informace v kompaktním návodu k obsluze
ve vašem jazyce na internetu:
http://support.automation.siemens.com/ww/view/cz/10806097
Vær venligst opmærksom på de advarselsanvisninger og ekstra informationer der findes på
dit sprog i kompaktdriftsvejledningen på internettet:
http://support.automation.siemens.com/ww/view/dk/10806097
Noudata lyhyen käyttöoppaan sisältämiä varoituksia ja huomio sen muutkin tiedot. Oman
kielisesi käyttöoppaan löydät internetistä osoitteesta:
http://support.automation.siemens.com/ww/view/fi/10806097
Λάβετε υπόψη τις υποδείξεις προειδοποίησης και τις πρόσθετες πληροφορίες των
συνοπτικών οδηγιών χρήσης που παρέχονται στη γλώσσα σας στο Διαδίκτυο:
http://support.automation.siemens.com/ww/view/gr/10806097

Information on the Internet
SCALANCE W788C-2
6Operating Instructions, 11/2014, A5E03692120-07
请注意互联网上精编版操作说明相应语言版本中的警告提示和附加信息：
http://support.automation.siemens.com/ww/view/cn/10806097
http://support.automation.siemens.com/ww/view/hk/10806097
http://support.automation.siemens.com/ww/view/sg/10806097
Kérjük, vegye figyelembe az interneten található, az Ön anyanyelvén íródott kompakt
használati útmutatóban található figyelmeztetéseket és további információkat:
http://support.automation.siemens.com/ww/view/hu/10806097
Skoðið vel viðvaranir og aðrar upplýsingar í notkunarleiðbeiningunum á ykkar tungumáli á
internetinu:
http://support.automation.siemens.com/ww/view/is/10806097
インターネットサイトにある各言語の注意事項および追加情報を参照してください:
http://support.automation.siemens.com/ww/view/jp/10806097
사이트에 있는 귀하의 언어로 된콤팩트 사용 설명서에 명시된 경고 지침 및추가 정보를
준수하십시오:
http://support.automation.siemens.com/ww/view/kr/10806097
http://support.automation.siemens.com/ww/view/kw/10806097
Neem goed nota van de waarschuwingen en extra informatie in de compacte
gebruiksaanwijzing in uw taal op internet:
http://support.automation.siemens.com/ww/view/be/10806097
http://support.automation.siemens.com/ww/view/nl/10806097
Vennligst følg advarslene og annen informasjon i den kompakte bruksanvisningen, som du
finner på ditt språk på internett:
http://support.automation.siemens.com/ww/view/no/10806097
Proszęzwrócićuwagęna ostrzeżenia oraz dodatkowe informacje w kompaktowej instrukcji
obsługi, dostępnej w odpowiednim języku w internecie:
http://support.automation.siemens.com/ww/view/po/10806097
Observera varningshänvisningarna och extrainformationerna i kompaktbruksanvisningen
som finns på ditt språk på internet:
http://support.automation.siemens.com/ww/view/se/10806097
İnternette kendi dilinizdeki kompakt işletim kılavuzunda yer alan uyarınotlarına ve ek
bilgilere lütfen dikkat edin:
http://support.automation.siemens.com/ww/view/tr/10806097

SCALANCE W788C-2
Operating Instructions, 11/2014, A5E03692120-07 7
Introduction
2
2.1
Information on the Operating Instructions
Validity of the Operating Instructions
These operating instructions cover the following products:
Product
Article number
SCALANCE W788C-2 RJ-45
6GK5 788-2FC00-1AA0
SCALANCE W788C-2 M12
6GK5 788-2GD00-1AA0
SCALANCE W788C-2 M12 EEC 6GK5788-2GD00-1TA0
If information relates to all the named products, the term SCALANCE W7x8 will be used.
These operating instructions apply to the following software version:
●SCALANCE W7x8C with firmware as of version 8.31
Purpose of the Operating Instructions
Using the Operating Instructions, you will be able to install and connect the SCALANCE
W7x8 correctly. The configuration and the integration of the device in a WLAN are not
described in these instructions.
Documentation on the accompanying CD
You will find introductory information about configuration in the document "Getting Started
SCALANCE WLC711" on the accompanying SIMATIC NET IWLAN CD under the file name:
GS_SCALANCE-WLC711_76 pdf
Note
Detection of the W788C-2 M12 EEC devices
When the W788C
-2 M12 EEC devices are detected by the configuration software of the
WLC 711, they are shown as W788C
-2 M12.
Note
Make sure that you read the explanations and instructions in the README.txt file

Introduction
2.2 Structure of the type designations
SCALANCE W788C-2
8Operating Instructions, 11/2014, A5E03692120-07
2.2
Structure of the type designations
The type designation of a SCALANCE W7x8 is made up of several parts that have the
following meaning:

SCALANCE W788C-2
Operating Instructions, 11/2014, A5E03692120-07 9
Description
3
3.1
Components of the product
The following components are supplied with the product:
●SCALANCE W7x8
●2 protective caps for the M12 sockets (only with device variant M12 / IP65)
●1 connector for the supply voltage (only with device variant RJ-45 / IP30)
●1 connector for the digital input/output (only with device variant RJ-45 / IP30)
●2 screws for mounting on an S7-300 standard rail
●SIMATIC NET Industrial Wireless LAN CD
Please check that the consignment you have received is complete. If the consignment is
incomplete, contact your supplier or your local Siemens office.
Note
The bracket for installation on a DIN rail does not ship with the product. You obtain a set of 3
under the following order number: 6GK5
798-8ML00-0AB3.

Description
3.2 Description of the device
SCALANCE W788C-2
10 Operating Instructions, 11/2014, A5E03692120-07
3.2
Description of the device
W7x8x-x RJ-45 - degree of protection IP30
①
LEDs
②
Connecting connectors, R-SMA type female
•Devices with one IWLAN interface: 3 connectors on the top (covered in the figure).
•Devices with two IWLAN interfaces: 3 connectors on the top and 3 on the underside.
③
Connector for power supply
④
Connector for Ethernet, RJ-45 type
⑤
Screw-down cover for the
- reset button and the
- PLUG compartment (not with W788C)
⑥
Connector for the digital input/output (not with W788C)
⑦
PLUG compartment (not with W788C)
⑧
Reset button
Figure 3-1 Device description of the RJ-45 variant

Description
3.2 Description of the device
SCALANCE W788C-2
Operating Instructions, 11/2014, A5E03692120-07 11
W7x8x-x M12 - degree of protection IP65
①
Connecting connectors, N-Connect type female
•Devices with one IWLAN interface: 3 connectors on the top (covered in the figure).
•Devices with two IWLAN interfaces: 3 connectors on the top and 3 on the underside.
②
LEDs
③
Connector for the supply voltage, type M12 (with cover)
④
Connector for Ethernet, M12 type (with cover)
⑤
Screw-down cover for the
- reset button and the
- PLUG compartment (not with W788C)
⑥
PLUG compartment (not with W788C)
⑦
Reset button (covered in the figure)
Figure 3-2 Device description of the M12 variant

Description
3.3 LED display
SCALANCE W788C-2
12 Operating Instructions, 11/2014, A5E03692120-07
3.3
LED display
Information on operating status and data transfer
On the front of the housing, several LEDs provide information on the operating status of the
SCALANCE W7x8:
LEDs with RJ-45 variants
LEDs with M12 variants
LED display of the SCALANCE W788C-2. You will find information on the significance of the
individual elements in the documentation for the WLC700.

SCALANCE W788C-2
Operating Instructions, 11/2014, A5E03692120-07 13
Mounting
4
CAUTION
Minimum distance to antennas
Fit the device so that there is a minimum clearance of 20 cm between antennas and
persons.
WARNING
If a device is operated in an ambient temperature of more than 50 °C, the temperature of
the device housing may be higher than 70 °C. The device must therefore be installed so
that it is only accessible to service personnel or users that are aware of the reason for
restricted access and the required safety measures at an ambient temperature higher than
50 °C.
WARNING
When used in hazardous environments corresponding to Class I, Division 2 or Class I,
Zone 2, the device must be installed in a cabinet or a suitable enclosure.
General notes on use according to ATEX and IECEx
WARNING
To comply with EC Directive 94/9 (ATEX95) or the conditions of IECEx, this enclosure or
cabinet must meet the requirements of at least IP54 in compliance with EN 60529.

Mounting
4.1 Securing the housing
SCALANCE W788C-2
14 Operating Instructions, 11/2014, A5E03692120-07
4.1
Securing the housing
Grounding terminal
WARNING
Operation of the W7x8 only with connected ground cable
To operate the SCALANCE W7x8 safely, the housing must make contact with a chassis
ground cable. Do not use the W7x8 without a ground cable connected.
The chassis ground cable is fixed with a screw. On the rear of the device there is an M4
threaded hole for this purpose.
Installation options
To install the W7x8, you have the following options:
●Wall mounting
●Installing on the S7-300 standard rail
●Installing on a DIN rail
CAUTION
Danger of injury by falling objects
If the SCALANCE W7x8 is subjected to strong vibration (> 10 g), mounting on a 35 mm DIN
rail does not provide adequate support. Under such conditions, the device can come out of
the mounting and may cause injury.
In this case, install the device on an S7-300 standard rail or on a wall.
Strain relief for the cables
Regardless of the type of installation, make sure that there is suitable strain relief for the
connecting cable.
Installation location
There are no restrictions regarding the installation location for the device. Antennas, in
particular directional antennas, must be mounted according to their characteristics.
Note
-
If you are installing outdoors, use the SCALANCE W786.
-
The minimum distance to fluorescent lamps should be 0.5 m.
-
When installed in a cabinet, we recommend that you do not install relays on the same or on
directly neighboring mounting rails.

Mounting
4.2 Wall mounting
SCALANCE W788C-2
Operating Instructions, 11/2014, A5E03692120-07 15
4.2
Wall mounting
Use the holes in the housing to screw the device to the wall or on a horizontal surface. The
location of the holes can be seen in the following figure:
Figure 4-1 Drilling pattern (dimensions in mm)

Mounting
4.3 Installing on the S7-300 standard rail
SCALANCE W788C-2
16 Operating Instructions, 11/2014, A5E03692120-07
4.3
Installing on the S7-300 standard rail
Follow the steps below to install the SCALANCE W7x8 on a vertical S7-300 rail:
1. Place the device on the upper edge of the S7-300 standard rail (position A).
2. Screw the device to the rail using the supplied screw (position B).
Figure 4-2 Installing on an S7-300 standard rail

Mounting
4.4 Installing on a DIN rail
SCALANCE W788C-2
Operating Instructions, 11/2014, A5E03692120-07 17
4.4
Installing on a DIN rail
The SCALANCE W7x8 is suitable for rail mounting on 35 mm DIN EN 50022 rails.
Bracket for DIN rail mounting
Note
The bracket for installation on a DIN rail
does not ship with the product. You obtain a set of 3
under the following order number: 6GK5
798-8ML00-0AB3.
The bracket consists of the following parts:
●1 DIN rail slider
●1 spring
●2 screws
Mount the bracket on the rear of the device as shown in the figure below:
Figure 4-3 Fitting the DIN rail slider

Mounting
4.4 Installing on a DIN rail
SCALANCE W788C-2
18 Operating Instructions, 11/2014, A5E03692120-07
Installing on the DIN rail
The following figure shows the W7x8 mounted on a DIN rail. Follow the steps outlined below:
1. Place the device on the upper edge of the DIN rail (position A).
2. Pull the spring-mounted DIN rail slider (position B) down and press the device against the
DIN rail until it locks in place.
Figure 4-4 Installing on a DIN rail

SCALANCE W788C-2
Operating Instructions, 11/2014, A5E03692120-07 19
Connection
5
5.1
Lightning protection, power supply and grounding
Notes on lightning protection
WARNING
Danger due to lightning strikes
Antennas installed outdoors must be within the area covered by a lightning protection
system. Make sure that all conducting systems entering from outdoors can be protected by
a lightning protection potential equalization system.
When implementing your lightning protection concept, make sure you adhere to the VDE
0182 or IEC 62305 standard.
Suitable lightning protectors are available in the range of accessories of SIMATIC NET
Industrial WLAN:
●Lightning protector LP798-1N (order no. 6GK5798-2LP00-2AA6)
●Lightning protector LP798-2N (order no. 6GK5798-2LP10-2AA6)
Note
We recommend that you use the maintenance
-free lightning protector LP798-2N.
Exception:
When there is also DC power is supplied via the antenna cable. In this case, only the
lightning protector LP798
-1N can be used.
WARNING
Danger due to lightning strikes
Installing this lightning protector between an antenna and a SCALANCE W700 is not
adequate protection against a lightning strike. The LP798-1N lightening protector only
works within the framework of a comprehensive lightning protection concept. If you have
questions, ask a qualified specialist company.

Connection
5.1 Lightning protection, power supply and grounding
SCALANCE W788C-2
20 Operating Instructions, 11/2014, A5E03692120-07
Note
The requirements of EN61000
-4-5, surge immunity tests on power supply lines, are met only
when a Blitzductor is used with 24 VDC:
BVT AVD 24
type no. 918 422
Manufacturer: DEHN+SÖHNE GmbH+Co.KG, Hans
Dehn Str. 1, Postfach 1640, D -
92306 Neumarkt, Germany
Safety extra low voltage
WARNING
Danger to life from overvoltage, fire hazard
SCALANCE W700 devices are designed for operation with a directly connectable safety
extra-low voltage or with the power supply adapters available as accessories (available
only for the SCALANCE W786 device). Therefore only safety extra-low voltage (SELV) with
limited power source (LPS) complying with IEC950/EN60950/VDE0805 may be connected
to the power supply terminals.
Take measures to prevent transient voltage surges of more than 40% of the rated voltage.
This is the case if you only operate devices with SELV (safety extra-low voltage).
The power supply unit to supply the SCALANCE W700 must comply with NEC Class 2
(requirements of class 2 for power supply units of the "National Electrical Code, table 11
(b)") or SELV with LPS (Limited Power Source) EN 60950-1. If the power supply is
designed redundantly (two separate power supplies), both power supplies must meet these
requirements.
Exception:
Power supply with PELV (according to VDE 0100-410 or IEC 60364-4-41) is also possible if
the generated rated voltage does not exceed the voltage limits 25 VAC or 60 VDC.
WARNING
Transient overvoltage
Take measures to prevent transient voltage surges of more than 40% of the rated voltage.
This is the case if you only operate devices with SELV (safety extra-low voltage).
