SIMATIC
S7-1500
S7-1500R/H redundant system
Getting Started
10/2018
A5E44910930
-AA
Introduction to the example
1
Configuration
2
Programming
3
Commissioning
4
Additional information
5

Siemens AG
Division Digital Factory
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E44910930-AA
Ⓟ
09/2018 Subject to change
Copyright © Siemens AG 2018.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

S7-1500R/H redundant system
Getting Started, 10/2018, A5E44910930-AA 3
Table of contents
1 Introduction to the example ..................................................................................................................... 4
1.1 Security information ..................................................................................................................5
1.2 Structure and task of the example ............................................................................................6
1.3 Procedure ...............................................................................................................................11
1.4 Requirements..........................................................................................................................12
1.5 Wiring diagram for a tunnel section ........................................................................................13
2 Configuration ........................................................................................................................................ 19
2.1 Configuring the assembly .......................................................................................................19
2.2 Configuring H CPUs................................................................................................................22
2.3 Configuring ET 200SP ............................................................................................................25
2.4 Configuring HMI devices.........................................................................................................30
3 Programming ........................................................................................................................................ 34
4 Commissioning ..................................................................................................................................... 48
5 Additional information............................................................................................................................ 51

S7-1500R/H redundant system
4Getting Started, 10/2018, A5E44910930-AA
Introduction to the example
1
Redundant automation systems are used in practice to achieve greater availability. In
redundantly operated systems, failure or malfunction of individual automation components
must not impede the operation of the plant.
S7-1500R/H redundant system
For the S7-1500R/H redundant system, the CPUs are duplicated, in other words redundant.
The two CPUs process the same project data and the same user program in parallel. The
two CPUs are synchronized over redundancy connections. If one CPU fails, the other CPU
maintains control of the process.
Basic knowledge required
The Getting Started guides you through the configuration and programming of an S7-1500H
redundant system using a concrete example. The following knowledge is required in order to
understand the Getting Started:
●General knowledge of automation technology
●Knowledge of requirements for high availability of automation systems
●Knowledge of the engineering system STEP 7 V15.1
WARNING
Personal injury and damage to property may occur.
The S7-1500 as a component of plants or systems is governed by specific standards and
regulations, based on the relevant field of application. Please observe the applicable safety
and accident prevention regulations such as IEC 60204-1 (general machine safety
requirements).
The example in this Getting Started serves as an introduction to the configuration and
programming of an S7-1500H redundant system. It cannot always and in every case be
transferred to effective live operations. Before you do this, you are urgently advised to
consult the current version of the system manual "SIMATIC S7-1500R/H redundant
system" and the device manuals of the modules used. The warnings and other information
there must be observed, even if they are not repeated in this Getting Started.
Failure to observe these regulations can result in serious injuries and damages to
machinery and facilities.

Introduction to the example
1.1 Security information
S7-1500R/H redundant system
Getting Started, 10/2018, A5E44910930-AA 5
1.1
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens' products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be
connected to an enterprise network or the internet if and to the extent such a connection is
necessary and only when appropriate security measures (e.g. firewalls and/or network
segmentation) are in place.
For additional information on industrial security measures that may be implemented, please
visit (https://www.siemens.com/industrialsecurity).
Siemens' products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customers' exposure
to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under (https://www.siemens.com/industrialsecurity).

Introduction to the example
1.2 Structure and task of the example
S7-1500R/H redundant system
6Getting Started, 10/2018, A5E44910930-AA
1.2
Structure and task of the example
Automation task light and fan control in a tunnel
The continuing increase in traffic volumes coupled with growing safety requirements demand
state-of-the-art tunnel systems. At the same time, equipment requirements for these
constructions are rising, especially when it comes to maximum safety and availability.
The example below comprises three subtasks:
●Control of the safety ventilation as a function of the air pollution level in the tunnel
●Control of the traffic lights and the barriers as a function of the air pollution level in the
tunnel
●Control of the lighting in the tunnel as a function of the illuminance of the outdoor light
Figure 1-1 Example Light and fan control tunnel
Control of the safety ventilation as a function of the air pollution level in the tunnel
Fans are used in the tunnel to extract harmful exhaust gases and supply fresh air.
Uninterrupted operation of the ventilation system is required to keep the concentration of
pollutants below a set level. Constant availability must be ensured for the event that
individual automation components fail, for example because of a fire in the tunnel. The S7-
1500H redundant system with two redundant H-CPUs is used to ensure fan availability.
Three fans ventilate the tunnel.
Control of the traffic lights and the barriers as a function of the air pollution level in the tunnel
The tunnel entries are controlled via two traffic lights. The traffic light control also requires
higher availability for safety reasons.
If the pollutant concentration exceeds a maximum limit for more than 2 minutes in a tunnel
section, then the tunnel is blocked.
Control of the lighting in the tunnel as a function of the illuminance of the outdoor light
The abrupt transition between light and dark at the entry to the tunnel is compensated for by
tunnel lighting in the various tunnel sections. Two light sensors measure the light intensity
outside the tunnel. The light intensity of the entry lights in the tunnel is controlled accordingly.
The interior lights in the tunnel are controlled by the prevailing daytime / nighttime.

Introduction to the example
1.2 Structure and task of the example
S7-1500R/H redundant system
Getting Started, 10/2018, A5E44910930-AA 7
Technology diagram
The technology diagram below shows the structure of the automation solution.
①
Tunnel lighting
②
Fan
③
Traffic lights
④
Barriers
⑤
Outdoor light sensors
⑥
Turbidity sensors
⑦
Air-quality sensors
⑧
HMI devices
⑨
H-CPUs
⑩
IO devices for tunnel sections 1 to 3
Figure 1-2 Technology diagram

Introduction to the example
1.2 Structure and task of the example
S7-1500R/H redundant system
8Getting Started, 10/2018, A5E44910930-AA
Automation components of the example
The configuration consists of:
2 S7-1500 H-CPUs
●When a CPU fails in redundant operation, the other CPU maintains control over the
tunnel operation.
3 ET 200SP as IO devices in the PROFINET ring
An ET 200SP (IO device) distributed I/O system is found in every tunnel section (1 to 3).
Sensors and actuators are connected to each IO device for the following tasks:
●Measurement of the pollutant concentration and as a function thereof:
–Control of the fan speed and air flow
–Control of the traffic lights and barriers
●Measurement of the light outside the tunnel:
–Control of the entry lights
●Control of the interior lights in the tunnel, depending on the day / night time.
2 Comfort Panels
The Comfort Panels are used by operators as a control center for monitoring tunnel
operation.

Introduction to the example
1.2 Structure and task of the example
S7-1500R/H redundant system
Getting Started, 10/2018, A5E44910930-AA 9
Principle of operation
Controlling the speed of the fans and controlling the traffic lights and barriers
Every fan:
●has two speeds (stages), which are switched on or off depending on the measured
pollutant concentration.
●has 2 directions of rotation. Depending on whether pollution is measured, the fan must
blow or suck.
The H-CPU measures the pollutant concentrations in the tunnel via analog input modules
and air-quality sensors.
If the pollutant concentration exceeds the maximum limit, the H-CPU responds in ET 200SP
via digital output modules as follows:
●It increases the speed of the fan motors
●It switches the traffic light system to red after two minutes
●It closes the barriers after two minutes
If the pollutant concentration falls below an average limit, the H-CPU responds in ET 200SP
via digital output modules as follows:
●It switches the ventilation motors to stop
●It switches the traffic lights to green
●It opens the barriers
Controlling the lighting in the tunnel
The H-CPU measures the light intensity outside and inside the tunnel using analog input
modules. Depending on the outdoor light, digital output modules adjust the brightness of the
entry lights in the tunnel to the optimum vision conditions. The digital output modules also
control the interior lights in the tunnel, depending on the day / night time.
The user program
in the CPU specifies limits and controls the input and output modules of
the ET 200SP.
The Comfort Panels
visualize the S7-1500H redundant system in an HMI screen. If required,
the operator can switch to manual operation via the HMI screen and change limit values.

Introduction to the example
1.2 Structure and task of the example
S7-1500R/H redundant system
10 Getting Started, 10/2018, A5E44910930-AA
S7-1500H versus S7-1500R
As an alternative to S7-1500H, you can use an S7-1500R redundant system for the solution
to the automation task. In this example, the S7-1500H redundant system is used as it offers
the following advantages for tunnel automation:
●much higher performance than S7-1500R with:
–separate redundancy connections over fiber-optic cable
–high computing power
–a higher number of PROFINET devices can be used
●distance between the two H CPUs up to 10 km
Advantages and benefits of the solution
●High availability of the system: If an H-CPU fails or is being maintained, the lighting and
fan control continues to function. The tunnel does not need to be blocked.
●Reliable monitoring and control of the tunnel facilities over large distances, up to 10 km
between the two H-CPUs
●Monitoring of the system and targeted information of the operating engineers in real time
●Signals are recorded and output directly in the ET 200SP distributed I/O systems in the
tunnel. There are no long cable runs.

Introduction to the example
1.3 Procedure
S7-1500R/H redundant system
Getting Started, 10/2018, A5E44910930-AA 11
1.3
Procedure
Tasks
Perform the following tasks for implementation of the example:
Table 1- 1 Procedure for tunnel automation
Step
Procedure
Further information
1 Configure hardware in STEP 7:
Configure the assembly with 2 H-CPUs, 3 ET 200SP stations with their
I/O modules and 2 Comfort Panels.
Section Configuring (Page 19)
2 Creating a user program in STEP 7:
•Program the user program in an organization block.
•You create an HMI screen.
Section Programming (Page 34)
3 Installing modules and wiring the assembly:
•Install all modules.
•Wire the load current supply, the modules in the PROFINET ring,
the redundancy connections and the Comfort Panels.
Redundant System S7-1500R/H
(https://support.industry.siemens.com/cs/
ww/en/view/109754833) system manual
ET 200SP Distributed I/O System
(https://support.industry.siemens.com/cs/
ww/en/view/58649293) system manual
Chapter Wiring diagram for a tunnel sec-
tion (Page 13)
4 Commissioning the example:
•Insert the SIMATIC memory cards in the H-CPUs.
•Switch on the load current supply and the CPUs.
•Assign redundancy IDs to the CPUs in the configuration on com-
missioning.
•Load the project data (hardware configuration and user program) to
the CPUs.
•Check the LEDs and evaluate the information on the CPU displays.
•Test how the example works.
Chapter Commissioning (Page 48)

Introduction to the example
1.4 Requirements
S7-1500R/H redundant system
12 Getting Started, 10/2018, A5E44910930-AA
1.4
Requirements
Requirements for the Example
The following hardware and software is available for processing the example:
Table 1- 2 Hardware/software requirements
Hardware/software
Modules//Versions
2 H-CPUs with synchroniza-
tion modules and SIMATIC
Memory Cards
•2 identical 1517H-3 PN CPUs with identical article numbers, function versions and firm-
ware version
•4 synchronization modules for cables up to 10 km in length (6ES7960-1FB00-0AA5)
•2 SIMATIC Memory Cards e.g. with 256 Mbyte capacity (6ES7954-8LL02-0AA0)
3 ET 200SP distributed I/O
systems
2 ET 200SP for tunnel sections 1 and 3 each consisting of:
•1 interface module IM 155-6 PN HF (6ES7155-6AU01-0CN0), FW version V4.2 or later
(with system redundancy S2)
•4 digital output modules:
–2 DQ 4x24VDC/2A ST each with a light-colored BaseUnit, BU type A0: BU15-
P16+A0+2D
–1 DQ 4x24VDC/2A ST with a dark-colored BaseUnit, BU type A0: BU15-P16+A0+2B
–1 DQ 4x24..230VAC/2A HF with a light-colored BaseUnit, BU type U0: BU20-
P16+A0+2D
•1 analog input module:
–AI 4xU/I 2-wire ST with a dark-colored BaseUnit, BU type A0: BU15-P16+A0+2B
•1 server module
1 ET 200SP for tunnel section 2 consisting of:
•1 interface module IM 155-6 PN HF (6ES7155-6AU01-0CN0), FW version V4.2 or later
(with system redundancy S2)
•2 digital output modules:
–1 DQ 4x24VDC/2A ST with a light-colored BaseUnit, BU type A0: BU15-P16+A0+2D
–1 DQ 4x24..230VAC/2A HF with a light-colored BaseUnit, BU type U0: BU20-
P16+A0+2D
•1 analog input module:
–AI 4xU/I 2-wire ST with a dark-colored BaseUnit, BU type A0: BU15-P16+A0+2B
•1 server module
2 HMI devices
TP1900 Comfort
2 load current supplies for
S7-1500R/H
PM 190 W 120/230 V AC
3 load current supplies for
ET 200SP
Load current supplies with 24 V DC output voltage (with safe electrical isolation)
Accessories
1 mounting rail, 2 fiber-optic cables, PROFINET cables
PC/PG with Engineering-
System
PG/PC with Ethernet interface and the following correctly installed software package:
•SIMATIC STEP 7 Professional, V15.1 or later
Switch for the connection of
the PG/PC
SCALANCE X-204IRT

Introduction to the example
1.5 Wiring diagram for a tunnel section
S7-1500R/H redundant system
Getting Started, 10/2018, A5E44910930-AA 13
Additional requirement
The PG/PC is connected to a switch via the PROFINET interface. The switch is a device in
the PROFINET ring during commissioning.
Installing modules and wiring the assembly
You can set up and wire the hardware before or after configuration and programming of the
user program.
You can find additional information on installation and wiring of an ET 200SP in the
ET 200SP distributed I/O system
(https://support.industry.siemens.com/cs/ww/en/view/58649293) system manual .
The wiring diagram for an ET 200SP for a tunnel section can be found in the section Wiring
diagram for a tunnel section (Page 13).
The procedure for installation and wiring of an S7-1500R/H redundant system is available in
the S7-1500R/H redundant system
(https://support.industry.siemens.com/cs/ww/en/view/109754833) system manual.
Conventions
Steps and settings which are specific for configuration and programming of an S7-1500H
redundant system will be dealt with in detail in the following sections. Procedures which you
are already familiar with from configuring and programming a SIMATIC S7-1500 will only be
briefly outlined.
1.5
Wiring diagram for a tunnel section
Introduction
The figures below show the wiring of the I/O modules of an ET 200SP distributed I/O system
for tunnel section 1 or 3.
When wiring the tunnel section 2, there is no wiring of the digital output modules for the
traffic lights control and barrier control nor of the outdoor light sensor on the analog input
module.

Introduction to the example
1.5 Wiring diagram for a tunnel section
S7-1500R/H redundant system
14 Getting Started, 10/2018, A5E44910930-AA
Connecting the supply voltage, PROFINET cables and grounding
The following figure shows the wiring of the supply voltage, the PROFINET cables and the
grounding on the ET 200SP.
①
Interface module IM 155-6 PN HF (6ES7155-6AU01-0CN0 firmware version V4.2 and later)
②
Traffic light control: DQ 4x24VDC/2A ST digital output module with a light-colored BaseUnit BU15-P16+A0+2D (BU
type A0)
③
Barrier control: DQ 4x24VDC/2A ST digital output module with a dark-colored BaseUnit BU15-P16+A0+2B (BU
type A0)
④
Measuring the light intensity and air pollution level: 4xU/I 2-wire ST analog input module with a dark-colored Ba-
seUnit BU15-P16+A0+2B (BU type A0)
⑤
Fan control system: DQ 4x24VDC/2A ST digital output module with a light-colored BaseUnit BU15-P16+A0+2D
(BU type A0)
⑥
Light control system: DQ 4x24..230VAC/2A HF digital output module with a light-colored BaseUnit BU20-
P16+A0+2D (BU type U0)
⑦
Server module
⑧
Mounting rail grounded at PE
⑨
Load current supply with 24 V DC output voltage (with safe electrical isolation)
⑩
PROFINET cables for the PROFINET ring
Figure 1-3 Wiring diagram

Introduction to the example
1.5 Wiring diagram for a tunnel section
S7-1500R/H redundant system
Getting Started, 10/2018, A5E44910930-AA 15
Connecting traffic light control
The following figure shows the wiring of the traffic lights on the DQ 4x24VDC/2A ST digital
output module ②.
Figure 1-4 Wiring of the traffic lights
Connecting barrier control
The following figure shows the wiring of the barrier control on the DQ 4x24VDC/2A ST digital
output module ③.
The barrier is opened and closed via a three-phase motor. The direction of rotation of the
three-phase motor is controlled via a reversing contactor:
●Open barrier →Contactor K1 actuated
●Close barrier →Contactor K2 actuated
If the barriers have reached their respective end position, they automatically switch off via
limit switches.
Figure 1-5 Wiring of the barrier control

Introduction to the example
1.5 Wiring diagram for a tunnel section
S7-1500R/H redundant system
16 Getting Started, 10/2018, A5E44910930-AA
Connecting sensors for light intensity and air pollution level
The following figure shows the wiring of the sensors for measuring the light intensity and air
pollution level on the AI 4xU/I 2-wire ST analog input module ④.
Figure 1-6 Wiring of sensors for light intensity and air pollution level

Introduction to the example
1.5 Wiring diagram for a tunnel section
S7-1500R/H redundant system
Getting Started, 10/2018, A5E44910930-AA 17
Connect light control function
The following figure shows the wiring of the fan control on the DQ 4x24VDC/2A ST digital
output module ⑤.
The direction of rotation of the fan (right/left) is controlled via a reversing contactor:
●Fan rotates clockwise →Contactor K1 actuated
●Fan rotates counterclockwise →Contactor K2 actuated
The speed (high/low) of the fan is controlled via a Dahlander circuit:
●Fan low speed →Contactor K5 actuated
●Fan high speed →Contactors K3 and K4 actuated
Figure 1-7 Wiring of fan control

Introduction to the example
1.5 Wiring diagram for a tunnel section
S7-1500R/H redundant system
18 Getting Started, 10/2018, A5E44910930-AA
Connect light control function
The following figure shows the wiring of the light control on the DQ 4x24..230VAC/2A HF
digital output module ⑥.
The lamps are dimmed via the Phase angle control - Phase angle proportional function of
the digital output mode:
●L1 →Entry light
●L2 →Interior light
Figure 1-8 Wiring of the traffic lights

S7-1500R/H redundant system
Getting Started, 10/2018, A5E44910930-AA 19
Configuration
2
2.1
Configuring the assembly
Introduction
Create a new project and add the CPU 1517H-3 PN and the 3 ET 200SP distributed I/O
systems. Network the assembly to a PROFINET ring.
Add 2 HMI devices TP1900 Comfort to the assembly.
You do not configure the PM 190 W 120/230 V AC load current supplies.
Requirement
You have set the IP address of the PG/PC, 192.168.0.50 in the example.
Creating a project and assigning hardware
1. Create a new project in STEP 7. Give the project the name "S7-1500H_GS".
Figure 2-1 Creating a new project
2. Select "Configure a device" and then "Configure networks".
The network view opens.
3. Select CPU 1517H-3 PN from the hardware catalog in the network view.
