Siemens SED2 Series User guide

s
∆ P
∆ P
Escape and
emergency route
A
ir handlin
g
system
Smoke extraction channel
SED2 Variable Speed Drive
Application Guide «Fire Mode»
CM1A5192en_01
23.10.2007
Building Technologies

2 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies 23.10.2007
Siemens Switzerland Ltd.
Building Technologies Group
International Headquarters
Gubelstrasse 22
CH-6301 Zug
Tel. [phone]
Fax [phone]
www.siemens.com/sbt
© 2007 Siemens Switzerland Ltd.
Sub
j
ect to chan
g
e

3 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Table of contents 23.10.2007
Table of contents
1About this document..............................................................................5
1.1 Revision history.........................................................................................5
1.2 Reference documents...............................................................................5
1.3 Before you start.........................................................................................5
1.3.1 Copyright...................................................................................................5
1.3.2 Quality assurance .....................................................................................5
1.3.3 Document use/request to the reader ........................................................6
2Safety and CE compliance.....................................................................7
2.1 Exclusion of liability...................................................................................8
2.2 Qualified personnel ...................................................................................9
2.3 User group ................................................................................................9
3Introduction...........................................................................................10
3.1 Smoke and heat extraction in the building..............................................10
3.2 Guidelines and standards for smoke and heat extraction.......................10
3.3 Interplay of ventilation plant and smoke and heat extraction in the event of fire... 11
3.4 Operation of SED2 in the event of fire ....................................................12
4Application Examples...........................................................................14
4.1 Application Example 1 ............................................................................14
4.1.1 Description ..............................................................................................14
4.1.2 Wiring diagram........................................................................................14
4.1.3 Parameter setting....................................................................................15
4.1.4 Remarks..................................................................................................15
4.2 Application Example 2 ............................................................................16
4.2.1 Description ..............................................................................................16
4.2.2 Wiring diagram........................................................................................16
4.2.3 Parameter setting....................................................................................17
4.2.4 Remarks..................................................................................................17
4.3 Application Example 3 ............................................................................18
4.3.1 Description ..............................................................................................18
4.3.2 Wiring diagram........................................................................................18
4.3.3 Parameter setting....................................................................................19
4.3.4 Remarks..................................................................................................19
4.4 Application Example 4 ............................................................................20
4.4.1 Description ..............................................................................................20
4.4.2 Wiring diagram........................................................................................20
4.4.3 Parameter setting....................................................................................21
4.4.4 Remarks..................................................................................................21
4.5 Application Example 5 ............................................................................22
4.5.1 Description ..............................................................................................22
4.5.2 Wiring diagram........................................................................................22
4.5.3 Parameter setting....................................................................................23
4.5.4 Remarks..................................................................................................23
4.6 Application Example 6 ............................................................................24
4.6.1 Description ..............................................................................................24
4.6.2 Wiring diagram........................................................................................24
4.6.3 Parameter setting....................................................................................25
4.6.4 Remarks..................................................................................................25

4 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Table of contents 23.10.2007
5Commissioning Wizard for Essential Service Mode .........................26
5.1 Introduction..............................................................................................26
5.2 Parameterisation of ESM function ..........................................................27
5.3 Languages...............................................................................................29
5.4 Distribution ..............................................................................................29
6Essential Service Mode (in-depth information)..................................30
6.1 Assigning the ESM function to a DIN (Digital Input) ..............................31
6.2 Activating P1271 (ESM Control Word)....................................................31
6.3 Defining the main Speed (Frequency) Setpoint for ESM ........................32
6.3.1 ESM and standard setpoint are the same...............................................32
6.3.2 ESM and standard setpoint are different.................................................32
6.3.3 Disabling the Additional Setpoint ............................................................33
6.3.4 Basic settings as ESM Fixed Frequency setpoint...................................33
6.4 Reverse Direction in ESM/Fire Mode......................................................35
6.5 PID Control in ESM/Fire Mode................................................................37
6.5.1 PID Control in both ESM and Standard Mode ........................................37
6.5.2 PID Control in Standard mode but disabled in ESM/Fire Mode.............38
6.5.3 PID Control in ESM/Fire Mode but disabled in standard Mode .............39
6.5.4 PID Control disabled in ESM/Fire Mode and Standard mode................39
6.6 Indication of ESM/Fire Mode...................................................................40
6.6.1 BOP indication of ESM/Fire Mode ..........................................................40
6.6.2 Relay output indication of ESM/Fire Mode..............................................40
6.6.3 Fault Handling in ESM/Fire Mode ...........................................................40
6.6.4 Automatic re-start in ESM/Fire Mode......................................................40
6.6.5 Acknowledging a fault when ESM/Fire Mode is first enabled .................41
6.7 Advanced settings...................................................................................41
6.7.1 ESM/Fire Mode Control Words for the SED2 .........................................41
6.7.2 Starting the SED2 in ESM/Fire Mode......................................................42
6.7.3 Stopping the SED2 in ESM/Fire Mode....................................................42

5 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies About this document 23.10.2007
1 About this document
1.1 Revision history
Version Date Changes Section Pages
V01 13.07.2007 None (new document) — —
1.2 Reference documents
Ref. Document title Type of document Document No.
[1] SED2 Getting Started Guide Commissioning CM1G5192X
[2] SED2 Commissioning Guide Commissioning, Configuration CM1G5192xx
[3] SED2 Data Sheet Technical Data CM1N5192xx
1.3 Before you start
1.3.1 Copyright
This document may be duplicated and distributed only with the express permission
of Siemens, and may be passed only to authorized persons or companies with the
required technical knowledge.
1.3.2 Quality assurance
These documents have been prepared with great care.
•The contents of all documents are checked at regular intervals.
•Any corrections necessary are included in subsequent versions.
•Documents are automatically amended as a consequence of modifications and
corrections to the products described.
Please ensure that you are aware of the latest revision date of the documentation.
If you find any lack of clarity while using this document, or if you have any criticisms
or suggestions, please contact the product manager in your nearest branch office,
or write directly to the support team at Headquarters in Zug (see below).
Support address:
Siemens Switzerland Ltd.
Building Technologies Group
International Headquarters
Field Support 5500
Gubelstrasse 22
6301 Zug, Switzerland
Tel. [phone]
Fax. [phone]
E-mail: [e-mail]

6 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies About this document 23.10.2007
1.3.3 Document use/request to the reader
Before using our products, it is important that you read the documents supplied
with or ordered at the same time as the products (equipment, applications, tools
etc.) carefully and in full.
We assume that the users of these products and documents have the appropriate
authorization and training, and that they are in possession of the technical knowl-
edge necessary to use the products in accordance with their intended application.
If, despite this, there is a lack of clarity or other problems associated with the use of
the documentation, please do not hesitate to contact the Product Manager at your
nearest branch office, or write directly to the support team at our Swiss headquar-
ters.
E-mail: [e-mail].
Please note that without prejudice to your statutory rights, Siemens accepts no li-
ability for any losses resulting from non-observance or improper observance of the
points referred to above.

7 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Safety and CE compliance 23.10.2007
2 Safety and CE compliance
Before installing and putting the equipment into operation, read these safety in-
structions and warnings carefully. Also read and obey all warning signs attached to
the equipment. Make sure that the warning labels are kept in a legible condition
and replace any missing or damaged labels.
•This equipment contains dangerous voltages and controls dangerous rotating me-
chanical parts. Loss of life, severe personal injury or property damage can result if
the instructions contained in this Manual are not followed
•Only suitably qualified personnel should work on this equipment, and only after be-
ing familiar with all safety notices, installation, operation and maintenance proce-
dures contained in this manual
•Use only permanently wired input power connections. The equipment must be
grounded (IEC 536 Class 1, NEC, and other applicable standards)
•If a Residual Current Circuit Breaker (RCCB or ELCB) is required, type B with a 300
mA tripping current must be used (the RCCB. should only supply one VSD). An un-
filtered VSD should be used or if the VSD has an EMC filter this must be discon-
nected, due to the filter leaking current to earth. The neutral conductor in the system
must be grounded
•Wait at least 5 minutes after the power has been turned off, before opening the
equipment. The dc-link capacitor remains charged to dangerous voltages even
when the power is removed. When working on open equipment, note that live parts
are exposed and do not touch such parts
•Do not connect machines with a three-phase power supply, fitted with EMC filters,
to a supply via an ELCB (Earth Leakage Circuit Breaker - see EN 50 178, section
6.5)
•Note that certain parameter settings may cause the VSD to restart automatically af-
ter an input power failure
•Do not use this equipment as an “emergency stop” mechanism (see EN 60 204,
9.2.5.4)
•Note that certain parameter settings may cause the VSD to start automatically
•Obey all general and regional installation and safety regulations relating to work on
high-voltage installations, as well as regulations covering correct use of tools and
personal protective equipment
•This equipment is capable of providing internal motor overload protection in ac-
cordance with UL508C section 42. An external PTC can also provide motor
overload protection via a special input
•This equipment is suitable for use in a circuit capable of delivering not more than
100,000 symmetrical amps (rms) for a maximum voltage of AC 230/460 V when
protected by a time delay fuse.
•Do not use the unit with a motor of a higher nominal power rating than the VSD,
or a nominal power less than half that of the VSD. Only operate the VSD when
the nominal current in P0305 exactly matches the motor rating plate nominal
current
•When using the analog inputs, the DIP switches must be correctly set and the
analog inputs correctly configured before enabling them. If this is not done, the
motor may start inadvertently
Warning

8 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Safety and CE compliance 23.10.2007
•Do not allow children or the general public to access or approach this equipment
•Do not install the VSD where it will be subjected to shock, vibration, electromag-
netic radiation, water hazards, or atmospheric pollutants such as dust or corro-
sive gasses
•Keep Operating Instructions, etc., with this equipment or with the end-user
•Use this equipment only for the purpose specified by the manufacturer. Do not
carry out any modifications or fit any spare parts, which are not sold or recom-
mended by the manufacturer; as this could cause fire, electric shock or other in-
juries
2.1 Exclusion of liability
The user of the SED2 variable speed drive must be aware that fire/emergency op-
eration may only be activated should crucial events occur (e.g. fire), where contin-
ued operation of the motor (fan) is mandatory to ensure smoke and heat extraction,
for instance, in order to facilitate the evacuation of people.
When triggering fire/emergency operation, certain alarm and fault status messages
of the SED2 (e.g. overtemperature of SED2, breakdown of bus communication) will
be suppressed. In the case of other faults (e.g. overvoltage or overcurrent), restarts
will permanently be triggered. Suppression of the protective functions shall ensure
that – during fire/emergency operation – the motor continues to run as long as
possible.
When using this operating mode, damage to the SED2 itself cannot be excluded,
be it due to failure of internal components or fire caused by excessive heat. In addi-
tion, it must be taken into account that – due to the parameterized behavior of the
SED2 – other HVAC plant components can also be damaged during fire/emer-
gency operation. This includes air dampers, for example, which can be damaged
as a result of overpressure (e.g. when the maximum motor speed is parameter-
ized). Such damage can lead to HVAC plant malfunction or failure – a fact to be
considered when triggering fire/emergency operation.
For these reasons, Siemens Building Technologies assumes no responsibility for
any faults, malfunctions and damage of the SED2 itself or of any other types of
components used in the relevant HVAC plant, or for direct or indirect damage re-
sulting from activation of fire/emergency operation.
The correct functioning of fire/emergency operation depends on the right selection
of the HVAC system components of which the SED2 constitutes only one compo-
nent. Plant used in vital sectors, such as ventilation plant that need to mandatory
and constantly deliver a certain amount of outside air, must be approved by the re-
spective authorities.
Fire/emergency operation can be triggered via one of the six digital inputs DIN1...6.
The BOP display shows alternately “ES“ and the motor’s frequency.
Fire/emergency operation can be deactivated any time via the digital input that was
used for activation. Then, the SED2 will resume normal operation as parameter-
ized.
Caution

9 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Safety and CE compliance 23.10.2007
2.2 Qualified personnel
In the sense of this documentation, qualified personnel are those who are knowl-
edgeable and qualified to install, mount, commission, operate and service/maintain
the SED2 Variable Speed Drive product. He or she must have the appropriate
qualifications to carry-out these activities, for example:
•Trained and authorized to energize and de-energize, ground and tag circuits and
equipment according to applicable safety standards.
•Trained or instructed according to the latest safety standards in the care and use
of the appropriate safety equipment.
•Trained in rendering first aid.
There is no explicit warning information in this documentation. However, reference
will be made to warning information and instructions in the Operating Instructions
for the particular product.
2.3 User group
These Guidelines were drawn-up to support customers and employees of Siemens
AG when engineering plants and machines.
The functions and features described in this document refer only to the SED2 Vari-
able Speed Drive with version Firmware 1.40 or greater.

10 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Introduction 23.10.2007
3 Introduction
3.1 Smoke and heat extraction in the building
”There is no smoke without a fire”. This old proverb can still be applied to our time
– and the order of the 2 risk factors ”smoke and fire” is correct too. A number of
fires in recent times have demonstrated that, very often, smoke poses a greater
threat to people than the fire itself. This shall be in indication of the importance of
smoke when discussing the safety of people in the case a building fire has broken
out.
On the one hand, strong smoke limits visibility or produces toxic gases, which
make breathing much more difficult so that escape routes can no longer be used
without wearing appropriate clothing. On the other hand, the accumulation of gases
produced by the fire will lead to enormous heat concentrations near the source of
the fire so that flashover to other spaces or plant can occur.
The necessity of smoke and heat extraction is uncontested. In general, however,
contractors must first be persuaded to include this requirement in their planning
work and to approve the investment since this feature does not constitute part of a
HVAC plant’s comfort requirements, but is ”only“ considered as a ”preventive
measure”.
Present national fire protection guidelines and standards, which sometimes even
give consideration to regional needs, partly define the requirements placed on
smoke and heat extraction in buildings. Proven applications come primarily from
Australia (S/NZ 1668.1-1998) and the U.S. (ASHRAE publication, Design of Smoke
Management). For European countries, EN 12101 lays down the requirements for
smoke and heat extraction components and the methods applied to differential
pressure systems (overpressure plants) in buildings.
3.2 Guidelines and standards for smoke and
heat extraction
USA NFPA 92A, NFPA 92B, ASHARE Guideline 5
Design of Smoke Management System
Europe EN 12101 Part1-6
Smoke and heat control systems
Germany VDMA 24200-1
Automatisierte Brandschutz- und Entrauchungssysteme ABE
Australia,
New Zealand
AS/NZS 1668.1:1998
The use of ventilation and airconditioning in buildings - Fire and
smoke control in multi-compartment buildings
Switzerland prSWKI BT101 Teil 1-6
Rauch- und Wärmefreihaltung

11 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Introduction 23.10.2007
3.3 Interplay of ventilation plant and smoke and
heat extraction in the event of fire
The illustration below shows a possible scenario in the event of fire and the inter-
play between ventilation plant and smoke and heat extraction. According to the
scenario chosen, a fire broke out on the floor in the middle of the building. In prin-
ciple, the change from ventilation mode (comfort mode) to fire mode (smoke ex-
traction mode) can take place automatically via the fire alarm center, or through a
key switch on the fire alarm panel.
In both cases, the ventilation plant in section 2 will be shut down first of all. Both
fire protection and smoke extraction dampers will be closed or opened as shown.
Then, the fume gas fan (smoke extraction) in section 3 will be activated. The hot
and usually toxic fumes will thus be vented to atmosphere. The resupply air duct
and the open damper ensure that the space will be adequately vented.
The fire protection dampers on the respective floor prevent smoke from reaching
the other floors via the supply and extract air ducts. However, open doors, passage
ways or other openings between the floors and the stairwell or lift shaft allow
smoke to spread. In order to keep escape routes and the other floors free from
smoke as long as possible, ventilation plant in these zones will purposely be oper-
ated under overpressure.
In zone 1 (stairwell), overpressure of 50 to 100 Pa is produced with the help of a
differential pressure sensor and a speed-controlled fan (using a PID controller).
Overpressure prevents smoke from entering the stairwell. Pressure changes
caused by the opening and closing of doors are compensated by the control sys-
tem, which also ensures that doors can still be opened in case pressure differen-
tials exceed a certain level.
The supply air fan in zone 2 will also be activated, producing overpressure like in
the stairwell. Naturally, differential pressure control could also be employed. But in
most cases, the fan operates at a fixed speed.
The interplay of smoke and heat extraction and ventilation plant pursues the follow-
ing targets:
•To minimize the amount of smoke and heat, the fume gases produced by the fire
shall be conducted to atmosphere as quickly as possible.
•Overpressure operation of the ventilation plant shall ensure that escape routes
and neighboring spaces will be kept free from smoke as long as possible.
Functioning principle of smoke and heat extraction and ventilation plant in the
event of fire:
∆P
 

∆P
Escape and
emergency route
Air handlin
g
system
Smoke extraction channel

12 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Introduction 23.10.2007
3.4 Operation of SED2 in the event of fire
The new firmware V1.40 actively supports operation in the event of fire. The focus
is clearly on the above mentioned overpressure plants, which can be easily imple-
mented through the use of speed-controlled fans. The change from comfort to fire
operation is accomplished by the Essential Service Mode (ESM). For use with the
SED2, this function has been completely revised and extended.
The ESM function was also available with former firmware versions of the SED2,
but has been constantly optimized based on experience made in the field and
feedback received from the Regional Companies (RC). This means that V1.40 in-
cludes all findings made thus far so that the SED2 also represents state of the art
as far as ESM is concerned.
ESM can be activated via digital inputs DIN1…6. Hence, the ESM function must be
assigned to one of these inputs.
Typically, the signal is delivered by the fire control panel. In that case, ”ES” appears
on the BOP display, which alternates with the motor’s frequency.
When the command for ESM is deactivated again, the SED2 will resume normal
operation.
The primary objective of ESM is to ensure fan operation “under all circumstances“.
As soon as ESM is activated, the SED2 starts its operation independently of the
operating state predefined by the building automation and control system. This
means that ESM is given priority over normal operation. In addition – when us-
ing ESM – the protective VSD functions (soft errors and warnings), such as over-
temperature or faulty communication, will be suppressed and the hard errors, such
as overvoltage and overcurrent, acknowledged an infinite number of times and the
motor restarted. The hard errors must not be suppressed and ignored!
It is possible to define any setpoint as the ESM setpoint. The flexibility of the SED2
allows this unlike other competitor drive that can only supply a fixed frequency set-
point in Fire-Mode. However, a fixed-frequency (e.g. maximum frequency) is the
most common setpoint and this can easily be configured.
Sometimes, ESM also calls for controlled operation (internal PID), when full over-
or low-pressure operation is not permitted because it shall still be possible to open
or close doors. When using ESM, it is also possible to reverse the motor’s direction
of rotation.
For that purpose, V1.40 offers a new parameter with 2 control words. These control
words are used to define the behavior in ESM. The following applications can be
implemented, either individually or in combination:
•Running to a defined fixed speed
•PID control with a defined fixed setpoint
•PID control with a preselected setpoint via analog input or bus
•Reversal of the direction of rotation
Activation of ESM
Difference between
ESM and normal opera-
tion
Definition of the SED2s
behavior in ESM

13 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Introduction 23.10.2007
Once ESM is activated, “ES“ is displayed on the SED2 BOP (Basic operating
Panel). ESM activation can also be assigned to one of the relays of the SED2.
The SED2 firmware offers ESM as a standard feature which can be enabled via a
parameter and also appropriately parameterized. We envisage a number of typical
applications for the ESM function. The following example shows a typical SED2
application in a shopping mall, including ESM:
L1 L2 L3
UVW
PE
PE
DC 10V
DC 0V
AIN2
11
10
2
28
9
DC 0V
DC 24V
AIN1
4
3
2
5
6
7
8
16
17
14
15
PTC
PTC
DIN1
DIN2
DIN3
DIN4
DIN5
DIN6
1
2 12
13
26
27
AOUT1
AOUT2
DOUT1
20
21
22
DOUT2
23
24
25
29
30
RS-485
SED2
L1
L2
L3
N
PE
F1 F1F1
M
Alarm Control Panel
Desigo PX
PTE-
SED2
•Several air handling plants are installed in a shopping center, using several
SED2 for the supply and extract air fans
•In normal operation, the Desigo system delivers the switch-on command and
setpoint to the VSD via bus
•If the fire alarm center activates ESM, the SED2 will start to operate with the
maximum speed at 50 Hz and suppresses the protective functions and error
messages as described above
•The plant will switch to overpressure operation in order to keep the rooms free
from smoke
Application example of
ESM

14 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Application Examples 23.10.2007
4 Application Examples
The use of EasyComm to commission the functions within ESM will greatly simplify
setting certain bits in the ESM control words.
4.1 Application Example 1
4.1.1 Description
•In normal operation the SED2 is receiving the setpoint over the analogue input 1,
e.g. from a BAC, e.g. DESIGO PX.
•In case of fire the fire control panel signals this to the SED2, it is going in the
ESM mode and the setpoint is still coming over the analogue input.
4.1.2 Wiring diagram
L1 L2 L3
UVW
PE
PE
DC 10V
DC 0V
AIN2
11
10
2
28
9
DC 0V
DC 24V
AIN1
4
3
2
5
6
7
8
16
17
14
15
PTC
PTC
DIN1
DIN2
DIN3
DIN4
DIN5
DIN6
1
2 12
13
26
27
AOUT1
AOUT2
DOUT1
20
21
22
DOUT2
23
24
25
29
30
RS-485
SED2
L1
L2
L3
N
PE
F1 F1F1
M
ON/OFF
Fire Control Panel
0...10 VDC
Setpoint
GND
Commissioning
ESM/Fire Mode with
EasyComm software

15 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Application Examples 23.10.2007
4.1.3 Parameter setting
Start with quick commissioning according the commissioning guide
CM1G5192. It is very important to enter the right motor data!
Par. Nr. Value Parameter function Function selection
P0003 3 User access level 3 Expert access
P0702(0) 26 Function of DIN2 in Auto mode ESM
P0702(1) 26 Function of DIN2 in Hand mode ESM
P1271(0) Activation of ESM control word press▼once;
will appear and ESM
control word is acti-
vated
For further information please see also Chapter 5 – Commissioning Wizard for
Essential Service Mode.
4.1.4 Remarks
•The hand mode will be disabled automatically when ESM is active.
•The information “drive fault” and “drive running” is still available on the 2 relay
outputs.
On demand the information “ESM active” can be configured to a relay output.

16 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Application Examples 23.10.2007
4.2 Application Example 2
4.2.1 Description
•In normal operation the SED2 is receiving the setpoint over the analogue input 1
e.g. from a BAC e.g. DESIGO PX.
•In case of fire the fire control panel signals this to the SED2, it is going in the
ESM mode and to a fixed frequency e.g. 40Hz.
4.2.2 Wiring diagram
L1 L2 L3
UVW
PE
PE
DC 10V
DC 0V
AIN
11
10
2
28
9
DC 0V
DC 24V
AIN1
4
3
2
5
6
7
8
16
17
14
15
PTC
PTC
DIN1
DIN2
DIN3
DIN4
DIN5
DIN6
1
2 12
13
26
27
AOUT1
AOUT2
DOUT1
20
21
22
DOUT2
23
24
25
29
30
RS-485
SED2
L1
L2
L3
N
PE
F1 F1F1
M
ON/OFF
0...10 VDC
Setpoint
GND
Fire Control Panel

17 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Application Examples 23.10.2007
4.2.3 Parameter setting
Start with quick commissioning according the commissioning guide
CM1G5192. It is very important to enter the right motor data!
Par. Nr. Value Parameter function Function selection
P0003 3 User access level 3 Expert access
P0702(0) 99 Function of DIN2 in „Auto“
mode
BICO = free parame-
terization
P0702(1) 99 Function of DIN2 in „Hand“
mode
BICO = free parame-
terization
P1000(0) 23 Setpoint source in Auto AI1 + FF
P1001 40 Fixed frequency when ESM is
active
in Hz
P1074(0) 722.1 Disable Additional Setpoint in
Auto
Disable AI1
P1074(1) 722.1 Disable Additional Setpoint in
Hand
Disable AI1
P1270(0) 722.1 Activate ESM in Auto DI2
P1270(1) 722.1 Activate ESM in Hand DI2
P1271(0) Activation of ESM control word press▼once;
will appear and ESM
control word is acti-
vated
P1271(1) Enable FF in ESM mode press▲once
For further information please see also Chapter 5 – Commissioning Wizard for
Essential Service Mode.
4.2.4 Remarks
•The hand mode will be disabled automatically when ESM is active.
•The information “drive fault” and “drive running” is still available on the 2 relay
outputs.
On demand the information “ESM active” can be configured to a relay output.

18 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Application Examples 23.10.2007
4.3 Application Example 3
4.3.1 Description
•In normal operation the SED2 is controlled from the Desigo PX via bus commu-
nication using the PTE module.
•In case of fire the fire control panel signals this to the SED2, it is going in the
ESM mode and the setpoint is still coming from the Desigo over the bus.
4.3.2 Wiring diagram
L1 L2 L3
UVW
PE
PE
DC 10V
DC 0V
AIN2
11
10
2
28
9
DC 0V
DC 24V
AIN1
4
3
2
5
6
7
8
16
17
14
15
PTC
PTC
DIN1
DIN2
DIN3
DIN4
DIN5
DIN6
1
2 12
13
26
27
AOUT1
AOUT2
DOUT1
20
21
22
DOUT2
23
24
25
29
30
RS-485
SED2
L1
L2
L3
N
PE
F1 F1F1
M
Fire Control Panel
Desigo PX
PTE-
SED2

19 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Application Examples 23.10.2007
4.3.3 Parameter setting
Start with quick commissioning according the commissioning guide
CM1G5192.
It is very important to enter the right motor data!
Par. Nr. Value Parameter function Function selection
P0003 3 User access level 3 Expert access
P0700 5 Command source DESIGO (USS on
COM link)
P0702(0) 26 Function of DIN2 in Auto mode ESM
P0702(1) 26 Function of DIN2 in Hand
mode
ESM
P1000 5 Setpoint source DESIGO (USS on
COM link)
P1271(0) Activation of ESM control word press▼once;
will appear and ESM
control word is acti-
vated
P2009(0) 1 USS normalization COM-Link Enabled
P2010(0) 6 USS baud rate COM-Link 9600 baud
P2011(0) 1 (e.g.) USS address COM-Link Address range 1 to 31
P2014(0) 0…65535 USS telegram off time 0…65535ms (Defines
a time after which a
fault message will be
generated (F0072 if
no telegram is re-
ceived via the USS
channels)
For further information please see also Chapter 5 – Commissioning Wizard for
Essential Service Mode.
4.3.4 Remarks
•The hand mode will be disabled automatically when ESM is active.
•The information “drive fault” and “drive running” is still available on the 2 relay
outputs.
On demand the information “ESM active” can be configured to a relay output.
•The fault F0072 (bus communication failure) will be ignored whilst ESM is active.
•In this example a DESIGO PX is used as the communication master but any
communication (FLN, P1, N2) could be used just as effectively.

20 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Application Examples 23.10.2007
4.4 Application Example 4
4.4.1 Description
•In normal operation the SED2 is controlled from the Desigo PX via bus commu-
nication using the PTE module.
•In case of fire the fire control panel signals this to the SED2, it is going in the
ESM mode and to a fixed frequency e.g. 40Hz.
4.4.2 Wiring diagram
L1 L2 L3
UVW
PE
PE
DC 10V
DC 0V
AIN2
11
10
2
28
9
DC 0V
DC 24V
AIN1
4
3
2
5
6
7
8
16
17
14
15
PTC
PTC
DIN1
DIN2
DIN3
DIN4
DIN5
DIN6
1
2 12
13
26
27
AOUT1
AOUT2
DOUT1
20
21
22
DOUT2
23
24
25
29
30
RS-485
SED2
L1
L2
L3
N
PE
F1 F1F1
M
Fire Control Panel
Desigo PX
PTE-
SED2
