Siemens SINAMICS S120 Technical Document

Equipment Manual 10/2008
SINAMICS S120 Cabinet Modules
SINAMICS
s

Preface
Safety information
1
System overview
2
Mechanical installation
3
Electrical installation
4
Cabinet Modules
5
Maintenance and servicing
6
Diagnostics
7
Options
8
Appendix
A
SINAMICS
S120
S120 Cabinet Modules
Equipment Manual
Manual
(GH5), 10/2008
A5E00427098A

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.
CAUTION
without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.
NOTICE
indicates that an unintended result or situation can occur if the corresponding information is not taken into
account.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The device/system may only be set up and used in conjunction with this documentation. Commissioning and
operation of a device/system may only be performed by qualified personnel. Within the context of the safety notes
in this documentation qualified persons are defined as persons who are authorized to commission, ground and
label devices, systems and circuits in accordance with established safety practices and standards.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be adhered to. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of the
owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E00427098A
Ⓟ 01/2009
Copyright © Siemens AG 2008.
Technical data subject to change

S120 Cabinet Modules Equipment Manual
Manual, (GH5), 10/2008, A5E00427098A 5
Preface
Information on the SINAMICS S120 documentation
The SINAMICS S120 documentation is subdivided into the following levels:
● General documentation/catalogs
● Manufacturer/service documentation
● Electronic documentation
This documentation is part of the manufacturer/service documentation for SINAMICS. All of
the documents are available individually.
Please contact your local Siemens office for further information about other available
SINAMICS publications.
For the sake of simplicity, this documentation does not contain comprehensive detailed
information about all types of the product and cannot cover every conceivable case of
installation, operation, or maintenance.
The contents of this documentation are not part of an earlier or existing agreement, a
promise, or a legal agreement, nor do they change this. The Purchase Agreement contains
the complete and exclusive obligations of Siemens, including the warranty provisions. These
contractual warranty provisions are neither extended nor curbed as a result of the
statements made in this documentation.
Audience
This documentation is aimed at machine manufacturers, plant engineers, commissioning
engineers, and service personnel who use SINAMICS.
Objective
This manual describes the hardware components and design of the SINAMICS S120
Cabinet Modules. It provides information about installation, electrical connection, and cabinet
design.

Preface
S120 Cabinet Modules Equipment Manual
6 Manual, (GH5), 10/2008, A5E00427098A
Technical support
If you have any questions, please contact our hotline:
European and African time zones
Phone: [phone] - 222
Fax: [phone] - 223
Internet: http://www.siemens.com/automation/support-request
Time zone Asia/Pacific
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
America time zone
Phone: [phone]
Fax: [phone]
E-mail: techsupport.s[email protected]
Note
Country-specific telephone numbers for technical support are provided at the following
Internet address:
http://www.automation.siemens.com/partners
"Calls are subject to charge (e.g. € 0.14/min from fixed lines within Germany). Tariffs of other
telephone providers may differ."
Internet address
Up-to-date information about our products can be found on the Internet at:
http://www.siemens.com
For information about SINAMICS S120 Cabinet Modules, go to:
http://www.siemens.com/sinamics-s120-cabinet-modules

S120 Cabinet Modules Equipment Manual
Manual, (GH5), 10/2008, A5E00427098A 7
Table of contents
Preface ...................................................................................................................................................... 5
1 Safety information.................................................................................................................................... 15
1.1 Requirements...............................................................................................................................15
1.2 Electrostatic sensitive devices (ESD) ..........................................................................................16
1.3 Safety information ........................................................................................................................17
1.4 Residual risks...............................................................................................................................19
2 System overview...................................................................................................................................... 21
2.1 Overview ......................................................................................................................................21
2.2 Field of application .......................................................................................................................23
2.3 Benefits ........................................................................................................................................23
2.4 Line Modules................................................................................................................................24
2.4.1 Basic Line Modules......................................................................................................................24
2.4.2 Smart Line Modules .....................................................................................................................25
2.4.3 Active Line Modules.....................................................................................................................26
2.5 DC link components.....................................................................................................................27
2.5.1 Braking Modules as an option for a Motor Module or a Line Module ..........................................27
2.5.2 Central Braking Modules..............................................................................................................27
2.6 Motor Modules .............................................................................................................................28
2.6.1 Booksize Base Cabinets with Booksize Cabinet Kits ..................................................................28
2.6.2 Chassis Cabinets .........................................................................................................................28
2.7 Auxiliary Power Supply Modules..................................................................................................28
2.8 System structure ..........................................................................................................................28
2.9 System data .................................................................................................................................29
2.10 Overview of options .....................................................................................................................31
3 Mechanical installation............................................................................................................................. 33
3.1 Important notes ............................................................................................................................33
3.2 Mechanical installation: Checklist ................................................................................................35
3.3 Mechanical installation.................................................................................................................37
3.3.1 Important safety precautions........................................................................................................37
3.3.2 Preparatory steps.........................................................................................................................37
3.3.3 Lifting the cabinet units off the transport pallet and installing them.............................................40
3.3.4 Disassembling the crane transport assembly ..............................................................................41
3.3.5 Connection to the foundation.......................................................................................................41
3.3.6 Connection for side-by-side installation of cabinet units..............................................................42
4 Electrical installation ................................................................................................................................ 43
4.1 Safety information ........................................................................................................................43
4.2 Electrical installation: Checklist....................................................................................................44

Table of contents
S120 Cabinet Modules Equipment Manual
8 Manual, (GH5), 10/2008, A5E00427098A
4.3 Introduction to EMC .................................................................................................................... 49
4.4 EMC-compliant design ................................................................................................................ 53
4.5 Connections ................................................................................................................................ 56
4.5.1 PE busbar.................................................................................................................................... 57
4.5.1.1 General information..................................................................................................................... 57
4.5.1.2 Connecting the PE busbar when cabinet units are installed side-by-side .................................. 58
4.5.1.3 Connecting the PE busbar in accordance with the plant-side grounding concept...................... 59
4.5.1.4 Connecting external cables to the PE busbar............................................................................. 59
4.5.2 DC busbar ................................................................................................................................... 60
4.5.2.1 General information..................................................................................................................... 60
4.5.2.2 Connecting the DC busbar when cabinet units are installed side-by-side.................................. 60
4.5.2.3 Connecting DC busbars to the power unit .................................................................................. 63
4.5.3 Auxiliary voltage busbar system ................................................................................................. 64
4.5.3.1 General information..................................................................................................................... 64
4.5.3.2 Connection overview................................................................................................................... 65
4.5.3.3 Connecting the auxiliary voltage busbar system when cabinet units are installed side-by-
side.............................................................................................................................................. 66
4.5.3.4 Connecting to the infeed ............................................................................................................. 67
4.5.4 Connecting the motor cables ...................................................................................................... 68
4.5.5 Line/power connections .............................................................................................................. 71
4.5.6 Adjusting the fan voltage............................................................................................................. 72
4.5.7 Operating Cabinet Modules on an isolated-neutral supply system (IT system) ......................... 74
4.5.8 Signal connections ...................................................................................................................... 74
4.5.9 Other connections ....................................................................................................................... 74
4.5.10 Cable routing............................................................................................................................... 75
4.5.10.1 General information..................................................................................................................... 75
4.5.10.2 Cable routing for Line Connection Modules................................................................................ 76
4.5.10.3 Cable routing for Basic Line Modules ......................................................................................... 79
4.5.10.4 Cable routing for Smart Line Modules ........................................................................................ 83
4.5.10.5 Cable routing for Active Line Modules ........................................................................................ 87
4.5.10.6 Cable routing for Booksize Base Cabinets + Booksize Cabinet Kit............................................ 94
4.5.10.7 Cable routing for Motor Modules in chassis format .................................................................... 94
4.5.10.8 Cable routing for Central Braking Modules............................................................................... 100
4.5.10.9 Cable routing for Auxiliary Power Supply Modules................................................................... 102
4.5.10.10 Safety and EMC ........................................................................................................................ 104
5 Cabinet Modules.................................................................................................................................... 105
5.1 Line Connection Modules.......................................................................................................... 105
5.1.1 General information................................................................................................................... 105
5.1.2 Description ................................................................................................................................ 105
5.1.2.1 Fuse switch disconnector (input current ≤ 800 A)..................................................................... 109
5.1.2.2 Circuit breaker (input current > 800 A)...................................................................................... 109
5.1.2.3 Terminal block -X40 – External 230 V AC auxiliary infeed ....................................................... 111
5.1.3 Versions of Line Connection Modules ...................................................................................... 112
5.1.3.1 Version L42 for Active Line Modules ........................................................................................ 112
5.1.3.2 Version L43 for Basic Line Modules ......................................................................................... 113
5.1.3.3 Version L44 for Smart Line Modules......................................................................................... 115
5.1.4 Options...................................................................................................................................... 116
5.1.5 Technical data........................................................................................................................... 117
5.1.6 Derating data............................................................................................................................. 121
5.2 Basic Line Modules ................................................................................................................... 123
5.2.1 General information................................................................................................................... 123
5.2.2 Description ................................................................................................................................ 123
5.2.3 Options...................................................................................................................................... 128

Table of contents
S120 Cabinet Modules Equipment Manual
Manual, (GH5), 10/2008, A5E00427098A 9
5.2.4 Technical data............................................................................................................................129
5.2.5 Derating data..............................................................................................................................133
5.3 Smart Line Modules ...................................................................................................................135
5.3.1 General information ...................................................................................................................135
5.3.2 Description .................................................................................................................................135
5.3.3 Options.......................................................................................................................................141
5.3.4 Technical data............................................................................................................................142
5.3.5 Derating data..............................................................................................................................146
5.4 Active Line Modules...................................................................................................................148
5.4.1 General information ...................................................................................................................148
5.4.2 Description .................................................................................................................................148
5.4.3 Options.......................................................................................................................................156
5.4.4 Technical data............................................................................................................................157
5.4.5 Derating data..............................................................................................................................162
5.5 Motor Modules in booksize format.............................................................................................164
5.5.1 General information ...................................................................................................................164
5.5.2 Description .................................................................................................................................164
5.5.3 Options.......................................................................................................................................170
5.5.4 Customer interface -X55.1.........................................................................................................171
5.5.5 Technical data............................................................................................................................172
5.5.6 Overload capability ....................................................................................................................176
5.5.7 Derating data..............................................................................................................................177
5.6 Motor Modules in chassis format ...............................................................................................178
5.6.1 General information ...................................................................................................................178
5.6.2 Description .................................................................................................................................178
5.6.3 Options.......................................................................................................................................185
5.6.4 Customer interface -X55 ............................................................................................................186
5.6.5 Technical data............................................................................................................................188
5.6.6 Overload capability ....................................................................................................................198
5.6.7 Derating data..............................................................................................................................199
5.7 Central Braking Modules............................................................................................................202
5.7.1 General information ...................................................................................................................202
5.7.2 Description .................................................................................................................................202
5.7.3 Options.......................................................................................................................................207
5.7.4 Interfaces ...................................................................................................................................208
5.7.5 Technical data............................................................................................................................213
5.7.6 Braking resistor ..........................................................................................................................215
5.7.6.1 Description .................................................................................................................................215
5.7.6.2 Safety information ......................................................................................................................215
5.7.6.3 Duty cycle...................................................................................................................................216
5.7.6.4 Interfaces on the braking resistor...............................................................................................217
5.7.6.5 Configuring the "Overtemperature" checkback..........................................................................217
5.7.6.6 Technical data............................................................................................................................218
5.8 Auxiliary Power Supply Modules................................................................................................221
5.8.1 General information ...................................................................................................................221
5.8.2 Description .................................................................................................................................221
5.8.3 Options.......................................................................................................................................225
5.8.4 Fuse switch disconnector (-Q1) .................................................................................................226
5.8.5 Customer interfaces for supplying power to an additional auxiliary voltage busbar system .....226
5.8.6 Transformer (-T11) for generating the auxiliary voltage 230 V AC............................................227
5.8.7 Auxiliary voltage busbar system ................................................................................................229
5.8.8 Technical data............................................................................................................................230

Table of contents
S120 Cabinet Modules Equipment Manual
10 Manual, (GH5), 10/2008, A5E00427098A
5.8.9 Derating data............................................................................................................................. 231
6 Maintenance and servicing .................................................................................................................... 233
6.1 Chapter content......................................................................................................................... 233
6.2 Cleaning the cabinet ................................................................................................................. 233
6.3 Servicing the cabinet................................................................................................................. 234
6.4 Replacing components.............................................................................................................. 235
6.4.1 General information................................................................................................................... 235
6.4.2 Safety information ..................................................................................................................... 236
6.4.3 Installation device for power blocks .......................................................................................... 237
6.4.4 Replacing the filter mats............................................................................................................ 238
6.4.5 Replacing power units............................................................................................................... 240
6.4.6 Replacing the power block for chassis format .......................................................................... 242
6.4.6.1 Replacing the power block, Basic Line Module, frame size FB................................................ 242
6.4.6.2 Replacing the power block, Basic Line Module, frame sizes GB and GD ................................ 244
6.4.6.3 Replacing the power block, Active Line Module, and Motor Module, frame size FX................ 246
6.4.6.4 Replacing the power block, Smart Line Module, Active Line Module, and Motor Module,
frame size GX ........................................................................................................................... 249
6.4.6.5 Replacing the power block, Smart Line Module, Active Line Module, and Motor Module,
frame size HX – left power block...............................................................................................252
6.4.6.6 Replacing the power block, Smart Line Module, Active Line Module, and Motor Module,
frame size HX - right power block ............................................................................................. 255
6.4.6.7 Replacing the power block, Smart Line Module, Active Line Module, and Motor Module,
frame size JX ............................................................................................................................ 258
6.4.7 Replacing the Motor Module for booksize format ..................................................................... 260
6.4.8 Replacing the Control Interface Board...................................................................................... 261
6.4.8.1 Replacing the Control Interface Board, Basic Line Module, frame size FB.............................. 261
6.4.8.2 Replacing the Control Interface Board, Basic Line Module, frame sizes GB and GD.............. 264
6.4.8.3 Replacing the Control Interface Board, Active Line Module and Motor Module, frame size FX ... 267
6.4.8.4 Replacing the Control Interface Board, Smart Line Module, Active Line Module, and
Motor Module, frame size GX ................................................................................................... 269
6.4.8.5 Replacing the Control Interface Board, Smart Line Module, Active Line Module, and
Motor Module, frame size HX ................................................................................................... 271
6.4.8.6 Replacing the Control Interface Board, Smart Line Module, Active Line Module, and
Motor Module, frame size JX ....................................................................................................273
6.4.9 Replacing the Control Unit ........................................................................................................ 275
6.4.9.1 Replacing the Control Unit for Basic Line Modules, Smart Line Modules, Active Line
Modules, and Motor Modules in chassis format........................................................................ 275
6.4.9.2 Replacing the Control Unit for Booksize Cabinet Kit ................................................................ 276
6.4.10 Replacing the fans .................................................................................................................... 277
6.4.10.1 Replacing the fan, Basic Line Module, frame sizes FB, GB, and GD....................................... 277
6.4.10.2 Replacing the fan, Smart Line Module, Active Line Module, and Motor Module, frame
sizes FX, GX ............................................................................................................................. 279
6.4.10.3 Replacing the fan, Smart Line Module, Active Line Module, and Motor Module, frame size
HX, left power block .................................................................................................................. 281
6.4.10.4 Replacing the fan, Smart Line Module, Active Line Module, and Motor Module, frame size
HX - right power block............................................................................................................... 283
6.4.10.5 Replacing the fan, Smart Line Module, Active Line Module, and Motor Module, frame size
JX .............................................................................................................................................. 285
6.4.10.6 Replacing the fan, Active Interface Module, frame size FI ....................................................... 287
6.4.10.7 Replacing the fan, Active Interface Module, frame size GI....................................................... 289
6.4.10.8 Replacing the fan, Active Interface Module, frame size HI ....................................................... 291
6.4.10.9 Replacing the fan, Active Interface Module, frame size JI........................................................ 293
6.4.10.10 Replacing the fan for Booksize Cabinet Kit............................................................................... 295

Table of contents
S120 Cabinet Modules Equipment Manual
Manual, (GH5), 10/2008, A5E00427098A 11
6.4.11 Replacing the fuses ...................................................................................................................298
6.4.11.1 Replacing the fuses for the auxiliary power supply....................................................................298
6.4.11.2 Replacing fuses in the fuse switch disconnector for Booksize Cabinet Kit ...............................299
6.4.11.3 Replacing the fuses (F71 - F73) in the Line Connection Module ..............................................300
6.4.11.4 Replacing the DC fuses for Motor Module in chassis format, frame sizes FX and GX .............301
6.4.11.5 Replacing the DC fuses for Motor Module in chassis format, frame sizes HX and JX..............302
6.4.11.6 Replacing the encapsulated fuses.............................................................................................304
6.4.11.7 Replacing the LV HRC fuses .....................................................................................................304
6.4.12 Replacing the DC interface (option L37) for Booksize Cabinet Kit ............................................305
6.4.13 Replacing the pre-charging resistors of the DC interface (option L37) for Booksize
Cabinet Kit..................................................................................................................................306
6.4.14 Replacing the backup battery for the cabinet operator panel....................................................307
6.5 Reforming the DC link capacitors ..............................................................................................309
7 Diagnostics............................................................................................................................................ 311
7.1 Chapter content .........................................................................................................................311
7.2 LEDs on the CU320 Control Unit...............................................................................................312
7.3 LEDs on the CBE20 Communication Board..............................................................................313
7.4 LEDs on the Control Interface Board in the Basic Line Module ................................................315
7.5 LEDs on the Control Interface Board in the Smart Line Module................................................316
7.6 LEDs on the Control Interface Board in the Active Line Module ...............................................317
7.7 LEDs on the Control Interface Board in the Motor Module in chassis format............................318
7.8 LEDs on the Motor Module in booksize format..........................................................................319
7.9 LEDs on the Voltage Sensing Module (VSM) in the Active Interface Module ...........................320
7.10 LEDs on the Central Braking Module ........................................................................................320
7.11 LEDs on the SMC10 Sensor Module.........................................................................................321
7.12 LEDs on the SMC20 Sensor Module.........................................................................................321
7.13 LEDs on the SMC30 Sensor Module.........................................................................................322
7.14 LEDs on the SITOP power supply unit ......................................................................................322
8 Options .................................................................................................................................................. 323
8.1 Safety information ......................................................................................................................323
8.2 D14, Preliminary copy of customer documentation ...................................................................324
8.3 G20, CBC10 Communication Board..........................................................................................325
8.4 G33, CBE20 Communication Board ..........................................................................................328
8.5 K08, AOP30 advanced operator panel ......................................................................................331
8.6 K46, SMC10 Sensor Module Cabinet-Mounted for resolvers....................................................333
8.6.1 General information ...................................................................................................................333
8.6.2 Safety information ......................................................................................................................334
8.6.3 Interfaces ...................................................................................................................................335
8.6.4 Connection example ..................................................................................................................337
8.7 K48, SMC20 Sensor Module Cabinet-Mounted for sin/cos incremental encoder or EnDat
absolute encoder .......................................................................................................................338
8.7.1 General information ...................................................................................................................338
8.7.2 Safety information ......................................................................................................................338

Table of contents
S120 Cabinet Modules Equipment Manual
12 Manual, (GH5), 10/2008, A5E00427098A
8.7.3 Interfaces................................................................................................................................... 339
8.7.4 Connection example ................................................................................................................. 341
8.8 K50, SMC30 Sensor Module Cabinet-Mounted for TTL, HTL, and SSI encoders ................... 342
8.8.1 General information................................................................................................................... 342
8.8.2 Safety information ..................................................................................................................... 346
8.8.3 Interfaces................................................................................................................................... 347
8.8.4 Connection example ................................................................................................................. 350
8.9 K51, Voltage Sensing Module for determining the motor speed and the phase angle ............ 351
8.10 K75, Second auxiliary voltage busbar system .......................................................................... 353
8.11 K76, auxiliary voltage generating unit in the Line Connection Module ..................................... 354
8.12 K82, terminal module for activating safety functions "Safe Torque Off" and "Safe Stop 1"...... 356
8.13 K90/K91, Control Unit with CompactFlash card with/without performance enhancement ....... 357
8.13.1 General information................................................................................................................... 357
8.13.2 Description ................................................................................................................................ 357
8.13.3 Customer terminal block -X55...................................................................................................358
8.13.4 CompactFlash card ................................................................................................................... 363
8.13.4.1 Using the CompactFlash card................................................................................................... 364
8.13.4.2 Data functions ........................................................................................................................... 365
8.13.4.3 Saving the CompactFlash card parameter settings.................................................................. 365
8.14 L08/L09, motor reactor / 2 motor reactors in series.................................................................. 366
8.15 L10, dv/dt filter plus Voltage Peak Limiter................................................................................. 369
8.16 L13, main contactor for Line Connection Modules < 800 A...................................................... 371
8.17 L22, supplied as standard without line reactor.......................................................................... 372
8.18 L25, circuit breaker in withdrawable unit design ....................................................................... 373
8.19 L34, output-side circuit breaker................................................................................................. 374
8.19.1 General information................................................................................................................... 374
8.19.2 Switching cycles for the output-side circuit breaker.................................................................. 376
8.19.3 Overview diagram of option L34 ............................................................................................... 377
8.19.4 Parameter assignment.............................................................................................................. 378
8.19.4.1 Parameterization with free function blocks ............................................................................... 378
8.19.4.2 Parameterization with DCC (Drive Control Chart) .................................................................... 381
8.20 L37, DC interface incl. pre-charging input circuit for the relevant DC link capacitance............ 382
8.20.1 General information................................................................................................................... 382
8.20.2 DC interface incl. pre-charging for Motor Module in chassis format......................................... 382
8.20.2.1 Important safety precautions..................................................................................................... 384
8.20.2.2 Accessibility of the DC connection to the Motor Module........................................................... 386
8.20.2.3 Measuring points for verifying isolation from supply................................................................. 387
8.20.2.4 Installation ................................................................................................................................. 389
8.20.2.5 DC interface, principle of operation...........................................................................................389
8.20.2.6 Commissioning the DC interface with option K90/K91 ............................................................. 390
8.20.2.7 Commissioning the DC interface without option K90/K91 ........................................................ 390
8.20.3 DC interface incl. pre-charging for Booksize Cabinet Kit.......................................................... 392
8.20.3.1 Important safety precautions..................................................................................................... 392
8.20.3.2 DC interface, principle of operation...........................................................................................393
8.20.3.3 Commissioning the DC interface with option K90/K91 ............................................................. 393
8.20.3.4 Commissioning the DC interface without option K90/K91 ........................................................ 394
8.21 L41, current transformer upstream of main switch ................................................................... 395

Table of contents
S120 Cabinet Modules Equipment Manual
Manual, (GH5), 10/2008, A5E00427098A 13
8.22 L42/L43/L44, Line Connection Module for Active Line Modules/Basic Line Modules/Smart
Line Modules..............................................................................................................................396
8.23 L45, EMERGENCY STOP pushbutton in the cabinet door .......................................................397
8.24 L46/L47, grounding switch upstream/downstream of main breaker..........................................398
8.24.1 Grounding switch upstream of main breaker (option L46).........................................................398
8.24.2 Grounding switch downstream of main breaker (option L47) ....................................................399
8.25 L51, holder for ARC detector .....................................................................................................400
8.26 L55, cabinet anti-condensation heating .....................................................................................402
8.27 L61/L62, L64/L65, braking units.................................................................................................403
8.27.1 General information ...................................................................................................................403
8.27.2 Interfaces ...................................................................................................................................404
8.27.3 S1 - Threshold switch ................................................................................................................405
8.27.4 Braking Module ..........................................................................................................................407
8.27.5 Example connection of Braking Module ....................................................................................410
8.27.6 Braking resistors ........................................................................................................................410
8.27.7 Technical data............................................................................................................................414
8.28 L87, insulation monitoring..........................................................................................................416
8.29 M06, base 100 mm high, RAL 7022 ..........................................................................................419
8.30 M07, cable-marshalling compartment 200 mm high, RAL 7035................................................420
8.31 M21, degree of protection IP21..................................................................................................422
8.31.1 General information ...................................................................................................................422
8.31.2 Mounting ....................................................................................................................................423
8.32 M23/M43/M54, degree of protection IP23/IP43/IP54 ................................................................425
8.32.1 General information ...................................................................................................................425
8.32.2 Mounting ....................................................................................................................................426
8.33 M26/M27, side panels mounted on right and left.......................................................................428
8.34 M59, closed cabinet door, air inlet from below through floor opening .......................................429
8.35 M60, additional shock protection ...............................................................................................430
8.36 M70, EMC shield bus.................................................................................................................431
8.36.1 General information ...................................................................................................................431
8.36.2 Connecting the cables to the EMC shield bus ...........................................................................431
8.37 M80 to M87, DC busbar system ................................................................................................432
8.37.1 General information ...................................................................................................................432
8.37.2 Safety information ......................................................................................................................433
8.38 M90, crane transport assembly (top-mounted)..........................................................................434
8.39 N52, DC link fuses for Basic Line Modules................................................................................435
8.40 P10, measuring instrument for line values (installed in the cabinet doors) ...............................436
8.41 P11, measuring instrument for line values with PROFIBUS connection (installed in the
cabinet door) ..............................................................................................................................437
8.42 Y11, factory assembly into transport units.................................................................................438
A Appendix................................................................................................................................................ 439
A.1 List of abbreviations ...................................................................................................................440
Index...................................................................................................................................................... 449

S120 Cabinet Modules Equipment Manual
Manual, (GH5), 10/2008, A5E00427098A 15
Safety information 1
1.1 Requirements
DANGER
The cabinet units described in this manual are used in industrial high-voltage installations.
During operation, this equipment contains rotating and live, bare parts. For this reason, it
could cause severe injury or significant material damage if the required covers are removed
without authorization, if the equipment is used or operated incorrectly, or if it has not been
properly maintained.
When the machines are used in non-industrial areas, the installation location must be
protected against unauthorized access (by protective fencing, for example) and appropriate
signs must be displayed.
The persons responsible for the safety of the plant are under an obligation to ensure that:
● The basic planning work for the plant and the transport, assembly, installation,
commissioning, maintenance, and repair work is carried out by qualified personnel and/or
checked by the experts responsible.
● All the documentation for the plant is always readily at hand.
● The technical data and specifications regarding the applicable installation, connection,
environmental, and operating conditions are always observed.
● The plant-specific assembly and safety guidelines are observed and personal protection
equipment is used.
● No work whatsoever is carried out by unqualified personnel either on this equipment or in
its vicinity.
These instructions are intended for qualified personnel and only contain information and
notes relating to the intended purpose of the machines.
The operating instructions and the machine documentation are available in the languages
specified in the supply contracts.
Note
We recommend engaging the support and services of your local Siemens service center for
all planning, installation, commissioning, and maintenance work.

Safety information
1.2 Electrostatic sensitive devices (ESD)
S120 Cabinet Modules Equipment Manual
16 Manual, (GH5), 10/2008, A5E00427098A
1.2 Electrostatic sensitive devices (ESD)
CAUTION
The Cabinet Modules contain electrostatic sensitive devices. These components can be
easily destroyed if not handled properly. Observe the following notes if you nevertheless
have to work with electronic modules:
•You should only touch electronic modules if absolutely necessary.
•If you do have to touch modules, your body must be electrically discharged first. For this
purpose, you are advised to wear a grounded ESD wristband.
•Modules must not come into contact with highly insulating materials (such as plastic
parts, insulated desktops, articles of clothing manufactured from man-made fibers).
•Modules must only be set down on conductive surfaces.
•Modules and components should only be stored and transported in conductive
packaging (such as metalized plastic boxes or metal containers).
•If the packaging is not conductive, the modules must be wrapped with a conductive
packaging material (such as conductive foam rubber or household aluminum foil), prior
to placing them in the packaging.
The necessary ESD protective measures are elucidated once again in the following
illustration:
g ga
b
e
d
c
d
a
c
d
b
c a
e
f
f f f f
6LWWLQJ 6WDQGLQJ 6WDQGLQJVLWWLQJ
Figure 1-1 EMC protective measures
● a = conductive floor surface
● b = ESD table
● c = ESD shoes
● d = ESD overall
● e = ESD wristband
● f = ground connection for cabinet units
● g = connection to conductive floor

Safety information
1.3 Safety information
S120 Cabinet Modules Equipment Manual
Manual, (GH5), 10/2008, A5E00427098A 17
1.3 Safety information
DANGER
Commissioning must not start until you have ensured that the machine in which the
components described here are to be installed complies with Directive 98/37/EC.
SINAMICS S120 Cabinet Modules must only be commissioned by suitably qualified
personnel.
The personnel must take into account the information provided in the technical customer
documentation for the product, and be familiar with and observe the specified danger and
warning notices.
Operational electrical equipment and motors have parts and components which are at
hazardous voltage levels.
When the machine or system is operated, hazardous axis movements can occur.
All work on the electrical system must be carried out when the system has been
disconnected from the power supply and is in a de-energized condition.
DANGER
When carrying out any kind of work on electrical devices, the following "five safety rules"
must always be observed:
•Disconnect from power supply.
•Protect against reconnection.
•Make sure that the equipment is de-energized.
•Ground and short-circuit.
•Cover or enclose adjacent components that are still live.
WARNING
Safe, problem-free operation of SINAMICS S120 Cabinet Modules requires proper
transportation, storage, setup, and installation, as well as careful operation and
maintenance.
The details in the catalogs and proposals also apply to the design of special equipment
versions.
In addition to the danger and warning information provided in the technical customer
documentation, the applicable national, local, and plant-specific regulations and
requirements must be taken into account.
Only protective extra-low voltages (PELVs) that comply with EN 60204-1 may be connected
to any connections and terminals between 0 and 48 V.

Safety information
1.3 Safety information
S120 Cabinet Modules Equipment Manual
18 Manual, (GH5), 10/2008, A5E00427098A
CAUTION
As part of routine tests, SINAMICS S120 Cabinet Modules undergo a voltage test in
accordance with EN 61800-5-1. Prior to performing the voltage test for electrical equipment
of industrial machines in accordance with EN 60204-1, Section 19.4, all connections of the
Cabinet Modules must be disconnected/removed to prevent the units from being damaged.
Motors must be connected according to the circuit diagrams provided.
Note
When operated in dry operating areas, SINAMICS S120 Cabinet Modules with three-phase
induction motors conform to Low Voltage Directive 2006/95/EC.
SINAMICS S120 Cabinet Modules with three-phase induction motors conform to EMC
Directive 2004/108/EC in the configurations specified in the associated EC Declaration of
Conformity, provided that the configuration guidelines and actions are consistently applied.
CAUTION
Operating the equipment in the immediate vicinity (< 1.5 m) of mobile telephones with a
transmitter power of > 1 W may lead to incorrect operation.

Safety information
1.4 Residual risks
S120 Cabinet Modules Equipment Manual
Manual, (GH5), 10/2008, A5E00427098A 19
1.4 Residual risks
Residual risks of power drive systems
When carrying out a risk assessment of the machine/plant in accordance with the EU
Machinery Directive, the machine manufacturer/plant operator must consider the following
residual risks associated with the control and drive components of a power drive system
(PDS).
1. Unintentional movements of driven machine components during commissioning,
operation, maintenance, and repairs caused by, for example:
– Hardware defects and/or software errors in the sensors, controllers, actuators, and
connection technology
– Response times of the controller and drive
– Operating and/or ambient conditions not within the scope of the specification
– Parameterization, programming, cabling, and installation errors
– Use of radio devices / cellular phones in the immediate vicinity of the controller
– External influences / damage
2. Exceptional temperatures as well as emissions of light, noise, particles, or gas caused by,
for example:
– Component malfunctions
– Software errors
– Operating and/or ambient conditions not within the scope of the specification
– External influences / damage
3. Hazardous shock voltages caused by, for example:
– Component malfunctions
– Influence of electrostatic charging
– Induction of voltages in moving motors
– Operating and/or ambient conditions not within the scope of the specification
– Condensation / conductive contamination
– External influences / damage
4. Electrical, magnetic and electromagnetic fields generated in operation that can pose a
risk to people with a pacemaker, implants or metal replacement joints, etc. if they are too
close.
5. Release of environmental pollutants or emissions as a result of improper operation of the
system and/or failure to dispose of components safely and correctly.
For more information about residual risks of the Power Drive System components, see the
relevant chapters in the technical user documentation.

Safety information
1.4 Residual risks
S120 Cabinet Modules Equipment Manual
20 Manual, (GH5), 10/2008, A5E00427098A
WARNING
Electromagnetic fields "electro smog"
Electromagnetic fields are generated by the operation of electrical power engineering
installations such as transformers, converters or motors.
Electromagnetic fields can interfere with electronic devices, which could cause them to
malfunction. For example, the operation of pacemakers can be impaired, potentially leading
to damage to a person's health or even death. It is therefore forbidden for persons with
pacemakers to enter these areas.
The plant operator is responsible for taking appropriate measures (labels and hazard
warnings) to adequately protect operating personnel and others against any possible risk.
•Observe the relevant nationally applicable health and safety regulations. In Germany,
"electromagnetic fields" are subject to regulations BGV B11 and BGR B11 stipulated by
the German statutory industrial accident insurance institution.
•Display adequate hazard warning notices.
•Place barriers around hazardous areas.
•Take measures, e.g. using shields, to reduce electromagnetic fields at their source.
•Make sure that personnel are wearing the appropriate protective gear.
