SINAMICS
Safety Integrated
Function Manual · 11/2009
SINAMICS S120
s

Safety Integrated
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
SINAMICS
S120
Safety Integrated
Function Manual
Valid for:
Firmware Version 4.3 SP1
(FHS), 11/2009
6SL3097-4AR00-0BP0
Preface
Standards and regulations
1
General information about
SINAMICS Safety Integrated
2
System features
3
Safety Integrated Basic
Functions
4
Safety Integrated Extended
Functions
5
Control of the safety
functions
6
Commissioning
7
Application examples
8
Acceptance tests and
acceptance reports
9
Appendix A
A

Legal information
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.
CAUTION
without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.
NOTICE
indicates that an unintended result or situation can occur if the corresponding information is not taken into
account.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation for the specific task, in particular its warning notices and
safety instructions. Qualified personnel are those who, based on their training and experience, are capable of
identifying risks and avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be adhered to. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of the
owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
Order number: 6SL3097-4AR00-0BP0
Ⓟ 03/2010
Copyright © Siemens AG 2007,
2008, 2009.
Technical data subject to change

Safety Integrated
Function Manual, (FHS), 11/2009, 6SL3097-4AR00-0BP0 5
Preface
SINAMICS documentation
The SINAMICS documentation is organized in 2 parts:
● General documentation/Catalogs
● Manufacturer/service documentation
A current overview of the documentation in the available languages is provided in the
Internet:
http://www.siemens.com/motioncontrol
Select the menu items "Support" --> "Technical Documentation" --> "Overview of
Publications."
The Internet version of DOConCD (DOConWEB) is available on the Internet:
http://www.automation.siemens.com/doconweb
Information on the range of training courses and FAQs (Frequently Asked Questions) is
available on the Internet:
http://www.siemens.com/motioncontrol
Follow the menu item "Support".

Preface
Safety Integrated
6 Function Manual, (FHS), 11/2009, 6SL3097-4AR00-0BP0
Usage phases and their tools/documents (as an example)
Table 1 Usage phases and the available documents/tools
Usage phase Document/tool
Orientation SINAMICS S Sales Documentation
Planning/configuration •SIZER configuration tool
•Configuration Manuals, Motors
Decision/ordering SINAMICS S Catalogs
Installation/assembly •SINAMICS S120 Equipment Manual for Control Units and
Additional System Components
•SINAMICS S120 Equipment Manual for Booksize/
Booksize Compact Power Units
•SINAMICS S120 Equipment Manual for Chassis Power
Units
•SINAMICS S120 Equipment Manual for AC Drives
Commissioning •STARTER parameterization and commissioning tool
•SINAMICS S120 Getting Started
•SINAMICS S120 Commissioning Manual
•SINAMICS S120 CANopen Commissioning Manual
•SINAMICS S120 Function Manual
•SINAMICS S120/S150 List Manual
Usage/operation •SINAMICS S120 Commissioning Manual
•SINAMICS S120/S150 List Manual
Maintenance/servicing •SINAMICS S120 Commissioning Manual
•SINAMICS S120/S150 List Manual
References •SINAMICS S120/S150 List Manual
Target group
This documentation is intended for machine manufacturers, plant manufacturers,
commissioning engineers, and service personnel who use the SINAMICS S drive system.
Benefits
The Safety Integrated Function Manual covers all information, procedures and operations
required for commissioning safety functions and servicing of SINAMICS S120.

Preface
Safety Integrated
Function Manual, (FHS), 11/2009, 6SL3097-4AR00-0BP0 7
Search guides The following guides are provided to help you locate information in this manual:
1. Contents
2. List of abbreviations
3. Index
Standard scope
The scope of the functionality described in this document can differ from the scope of the
functionality of the drive system that is actually supplied.
● Other functions not described in this documentation might be able to be executed in the
drive system. However, no claim can be made regarding the availability of these functions
when the equipment is first supplied or in the event of servicing.
● Functions can be described in the documentation that are not available in a particular
product version of the drive system. The functionality of the supplied drive system should
only be taken from the ordering documentation.
● Extensions or changes made by the machine manufacturer must be documented by the
machine manufacturer.
For reasons of clarity, this documentation does not contain all of the detailed information on
all of the product types. This documentation cannot take into consideration every
conceivable type of installation, operation and service/maintenance.
Technical Support
In case of questions, please contact us through the following hotline:
Europe/Africa
Phone [phone] - 222
Fax [phone] - 223
0.14 €/min. from German landlines, max. 0.42 €/min for calls from a mobile phone
Internet http://www.siemens.de/automation/support-request
America
Phone [phone]
Fax [phone]
E-mail mailto:[email protected]
Asia/Pacific
Phone [phone]
Fax [phone]
E-mail mailto:support.asia.automatio[email protected]
Note
Country-specific telephone numbers for technical support are provided under the following
Internet address:
http://www.siemens.com/automation/service&support

Preface
Safety Integrated
8 Function Manual, (FHS), 11/2009, 6SL3097-4AR00-0BP0
Questions on the manual
If you have any questions (suggestions, corrections) regarding this documentation,
please fax or e-mail us at:
Fax [phone]
E-mail mailto:[email protected]
A fax form is available in the appendix of this document.
Internet address for SINAMICS
http://www.siemens.com/sinamics
Internet address for Safety Integrated
http://www.siemens.com/safety
This address contains detailed application examples for Safety Integrated.
Notation
The following notation and abbreviations are used in this documentation:
Notation for parameters (examples):
● p0918 Adjustable parameter 918
● r1024 Display parameter 1024
● p1070[1] Adjustable parameter 1070, index 1
● p2098[1].3 Adjustable parameter 2098, index 1, bit 3
● p0099[0...3] Adjustable parameter 99 indices 0 to 3
● r0945[2](3) Display parameter 945 index 2 of drive object 3
● p0795.4 Adjustable parameter 795 bit 4
Notation for faults and alarms (examples):
● F12345 Fault 12345
● A67890 Alarm 67890

Preface
Safety Integrated
Function Manual, (FHS), 11/2009, 6SL3097-4AR00-0BP0 9
ESD Notes
CAUTION
Electrostatic sensitive devices (ESD) are single components, integrated circuits or devices
that can be damaged by electrostatic fields or electrostatic discharges.
Regulations for the ESD handling:
During the handling of electronic components, pay attention to the grounding of the person,
workplace and packaging!
Electronic components may be touched by persons only when
•these persons are grounded using an ESD bracelet, or
•these persons in ESD areas with a conducting floor wear ESD shoes or ESD grounding
straps.
Electronic components should be touched only when this is unavoidable. The touching is
permitted only on the front panel or on the circuit board edge.
Electronic components must not be brought into contact with plastics or clothing made of
artificial fibers.
Electronic components may only be placed on conducting surfaces (table with ESD coating,
conducting ESD foamed material, ESD packing bag, ESD transport container).
Electronic components may not be placed near display units, monitors or televisions
(minimum distance from the screen > 10 cm).
Measurements must only be taken on boards when the measuring instrument is grounded
(via protective conductors, for example) or the measuring probe is briefly discharged before
measurements are taken with an isolated measuring device (for example, touching a bare
metal housing).

Preface
Safety Integrated
10 Function Manual, (FHS), 11/2009, 6SL3097-4AR00-0BP0
Safety notices
DANGER
•Commissioning is absolutely prohibited until it has been completely ensured that the
machine, in which the components described here are to be installed, is in full
compliance with the provisions of the EC Machinery Directive.
•SINAMICS devices and AC motors must only be commissioned by suitably qualified
personnel.
•The personnel must take into account the information provided in the technical customer
documentation for the product, and be familiar with and follow the specified danger and
warning notices.
•When electrical equipment and motors are operated, the electrical circuits automatically
conduct a dangerous voltage.
•When the machine or system is operated, hazardous axis movements can occur.
•All of the work carried-out on the electrical machine or system must be carried-out with it
in a no-voltage condition.
•SINAMICS devices with three-phase motors must only be connected to the power
supply via an AC-DC residual-current-operated device with selective switching once
verification has been provided that the SINAMICS device is compatible with the
residual-current-operated device in accordance with IEC 61800-5-1, Section 5.2.11.2.
WARNING
•The successful and safe operation of this equipment and motors is dependent on
correct transport, proper storage, installation and mounting as well as careful operator
control, service and maintenance.
•For special versions of the drive units and motors, information and data in the Catalogs
and quotations additionally apply.
•In addition to the danger and warning information provided in the technical customer
documentation, the applicable national, local, and plant-specific regulations and
requirements must be taken into account.
•Only protective extra-low voltages (PELV, DVC-A) that comply with EN 60204-1:2006
can be connected to the connections and terminals between 0 V and 48 V.
CAUTION
•The motors can have surface temperatures of over +80 °C.
•This is the reason that temperature-sensitive components, e.g. cables or electronic
components may neither be in contact nor be attached to the motor.
•When attaching the connecting cables, you must ensure that:
– they are not damaged,
– they are not under tension,
– they cannot come into contact with any rotating parts.

Preface
Safety Integrated
Function Manual, (FHS), 11/2009, 6SL3097-4AR00-0BP0 11
CAUTION
•As part of routine tests, SINAMICS devices are subject to a voltage test in accordance
with EN 61800-5-1. Before the voltage test is performed on the electrical equipment of
industrial machines to EN 60204-1:2006, Section 18.4, all connectors of SINAMICS
equipment must be disconnected/unplugged to prevent the equipment from being
damaged.
•Motors should be connected-up according to the circuit diagram provided, otherwise
they can be destroyed.
Note
When operated in dry areas, SINAMICS devices with three-phase motors conform to the
Low-Voltage Directive 2006/95/EC.

Preface
Safety Integrated
12 Function Manual, (FHS), 11/2009, 6SL3097-4AR00-0BP0

Safety Integrated
Function Manual, (FHS), 11/2009, 6SL3097-4AR00-0BP0 13
Table of contents
Preface ...................................................................................................................................................... 5
1 Standards and regulations....................................................................................................................... 17
1.1 General information .....................................................................................................................17
1.1.1 Aims .............................................................................................................................................17
1.1.2 Functional safety..........................................................................................................................18
1.2 Safety of machinery in Europe.....................................................................................................18
1.2.1 Machinery Directive .....................................................................................................................19
1.2.2 Harmonized European Standards ...............................................................................................19
1.2.3 Standards for implementing safety-related controllers ................................................................21
1.2.4 EN ISO 13849-1:2006 (previously EN 954-1)..............................................................................23
1.2.5 EN 62061 .....................................................................................................................................24
1.2.6 Series of standards EN 61508 (VDE 0803) .................................................................................26
1.2.7 Risk analysis/assessment............................................................................................................27
1.2.8 Risk reduction ..............................................................................................................................29
1.2.9 Residual risk.................................................................................................................................29
1.3 Machine safety in the USA...........................................................................................................30
1.3.1 Minimum requirements of the OSHA ...........................................................................................30
1.3.2 NRTL listing..................................................................................................................................30
1.3.3 NFPA 79.......................................................................................................................................31
1.3.4 ANSI B11 .....................................................................................................................................31
1.4 Machine safety in Japan ..............................................................................................................32
1.5 Equipment regulations .................................................................................................................32
1.6 Other safety-related issues..........................................................................................................33
1.6.1 Information sheets issued by the Employer's Liability Insurance Association.............................33
1.6.2 Additional references ...................................................................................................................33
2 General information about SINAMICS Safety Integrated .........................................................................35
2.1 Supported functions .....................................................................................................................35
2.2 Preconditions for the Safety Extended Functions........................................................................37
2.3 Controlling the Safety Integrated functions..................................................................................38
2.4 Parameter, checksum, version, password...................................................................................39
2.5 DRIVE-CLiQ rules for Safety Integrated Functions .....................................................................42
3 System features....................................................................................................................................... 43
3.1 Certification ..................................................................................................................................43
3.2 Safety instructions........................................................................................................................43
3.3 Probability of failure of the safety functions .................................................................................46
3.4 Response times ...........................................................................................................................47
3.5 Residual risk.................................................................................................................................50

Table of contents
Safety Integrated
14 Function Manual, (FHS), 11/2009, 6SL3097-4AR00-0BP0
4 Safety Integrated Basic Functions ........................................................................................................... 53
4.1 Safe Torque Off (STO)................................................................................................................ 53
4.2 Safe Stop 1 (SS1, time controlled).............................................................................................. 57
4.3 Safe Brake Control (SBC)........................................................................................................... 59
4.4 Safety faults ................................................................................................................................ 62
4.5 Forced dormant error detection .................................................................................................. 64
5 Safety Integrated Extended Functions..................................................................................................... 65
5.1 Parking note ................................................................................................................................ 65
5.2 Safe Torque Off (STO)................................................................................................................ 65
5.2.1 Safe Torque Off with encoder ..................................................................................................... 65
5.2.2 Encoderless Safe Torque Off...................................................................................................... 65
5.3 Safe Stop 1 (SS1) ....................................................................................................................... 66
5.3.1 Safe Stop 1 with encoder (time and acceleration controlled) ..................................................... 66
5.3.2 Encoderless Safe Stop 1 (time and speed controlled)................................................................ 68
5.3.3 Integration ................................................................................................................................... 70
5.4 Safe Stop 2 (SS2) ....................................................................................................................... 71
5.5 Safe Operating Stop (SOS)......................................................................................................... 73
5.6 Safely-Limited Speed (SLS)........................................................................................................ 75
5.6.1 Safely-Limited Speed with encoder ............................................................................................ 75
5.6.2 Encoderless Safely Limited Speed ............................................................................................. 77
5.6.3 EPOS and Safely-Limited Speed................................................................................................ 80
5.7 Safe Speed Monitor (SSM) ......................................................................................................... 81
5.8 Safe Acceleration Monitor (SBR) ................................................................................................ 84
5.9 Safe Brake Ramp (SBR)............................................................................................................. 86
5.10 Safety faults ................................................................................................................................ 88
5.11 Message buffer ........................................................................................................................... 92
5.12 Safe actual value acquisition ...................................................................................................... 94
5.13 Forced dormant error detection ................................................................................................ 100
6 Control of the safety functions ............................................................................................................... 105
6.1 Overview of F-DI/F-DOs and of their structure ......................................................................... 105
6.2 Control signals by way of terminals on the Control Unit and Motor/Power Module.................. 106
6.3 Control via TM54F..................................................................................................................... 110
6.3.1 TM54F design ........................................................................................................................... 110
6.3.2 F-DI function.............................................................................................................................. 111
6.3.3 Function of the F-DO................................................................................................................. 113
6.4 Activation via PROFIsafe .......................................................................................................... 115
6.4.1 Setting up PROFIsafe communication...................................................................................... 115
6.4.2 Structure of telegram 30............................................................................................................ 116
6.4.2.1 Structure of telegram 30 (Basic Functions)............................................................................... 116
6.4.2.2 Structure of telegram 30 (Extended Functions) ........................................................................ 118

Table of contents
Safety Integrated
Function Manual, (FHS), 11/2009, 6SL3097-4AR00-0BP0 15
7 Commissioning ...................................................................................................................................... 121
7.1 Safety Integrated firmware versions ..........................................................................................121
7.2 Commissioning Safety Integrated functions ..............................................................................122
7.2.1 Prerequisites for commissioning the Safety Integrated function................................................123
7.2.2 Default settings for commissioning Safety Integrated functions without an encoder ................124
7.2.3 Standard commissioning of Safety Integrated functions ...........................................................126
7.2.4 Setting the sampling times.........................................................................................................127
7.3 Commissioning TM54F by means of STARTER/SCOUT..........................................................129
7.3.1 Basic sequence of commissioning.............................................................................................129
7.3.2 Configuration start screen..........................................................................................................130
7.3.3 TM54F configuration ..................................................................................................................132
7.3.4 Test stop ....................................................................................................................................134
7.3.4.1 Test stop modes of the TM54F..................................................................................................134
7.3.4.2 Test stop mode 1 .......................................................................................................................135
7.3.4.3 Test stop mode 2 .......................................................................................................................136
7.3.4.4 Test stop mode 3 .......................................................................................................................137
7.3.4.5 Test stop mode parameters .......................................................................................................138
7.3.5 F-DI/F-DO configuration.............................................................................................................139
7.3.6 Control interface of the drive group ...........................................................................................141
7.4 Procedure for configuring PROFIsafe communication ..............................................................142
7.4.1 Extended Functions: Configuring PROFIsafe communication ..................................................142
7.4.2 Basic Functions: Configuring PROFIsafe communication.........................................................146
7.4.2.1 Configuring PROFIsafe via PROFIBUS.....................................................................................147
7.5 PROFIsafe via PROFINET ........................................................................................................156
7.5.1 Configuring PROFIsafe via PROFINET.....................................................................................156
7.5.2 Requirements for PROFIsafe communication ...........................................................................157
7.5.3 Configuring PROFIsafe via PROFINET.....................................................................................158
7.5.4 Initializing the drives...................................................................................................................163
7.6 PROFIsafe configuration with STARTER (Basic Functions) .....................................................163
7.7 Commissioning a linear/rotary axis............................................................................................168
7.8 Modular machine concept Safety Integrated .............................................................................171
7.9 Information pertaining to component replacements...................................................................172
7.10 Information pertaining to series commissioning.........................................................................173
8 Application examples............................................................................................................................. 175
8.1 Input/output interconnections of a safety switching device with TM54F....................................175
8.2 Application examples .................................................................................................................178
9 Acceptance tests and acceptance reports ............................................................................................. 179
9.1 Safety logbook ...........................................................................................................................184
9.2 Acceptance reports ....................................................................................................................185
9.2.1 Plant description - Documentation part 1...................................................................................185
9.2.2 Description of safety functions - Documentation Part 2.............................................................187
9.2.2.1 Function table.............................................................................................................................187
9.2.2.2 Safety Integrated functions used ...............................................................................................187
9.2.2.3 Safety Integrated functions parameterized via TM54F..............................................................189
9.2.2.4 Safety equipment .......................................................................................................................190

Table of contents
Safety Integrated
16 Function Manual, (FHS), 11/2009, 6SL3097-4AR00-0BP0
9.3 Acceptance tests....................................................................................................................... 190
9.3.1 Basic Function........................................................................................................................... 191
9.3.1.1 Safe Torque Off......................................................................................................................... 191
9.3.1.2 Safe Stop 1 ............................................................................................................................... 193
9.3.1.3 Safe Brake Control.................................................................................................................... 195
9.3.2 Extended Functions .................................................................................................................. 196
9.3.2.1 Acceptance tests for Extended Functions................................................................................. 196
9.3.2.2 Safe Torque Off......................................................................................................................... 197
9.3.2.3 Safe Stop 1 ............................................................................................................................... 199
9.3.2.4 Safe Brake Control.................................................................................................................... 201
9.3.2.5 Safe Stop 2 ............................................................................................................................... 203
9.3.2.6 Safe Operating Stop.................................................................................................................. 205
9.3.2.7 Safely Limited Speed ................................................................................................................ 207
9.3.2.8 Safe Speed Monitor .................................................................................................................. 212
9.4 Completion of certificate............................................................................................................ 214
A Appendix A ............................................................................................................................................ 217
A.1 List of abbreviations .................................................................................................................. 217
A.2 Document structure................................................................................................................... 226
Index...................................................................................................................................................... 229

Safety Integrated
Function Manual, (FHS), 11/2009, 6SL3097-4AR00-0BP0 17
Standards and regulations 1
1.1 General information
1.1.1 Aims
Manufacturers and operating companies of equipment, machines, and products are
responsible for ensuring the required level of safety. This means that plants, machines, and
other equipment must be designed to be as safe as possible in accordance with the current
state of the art. To ensure this, companies describe in the various standards the current
state of the art covering all aspects relevant to safety. When the relevant Standards are
observed, this ensures that state-of-the-art technology has been utilized and, in turn, the
erector/builder of a plant or a manufacturer of a machine or a piece of equipment has fulfilled
his appropriate responsibility.
Safety systems are designed to minimize potential hazards for both people and the
environment by means of suitable technical equipment, without restricting industrial
production and the use of machines more than is necessary. The protection of man and
environment must be assigned equal importance in all countries, which is it is important that
rules and regulations that have been internationally harmonized are applied. This is also
designed to avoid distortions in the competition due to different safety requirements in
different countries.
There are different concepts and requirements in the various regions and countries of the
world when it comes to ensuring the appropriate degree of safety. The legislation and the
requirements of how and when proof is to be given and whether there is an adequate level of
safety are just as different as the assignment of responsibilities.
The most important thing for manufacturers of machines and companies that set up plants
and systems is that the legislation and regulations in the country where the machine or plant
is being operated apply. For example, the control system for a machine that is to be used in
the US must fulfill local US requirements even if the machinery construction company (OEM)
is based in the European Economic Area (EEA).

Standards and regulations
1.2 Safety of machinery in Europe
Safety Integrated
18 Function Manual, (FHS), 11/2009, 6SL3097-4AR00-0BP0
1.1.2 Functional safety
Safety, from the perspective of the object to be protected, cannot be split-up. The causes of
hazards and, in turn, the technical measures to avoid them can vary significantly. This is why
a differentiation is made between different types of safety (e.g. by specifying the cause of
possible hazards). "Functional safety" is involved if safety depends on the correct function.
To ensure the functional safety of a machine or plant, the safety-related parts of the
protection and control devices must function correctly. In addition, the systems must behave
in such a way that either the plant remains in a safe state or it is brought into a safe state if a
fault occurs. In this case, it is necessary to use specially qualified technology that fulfills the
requirements described in the associated Standards. The requirements to achieve functional
safety are based on the following basic goals:
● Avoiding systematic faults
● Controlling systematic faults
● Controlling random faults or failures
Benchmarks for establishing whether or not a sufficient level of functional safety has been
achieved include the probability of hazardous failures, the fault tolerance, and the quality that
is to be ensured by minimizing systematic faults. This is expressed in the Standards using
different terms. In IEC/EN 61508, IEC/EN 62061, IEC/EN 61800-5-2: "Safety Integrity Level"
(SIL) and
EN ISO 13849-1:2006: "Categories" and "Performance Level" (PL).
1.2 Safety of machinery in Europe
The EU Directives that apply to the implementation of products are based on Article 95 of the
EU contract, which regulates the free exchange of goods. These are based on a new global
concept ("new approach", "global approach"):
● EU Directives only specify general safety goals and define basic safety requirements.
● Technical details can be defined by means of standards by Standards Associations that
have the appropriate mandate from the commission of the European Parliament and
Council (CEN, CENELEC). These standards are harmonized in line with a specific
directive and listed in the official journal of the commission of the European Parliament
and Council. Legislation does not specify that certain standards have to be observed.
When the harmonized Standards are observed, it can be assumed that the safety
requirements and specifications of the Directives involved have been fulfilled.
● EU Directives specify that the Member States must mutually recognize domestic
regulations.
The EU Directives are equal. This means that if several Directives apply for a specific piece
of equipment or device, the requirements of all of the relevant Directives apply (e.g. for a
machine with electrical equipment, the Machinery Directive and the Low-Voltage Directive
apply).

Standards and regulations
1.2 Safety of machinery in Europe
Safety Integrated
Function Manual, (FHS), 11/2009, 6SL3097-4AR00-0BP0 19
1.2.1 Machinery Directive
The basic safety and health requirements specified in Annex I of the Directive must be
fulfilled for the safety of machines.
The protective goals must be implemented responsibly to ensure compliance with the
Directive.
Manufacturers of a machine must verify that their machine complies with the basic
requirements. This verification is facilitated by means of harmonized standards.
1.2.2 Harmonized European Standards
The two Standards Organizations CEN (Comité Européen de Normalisation) and CENELEC
(Comité Européen de Normalisation Électrotechnique), mandated by the EU Commission,
drew-up harmonized European standards in order to precisely specify the requirements of
the EC directives for a specific product. These standards (EN standards) are published in the
official journal of the commission of the European Parliament and Council and must be
included without revision in domestic standards. They are designed to fulfill basic health and
safety requirements as well as the protective goals specified in Annex I of the Machinery
Directive.
When the harmonized standards are observed, it is "automatically assumed" that the
Directive is fulfilled. As such, manufacturers can assume that they have observed the safety
aspects of the Directive under the assumption that these are also covered in this standard.
However, not every European Standard is harmonized in this sense. Key here is the listing in
the official journal of the commission of the European Parliament and Council.
The European standards regarding the safety of machines are structured in a hierarchical
manner as follows:
● A standards (basic standards)
● B standards (group standards)
● C standards (product standards)
Type A standards/basic standards
A standards include basic terminology and definitions relating to all types of machine. This
includes EN ISO 12100 (previously EN 292) "Safety of Machines, Basic Terminology,
General Design Principles."
A standards are aimed primarily at the bodies responsible for setting the B and C standards.
The measures specified here for minimizing risk, however, may also be useful for
manufacturers if no applicable C standards have been defined.

Standards and regulations
1.2 Safety of machinery in Europe
Safety Integrated
20 Function Manual, (FHS), 11/2009, 6SL3097-4AR00-0BP0
Type B standards/group standards
B standards cover all safety-related standards for various different machine types. B
standards are aimed primarily at the bodies responsible for setting C standards. They can
also be useful for manufacturers during the machine design and construction phases,
however, if no applicable C standards have been defined.
A further sub-division has been made for B standards:
● Type B1 standards for higher-level safety aspects (e.g. ergonomic principles, safety
clearances from sources of danger, minimum clearances to prevent parts of the body
from being crushed).
● Type B2 standards for protective safety devices are defined for different machine types
(e.g. EMERGENCY STOP devices, two-hand operating circuits, interlocking elements,
contactless protective devices, safety-related parts of controls).
Type C standards/product standards
C standards are product-specific standards (e.g. for machine tools, woodworking machines,
elevators, packaging machines, printing machines, etc.). Product standards list requirements
for specific machines. The requirements can, under certain circumstances, deviate from the
basic and group standards. Type C/product standards have the highest priority for machine
manufacturers who can assume that it fulfills the basic requirements of Annex I of the
Machinery Directive (automatic presumption of compliance). If no product standard has been
defined for a particular machine, type B standards can be applied when the machine is
constructed.
A complete list of the standards specified and the mandated draft standards are available on
the Internet at the following address:
http://www.newapproach.org/
Recommendation: Due to the rapid pace of technical development and the associated
changes in machine concepts, the standards (and C standards in particular) should be
checked to ensure that they are up to date. Please note that the application of a particular
standard may not be mandatory provided that all the safety requirements of the applicable
EU directives are fulfilled.
