Siemens Tek wireless enhancement User manual

1
Tek wireless enhancement
User Guide

2

1
Dear Customer,
Your hearing instruments equipped with e2e wire-
lessTM 2.0 technology can be controlled by your new Tek
Connect remote control.
This remote control offers you more hearing comfort in
your standard life situations. Via Bluetooth it links your
hearing instruments to the expanding world of electron-
ic media. It will support you when you watch television,
listen to music or talk on the phone.
These instructions, together with the guidance from
your Hearing Care Professional, will help you to under-
stand how your remote control works.
If you have further questions, please contact your Hear-
ing Care Professional.
Introduction
3

A
1
2Contents
3
4
5
6
7
8
Tek upgrade 6
Included in delivery
- 6
Intended use 8
General notes on safety 9
Safety notes for batteries 11
Getting started 12
Before first use 1
- 2
Charging process 1
- 2
Running time of the rechargeable battery 1
- 2
Wearing the remote control 1
- 4
Basic functions 15
Key lock 1
- 5
Changing the hearing program 1
- 5
Changing the volume 1
- 6
Changing the SoundBalance (Treble) 1
- 6
Read out the hearing instrument's
-
information 16
Turning the hearing instruments on/off 1
- 7
Turning the remote control on/off 1
- 7
Symbols 1
- 8
What is Bluetooth? 19
9
4

A1
13
11
12
2
Using the remote control with a phone 20
Pairing remote control and phone 2
- 0
Connecting remote control and phone 2
- 2
Headset and hands-free 2
- 3
Making a call 2
- 5
Shifting an existing call from/ to the
-
remote control 25
Using the Tek Transmitter 26
Turning the Tek Transmitter on/off 2
- 6
Sound level 2
- 7
Charging the Tek Transmitter 2
- 7
Connecting the Tek Transmitter with an
-
external device 28
Receiving the audio stream from an external
-
device 30
Receiving a phone call while watching TV 3
- 1
Using the direct audio input 32
Connecting directly to your mp3 player 3
- 2
Receiving a phone call while using the direct
-
audio input 33
Maintenance and care 34
Technical information 35
Disposal informatio 37
10
14
15
5

Included in delivery
Device and accessories:
Tek connect remote control with rechargeable battery and

lanyard
Tek Transmitter

1Display
2Program buttons
3Volume buttons
4Telephone buttons
remote control on/off
5Microphone opening
6Key lock
7Read out button
hearing instruments on/off
8SoundBalance buttons
92.5mm stereo socket
10 Socket for power plug
3Tek upgrade
11 On/Off switch
12 Soundlevel
13 Socket for power plug
14 2.5mm stereo socket
15 LED
11
12
13
14
15
1
7
8
9
2
3
4
5
6
10
6

Tek upgrade
2 Power plugs with country specific adapters
(one for remote control, one for Tek Transmitter)
Cables:
1.8 m audio cable with 3.5mm stereo

plug on one side and a 2.5 mm stereo
plug on the other side
0.3 m audio cable with 3.5mm stereo

plug on one side and a 2.5 mm stereo
plug on the other side
Adapter set:
2.5 stereo plug to 3.5 stereo socket

6.3 stereo plug to 3.5 stereo socket
RCA (cinch) to 3.5 stereo socket
RCA (cinch) to SCART
3
7

The Tek wireless enhancement is intended to operate
hearing instruments.
Read and follow the instructions of this user guide to
avoid injuries or damage to the remote control.
Symbols:
Be aware of information marked with the warning symbol
WARNING, CAUTION or NOTICE!
WARNING points out a situation that could
lead to serious injuries.
CAUTION indicates a situation that could lead
to minor and moderate injuries.
NOTICE NOTICE indicates possible property
damage.
Advice and tips on how to handle your
hearing instrument better.
Instruction. Indicates that something has to be
done.
4Intended use
8

NOTICE
Your remote control is sensitive to extreme heat, high
humidity, strong magnetic fields (>0.1T), X-rays and me-
chanical stress.
Do not expose your remote control to extreme tem-
X
perature or high humidity.
Do not leave it in direct sunlight.
X
Do not immerse it in water.X
WARNING
Wireless systems may interfere with measuring devices
and electronic equipment.
Turn the remote control off when in hospitals or air-
X
planes.
Prior to use in conjunction with an electronic implant
X
or life supporting system, have the electromagnetic
compatibility verified.
In some countries restrictions for the usage of wireless
equipment exist.
Refer to local authorities for further information.
X
5
General notes on safety
The function of the wireless link might be affected
by a nearby electro-magnetic field, such as computer
monitors.
Keep an appropriate distance from the source of in-
X
terference if you experience difficulty.
9

WARNING
Risk of interference with cardiac pacemakers.
Do not use the remote control if you are fitted with a
X
cardiac pacemaker.
WARNING
Risk in explosive environments, e.g. mining areas!
Do not use your hearing instruments (and remote con-
X
trol) in areas where there is a danger of explosions.
In case the hearing instrument is controlled by ano-X
ther person’s remote control, return to your Hearing
Care Professional with your remote control and hea-
ring instruments.
5General notes on safety
WARNING
Strangulation hazard when lanyard gets entangled in
e.g. moving mechanical parts of machines.
Use only the delivered breakaway lanyard. It will
X
automatically detach when entangled.
10

WARNING
Risk of explosion when the rechargeable battery is
handled wrong.
Do not short circuit, pierce, crush or disassemble the
X
rechargeable battery.
Do not place in oven or fire.
X
Do not immerse in water.X
Charge the rechargeable battery between 0ºC and 45ºCX
Remove the rechargeable battery when the instrumentX
is not in use for a prolonged period of time.
Do not throw used batteries into household trash.X
Return them to your Hearing Care Professional for
environmentally correct disposal.
WARNING
Choking hazard posed by small parts.
Keep batteries, small parts and remote control out of
X
children‘s reach.
If swallowed consult a physician or hospital immedi-
X
ately.
Safety notes for batteries 6
11

Before first use
Insert the rechargeable battery into the remote control.X
Charge the rechargeable battery before first use.X
Charging process
Connect the remote control with theX
power plug to a power supply.
The charging process starts. Charging
time is about 5 hours depending on
the status of the rechargeable battery.
Charging is complete when the bat-
tery symbol shows a full battery.
Running time of the rechargeable
battery
The running time of the rechargeable battery depends on
the way the remote control is used.
The function with the highest power consumpting is the

transmission of an audio signal. This function is active
when telephoning or listening to an external device. The
rechargeable battery will last about 5 hours in this case.
When no transmission of audio signal is active and a

phone is paired, the rechargeable battery will last several
days.
When no transmission of audio signal is active and no

telephone is paired, the rechargeable battery lasts sev-
eral months.
Getting started
7
12

Getting started 7
The remote control will go into a stand-by mode after
a period of inanctivity. In stand-by mode no informa-
tion is shown on the display.
Press any key to turn the remote control back into
X
working mode to see the information on the display.
1
1
3
2
Display information
1Hearing program
2Program description
only available if programmed by your
Hearing Care Professional.
3Battery status of remote control
13

Getting started
7
Wearing the remote control
To operate your hearing instruments wear the remote con-X
trol within a distance of 1m (40in) to the hearing instru-
ments. You can wear the remote control, for example, in
your pocket.
You can also set the remote control on
the table in front of you, for example
when watching tv.
For best listening quality turn the
X
remote control in the same direction
you are facing.
When telephoning with the remote
X
control, hold the remote control in
your hand and speak directly into the
microphone.
For best listening quality when re-X
ceiving an audio stream, wear the re-
mote control with the lanyard around
your neck. This way remote control
and hearing instruments are in the
proper distance and alignment.
14

Basic functions 8
Key lock
Your remote control has a key lock on the
left side.
Slide the control to the bottom to enable
X
the key lock.
Pressing the buttons will now have no
effect.
Slide the control to the top to disable the key
X
lock.
Changing the hearing program
The remote control allows you to control up to
5 programs of your hearing instruments.
Your Hearing Care Professional will program
the settings in the different programms for
your particular listening needs.
Press the number of the desired hearing
X
program.
The remote control shows the number of
the program you are in now.
You hear the acoustic signal for the chosen
program in your hearing instruments.
locked / unlocked
Your Hearing Care Professional can activate or de-
activate acoustic signals in your hearing instruments.
Acoustic signals confirm changes in the settings such
as program, volume or SoundBalance.
15

Basic functions
8
Changing the volume
PressXto increase the volume.
Press
Xto decrease the volume.
Changing the SoundBalance (Treble)
With the rocker switch on the right side of the
remote control you can change the sound of your
hearing instruments.
Press
X+ (up) to get a more shrill sound.
Press
X–(down) to get more muffled sound.
Read out the hearing instrument's information
This functions gives you the possibility to view the
current settings like battery status, volume or hea-
ring program of your hearing instruments.
Hold the remote control close to one of your
X
hearing instruments (about 10 cm / 4 in).
Press the read out button.
X
The display of the remote control shows you the
following information:
1Hearing program with description
2Sound control of hearing instruments
3Volume of hearing instruments
4Battery status of hearing instruments
left / right
T
R
E
B
L
E
1 2 3 4
16

Basic functions 8
Turning the hearing instruments on/off
Press the read out button for more than 5X
seconds to turn your hearing instruments
off.
Press one of the program buttons on the
X
remote control to turn the hearing instru-
ments back on.
Turning the remote control on/off
PressXfor about 5 seconds to turn the remote control
off.
Press
Xfor about 5 seconds to turn the remote control
back on.
WARNING
Wireless systems may interfere with measuring devices
and electronic equipment.
Turn the remote control off when in hospitals or air-
X
planes.
Prior to use in conjunction with an electronic implant
X
or life supporting system, have the electromagnetic
compatibility verified.
17

Basic functions
8
Symbols
program number
bluetooth connection active
or phone connection active
full
empty
charging
battery status of remote control
/ volume up / volume down
/ treble up/ treble down
/ key lock activated / deactivated
incoming call
active call
hearing instruments off
error
/ / searching bluetooth audio stream/
bluetooth audio stream activ / direct
audio stream activ
Read-out symbols
Sound balance and volume of hearing
instruments
battery status of left and right hearing
instrument
18

9
What is Bluetooth?
Bluetooth is a wireless standard that provides a way to
wirelessly connect devices like cell phones, laptops, head-
sets and others.
Over a Bluetooth connection the devices can exchange in-
formation such as data, sound or even control commands.
The range of the Bluetooth connection in the Tek Connect
remote control is about 10 m (32 ft). Walls or objects in be-
tween the devices can shorten this distance.
The Tek Connect remote control can be connected via
Bluetooth to your cell phone or to the Tek Transmitter.
Follow the instructions of the following chapters to hear
sound of your cell phone, TV or mp3 player directly in your
hearing instruments.
The Bluetooth symbol denotes wether or not a device
is Bluetooth compatible.
19

10 Using the remote control with a phone
The remote control allows you to
use your hearing instruments as a
wireless headset when you are tele-
phoning with a Bluetooth compat-
ible phone or cell phone.
Instead of using the telephone
receiver, you speak in your remote
control and listen through your
hearing instruments.
Pairing remote control and phone
Before you can use the remote control with a phone for
the first time you need to pair your phone and the remote
control. The pairing process can be compared with an "in-
troduction" of phone and remote control. After the pairing
process the phone and remote control "know" each other.
The pairing process does not need to be repeated.
Activate the Bluetooth function in your phone.
X
The display of your phone should
show a Bluetooth symbol when the
Bluetooth function is activated.
Press and hold
Xon the remote con-
trol for about 7 seconds.
The remote control changes to pairing mode. You now
have 2minutes to
finish the pairing process.
Search in the menu of your phone for other Bluetooth
X
20
