Siemens SIMATIC HMI IFP User manual

IFP, IFP PRO, IFP ETH
SIMATIC HMI
Industrial Flat Panels
IFP, IFP PRO, IFP ETH
Operating Instructions
09/2019
A5E31298376
-AJ
Preface
Overview
1
Safety information
2
Installing and connecting the
device
3
Commissioning the device
4
Operating the device
5
Maintaining and servicing
your device
6
Technical information
7
Technical Support
A
Markings and symbols
B
List of abbreviations
C

Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
Ⓟ
09/2019 Subject to change
Copyright © Siemens AG 2019.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

IFP, IFP PRO, IFP ETH
Operating Instructions, 09/2019, A5E31298376-AJ 3
Preface
These operating instructions contain all the information you need for commissioning and
operation of the SIMATIC Industrial Flat Panel IFP.
It is intended both for programming and testing personnel who commission the device and
connect it with other units (automation systems, programming devices), as well as for service
and maintenance personnel who install add-ons or carry out fault/error analyses.
Basic knowledge required
A solid background in personal computers and Microsoft operating systems is required to
understand this manual. General knowledge in the field automation control engineering is
recommended.
Scope of the operating instructions
These operating instructions apply to the following industry Flat Panels with the article
numbers 6AV7863-.....-0... and 6AV7863-.....-1...:
●SIMATIC IFP1500, IFP1900, IFP2200
●SIMATIC IFP1900 ETH, IFP2200 ETH
●SIMATIC IFP1900 PRO, IFP2200 PRO
Scope of this documentation
The SIMATIC Industrial Flat Panel is supplied with the following documents:
●In printed form: Quick Install Guide for the device, Installation and Commissioning
Instructions
●Electronically as PDF file on the "Documentation and Drivers" CD/DVD:
–Operating instructions Industrial Flat Panels IFP, IFP PRO, IFP ETH
–Operating Manual SIMATIC Industrial PC Panel Drivers and Tools PDT
You can find the Operating Manual in the PDT installation directory after PDT has
been installed.
Conventions
In these operating instructions, the SIMATIC IFP is also referred to as "Flat Panel" or
"device".
The devices SIMATIC IFP1900 ETH and IFP2200 ETH are also referred to as "Ethernet
Monitor" and "ETH version".
A touch device generally refers to a device with a touch screen, as opposed to a pure
"display device". Touch screen is the general term for a capacitive multi-touch screen and
resistive single touch screen.
The devices IFP1500, IFP1900, IFP2200, IFP1900 ETH and IFP2200 ETH are referred to as
"built-in units".

Preface
IFP, IFP PRO, IFP ETH
4Operating Instructions, 09/2019, A5E31298376-AJ
The devices IFP1900 PRO and PRO IFP2200 are referred to as "PRO devices".
At some places in these operating instructions, the general term "Windows Embedded
Standard" is used to refer to "Windows Embedded Standard 2009" and "Windows
Embedded Standard 7". "Windows 7" is used as an abbreviation for "Windows 7 Ultimate".
Figures
This manual contains figures of the described devices. The supplied device might differ in
some details from the figures. Within some of the figures, one device is used to represent all
Industrial Flat Panels.
History
The following earlier release versions of these operating instructions have been published:
Edition
Comment
09/2012
First Edition
06/2014
Description of devices with capacitive multi-touch screen
11/2014
Update with IPC Wizard 2.1 and corrections
06/2015 The description of the following devices has been added:
•SIMATIC IFP1900 PRO for pedestal (extendable, flange bottom)
•SIMATIC IFP1900 PRO for support arm (not extendable, flange top)
•SIMATIC IFP1900 ETH, IFP2200 ETH
07/2015
Corrections
07/2016 The description of the following devices has been added:
•SIMATIC IFP1900 PRO for support arm (extendable, round tube)
•SIMATIC IFP2200 PRO for pedestal (extendable, flange bottom)
•SIMATIC IFP2200 PRO for support arm (not extendable, flange top)
•SIMATIC IFP2200 PRO for support arm (extendable, round tube)
11/2016 Additions:
•System components for PRO devices: Extension Unit
•Mounting of PRO devices for support arm (extendable, round tube) on a 48.3 mm
round tube
•Information on USB interfaces of Ethernet Monitors
•Information about standards, certificates and securing of cables for Ex approval
11/2017 Corrections
SIMATIC IFP1900 PRO and SIMATIC IFP2200 PRO: Dimensions for die-cast
aluminum housing updated.
09/2019 Additions:
•System components for PRO devices: further Extension Units and PRO options
•"Removing the device" description supplemented
•Position of the mounting clips for 22" built-in unit
•Notes on UL and FM approvals

IFP, IFP PRO, IFP ETH
Operating Instructions, 09/2019, A5E31298376-AJ 5
Table of contents
Preface ........................................................................................................................................3
1 Overview......................................................................................................................................9
1.1 Product description.............................................................................................................. 9
1.2 Scope of delivery............................................................................................................... 12
1.3 Design of the built-in units ................................................................................................. 13
1.3.1 IFP1500/1900/2200 Multitouch, IFP1900/2200 ETH .......................................................... 13
1.3.2 IFP1500/1900/2200 Touch ................................................................................................ 15
1.3.3 IFP1500 Touch/Key........................................................................................................... 16
1.3.4 Interfaces .......................................................................................................................... 16
1.3.4.1 Standard versions ............................................................................................................. 16
1.3.4.2 Ethernet Monitor devices................................................................................................... 17
1.3.4.3 Extended versions............................................................................................................. 17
1.4 Design of the PRO devices................................................................................................ 18
1.4.1 PRO devices for support arm (not extendable, flange top) ................................................. 18
1.4.2 PRO devices for pedestal (extendable, flange bottom)....................................................... 19
1.4.3 PRO devices for support arm (extendable, round tube)...................................................... 21
1.4.4 Interfaces .......................................................................................................................... 22
1.5 System components and accessories................................................................................ 23
1.5.1 System components for PRO devices................................................................................ 23
1.5.2 Accessories....................................................................................................................... 27
2 Safety information ....................................................................................................................... 29
2.1 General safety instructions ................................................................................................ 29
2.2 Notes about usage ............................................................................................................ 31
2.3 Use in hazardous areas..................................................................................................... 35
3 Installing and connecting the device .............................................................................................. 37
3.1 Preparing for installation.................................................................................................... 37
3.1.1 Checking the delivery package .......................................................................................... 37
3.1.2 Built-in unit ........................................................................................................................ 38
3.1.2.1 Permitted mounting positions............................................................................................. 38
3.1.2.2 Checking clearances ......................................................................................................... 40
3.1.2.3 Preparing the mounting cutout........................................................................................... 41
3.1.2.4 Labeling the function keys ................................................................................................. 42
3.1.3 PRO devices ..................................................................................................................... 44
3.1.3.1 Permitted mounting positions............................................................................................. 44
3.2 Installing the built-in unit .................................................................................................... 44
3.2.1 Notes on installation .......................................................................................................... 44
3.2.2 Mounting clips or mounting brackets, position for IP65....................................................... 45
3.2.3 Fastening the device with mounting clips or mounting brackets.......................................... 46
3.2.4 Position of the mounting clips for IP66-complaint installation.............................................. 48

Table of contents
IFP, IFP PRO, IFP ETH
6Operating Instructions, 09/2019, A5E31298376-AJ
3.3 Mounting the PRO device...................................................................................................49
3.3.1 Notes on mounting .............................................................................................................49
3.3.2 PRO devices for support arm (not extendable, flange top) and for pedestal
(extendable, flange bottom)................................................................................................51
3.3.3 PRO devices for support arm (extendable, round tube).......................................................53
3.4 Connecting the device........................................................................................................56
3.4.1 Notes on connection...........................................................................................................56
3.4.2 Earthing the device.............................................................................................................57
3.4.3 Connecting the power supply..............................................................................................58
3.4.3.1 Connecting devices with 24 V DC 2-pin ..............................................................................59
3.4.3.2 Connecting devices with 3-pin 24 V DC ..............................................................................61
3.4.3.3 Connecting an AC power supply.........................................................................................62
3.4.4 Connecting IFP Standard, Extended and PRO to a PC.......................................................64
3.4.4.1 Overview............................................................................................................................64
3.4.4.2 Standard version ................................................................................................................66
3.4.4.3 Extended version, PRO device...........................................................................................66
3.4.5 Connecting Ethernet Monitor to a PC..................................................................................67
3.4.5.1 Overview............................................................................................................................67
3.4.5.2 Connection versions...........................................................................................................68
3.4.6 Connecting a USB device...................................................................................................68
3.4.7 Securing the cables............................................................................................................69
3.4.8 Securing cables for use in hazardous areas........................................................................70
3.5 Removing the device..........................................................................................................71
3.5.1 Removing the built-in unit ...................................................................................................71
3.5.2 Removing a PRO device ....................................................................................................72
4 Commissioning the device ........................................................................................................... 73
5 Operating the device ................................................................................................................... 75
5.1 Operator input options........................................................................................................75
5.2 Operating a device with resistive single touch screen .........................................................76
5.3 Operating a device with capacitive multi-touch screen ........................................................77
5.4 Operating a Touch/Key device............................................................................................79
5.5 Advanced device functions.................................................................................................82
6 Maintaining and servicing your device ........................................................................................... 83
6.1 General information on maintenance and servicing.............................................................83
6.2 Cleaning the device............................................................................................................83
6.3 Ethernet Monitors - Diagnostics and reset ..........................................................................84
6.3.1 Diagnostics screen.............................................................................................................84
6.3.2 Restoring the factory settings for an Ethernet Monitor.........................................................85
6.4 Spare parts and repairs......................................................................................................86
6.5 Recycling and disposal.......................................................................................................86

Table of contents
IFP, IFP PRO, IFP ETH
Operating Instructions, 09/2019, A5E31298376-AJ 7
7 Technical information................................................................................................................... 87
7.1 Certificates and approvals ................................................................................................. 87
7.2 Directives and declarations................................................................................................ 91
7.2.1 ESD guideline ................................................................................................................... 91
7.3 Dimension drawings .......................................................................................................... 94
7.3.1 Dimension drawing of the IFP1500 Multitouch ................................................................... 94
7.3.2 Dimension drawing of the IFP1500 Monitor and Touch ...................................................... 95
7.3.3 Dimension drawing of the IFP1900 Multitouch and IFP1900 ETH....................................... 96
7.3.4 Dimension drawing of the IFP1900 Monitor and Touch ...................................................... 97
7.3.5 Dimension drawing of the IFP2200 Multitouch and IFP2200 ETH....................................... 98
7.3.6 Dimension drawing of the IFP2200 Monitor and Touch ...................................................... 99
7.3.7 Dimension dimensional drawing of the IFP1900 PRO ...................................................... 100
7.3.8 Dimension drawing of the IFP2200 PRO.......................................................................... 103
7.3.9 Dimension drawing of the IFP1500 Touch/Key................................................................. 106
7.3.10 Dimension drawing Host Unit USB................................................................................... 107
7.3.11 Dimensions for labeling strips .......................................................................................... 108
7.4 Rating plate..................................................................................................................... 109
7.5 Technical specifications................................................................................................... 109
7.5.1 General technical specifications....................................................................................... 109
7.5.2 Ambient conditions .......................................................................................................... 112
7.5.2.1 Transport and storage conditions..................................................................................... 112
7.5.2.2 Operating conditions........................................................................................................ 113
7.5.2.3 Electromagnetic compatibility .......................................................................................... 115
7.5.2.4 Information on insulation tests, protection class and degree of protection......................... 116
7.6 Interface description ........................................................................................................ 117
7.6.1 24 V DC Power Supply.................................................................................................... 117
7.6.2 DVI-D interface................................................................................................................ 118
7.6.3 DisplayPort...................................................................................................................... 119
7.6.4 USB interface, Type B..................................................................................................... 119
7.6.5 USB hub, Type A............................................................................................................. 120
7.6.6 Ethernet .......................................................................................................................... 120
A Technical Support ..................................................................................................................... 121
A.1 Service and support ........................................................................................................ 121
A.2 Troubleshooting .............................................................................................................. 122
B Markings and symbols ............................................................................................................... 123
B.1 Safety-relevant symbols .................................................................................................. 123
C List of abbreviations................................................................................................................... 125
Glossary................................................................................................................................... 127
Index ....................................................................................................................................... 129

Table of contents
IFP, IFP PRO, IFP ETH
8Operating Instructions, 09/2019, A5E31298376-AJ

IFP, IFP PRO, IFP ETH
Operating Instructions, 09/2019, A5E31298376-AJ 9
Overview
1
1.1 Product description
SIMATIC Industrial Flat Panels are LCD monitors suitable for industrial use with a brilliant
TFT display which can be connected to all SIMATIC IPCs as well as almost all generally
available PCs.

Overview
1.1 Product description
IFP, IFP PRO, IFP ETH
10 Operating Instructions, 09/2019, A5E31298376-AJ
Features of the built-in units
●Rugged front
●Brilliant TFT display with a wide reading angle;
Resistive single touch screen in sizes 15", 19" and 22"
Capacitive multi-touch screen available in sizes 15", 19" and 22"
●Available as pure display device (monitor) or touch device
●Can be placed up to 5 m from the IPC
●DVI-D and DisplayPort V1.1 interface
●Multi-monitoring support
●Backlighting can be dimmed via software
●24 V DC power supply
●Degree of protection IP65 in installed state
●Enclosure type: Front face only Type 4X/Type 12 (indoor use only)
●Up to 16 million colors
Additional features of the Extended versions
●Up to 30 m away from PC possible via DVI
●Power supply (with USB) 24 V DC and 100-240 V AC
●2 USB ports
●Also available as touch/key version with front USB interface

Overview
1.1 Product description
IFP, IFP PRO, IFP ETH
Operating Instructions, 09/2019, A5E31298376-AJ 11
Additional features of the PRO devices
●All-round dust-proof and splash-proof with IP65 degree of protection and
Enclosure Type 4X / 12 (indoor use only)
●Can be mounted directly on the machine
●19" display, 22" display; capacitive multi-touch screen
●Device versions for mounting:
–IFP PRO for pedestal (extendable, flange bottom)
–IFP PRO for support arm (not extendable, flange top)
–IFP PRO for support arm (extendable, round tube)
Adapters and adapter sets that can be ordered separately support mounting systems
from various manufacturers.
–Basic adapter, included in the product package of PRO devices for pedestal
(extendable, flange bottom) and for support arm (not extendable, flange top).
–With PRO devices for support arm (extendable, round tube):
- Cover for the mechanical interface below, included in the product package
- Flange mount available as accessory
●Can be placed up to 30 m away via DVI
●2 USB ports
Additional features of the Ethernet Monitors
●Configuration and operation in the Ethernet/LAN network
●Length of the Ethernet/LAN connection as customary with conventional LAN technology
●Automatic establishment of connection to SIMATIC IPC
●Automatic configuration using 1:1 cable connection
●Ethernet Monitor software and monitor diagnostic function

Overview
1.2 Scope of delivery
IFP, IFP PRO, IFP ETH
12 Operating Instructions, 09/2019, A5E31298376-AJ
1.2 Scope of delivery
The product package includes the following components:
Name
Figure
Number
Industrial Flat Panel 1
Installation instructions
(Quick Install Guide)
1
Accessory kit
"Mounting clips 1
and
power supply connector"
12
1
"Connecting cables" accessory
kit 1
DVI connecting cable or DisplayPort connecting cable;
2 m in length, for commissioning
1
USB connecting cable, 2 m in length
2
1
Ethernet connecting cable, 2 m in length
3
1
Power supply cable 230 V AC
4
1
Base adapter 5 1
Cover for mechanical interface 6 1
"Documentation and Drivers" CD
1
1
Not with PRO devices
2
Not with standard display device (monitor)
3
Only with devices of the Ethernet Monitor type
4
Only with devices with AC power supply
5
Only with PRO devices for pedestal (extendable, flange bottom) and for support arm (not
extendable, flange top)
6Only with PRO devices for support arm (extendable, round tube)

Overview
1.3 Design of the built-in units
IFP, IFP PRO, IFP ETH
Operating Instructions, 09/2019, A5E31298376-AJ 13
1.3 Design of the built-in units
1.3.1 IFP1500/1900/2200 Multitouch, IFP1900/2200 ETH
This section describes the design of the multi-touch devices, using the IFP1900 Multitouch
as an example.
Front view and bottom view
①
Display/touch screen
②
Recesses for mounting clips
③
Mounting seal

Overview
1.3 Design of the built-in units
IFP, IFP PRO, IFP ETH
14 Operating Instructions, 09/2019, A5E31298376-AJ
Rear view
①
Rating plate
②
Interface name
③
Equipotential bonding
④
Retaining elements for strain relief of the connecting cables

Overview
1.3 Design of the built-in units
IFP, IFP PRO, IFP ETH
Operating Instructions, 09/2019, A5E31298376-AJ 15
1.3.2 IFP1500/1900/2200 Touch
This section describes the design of the monitor and touch devices, using the IFP1500
Touch as an example.
Front view and side view
①
Display/touch screen
②
Recesses for mounting clips
③
Mounting seal
Rear view
See section "IFP1500/1900/2200 Multitouch".

Overview
1.3 Design of the built-in units
IFP, IFP PRO, IFP ETH
16 Operating Instructions, 09/2019, A5E31298376-AJ
1.3.3 IFP1500 Touch/Key
Front view
①
Display and function keys with LED
②
Alphanumeric keys
③
Control keys
④
Cursor keys
⑤
USB port
1.3.4 Interfaces
1.3.4.1 Standard versions
①
X80 connector for 24 V DC power supply
②
X71 DVI-D interface
③
X70 DisplayPort interface
④
X60 USB Type B

Overview
1.3 Design of the built-in units
IFP, IFP PRO, IFP ETH
Operating Instructions, 09/2019, A5E31298376-AJ 17
1.3.4.2 Ethernet Monitor devices
①
X80 connector for 24 V DC power supply
②
X1 Ethernet port
③
Reset button
④
X70 DisplayPort interface
⑤
X61/X62 USB Type A
⑥
X60 USB Type B
1.3.4.3 Extended versions
①
Connection for 100 to 240 V AC power supply
⑤
X61/X62 USB Type A
②
X80 connector for 24 V DC power supply
⑥
X63 USB link interface
③
X71 DVI-D interface
⑦
X60 USB Type B
④
X70 DisplayPort interface

Overview
1.4 Design of the PRO devices
IFP, IFP PRO, IFP ETH
18 Operating Instructions, 09/2019, A5E31298376-AJ
1.4 Design of the PRO devices
1.4.1 PRO devices for support arm (not extendable, flange top)
The following figures show the design of the devices using the IFP1900 PRO for support arm
(not extendable, flange top) as an example.
Front view and side view
①
Display with touch screen
②
Enclosure
③
Backplane cover
Top view
①
Mechanical interface for fastening

Overview
1.4 Design of the PRO devices
IFP, IFP PRO, IFP ETH
Operating Instructions, 09/2019, A5E31298376-AJ 19
Rear view
①
Mechanical interface for fastening
②
Rating plate
③
Enclosure
④
Backplane cover
1.4.2 PRO devices for pedestal (extendable, flange bottom)
The following figures show the design of the devices using the IFP1900 PRO for pedestal
(extendable, flange bottom) as an example.
Front view and side view
①
Display with touch screen
②
Enclosure
③
Backplane cover

Overview
1.4 Design of the PRO devices
IFP, IFP PRO, IFP ETH
20 Operating Instructions, 09/2019, A5E31298376-AJ
Bottom view
①
Mechanical interface for fastening
Rear view
①
Backplane cover
②
Enclosure
③
Rating plate
④
Mechanical interface for fastening
