Siemens SIMATIC NET SCALANCE M826 User manual

SIMATIC NET
Industrial Remote
Communication Remote Networks
SCALANCE M826
Operating Instructions
10/2022
C79000-G8976-C362-07
Preface
Safety notices 1
Security recommendations 2
Description of the device 3
Installation and removal 4
Connecting up 5
Maintenance and cleaning 6
Technical speci󹪝cations 7
Dimension drawings 8
Approvals 9

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Quali󹪝ed Personnel
The product/system described in this documentation may be operated only by personnel quali󹪝ed for the speci󹪝c
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Quali󹪝ed personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance
are required to ensure that the products operate safely and without any problems. The permissible ambient
conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identi󹪝ed by ® are registered trademarks of SiemensAG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
Document order number:C79000-G8976-C362
Ⓟ 11/2022 Subject to change
Copyright © SiemensAG 2014 - 2022.
All rights reserved

Preface
Scope of validity of the operating instructions
These operating instructions apply to the following device:
• SCALANCEM826-2
Purpose of the operating instructions
These operating instructions contain information with which you will be able to install and
connect the SCALANCE M826 correctly. The con󹪝guration and the integration of the device in
a network are not described in these instructions.
Naming of the devices
Classi󹪝cation Description Terms used
Product line For all devices and variants in the prod‐
uct line, the term M-800 is used.
M-800
Device family For all devices and variants in the device
family line, the term M82x is used.
M82x
Device If information relates to a speci󹪝c device,
the device name is used.
M826
Article numbers
Product Description Article number
SCALANCE M826-2 SHDSL router 6GK5826-2AB00-2AB2
You will 󹪝nd the article numbers for the Siemens products of relevance here in the following
catalogs:
• SIMATIC NET Industrial Communication / Industrial Identi󹪝cation, catalog IKPI
• SIMATIC Products for Totally Integrated Automation and Micro Automation, catalog ST70
• Industry Mall - catalog and ordering system for automation and drive technology, Online
catalog (https://mall.industry.siemens.com)
You can request the catalogs and additional information from your Siemens representative.
Documentation on the Internet
You can 󹪝nd the current version of the document on the Internet at. (https://
support.industry.siemens.com/cs/ww/en/ps/15985/man)
Enter the name or article number of the product in the search 󹪝lter.
SCALANCE M826
Operating Instructions, 10/2022, C79000-G8976-C362-07 3

Documentation on con󹪝guration
You will 󹪝nd detailed information on con󹪝guring the devices in the following con󹪝guration
manuals:
• SCALANCE M-800 Web Based Management
• SCALANCE M-800 Command Line Interface
Note
Make sure that you read the explanations and instructions in the readme.htm 󹪝le.
Further documentation
• System manual "Industrial Ethernet"
The system manual contains information on other SIMATIC NET products that you can
operate along with the devices of this product line in an Industrial Ethernet network.
There, you will 󹪝nd among other things optical performance data of the communications
partner that you require for the installation.
The "SIMATIC NET Industrial Ethernet" system manual can be found on the Internet pages of
Siemens Industry Online Support under the following entry ID: 27069465 (https://
support.industry.siemens.com/cs/ww/en/view/27069465)
• "Passive network components" system manual
This system manual contains installation instructions for several of the most common
components and guidelines for setting up networked automation plants in buildings.
The "Passive network components" system manual can be found on the Internet pages of
Siemens Industry Online Support under the following entry ID: 84922825 (https://
support.industry.siemens.com/cs/ww/en/view/84922825)
SIMATIC NET manuals
You will 󹪝nd SIMATIC NET manuals on the Internet pages of Siemens Industry Online Support:
• using the search function:
Link to Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/)
Enter the entry ID of the relevant manual as the search item.
• In the navigation panel on the left hand side in the area "Industrial Communication":
Link to the area "Industrial Communication" (https://
support.industry.siemens.com/cs/ww/en/ps/15247/pm)
Go to the required product group and make the following settings:
tab "Entry list", Entry type "Manuals"
You will 󹪝nd the documentation for the SIMATIC NET products relevant here on the data
medium that ships with some products:
• Product CD / product DVD
• SIMATIC NET Manual Collection
Preface
SCALANCE M826
4Operating Instructions, 10/2022, C79000-G8976-C362-07

Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be connected
to an enterprise network or the internet if and to the extent such a connection is necessary
and only when appropriate security measures (e.g. 󹪝rewalls and/or network segmentation)
are in place.
For additional information on industrial security measures that may be implemented, please
visit
https://www.siemens.com/industrialsecurity (https://www.siemens.com/industrialsecurity).
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customer’s exposure
to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under
https://www.siemens.com/cert (https://www.siemens.com/cert).
Firmware
The 󹪝rmware is signed and encrypted. This ensures that only 󹪝rmware created by Siemens can
be downloaded to the device.
The 󹪝rmware is available on the Internet pages of the Siemens Industry Online Support (https://
support.industry.siemens.com/cs/ww/en/ps/15982/dl):
Note on 󹪝rmware/software support
Check regularly for new 󹪝rmware/software versions or security updates and apply them. After
the release of a new version, previous versions are no longer supported and are not maintained.
Decommissioning
Shut down the device properly to prevent unauthorized persons from accessing con󹪝dential
data in the device memory.
To do this, restore the factory settings on the device.
Also restore the factory settings on the storage medium.
Preface
SCALANCE M826
Operating Instructions, 10/2022, C79000-G8976-C362-07 5

Recycling and disposal
The products are low in pollutants, can be recycled and meet the requirements of the WEEE
directive 2012/19/EU for the disposal of electrical and electronic equipment.
Do not dispose of the products at public disposal sites.
For environmentally friendly recycling and the disposal of your old device contact a certi󹪝ed
disposal company for electronic scrap or your Siemens contact (Product return (https://
support.industry.siemens.com/cs/ww/en/view/109479891)).
Note the di󹪜erent national regulations.
Device defective
If a fault develops, send the device to your SIEMENS representative for repair. Repairs on-site are
not possible.
Trademarks
The following and possibly other names not identi󹪝ed by the registered trademark sign ® are
registered trademarks of Siemens AG:
SCALANCE, SINEMA, KEY-PLUG, C-PLUG
License conditions
Note
Open source software
Read the license conditions for open source software carefully before using the product.
You will 󹪝nd license conditions in the following documents on the supplied data medium:
• OSS_Scalance-M-800-S615_86.pdf
SIMATIC NET glossary
The SIMATICNET glossary describes terms that may be used in this document.
You will 󹪝nd the SIMATIC NET glossary in the Siemens Industry Online Support at the
following address:
50305045 (https://support.industry.siemens.com/cs/ww/en/view/50305045)
Preface
SCALANCE M826
6Operating Instructions, 10/2022, C79000-G8976-C362-07

Table of contents
Preface ................................................................................................................................................... 3
1 Safety notices ........................................................................................................................................ 9
2 Security recommendations.................................................................................................................. 11
3 Description of the device..................................................................................................................... 19
3.1 Product characteristics ....................................................................................................... 19
3.2 Device view ....................................................................................................................... 20
3.3 Scope of delivery ............................................................................................................... 20
3.4 Accessories ........................................................................................................................ 21
3.4.1 PLUG ................................................................................................................................. 22
3.4.2 Installation ........................................................................................................................ 22
3.5 Terminals........................................................................................................................... 23
3.6 LED display ........................................................................................................................ 24
3.7 SET button......................................................................................................................... 26
3.8 PLUG ................................................................................................................................. 27
4 Installation and removal...................................................................................................................... 31
4.1 Safety notices for installation ............................................................................................. 31
4.2 Securing the housing......................................................................................................... 34
4.3 Wall mounting ................................................................................................................... 34
4.4 Installing on the DIN rail..................................................................................................... 36
4.5 Installing on the S7-300 standard rail ................................................................................. 37
4.6 Installing on the S7-1500 standard rail ............................................................................... 38
4.7 Mounting on a pedestal ..................................................................................................... 39
5 Connecting up ..................................................................................................................................... 41
5.1 Safety when connecting up................................................................................................ 41
5.2 Power supply ..................................................................................................................... 45
5.3 Grounding ......................................................................................................................... 46
5.4 Digital input/output ........................................................................................................... 46
5.5 SHDSL connection.............................................................................................................. 49
5.6 Ethernet port ..................................................................................................................... 53
5.7 Replacing the PLUG............................................................................................................ 54
SCALANCE M826
Operating Instructions, 10/2022, C79000-G8976-C362-07 7

6 Maintenance and cleaning .................................................................................................................. 57
7 Technical speci󹪝cations ....................................................................................................................... 59
8 Dimension drawings............................................................................................................................ 63
9 Approvals............................................................................................................................................. 65
9.1 EC declaration of conformity .............................................................................................. 66
9.1.1 ATEX.................................................................................................................................. 66
9.1.2 EMC................................................................................................................................... 67
9.1.3 RoHS ................................................................................................................................. 67
9.2 UK Declaration of Conformity............................................................................................. 68
9.2.1 The Equipment and Protective Systems Intended for use in Potentially Explosive
Atmospheres Regulations 2016.......................................................................................... 68
9.2.2 The Electromagnetic Compatibility Regulations 2016.......................................................... 69
9.2.3 The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic
Equipment Regulations 2012 ............................................................................................. 69
9.3 General approvals .............................................................................................................. 70
Index .................................................................................................................................................... 73
Table of contents
SCALANCE M826
8Operating Instructions, 10/2022, C79000-G8976-C362-07

Safety notices 1
CAUTION
To prevent injury and damage, read the manual before using the device.
Read the safety notices
Note the following safety notices. These relate to the entire working life of the device.
You should also read the safety notices relating to handling in the individual sections,
particularly in the sections "Installation" and "Connecting up".
WARNING
Hot surfaces
Electric devices have hot surfaces. Do not touch these surfaces. They could cause severe burns.
• Allow the device to cool down before starting any work on it.
WARNING
EXPLOSION HAZARD
Do not open the device when the supply voltage is turned on.
SCALANCE M826
Operating Instructions, 10/2022, C79000-G8976-C362-07 9

Safety notices
SCALANCE M826
10 Operating Instructions, 10/2022, C79000-G8976-C362-07
