Siemens SIPROTEC 6MD665 User manual

SIPROTEC
Bay Processing Unit
6MD665
V 4.2
Manual
C53000-G1876-C103-3
3UHIDFH
,QWURGXFWLRQ 1
)XQFWLRQV 2
,QVWDOODWLRQDQG&RPPLVVLRQLQJ 3
7HFKQLFDO'DWD 4
$SSHQGL[ A
/LWHUDWXUH
*ORVVDU\
,QGH[

6MD665 Manual
C53000-G1876-C103-3
Disclaimer of liability
We have checked the text of this manual against the hardware
and software described. Exclusions and deviations cannot be
ruled out; we accept no liability for lack of total agreement.
The information in this manual is checked periodically, and nec-
essary corrections will be included in future editions. We appreci-
ate any suggested improvements.
We reserve the right to make technical improvements without
notice.
Copyright
Copyright © Siemens AG 2002. All rights reserved.
Dissemination or reproduction of this document, or evaluation
and communication of its contents, is not authorized except
where expressly permitted. All rights reserved, particularly for the
purposes of patent application or trademark registration.
Registered Trademarks
SIPROTEC, SINAUT, SICAM and DIGSI are registered trade-
marks of SIEMENS AG. Other designations in this manual may
be trademarks that if used by third parties for their own purposes
may violate the rights of the owner.
4.20.03

i6MD665 Manual
C53000-G1876-C103-3
Preface
Purpose of This
Manual This manual describes the functions, operation, installation, and placing into service of device 6MD665. In particular, one will find:
• Descriptions of device functions and settings;
• Instructions for Installation and Commissioning;
• Compilation of the technical specifications;
• As well as a compilation of the most significant data for experienced users in the
Appendix.
General information about design, configuration, and operation of SIPROTEC®4
devices is laid down in the SIPROTEC®system description /1/.
Target Audience Engineers, commissioning engineers, personnel concerned with adjustment, check-
ing, and service of selective protective equipment, automatic and control facilities and
personnel of electrical facilities and power plants.
Scope of validity of
the manual This manual is valid for SIPROTEC®4 Bay Processing Unit 6MD665; Firmware
version V 4.2.
Indication of Con-
formity
Additional Support Should further information on the System SIPROTEC®4 be desired or should partic-
ular problems arise which are not covered sufficiently for the purchaser's purpose, the
matter should be referred to the local Siemens representative.
Training Courses Individual course offerings may be found in our Training Catalogue, or questions may
be directed to our training centre in Nuremberg.
ThisproductcomplieswiththedirectiveoftheCouncilofthe
European Communities on the approximation of the laws of
the member states relating to electromagnetic compatibility
(EMC Council Directive 89/336/EEC) and concerning elec-
trical equipment for use within certain voltage limits (Low-
voltage Directive 73/23/EEC).
This conformity is proved by tests conducted by Siemens
AG in accordance with Article 10 of the Council Directive in
agreement with the generic standards EN 50 081 and EN
50 082 for EMC directive, and with the standard EN 60 255-
6 for the low-voltage directive. This device was designed
and produced for industrial use according to the EMC stan-
dard.
The product conforms with the international standard of the
series IEC 60 255 and the German standard DIN 57 435/
Part 303 (corresponds to VDE 0435/Part 303).

Preface
ii 6MD665 Manual
C53000-G1876-C103-3
Instructions and
Warnings The warnings and notes contained in this manual serve for your own safety and for an appropriate lifetime of the device. Please observe them!
The following warning terms and standard definitions are used:
DANGER! indicates that death, severe personal injury or substan-
tial property damage will result if proper precautions
are not taken.
Warning indicates that death, severe personal injury or substan-
tial property damage can result if proper precautions
are not taken.
Caution indicates that minor personal injury or property
damage can result if proper precautions are not taken.
This particularly applies to damage on or in the device
itself and consequential damage thereof.
Note indicates information about the device or respective
part of the instruction manual which is essential to
highlight.
WARNING!
Hazardous voltages are present in this electrical equipment during operation.
Non–observance can result in death, personal injury or substantial property damage.
Only qualified personnel shall work on and around this equipment. It must be thor-
oughly familiar with all warnings and safety notices of this manual as well as with the
applicable safety regulations.
The successful and safe operation of this device is dependent on proper handling,
installation, operation, and maintenance by qualified personnel under observance of
all warnings and hints contained in this manual.
In particular the general erection and safety regulations (e.g. IEC, DIN, VDE, EN or
other national and international standards) regarding the correct use of hoisting gear
must be observed.
Definition QUALIFIEDPERSONNEL For the purpose of this instruction manual and product
labels, a qualified person is one who is familiar with the
installation, construction and operation of the equip-
ment and the hazards involved. In addition, he has the
following qualifications:
– Is trained and authorized to energize, de-energize,
clear, ground and tag circuits and equipment in
accordance with established safety practices.
– Is trained in the proper care and use of protective
equipment in accordance with established safety
practices.
– Is trained in rendering first aid.

Preface
iii
6MD665 Manual
C53000-G1876-C103-3
Typographic and
Symbol Conven-
tions
To designate terms which refer in the text to information of the device or for the device,
the following fonts are used:
3DUDPHWHU1DPHV, i.e.designatorsofconfigurationorfunctionparameters
which may appear word-for-word in the display of the
device or on the screen of a personal computer (with
DIGSI®), are marked in bold letters of a monospace
type style. The same goes for the titles of menus.
3DUDPHWHU2SWLRQV, i.e. possible settings of text parameters, which may
appear word-for-word in the display of the device or on
the screen of a personal computer (with DIGSI®), are
written in italic style, additionally. The same goes for
the options of the menus.
´,QGLFDWLRQVµ, i.e. designators for information, which may be output
by the relay or required from other devices or from the
switchgear, are marked in a monospace type style in
quotation marks.
Deviations may bepermitted in drawings when the type of designator can beobviously
derived from the illustration.
The following symbols are used in drawings:
device-internal logical input signal
device-internal logical output signal
internal input signal of an analogue quantity
external binary input signal with number No. (binary
input, input indication)
external binary output signal with number No. (device
indication)
Example of a parameter switch designated with the
address and the possible settings
Besides these, graphical symbols are used according to IEC 60 617–12 and
IEC 60 617–13 or similar. Some of the most frequently used are listed below:
Input signal of an analogue quantity

Preface
iv 6MD665 Manual
C53000-G1876-C103-3
OR gate
AND gate
Exclusive–OR gate (antivalence): output is active, if
only one of the inputs is active
Coincidence gate (equivalence): output is active, if
both inputs are active or inactive at the same time
Dynamic inputs (edge–triggered) above with positive,
below with negative edge
Formation of one analogue output signal from a
number of analogue input signals
Limit stage with setting address and parameter desig-
nator (name)
Timer(pickupdelayT, exampleadjustable)withsetting
address and parameter designator (name)
Timer (dropout delay T, example non-adjustable)
Dynamic triggered pulse timer T (monoflop)

Preface
v
6MD665 Manual
C53000-G1876-C103-3
Static memory (RS-flipflop) with setting input (S),
resetting input (R), output (Q) and inverted output (Q)
■

Preface
vi 6MD665 Manual
C53000-G1876-C103-3

i6MD665 Manual
C53000-G1876-C103-3
Contents
1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Overall Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.2 Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3 Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1 General functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1.1 Functional scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1.1.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1.1.2 Configuration Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1.1.3 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.1.2 Power System Data 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.1.2.1 Configuration Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.1.2.2 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.1.3 Device, General Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.1.3.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.1.3.2 Configuration Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.1.3.3 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.1.3.4 Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.1.4 Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.1.4.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.2 Command processing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.2.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.2.1.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.2.2 Control Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.2.2.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.2.2.2 Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.2.3 Control Authorization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.2.3.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.2.3.2 Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.2.4 Process Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.2.4.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.3 Message Processing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
2.3.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Contents
ii 6MD665 Manual
C53000-G1876-C103-3
2.4 Measured value processing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
2.4.1 Measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
2.4.1.1 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
2.4.1.2 Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
2.4.2 General Transducer Blocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
2.4.2.1 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
2.4.3 Parameterizing Transducer Blocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
2.4.3.1 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
2.4.4 Measurement U 1.packet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
2.4.4.1 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
2.4.4.2 Configuration Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
2.4.4.3 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
2.4.4.4 Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
2.4.5 Measurement I 1.packet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
2.4.5.1 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
2.4.5.2 Configuration Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
2.4.5.3 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
2.4.5.4 Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
2.4.6 Measurement 1phase 1.packet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
2.4.6.1 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
2.4.6.2 Configuration Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
2.4.6.3 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
2.4.6.4 Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
2.4.7 Measurement 3phase 1.packet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
2.4.7.1 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
2.4.7.2 Configuration Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
2.4.7.3 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
2.4.7.4 Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
2.4.8 Measurement Aron 1.packet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
2.4.8.1 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
2.4.8.2 Configuration Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
2.4.8.3 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
2.4.8.4 Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
2.5 Metered Value Processing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
2.5.1 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
2.6 Threshold-Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
2.6.1 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
2.6.2 Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
2.7 Circuit breaker synchronisation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
2.7.1 SYNC Function group 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
2.7.1.1 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
2.7.1.2 Configuration Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
2.7.1.3 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
2.7.1.4 Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
2.7.2 SYNC function group 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
2.7.2.1 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
2.7.3 Parameterizing SYNC function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
2.7.3.1 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
2.7.4 Runtime measurement for the CB synchronisation via the process bus. . . . . . . . . . . . . . . 67
2.7.4.1 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Contents
iii
6MD665 Manual
C53000-G1876-C103-3
2.8 Inter relay communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
2.8.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
2.9 Process bus link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
2.9.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
3 Installation and Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
3.1 Installation and Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
3.1.1 Configuration Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
3.1.2 Hardware Modifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
3.1.2.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
3.1.2.2 Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
3.1.2.3 Switching elements on the PCBs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
3.1.2.4 Interface Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
3.1.2.5 Reassembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
3.1.3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
3.1.3.1 Panel Flush Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
3.1.3.2 Rack Mounting and Cabinet Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
3.1.3.3 Mounting with Detached Operator Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
3.1.3.4 Mounting without operator panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
3.2 Checking Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
3.2.1 Checking the data connections of the serial interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . .112
3.2.2 Operating interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
3.2.3 Service / Function interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
3.2.4 System interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
3.2.5 Termination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
3.2.6 Time Synchronization Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
3.2.7 Optical Fibers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
3.2.8 Checking Power System Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
3.3 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117
3.3.1 General information about the intelligent switchgear bay . . . . . . . . . . . . . . . . . . . . . . . . . .118
3.3.2 Test Mode and Transmission Block. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
3.3.3 Testing System Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
3.3.4 Checking the Binary Inputs and Outputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
3.3.5 Testing User-Defined Functions (CFC logic). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
3.3.6 Trip/Close Tests for the Configured Operating Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . 123
3.3.7 Checking the process bus interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
3.4 Final Preparation of the Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Contents
iv 6MD665 Manual
C53000-G1876-C103-3
4 Technical Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
4.1 General Device Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
4.1.1 Analogue inputs (optional). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
4.1.2 Auxiliary voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
4.1.3 Binary inputs and outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
4.1.4 Communication interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
4.1.5 Electrical Tests. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
4.1.6 Mechanical Stress Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
4.1.7 Climatic stress tests. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
4.1.8 Service Conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
4.1.9 Construction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
4.2 Switchgear control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
4.3 Circuit breaker synchronisation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
4.4 User Definable Functions (CFC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
4.5 Operating measured values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
4.6 Inter relay communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
4.7 Auxiliary functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
4.8 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
4.8.1 Housing for Panel Flush Mounting or Cabinet Installation. . . . . . . . . . . . . . . . . . . . . . . . . 148
4.8.2 Mounting with detached operator panel or without operator panel . . . . . . . . . . . . . . . . . . 149
4.8.3 Detached Operator Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
4.8.4 D-SUB miniature Connector of Dongle Cable (Panel Flush or Cubicle Door Cutout) . . . . 151
A Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
A.1 Ordering Information and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
A.1.1 Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
A.1.1.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
A.1.2 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
A.2 Terminal Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
A.2.1 Housing for panel surface and cabinet mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
A.2.2 Housing with detached operator panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
A.2.3 Housing for installation without operator panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
A.3 Connection Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
A.4 Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
A.4.1 LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
A.4.2 Binary Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
A.4.3 Binary Output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
A.4.4 Function Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
A.4.5 Default display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
A.4.6 Pre-defined CFC-charts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168

Contents
v
6MD665 Manual
C53000-G1876-C103-3
A.5 Protocol-Dependent Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
A.6 Functional Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
A.7 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
A.8 Information Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
A.9 Group Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
A.10 Measured Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
Literature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205

Contents
vi 6MD665 Manual
C53000-G1876-C103-3

16MD665 Manual
C53000-G1876-C103-3
Introduction 1
The SIPROTEC®Bay Processing Unit 6MD665 is introduced in this chapter. The
device is presented in its application, characteristics, and scope of functions.
1.1 Overall Operation 2
1.2 Applications 5
1.3 Characteristics 7

1 Introduction
26MD665 Manual
C53000-G1876-C103-3
1.1 Overall Operation
The digital SIPROTEC® Bay Processing Unit 6MD665 is equipped with a powerful
microprocessor system. The device accomplishes all functions for controlling and
monitoring of process components via the process bus. Additionally, measured values
can be recorded and digitally processed by the Bay Processing Unit.
Hardware structure
Figure 1-1 Hardware structure of the Bay Processing Unit 6MD665

1.1 Overall Operation
3
6MD665 Manual
C53000-G1876-C103-3
Microcomputer
System The control functions and the measurement quantities are processed in the microcom- puter system µC. They especially consist of:
• Control of command outputs,
• Decision for close commands,
• Processing of indication inputs,
• Storage of annunciations, fault data and fault values for fault analysis,
• Control of signals for logical functions,
• Filtering and conditioning of the measured signals,
• Continuous monitoring of the measured quantities
• Monitoring the communication with other devices,
• Querying of limit values and time sequences,
• Management of the operating system and the associated functions such as data
recording, real-time clock, communication, interfaces, etc.
Analog inputs
(optional) The measuring inputs (ILx, Vx) convert the currents and voltages coming from the
transformers and adapt them to the level appropriate for the internal processing of the
device. The device has 3 current and 4 voltage inputs.
The current and voltageinputs can be used separately for measured value acquisition.
Within the scope of configuration, one- or three-phase evaluation functions are avail-
able for evaluation of the analogue inputs and evaluation after the Aron connection.
With voltage inputs, both phase-earth and phase-phase voltages can be applied. In
addition to a three-phase system, another reference voltage for synchronisation tasks
or a displacement voltage Vncan be measured via the fourth voltage input.
Furthermore, two measuring transducer inputs are available.
The analogue values are transferred further to the IA input amplifier group.
The input amplification IA stage provides high-resistance terminations for the ana-
logue input quantities. It consists of filters that are optimised with regard to bandwidth
and processing speed.
The analogue-to-digital (AD) stage consists of a multiplexor, an analogue-to-digital (A/
D) converter and memory components for the transmission of digital signals to the
microcomputer system.
Binary Inputs and
Outputs Binary inputs and outputs from and to the computer system are routed via the I-/O modules (inputs and outputs). The computer system obtains the information from the
system (e.g remote resetting) or the external equipment (e.g. blocking commands).
Outputs are, in particular, commands to the switchgear units and indications for
remote signalling of important events and statuses.
Front Elements With devices with integrated or detached operator panel, information such as mes-
sages related to events, states, measured values and the functional status of the
device are provided via light-emitting diodes (LEDs) and a display screen (LCD) on
the front panel.
Integrated control and numeric keys in conjunction with the LCD facilitate local inter-
action with the device. Via these elements all information of the device such as con-
figuration and setting parameters, operating messages and measured values can be
accessed. Setting parameters may be changed in the same way.
In addition, control of circuit breakers and other equipment is possible from the front
panel of the device.

1 Introduction
46MD665 Manual
C53000-G1876-C103-3
Serial Interfaces A serial PC interface is provided for local communications with the device through a
personal computer using the operating program DIGSI®. This permits convenient
operation of all functions of the device.
A separate Service Port can be provided for remote communications via a modem, or
substation computer using DIGSI®4. This port is especially well suited for the fixed
wiring of the devices to the PC or operation via a modem.
Via the serial system interface all device data can be transferred to a central evalua-
tion unit or to a control center. This interface may be provided with various protocols
and physical transmission schemes to suit the particular application.
Communication with other SIPROTEC®4 devices which also have inter relay commu-
nication can occur via the serial interface to the (optional) on the device rear. Com-
munication is achieved regardless of the connection to the central device SICAM SAS
and a redundancy to the system interface.
A further interface is provided for the time synchronization of the internal clock via
external synchronization sources.
Further communication protocols can be realised via additional interface modules.
Process bus inter-
face The process bus interface allows a direct communication with SICAM HV modules. It is equipped with an Ethernet module.
Power Supply The before-mentioned function elements and their voltage levels are supplied with
power by a power supplying unit (Uaux or PS). Voltage dips may occur if the voltage
supply system (substation battery) becomes short-circuited. Usually, they are bridged
by a capacitor (see also Technical Data).

1.2 Applications
5
6MD665 Manual
C53000-G1876-C103-3
1.2 Applications
The SIPROTEC®Bay Processing Unit 6MD665 is an integrated part of the SICAM
power automation system. Command outputs and indication inputs are especially
adapted to the requirements of high-voltage technology.
By means of appropriately equipped switchgears the Bay Processing Unit can com-
municate with the SICAM HV modules via a process bus. Therefore the system is also
called an intelligent switchgear bay. The SICAM HV modules are not suitable for all
types of switchgears. Detailed information can be obtained from your local Siemens
sales representative.
When connecting the circuit breaker, the Bay Processing Unit can check if the syn-
chronisation conditions of the two subnetworks to be combined are met (synchro-
check). This makes the use of an additional external synchronisation device unneces-
sary. The synchronisation conditions can be configured conveniently with the DIGSI®
operating program. The device distinguishes between synchronous and asynchro-
nous networks and reacts differently on the connection.
Control functions The device provides a control function which can be accomplished for activating and
deactivating switchgears via integrated operator panel, system interface, binary
inputs, and the serial port using a personal computer with DIGSI®.
The status of the primary equipment can be transmitted to the device via auxiliary con-
tacts connected to binary inputs. The present status (or position) of the primary equip-
ment can be displayed on the device, and used for interlocking or plausibility monitor-
ing. The number of the operating equipment to be switched is limited by the binary
inputs and outputs available in the device or the binary inputs and outputs allocated
for the switch position indications. Depending on the primary equipment being con-
trolled, one binary input (single point indication) or two binary inputs (double point indi-
cation) may be used for this process.
The capability of switching primary equipment can be restricted by a setting associ-
ated with switching authority (Remote or Local), and by the operating mode (inter-
locked/non-interlocked, with or without password request).
Processing of interlocking conditions for switching (e.g. system interlocking) can be
established with the aid of integrated, user-configurable logic functions.
Messages and Mea-
sured Values The operating messages provide information about conditions in the power system and the device. Measurement quantities and values that are calculated can be dis-
played locally and communicated via the serial interfaces.
Device indications can be assigned to a number of LEDs, externally processed via
output contacts, linked with user-definable logic functions and/or issued via serial
interfaces.
Communication For communication with external operator and control systems and Inter relay commu-
nication, serial interfaces are available.
A 9-pole DSUB socket on the front cover ensures the local communication with a per-
sonal computer. By means of the SIPROTEC®operating software DIGSI®4, all oper-
ational and evaluation tasks can be executed via this user interface, such as specify-
ing and modifying configuration parameters and settings, configuring user-specific
logic functions, retrieving operational messages and measured values, inquiring
device conditions and measured values, issuing control commands.

1 Introduction
66MD665 Manual
C53000-G1876-C103-3
Depending on the individual ordering variant, additional interfaces are located on the
rear side of the device. They serve to establish an extensive communication with other
digital operating, control and memory components:
The service interface can be operated via electrical data lines or fibre optics and also
allows communication via modem. For this reason, remote operation is possible via
personalcomputer and the DIGSI®operating software, e.g. to operate several devices
via a central PC.
The system interface ensures the central communication between the device and the
substation controller. The service interface can be operated through data cables or
fibre optic cables.
The device has a field bus coupling with PROFIBUS FMS. The PROFIBUS FMS
according to DIN 19 245 is an open communication standard with particularly wide
acceptance in process control and automation engineering, with especially high per-
formance. A profile has been defined for the PROFIBUS communication that covers
all of the information types required for process control engineering. The integration of
the devices into the power automation system SICAM®can also take place with this
profile.
In addition, standardised protocols in accordance with IEC 60 870-5-103 are available
for data transmission. The integration of the devices into automation systems from
other manufacturers can also take place with this profile.
Optionally, you can use an additional serial interface for Inter relay communication. It
takes over communication with other SIPROTEC®4 devices, regardless if the device
is connected to the control center.
The process bus interface allows a direct communication with SICAM HV modules.
They communicate process data between the Bay Processing Unit and the device
control (of circuit breakers, disconnectors and ground switches). Here, a PCU (Pro-
cess Communication Unit) serves as a communication link between controller and
process bus.
