Siemens Micromaster 15-8DB50 User manual

© Siemens plc 1999 G85139-H1750-U049-C1
19/08/99
Contents
SAFETY INSTRUCTIONS..................................................... 3
1. OVERVIEW....................................................................... 4
2. INSTALLATION.............................................................. 10
3. FRONT PANEL CONTROLS & BASIC OPERATION ... 18
4. OPERATING MODES..................................................... 21
5. SYSTEM PARAMETERS ............................................... 24
6. FAULT CODES............................................................... 39
7. SPECIFICATIONS .......................................................... 40
8. SUPPLEMENTARY INFORMATION ............................. 43
MICROMASTER
Operating Instructions

English
G85139-H1750-U049-C1 © Siemens plc 199
9
19/08/99 2
Contents
1Overview 4
1.1 Installation - General Notes 5
1.2 Wiring Guidelines to Minimise the Effects of EMI 6
1.3 Electrical Installation - General Notes 9
1.3.1 Operation with Unearthed (IT) Supplies 9
1.3.2 Operation with Residual Current Device (RCD) 9
1.3.3 Installation after a Period of Storage 9
1.3.4 Operation with Long Cables 9
2 Installation 10
2.1 Mechanical Installation 10
2.2 Electrical Installation 11
2.2.1 Power and Motor Connections - Frame Size A 11
2.2.2 Power and Motor Connections - Frame Size B 13
2.2.3 Power and Motor Connections - Frame Size C 14
2.2.4 Control Connections 16
2.2.5 External Motor Thermal Overload Protection 17
2.2.6 Block Diagram 17
3 Front Panel Controls & Basic Operation 18
3.1 Front Panel Controls 18
3.2 Basic Operation 19
3.2.1 General 19
3.2.2 Initial Testing 19
3.2.3 Basic Operation - 10 Step Guide 20
4Operating Modes 21
4.1 Digital Control 21
4.2 Analogue Control 21
4.3 Stopping the Motor 22
4.4 If the Motor does not Start Up 22
4.5 Local and Remote Control 22
4.6 Closed Loop Control 23
4.6.1 General Description 23
4.6.2 Hardware Setup 23
4.6.3 Parameter Settings 23
5 System Parameters 24
6 Fault Codes 39
7 Specifications 40
8 Supplementary Information 43
8.1 Application Example 43
8.2 USS Status Codes 43
8.3 Electro-Magnetic Compatibility (EMC) 44
8.4 Environmental Aspects 46
8.5 User's Parameter Settings 47

© Siemens plc 1999 G85139-H1750-U049-C1
319/08/9
9
Safety Instructions
Before installing and putting this equipment into operation, please read these safety instructions and
warnings carefully and all the warning labels attached to the equipment. Make sure that the warning labels
are kept in a legible condition and replace missing or damaged labels.
WARNING
This equipment contains dangerous voltages an
d
controls dangerous rotating mechanical parts.
Loss of life, severe personal injury or propert
y
damage can result if the instructions contained i
n
this manual are not followed.
Only suitable qualified personnel should work o
n
this equipment, and only after becoming familia
r
with all safety notices, installation, operation an
d
maintenance procedures contained in this manual.
The successful and safe operation of thi
s
equipment is dependent upon its proper handling,
installation, operation and maintenance.
•MICROMASTERS operate at high voltages.
•Only permanently-wired input powe
r
connections are allowed. This equipment mus
t
be grounded (IEC 536 Class 1, NEC and othe
r
applicable standards).
•If a Residual Current-operated protectiv
e
Device (RCD) is to be used, it must be a
n
RCD type B.
•Machines with a three phase power supply,
fitted with EMC filters, must not be connecte
d
to a supply via an ELCB (Earth Leakag
e
Circuit-Breaker - see DIN VDE 0160, sectio
n
6.5).
•The following terminals can carry dangerou
s
voltages even if the inverter is inoperative:
- the power supply terminals L/L1, N/L2, L3.
- the motor terminals U, V, W.
•Only qualified personnel may connect, star
t
the system up and repair faults. Thes
e
personnel must be thoroughly acquainted wit
h
all the warnings and operating procedure
s
contained in this manual.
•Certain parameter settings may cause th
e
inverter to restart automatically after an inpu
t
power failure.
This equipment is capable of providin
g
internal motor overload protection i
n
accordance with UL508C section 42. Refer t
o
P074. Motor overload protection can also b
e
provided by using an external PTC. Thi
s
applies to units at software issue (P922) 3.0
6
or greater only .
This equipment is suitable for use in a circui
t
capable of delivering not more than 100,00
0
symmetrical amperes (rms), for a maximum
voltage of 230/460V* when protected by
a
time delay fuse* (*See Section 7).
•This equipment must not be used as a
n
‘emergency stop mechanism’ (see EN 60204,
9.2.5.4)
•If motor thermal protection is required, then a
n
external PTC must be used. (Refer to Sectio
n
2.2.5.)
•Lowering the fan tray on Frame Size
C
MICROMASTER exposes rotating parts.
Power must be isolated prior to this operation.
CAUTION
•Children and the general public must b
e
prevented from accessing or approaching th
e
equipment!
•This equipment may only be used for th
e
purpose specified by the manufacturer.
Unauthorised modifications and the use o
f
spare parts and accessories that are not sold
or recommended by the manufacturer of th
e
equipment can cause fires, electric shocks
and injuries.
•Keep these operating instructions within eas
y
reach and give them to all users!
European Low Voltage Directive
The MICROMASTER product range complies with the requirements
of the Low Voltage Directive 73/23/EEC as amended by Directive
98/68/EEC. The units are certified for compliance with the following
standards:
EN 60146-1-1 Semiconductor converters - General requirements
and line commutated converters
EN 60204-1 Safety of machinery - Electrical equipment of
machines
European Machinery Directive
The MICROMASTER inverter series does not fall under the scope of
the Machinery Directive. However, the products have been fully
evaluated for compliance with the essential Health & Safety
requirements of the directive when used in a typical machine
application. A Declaration of Incorporation is available on request.
European EMC Directive
When installed according to the recommendations described in this
manual, the MICROMASTER fulfils all requirements of the EMC
Directive as defined by the EMC Product Standard for Power Drive
Systems EN61800-3.
Underwriters Laboratories
ISO 9001
Siemens plc operates a quality management system, which complies
with the requirements of ISO 9001.
UL and CUL listed power
conversion equipment 5B33 for
use in a pollution degree 2
environment

English 1. OVERVIEW
G85139-H1750-U049-C1 © Siemens plc 199
9
19/08/99 4
1. OVERVIEW
The MICROMASTERS are a range of frequency inverters for controlling the speed of three phase AC motors.
Various models are available, ranging from the compact 120 W single phase input MICROMASTER up to the 7.5
kW three phase input MICROMASTER.
The inverters are microprocessor-controlled and use state of the art IGBT technology for reliability and
flexibility. A special pulse-width modulation method with selectable ultrasonic pulse frequency permits
extremely quiet motor operation. Inverter and motor protection is provided by comprehensive protective
functions.
For additional product information such as application examples, part numbers, operation with long cables etc,
please refer to catalog DA64 or http://www.con.siemens.co.uk
Features:
•Easy to install, program and commission.
•Closed loop control using a Proportional, Integral (PI) control loop function.
•High starting torque with automatic starting boost.
•Remote control capability via RS485 serial link using the USS protocol with the ability to control up to 31
inverters.
•A comprehensive range of parameters is provided to enable the inverters to be configured for use in
almost any application.
•Membrane-type front panel controls for simple operation.
•Built-in non-volatile memory for storing parameter settings.
•Factory default parameter settings pre-programmed for European and North American requirements.
•Output frequency (and hence motor speed) can be controlled by one of five methods:
(1) Frequency setpoint using the keypad.
(2) High resolution analogue setpoint (voltage input).
(3) External potentiometer to control motor speed.
(4) Fixed frequencies via binary inputs.
(5) Serial interface (US protocol, PROFIBUS, CANbus)
•Built-in DC injection brake with special COMPOUND BRAKING.
•Integral EMC filter on single phase input inverters (MM12 - MM300, and three phase input inverters
MM220/3F to MM750/3F
•Acceleration/deceleration times with programmable smoothing.
•Fully programmable single relay output incorporated.
•External Options connector for optional multi-language Clear Text Display (OPM2) optional PROFIBUS or
CANbus module.
•Automatic recognition of 2, 4, 6 or 8-pole motors by software.
•Integral software-controlled cooling fan.
•Fast Current Limit (FCL) for reliable trip-free operation.
•Compact design and the ability to mount inverters side by side provides greater space saving.

1. OVERVIEW English
© Siemens plc 1999 G85139-H1750-U049-C1
519/08/9
9
1.1 Installation - General notes
Environmental Requirements
Hazard Notes Ideal Installation
Temperature
Altitude
Shock
Vibration
Electro-
Magnetic
Radiation
Atmospheric
Pollution
Water
Overheating
Min. Operating = 0°C
Max. Operating = 50°C (MMV)
If the Inverter is to be installed at an altitude >1000m,
derating will be required. (Refer to DA64 Catalogue)
Do not drop the inverter or expose to sudden shock.
Do not install the inverter in an area where it is likely to
be exposed to constant vibration.
Do not install the inverter near sources of electro-
magnetic radiation.
Do not install the inverter in an environment, which
contains atmospheric pollutants such as dust,
corrosive gases, etc.
Take care to site the inverter away from potential
water hazards, e.g. do not install the inverter beneath
pipes that are subject to condensation. Avoid installing
the inverter where excessive humidity and
condensation may occur.
Mount the inverter vertically to ensure optimum
cooling. Additional ventilation may be required for
horizontal mounting.
Ensure that the inverter’s air vents are not obstructed,
including the air vent at the front of the unit, which
should be at least 15mm from any obstruction
Make sure that there is an adequate air-flow through
the cabinet, as follows:
1. Using the formula below, calculate the air-flow
required:
Air-flow (m3/ hr) = (Dissipated Watts / ∆T) x 3.1
2. If necessary, install cabinet cooling fan(s).
Note:
Dissipation (Watts) = 3-5% of inverter rating.
∆T = Allowable temperature rise within cabinet in °C.
3.1 = Specific heat of air at sea level.
160 mm
100 mm
Figure 1.1
Note: The Plastic Material of the case can be degraded by oil or grease. Care should be taken to
ensure that the mounting surface and fixings are thoroughly degreased before use.

English 1. OVERVIEW
G85139-H1750-U049-C1 © Siemens plc 199
9
19/08/99 6
1.2 Wiring Guidelines to Minimise the Effects of EMI
The inverters are designed to operate in an industrial environment where a high level of Electro-Magnetic
Interference (EMI) can be expected. Usually, good installation practices will ensure safe and trouble-free
operation. However, if problems are encountered, the following guidelines may prove useful. In particular,
grounding of the system 0V at the inverter, as described below, may prove effective. Figure 1.2.1- 3 illustrates
how an RFI suppression filter should be installed.
(1) Ensure that all equipment in the cubicle is well earthed using short, thick earthing cable connected to a
common star point or busbar. It is particularly important that any control equipment that is connected
to the inverter (such as a PLC) is connected to the same earth or star point as the inverter via a short,
thick link. Flat conductors (e.g. braids or metal brackets) are preferred as they have lower impedance
at high frequencies.
The return earth from motors controlled by the inverters should be connected directly to the earth
connection (PE) on the associated inverter.
(2) Wherever possible, use screened leads for connections to the control circuitry. Terminate the ends of
the cable neatly, ensuring that unscreened wires are as short as possible. Use cable glands whenever
possible.
(3) Separate the control cables from the power connections as much as possible, using separate trunking,
etc. If control and power cables cross, arrange the cables so that they cross at 90° if possible.
(4) Ensure that contactors in the cubicle are suppressed, either with R-C suppressors for AC contactors
or ‘flywheel’ diodes for DC contactors, fitted to the coils. Varistor suppressors are also effective. This
is particularly important if the contactors are controlled from the relay on the inverter.
(5) Use screened or armoured cables for the motor connections and ground the screen at both ends via
the cable glands.
(6) If the drive is to be operated in an Electromagnetically noisy environment, the RFI filter should be
used to reduce the conducted and radiated interference from the inverter. For optimum performance,
there should be a good conductive bond between filter and metal mounting plate.
(7) For FSA units (Fig 1.2.1), the flat earth braid strap, supplied with the unit, should be fitted to minimise
emissions .
On no account must safety regulations be compromised when installing inverters!

1. OVERVIEW English
© Siemens plc 1999 G85139-H1750-U049-C1
719/08/9
9
Figure 1.2.1: Wiring guidelines to minimise effects of EMI - MICROMASTER FSA
Figure 1.2.2: Wiring guidelines to minimise effects of EMI - MICROMASTER FSB
MAINS POWER INPUT
METAL BACK-PLATE
FOOTPRINT FILTER
CONTROL
CABLE
CONTROL
CABLE
Fix motor and control cable screens
securely to metal back plate using
suitable clips.
MAINS POWER INPUT
METAL BACK-PLATE
FOOTPRINT FILTER
CONTROL
CABLE
Fix motor and control cable screen
securely to metal back plate using
suitable clips.
EARTH BRAID EARTH BRAID

English 1. OVERVIEW
G85139-H1750-U049-C1 © Siemens plc 199
9
19/08/99 8
Figure 1.2.3: Wiring guidelines to minimise effects of EMI - MICROMASTER FSC
MAINS POWER INPUT
FOOTPRINT FILTER
METAL BACK-PLATE
Fix motor and control cable screen
securely to metal back plate using
suitable clips.

1. OVERVIEW English
© Siemens plc 1999 G85139-H1750-U049-C1
919/08/9
9
1.3 Electrical Installation - General Notes
1.3.1 Operation with Unearthed (IT) Supplies
The MICROMASTER will operate from unearthed supplies and will continue to operate if an input phase is
shorted to earth. If an output phase is shorted to earth, the MICROMASTER will trip and indicate F002.
1.3.2 Operation with Residual Current Device (RCD)
The MICROMASTER inverters will operate without nuisance tripping with an RCD (also called ELCBs or
RCCBs) fitted to the input providing:
•A type B RCD is used.
•The trip limit of the RCD is 300mA.
•The neutral of the supply is earthed.
•Only one inverter is supplied from each RCD.
•The output cables are less than 50m (screened) or 100m (unscreened).
1.3.3 Installation after a Period of Storage
It is necessary to reform the capacitors in the inverter if the unit has been stored for a prolonged period.
•Period of storage 1 year old or less:
No reforming is required.
•1 - 2 years old:
Apply power to the inverter one hour before giving the run command. (Preparation time 1 Hour)
•2 - 3 years old:
Use a variable AC supply. Apply 25% of input voltage for 30 minutes. Increase volts to 50% for a further
30 minutes. Increase volts to 75% for further 30 minutes. Increase volts to 100% for a further 30 minutes.
Now ready for run signal. (Preparation Time 2 hours)
•3 years and over:
As with 2 - 3 years, but the steps should be 2 hours. (Preparation Time 8 Hours)
1.3.4 Operation with Long Cables
Motor cable lengths vary depending on type of cable, power rating and voltage rating - and in some cases can
be as long as 200m without the need for additional chokes. Refer to DA64 catalogue for further details.
In any case, all inverters will operate at full specification with cable lengths up to 25m for screened cable or
50m for unscreened cables.

English 2. INSTALLATION
G85139-H1750-U049-C1 © Siemens plc 199
9
19/08/99 10
2. INSTALLATION
2.1 Mechanical Installation
WARNING
THIS EQUIPMENT MUST BE EARTHED.
To guarantee the safe operation of the equipment it must be installed and commissioned properly b
y
qualified personnel in compliance with the warnings laid down in these operating instructions.
Take particular note of the general and regional installation and safety regulations regarding work o
n
dangerous voltage installations (e.g. VDE), as well as the relevant regulations regarding the correc
t
use of tools and personal protective gear.
The mains input and motor terminals can carry dangerous voltages even if the inverter is inoperative
.
Use insulated screwdrivers only on these terminal blocks.
DIN Rail
Depth D
W
H2H1
F
∅
∅= 4.5 mm
Depth D
W
HH1
∅
∅=4.8 mm (B)
∅= 5.6 mm (C)
W1
Frame Size A Frame Sizes B and C
Frame size B:
4 bolts M4
4 nuts M4
4 washers M4
2 bolts M4
2 nuts M4
2 washers M4
Frame size C:
4 bolts M5
4 nuts M5
4 washers M5
HH2
Tightening Torque
(with washers fitted)
2.5 Nm Frame size A and B
3.0 Nm Frame size C

2. INSTALLATION English
© Siemens plc 1999 G85139-H1750-U049-C1
11 19/08/9
9
Model
MMxxx
1 AC 230 V
Class A
Filter
MMxxx/2
1/3 AC 230 V
Without
Filter
MMxxx/3
3 AC 380 -
500 V
Without
Filter
Frame Sizes
(all measurements in mm)
MM12
MM25
MM37
MM55
MM75
MM110
MM150
MM220
MM300
MM400
MM550
MM750
A
A
A
A
A
B
B
C
C
-
-
-
A
A
A
A
A
B
B
C
C
C
-
-
-
-
A
A
A
A
A
B*
B*
C*
C*
C*
H W D H1 H2 W1 F
A= 147 x 73 x 141 160 175 - 55
B= 184 x 149 x 172 174 184 138 -
C= 215 x 185 x 195 204 232 174 -
* These units also available with built in filter e.g. MM220/3F
Figure 2.1.1: Mechanical Installation Diagram
2.2 Electrical Installation
Read the Wiring Guidelines given in section 1.2 before commencing installation.
The electrical connectors on the MICROMASTER are shown in Figure 2.2.1. Connect the cables to the power
and control terminal blocks in accordance with the information supplied in sections 2.3.1 - 2.3.4. Ensure that
the leads are connected correctly and the equipment is properly earthed as shown in Figure 2.2.1.
CAUTION
The control, power supply and motor leads must be laid separately. They must not be fed
through the same cable conduit/trunking. High voltage insulation test equipment must not b
e
used on cables connected to the inverter.
Use screened cable for the control lead. Use Class 1 60/75oC copper wire only (for UL compliance). Tightening
torque for the power (mains input and motor) terminals is 1.1 Nm.
To tighten up the power/motor terminal screws use a 4 - 5 mm cross-tip screwdriver.
2.2.1 Power and Motor Connections - Frame Size A
Ensure that the power source supplies the correct voltage and is designed for the necessary current (see
section 7). Ensure that the appropriate circuit-breakers/fuses with the specified current rating are connected
between the power supply and inverter (see section 7).
Connect the power and motor connections as shown in Figure 2.2.1.
Fit the earth braid strap, supplied with the unit, between the PE faston connector and the mounting surface.
Ensure there is a good electrical connection between the mounting surface and the earth strap.
WARNING
Isolate the mains electrical supply before making or changing connections to the unit.
Ensure that the motor is confi
g
ured for the correct su
pp
l
y
volta
g
e. Sin
g
le/three
p
hase 230
V
MICROMASTERS must not be connected to a 400 V three phase supply.
When s
y
nchronous machines are connected or when cou
p
lin
g
several motors in
p
arallel, th
e
inverter must be operated with voltage/frequency control characteristic (P077= 0 or 2).

English 2. INSTALLATION
G85139-H1750-U049-C1 © Siemens plc 199
9
19/08/99 12
Control
Terminals
Mains Input
Terminals
Motor Terminal s
V
U
PE
PE L/L1 N/L2 L3
W
FUSE CONTACTOR
FILTER
(Class B only)
N
L
MICROMASTER
N
L3
L2
L1
PPPE
W
W
V
V
U
U
FUSES
TYPICAL INSTALLATION
CONTACTOR FILTER
L3
MICROMASTER
L1
L2
L3
L2
L1
PPE PE
W
W
V
V
U
U
MOTOR
MOTOR
THREE PHASE
SINGLE PHASE
Figure 2.2.1: Power Connections
Asynchronous and synchronous motors can be connected to the MICROMASTER
inverters either individually or in parallel.
Note:If a synchronous motor is connected to the inverter, the motor current may be
two and a half to three times greater than that expected, so, the inverter must be de-
rated accordingly.

2. INSTALLATION English
© Siemens plc 1999 G85139-H1750-U049-C1
13 19/08/9
9
2.2.2 Power and Motor Connections - Frame Size B
The terminal arrangement for frame size B is similar to frame size A (see Figure 2.2.1).
Refer to Figure 2.2.2 and proceed as follows:
B
A
Power Connections Access Diagram - Frame Size B
Removal of Terminal Cover- Frame Size B
D
E
C
FG
J
H
Removal of Gland Plate- Frame Size B
Figure 2.2.2
3. Remove the earthing screw C from the gland plate.
4. Press both release catches D and E to release the
gland plate and then remove the metal gland plate
from the inverter.
1. Insert the blade of a small screwdriver into slot A in the
front of the inverter and press in the direction of the arrow.
At the same time, press down on tab B at the side of the
access panel.
2. This will release the access panel, which will then swing
down on its rear-mounted hinges.
Note: The access panel can be removed from
the inverter when at an angle o
f
approximately 30° to the horizontal. I
f
allowed to swing lower, the panel will
remain attached to the inverter.
F: Control cable input
G: Mains cable input
H: Motor cable output
J: Braking resistor/ DC link cable input

English 2. INSTALLATION
G85139-H1750-U049-C1 © Siemens plc 199
9
19/08/99 14
5. Ensure that the power source supplies the correct voltage and is designed for the necessary current (see
section 7). Ensure that the appropriate circuit-breakers with the specified current rating are connected
between the power supply and inverter (see section 7).
6. For the power input, use a 3-core cable for single phase units or a 4-core cable for three phase units. For
the cross-section of each core see section 7.
7. Use a 4-core screened cable to connect the motor.
8. Carefully measure and cut the cable leads for power connections, motor connections and braking resistor
connections (if required) before feeding the screened cables through the glands in the metal gland plate
provided (see Figure 2.2.2) and securing the glands.
9. Carefully measure and cut the cable leads for the control connections (if required). Feed the control cable
through the correct gland (see Figure 2.2.2) and secure the gland to the metal gland-plate.
10. Carefully feed the power and control leads through the correct holes in the inverter housing.
11. Secure the metal gland plate to the underside of the inverter. Fit and tighten the earth securing screw.
12. Connect the power input leads to the power terminals L/L1 - N/L2 (1 phase) or L/L1, N/L2, L3 (3 phase),
and earth (PE) (shown in Figure 2.2.2 ) and torque down the screws.
13. Connect the motor leads to the motor terminals U, V, W and the earth (PE) (shown in Figure 2.2.2) and
torque down the screws.
Note: For operation with cables longer than 25m see section 1.3.
14. If required, secure Faston connectors to the braking resistor leads and fit the connectors to the B+/DC+
and B- terminals under the inverter.
15. Connect the control leads as shown in Figures 2.2.4 and 2.2.6, Section 2.2.4 and 2.2.6.
2.2.3 Power and Motor Connections - Frame Size C
The terminal arrangement for frame size C is identical to frame size A (see Figure 2.2.1). However, before the
wires can be connected to the terminal blocks, you must lower the fan housing and secure the cables to the
gland plate.
Refer to Figure 2.2.3 and proceed as follows:
1. While supporting the fan housing with one hand, insert the blade of a screwdriver into slot A on the
underside of the inverter and press upwards to release the securing tab. Lower the fan housing, allowing it
to swing out to the right on its side-mounted hinges.
2. Applying pressure to the gland plate release clips B and C in the direction of the arrows. Swing the plate
out to the left on its side-mounted hinges,
3. Secure each cable to the correct hole in the gland plate, ensuring that the exposed wires are long enough
to reach the terminal blocks.
4. Connect the wires to the terminal blocks as shown in Figure 2.2.1 (See section 2.2.4 for information about
connecting the control wires.) IT IS MOST IMPORTANT THAT THE MOTOR AND CONTROL WIRES
ARE KEPT APART.
5. Swing the gland plate back into the base of the inverter. Ensure that the release clips snap into position.
6. Swing the fan housing back into the base of the inverter.

2. INSTALLATION English
© Siemens plc 1999 G85139-H1750-U049-C1
15 19/08/9
9
A
B
C
D
E
F
G
Figure 2.2.3: Power Connections Access Diagram - Frame Size C
A
: Fan housing opening tab
B & C: Gland plate release tabs
D: Control cable input
E: Mains cable input
F: Motor cable input
G: Braking resistor/ DC link cable input
HJ
H: Fan connector
J: Fan Housing removal tab
To remove fan housing and fan disconnect fan
connector ‘H’, release tab ‘J’ in direction shown
and remove fan and housing in same direction.

English 2. INSTALLATION
G85139-H1750-U049-C1 © Siemens plc 199
9
19/08/99 16
2.2.4 Control Connections
1234 85 6 7 9 10 11
Power Supply
(+10 V, max. 10 mA)
Analogue Input
(0/2 - 10 V)
(input impedance = 70 kΩ)
Output Relay
(normally open)
max. 0.4 A / 110 V AC
1 A / 30 V DC
(resistive rating)
Digital Inputs
(7.5 - 33 V, max. 5 mA)
Power Supply
for
PI Feedback
Transducer or other
load
(+15 V, max. 50 mA)
P10+ 0V AIN+ AIN- P15+DIN1 DIN2 DIN3
RL1B
(NO)
RL1C
(COM)
0V
Control Terminal Block
Insert small blade screwdrive
r
(max. 3.5 mm) as shown whil
e
inserting control wire from below.
Front Panel
RS485 D-type
N-
0V
5V
(max.250 mA)
P+
6
1
5
9
Figure 2.2.4: Control Connections

2. INSTALLATION English
© Siemens plc 1999 G85139-H1750-U049-C1
17 19/08/9
9
2.2.5. External Motor Thermal Overload Protection
When operated below rated speed, the cooling effect of fans fitted to the motor shaft is reduced.
Consequentially, most motors require de-rating for continuous operation at low frequencies. To ensure that
motors are protected against overheating under these conditions, a PTC temperature sensor must be fitted to
the motor and connected to the inverter control terminals as shown in Figure 2.2.5.
Note: To enable the trip function, set parameter P051, P052 or P053 =19.
MOTOR
PTC
1kΩ
ΩΩ
Ω
8
9
7
Inverter Control
Terminals
Figure 2.2.5: Motor Overload PTC Connection
2.2.6 Block Diagram
P
Jog
M
PE U, V,
W
3 ~
CPU
A
D
SI
2
3
4
5
6
10
11
PE
1/3 AC 230 V
3 AC 380 - 500 V
L/L1, N/L2
or
L/L1, N/L2, L3
1
7
+10V
0V
–
+
24 V
OR
O
R
V
:0 - 10 V
2 - 10 V AIN
+
AIN-
DIN1
DIN
2
DIN
3
PE
RL1
≥
≥≥
≥4.7 kΩ
~
RL1B
RL1C
8+15V
0V
9
Power Supply for
PI Feedback
Transducer
or other load.
RS485
Figure 2.2.6: Block Diagram

English 3. FRONT PANEL CONTROLS & BASIC OPERATION
G85139-H1750-U049-C1 © Siemens plc 199
9
19/08/99 18
3. FRONT PANEL CONTROLS & BASIC OPERATION
3.1 Front Panel Controls
CAUTION
The digital frequency setpoint has been set at 5.00 Hz in the factory. This means that, it is no
t
necessary to enter a frequency setpoint via the ∆button or parameter P005 in order to test tha
t
the motor turns following a RUN command.
A
ll settings must only be entered by qualified personnel, paying particular attention to th
e
safety precautions and warnings.
The parameter settings required can be entered using the three parameterisation buttons (P, ∆and ∇) on the
front panel of the inverter. The parameter numbers and values are indicated on the four digit LED display.
FORWARD / REVERSE
Button
LED Display
RS485
Interface
RUN
Button
STOP
Button
Removable
Cover Strip
JOG
Button
UP / INCREASE
Fre
q
uenc
y
DOWN / DECREASE
Frequency
Parameterisation
Button
P
Jog
Pressing this button while the inverter is stopped causes it to start and run at the preset jog frequency. The
inverter stops as soon as the button is released. Pressing this button while the inverter is running has no
effect. Disabled if P123 = 0.
Press to start the inverter. Disabled if P121 = 0.
Press to stop the inverter. Press once for an OFF1 (see section 4.3). Press twice (or hold down) for an OFF2
(see section 4.3) to immediately remove voltage from the motor allowing the motor to coast to a halt without
ramp-down.
LED Display Displays frequency (default), parameter numbers or parameter values (when P is pressed) or fault codes.
Press to change the direction of rotation of the motor. REVERSE is indicated by a minus sign (values < 100)
or a flashing decimal point (values > 100). Disabled if P122 = 0
Press to INCREASE frequency. Used to change parameter numbers or values to higher settings during the
parameterisation procedure. Disabled if P124 = 0.
Press to DECREASE frequency. Used to change parameter numbers or values to lower settings during the
parameterisation procedure. Disabled if P124 = 0.
Press to access parameters. Disabled if P051 - P053 = 14 when using digital inputs. Press and hold to access
higher resolution for some parameters. See section 5
Figure 3.1: Front Panel
Jog
P

3. FRONT PANEL CONTROLS & BASIC OPERATION English
© Siemens plc 1999 G85139-H1750-U049-C1
19 19/08/9
9
3.2 Basic Operation
Refer to section 5 for a full description of each parameter.
3.2.1 General
(1) The inverter does not have a main power switch and is live when the mains supply is connected. It waits,
with the output disabled, until the RUN button is pressed or for the presence of a digital ON signal at
terminal 5 (rotate right) or terminal 6 (rotate left) - see parameters P051 - P053.
(2) If output frequency is selected to be displayed (P001 = 0), the corresponding setpoint is displayed
approximately every 1.5 seconds while the inverter is stopped.
(3) The inverter is programmed at the factory for standard applications on Siemens four-pole standard motors.
When using other motors it is necessary to enter the specifications from the motor's rating plate into
parameters P081 to P085 (see Figure 3.2.1). Note: Access to these parameters is not possible unless
P009 has been set to 002 or 003.
3Mot
IEC 56
IM B3
cosϕ0,81 cosϕ0,81
1LA5053-2AA20
Nr. E D510 3053
IP54 Rot. KL 16 I.Cl.F
12 022
60 Hz 440 V Y
0,34 A
0,14 kW
3310 /min
220/380 V
∆
/Y
0,12
2745
VDE 0530 S.F. - 1,15
/min
P081
P084
P083 P082 P085
0,61/0,35 A
50 Hz
kW
Figure 3.2.1: Typical Motor Rating Plate Example
Note: Ensure that the inverter is configured correctly to the motor, i.e. in the above example delta terminal
connection is for 220 V.
3.2.2 Initial Testing
(1) Check that all cables have been connected correctly (section 2) and that all relevant product and
plant/location safety precautions have been complied with.
(2) Apply mains power to the inverter.
(3) Ensure that it is safe to start the motor. Press the RUN button on the inverter. The display will change to 5.0 and
the motor shaft will begin to turn. It will take one second for the inverter to ramp up to 5 Hz.
(4) Press the STOP button. The display will change to 0.0 and the motor slow to a complete stop within one second.

English 3. FRONT PANEL CONTROLS & BASIC OPERATION
G85139-H1750-U049-C1 © Siemens plc 199
9
19/08/99 20
3.2.3 Basic Operation - 10 Step Guide
The basic method of setting up the inverter for use is described below. This method uses a digital frequency
setpoint and requires only the minimum number of parameters to be changed from their default settings. It
assumes that a standard Siemens four-pole motor is connected to the inverter (see section 3.2.1 if a different
motor type is being used).
Step /Action Button Display
1. Apply mains power to the inverter.
The display will alternate between the actual frequency (0.0 Hz) and the
requested frequency setpoint (5.0 Hz default).
2. Press the parameterisation button.
3. Press the ∆button until parameter P005 is displayed.
4. Press P to display the current frequency setpoint (5 Hz is the factory
default setting).
5. Press the ∆button to set the desired frequency setpoint
(e.g. 35 Hz).
6. Press P to lock the setting into memory.
7, Press the ∇button to return to P000.
8. Press P to exit the parameterisation procedure.
The display will alternate between the current frequency and the requested
frequency setpoint.
9. Start the inverter by pressing the RUN button.
The motor shaft will start to turn and the display will show that the inverter is
ramping up to the setpoint of 35 Hz.
Note
The setpoint will be achieved after 7 seconds (35 Hz/50 Hz x 10 s *).
If required, the motor speed (i.e. frequency) can be varied directly by using
the ∆∇buttons. (Set P011 to 001 to enable the new frequency setting to be
retained in memory during periods when the inverter is not running.)
10. Switch the inverter off by pressing the STOP button.
The motor will slow down and come to a controlled stop (takes 7 s **).
*Default ramp-up time is 10 s to reach 50 Hz (defined by P002 and P013).
** Default ramp-down time is 10 s from 50 Hz (defined by P003 and P013).
P
P
P
P
