Siemens SINAMICS G120 Assembly instructions

Power Module PM230, IP20 /
Push-through technology (PT)
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
SINAMICS
SINAMICS G120P
Power Module PM230, IP20 /
Push-through technology (PT)
Hardware Installation Manual
06/2014 Edition
06/2014
A5E34331322B AA
Fundamental safety
instructions
1
Introduction
2
Installing/mounting
3
Connecting
4
Service and maintenance
5
Technical specifications
6
Accessories
7
Appendix
A

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Division Digital Factory
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E34331322B AA
Ⓟ04/2015 Subject to change
Copyright © Siemens AG 2013 - 2014.
All rights reserved

Table of contents
1 Fundamental safety instructions.............................................................................................................. 7
1.1 General safety instructions .......................................................................................................7
1.2 Safety instructions for electromagnetic fields (EMF) ..............................................................10
1.3 Handling electrostatic sensitive devices (ESD) ......................................................................11
1.4 Industrial security ....................................................................................................................12
1.5 Residual risks of power drive systems....................................................................................13
2 Introduction........................................................................................................................................... 15
3 Installing/mounting ................................................................................................................................ 17
3.1 Installation conditions..............................................................................................................17
3.2 Power losses and air cooling requirements ............................................................................18
3.3 Mounting the Power Modules .................................................................................................20
3.3.1 Installing Power Modules........................................................................................................20
3.3.2 Dimension drawings and drilling dimensions for IP20 Power Modules ..................................22
3.3.2.1 Build-in Power Modules - IP20 ...............................................................................................22
3.3.3 Dimension drawings and drilling dimensions for PT Power Modules.....................................25
3.4 Control Unit installation ...........................................................................................................27
3.5 Installing supplementary components ....................................................................................27
4 Connecting ........................................................................................................................................... 29
4.1 Mains and Motor Connection..................................................................................................32
4.1.1 Permissible line supplies ........................................................................................................32
4.1.2 Connection overview PM230 ..................................................................................................36
4.1.3 Line connection.......................................................................................................................37
4.1.4 Motor cable length ..................................................................................................................38
4.1.5 Motor connection ....................................................................................................................39
4.1.6 Connection terminals at the inverter .......................................................................................39
4.2 EMC-compliant installation .....................................................................................................41
4.2.1 Avoiding electromagnetic influence (EMI) ..............................................................................41
4.2.2 Installing the converter in compliance with EMC rules ...........................................................43
4.2.3 EMC-compliant cabinet design ...............................................................................................44
4.2.4 Cabling....................................................................................................................................46
4.2.5 Equipotential bonding .............................................................................................................48
4.2.6 EMC-compliant wiring.............................................................................................................51
5 Service and maintenance...................................................................................................................... 53
5.1 Maintenance ...........................................................................................................................53
5.2 Replacing the cooling fan .......................................................................................................54
Power Module PM230, IP20 / Push-through technology (PT)
Hardware Installation Manual, 06/2014, A5E34331322B AA 5

Table of contents
6 Technical specifications ........................................................................................................................ 57
6.1 General technical data (400 V inverters) ............................................................................... 58
6.2 Specific technical data ........................................................................................................... 62
6.3 Restrictions for special ambient conditions............................................................................ 68
6.3.1 Current de-rating depending on the operating temperature .................................................. 68
6.3.2 Current and voltage derating dependent on the installation altitude ..................................... 69
6.3.3 Current and power limiting depending on the line voltage..................................................... 69
6.3.4 Current reduction depending on pulse frequency.................................................................. 70
6.4 Permissible shock and vibration values................................................................................. 70
6.5 Electromagnetic compatibility of the inverter ......................................................................... 71
6.5.1 Assigning the inverter to EMC categories.............................................................................. 73
6.5.2 EMC limit values in South Korea ........................................................................................... 75
7 Accessories .......................................................................................................................................... 77
7.1 Mounting Frames ................................................................................................................... 77
7.2 Line filters............................................................................................................................... 79
A Appendix .............................................................................................................................................. 81
A.1 Manuals and technical support .............................................................................................. 81
A.1.1 Manuals for your inverter ....................................................................................................... 81
A.1.2 Configuring support................................................................................................................ 82
A.1.3 Product Support ..................................................................................................................... 82
A.2 Standards............................................................................................................................... 83
A.3 Abbreviations ......................................................................................................................... 84
Index .................................................................................................................................................... 85
Power Module PM230, IP20 / Push-through technology (PT)
6Hardware Installation Manual, 06/2014, A5E34331322B AA

Fundamental safety instructions
1
1.1
General safety instructions
DANGER
Danger to life due to live parts and other energy sources
Death or serious injury can result when live parts are touched.
•Only work on electrical devices when you are qualified for this job.
•Always observe the country-specific safety rules.
Generally, six steps apply when establishing safety:
1. Prepare for shutdown and notify all those who will be affected by the procedure.
2. Disconnect the machine from the supply.
–Switch off the machine.
–Wait until the discharge time specified on the warning labels has elapsed.
–Check that it really is in a no-voltage condition, from phase conductor to phase
conductor and phase conductor to protective conductor.
–Check whether the existing auxiliary supply circuits are de-energized.
–Ensure that the motors cannot move.
3. Identify all other dangerous energy sources, e.g. compressed air, hydraulic systems, or
water.
4. Isolate or neutralize all hazardous energy sources by closing switches, grounding or
short-circuiting or closing valves, for example.
5. Secure the energy sources against switching on again.
6. Ensure that the correct machine is completely interlocked.
After you have completed the work, restore the operational readiness in the inverse
sequence.
WARNING
Danger to life through a hazardous voltage when connecting an unsuitable power supply
Touching live components can result in death or severe injury.
•Only use power supplies that provide SELV (Safety Extra Low Voltage) or PELV-
(Protective Extra Low Voltage) output voltages for all connections and terminals of the
electronics modules.
Power Module PM230, IP20 / Push-through technology (PT)
Hardware Installation Manual, 06/2014, A5E34331322B AA 7

Fundamental safety instructions
1.1 General safety instructions
WARNING
Danger to life when live parts are touched on damaged devices
Improper handling of devices can cause damage.
For damaged devices, hazardous voltages can be present at the enclosure or at exposed
components; if touched, this can result in death or severe injury.
•Ensure compliance with the limit values specified in the technical data during transport,
storage and operation.
•Do not use any damaged devices.
WARNING
Danger to life through electric shock due to unconnected cable shields
Hazardous touch voltages can occur through capacitive cross-coupling due to unconnected
cable shields.
•As a minimum, connect cable shields and the conductors of power cables that are not
used (e.g. brake cores) at one end at the grounded housing potential.
WARNING
Danger to life due to electric shock when not grounded
For missing or incorrectly implemented protective conductor connection for devices with
protection class I, high voltages can be present at open, exposed parts, which when
touched, can result in death or severe injury.
•Ground the device in compliance with the applicable regulations.
WARNING
Danger to life due to electric shock when opening plug connections in operation
When opening plug connections in operation, arcs can result in severe injury or death.
•Only open plug connections when the equipment is in a no-voltage state, unless it has
been explicitly stated that they can be opened in operation.
WARNING
Danger to life due to fire spreading if housing is inadequate
Fire and smoke development can cause severe personal injury or material damage.
•Install devices without a protective housing in a metal control cabinet (or protect the
device by another equivalent measure) in such a way that contact with fire is prevented.
•Ensure that smoke can only escape via controlled and monitored paths.
Power Module PM230, IP20 / Push-through technology (PT)
8Hardware Installation Manual, 06/2014, A5E34331322B AA

Fundamental safety instructions
1.1 General safety instructions
WARNING
Danger to life through unexpected movement of machines when using mobile wireless
devices or mobile phones
Using mobile wireless devices or mobile phones with a transmit power > 1 W closer than
approx. 2 m to the components may cause the devices to malfunction, influence the
functional safety of machines therefore putting people at risk or causing material damage.
•Switch the wireless devices or mobile phones off in the immediate vicinity of the
components.
WARNING
Danger to life due to the motor catching fire in the event of insulation overload
There is higher stress on the motor insulation through a ground fault in an IT system. If the
insulation fails, it is possible that death or severe injury can occur as a result of smoke and
fire.
•Use a monitoring device that signals an insulation fault.
•Correct the fault as quickly as possible so the motor insulation is not overloaded.
WARNING
Danger to life due to fire if overheating occurs because of insufficient ventilation clearances
Inadequate ventilation clearances can cause overheating of components with subsequent
fire and smoke. This can cause severe injury or even death. This can also result in
increased downtime and reduced service lives for devices/systems.
•Ensure compliance with the specified minimum clearance as ventilation clearance for
the respective component.
WARNING
Danger of an accident occurring due to missing or illegible warning labels
Missing or illegible warning labels can result in accidents involving death or serious injury.
•Check that the warning labels are complete based on the documentation.
•Attach any missing warning labels to the components, in the national language if
necessary.
•Replace illegible warning labels.
Power Module PM230, IP20 / Push-through technology (PT)
Hardware Installation Manual, 06/2014, A5E34331322B AA 9

Fundamental safety instructions
1.2 Safety instructions for electromagnetic fields (EMF)
NOTICE
Device damage caused by incorrect voltage/insulation tests
Incorrect voltage/insulation tests can damage the device.
•Before carrying out a voltage/insulation check of the system/machine, disconnect the
devices as all converters and motors have been subject to a high voltage test by the
manufacturer, and therefore it is not necessary to perform an additional test within the
system/machine.
WARNING
Danger to life when safety functions are inactive
Safety functions that are inactive or that have not been adjusted accordingly can cause
operational faults on machines that could lead to serious injury or death.
•Observe the information in the appropriate product documentation before
commissioning.
•Carry out a safety inspection for functions relevant to safety on the entire system,
including all safety-related components.
•Ensure that the safety functions used in your drives and automation tasks are adjusted
and activated through appropriate parameterizing.
•Perform a function test.
•Only put your plant into live operation once you have guaranteed that the functions
relevant to safety are running correctly.
Note
Important safety notices for Safety Integrated functions
If you want to use Safety Integrated functions, you must observe the safety notices in the
Safety Integrated manuals.
1.2
Safety instructions for electromagnetic fields (EMF)
WARNING
Danger to life from electromagnetic fields
Electromagnetic fields (EMF) are generated by the operation of electrical power equipment
such as transformers, converters or motors.
People with pacemakers or implants are at a special risk in the immediate vicinity of these
devices/systems.
•Ensure that the persons involved are the necessary distance away (minimum 2 m).
Power Module PM230, IP20 / Push-through technology (PT)
10 Hardware Installation Manual, 06/2014, A5E34331322B AA

Fundamental safety instructions
1.3 Handling electrostatic sensitive devices (ESD)
1.3
Handling electrostatic sensitive devices (ESD)
Electrostatic sensitive devices (ESD) are individual components, integrated circuits, modules
or devices that may be damaged by either electric fields or electrostatic discharge.
NOTICE
Damage through electric fields or electrostatic discharge
Electric fields or electrostatic discharge can cause malfunctions through damaged
individual components, integrated circuits, modules or devices.
•Only pack, store, transport and send electronic components, modules or devices in their
original packaging or in other suitable materials, e.g conductive foam rubber of
aluminum foil.
•Only touch components, modules and devices when you are grounded by one of the
following methods:
–Wearing an ESD wrist strap
–Wearing ESD shoes or ESD grounding straps in ESD areas with conductive flooring
•Only place electronic components, modules or devices on conductive surfaces (table
with ESD surface, conductive ESD foam, ESD packaging, ESD transport container).
Power Module PM230, IP20 / Push-through technology (PT)
Hardware Installation Manual, 06/2014, A5E34331322B AA 11

Fundamental safety instructions
1.4 Industrial security
1.4
Industrial security
Note
Industrial security
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, solu
tions, machines, equipment and/or networks. They are
important components in a holistic industrial security concept. With this in mind, Siemens’
products and solutions undergo continuous development. Siemens recommends strongly
that you regularly check for
product updates.
For the secure operation of Siemens products and solutions, it is necessary to take suitable
preventive action (e.g. cell protection concept) and integrate each component into a holistic,
state
-of-the-art industrial security concept. Third-party products that may be in use should
also be considered. For more information about industrial security, visit Hotspot
-Text
(
http://www.siemens.com/industrialsecurity).
To stay informed ab
out product updates as they occur, sign up for a product-specific
newsletter. For more information, visit Hotspot
-Text
(
http://support.automation.siemens.com).
WARNING
Danger as a result of unsafe operating states resulting from software manipulation
Software manipulation (e.g. by viruses, Trojan horses, malware, worms) can cause unsafe
operating states to develop in your installation which can result in death, severe injuries
and/or material damage.
•Keep the software up to date.
You will find relevant information and newsletters at this address
(http://support.automation.siemens.com).
•Incorporate the automation and drive components into a holistic, state-of-the-art
industrial security concept for the installation or machine.
You will find further information at this address
(http://www.siemens.com/industrialsecurity).
•Make sure that you include all installed products into the holistic industrial security
concept.
Power Module PM230, IP20 / Push-through technology (PT)
12 Hardware Installation Manual, 06/2014, A5E34331322B AA

Fundamental safety instructions
1.5 Residual risks of power drive systems
1.5
Residual risks of power drive systems
The control and drive components of a drive system are approved for industrial and
commercial use in industrial line supplies. Their use in public line supplies requires a
different configuration and/or additional measures.
These components may only be operated in closed housings or in higher-level control
cabinets with protective covers that are closed, and when all of the protective devices are
used.
These components may only be handled by qualified and trained technical personnel who
are knowledgeable and observe all of the safety instructions on the components and in the
associated technical user documentation.
When assessing the machine's risk in accordance with the respective local regulations (e.g.,
EC Machinery Directive), the machine manufacturer must take into account the following
residual risks emanating from the control and drive components of a drive system:
1. Unintentional movements of driven machine components during commissioning,
operation, maintenance, and repairs caused by, for example,
–Hardware and/or software errors in the sensors, control system, actuators, and cables
and connections
–Response times of the control system and of the drive
–Operation and/or environmental conditions outside the specification
–Condensation/conductive contamination
–Parameterization, programming, cabling, and installation errors
–Use of wireless devices/mobile phones in the immediate vicinity of the control system
–External influences/damage
2. In the event of a fault, exceptionally high temperatures, including an open fire, as well as
emissions of light, noise, particles, gases, etc. can occur inside and outside the inverter,
e.g.:
–Component failure
–Software errors
–Operation and/or environmental conditions outside the specification
–External influences/damage
Inverters of the Open Type/IP20 degree of protection must be installed in a metal control
cabinet (or protected by another equivalent measure) such that contact with fire inside
and outside the inverter is not possible.
Power Module PM230, IP20 / Push-through technology (PT)
Hardware Installation Manual, 06/2014, A5E34331322B AA 13

Fundamental safety instructions
1.5 Residual risks of power drive systems
3. Hazardous shock voltages caused by, for example,
–Component failure
–Influence during electrostatic charging
–Induction of voltages in moving motors
–Operation and/or environmental conditions outside the specification
–Condensation/conductive contamination
–External influences/damage
4. Electrical, magnetic and electromagnetic fields generated in operation that can pose a
risk to people with a pacemaker, implants or metal replacement joints, etc., if they are too
close
5. Release of environmental pollutants or emissions as a result of improper operation of the
system and/or failure to dispose of components safely and correctly
Note
The components must be protected against conductive contamination (e.g. by installing them
in a control cabinet with degree of protection IP54 according to IEC 60529 or NEMA 12).
Assuming that conductive contamination at the i
nstallation site can definitely be excluded, a
lower degree of cabinet protection may be permitted.
For more information about residual risks of the components in a drive system, see the
relevant sections in the technical user documentation.
Power Module PM230, IP20 / Push-through technology (PT)
14 Hardware Installation Manual, 06/2014, A5E34331322B AA

Introduction
2
PM230 Power Module
The PM230 Power Module is part of the modular family of SINAMICS G120 inverters.
PM230 Power Modules have been specifically designed for pump and fan drives in HVAC
applications.
They are available with class A filter or no filter in a power range from 0.37 kW … 75 kW and
a line voltage range from 3 AC 380 V … 480 V.
The Power Modules can be used with the following Control Units including all communication
variants with firmware version 4.4 or higher.
●CU230P-2
●CU240B-2
●CU240E-2
Operation with any other Control Units as listed above is not permitted.
Note
Failsafe functions are not supported by the PM230.
Power Module PM230, IP20 / Push-through technology (PT)
Hardware Installation Manual, 06/2014, A5E34331322B AA 15

Introduction
Power Module PM230, IP20 / Push-through technology (PT)
16 Hardware Installation Manual, 06/2014, A5E34331322B AA

Installing/mounting
3
3.1
Installation conditions
When installing the Power Modules carefully observe the conditions listed below in order to
guarantee reliable, continuous and disturbance-free operation.
●The Power Module is designed for installation in a control cabinet.
●It provides protection against the ingress of solid foreign objects ≥ 12.5 mm.
●It does not provide any protection against the ingress of dust or liquids.
●For EMC-compliant installation, please observe Section Connecting (Page 29).
WARNING
To ensure the safe operation of the equipment, it must be installed and commissioned by
qualified personnel in full compliance with the warnings laid down in this manual.
Take particular note of the general and regional installation and safety regulations
regarding work on dangerous voltage installation (e.g. EN 61800-5-1) as well as the
relevant regulations regarding the correct use of tools and personal protective equipment
(PPE).
Power Module PM230, IP20 / Push-through technology (PT)
Hardware Installation Manual, 06/2014, A5E34331322B AA 17

Installing/mounting
3.2 Power losses and air cooling requirements
3.2
Power losses and air cooling requirements
Cooling requirements
Depending on the power loss of the individual components, the control cabinet will require a
cooling airflow to prevent the components from overheating.
Formula for calculating the cooling airflow:
•
Power loss:
Total of the power losses of the individual components.
•
Δ T
Permissible temperature rise in the electrical cabinet
Measures in order to ensure that the components are adequately cooled
1. Add the power losses of the individual components.
–For the Power Module, apply the data in Section "Specific technical data (Page 62)".
–The power loss of the CU is less than 0.04 kW.
–Use the manufacturers data for components, for example reactors or filters
2. Calculate the air flow required, using the formula above.
3. Ensure that the control cabinet is appropriately ventilated and equipped with suitable air
filters.
4. Ensure that the components have the specified clearances with respect to one another.
5. Ensure that the components are provided with adequate cooling air through the cooling
openings.
6. Use the appropriate air barriers to prevent cooling air short circuits
Power Module PM230, IP20 / Push-through technology (PT)
18 Hardware Installation Manual, 06/2014, A5E34331322B AA

Installing/mounting
3.2 Power losses and air cooling requirements
Figure 3-1 Air barriers for avoiding cooling air short circuits
The power loss values specified in the technical data refer to the values specified for an
output frequency of 50 Hz.
Special features of Power Modules with push-through technology (PT Power Modules)
When you use PT Power Modules, the majority of the power loss is dissipated through the
heatsink located outside the control cabinet.
Power Module PM230, IP20 / Push-through technology (PT)
Hardware Installation Manual, 06/2014, A5E34331322B AA 19

Installing/mounting
3.3 Mounting the Power Modules
3.3
Mounting the Power Modules
3.3.1
Installing Power Modules
Mounting Power Modules with degree of protection IP20
Procedure
Proceed as follows to correctly mount the Power Module:
1. Mount the Power Module in a control cabinet.
2. Maintain the minimum clearances to other components in the control cabinet specified
below.
3. Install the Power Modules vertically with the line and motor connections facing
downwards. It is not permissible to install them in any other position.
4. Position the Power Module in the control cabinet so that the cables for the motor and line
supply are connected in accordance with the terminal layout.
5. Use the mounting devices specified below.
6. Comply with the torques of the mounting devices specified below.
You have correctly mounted the Power Module.
Power Module PM230, IP20 / Push-through technology (PT)
20 Hardware Installation Manual, 06/2014, A5E34331322B AA
