Siemens Opdima MAMMOMAT 1000 Instructions and recipes

MAMMOMAT 1000/3000/3000 Nova - Opdima?
Register 3 English
Print No.: SPB7-230.033.10.03.02 Doc. Gen. Date: 08.02
Replaces: SPB7-230.033.10.02.02 66 08 744
© Siemens AG 2002
The reproduction, transmission or
use of this document or its contents
is not permitted without express
written authority. Offenders will be
liable for damages. All rights,
including rights created by patent
grant or registration of a utility
model _or_design,_are_reserved.
Installation
Installation and Start-Up Instructions

Opdima?Register 3 SPB7-230.033.10 Page 2 of 4 Siemens-Elema AB
Installation Rev. 03 08.02 SPS-UD Solna, Sweden
0 - 2 Revision
Chapter Page Revision
All All 03

Contents 0 - 3
Siemens-Elema AB Register 3 SPB7-230.033.10 Page 3 of 4 Opdima?
Solna, Sweden Rev. 03 08.02 SPS-UD Installation
1 _______Prerequisites __________________________________________________1 - 1
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
MAMMOMAT with serial number lower than 2091 . . . . . . . . . . . . . . . . . . . 1 - 1
MAMMOMAT with serial number within the interval 2091-3241. . . . . . . . . . . . . 1 - 1
MAMMOMAT with serial number within the interval 3242-5199. . . . . . . . . . . . . 1 - 1
Training of customer support engineers. . . . . . . . . . . . . . . . . . . . . . . . . 1 - 2
Text emphasis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 2
Documents required. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3
CD-ROMs required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3
Meters and appliances required. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3
Tools required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3
Additional installation material required . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3
Start-up, DHHS and X-ray decree area of application . . . . . . . . . . . . . . . . . 1 - 4
Notes on start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4
Checking and recording for the area of application of the X-ray decree
(§16 Germany). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4
Checking and data recording in the USA . . . . . . . . . . . . . . . . . . . . . . 1 - 4
2 _______Protective measures for CCD camera______________________________2 - 1
3 _______Protective measures ____________________________________________3 - 1
4 _______Preparatory work_______________________________________________4 - 1
Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2
Workstation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2
Biopsy controller, miscellaneous . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2
Optional equipment and update kits. . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2
5 _______Installation ____________________________________________________5 - 1
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1
Sub-assemblies, overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1
Removal of MAMMOMAT stand covers. . . . . . . . . . . . . . . . . . . . . . . . . 5 - 2
MAMMOMAT stand with separate rear side covers. . . . . . . . . . . . . . . . . 5 - 2
Left rear side cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 2
Right rear side cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 2
Middle rear cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 2
MAMMOMAT stand with single rear cover . . . . . . . . . . . . . . . . . . . . . 5 - 3
Rear cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 3
Installation of biopsy controller holders . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 4
Modification of MAMMOMAT stand . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 6
Modification of MAMMOMAT generator. . . . . . . . . . . . . . . . . . . . . . . . . 5 - 6
Replacing board D702. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 6
Replacing software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 7
Installing isolation board D707. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 7
Page

Opdima?Register 3 SPB7-230.033.10 Page 4 of 4 Siemens-Elema AB
Installation Rev. 03 08.02 SPS-UD Solna, Sweden
0 - 4 Contents
Restoring installation parameters. . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 8
Connection of cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 9
Cables to MAMMOMAT generator (and printer if present) . . . . . . . . . . . . .5 - 10
Cables to biopsy unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 13
Power connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 13
Cables to CCD camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 14
Installation of cable duct . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 16
Modification of cable outlet cover. . . . . . . . . . . . . . . . . . . . . . . . . .5 - 16
Installation of workstation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 17
Preparing the workstation table (option) . . . . . . . . . . . . . . . . . . . . . .5 - 17
Connecting the workstation. . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 20
Connecting the workstation to the network . . . . . . . . . . . . . . . . . . . . .5 - 24
Installation of Opdima printer (option) . . . . . . . . . . . . . . . . . . . . . . .5 - 24
Strain relieving the cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 26
Functional test (workstation table) . . . . . . . . . . . . . . . . . . . . . . . . .5 - 26
6 ______ Final procedures _______________________________________________6 - 1
General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
Starting up the MAMMOMAT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
Starting up the workstation and login. . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
Starting up the MO unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
Installation of software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
Mounting of covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
Filling in of LINA CARD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
Performing of DHHS maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
7 ______ Changes to previous version _____________________________________7 - 1
Page

1 - 1
Siemens-Elema AB Register 3 SPB7-230.033.10 Page 1 of 4 Opdima?
Solna, Sweden Rev. 03 08.02 SPS-UD Installation
Prerequisites 1
General 1
Depending on the serial number of your MAMMOMAT, complementary measures may
have to be performed when installing Opdima?. Where necessary, the measures are
described in these instructions. The following has to be carried out with all serial numbers:
•InstallationofisolationboardD707 (kitpartNo.6396 704)in the generator,ifnotalready
donein conjunctionwithinstallationof printer(option)
•Thewall socket for the workstationpowersupplymust be connected to thesame branch
circuit as the MAMMOMAT power supply
•ThisInstallationand Start-UpInstructionis validforOpdima?systems;
-with SUN workstationpartNo. 64 30453/ Ultra 10 fromserial number 1201
MAMMOMAT with serial number lower than 2091 1
The following has to be carried out:
•Exchangeof printedcircuitboard D702(kit part No. 6421 288) in the generator
•UpgradeoftheMAMMOMATsoftware(generatorand stand)toV2.2 (partNo.
6298 769,if the versionto be upgradedis lowerthanV1.5, the AEChaveto be
upgraded,seeUpdateInstruction,UI 001/96)
•Performanceof“Stereotacticbiopsyattachmentupdate”according to MAMMOMAT
3000Installationand Setting InstructionsUpdate Kitfor StereotacticBiopsyAttachment
RX B7-230.033.02...
MAMMOMAT with serial number within the interval 2091-3241 1
The following has to be carried out:
•Exchangeof board D702 (kitpartNo. 6421288)in the generator
•UpgradeoftheMAMMOMATsoftware(generatorand stand)toV2.2(partNo.
6298 769,if the versionto be upgradedis lowerthanV1.5, the AEChaveto be
upgraded,seeUpdateInstruction,UI 001/96)
MAMMOMAT with serial number within the interval 3242-5199 1
The following has to be carried out:
•UpgradeoftheMAMMOMATsoftware(generatorand stand)toV2.2(partNo.
6298 769,if the versionto be upgradedis lowerthanV1.5, the AEChaveto be
upgraded,seeUpdateInstruction,UI 001/96)

Opdima?Register 3 SPB7-230.033.10 Page 2 of 4 Siemens-Elema AB
Installation Rev. 03 08.02 SPS-UD Solna, Sweden
1 - 2 Prerequisites
Training of customer support engineers 1
Due to the technology used in this equipment, setup, service and maintenance may only
be carried out by a customer support engineer who has attended a training workshop or
has participated in at least one installation.
Text emphasis 1
DANGER indicates when there is an immediate danger that leads
to death or serious physical injury.
WARNING indicates a risk of danger that may lead to death or to
serious physical injury.
CAUTION used with the safety alert symbol indicates a risk of
danger that leads to slight or moderate physical injury and/or
damage to property.
NOTICE used without the safety alert symbol indicates a risk of
danger that if disregarded leads or may lead to a potential situa-
tion which may result in an undesirable result or state other than
death, physical injury or damage to property.
NOTE contains information provided with special emphasis to
facilitate proper use of the equipment or proper execution of a
procedure, i.e. hints, tips.
DANGER
WARNING
CAUTION
NOTICE
NOTE

Prerequisites 1 - 3
Siemens-Elema AB Register 3 SPB7-230.033.10 Page 3 of 4 Opdima?
Solna, Sweden Rev. 03 08.02 SPS-UD Installation
Documents required 1
•Supplementtothe Instructionsfor Use MAMMOMAT 3000 -Opdima?
(includedintheOpdima?delivery)
•MAMMOMAT 1000/3000/3000Nova -Opdima?Service Instructions
(includedintheOpdima?delivery)
•MAMMOMAT 300/3000,MAMMOMAT3000Modularincl.StereotacticBiopsy
AttachmentandOpdima?DHHS MaintenanceInstructions
(includedintheOpdima?delivery)
•MAMMOMAT 300/3000,MAMMOMAT3000Modularincl.StereotacticBiopsy
AttachmentandOpdima?MeasurementCertificates
(includedintheOpdima?delivery)
•MAMMOMAT 1000/3000/3000Nova -Opdima?PlanningGuide
•InstallationInstructionsforIsolationP.c. Board D707,RX B7-120.031.04... (where
applicable)
•MAMMOMAT 1000/3000/3000Nova Installationand Start-Up Instructions
•MAMMOMAT 1000/3000Nova WiringDiagram
•MAMMOMAT 3000InstallationandSettingInstructionsUpdate Kit forStereotactic
BiopsyAttachment(where applicable)
•TechnicalInformationTI 219
CD-ROMs required 1
•Ultra10 Service Manual, part No. 65 27670 (includedinthe Opdima?delivery)
Meters and appliances required 1
•Protectivegroundwiretester(4415 899 RV090)
•ServicePC (e.g.Siemens-NixdorfPCD 3NSX/20orsimilar)withconnectingcable,PC to
generator(part No.99 00440RE999)
•Stereocalibrationphantom (includedinthe delivery)(partNo.6430701)
•Acrylicplastic (PMMA) plates, four plates measuring150 mmx 150mm x 20mm and
one platemeasuring 150 mm x 150 mm x 10mm, part No.85 49 438 and 9788 423
respectively
•Resolutionphantom with atleast10 linepairsper mm
•4.5cm PMMA
Tools required 1
•Standardinstallation tools
•Electricdrill with5 mm drill
Additional installation material required 1
•Extensionmainscordwithatleastthreeoutlets,of protectiveearthtype

Opdima?Register 3 SPB7-230.033.10 Page 4 of 4 Siemens-Elema AB
Installation Rev. 03 08.02 SPS-UD Solna, Sweden
1 - 4 Prerequisites
Start-up, DHHS and X-ray decree area of application 1
Notes on start-up 1
Opdima?is adjusted, programmed and tested in the factory, leaving only the connection
to the on-site mains voltage, the functional tests and customer dependent adjustments to
be performed.
Checking and recording for the area of application of the X-ray decree
(§16 Germany) 1
An X-ray unit can only be put into operation if an acceptance test has been performed
according to §16 RoeV. It is recommended that the responsible Customer Service
Engineer is present to assist the person responsible for this acceptance test.
Checking and data recording in the USA 1
Maintenance measurements must be made according to the instructions in MAMMOMAT
300/3000, MAMMOMAT 3000 Modular incl. Stereotactic Biopsy Attachment and Opdima?
DHHS Maintenance Instructions.
Sections
•Requiredlabels
•Reproducibility
•Automaticexposure control(AEC)
The result must be recorded in the document MAMMOMAT 300/3000, MAMMOMAT 3000
Modular incl. Stereotactic Biopsy Attachment and Opdima?Measurement Certificates.

2 - 1
Siemens-Elema AB Register 3 SPB7-230.033.10 Page 1 of 2 Opdima?
Solna, Sweden Rev. 03 08.02 SPS-UD Installation
Protective measures for CCD camera 2
The camera shall be used within 1030?C.
The camera shall be transported or stored within 040?C.
The CCD camera is very sensitive to mechanical shocks and tem-
perature changes. In the camera shock and temperature sensors
are integrated.
Risk of damaging the equipment.
The camera has to be handled with extreme care.
When disconnected from the biopsy controller, the camera shall
always be stored in the attachécase delivered with the system.
Do not touch the pins in the contacts of the camera.
CAUTION

Opdima?Register 3 SPB7-230.033.10 Page 2 of 2 Siemens-Elema AB
Installation Rev. 03 08.02 SPS-UD Solna, Sweden
2 - 2 Protective measures for CCD camera
This page intentionally left blank.

3 - 1
Siemens-Elema AB Register 3 SPB7-230.033.10 Page 1 of 2 Opdima?
Solna, Sweden Rev. 03 08.02 SPS-UD Installation
Protective measures 3
It is very important that any intervention in the equipment shall start with disconnecting it
from the power supply with the main circuit breaker. To prevent accidental triggering of
high voltage and radiation, set the switch S2 (SS) on board D702 to OFF (lower position,
no triggering of the SS relay).
Shut down the application software before switching off the
power for the workstation (see Logout and turning off the work-
station in Supplement to the Instructions for Use MAMMOMAT
3000 - Opdima?).
Switching off the workstation before the software has been
closed down may cause damage to the files on the hard disc.
If the system is only switched off at the control panel or with S2/
D711 in the MAMMOMAT generator, line voltage will still be
present at the generator line connection, line filter Z1, Z2, trans-
former T1, transformer T10 and board D711 (see MAMMOMAT
1000/3000 Nova Wiring Diagram).
Life-threatening electric shock hazard exists.
Disconnect mains cable and comply with the information on this
page.
After shut-down of the system, there may still be about 380 V DC
present on the intermediate circuit of the MAMMOMAT generator.
Life-threatening electric shock hazard exists.
The voltage level will be indicated by LED V24 on board D710. The
voltage will drop to less than 30 V within about 3 minutes, the LED
goes out at about 30 V.
The boards contain electrostatic highly sensitive components
requiring particular care in their handling.
Risk of damaging components.
Use ESD-equipment, ground prior to making contact and place
the components on a conductive surface, see Technical Informa-
tion TI 219.
CAUTION
WARNING
WARNING
CAUTION

Opdima?Register 3 SPB7-230.033.10 Page 2 of 2 Siemens-Elema AB
Installation Rev. 03 08.02 SPS-UD Solna, Sweden
3 - 2 Protective measures
This page intentionally left blank.

4 - 1
Siemens-Elema AB Register 3 SPB7-230.033.10 Page 1 of 2 Opdima?
Solna, Sweden Rev. 03 08.02 SPS-UD Installation
Preparatory work 4
Scope of delivery 4
The following parts are always included in the delivery of your equipment:
•Technical Manual comprising information for installation, operationand service
•CCD camera with afixedcable
•Biopsycontrollerwith fivecables and cableduct
•Workstationincluding:
-power supply cable
-networkcable
-monitor
-keyboard
-mouse
- MO unit with one powersupply cableand one datacable
-Main unit includingCD drive
If ordered, the following is delivered:
•Biopsyunit
•Compressionplatefor biopsyexamination
•Printedcircuitboard D702
•MAMMOMAT software V2.2 orhigher
•Isolationp.c. board D707 kit
•DICOM license key
•Workstationtable
•Printer

Opdima?Register 3 SPB7-230.033.10 Page 2 of 2 Siemens-Elema AB
Installation Rev. 03 08.02 SPS-UD Solna, Sweden
4 - 2 Preparatory work
Unpacking 4
General 4
Workstation 4
The workstation is packed in a card board box which also contains technical
documentation and CDs for application software and operating system*.
Biopsy controller, miscellaneous 4
The biopsy controller is packed in a card board box together with cables, miscellaneous
installation material.
CCD camera
The CCD camera is packed in an attachécase. Keep the case for future use.
Optional equipment and update kits 4
If optional equipment and/or update kits are ordered, these are packed in separate boxes.
Follow the directional marks on the box during transport, storage
and unpacking.
*. Only needed if a software reinstallation is necessary (see MAMMOMAT 1000/3000/3000 Nova - Opdima?Service
Instructions). Store the documentation and software CDs in a proper place for future service use.
The CCD camera is very sensitive to mechanical shocks and tem-
perature changes. In the camera shock and temperature sensors
are integrated.
Risk of damaging the equipment.
The camera has to be handled with extreme care.
When disconnected from the biopsy controller, the camera shall
always be stored in the attachécase delivered with the system.
Do not touch the pins in the contacts of the camera.
NOTE
CAUTION

5 - 1
Siemens-Elema AB Register 3 SPB7-230.033.10 Page 1 of 26 Opdima?
Solna, Sweden Rev. 03 08.02 SPS-UD Installation
Installation 5
General 5
Before starting the installation, a backup of the installation parameters of the
MAMMOMAT has to be carried out.
1. Connect aPC to the MAMMOMAT andstart the service program.
2. SelectMain menu => Backup => Copyinstallationarea to disk => All.
Thiswillstoretheinstallationparameterson the harddiskofthePC.
3. SelectMain menu => Backup => Copyinstallation area to floppy => All.
Thiswillstoretheinstallationparametersonthe servicediskette.
4. SwitchofftheMAMMOMAT.
Sub-assemblies, overview 5
The components shall be placed according to the figure below.
The workstation shall be placed at least 1.5 m from the object
table of the stand.
X
Y
Z
mm
mm
mm
X
Y
Z
X
Y
Z
Z
X
Y
HEWLETT
PACKARD
Biopsy
controller
Biopsy unit
CCD camera
Generator
Workstation
Stand with
X-ray unit Workstation table
Fig. 1 MAMMOMAT 3000 Nova with digital biopsy and spot imaging system Opdima ?
NOTE

Opdima?Register 3 SPB7-230.033.10 Page 2 of 26 Siemens-Elema AB
Installation Rev. 03 08.02 SPS-UD Solna, Sweden
5 - 2 Installation
Removal of MAMMOMAT stand covers 5
MAMMOMAT stand with separate rear side covers 5
Left rear side cover 5
1. Remove thescrew (5/Fig.2) at thetop of the stand.
2. Pryloosethe plasticstrip(2/Fig.2) using ascrewdriveror similartool.
3. Removethescrews(3/Fig.2)and remove thecover(6/Fig.2).
Right rear side cover 5
1. Remove thescrew (1/Fig.2), proceed asfor the left side cover andremove the
rightside cover(4/Fig.2).
Middle rear cover 5
1. Removethetwo screws(7/Fig.2)at the topof thestand.
2. Removethecover(8/Fig.2)by liftingit up.
High voltage!
Life-threatening electric shock hazard exists.
Switch off the power to the system with the main circuit breaker.
WARNING
9
74
8
6
3
2
OPD00150
1
5
Fig. 2 Removal of covers

Installation 5 - 3
Siemens-Elema AB Register 3 SPB7-230.033.10 Page 3 of 26 Opdima?
Solna, Sweden Rev. 03 08.02 SPS-UD Installation
MAMMOMAT stand with single rear cover 5
Rear cover 5
1. Removethe screws(1/Fig.3) at the topofthestand.
2. Pryloose the plastic strips(2/Fig.3)on both sidesusing a screwdriveror similar
tool.
3. Removethe screws(3/Fig.3) on both sidesand removethecover(4/Fig.3).
High voltage!
Life-threatening electric shock hazard exists.
Switch off the power to the system with the main circuit breaker.
WARNING
1
2
3
OPD00266
4
Fig. 3 Removal of covers

Opdima?Register 3 SPB7-230.033.10 Page 4 of 26 Siemens-Elema AB
Installation Rev. 03 08.02 SPS-UD Solna, Sweden
5 - 4 Installation
Installation of biopsy controller holders 5
The biopsy controller is attached to the rear cover of the stand. To install the holders
proceed as follows:
1. Attachthetwo drillingtemplates(1/Fig. 4) includedin thisdocumenton theinside
ofthe rear cover accordingto Fig. 4. ThetemplatemarkedB shallbe placed
underneaththe templatemarked A withno spacebetweenthem.Make sure that
thetemplatesare centered and thatthe sides ofthe templatesare parallelto the
rearcoversides.
2. Drill five holes with a 5 mm drill in the rear cover according to the templates.
3. Installthe threeholders(2/Fig.4) byusingthenuts(3/Fig.4).
4. Installthe twostandoffs(4/Fig.4) byusingthescrews(5/Fig.4)and the washers
(6/Fig.4).
UP
OPD00267
985 –5 mm
3
45
2
1
A
B
6
Fig. 4 Rear cover, from the back side

Installation 5 - 5
Siemens-Elema AB Register 3 SPB7-230.033.10 Page 5 of 26 Opdima?
Solna, Sweden Rev. 03 08.02 SPS-UD Installation
5. Installthe rearcover (2/Fig.5) onthestandand attachthe biopsycontroller
(1/Fig.5) to theholders.Switch onthe power-onswitchon the biopsy controller.
OPD00152
1
2
Fig. 5 Biopsy controller

Opdima?Register 3 SPB7-230.033.10 Page 6 of 26 Siemens-Elema AB
Installation Rev. 03 08.02 SPS-UD Solna, Sweden
5 - 6 Installation
Modification of MAMMOMAT stand 5
MAMMOMAT with serial number lower than 5200 must be updated with new software.
1. ReplacetheexistingsoftwareonboardD801 withthe V2.2 (orhigher) software.
Modification of MAMMOMAT generator 5
Replacing board D702 5
MAMMOMAT with serial number lower than 3242 must be updated with a new board
D702.
1. Pryloosethe plasticstrips(1/Fig.6), usinga screwdriverorsimilartool.
2. Removethesixteen screws (2/Fig.6) and remove thefront cover (3/Fig.6).
3. Remove theboard D702 in Fig.7 from thegenerator.
4. InstallsoftwareV2.2 (or higher) on thenew boardD702.
5. Installthe newboardD702Fig. 7 inthegenerator.
If upgrading from a version lower than V1.5, the AEC have to be
upgraded, see Update Instruction, UI 001/96.
If upgrading from a version lower than V1.5, the AEC have to be
upgraded, see Update Instruction, UI 001/96.
NOTE
OPD00153
3
1
2
Fig. 6 Removal of generator front cover
NOTE
