Siemens Pointek CLS200 User manual

Capacitance Switches
Operating Instructions 04/2011
Pointek CLS200/CLS300 (Digital)

© Siemens AG 2011
Safety Guidelines: Warning notices must be observed to ensure personal safety as well as that of
others, and to protect the product and the connected equipment. These warning notices are
accompanied by a clarification of the level of caution to be observed.
Qualified Personnel: This device/system may only be set up and operated in conjunction with this
manual. Qualified personnel are only authorized to install and operate this equipment in accordance with
established safety practices and standards.
Unit Repair and Excluded Liability:
•The user is responsible for all changes and repairs made to the device by the user or the user’s
agent.
•All new components are to be provided by Siemens Milltronics Process Instruments.
•Restrict repair to faulty components only.
•Do not reuse faulty components.
Warning: Cardboard shipping package provides limited humidity and moisture protection. This product
can only function properly and safely if it is correctly transported, stored, installed, set up, operated, and
maintained.
This product is intended for use in industrial areas. Operation of this equipment in a residential area
may cause interference to several frequency based communications.
Note: Always use product in accordance with specifications.
Copyright Siemens AG 2011. All Rights
Reserved
Disclaimer of Liability
This document is available in bound version and in
electronic version. We encourage users to purchase
authorized bound manuals, or to view electronic
versions as designed and authored by Siemens
Milltronics Process Instruments. Siemens Milltronics
Process Instruments will not be responsible for the
contents of partial or whole reproductions of either
bound or electronic versions.
While we have verified the contents of this
manual for agreement with the
instrumentation described, variations remain
possible. Thus we cannot guarantee full
agreement. The contents of this manual are
regularly reviewed and corrections are
included in subsequent editions. We welcome
all suggestions for improvement.
Technical data subject to change.
MILLTRONICS®is a registered trademark of Siemens Milltronics Process Instruments.
Contact SMPI Technical Publications European Authorized Representative
at the following address:
Technical Publications Siemens AG
Siemens AG Industry Sector
Siemens Milltronics Process Instruments 76181 Karlsruhe
1954 Technology Drive, P.O. Box 4225 Deutschland
Peterborough, Ontario, Canada, K9J 7B1
Email: [e-mail]
•For a selection of Siemens Milltronics level measurement manuals, go to:
www. siemens.com/processautomation. Under Process Instrumentation, select
Level
Measurement
and then go to the manual archive listed under the product family.
•For a selection of Siemens Milltronics weighing manuals, go to:
www. siemens.com/processautomation. Under Weighing Technology, select
Continuous
Weighing Systems
and then go to the manual archive listed under the product family.

i
mmmmm
Table of Contents
Table of Contents
Safety Notes ...........................................................................................................................................1
Safety marking symbols ............................................................................................................1
The Manual ...............................................................................................................................................1
Application Examples .................................................................................................................2
Technical Support ....................................................................................................................................3
Abbreviations and Identifications ...........................................................................................3
Pointek CLS200/300 Digital ............................................................................................... 5
Applications ..............................................................................................................................................6
Features .....................................................................................................................................................6
System Implementation .........................................................................................................................7
Programming ................................................................................................................................7
Specifications ......................................................................................................................8
Installation: Pointek CLS200 Digital .............................................................................. 15
Location ..................................................................................................................................................15
Mounting .................................................................................................................................................15
Mounting Restrictions ..............................................................................................................16
CLS200 Dimensions ..................................................................................................................17
Process Cautions .................................................................................................................................18
Installation: Pointek CLS300 Digital ..............................................................................20
Location ..................................................................................................................................................20
Mounting .................................................................................................................................................20
Mounting Restrictions ..............................................................................................................21
Process Cautions .................................................................................................................................22
CLS300 Dimensions ..............................................................................................................................23
Wiring: CLS200/300 Digital ..............................................................................................24
Electrical Connection ...........................................................................................................................24
Recommended Cable Entries (equivalents can be used) ...........................................................25
Connection to screw terminals ..............................................................................................27
Local Operation: Pointek CLS200/300 Digital (Standalone) ......................................29
Local User Interface (LUI) ...................................................................................................................29
Input keypad ...............................................................................................................................29
LCD display (local operation) .................................................................................................29
Programming via the Local User Interface (LUI) ...........................................................................32
Mode selection and adjustment ............................................................................................32
Status codes ...............................................................................................................................35
Error messages .........................................................................................................................35
Mode 2: Sensor test (default: OFF) .......................................................................................36
Mode 4: Rise Time (default: 0.0 s) .........................................................................................37
Mode 5: Fall Time (default: 0.0 s) ...........................................................................................37
Mode 10: HW Write Protection (default: OFF, display – –) .............................................38

ii
mmmmm
Table of Contents
Mode 13: Display Source (default: 0) ...................................................................................38
Mode 14: Unit (default: °C) ......................................................................................................39
Mode 15: Node address (default: 126) .................................................................................39
Mode 16: PROFIBUS Ident Number (default: 1) .................................................................40
Mode 19: 0% Application Range setting ..............................................................................40
Mode 20: 100% Application Range setting .........................................................................41
Mode 23: Alarm output trigger (default: dIAG) ...................................................................43
Mode 24: Contact type (default: CLOSE) ..............................................................................44
Mode 25: Switch Point Off to On/Switch Point 1/Rising Edge (default: 55%) .............44
Mode 26: Switch Point On to Off/ Falling Edge (default: 45%) ........................................45
Mode 27: Local Status Text (default: U_075) ......................................................................46
CLS200 Digital Switching Point Setup ..............................................................................................46
CLS300 Digital Switching Point Setup ..............................................................................................48
Wiring: connecting CLS200/300 Digital to a PROFIBUS PA network .....................50
Electrical Connection ...........................................................................................................................50
PROFIBUS PA connection to screw terminals ..................................................................51
PROFIBUS PA connection via M12 plug .............................................................................52
Remote Operation via PROFIBUS PA ............................................................................53
SIMATIC PDM ........................................................................................................................................53
Electronic Device Description (EDD) ....................................................................................53
Configuration ..............................................................................................................................53
Setting the PROFIBUS address .............................................................................................54
Bus Termination ........................................................................................................................54
Power Demands ........................................................................................................................54
Cyclic versus Acyclic Data .....................................................................................................54
Status .......................................................................................................................................................55
Status Byte .................................................................................................................................55
Configuration Example .............................................................................................................62
PROFIBUS PA Parameters ...............................................................................................63
Measured Values ..................................................................................................................................63
Functions .....................................................................................................................................64
Changing parameter settings .................................................................................................64
Filling level status: .....................................................................................................................65
Lock ..............................................................................................................................................71
Sensor Test .................................................................................................................................72
Display Source for local operation .......................................................................................72
Appendix A: Technical References ...............................................................................73
Operating Principles .............................................................................................................................73
High Frequency Oscillator ...................................................................................................................73
Detection Range ....................................................................................................................................74
The Pointek CLS200 electrode ...........................................................................................................74
The Pointek CLS300 electrode ...........................................................................................................75
Sensor Test .............................................................................................................................................76
PROFIBUS PA electronics: mode of operation ..............................................................................77
Pointek CLS200 Digital Pressure versus Temperature Curves ..................................................78
CLS200 compact and extended rod versions, threaded ..................................................78

iii
mmmmm
Table of Contents
CLS200 cable version, threaded ............................................................................................78
CLS200 sanitary compact and extended rod versions .....................................................78
CLS200 compact and extended rod, ASME welded flange ............................................79
CLS200 cable, ASME welded flange ....................................................................................79
CLS200 compact and extended rod, EN welded flange ...................................................79
CLS200 cable, EN welded flange ...........................................................................................80
Pointek CLS300 Digital Pressure versus Temperature Curves ..................................................80
CLS300 standard, extended rod and cable versions, threaded .....................................80
CLS300 high temperature rod version, threaded ...............................................................80
CLS300 standard, extended rod and cable versions, ASME welded flange ..............81
CLS300 high temperature rod version, ASME welded flange ........................................81
CLS300 standard, extended rod and cable versions, EN welded flange .....................82
CLS300 high temperature rod version, EN welded flange ..............................................82
Appendix B: Maintenance and Repairs .......................................................................83
Unit Repair and Excluded Liability ....................................................................................................83
Appendix C: Profile structure – Pointek CLS200/300 (PROFIBUS PA) ....................84
PROFIBUS PA electronics: mode of operation ..............................................................................84
Block model for recording and processing measured values ...................................................85
Parameters for local digital display ......................................................................................86
Description of the blocks .....................................................................................................................86
Transducer Block ......................................................................................................................86
Discrete Input Function Block ................................................................................................88
Appendix D: Product Nameplates .................................................................................89
Pointek CLS200 ......................................................................................................................................89
Pointek CLS300 ......................................................................................................................................90
Appendix E: Hazardous Area Installation ....................................................................91
Instructions specific to hazardous area installations ..................................................................91
Operating the CLS200 Intrinsically Safe configuration in hazardous areas ...........................92
Operating the CLS200 Flameproof / Explosion Proof configuration in hazardous areas ....93
Operating the CLS300 Intrinsically Safe configuration in hazardous areas ...........................93
Operating the CLS300 Flameproof / explosion proof configuration in hazardous areas ....94
Appendix F: Dimensions - CLS200 Digital ....................................................................95
Appendix G: CLS300 Digital Dimensions .................................................................... 103
Threaded Processs Connection ..........................................................................................103
High Temperature Rod Version, threaded .................................................................................... 105
Non-insulated Cable Version, threaded ............................................................................106
Insulated Cable Version, threaded ................................................................................................. 107
CLS300 - Flanged Process Connections ............................................................................108
Flange Facing Table ...............................................................................................................108

iv
mmmmm
Table of Contents
Rod Version, welded flange ............................................................................................................. 109
High Temperature Rod Version, welded flange ...........................................................................110
Non-insulated Cable Version, welded flange ..............................................................................111
Insulated Cable Version, welded flange ........................................................................................112
Appendix H: Shortening the cable .............................................................................. 113
Pointek CLS200 Digital, Cable Version ...............................................................................113
Pointek CLS300 Digital, Cable Version ...............................................................................116
Index .................................................................................................................................. 119

7ML19985JJ03 Pointek CLS200/300 Digital – OPERATING INSTRUCTIONS Page 1
mmmmm
Pointek CLS200/300
Safety Notes1
Special attention must be paid to warnings and notes highlighted from the rest of the text
by grey boxes.
Safety marking symbols
The Manual
Pointek CLS200/300 is available in two models, Standard and Digital. For information on
the CLS200/300 Standard model, please see manual 7ML19985JH02.
This manual will help you set up your Pointek CLS200/300 Digital for optimum
performance. There are two installation options:
• the unit can be used as a standalone device, controlled locally
• the unit can be installed on a network, and controlled either remotely via PROFIBUS
PA, or locally using the local user interface (LUI)
1. This symbol is used when there is no corresponding caution symbol on the product.
WARNING: relates to a caution symbol on the product, and means
that failure to observe the necessary precautions can result in
death, serious injury, and/or considerable material damage.
WARNING1: means that failure to observe the necessary
precautions can result in death, serious injury, and/or considerable
material damage.
Note: means important information about the product or that part of the operating
manual.
In manual On Product Description
WARNING: refer to accompanying documents (manual)
for details.
Earth (ground) Terminal
Protective Conductor Terminal
Note: Please follow the installation and operating procedures for a quick, trouble-free
installation and to ensure the maximum accuracy and reliability of your Pointek CLS200/
300. This manual applies to the Pointek CLS200/300 Digital models only.
Note: This manual applies to CLS200/300 Digital devices manufactured
after August 2010. For Units manufactured prior to August 2010 please use
Operating Instructions 7ML19985JJ01.

P
Page 2 Pointek CLS200/300 Digital – OPERATING INSTRUCTIONS 7ML19985JJ03
mmmmm
Pointek CLS200/300
Sections in this manual are designated as follows:
1. Digital: Information is applicable to any CLS200/300 Digital unit (indicated by Digital
in the page footers)
•
Pointek CLS200/300 Digital - an introduction to Pointek CLS200/300 Digital model
and to the manual
•
Specifications
• Installation: Pointek CLS200 Digital
• Appendix A: Technical References
• Appendix B: Maintenance and Repairs
• Appendix D: Product Nameplates
• Appendix E: Hazardous Area Installation
• Appendix F: Dimensions - CLS200 Digital
• Appendix G: CLS300 Digital Dimensions
• Appendix H: Shortening the cable
2. Standalone: Information is applicable to units installed as a standalone device
(indicated by Standalone in the page footers), and to units installed on a PROFIBUS
PA network:
•
Wiring: CLS200/300 Digital
• Local Operation: Pointek CLS200/300 Digital (Standalone)
3. PROFIBUS PA: Information is applicable only to units connected to PROFIBUS PA
(indicated by PA on the side tabs and PROFIBUS PA in the page footers).
•
Wiring: connecting CLS200/300 Digital to a PROFIBUS PA network
• Remote Operation via PROFIBUS PA
• PROFIBUS PA Parameters
• Appendix C: Profile structure – Pointek CLS200/300 (PROFIBUS PA)
We always welcome suggestions and comments about manual content, design, and
accessibility. Please direct your comments to [email protected]om.
For other Siemens Milltronics level measurement manuals, go to:
www.siemens.com/level and look under Level Measurement.
Application Examples
The application examples used in this manual illustrate typical installations using
Pointek CLS200/300; other configurations may also apply.
In all examples, substitute your own application details. If the examples do not apply to
your application, check the applicable parameter reference for the available options.

7ML19985JJ03 Pointek CLS200/300 Digital – OPERATING INSTRUCTIONS Page 3
mmmmm
Pointek CLS200/300
Technical Support
Support is available 24 hours a day.
To find your local Siemens Automation Office address, phone number and fax number go
to:
www.siemens.com/automation/partner
• Click on the tab Contacts by Product then drill down to find your product group
(+Process Automation > +Process Instrumentation > +Level Measuring
Instruments).
• Select the team Te ch ni cal Su pp or t . Click on Next.
• Click on the appropriate continent, then select the country followed by the city.
Click on Next.
For on-line technical support go to:
www.siemens.com/automation/support-request
• Enter the device name or order number, then click on Search, and select the
appropriate product type. Click on Next.
• You will be prompted to enter a keyword describing your issue. Then either
browse the relevant documentation, or click on Next to email a detailed
description of your issue to Siemens Technical Support staff.
Siemens IA/DT Technical Support Center: phone [phone]
Abbreviations and Identifications
Short form Long Form Description Units
CE / FM / CSA Conformitè Europèene / Factory
Mutual / Canadian Standards
Association
safety approval
εrrelative dielectric
constant
ESD Electrostatic Discharge
Ex Explosion Proof safety approval
Exd Flame Proof method of protection
for a hazardous area
FEP Fluorinated Ethylene Polymer modified polymer
FKM/FPM Fluorelastomer
FFKM/FFPM Perfluoroelastomer
IS Intrinsically Safe method of protection
for a hazardous area
LCD Liquid Crystal Display
LUI Local User Interface

P
Page 4 Pointek CLS200/300 Digital – OPERATING INSTRUCTIONS 7ML19985JJ03
mmmmm
Pointek CLS200/300
μFmicro Farads 10-6 Farad
μs micro Seconds 10-6 Seconds
NC normally closed relay contact position
NO normally open relay contact position
pF pico Farads 10-12 Farad
PDM Process Device Manager configuration tool
PEEK Polyaryletheretherketone organic polymer
PPS Polyphenylene Sulfide polymer
PTFE Polytetrafluoroethylene thermoplastic
fluoropolymer
PVDF Polyvinylidene Fluoride engineered
fluoropolymer
Short form Long Form Description Units

7ML19985JJ03 Pointek CLS200/300 Digital – OPERATING INSTRUCTIONS Page 5
mmmmm
Pointek CLS200/300
Pointek CLS200/300 Digital
Pointek CLS200/300 is a versatile capacitance switch, ideal for level detection of
interfaces, solids, liquids, slurries, and foam, and for simple pump control. The switch
responds to the presence of any material with a relative dielectric constant of 1.5 or more
by detecting a change in capacitance, which is registered as a change in oscillating
frequency.
The switch can be set to detect before contact or on contact with the probe. The design
of the CLS200 Digital allows the instrument to operate independently of the tank wall or
pipe, so it does not require an external reference electrode for level detection in a non-
conductive vessel such as concrete or plastic1. The CLS300 Digital requires a connection
to earth/ground for effective capacitance measurement.
The power supply is galvanically isolated and can accept voltages in the range 12 to
30 V DC (12 to 24 V DC for Intrinsically Safe (IS) models), depending on the application.
The materials used in the probe construction provide a high level of chemical resistance,
and an excellent temperature rating on the process wetted portion of the probe: up to
125 °C (257 °F) for the CLS200 and 400 °C (752 °F) for the CLS300.
Notes:
• Pointek CLS200/300 is available in two models: the standard model, and the digital
model with integral local display. For information on the CLS200/300 Standard,
please see manual 7ML19985JH02.
• Pointek CLS200/300 is to be used only in the manner outlined in this instruction
manual, otherwise protection provided by the equipment may be impaired.
• This product is intended for use in industrial areas. Operation of this equipment in a
residential area may cause interference to several frequency based
communications.
1. Refer to
Approvals - CLS200 on page 13 for CE applications.
window in lid
integral local
display
standalone unit unit on a network
window in lid
integral local
display
hub or gland/
optional
M12 plug
hub or gland

P
Page 6 Pointek CLS200/300 Digital – OPERATING INSTRUCTIONS 7ML19985JJ03
mmmmm
Pointek CLS200/300
Modular design and construction provide a wide choice of configurations, including rod,
cable, and sanitary versions. Pointek CLS200/300 Digital can be used either:
• as a standalone unit, programmed locally using the local user interface, or
• installed as part of a network, programmed remotely using SIMATIC PDM on a
Profibus PA network (or locally using the Local User Interface).
Applications
Level Detection
Pointek CLS200/300 is designed for level detection and simple pump control in a variety of
applications:
• Liquids, solids (powder and granules), slurries, interface detection (for example, oil/
water), and foam detection
• Foods and pharmaceuticals
• Chemical and petrochemical
• High pressure and temperature
Alarm signalling
The solid-state switch can be set to react either to a diagnosed fault in the instrument, or
to a change in the process level.
Fault Signalling
Pointek CLS200/300 can actively report information on its own status via PROFIBUS PA
when used as part of a network, or by means of a pre-defined output status at the solid
state switch and on the Local User Interface (LUI).
Features
• Potted construction protects components from shock, vibration, humidity, and/or
condensation
• High chemical resistance on probes
• Level detection independent of tank wall/pipe (CLS200 only)1
• Freely programmable set up covers wide range of applications/materials
• Integrated Local User Interface (LUI) for ease of use
• Rigid and cable versions available
• Communication via PROFIBUS PA (profile version 3.0, Class B)
• Intrinsically Safe (IS) transmitter design for hazardous areas (requires external
barrier or IS power supply)
• Patented Active Shield minimizes the effect of product build-up at the sensor
mounting point (CLS300 only)
1. Refer to
Approvals - CLS200 on page 13 for CE applications.

7ML19985JJ03 Pointek CLS200/300 Digital – OPERATING INSTRUCTIONS Page 7
mmmmm
Pointek CLS200/300
System Implementation
Pointek CLS200/300 supports PROFIBUS communication protocol, and SIMATIC PDM
software.
Programming
Pointek CLS200/300 carries out its level measurement function according to the set of
built-in parameters. You can make parameter changes locally via the local user interface,
or from a remote location via a PC using SIMATIC PDM software.
Basic PLC configuration with PROFIBUS PA
PROFIBUS PA
PROFIBUS DP
DP/PA
coupler
active PLC
PC/laptop
PDM
Pointek CLS30 0
(PROFIBUS PA)
Pointek CLS200
(PROFIBUS PA)
Pointek CLS200
(PROFIBUS PA)

Page 8 Pointek CLS200/300 Digital – OPERATING INSTRUCTIONS 7ML19985JJ03
mmmmm
Specifications
Specifications
Pointek CLS200/300
Power
•busvoltage
- general purpose 12 to 30 V DC, 12.5 mA
- Intrinsically Safe 12 to 24 V DC, 12.5 mA
•startingcurrent<
current of normal operation yes
• fault current (max. uninterrupted current
minus current of normal operation) 0 mA
• fault disconnect equipment (FDE) yes
• auxiliary source bus powered
• separate supply necessary no
Performance
Repeatability approx. ± 2 mm for a conductive
fluid
Interface
Configuration
• locally, using local user interface (LUI), for standalone operation, or
• remotely, using SIMATIC PDM on a Profibus PA network
Local Digital Display
•LCD
Output (bus) PROFIBUS PA (IEC 61158 CPF3 CP3/2)
Bus physical layer: IEC 61158-2 MBP(-IS)
• polarity-independent yes
• simultaneous communication
with Master Class 2 4 (max.)
Cyclic User data (normal operation)
• byte output 2 bytes representing one value
• byte input 0
• device profile PROFIBUS PA Profile for Process Control
Devices Version 3.0, Class B
• function blocks 1
• discrete input 1
Note: Siemens Milltronics makes every attempt to ensure the accuracy of these
specifications, but reserves the right to change them at any time.

7ML19985JJ03 Pointek CLS200/300 Digital – OPERATING INSTRUCTIONS Page 9
mmmmm
Specifications
• logical inversion parameterizable
Simulation functions
•output yes
• input yes
• failsafe parameterizable (last usable value,
substitute value, erroneous value)
Block Structure
•physicalblock 1
• transducer block 1
• transducer block discrete input yes
• monitoring measuring limits yes
Alarm Outputs
• solid-state switch galvanically isolated
non-polarity sensitive transistor
rated 30V DC or peak AC max., 82mA max
voltage drop below 1 V typical @ 50 mA
• time delay controlled by software
2 delay timers: alarm ON delay and alarm OFF delay)
• hysteresis 100% adjustable, in 1 count increments1on the display
• failsafe operation Failsafe High or Failsafe Low
• terminal removable terminal block, 2.5 mm2max.
Diagnostics
• input reed contact: for test function
1. The frequency value is always represented in ‘counts’: see
Counts on page 73 for
more detail.

Page 10 Pointek CLS200/300 Digital – OPERATING INSTRUCTIONS 7ML19985JJ03
mmmmm
Specifications
Mechanical
Electrode - CLS200 Digital1
Model Length
(max)
Process
Connections Extension Tensile
(max) Wetted Parts
Rod 5500 mm/
216.5”
• Threaded:
¾”, 1", or 1 ½"
BSPT (R), BSPP
(G) or NPT; 1 ¼”
NPT only
• Welded flange:
ASME: 1”, 1 ½”, 2”,
3” or 4”
DN 25, 40, 50, 80
or 100
316L¹
stainless
steel
n/a •316L
1stainless
steel (optional
PFA coating)
• FKM seals
(optional FFKM)
• PPS probe
(optional PVDF)
Sanitary 5500 mm/
216.5”
1", 1 ½ ", 2”, 2 ½"
and 3”sanitary
clamp
316L¹
stainless
steel
n/a •316L
1stainless
steel
• FKM seals
(optional FFKM)
• PPS probe
(optional PVDF)
Cable 30000 mm/
1181.1”
• Threaded:
¾ ", 1", or 1 ½"
BSPT (R), BSPP
(G) or NPT; 1 ¼”
NPT only
• Welded flange:
ASME: 1”, 1 ½”, 2”,
3” or 4”
DN 25, 40, 50, 80
or 100
FEP
(Fluorinated
Ethylene
Polymer)
180 kg/
400 lbs
•316L
1stainless
steel
• FEP jacketed
cable
• FKM seals
(optional FFKM)
• PPS probe
(optional PVDF)
1. Or 1.4404 material.

7ML19985JJ03 Pointek CLS200/300 Digital – OPERATING INSTRUCTIONS Page 11
mmmmm
Specifications
Electrode - CLS300 Digital1
Active Shield Length (CLS300 only):
Model Length
(max)
Process
Connections
Tensile
(max) Wetted Parts
Rod
(19 mm/
0.75” dia.)
1000 mm/40” • Threaded:
¾”, 1", or 1 ½" BSPT
(R), BSPP (G) or NPT;
1 ¼” NPT only
• Welded flange:
ASME: 1”, 1 ½”, 2”, 3” or
4”
DN 25, 40, 50, 80 or
100
n/a • 316L1stainless steel
• FKM seals (optional
FFKM)
• PFA lining on Active
Shield
• PEEK isolators
Cable 25000 mm/
985”
• Threaded:
1 ½" BSPT (R), BSPP
(G) or NPT; 1 ¼” NPT
only
• Welded flange:
ASME: 1 ½”, 2”, 3” or
4”
DN 40, 50, 80 or 100
1900 kg/
4188 lbs
• 316L1stainless steel
Active Shield and
cable weight
• 316L1stainless steel
cable (optional PFA
jacketed cable)
• FKM seals (optional
FFKM)
• PEEK isolators
High
Tem pera ture
version
1000 mm/40” • Threaded:
¾”, 1", or 1 ½" BSPT
(R), BSPP (G) or NPT;
1 ¼” NPT only
• Welded flange:
ASME: 1”, 1 ½”, 2”, 3” or
4”
DN 25, 40, 50, 80 or
100
n/a • 316L1stainless steel
• Ceramic isolators
1. Or 1.4404 material.
Active
Shield
Length Minimum insertion length
Threaded Flanged Rod version Cable
version
High Temp.
version
Standard
length 125 mm/4.92” 105 mm/4.13” 350 mm/13.78” 500 mm/19.69” 350 mm/13.78”
Extended
shield 250 mm/9.84” 230 mm/9.06” 500 mm/19.69” 1000 mm/40” 500 mm/19.69”
Extended
shield 400 mm/15.75” 380 mm/14.96” 750 mm/29.53” 1000 mm/40” 750 mm/29.53”

Page 12 Pointek CLS200/300 Digital – OPERATING INSTRUCTIONS 7ML19985JJ03
mmmmm
Specifications
Enclosure
• termination removable terminal block, 2.5 mm2 max.
• construction powder-coated aluminum with gasket
• optional thermal isolator 316L1stainless steel
• cable entry 2 x M20 thread (option: 1 x 1/2” NPT with adaptor,
and 1 x plugged entry)
• ingress protection Type 4 / NEMA 4 / IP65 standard, IP68 optional
Weight
Weight varies based on configuration. For example:
• compact Pointek CLS200, 1 kg (2.20 lb.) approx.
100 mm (4”) insertion length,
¾” process connection
Environmental
• location indoor/outdoor
• altitude 5000 m (16,405 ft.) max.
• ambient temperature –40 to 85 °C (–40 to 185 °F), (in potentially explosive
atmospheres, note the temperature classes)
• LUI (local user interface) –30 to 85 °C (–22 to 185 °F)
• storage temperature –40 to 85 °C (–40 to 185 °F)
• relative humidity suitable for outdoor (Type 4 / NEMA 4 / IP65 standard,
IP68 optional)
• installation category I
• pollution degree 4
Process
• relative dielectric 1.5 minimum
constant (εr)
•CLS200 temperature:2
- without thermal isolator –40 to 85 °C (–40 to 185 °F)
- with thermal isolator –40 to 125 °C (–40 to 257 °F)
1. Or 1.4404 material.
Note: The use of approved watertight conduit hubs/glands is required for Type 4 /
NEMA 4, Type 6 / NEMA 6, IP68 (outdoor applications). For CE requirements the use
of EMC rated cable entries is required for all CLS200 devices.
Note: Please see Pointek CLS200 Digital Pressure versus Temperature Curves on
page 78 and Pointek CLS300 Digital Pressure versus Temperature Curves on page 80.
2. at process connection

7ML19985JJ03 Pointek CLS200/300 Digital – OPERATING INSTRUCTIONS Page 13
mmmmm
Specifications
•CLS200 pressure (vessel):
- rod version –1 to 25 bar g/–14.6 to 365 psi g (nominal)
- cable version –1 to 10 bar g/–14.6 to 150 psi g (nominal)
- sliding coupling version –1 to 10 bar g/–14.6 to 150 psi g (nominal)
•CLS300 temperature:1
- rod/cable version –40 to 200°C (–40 to 392 °F)
- high temperature version –40 to 400 °C (–40 to 752 °F)
•CLS300 pressure (vessel): –1 to 35 bar g/–14.6 to 511 psi g (nominal)
Approvals
CLS200
• General Purpose CSA, FM, CE, C-TICK
• Flameproof Enclosure ATEX II 1/2 G EEx d[ia] IIC T6...T4
with IS Probe ATEX II 1/2 D T100°C
• Dust Ignition Proof ATEX II 1/2 D T100°C
with IS Probe CSA/FM Class II, Div. 1, Gr. E, F, G
CSA/FM Class III T4
• Explosion Proof Enclosure CSA/FM Class I, Div. 1, Gr. A, B, C, D
with IS Probe CSA/FM Class II, Div. 1 Gr. E, F, G
CSA/FM Class III T4
• Intrinsically Safe2ATEX II 1 G EEx ia IIC T6...T4
ATEX II 1/2 D IP6X T100°C
CSA/FM Class I, Div. 1, Gr. A, B, C, D
CSA/FM Class II, Div. 1, Gr. E, F, G
CSA/FM Class III T4
• Non-incendive CSA/FM Class I, Div. 2, Gr. A, B, C, D
CSA/FM Class II, Div. 2, Gr. F, G
CSA/FM Class III T4 or T6
• Non-Sparking ATEX II 3 G Ex nA II T6...T4
ATEX II 2 D IP6X T100°C
• Marine Lloyds Register of Shipping, Categories ENV1,
ENV2 and ENV5
• Others Pattern Approval (China)
1. at process connection
2. barrier or Intrinsically Safe power supply required for Intrinsically Safe protection
Note: EN 61326 (CE EMC) testing was conducted on the Pointek CLS200 while
mounted in a metallic vessel and wired using shielded cable, where the cable was
terminated in an EMC cable gland at the device entry point. In addition, units with a
flange process connection were mounted using a metallic gasket.

Page 14 Pointek CLS200/300 Digital – OPERATING INSTRUCTIONS 7ML19985JJ03
mmmmm
Specifications
CLS300
• General Purpose CSA, FM, CE, C-TICK
• Dust Ignition Proof ATEX II 1/2 D, 2 D IP6X T100°C
• Dust Ignition Proof CSA/FM Class II, Div. 1, Gr. E, F, G
with IS Probe CSA/FM Class III T4
• Flameproof Enclosure ATEX II 1/2 G EEx d[ia] IIC T6...T4
with IS Probe ATEX II 1/2 D T100°C
• Explosion Proof CSA/FM Class I, Div. 1, Gr. A, B, C, D
with IS Probe CSA/FM Class II, Div. 1, Gr. E, F, G
CSA/FM Class III T4
• Intrinsically Safe1ATEX II 1 G EEx ia IIC T6...T4
ATEX II 1/2 D, 2 D IP6X T100°C
CSA/FM Class I, Div. 1, Gr. A, B, C, D
CSA/FM Class II, Div. 1, Gr. E, F, G
CSA/FM Class III T4
• Marine Lloyds Register of Shipping, Categories ENV1,
ENV2 and ENV5
• Others Pattern Approval (China)
1. barrier or Intrinsically Safe power supply required for Intrinsically Safe protection
Note: EN61326 (CE EMC) testing was conducted on the Pointek CLS300 while
mounted in a metallic vessel and wired using shielded cable. Units with flange
process connections were tested while mounted in a metallic vessel with a metallic
gasket and with shielded cables.
