Siemens SIMATIC RTLS Series User manual

SIMATIC RTLS
Localization systems
SIMATIC RTLS4030T
Operating Instructions
06/2020
C79000
-G8976-C520-03
Introduction
1
Device description
2
Installation & Operation
3
Technical specifications
4
Approvals
5

Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
C79000-G8976-C520-03
Ⓟ
06/2020 Subject to change
Copyright © Siemens AG 2020.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury
may
result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SIMATIC RTLS4030T
Operating Instructions, 06/2020, C79000-G8976-C520-03 3
Table of contents
1 Introduction............................................................................................................................................. 5
2 Device description................................................................................................................................... 9
2.1 Characteristics ..........................................................................................................................9
2.2 Order data RTLS4030T ............................................................................................................9
2.3 LED status indicator..................................................................................................................9
2.4 Dimension drawing .................................................................................................................10
3 Installation & Operation......................................................................................................................... 11
3.1 Notes on installation................................................................................................................11
3.2 Cleaning and maintenance .....................................................................................................12
4 Technical specifications ........................................................................................................................ 13
5 Approvals.............................................................................................................................................. 15

Table of contents
SIMATIC RTLS4030T
4Operating Instructions, 06/2020, C79000-G8976-C520-03

SIMATIC RTLS4030T
Operating Instructions, 06/2020, C79000-G8976-C520-03 5
Introduction
1
Purpose of the Operating Instructions
These operating instructions support you when installing and connecting up the SIMATIC
RTLS4030T device.
The configuration and the integration of the devices in a network are not described in these
operating instructions.
Validity of the Operating Instructions
These operating instructions apply to the following device:
●RTLS4030T (CE; article number: 6GT2700-3DA03)
●RTLS4030T (FCC/NOM; article number: 6GT2700-3DA13)
●RTLS4030T (CMIIT; article number: 6GT2700-3DA23)
Further documentation
The system manual "Commissioning SIMATIC RTLS" provides information on other
SIMATIC RTLS products that you can operate together with the devices in this product line
in an Industrial Ethernet network.
You can find the system manual at the following link:
(https://support.industry.siemens.com/cs/us/en/ps/25277)
Trademarks
The following and possibly other names not identified by the registered trademark sign ®are
registered trademarks of Siemens AG:
SIMATIC RTLS

Introduction
SIMATIC RTLS4030T
6Operating Instructions, 06/2020, C79000-G8976-C520-03
Industry Online Support
In addition to the product documentation, the comprehensive online information platform of
Siemens Industry Online Support offers support at the following Internet address:
(https://support.industry.siemens.com/cs/start?lc=en-US)
Apart from news, there you will also find:
●Project information: Manuals, FAQs, downloads, application examples etc.
●Contacts, Technical Forum
●The option submitting a support query: (https://support.industry.siemens.com/My/us/en/)
●Our service offer:
Right across our products and systems, we provide numerous services that support you
in every phase of the life of your machine or system - from planning and implementation
to commissioning, through to maintenance and modernization.
You will find contact information on the Internet at the following address:
(https://www.automation.siemens.com/aspa_app/?ci=yes&lang=en)
SITRAIN - Training for Industry
The training offer includes more than 300 courses on basic topics, extended knowledge and
special knowledge as well as advanced training for individual sectors - available at more
than 130 locations. Courses can also be organized individually and held locally at your
location.
You will find detailed information on the training curriculum and how to contact our customer
consultants at the following Internet address:
(https://new.siemens.com/global/en/products/services/industry/sitrain/personal.html)
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be
connected to an enterprise network or the internet if and to the extent such a connection is
necessary and only when appropriate security measures (e.g. firewalls and/or network
segmentation) are in place.
For additional information on industrial security measures that may be implemented, please
visit: (https://new.siemens.com/global/en/company/topic-areas/future-of-
manufacturing/industrial-security.html)
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customers’ exposure
to cyber threats.

Introduction
SIMATIC RTLS4030T
Operating Instructions, 06/2020, C79000-G8976-C520-03 7
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under: (https://support.industry.siemens.com/cs/us/en/ps/15247/pm)
Recycling and disposal
The products are low in harmful substances, can be recycled and meet the requirements of
the Directive 2012/19/EU for disposal of waste electrical and electronic equipment (WEEE).
Do not dispose of the products at public disposal sites.
For environmentally compliant recycling and disposal of your electronic waste, please
contact a company certified for the disposal of electronic waste or your Siemens
representative.
Note the different national regulations.

Introduction
SIMATIC RTLS4030T
8Operating Instructions, 06/2020, C79000-G8976-C520-03

SIMATIC RTLS4030T
Operating Instructions, 06/2020, C79000-G8976-C520-03 9
Device description
2
2.1 Characteristics
SIMATIC RTLS4030T
Characteristics
Design
①
Status indicators (LED)
②
Battery compartment
General The transponder is the mobile device for locali-
zation in the RTLS localization system. It sends
position data to gateways which transmit the
data to the Locating Manager server.
Area of application The device is suitable only for use in indoors.
2.2 Order data RTLS4030T
Table 2- 1 Order data RTLS4030T
Article number
SIMATIC RTLS4030T
including 1 x battery CR123A
Packaging unit: 5 items (including 5 batteries)
CE
6GT2700-3DA03
FCC/NOM 6GT2700-3DA13
CMIIT
6GT2700-3DA23
2.3 LED status indicator
The operating states of the transponder are indicated by the LED. These can assume the
states from and briefly light up .
LED
Meaning
Red LED is off when the transponder is in operation
Lights up red briefly when the transponder is in transition from idle state to
movement
Red LED lights up for 0.6 seconds at system startup

Device description
2.4 Dimension drawing
SIMATIC RTLS4030T
10 Operating Instructions, 06/2020, C79000-G8976-C520-03
2.4 Dimension drawing
Figure 2-1 Dimension drawing SIMATIC RTLS4030T - All dimensions specified in millimeters

SIMATIC RTLS4030T
Operating Instructions, 06/2020, C79000-G8976-C520-03 11
Installation & Operation
3
3.1 Notes on installation
Note
Before you install the devices, read this section carefully to ensure trouble
-free installation
and commissioning.
The devices can only be used in conjunction with the RTLS localization system. The radio
address of the RTLS4030T can be obtained from the data matrix code printed on the device.
Mount the device so that it has a direct line-of-sight connection to the gateways (360°
panorama view). Any type of material can impact wireless localization. Wireless localization
through metal is not possible. In this case, localization via wireless reflections can occur
which results in an inaccurate localization.
Check the device for damages before you use it so that it is not damaged during operation.
The specified operating temperature ranges must be observed.
The device contains a lithium battery.
CAUTION
Fires and burns
Improper handling of batteries can lead result in fires and burns.
The housing of the device must not be squashed, punctured or exposed to other mechanical
influences. It may only be opened to change batteries.
Never expose the device to fire, temperatures above 50 °C or direct sunlight for an extended
period of time.
In dry environments the device battery must be replaced.

Installation & Operation
3.2 Cleaning and maintenance
SIMATIC RTLS4030T
12 Operating Instructions, 06/2020, C79000-G8976-C520-03
Assembling the transponder prior to starting up
Proceed as follows to assemble the transponder prior to starting up:
1. Insert the battery in the battery compartment according to the polarity direction.
2. Close the housing by first placing the top part into the bottom housing and letting it
engage on the bottom.
CAUTION
Remove the battery before returning the device
Remove the battery before returning the device. Batteries must not be returned.
Battery change
CAUTION
Use approved batteries
Installation of non-approved or damaged batteries may result in damage to the device or its
surroundings. Only use batteries approved by the manufacturer, see section "Technical
specifications (Page 13)". Before inserting a battery, make sure that it is not damaged.
Proceed as follows to replace the battery in the transponder:
1. Open the housing at the designated recess on the left-hand side in an upwards direction
using a suitable tool.
2. Remove the battery to be replaced and wait 30 seconds before inserting the new battery
while maintaining the polarity direction.
3. Close the housing again until you hear it click into place.
3.2 Cleaning and maintenance
The enclosure may only be opened to change batteries.
The device may only be repaired or opened for other types of work by an authorized
maintenance company.
Improper opening or repairing of the device may result in risks for the user. Opening the
device without permission renders the warranty of the Siemens AG null and void.
Do not clean the enclosure with liquids or abrasive, caustic or flammable cleaning products.

SIMATIC RTLS4030T
Operating Instructions, 06/2020, C79000-G8976-C520-03 13
Technical specifications
4
Table 4- 1 Technical specifications of the transponder RTLS4030T
6GT2700-3DA03, 6GT2700-3DA13
6GT2700-3DA23
Product name
SIMATIC RTLS4030T
PULSE radio frequencies (localization)
Wireless method
IEEE 802.15.4-2015 UWB HRP PHY
Transmission speed
850 Kbps
Operating frequency rated value 3993.6 MHz (UWB channel 2; CE, FCC/NOM)
6489.6 MHz (UWB channel 5; CE, FCC/NOM, CMIIT)
Bandwidth
499.2 MHz
Frequency range 3100 MHz ... 4800 MHz (CE, FCC/NOM)
6000 MHz ... 7000 MHz (CE, FCC/NOM, CMIIT)
Transmit power
0.037 mW (-41.3 dBm/MHz)
Range
Maximum 30 m
Accuracy of the localization (typical) 0.2 m
Antennas
Built-in UWB antenna
PHASE radio frequencies (communication and optional localization)
Wireless method
IEEE 802.15.4
Transmission speed
1 Mbit/s
Operating frequency rated value
2400 ... 2480 MHz ISM band
Bandwidth 2 MHz; data transmission on 802.15.4; channels configura-
ble
Frequency range
2400 MHz ... 2483.5 MHz
Transmit power
Maximum 4 dBm (configurable)
Range
Maximum 50 m
Accuracy of the localization (typical)
1 m
Antennas
Built-in 2.4 GHz antenna
Supply voltage
Supply voltage Battery CR123A: 3 V Lithium rechargeable
Brand: VARTA (1550 mAh) or Panasonic (1400 mAh)
Service life (at 20 ℃) Standby: 1 year
Operation: 100 % UWB localization with 1 second: 6 months

Technical specifications
SIMATIC RTLS4030T
14 Operating Instructions, 06/2020, C79000-G8976-C520-03
6GT2700-3DA03, 6GT2700-3DA13
6GT2700-3DA23
Permitted ambient conditions
Ambient temperature
•During write/read access
•Outside write/read access
•During storage
•-10 ... +50 °C
•-10 ... +50 °C
•-10 ... +50 °C
Design, dimensions, weights and connectors
Dimensions (L x W x H)
89 x 29 x 30 mm
Weight
90 g (incl. battery)
Degree of protection
IP54
Method of securing
2 screws M2.5 or cable ties
Enclosure
Plastic housing
Color
Anthracite

SIMATIC RTLS4030T
Operating Instructions, 06/2020, C79000-G8976-C520-03 15
Approvals
5
You can find the current EU Declaration of Conformity for these products on the Internet at
Siemens Industry Online Support.
Link:
(https://support.industry.siemens.com/cs/products?dtp=Certificate&mfn=ps&pnid=14970&lc=
en-US)
The products described in this document meet the requirements of the following EU
directives:
●RoHS Directive 2011/65/EU
Directive of the European Parliament and of the Council of 8 June 2011 on the restriction
of the use of certain hazardous substances in electrical and electronic equipment, official
journal of the EU L174, 1 July 2011, pages 88-110
●Radio Equipment Directive 2014/53/EU (RED)
Directive of the European Parliament and of the Council of 16 April 2014 on the
harmonization of the laws of the member states relating to placing radio equipment on the
market; official journal of the EU L153, 22 May 2014, pages 62-106
RoHS directive (restriction of the use of certain hazardous substances)
The products described in these operating instructions meet the requirements of the EU
directive 2011/65/EU on the restriction of the use of certain hazardous substances in
electrical and electronic equipment.
Applied standard:
●EN 50581
Technical documentation for the assessment of electrical and electronic products with
respect to restriction of hazardous substances
The products described in this document meet the requirements of the applied standards:
Article 3 (1) a) Protection of health and safety
●EN 62368-1
Equipment for audio/video, information and communication technology – Part 1: Safety
requirements
●EN 62311
Assessment of electronic and electrical equipment related to human exposure restrictions
in electromagnetic fields (0 Hz - 300 GHz)
The products described in these operating instructions meet the requirements of EU directive
2014/30/EU "Electromagnetic Compatibility" according to the designated standards for the
following areas of application.

Approvals
SIMATIC RTLS4030T
16 Operating Instructions, 06/2020, C79000-G8976-C520-03
Article 3 (1) b) EMC
●ETSI EN 301 489-1
Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic
compatibility for radio equipment and services - Part 1: Common technical requirements
●ETSI EN 301 489-17
Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic
compatibility for radio equipment and services - Part 17:
Specific conditions for broadband data transmission systems
●ETSI EN 301 489-33
Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic
compatibility for radio equipment and services - Part 33:
Special conditions for ultra-wideband (UWB) devices
●EN 55011
Industrial, scientific and medical equipment - Radio-frequency disturbance
characteristics – Limits and methods of measurement
●EN 55032 Class A, Class B
Electromagnetic compatibility of multimedia equipment – Emission requirements
●EN 55035
Electromagnetic compatibility of multimedia equipment - Immunity requirements
●EN 61000-6-1
Electromagnetic compatibility (EMC) - Part 6-1: Generic standards - Immunity for
residential, commercial and light-industrial environments
●EN 61000-6-2
Electromagnetic compatibility (EMC) - Part 6-2: Generic standards - Immunity for
industrial environments
●EN 61000-6-3
Electromagnetic compatibility (EMC) - Part 6-3: Generic standards - Emission standard
for residential, commercial and light-industrial environments
●EN 61000-6-4
Electromagnetic compatibility (EMC) - Part 6-4: Generic standards - Emission standard
for industrial environments

Approvals
SIMATIC RTLS4030T
Operating Instructions, 06/2020, C79000-G8976-C520-03 17
Article 3 (2) Efficient use of the radio spectrum
●ETSI EN 300 328
Wideband transmission systems; Data transmission equipment operating in the 2.4 GHz
ISM band and using wide band modulation techniques. Harmonized standard covering
the essential requirements of article 3.2 of the EU Directive 2014/53/EU
●ETSI EN 302 065-2
Short Range Devices (SRD) using ultra-wideband technology (UWB); Harmonized
standard covering the essential requirements of article 3.2 of the Directive 2014/53/EU;
Part 2: Requirements for UWB location tracking
Note
The specified approvals are only valid if the corresponding symbol is printed on the
device.
FCC information
Siemens SIMATIC RTLS4030T (MLFB 6GT2700-3DA13); FCC ID SCF4030T01
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Caution
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
NOM información
Siemens SIMATIC RTLS4030T (MLFB 6GT2700-3DA13); IFT RCPSIRT19-1566
La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que
este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo
debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no
deseada.
